C O M M U N I C A T I O N S
the activity of bCD-PLL remained nearly unaffected throughout
the remaining 4 day incubation. We hypothesize that, like poly-
(
ethylene glycol) (PEG),16 the attached polylysine in bCD-PLL
may produce a steric exclusion space that prevents the proteolysis
of bCD by proteases such as cathepsins and matrix metallopro-
teinases (MMPs) that are overexpressed in highly invasive cancer
cell lines, such as MDA-MB-231.17
In summary, we have developed a novel cancer therapeutic
enzyme labeled with multimodal imaging reporters demonstrating
high relaxivity, low cytotoxicity, improved enzymatic specificity
to prodrug, efficient cell uptake, and high enzymatic stability in
serum as well as in breast cancer cell culture. This conjugate is the
first prototype for noninvasive image-guided enzyme/prodrug cancer
therapy. In vivo studies of this conjugate in tumor xenograft models
are currently underway.
Figure 1. (A) In vitro cytotoxicity of bCD, PLL, and bCD-PLL in a human
breast cancer cell line, MDA-MB-231, acquired from an MTT assay at a
dose of 4.3 µM that will be used for in vivo studies. Standard deviations
are shown with error bars (n ) 4); // indicates statistical significance at
levels of p < 0.01 for the PLL or bCD versus control. (B) Internalization
of bCD-PLL within MDA-MB-231 cells after treatment with bCD-PLL
(
100 ng/mL) for 30 min. Rhodamine fluorescence is shown in red, and
nuclei counterstained with DAPI are displayed in blue.
Acknowledgment. This work was supported by NIH P50
CA103175 (JHU ICMIC Program). We thank Dr. Barry Stoddard
of the Fred Hutchinson Cancer Research Center for providing the
pET-bCD expression vector. We thank Dr. Michal Neeman, Dr.
Venu Raman, and Dr. Peter Senter for helpful discussions. We thank
Dr. Maria Mikhaylova for her assistance with the DLS and ICP-
AES studies. We gratefully acknowledge the support of Dr.
Jonathan S. Lewin.
Supporting Information Available: Synthesis and characterization
of the bCD-PLL conjugate, kinetic studies, in vitro cytotoxicity and
cell uptake studies, enzymatic stability studies in serum, and cell culture.
This material is available free of charge via the Internet at http://
pubs.acs.org.
Figure 2. (A) Relative cell viability of MDA-MB-231 cells after incubation
with therapeutic enzyme (0.13 µM) for 0-72 h following additional 5 day
treatment with prodrug 5FC (1.5 mg/mL). (B) Dynamic enzymatic activity
of bCD and bCD-PLL in fresh mouse serum at 37 °C. Enzymatic activity
was measured in 0.5 mM cytosine, Tris-HCl (50 mM), pH 7.5, 25 °C.
Standard deviations are shown with error bars (n ) 4).
mise its enzymatic activity. In fact, compared to bCD, bCD-PLL
References
demonstrated a slightly increased preference to 5FC relative to
(1) (a) Xu, G.; McLeod, H. L. Clin. Cancer Res. 2001, 7, 3314-3324. (b)
Bagshawe, K. D.; Sharma, S. K.; Burke, P. J.; Melton, R. D.; Knox, R.
J. Curr. Opin. Immunol. 1999, 11, 579-583.
m
cytosine with higher kcat and kcat/K values. The relative enzymatic
specificity11 of bCD-PLL to 5FC was determined to be 0.021,
while the value was 0.018 for bCD.
(2) Niculescu-Duvaz, I.; Springer, C. J. AdV. Drug DeliVery ReV. 1997, 2,
1
51-172.
(
3) (a) Ireton, G. C.; McDermott, G.; Black, M. E.; Stoddard, B. L. J. Mol.
Biol. 2002, 315, 687-697. (b) Ireton, G. C.; Black, M. E.; Stoddard, B.
L. Acta Crystallogr., Sect. D 2001, 57, 1643-1645.
The cytotoxicity of bCD-PLL in a human breast cancer cell
line, MDA-MB-231, was studied using an MTT assay.13 The
concentrations used were derived from estimates to generate 165
mg/kg of 5FU typically used to treat experimental tumors in vivo.14
Both PLL and bCD exhibited moderate toxicity with a relative cell
viability of 84 and 82% after 5 days incubation (Figure 1A), whereas
no obvious cytotoxicity was detected for bCD-PLL. Fluorescence
microscopy showed that bCD-PLL can be internalized by MDA-
MB-231 cells efficiently even after a 30 min treatment (Figure 1B).
