Ketoprofen-based ionic liquids: Synthesis and interactions with bovine serum albumin

Article abstract of DOI:10.3390/molecules25010090

The development of ionic liquids based on active pharmaceutical ingredients (API-ILs) is a possible solution to some of the problems of solid and/or hydrophobic drugs such as low solubility and bioavailability, polymorphism and an alternative route of administration could be suggested as compared to the classical drug. Here, we report for the first time the synthesis and detailed characterization of a series of ILs containing a cation amino acid esters and anion ketoprofen (KETO-ILs). The affinity and the binding mode of the KETO-ILs to bovine serum albumin (BSA) were assessed using fluorescence spectroscopy. All compounds bind in a distance not longer than 6.14 nm to the BSA fluorophores. The estimated binding constants (KA) are in order of 10⁵ L mol^-1, which is indicative of strong drug or IL-BSA interactions. With respect to the ketoprofen-BSA system, a stronger affinity of the ILs containing l-LeuOEt, l-ValOBu, and l-ValOEt cation towards BSA is clearly seen. Fourier transformed infrared spectroscopy experiments have shown that all studied compounds induced a rearrangement of the protein molecule upon binding, which is consistent with the suggested static mechanism of BSA fluorescence quenching and formation of complexes between BSA and the drugs. All tested compounds were safe for macrophages.

Full text of DOI:10.3390/molecules25010090

molecules
Article
Ketoprofen-Based Ionic Liquids: Synthesis and
Interactions with Bovine Serum Albumin
Paula Ossowicz 1 , Proletina Kardaleva , Maya Guncheva * , Joanna Klebeko ,
Ewelina Swia˛tek , Ewa Janus
2
2,
1
´
1
1
, Denitsa Yancheva 2 and Ivan Angelov 2
1
Department of Chemical Organic Technology and Polymeric Materials, Faculty of Chemical Technology and
Engineering, West Pomeranian University of Technology, Piastów Ave. 42, 71-065 Szczecin, Poland;
paula.ossowicz@zut.edu.pl (P.O.); joanna.klebeko@gmail.com (J.K.); ewelinaswiatek94@gmail.com (E.S.);
´
ejanus@zut.edu.pl (E.J.)
2
Institute of Organic Chemistry with Centre of Phytochemistry, Bulgarian Academy of Sciences,
Acad. G. Bonchev Str. Bl. 9, 1113 Sofia, Bulgaria; pkardaleva@orgchm.bas.bg (P.K.);
deni@orgchm.bas.bg (D.Y.); ipangelov@orgchm.bas.bg (I.A.)
Correspondence: maiag@orgchm.bas.bg
*
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
Received: 25 November 2019; Accepted: 23 December 2019; Published: 25 December 2019
ꢀ
ꢁꢂꢃꢄꢅꢆ
Abstract: The development of ionic liquids based on active pharmaceutical ingredients (API-ILs)
is a possible solution to some of the problems of solid and/or hydrophobic drugs such as low
solubility and bioavailability, polymorphism and an alternative route of administration could be
suggested as compared to the classical drug. Here, we report for the first time the synthesis and
detailed characterization of a series of ILs containing a cation amino acid esters and anion ketoprofen
(KETO-ILs). The affinity and the binding mode of the KETO-ILs to bovine serum albumin (BSA)
were assessed using fluorescence spectroscopy. All compounds bind in a distance not longer than
5
−1
,
6
.14 nm to the BSA fluorophores. The estimated binding constants (KA) are in order of 10 L mol
which is indicative of strong drug or IL-BSA interactions. With respect to the ketoprofen-BSA system,
a stronger affinity of the ILs containing l-LeuOEt, l-ValOBu, and l-ValOEt cation towards BSA is
clearly seen. Fourier transformed infrared spectroscopy experiments have shown that all studied
compounds induced a rearrangement of the protein molecule upon binding, which is consistent with
the suggested static mechanism of BSA fluorescence quenching and formation of complexes between
BSA and the drugs. All tested compounds were safe for macrophages.
Keywords: ketoprofen; ionic liquids; bovine serum albumin; binding constants; secondary structure
1
. Introduction
Ionic liquids (ILs) are organic salts consisting of bulky organic cations and organic or inorganic
◦
anions [
1
]. In general, they are characterized by low melting temperature (<100 C), low vapor
pressure, low flammability, high thermal stability, etc. [
1
]. Their physicochemical properties can be
easily tuned by appropriate selection of the cation and the anion or an introduction of substituents in
the molecule of cation or anion. Therefore, in the last few decades, they have attracted great interest in
view of their potential diverse applications. The application of ILs in pharmaceutics and medicine is
a relatively new research area. Numerous studies have shown the potential of ILs as drug-delivery
systems, biomedical analytics, sensors, excipients, solvents and stabilizers of biomolecules, [
On the other hand, some ILs exhibit biological activities, e.g., antibacterial, antitumor, and other [
2
–
10].
6
].
7–
Further, the development of ILs based on active pharmaceutical ingredients (API-ILs), single active
liquid salts, is a possible solution of some of the problems of solid and/or hydrophobic drugs such
as low solubility and bioavailability, polymorphism and an alternative route of administration could
Molecules 2020, 25, 90; doi:10.3390/molecules25010090
www.mdpi.com/journal/molecules

Molecules 2020, 25, 90
2 of 17
be suggested as compared to the classical drug [11
,12]. In addition, ILs based on two biologically
active ions have been also investigated, e.g., ILs containing a cation with anti-bacterial or pain-reliever
properties and an anion anti-inflammatory, antibacterial, anti-pyretic activity, or wetting agents and
emollients [13,14]. They have the advantage to retain the biological activities inherited from the two
API-precursors [11,15].
ILs based on a non-steroidal anti-inflammatory drug such as ibuprofen (Ibu), naproxen, and
ketoprofen (KETO) have been in the focus of recent investigations. Santos et al. proposed a novel
formulation based on ammonium, imidazolium, or pyridinium (Pyr) cations and ibuprofen anion,
which characterized with enhanced water solubility in comparison to that of the sodium ibuprofenate
(control) [16]. Except for [C16Pyr][Ibu], all the other Ibu-based ILs exhibited less cytotoxic effect to
normal human dermal fibroblasts or ovarian carcinoma (A2780) cell line in comparison to the parent
sodium ibuprofenate [16]. An enhanced topical anti-inflammatory activity was reported for a series of
ILs containing cations terpenes and anion Ibu [17]. Interestingly, Ibu- based ILs containing cations
ranitidinium or diphenhydraminium exhibited activity against Candida sp., which was not inherited
from the parent salt—however, they are shown to be more cytotoxic to human lymphocytes [14].
Based on IL50 values estimated for the inhibition of cytochrome C oxidase, Azevedo et al. have found
that the cholinium ketoprofenate (IC50
≈
21.3 mM) produced a lower cytotoxic effect than sodium
ketoprofenate (IC50 0.0006 mM) and therefore it is considered safer [18]. On the contrary, cholinium
≈
naproxenate is more toxic than its parent sodium salt [18].
Serum albumins are the most abundant proteins in mammalian plasma responsible for the
transport of both exogenous and endogenous molecules such as hormones, steroids, fatty acids,
drugs, etc., as well as play an essential role in the maintenance of the blood oncotic pressure and
pH [19]. The bovine serum albumin (BSA) is highly homologous (76%) to human serum albumin
and is very often used as a model protein to study the mechanism of binding and interactions of
small molecules with the protein [20]. BSA is a single-chain globular heart-shaped protein composed
of three homologous domains (I, II, and III) each domain includes two subdomains (A and B). The
subdomains IIA and IIIA are responsible for drug binding [19]. The geometry of the two binding
pockets is quite different, the larger one is IIA subsite and it specifically binds molecules such as
warfarin, salicylates, penicillin, while the IIIA subdomain is narrower one and it binds ibuprofen,
ketoprofen, benzodiazepines, and some others [19]. To study the drug-serum albumins interactions is
of importance to understand pharmacokinetics and pharmacodynamics of the drugs, i.e., to reveal the
factors affecting their absorption, distribution, metabolism, and excretion of the drugs.
To the best of our knowledge, besides the paper of Azevedo et al., no other reports on
the KETO-based ILs have been published [18]. Here, we report the synthesis, identification, and
characterization of a series of ILs containing as a cation the amino acid ester and an anion KETO.
Considering the information from the literature on the low toxicity of ethyl esters of non-polar amino
acids, we made the selection of the structure of L-valine and L-leucine esters as the cation [21]. Apart
from the ethyl esters of these amino acids, for L-valine we have also obtained esters with longer chain
alcohols. Our primary goal was to investigate the interaction of the KETO-ILs with BSA. We assessed
the affinity and the binding mode of the KETO-ILs to BSA using fluorescence spectroscopy. The effect
of the compounds on the conformation of BSA was monitored using Fourier transformed infrared
spectroscopy (FTIR). The cytotoxicity of the compounds against the murine macrophage cell line (RAW
2
2
2
64.7) was evaluated.
. Results
.1. Synthesis of the Amino-Acid Ester-Ketoprofenate
Using a three-step method, we synthesized five novel ketoprofen-based ILs containing cation
amino acid esters (Scheme 1).

