In silico design, chemical synthesis and toxicological evaluation of 1,3-
thiazolidine-2,4-dione derivatives as PPARγ agonists
D. Alemán-González-Duhart, F. Tamay-Cach, J. Correa-Basurto, Padilla-Martínez, II,
S. Álvarez-Almazán, J.E. Mendieta-Wejebe
PII:
S0273-2300(17)30029-6
10.1016/j.yrtph.2017.02.008
YRTPH 3768
DOI:
Reference:
To appear in: Regulatory Toxicology and Pharmacology
Received Date: 21 September 2016
Revised Date: 7 February 2017
Accepted Date: 9 February 2017
Please cite this article as: Alemán-González-Duhart, D., Tamay-Cach, F., Correa-Basurto, J., Padilla-
Martínez II., , , Álvarez-Almazán, S., Mendieta-Wejebe, J.E., In silico design, chemical synthesis
and toxicological evaluation of 1,3-thiazolidine-2,4-dione derivatives as PPARγ agonists, Regulatory
Toxicology and Pharmacology (2017), doi: 10.1016/j.yrtph.2017.02.008.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
1
2
In silico design, chemical synthesis and toxicological evaluation of 1,3-thiazolidine-2,4-
dione derivatives as PPARγ agonists
3
Alemán-González-Duhart D1, Tamay-Cach F2*, Correa-Basurto J3, Padilla-Martínez II4,
Álvarez-Almazán S1, and Mendieta-Wejebe JE1*
4
5
6
1Laboratorio de Biofísica y Biocatálisis, Sección de Estudios de Posgrado e Investigación,
Escuela Superior de Medicina, Instituto Politécnico Nacional, Plan de San Luis y Díaz
Mirón, Casco de Santo Tomas, Ciudad de México, 11340, México.
7
8
9
2Laboratorio de Investigación en Bioquímica, Departamento de Formación Básica
Disciplinaria y Sección de Estudios de Posgrado e Investigación, Escuela Superior de
Medicina, Instituto Politécnico Nacional, Plan de San Luis y Díaz Mirón, Casco de Santo
Tomas, Ciudad de México, 11340, México.
10
11
12
13
14
15
16
17
18
19
20
21
22
3Laboratorio de Modelado Molecular, Bioinformática y Diseño de Fármacos, Sección de
Estudios de Posgrado e Investigación, Escuela Superior de Medicina, Instituto Politécnico
Nacional, Plan de San Luis y Díaz Mirón, Ciudad de México, 11340, México.
4Laboratorio de Investigación Química, Departamento de Ciencias Básicas, Unidad
Profesional Interdisciplinaria de Biotecnología, Instituto Politécnico Nacional, Av.
Acueducto s/n, Barrio La Laguna Ticomán, Ciudad de México, 07340, México.
*Correspondence to:
Mendieta-Wejebe JE and Tamay-Cach F.
Phone: (5255)57296300 ext. 62829 and 62747
E-mail: jesmenwej@yahoo.com and dr.felicianotamay@gmail.com

ACCEPTED MANUSCRIPT
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Abstract
Peroxisome proliferator-activated receptors (PPARs) are nuclear receptors involved in the
metabolism of lipids and carbohydrates. The exogenous ligands of these receptors are
thiazolidinediones (TZDs), which are used to treat type 2 diabetes mellitus (DM2).
However, drugs from this group produce adverse effects such as hepatic steatosis. Hence,
the aim of this work was to design a set of small molecules that can activate the γ isoform
of PPARs while minimizing the adverse effects. The derivatives were designed containing
the polar head of TZD and an aromatic body, serving simultaneously as the body and tail.
Two ligands were selected out of 130 tested. These compounds were synthesized in a
solvent-free reaction and their physicochemical properties and toxicity were examined.
Acute oral toxicity was determined by administering these compounds to female Wistar rats
in increasing doses (as per the OECD protocol 425). The median lethal dose (LD50) of the
compound substituted with a hydroxyl heteroatom was above 2000 mg/kg, and that of the
compound substituted with halogens was 700-1400 mg/kg. The results suggest that the
compounds can interact with PPARγ and elicit biological responses similar to other TZDs,
but without showing adverse effects. The compounds will be subsequently evaluated in a
DM2 animal model.
Keywords:
PPARγ agonists, thiazolidinedione, in silico studies, chemical synthesis, acute toxicity.