(
4) Mahan, S. D.; Ireton, G. C.; Stoddard, B. L.; Black, M. E. Biochemistry
2
004, 43, 8957-8964.
(5) Mahan, S. D.; Ireton, G. C.; Knoeber, C.; Stoddard, B. L.; Black, M.
Protein Eng. Des. Sel. 2004, 17, 625-633.
(
6) Uzgiris, E. E. InVest. Radiol. 2004, 39, 131-137.
(7) Dafni, H.; Gilead, A.; Nevo, N.; Eilam, R.; Harmelin, A.; Neeman, M.
Magn. Reson. Med. 2003, 50, 904-914.
(
8) Aboagye, E. O.; Artemov, D.; Senter, P. D.; Bhujwalla, Z. M. Cancer
Res. 1998, 58, 4075-4078.
(
9) (a) Jain, R. K. J. Controlled Release 2001, 74, 7-25. (b) Yuan, F.; Dellian,
M.; Fukumura, D.; Leunig, M.; Berk, D. A.; Torchilin, V. P.; Jain, R. K.
Cancer Res. 1995, 55, 3752-3756.
The PLL moiety may facilitate the cell uptake of bCD-PLL through
polycation-mediated endocytosis.15
(10) Aime, S.; Botta, M.; Fasano, M.; Terreno, E. Chem. Soc. ReV. 1998, 27,
1
9-29.
The enzymatic stability of bCD-PLL was tested on cultured
tumor cells. Briefly, MDA-MB-231 cells were incubated with
various concentrations (0.13-4.3 µM) of bCD-PLL for 0, 2, 8,
(11) (a) Ipata, P. L.; Cercignani, G. Methods Enzymol. 1978, 51, 395-400.
(
b) Hayden, M. S.; Linsley, P. S.; Wallace, A. R.; Marquardt, H.; Kerr,
D. E. Protein Expr. Purif. 1998, 12, 173-184.
(
12) Cornish-Bowden, A. Fundamentals of Enzyme Kinetics; Portland Press
Ltd: London, 1995; pp 30-37.
2
4, 48, and 72 h before the addition of 5FC. At the end of 5 days
of prodrug treatment, the relative cell viabilities were evaluated
Figure S8). The bCD-PLL remained capable of converting
sufficient 5FC to 5FU to cause 90% cell death at all concentrations
0.13-4.3 µM) and incubation periods (0-72 h). However, bCD
(
13) For detailed information about MTT assay, see: Li, C.; Greenwood, T.
R.; Bhujwalla, Z. M.; Glunde, K. Org. Lett. 2006, 8, 3623-3626.
(
(14) Aboagye, E. O.; Bhujwalla, Z. M.; Shungu, D. C.; Glickson, J. D. Cancer
Res. 1998, 58, 1063-1067.
(
(
(
15) Hong, S.; Leroueil, P. R.; Janus, E. K.; Peters, J. L.; Kober, M. M.; Islam,
M. T.; Orr, B. G.; Baker, J. R., Jr.; Banaszak Holl, M. M. Bioconjugate
Chem. 2006, 17, 728-734.
(
exhibited enzymatic stability lower than that of bCD-PLL as
indicated by the increased cell viability observed at the longer time
points with low bCD concentrations (Figure 2A). The enzymatic
stability of bCD-PLL was further studied in fresh mouse serum
at 37 °C (Figure 2B). Significantly, while bCD lost about 60% of
its cytosine metabolizing capability in the initial 20 h incubation,
16) (a) Harris, J. M.; Chess, R. B. Nat. ReV. Drug DiscoVery 2003, 2, 214-
221. (b) Veronese, F. M.; Harris, J. M. AdV. Drug DeliVery Syst. 2002,
5
4 (4), whole issue.
17) (a) Ishibashi, O.; Mori, Y.; Kurokawa, T.; Kumegawa, M. Cancer Biochem.
Biophys. 1999, 17, 69-78. (b) Munoz-Najar, U. M.; Neurath, K. M.;
Vumbaca, F.; Claffey, K. P. Oncogene 2006, 25, 2379-2392.
JA066199I
J. AM. CHEM. SOC.
9
VOL. 128, NO. 47, 2006 15073