Molecules 2020, 25, 90
3 of 17
Scheme 1. General synthetic procedure for [AAOR][KETO].
To assess the impact of the chain-length of the alcohol on BSA-IL interactions, four of the selected
for the synthesis compounds were esters of l-valine (Val) with various alcohols (ethanol, propanol,
isopropanol, and butanol). The ethyl ester of l-leucine was also obtained in order to evaluate the effect
of the size of the amino acid side chain on the biological activity and protein IL interactions. Besides,
short-chain esters of non-polar amino acids were expected to be not cytotoxic to cells. This assumption
is based on the reported in the literature low toxicity of salicylic acid-based ILs having cation l-alanine
ethyl ester or l-leucine ethyl ester on human cervical cancer cells (HeLa) and murine fibroblasts
(
L929), for which the determined IC50 values were in the millimolar range [21]. The compounds
1
13
were obtained in high yields (90–95%) and were identified in detail by H-NMR, C-NMR, FTIR
and elemental analysis (See Section 3 and Figures S1–S32, Supplementary Materials). These analyses
confirmed that synthesized compounds are organic salts with amino acid cation and ketoprofenate
anion. The NMR spectra clearly show signals for the protonated NH group of the amino acid,
2
with a chemical shift in the range between 4.84 for [L-ValOPr][KETO] to 6.67 for [l-LeuOEt][KETO],
for which the integration corresponds to three protons. Another piece of evidence is the presence of
−
1
strong bands at ca. 1570 and 1390 cm in FTIR spectra, assigned to the symmetric and asymmetric
−
−
stretching vibrations of carboxylate anion v(COO )sym. and v(COO )as., respectively [22,23]. In
addition, the performed spectroscopic analyses completely exclude the formation of an imine between
the ketoprofen carbonyl group and the amino group of amino acid, which literature has reported for
ketoprofen and isoniazid [24]. On the 13C-NMR spectra of all obtained KETO-ILs, there is not observed
the characteristic signal for imine with a chemical shift between 162 and 164 ppm. Moreover, in FTIR
spectra there are not the characteristic bands for Schiff bases, neither the vibrational band of N–H at
−
1
−1
3
355 cm nor C=N stretching vibration band at 1657 cm [25].
◦
KETO-ILs are solids with melting points below 100 C, which within the series, decreases with
increasing the alkyl chain-length in the ester group of the amino acid cation (Table 1). Among the
synthesized ketoprofen salts, the derivative obtained by pairing with L-leucine ethyl ester had the
◦
highest melting point (m.p. 94.23 C), which was higher than for the parent acid form. Melting
points of ketoprofen salts with L-valine esters characterized melting points comparable to that for
◦
choline ketoprofenate (m.p. 62–65 C) demonstrated by Ribeiro et al. [26]. Tetrabutylammonium salt
of ketoprofen is also known from the literature [27], but authors had not given the melting point of
that. According to the confirmed definition, the synthesized KETO-ILs can be qualified as the protic
ionic liquids [28].
Table 1. The melting points and thermal stability of ketoprofen and its amino acid ester derivatives.
◦
◦
[α]λT
[M]λT
Compound
Colour
Tm ( C)
Tonset ( C)
[
[
l-LeuOEt][KETO]
l-ValOEt][KETO]
white
white
white
white
white
white
94.23
63.55
58.59
60.09
58.75
92.17
95.7
100.4
69.4
52.3
101.1
265.4
+7.739
+4.679
+8.083
+5.455
+4.167
0
32.002
+18.690
+33.426
+22.559
+17.819
0
[
[
l-ValOiPr][KETO]
[
l-ValOPr][KETO]
l-ValOBu][KETO]
KETO
T
m
—melting point; Tonset—the onset of the thermal degradation; [
α]
λ λ
T—specific rotation; [M] T—molar
specific rotation.

Molecules 2020, 25, 90
4 of 17
The thermal stabilities of the obtained KETO-ILs were investigated by TG. The onset temperature
of the mass loss was determined (Tonset, Table 1). The thermal degradation of received compounds
◦
takes place at the onset of the first stage. The onset temperature was in the range of 52.3–100.4 C,
◦
whereas the value for ketoprofen was 265.4 C. For this reason, the synthesized KETO-ILs showed
lower thermal stability than parent ketoprofen. No direct relationship of thermal stability was found
with the increasing length of the alkyl chain in the ester group of the amino acid cation. The highest
◦
onset temperature, close to 100 C, was demonstrated for [l-LeuOEt][KETO] and [l-ValOBu][KETO],
while the lowest was found for [l-ValOPr][KETO]. The structure of the amino acid side chain has an
only small effect on stability KETO-ILs—slightly higher stability was established for the L-valine cation
than for L-leucine. All obtained ketoprofen derivatives are chiral (two chiral center) with specific
rotation listed in Table 1.
The solubility in water and conventional organic solvents have been investigated and summarized
in Table 2. The solvents were ranked with a decreasing value of empirical polarity parameters
(
ET(30)) [29]. According to the used Vogel’s methodology for estimation of solubility, these compounds
−
1
were classified as insoluble in water, because their solubility is below 33.3333 g L . All KETO-ILs
were also insoluble in non-polar solvents such as n-hexane. Generally obtained KETO-ILs were soluble
or partly soluble in ethanol and chloroform. Most of them were insoluble or partly soluble in diethyl
ether and well soluble in toluene with the exception of [l-ValOEt][KETO].
◦
Table 2. Solubility in water and organic solvents of ketoprofen and its amino acids derivatives at 25 C.
Water Ethanol Chloroform
Ethyl-Acetate
(38.1)
Diethyl-Ether
(34.5)
Toluene
(33.9)
n-Hexane
(31.0)
Compound
(63.1)
(51.9)
(39.1)
[
[
l-LeuOEt][KETO]
l-ValOEt][KETO]
−
−
−
−
−
−
+/−
+/−
−
−
−
+/−
+
+
−
+
+
+
−
−
−
−
−
−
−
+
+
[l-ValOiPr][KETO]
[l-ValOPr][KETO]
[l-ValOBu][KETO]
KETO
+
+
+
+
+/−
+
+
−
+
+/−
−
−
+
+/−
+
Solvents were ranked with decreasing value of empirical solvent polarityarameters, E
T
(30) [23] (“+”: soluble
−
1
−1
−1
◦
>
100 g L ; “+/
−
”: partially soluble 33–100 g L ; “
−
”: insoluble <33 g L ) at the temperature 25 C by modified
Vogel’s method [30].
2
.2. Binding Constants and Binding Sites for the Interactions of Bovine Serum Albumin (BSA) with the
Ketoprofen-Based Ionic Liquids (ILs)
According to the literature, ketoprofen binds in the site 1 of domain IIA of BSA [31]. This binding
pocket is highly hydrophobic, and the binding is assisted by stacking interaction of the aromatic rings of
ketoprofen molecules with the hydrophobic amino acid residues comprising this binding site, namely
one tryptophane (Trp213), four leucines, two isoleucines, two alanines, and one phenylalanine [31].
Additionally, the carboxylic group of the ketoprofen is hydrogen-bonded with the hydroxyl group
of Tyr149, the imidazole nitrogen atoms of His241, and the guanidine group of Arg256 which ensure
strong interactions [31].
Fluorescence spectroscopy is a useful tool for the investigation of the interactions of proteins
with small molecules. The method gives information on the binding mode, binding sites, and binding
constants of small molecules to protein and can be applied for monitoring of the induced conformational
changes. The fluorescence of BSA is due to tryptophan, tyrosine, and phenylalanine residues that
present in the protein molecule. At excitation wavelength fixed at 280 nm, the fluorescence spectrum
of BSA is characterized by a strong emission band with a maximum at 355 nm.
Upon the addition of small molecules to the solution, a decrease in the BSA fluorescence may
occur. The process is typically ascribed either to the formation of a non-fluorescence-quencher complex
in the ground state, a process referred to as static quenching, or the quenching could be due to collisions
between the excited fluorophore and quencher (dynamic quenching) [32].