ACCEPTED MANUSCRIPT
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
Introduction
Type 2 diabetes mellitus (DM2) is a complex metabolic disease characterized by
hyperglycemia (caused by a defect in pancreatic β cells), insulin resistance in peripheral
tissues, and excessive accumulation of triglycerides and fatty acid derivatives in skeletal
muscles and other tissues. The latter characteristic is highly correlated with the
development of the chronic micro and macro vascular complications of the disease [1-13].
The treatment of DM2 has aimed to decrease hyperglycemia by improving insulin secretion
or reducing insulin resistance in peripheral tissues, an effect found with thiazolidinediones
(TZDs) [7,9,14-16]. These compounds, also known as glitazones, are used clinically as
insulin sensitizers to lower the levels of blood glucose and circulating triglycerides
[9,14,16-19]. To carry out these activities, TZDs act as full agonists of peroxisome
proliferator-activated receptors (PPARs) γ. In addition to such beneficial functions, they are
involved in the increase of adipocyte differentiation and improvement of fatty acids. Since
these molecules have attracted the attention of several research groups worldwide, new
strategies have been sought and discovered to synthesize them [14,16-18,20,21].
Three isoforms have been described for PPARs: α, β/δ and γ. Each of these regulate tissue-
specific target genes involved in biological pathways for lipid and glucose homeostasis. Of
the PPARs, PPARγ is particularly important in the pathology of various disorders,
including DM2, obesity, dyslipidemia, atherosclerosis, neoplastic diseases and tumors,
inflammatory conditions, and neurodegenerative diseases [8,14,16,22-33].
PPARγ is organized into domains, each associated with certain functions, such as ligand
binding, activation, and DNA binding (Figure 1). The amino terminal A/B domain has a
ligand-dependent transactivation function. The C domain is the central DNA-binding
domain, which contains two zinc finger-like structures and one α helical DNA binding

ACCEPTED MANUSCRIPT
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
motif. The E/F domain has the ligand-dependent transactivation function, which allows for
conformational changes in the presence of a ligand. This in turn leads to the recruitment of
co-activators and the release of co-repressors [16,22,34,35].
Figure 1. The main functional domains of PPARγ. A/B has the activation function 1 (AF-
1) and C is the DNA-binding domain (DBD). D serves as a hinge between C and E/F, the
latter of which is the ligand-binding domain (LBD) that contains AF-2, a ligand-binding
dimerization transactivation domain.
The PPARγ ligand-binding domain (LBD) contains a large binding pocket that permits
diverse types of ligands to enter and search for the proper resting conformation that enables
each of them to form a ligand-receptor complex. Fatty acids or their derivatives are natural
ligands of PPARγ. Synthetic ligands, such as TZDs, L-tyrosine analogs and some
nonsteroidal anti-inflammatory drugs, can be classified as either full or partial agonists [16-
18,22,26,34,36-40].
TZDs as well as most known PPARγ agonists share common features, including a
hydrophilic head group, a central hydrophobic body, and a flexible linker to a cyclic tail.
The hydrophilic head group has hydroxyl, carbonyl or carboxyl oxygen atoms that allow it
to form H bonds with the key amino acid residues: Tyr 473 (having an AF2 helix H12,
which appears to be crucial for maintaining the helix in an adequate conformation for
coactivator recruitment), His 449 (H11), His323 (H5), Ser289 (H3), and Gln286 (H3) of the
LBD. In this way, full agonists are able to generate an intermolecular network with the
receptor.