Molecules 2020, 25, 90
5 of 17
The emission spectra of BSA in the presence of various concentrations of ketoprofen and KETO-ILs
were recorded in the range from 300 to 500 nm (λex = 280 nm). We have observed a significant decrease
in the fluorescence intensities of the BSA fluorophores with increasing the concentration of the tested
compounds added to the BSA solution (Figure 1), which suggests binding of the tested compounds in
the protein molecule. The change in the local environment near the fluorophores was insignificant,
which is evident from the slight blue shift of the emission maxima by up to 1 or 2 nm. The fluorescence
quenching data are analyzed according to the Stern–Volmer Equation (1) [32]:
Fo
F
=
1 + kqτq [Q] = 1 + Ksv[Q],
(1)
o
where F
is quencher (KETO-IL or ketoprofen) concentration, KSV is the Stern–Volmer quenching constant, k
the bimolecular quenching constant (quenching rate constant), and τqo is the average life-time of the
o
and F is the fluorescence peak intensities in the absence and in the presence of quencher. [Q]
q
is
−8
protein without quencher, generally taken to be 10 s [33].
The obtained Ksv and K values were summarized in Table 3. The maximum scatter quenching
constant K that is due to collisions between biomolecules is 2
of BSA quenching due to KETO-ILs is greater than K of scatter procedure, therefore, we assume
q
10
−1 −1
q
×
10 L mol s [33]. The rate constant
q
that a static quenching mechanism is more likely to occur. The conclusion agrees with the report of
Bi et al., who demonstrated that the quenching mechanism of HSA by ketoprofen is static [33]. The Ksv
of binding of ketoprofen with BSA was in the same range as that reported for the ketoprofen with
HSA [33].
Figure 1. Cont.

Molecules 2020, 25, 90
6 of 17
Figure 1. Change in the fluorescence emission spectra of BSA in the presence of various concentration of
ketoprofen ( ); [l-LeuOEt][KETO] ( ); [l-ValOEt][KETO] ( ); [l-ValOiPr][KETO] ( ) [l-ValOPr][KETO]
) and [l-ValOBu][KETO] ( ) in sodium phosphate buffer (pH 7.4, 50 mM) at 25 C. The insertions
a
b
c
d
◦
(
e
f
represent the Stern–Volmer plot.
q
Table 3. Stern–Volmer quenching constants (Ksv) and bimolecular quenching rate constant (K ) of
◦
binding of ketoprofen and the ketoprofen-based ILs with BSA at 25 C.
4
−1
12
−1 −1
Compound
Ksv (10 , L mol
)
kq (10 , L mol
s
)
R
[
[
l-LeuOEt][KETO]
l-ValOEt][KETO]
8.3
6.3
7.1
7.1
7.3
8.4
8.3
6.3
7.1
7.1
7.3
8.4
0.9900
0.9948
0.9981
0.9958
0.9969
0.9953
[
l-ValOiPr][KETO]
[
[
l-ValOPr][KETO]
l-ValOBu][KETO]
KETO
R—correlation coefficient.
q
The estimated Ksv and K values are of the same order of magnitude and the structure of the
cation seems not to affect the binding properties of the active pharmaceutical ingredient (ketoprofen).
If the [AAOR][KETO] and ketoprofen bind independently to a set of equivalent sites on the BSA
molecule, the effective binding constant (K ) and the number of binding sites (n) can be calculated
A
using the following Equation (2):
Fo − F
log(
) = log K + n log[Q],
(2)
A
F
Fo−F
where F
o
, F, and [Q] have the same meaning as Equation (1). The dependence of log(
)
vs. log[Q]
F
is linear with a slope equal to the number of the binding sites, and y-intercept corresponds to the log of
the effective binding constant (K ). The estimated values of K and n are listed in Table 4 (Figure S33,
A
A
Supplementary Materials).
Table 4. Binding constants (K ) and binding sites (n) of binding of ketoprofen and the ketoprofen-based
A
◦
ILs with BSA at 25 C.
5
−1
)
Compound
l-LeuOEt][KETO]
l-ValOEt][KETO]
l-ValOiPr][KETO]
KA (10 , L mol
N
R
[
[
[
7.1
8.2
1.5
2.3
7.5
2.6
1.2
1.2
1.1
1.1
1.2
1.1
0.9972
0.9934
0.9985
0.9924
0.9988
0.9954
[
l-ValOPr][KETO]
l-ValOBu][KETO]
KETO
[
R—correlation coefficient.

Molecules 2020, 25, 90
7 of 17
5
−1
The obtained binding constants (K ) are in order of 10 L mol , which is indicative of strong
A
drug or IL-BSA interactions. With respect to ketoprofen-BSA system, a stronger affinity of the ILs
containing l-LeuOEt, l-ValOBu and l-ValOEt cation towards BSA is clearly seen.
According to the Förster theory, the nonradiative energy transfer rate (FRET) between a donor
(
BSA fluorophores) and an acceptor (Ketoprofen or KETO-ILs) depends on the extent of the overlapping
of the donor emission spectrum and the acceptor absorption spectrum, the relative orientation of the
donor and acceptor transition dipoles, as well as from the distance between the donor and acceptor.
The following equations are used to estimate the steady-state FRET parameters:
F
Fo
Ro6
E = 1 −
=
,
(3)
Ro + ro6
6
Ro = 8.8x10 K2n φJ,
6
−25
−4
(4)
(5)
P
4
F(λ)ε(λ)λ ∆λ
J =
P
,
F(λ)∆λ
where E is energy transfer efficacy, R
o
is the characteristic distance called Förster distance or critical
distance at which the energy transfer efficacy is 50%, r
and the BSA fluorophores. K is the spatial orientation factor describing the relative orientation in
the space of transition dipoles of the donor and the acceptor, K = 2/3, n is the refractive index of
o
is the distance between the quencher (drug)
2
2
the medium,
ϕ
is the fluorescence quantum yield of the donor, n = 1.33,
ϕ
= 0.13 [34]. F(
λ) is the
−1
−1
fluorescence intensity of the fluorescence of the donor,
ε(λ) (L mol cm ) is the molar absorption
coefficient of the acceptor at wavelength λ. The estimated FRET values are listed in Table 5.
Table 5. Steady-state FRET parameters of the BSA-[AAOR] [KETO] interactions.
System
Ro (nm)
EFRET
ro (nm)
BSA-[l-LeuOEt][KETO]
BSA-[l-ValOEt][KETO]
BSA-[l-ValOiPr][KETO]
BSA-[l-ValOPr][KETO]
BSA-[l-ValOBu][KETO]
BSA-KETO
3.30
3.43
3.38
3.46
3.32
3.37
0.0246
0.1830
0.0625
0.1770
0.0520
0.0630
◦
6.14
4.68
5.42
4.74
5.48
5.40
[BSA] = [Quencher] = 2 µM; T = 25 C.
o
As seen, for the ketoprofen and all KETO-ILs the donor-acceptor distance is r is less 8 nm [34],
which is in accordance with Förster’s non-radiative energy transfer theory and is a proof of that
the BSA fluorescence quenching is a result of the formation of a nonfluorescent ground state
fluorophore-compound complex, i.e., static quenching mechanism.
2
.3. Changes in the Secondary Structure of BSA upon Binding of the Ketoprofen-Based ILs
We applied FTIR spectroscopy to study the effect of KETO-ILs on the secondary structure of
−1
BSA. In the spectra of proteins, the Amide I band region (1700–1600 cm ) is mainly due to the
starching vibrations of the carbonyl group (80%) and is highly sensitive to the changes in the geometry
and the environment of the amide bonds [34]. The original spectra, the second derivative and the
deconvoluted spectra of the complexes of BSA with KETO-ILs are given in Supplementary (Figures
S34–S39). The band assignments were done according to Jackson and Mantsch and the analysis of the
structure was taken into consideration the data on the BSA available in the literature [35–37].
For each BSA-drug complex, are observed several bands having a center within 1610–1628,
−1
1
625–1640, 1640–1648, 1648–1660 and 1675–1698 cm , which are characteristic for aggregated strands,
β
-sheets (low frequency), distorted/random coils, -helices, -sheets (high frequency) or extended
α
β
conformation [35]. The Amide I band components, their relative area and the assignment for the native
BSA and its complexes with the studied compounds are given in Table 6.

Molecules 2020, 25, 90
8 of 17
Table 6. FTIR analysis of the Amide I band of BSA-[KETO][AAOR] complexes in phosphate buffer (pH 7.4, 50 mM).
Aromatic Residues/Aggregated
Strands/Antiparallel β-Sheets
α-Helices
Band Position
Relative
β-Structures
Unordered Structures
Assignment of the Secondary
Structure Components [36]
Band Position
Relative
Area (%)
Band Position
Relative
Area (%)
Band Position
Relative Area
(%)
−1
−1
−1
−1
(cm )
(cm
)
Area (%)
(cm
)
(cm
)
native BSA
BSA-KETO
BSA-[l-LeuOEt][KETO]
BSA-[l-ValOEt][KETO]
1655
1655
1655
1656
47.3
46.2
36.7
28.8
1629; 1674
1636; 1673
1628; 1673
1628; 1674
11.6; 12.9
36.2; 12.4
13.5; 13.7
22.4; 15.0
15.5; 11.2;
11.8
1642
-
1642
1643
21
-
21.5
17.25
1617
1618
1615; 1684; 1696
1607; 1698
7.1
5.2
11.6; 1.9; 1.0
14.1; 2.4
1
626; 1638;
674
BSA-[l-ValOiPr][KETO]
1658
23.8
1648
11.7
1604; 1605; 1687
2.0; 23.3; 1.0
1
BSA-[l-ValOPr][KETO]
BSA-[l-ValOBu][KETO]
1658
1656
26.9
27.8
1631; 1673
1640; 1675
19.5; 13.6
31.0; 11.8
1646
-
29.2
-
1616
1620; 1693
11.0
26.3; 1.0

Molecules 2020, 25, 90
9 of 17
As seen all studied compounds induced a rearrangement of the protein molecule upon binding,
which is consistent with the suggested static mechanism of BSA fluorescence quenching and formation
of complexes between BSA and the drugs. In the presence of ketoprofen the helical structure of
−1
the protein was preserved, however, we observed a complete loss of the band at 1943 cm , which
is ascribed to the random coils and unordered structures, in favor of the
stimulated the partial unfolding of BSA and we monitored a decrease in the
β
-structures. KETO-ILs
-helical content and an
α
increase in antiparallel β-sheets and aggregates in this BSA-IL complex. No shift of the peak positions
and very close to the native BSA conformation was observed for the BSA-[l-LeuOEt][KETO] system.
In addition, [l-ValOiPr][KETO] caused the most dramatic changes in the secondary structure, namely
a significant loss of helical structures and aggregation, which is consistent with the observed slight
lowering of the estimated binding constant. It is noteworthy to be mentioned that the conformational
changes seem not to affect the binding properties of the BSA. On the contrary, the ILs with [l-LeuOEt],
[
l-ValOEt] and [l-ValOBu] cations even exhibited slightly higher affinity to BSA.
2
.4. Cytotoxicity of the Ketoprofen-Based ILs on Murine Macrophages
The effect of ketoprofen-based ILs was evaluated in RAW 264.7 macrophages after 24 h incubation
with different concentrations of the compounds (1, 10 and 100
µM). As controls were used untreated
cells, cells treated with 1% DMSO (the solvent in which the compounds are prepared) and 100
µg NaF
and 1% DMSO. As seen in Figure 2 at the tested concentrations, the ILs were safe for macrophages.
Moreover, the compounds even were able to stimulate cell proliferation and to minimize the toxic
effect of the solvent.
Figure 2. Effect of ketoprofen-based ionic liquids (ILs) on the percentage of cell viability in RAW 264.7
macrophages. Control cells were treated with media alone. Values are the mean
mean of three independent experiments. ** p < 0.01, * p < 0.05 indicates.
±
standard error of the
3
. Materials and Methods
3
.1. Materials
Ketoprofen was isolated from commercially available medicines in pills (Ketonal forte® (100 mg)
tablet manufactured by SANDOZ, Holzkirchen, Germany) by extraction with ethanol, then purification
of the extract by filtration and then precipitation from extract with water. Identification of isolated
compounds was performed by NMR analysis and purity was determined by acid-base (acidimetric)
titration, according to the Pharmacopoeia and elementary analysis. l-valine and l-leucine with high
purity (>99.0%) were purchased from Carl Roth (Karlsruhe, Germany). Trimethylsilyl chloride with

Molecules 2020, 25, 90
10 of 17
high purity ( 99.0%) (TMSCl) was obtained from Sigma-Aldrich (Steinheim am Albuch, Germany).
≥
Ethanol (EtOH), propan-2-ol (i-PrOH), propan-1-ol (PrOH), butan-1-ol (BuOH), dimethyl sulfoxide,
chloroform, ethyl acetate, diethyl ether, toluene and n-hexane and ammonia solution were high purity
provided by Chempur (Gliwice, Poland). All reagents, solvents, and other materials were of analytical
grade and were used without any further purification. Deuterated chloroform (CDCl ) (99.8%) (+0.03%
3
TMSCl) was obtained from Eurisotop (Cheshire, England).
Bovine serum albumin (BSA), heat shock fraction, protease-free, fatty acid-free, essentially globulin
free (pH 7,
≥
98%), Dulbecco’s Modified Eagle’s Medium (DMEM) containing 4 mM L-glutamine,
−
1
−1
4500 mg L glucose, 1 mM sodium pyruvate, and 1500 mg L sodium bicarbonate, trypsin-EDTA
solution, and penicillin–streptomycin–neomycin stabilized solution were purchased from Merck
(Darmstadt, Germany).
Murine macrophages RAW 264.7 was obtained from the American Tissue Culture Collection
ATCC) (Manassas, VA, USA). Alamar Blue cell viability reagent was purchased from Thermo Scientific
Waltham, MA, USA).
(
(
3
.2. Synthesis of the Ketoprofen Amino Acid Alkyl-Esters [AAOR][KETO]
The ketoprofen amino acid alkyl esters (Schemes 2–7) were synthesized using a modified three-step
method (Scheme 1) [21
,38]. Initially, a suspension of 2.0 g of an amino acid in 30 mL of alkyl alcohol
(
such as ethan-1-ol, propan-1-ol, propan-2-ol or butan-1-ol) was stirred vigorously at room temperature.
Then, two molar equivalents of TMSCl were added into the reaction mixture, and the solution was
◦
stirred thoroughly at 60 C for 24 h. The excess of TMSCl and alcohol and formed by-products were
◦
removed by evaporation at 60 C under vacuum. The product was purified by washing with diethyl
ether. As a result, the amino acid alkyl ester hydrochloride (l-AAOR
·
HCl) was obtained with good yield.
Then, so obtained L-AAOR HCl was reacted with the ammonia solution (mole ratio of ammonia:AAE
·
salt = 3:1). To the reaction mixture water (5 mL) and diethyl ether (25 mL) were added, and the solution
was intensively stirred for 15 min at room temperature. The organic layer was separated and dried
using anhydrous Na SO and then concentrated under vacuum to receive the l-AAOR. In the third
2
4
step, an equimolar mixture of the synthesized l-AAOR and ketoprofen was dissolved in chloroform.
The mixture was stirred thoroughly for 20 min at room temperature, and then solvents were removed
by evaporation under reduced pressure. The obtained ketoprofen derivatives were white solid, and
1
13
their ionization and purities were evaluated using H- and C-NMR spectroscopy.
3
.3. Characterization of the Ketoprofen Amino Acid Alkyl-Esters [AAOR][KETO]
1H-NMR (400.13 MHz) and 13C-NMR (100.62 MHz) spectra were recorded in CDCl on a BRUKER
3
DPX-400 Avance III HD spectrometer (Billerica, MA, USA). TMS was used as an internal standard.
ATR–FTIR spectra were collected in a Thermo Fisher Scientific Nicolet FTIR 380 FTIR Spectrometer
(
Waltham, MA, USA) equipped with attenuated total reflectance (ATR) sampling accessory (diamond
–1
plate). Spectra were recorded in transmittance mode from 400 to 4000 cm , co–adding 16 interferograms
at a resolution of 4 cm . The content of elements, i.e., hydrogen, nitrogen, carbon, and oxygen were
–1
determined by CHNS/O elemental analysis. The elemental analysis was performed using a Thermo
Scientific
™
FLASH 2000 CHNS/O Elemental Analyzer (Waltham, MA, USA). Thermogravimetric
®
analysis was carried out on thermomicrobalance TG 209 F1 Libra from NETZSCH (Selb, Germany), in
◦
◦
◦
−1
Al O crucible. Samples between 5–10 mg were heated from 25 C to 1000 C with a heating rate of 10 C
2
3
−
1
3
−1
3
min , under air atmosphere (flow rate: air—25 cm min , nitrogen (as protective gas)—10 cm min ).
Phase transformation temperatures were measured using a TA Instruments DSC analyzer model
◦
Q-100 (New Castle, DE, USA). Measurements were performed within the temperature range of 0 C to
◦
◦
−1
1
00–200 C (depends on thermal stability), in a nitrogen atmosphere. The heating rate was 10 C min
.
The sample was loaded on an aluminum pan sealed with a pinhole cap. The specific rotation [α]D20
measurements were determined with an AUTOPOL IV Polarimeter from Rudolph Research Analytical

Molecules 2020, 25, 90
11 of 17
(
Hackettstown, NJ, USA) for aqueous solutions of AAILS (c = 0.01 g cm 3). The measurements were
−
◦
performed at 20 C.
3
.3.1. [l-LeuOEt][KETO]—l-Leucine Ethyl Ester Ketoprofenate
Scheme 2. l-Leucine ethyl ester ketoprofenate.
1
The compound was obtained according general procedure in 94.0% yield as white solid. H-NMR
400 MHz, CDCl3) in ppm: 7.71–7.81 (m, 3H, H7, H12, H16); 7.62 (d, J9,8 = 7.6 Hz, 1H, H9); 7.54–7.60
m, 2H, H13, H14); 7.44–7.49 (m, 2H, H5, H15); 7.38 (t, J6,5 = 7.6 Hz, 1H, H6); 6.67 (s, 3H, H22); 4.12–4.18
m, 2H, H24); 3.68–3.72 (m, 1H, H2); 3.59 (dd, J20,19 = 4.6 Hz, 1H, H21); 1.69–1.73 (m, 1H, H20); 1.58–1.62
(
(
(
(
δ
m, 1H, H19); 1.44–1.51 (m, 4H, H3, H20); 1.24 (t, J2
=7.2 Hz, 3H, H25); 0.85–0.89 (dd, J17(18),19 =
5,24
7
.6 Hz, 6H, H17, H18); 13C-NMR (100 MHz, CDCl ) δ in ppm: 196.72 (C1); 178.79 (C23); 173.68 (C10);
3
1
1
42.37 (C8); 137.56 (C11); 132.43 (C4); 131.84 (C5); 130.09 (C14); 129.29 (C12); 128.57 (C16); 128.26 (C9);
28.23 (C6); 61.46 (C24); 51.79 (C21); 46.55 (C2); 42.09 (C20); 24.52 (C19); 22.58 (C18); 21.85 (C17); 18.72
(
C3); 14.10 (C25); FTIR: ν (ATR): 2957; 2933; 2872; 1742; 1653; 1597; 1539; 1479; 1456; 1446; 1391; 1362;
1
6
317; 1281; 1252; 1231; 1196; 1172; 1132; 1093; 1074; 1026; 995; 968; 932; 921; 880; 824; 780; 728; 706; 644;
−
1
−1
07; 574; 523; 444 cm ; Elemental analysis: Calc. (%) for C H NO (413.51 g mol ) C (69.71), H
24
31
5
(7.56), N (3.39), O (19.35), Found C (69.82), H (7.53), N (3.37), O (19.33).
3
.3.2. [l-ValOEt][KETO]—l-Valine Ethyl Ester Ketoprofenate
Scheme 3. l-Valine ethyl ester ketoprofenate.
1
The compound was obtained according general procedure in 94.0% yield as white solid. H-NMR
400 MHz, CDCl3) in ppm: 7.75–7.81 (m, 3H, H7, H12, H16); 7.64 (d, J9,8 = 7.6 Hz, 1H, H9); 7.53–7.60
m, 2H, H13, H14); 7.48 (t, J6,5 = 7.3 Hz, 2H, H5, H15); 7.40 (t, J6,5 = 7.7 Hz, 1H, H6); 5.75 (s, 3H, H21);
.02–4.26 (m, 2H, H23); 3.68–3.72 (m, 1H, H2); 3.44 (d, J20,19 = 4.6 Hz, 1H, H20); 1.98–2.16 (m, 1H, H19);
.49 (d, J3,2 = 7.1 Hz, 3H, H3); 1.25 (t, J24,23 = 7.2 Hz, 3H, H24); 0.88–0.95 (m, 6H, H17, H18); 13C-NMR
100 MHz, CDCl3) in ppm: 196.65 (C1); 178.49 (22); 173.58 (C10); 141.64 (C8); 137.72 (C11); 137.54
C4); 132.45 (C5); 131.76 (C14); 130.10 (C12/C16); 129.31 (C9); 128.79 (C6); 128.37 (C7); 128.28 (C13);
1.17 (C23); 58.95 (C20); 46.00 (C2); 31.39 (C19); 18.72 (C18), 18.52 (C17); 17.29 (C3); 14.21 (C24); FTIR:
ATR): 2968; 2929; 2876; 2610; 1741; 1651; 1596; 1574; 1517; 1481; 1463; 1446; 1387; 1361; 1316; 1280; 1257;
(
(
4
1
(
(
δ
δ
6
(
ν
−
1
1
218; 1204; 1180; 1173; 1135; 1107; 1074; 1065; 1053; 1015; 996; 966; 952; 878; 859; 778; 718; 705; 642 cm ;
−1
Elemental analysis: Calc. (%) for C H NO (399.48 g mol ) C (69.15), H (7.32), N (3.51), O (20.03),
23
29
5
Found C (69.20), H (7.30), N (3.55), O (20.10).

Molecules 2020, 25, 90
12 of 17
3
.3.3. [l-ValOiPr][KETO]—l-Valine Isopropyl Ester Ketoprofenate
Scheme 4. L-valine isopropyl ester ketoprofenate.
1
The compound was obtained according general procedure in 90.0% yield as white solid. H-NMR
400 MHz, CDCl3) in ppm: 7.73–7.83 (m, 3H, H7, H12, H16); 7.61–7.67 (dt, 1H, H9); 7.52–7.60 (m, 2H,
H13, H14); 7.47 (t, J6,5 = 7.6 Hz, 2H, H5, H15); 7.39 (t, J6,5 = 7.7 Hz, 1H, H6); 5.63 (s, 3H, H21); 4.95–5.12
m, 2H, H23); 3.66–3.79 (m, 1H, H2); 3.40 (d, J20,19 = 4.6 Hz, 1H, H20); 2.03–2.12 (m, 1H, H19); 1.49 (d,
J3,2 = 7.2 Hz, 3H, H3); 1.24 (d, J24,23 = 7.1 Hz, 6H, H24, 25); 0.87–0.95 (dd, 6H, H17, H18); 13C-NMR (100
MHz, CDCl3) in ppm: 196.70 (C1); 178.48 (C22); 141.95 (C10); 137.65 (C8); 137.54 (C11); 132.43 (C4);
31.79 (C5); 130.10 (C14); 129.33 (C12/C16); 129.31 (C9); 128.69 (C6); 128.32 (C7); 128.27(C13); 68.90
C23); 58.90 (C20); 46.21 (C2); 31.30 (C19); 21.76 (C18); 18.65 (C17); 18.60 (C3); 17.26 (C24/C25); FTIR:
ATR): 2976; 2933; 2877; 1738; 1660; 1597; 1577; 1558; 1448; 1387; 1358; 1318; 1283; 1233; 1180; 1144; 1105;
(
δ
(
δ
1
(
ν
(
1
(
−
075; 999; 954; 915; 880; 822; 775; 721; 705; 643 cm ; Elemental analysis: Calc. (%) for C H NO
24 31 5
413.51 g mol ) C (69.71), H (7.57), N (3.39), O (19.35), Found C (69.75), H (7.56), N (3.38), O (19.34).
1
−
1
3
.3.4. [l-ValOPr][KETO]—l-Valine Propyl Ester Ketoprofenate
Scheme 5. l-Valine propyl ester ketoprofenate.
1
The compound was obtained according general procedure in 93.0% yield as white solid. H-NMR
400 MHz, CDCl3) in ppm: 7.74–7.82 (m, 3H, H7, H12, H16); 7.63–7.68 (dt, 1H, H9); 7.52–7.60 (m, 2H,
H13, H14); 7.47 (t, J6,5 = 7.6 Hz, 2H, H5, H15); 7.41 (t, J6,5 = 7.7 Hz, 1H, H6); 4.85 (s, 3H, H21); 4.03–4.12
(
δ
(
(
m, 2H, H23); 3.72–3.79 (m, 1H, H2); 3.42 (d, J20,19 = 4.7 Hz, 1H, H20); 2.03–2.13 (m, 1H, H19); 1.61–1.69
m, 2H, H24); 1.51 (d, J3,2 = 7.1 Hz, 3H, H3); 0.89–0.97 (m, 6H, H17, H18, H25); 13C-NMR (100 MHz,
CDCl3)
δ
in ppm: 196.64 (C1); 178.35 (C10); 174.20 (C22); 141.41 (C8); 137.75 (C11); 137.52 (C4); 132.47
(C5); 131.73 (C14); 130.10 (C12); 129.32 (C9); 128.88 (C6); 128.42 (C7); 128.29 (C13/C15); 66.71 (C23);
5
ν
9.14 (C20); 45.81 (C2); 31.59 (C19); 21.95 (C24); 18.88 (C18); 18.46 (C17); 17.23 (C3); 10.40 (C25); FTIR:
(ATR): 2969; 2935; 2879; 1742; 1659; 1597; 1578; 1462; 1448; 1389; 1358; 1318; 1283; 1222; 1179; 1140;
−
059; 999; 955; 929; 910; 881; 777; 721; 705; 643; cm ; Elemental analysis: Calc. (%) for C H NO
24 31 5
1
1
−
1
(413.51 g mol ) C (69.71), H (7.57), N (3.39), O (19.35), Found C (69.74), H (7.55), N (3.37), O (19.33).
3
.3.5. [l-ValOBu][KETO]—l-Valine Butyl Ester Ketoprofenate
Scheme 6. l-Valine butyl ester ketoprofenate.
1
Compound was obtained according general procedure in 95.0% yield as white solid. H-NMR
400 MHz, CDCl3) in ppm: 7.75–7.82 (m, 3H, H7,H12, H16); 7.61–7.66 (dt, 1H, H9); 7.53–7.60 (m, 2H,
(
δ

Molecules 2020, 25, 90
13 of 17
H13, H14); 7.47 (t, J6,5 = 7.6 Hz, 2H, H5, H15); 7.39 (t, J6,5 = 7.7 Hz, 1H, H6); 5.62 (s, 3H, H21); 4.05–4.16
(
(
m, 2H, H23); 3.68–3.76 (m, 1H, H2); 3.44 (d, J20,19 = 4.5 Hz, 1H, H20); 2.04–2.12 (m, 1H, H19); 1.56–1.64
m, 2H, H24); 1.48 (d, J3,2 = 7.2 Hz, 3H, H3); 0.87–0.95 (m, 9H, H17, H18, H25, H26); 13C-NMR (100
MHz, CDCl3)
32.45 (C5); 131.80 (C14); 130.10 (C12); 129.31 (C9); 128.70 (C6); 128.32 (C7); 128.27 (C13/C15); 65.10
C23); 58.91 (C20); 46.21 (C2); 31.31 (C19); 30.56 (C24); 19.09 (C25); 18.60 (C18); 18.60 (C17); 17.32 (C3);
δ in ppm: 196.70 (C1); 178.52 (C10); 173.51 (C22); 141.94 (C8); 137.65 (C11); 137.53 (C4);
1
(
1
3.65 (C26); FTIR:
ν (ATR): 2964; 2934; 2875; 1742; 1660; 1597; 1578; 1462; 1448; 1389; 1358; 1318; 1283;
−1
1
242; 1219; 1179; 1140; 1062; 1021; 999; 954; 881; 779; 721; 705; 643 cm ; Elemental analysis: Calc. (%)
−1
for C H NO (427.53 g mol ) C (70.23), H (7.78), N (3.27), O (18.71), Found C (70.25), H (7.80), N
25
33
5
(3.25), O (19.69).
3
.3.6. Ketoprofen
Scheme 7. Ketoprofen.
1H-NMR (400 MHz, CDCl3)
δ
in ppm: 7.67–7.74 (m, 3H, H9, H16, H12); 7.59–7.61 (dt, 1H, H7);
7
.44–7.54 (m, 2H, H4, H5); 7.30–7.42; (m, 3H, H); 3.69–3.79 (m, 1H, H); 1.46 (d, J2,1 = 7.1 Hz, 3H, H1);
13
C-NMR (100 MHz, CDCl3)
32.60 (C5); 131.71 (C14); 130.14 (C12/C16); 129.39 (C9); 129.31 (C6); 128.63 (C7); 128,34 (C13/C15); 45.25
(ATR): 2978; 2926; 1697; 1655; 1598; 1576; 1457; 1419; 1370; 1319; 1308; 1285;
δ in ppm: 196.56 (C10); 180.24 (1); 140.12 (C8); 137.93 (C11); 137.41 (C4);
1
(C2); 18.13 (C3); FTIR:
ν
−1
1227; 1195; 1175; 1134; 1178; 1063; 1061; 968; 928; 916; 866; 717; 703; 691; 643; 614 cm ; Elemental
−1
analysis: Calc. (%) for C H O (254.28 g mol ) C (75.58), H (5.55), N (0.00), O (18.88), Found C
16
14
3
(75.56), H (5.56), N (0.00), O (18.88).
3
.4. Fluorescence Quenching Measurements
All fluorescence measurements were carried out on Perkin Elmer LS 55 fluorimeter equipped
with a 1.0 cm quartz cuvette.
The experiments were carried out in sodium phosphate buffer (pH 7.4, 50 mM) at 25 C, the BSA
concentration was kept constant (2 M) and the concentration of the ketoprofen and [AAOR][KETO]
were varied from 2 to 60 M. The fluorescence spectra were recorded in the range from 295 to
50 nm by exciting BSA at 280 nm using a slit width of 10/10 nm. BSA-ILs incubated 1 hour prior to
the measurements.
◦
µ
µ
5
The measurements of UV-spectrum of ketoprofen and ILs at fixed concentrations were performed
on Evolution 300 Thermo Scientific equipped with a Peltier temperature control accessory with the
highest resolution (1 nm) using matched 1 cm path length quartz cuvettes.
3
.5. Fourier Transformed Infrared Spectroscopy
FTIR spectra of the BSA (20 g L 1, 0.3 mM) dissolved in sodium phosphate buffer (pH 7.4, 50 mM)
−
and its complexes with 0.3 mM ketoprofen or ILs (molar ratio 1:1) were recorded on Bruker Tensor 27
spectrometer, equipped with a detector of deuterated triglycine sulphate (DTGS). The FTIR spectra
were collected by direct deposition of the samples on attenuated total reflectance (ATR) element
−
1
(
diamond crystal) in frequency region 4000–600 cm (ATR) with 128 scannings and at a resolution
−
1
of 1 cm . The spectra of the proteins were referenced to the respective spectra of 50 mM sodium
phosphate buffer, pH 7.4 containing the same amount of the corresponding IL.
Then the ATR-FTIR spectra were Fourier deconvoluted by Opus software version 5.5 using a
−1
bandwidth of 12 cm , 2.9 resolution enhancement factor, and Lorentzian lineshape. Second derivative

Molecules 2020, 25, 90
14 of 17
spectra were obtained using the Savitzky-Golay algorithm based on 17 smoothing points. Then,
the relative contribution of each band component of the Amide I band was determined by curve
fitting following the procedure of the OPUS program. In the fitting, the number of components
and the initial values of their position were set as determined from the second derivative spectra.
−1
The initial bandwidth of all components was set to 12 cm and the components were approximated by
mixed Lorentzian/Gaussian functions. The curve-fitting was performed according to the Local Least
Squares algorithm. The assignment of the Amide I band positions to the secondary structure was done
according to [36].
3
.6. Cell Cultures Conditions
Murine macrophages RAW 264.7 were cultured in DMEM high glucose medium containing
L-Glutamine, antibiotic mixture B and 10% fetal bovine serum. The cells were cultivated at a humified
◦
atmosphere, 37 C, and 5% CO .
2
4
For the experimental procedures, cells were seeded in a sterile 96-well plate at 1
well and incubated for 24 h at 37 C and 5% CO for obtaining adherent cell cultures and good cell
×
10 cells per
◦
2
spreading. Then, the cells were incubated for an additional 24 h with ketoprofen or [AAOR][KETO]
at concentrations 1, 10, and 100 µM. Control experiments with non-treated cells, treated with 1%
DMSO (the solvent used to prepare the stock solution of the samples) and 100
were performed.
µg NaF and 1% DMSO
3
.7. Cell Viability Assay
The cell viability of RAW 264.7 cells in the presence of the ILs and ketoprofen was applied a
colorimetric assay using an Alamar Blue reagent. The reagent was diluted with DMEM media (1:10),
◦
an aliquot of 10
of 5% CO2.
µ
L of the solution was added to each well and incubated for 3h at 37 C under a flow
The measurements were carried out at an excitation wavelength of 544 nm and an emission
wavelength of 590 nm with a 96-well plate reader FLUOstar Galaxy (Tecan BMG Labtechnologies,
Ortenberg, Germany). The survival of the cells, treated with different concentrations of the tested
compounds, was presented in percentages from the control (non-treated cells).
The values are presented as mean
The values were significantly different if the p-value was < 0.05.
±
standard deviation of three independent experiments.
4
. Conclusions
Five novel ionic liquids containing ketoprofen anion were synthesized. The compounds were
safe for the immune cells in the tested concentration range. The affinity of the ILs to serum albumin
5
−1
is within the range of the estimated binding constants (KA) are in order of 10 L mol , which is
indicative of strong drug or IL-BSA interactions. The compounds have the potential to be the basis of
novel formulations.
1
Supplementary Materials: The following are available online, Figure S1: H-NMR spectra of ketoprofen and
its derivatives (in the red square, the protonated amino group is marked)—from the top: [l-LeuOEt][KETO],
[
l-ValOEt][KETO], [l-ValOiPr][KETO], [l-ValOPr][KETO], [l-ValOBu][KETO] and [KETO], Figure S2: 13C-NMR
spectra of ketoprofen and its derivatives—from the top: [l-LeuOEt][KETO], [l-ValOEt][KETO], [l-ValOiPr][KETO],
1
[
l-ValOPr][KETO], [l-ValOBu][KETO] and [KETO], Figure S3: H-NMR spectra of l-leucine ethyl ester
13
1
ketoprofenate, Figure S4: C-NMR spectra of l-leucine ethyl ester ketoprofenate, Figure S5: H-NMR spectra of
1
3
l-valine ethyl ester ketoprofenate, Figure S6: C-NMR spectra of l-valine ethyl ester ketoprofenate, Figure S7:
1
13
H-NMR spectra of l-valine isopropyl ester ketoprofenate, Figure S8: C-NMR spectra of l-valine isopropyl ester
1
13
ketoprofenate, Figure S9: H-NMR spectra of l-valine propyl ester ketoprofenate, Figure S10: C-NMR spectra of
l-valine propyl ester ketoprofenate, Figure S11: H-NMR spectra of l-valine butyl ester ketoprofenate, Figure
S12: C-NMR spectra of l-valine butyl ester ketoprofenate, Figure S13: H-NMR spectra of ketoprofen, Figure
1
1
3
1
1
3
S14: C-NMR spectra of ketoprofen, Figure S15: FTIR spectra of [l-LeuOEt][KETO], Figure S16: FTIR spectra of
l-ValOEt][KETO], Figure S17: FTIR spectra of [l-ValOiPr][KETO]; Figure S18: FTIR spectra of [l-ValOPr][KETO],
[

Molecules 2020, 25, 90
15 of 17
Figure S19: FTIR spectra of [l-ValOBu][KETO]; Figure S20: FTIR spectra of [KETO], Figure S21:The TG, DTG
and c-DTA curves of [l-LeuOEt][KETO], Figure S22:The TG, DTG and c-DTA curves of [l-ValOEt][KETO];
Figure S23: The TG, DTG and c-DTA curves of [l-ValOiPr][KETO], Figure S24:The TG, DTG and c-DTA curves
of [l-ValOPr][KETO], Figure S25: The TG, DTG and c-DTA curves of [l-ValOBu][KETO], Figure S26:The TG,
DTG and c-DTA curves of [KETO], Figure S27: The DSC curves of [l-LeuOEt][KETO], Figure S28: The DSC
curves of [l-ValOEt][KETO], Figure S29: The DSC curves of [l-ValOiPr][KETO], Figure S30: The DSC curves of
[
l-ValOPr][KETO], Figure S31: The DSC curves of [l-ValOBu][KETO], Figure S32: The DSC curves of [KETO],
◦
Figure S33: The plot of log (Fo
−
F)/F vs log. [Q] at 25 C, where Q is ketoprofen (A); [l-LeuOEt][KETO] (B);
[
l-ValOEt][KETO] (C); [l-ValOiPr][KETO] (D) [l-ValOPr][KETO] (E) and [l-ValOBu][KETO] (F), Figure S34: The
original (a), second derivative and deconvoluted ATR-FTIR spectra in Amide I region of native BSA in PBS buffer
−1
(pH 7.4, 50 mM) at concentration of 20 mg L , Figure S35: The original (a), second derivative and deconvoluted
ATR-FTIR spectra in Amide I and Amide II region of native BSA-ketoprofen (1:1) in PBS buffer (pH 7.4, 50 mM),
Figure S36: The original (a), second derivative and deconvoluted ATR-FTIR spectra in Amide I and Amide II
region of native BSA-[l-LeuOEt][KETO] (1:1) in PBS buffer (pH 7.4, 50 mM), Figure S37: The original (a), second
derivative and deconvoluted ATR-FTIR spectra in Amide I and Amide II region of native BSA-[l-ValOEt][KETO]
(
1:1) in PBS buffer (pH 7.4, 50 mM), Figure S38: The original (a), second derivative and deconvoluted ATR-FTIR
spectra in Amide I and Amide II region of native BSA-[l-ValOiPr][KETO] (1:1) in PBS buffer (pH 7.4, 50 mM),
Figure S39: The original (a), second derivative and deconvoluted ATR-FTIR spectra in Amide I and Amide II
region of native BSA-[l-ValOPr][KETO] (1:1) in PBS buffer (pH 7.4, 50 mM), Figure S40: The original (a), second
derivative and deconvoluted ATR-FTIR spectra in Amide I and Amide II region of native BSA-[l-ValOBu][KETO]
(1:1) in PBS buffer (pH 7.4, 50 mM).
´
´
Author Contributions: Data curation, P.O., P.K., J.K. and E.S.; Formal analysis, P.O., P.K., J.K., E.S., D.Y. and
I.A.; Investigation, M.G.; Methodology, P.O., P.K., D.Y. and I.A.; Resources, E.J.; Validation, M.G. and E.J.;
Writing—original draft, M.G. All authors have read and agreed to the published version of the manuscript.
Funding: The National Research Programme “Young scientists and postdoctoral students” of the Bulgarian
Ministry of Education and Science approved by DCM#577/17.08.2018.
Conflicts of Interest: The authors declare no conflict of interest.
References
1
2
.
.
Welton, T. Ionic liquids: A brief history. Biophys. Rev. 2018, 10, 691–706. [CrossRef] [PubMed]
Egorova, K.S.; Gordeev, E.G.; Ananikov, V.P. Biological activity of ionic liquids and their application in
pharmaceutics and medicine. Chem. Rev. 2017, 117, 7132–7189. [CrossRef] [PubMed]
Adawiyah, N.; Moniruzzaman, M.; Hawatulaila, S.; Goto, M. Ionic liquids as a potential tool for drug
delivery systems. Med. Chem. Commun. 2016, 7, 1881–1897. [CrossRef]
Marrucho, I.M.; Branco, L.C.; Rebelo, L.P.N. Ionic liquids in pharmaceutical applications. Annu. Rev. Chem.
Biomol. Eng. 2014, 5, 527–546. [CrossRef] [PubMed]
Zhou, Z.; Liu, C.; Wan, X.; Fang, L. Development of a w/o emulsion using ionic liquid strategy for transdermal
3
4
5
.
.
.
delivery of anti-aging component α-lipoic acid: Mechanism of different ionic liquids on skin retention and
efficacy evaluation. Eur. J. Pharm. Sci. 2020, 141, 105042. [CrossRef] [PubMed]
6.
7.
8.
9.
Maneewattanapinyo, P.; Yeesamun, A.; Watthana, F.; Panrat, K.; Pichayakorn, W.; Suksaeree, J. Controlled
release of lidocaine–diclofenac ionic liquid drug from freeze-thawed gelatin/poly(vinyl alcohol) transdermal
patches. AAPS Pharm. Sci. Tech. 2019, 20, 322. [CrossRef]
Rzemieniecki, T.; Gwiazdowska, D.; Rybak, K.; Materna, K.; Ju s´ , K.; Pernak, J. Synthesis, properties, and
antimicrobial activity of 1-alkyl-4-hydroxy-1-methylpiperidinium ionic liquids with mandelate anion. ACS
Sustain. Chem. Eng. 2019, 7, 15053–15063. [CrossRef]
Garcia, I.M.; Ferreira, C.J.; de Souza, V.S.; Castelo, V.; Leitune, B.; Samuel, S.M.W.; de Souza Balbinot, G.;
de Souza da Motta, A.; Visioli, F.; Scholten, J.D.; et al. Ionic liquid as antibacterial agent for an experimental
orthodontic adhesive. Dent. Mat. 2019, 35, 1155–1165. [CrossRef]
Bourakadi, K.E.; Merghoub, N.; Hicham, G.; Mekhzoum, M.E.M.; Essassi, E.M.; Qaiss, A.E.K.; Bouhfid, R.
Synthesis, characterization and in vitro antiproliferative evaluation of ionic liquids based on alkyl-substituted
thiabendazolium. J. Mol. Liq. 2019, 282, 63–69. [CrossRef]
1
1
0. Guncheva, M. Ionic Liquids for Anticancer Application. In Encyclopedia of Ionic Liquids; Zhang, S., Ed.;
Springer: Singapore, 2019.
1. Hough, W.L.; Rogers, R.D. Ionic liquids then and now: From solvents to materials to active pharmaceutical
ingredients. Bull. Chem. Soc. Jpn. 2007, 80, 2262–2269. [CrossRef]

Molecules 2020, 25, 90
16 of 17
1
1
1
2. Fernandez-Stefanuto, V.; Tojo, E. New active pharmaceutical ingredient-ionic liquids (API-ILs) derived from
indomethacin and mebendazole. Proceedings 2019, 9, 5781. [CrossRef]
3. Shamshina, J.L.; Barber, P.S.; Rogers, R.D. Ionic liquids in drug delivery. Expert Opin.on Drug Deliv. 2013, 10,
1
367–1381. [CrossRef] [PubMed]
4. Frizzo, C.P.; Wust, K.; Tier, A.Z.; Beck, T.S.; Rodrigues, L.V.; Vaucher, R.A.; Bolzan, L.P.S.; Terra Soares, F.;
Martins, M.A.P. Novel ibuprofenate- and docusate-based ionic liquids: Emergence of antimicrobial activity.
RSC Adv. 2016, 6, 100476–100486. [CrossRef]
1
1
1
1
5. Bica, K.; Rodrıguez, H.; Gurau, G.; Cojocaru, O.A.; Riisager, A.; Fehrmannd, R.; Rogers, R.D. Pharmaceutically
active ionic liquids with solids handling, enhanced thermal stability, and fast release. Chem. Commun. 2012
8, 5422–5424. [CrossRef]
6. Santos, M.M.; Raposo, L.R.; Carrera, G.V.S.M.; Costa, A.; Dion
,
4
í
sio, M.; Baptista, P.V.; Fernandes, A.R.;
Branco, L.C. Ionic liquids and salts from ibuprofen as promising innovative formulations of an old drug.
Chem. Med. Chem. 2019, 14, 907–911. [CrossRef]
7. Theoduloz, C.; Delporte, C.; Valenzuela-Barra, G.; Silva, X.; Cádiz, S.; Bustamante, F.; Pertino, M.W.;
Schmeda-Hirschmann, G. Topical anti-inflammatory activity of new hybrid molecules of terpenes and
synthetic drugs. Molecules 2015, 20, 11219–11235. [CrossRef]
8. Azevedo, A.M.O.; Costa, S.P.F.; Dias, A.F.V.; Marques, A.H.O.; Pinto, P.C.A.G.; Bica, K.; Ressmann, A.K.;
Passos, M.L.C.; Araújo, R.T.S.; Reis, S.; et al. Anti-inflammatory choline based ionic liquids: Insights into
their lipophilicity, solubility and toxicity parameters. J. Mol. Liq. 2017, 232, 20–26. [CrossRef]
9. Spinella, R.; Sawhney, R.; Jalan, R. Albumin in chronic liver disease: Structure, functions and therapeutic
implications. Hepatol. Int. 2016, 10, 124–132. [CrossRef]
0. Zhu, J.L.; He, J.; He, H.; Tan, S.H.; He, X.M.; Pham-Huy, C.; Li, L. Study on the interaction between ketoprofen
and bovine serum albumin by molecular simulation and spectroscopic methods. Spectroscopy 2011, 26,
1
2
3
37–348. [CrossRef]
2
2
1. Moshikur, R.; Chowdhury, R.; Wakabayashi, R.; Tahara, Y.; Moniruzzaman, M.; Goto, M. Characterization
and cytotoxicity evaluation of biocompatible amino acid esters used to convert salicylic acid into ionic liquids.
Int. J. Pharm. 2018, 546, 31–38. [CrossRef]
2. Koleva, B.; Kolev, T.; Spiteller, M. Spectroscopic analysis and structural elucidation of small
peptides—Experimental and theoretical tools. In Advances in Chemistry Research; Taylor, J.C., Ed.; Nova
Science Publishers Inc.: New York, NY, USA, 2010; Volume 3, pp. 675–755.
2
3. Roeges, N.P. A Guide to the Complete Interpretation of Infrared Spectra of Organic Structures; Wiley: Hoboken, NJ,
USA, 1994.
2
4. Rehman, N.; Khalid, M.; Bhatti, M.H.; Yunus, U.; Braga, A.A.C.; Ahmed, F.; Ali Mashhadi, S.M.; Tahir, M.N.
Schiff base of isoniazid and ketoprofen: Synthesis, X-ray crystallographic, spectroscopic, antioxidant, and
computational studies. Turk. J. Chem. 2018, 42, 639–651.
2
5. Ossowicz, P.; Janus, E.; Schroeder, G.; Rozwadowski, Z. Spectroscopic studies of amino acid ionic
liquid-supported Schiff bases. Molecules 2013, 18, 4986–5004. [CrossRef] [PubMed]
6. Ribeiro, R.; Pinto, P.C.A.G.; Azevedo, A.M.O.; Bica, K.; Ressmann, A.K.; Reis, S.; Saraiva, M.L.M.F.S.
Automated evaluation of protein binding affinity of anti-inflammatory choline based ionic liquids. Talanta
2
2
016, 150, 20–26. [CrossRef] [PubMed]
7. Martin, K.; N ges, J.; Haav, K.; Kadam, S.A.; Pung, A.; Leito, I. Exploring selectivity of 22 acyclic urea-,
carbazole- and indolocarbazole-based receptors towards 11 monocarboxylates. Eur. J. Org. Chem. 2017, 2017,
231–5237. [CrossRef]
8. Greaves, T.L.; Drummond, C.J. Protic ionic liquids: Evolving structure
applications. Chem. Rev. 2015, 115, 11379–11448. [CrossRef] [PubMed]
9. Reichardt, C.; Welton, T. Solvents and Solvent Effects in Organic Chemistry, 4th ed.; Wiley-VCH: Weinheim,
Germany, 2011.
0. Furniss, B.S.; Hannaford, A.J.; Smith, P.W.J.; Tatchell, A.R. Vogel’s Textbook of Practical Organic Chemistry,
2
õ
5
2
2
3
3
3
−property relationships and expanding
5
th ed.; Longman Group UK Ltd.: London, UK, 1989.
1. Castagna, R.; Donini, S.; Colnago, P.; Serafini, A.; Parisini, E.; Bertarelli, C. Biohybrid electrospun membrane
for the filtration of ketoprofen drug from water. ACS Omega 2019, 4, 13270–13278. [CrossRef] [PubMed]
2. Lacowicz, J. Principles of Fluorescence Spectroscopy, 3rd ed.; Springer: New York, NY, USA, 2011.

Molecules 2020, 25, 90
17 of 17
3
3
3
3
3. Bi, S.; Yan, L.; Sun, Y.; Zhang, H. Investigation of ketoprofen binding to human serum albumin by spectral
methods. Spectrochim. Acta A 2011, 78, 410–414. [CrossRef]
4. Kong, J.; Yu, S. Fourier transform infrared spectroscopic analysis of protein secondary structures. Acta Biochim.
Biophys. Sin. 2007, 39, 549–559. [CrossRef]
5. Jackson, M.; Mantsch, H.H. The use and misuse of FTIR spectroscopy in the determination of protein
structure. Crit. Rev. Biochem. Mol. Biol. 1995, 30, 95–120. [CrossRef]
6. Majorek, K.A.; Porebski, P.J.; Dayal, A.; Zimmerman, M.D.; Jablonska, K.; Stewart, A.J.; Chruszcz, M.;
Minor, W. Structural and immunologic characterization of bovine, horse, and rabbit serum albumins.
Mol. Immunol. 2012, 52, 174–182. [CrossRef]
3
3
7. Alhazmi, H. FTIR spectroscopy for the identification of binding sites and measurements of the binding
interactions of important metal ions with bovine serum albumin. Sci. Pharm. 2019, 87, 5. [CrossRef]
8. Furukawa, S.; Hattori, G.; Sakai, S.; Kamiya, N. Highly efficient and low toxic skin penetrants composed of
amino acid ionic liquids. RSC Adv. 2016, 6, 87753–87755. [CrossRef]
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
CC BY) license (http://creativecommons.org/licenses/by/4.0/).
(