ACCEPTED MANUSCRIPT
91
92
Whereas this H bond network stabilizes the receptor in the proper conformation, the acid
head group of commercially available TZDs are prone to racemization under physiological
conditions due to their stereogenic center at C5. Furthermore, it has been demonstrated that
only the (S)-enantiomers bind to the receptor, which suggests that approximately 50% of
the active substance is inactive.
93
94
95
96
The binding of these ligands causes conformational changes in the receptors, and this
facilitates ligand interaction with co-activator proteins in the nucleus. The resulting protein
complexes activate the transcription of specific target genes, inducing intracellular
signaling cascades that mediate physiological effects [16-21,26,30,31,34,36-40].
Despite the excellent potency of TZDs, they have severe side effects such as fluid retention,
weight gain, hepatotoxicity (only for troglitazone), plasma-volume expansion,
hemodilution, edema, and congestive heart failure. Because of these unfavorable effects,
the clinical application of TZDs has been limited, especially for diabetic patients suffering
from cardiomyopathy [14,16,17,30,31,33,39-41].
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
The aim of the present study was to produce TZD derivatives that are effective for treating
DM2, but with less side effects. There was a specific purpose for each aspect of the current
contribution, including molecular docking, synthesis and acute toxicity. Molecular docking
studies were performed on PPARγ with a series of TZD derivatives to predict the
orientation within a targeted binding site. For chemical synthesis of the derivatives, high
yield was sought within the context of a solvent-free reaction. The acute toxicity study was
conducted to obtain relatively safe compounds that could be administrated to healthy
animals.
Materials and methods

ACCEPTED MANUSCRIPT
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
Docking studies
The structures of the compounds were drawn with ChemDraw Ultra v10.0 (Cambridge Soft
Corporation, USA), then copied to Chem3D Ultra v10.0 to create a 3D model. Afterwards,
they were subjected to energy minimization with Gaussian 09 and GaussView v5 (Gaussian
Inc, USA) [42], using molecular mechanics (MM2) in an AM1 platform. The minimization
was executed until the root mean square gradient value became smaller than 0.001
kcal/mol. Corresponding pdb files were prepared by means of AutoDock Tools v1.5.6 [43].
The selection of the protein for molecular docking studies was based on several factors.
The structure was determined by X-ray diffraction with a resolution between 2.0 and 2.5 Å.
A co-crystallized ligand and a co-activator were required, protein breaches in the 3D
structure were not permitted, and the LBD had to be complete [44,45]. In the crystal
chosen, PDB entry 2PRG [46], rosiglitazone and SRC-1 were co-crystallized as the ligand
and the coactivator, respectively. The LBD formed a homodimer in which both monomers
had a nearly identical Cα conformation, allowing the “A” monomer to be selected for the
docking studies. All water molecules and the crystallographic ligand were removed from
the receptor. All hydrogen atoms were added, Kollman’s charges assigned, and non-polar
hydrogen atoms merged [43-48].
The active binding site region was defined as a 60 x 60 x 60 cube, with points separated by
0.375 Å. The Lamarckian genetic algorithm was applied for the search, utilizing default
parameters. The LBD was considered as a rigid molecule and the ligands as flexible (all
non-ring torsions were accepted). Before docking the proposed compounds, the docking
protocols of AutoDock v4.0 and AutoGrid v4.0 were validated by predicting the binding
mode of a well-known crystallographic ligand (rosiglitazone). Results were visualized with
Pymol 1.0 and VMD v1.8.7 [6,20,23,29,39,43,47,48].

ACCEPTED MANUSCRIPT
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
The physicochemical properties of the compounds were also evaluated and the predictive
toxicity calculated by using online software: Molinspiration Cheminformatics [49] and
Osiris Property Explorer [50].
Chemical synthesis
The reaction sequence employed for the synthesis of the proposed compounds was based
on a Knoevenagel condensation, using equimolar concentrations and a catalytic amount of
urea at 10 mol % in a solvent-free environment (Figure 2) [20,51,52]. 2,4-thiazolidinedione
can undergo a Knoevenagel condensation with a variety of substituted aldehydes to produce
5-arylidene-2,4-thiazolidinediones (Figure 2). All the synthesized compounds were
characterized by spectroscopic methods such as IR, 1H NMR, 13C NMR and MS [20].
Figure 2. Proposed synthesis methodology.
Acute Toxicity Study
Acute oral toxicity was performed as per the OECD (Organization of Economic
Cooperation and Development) 425 guideline (Up & down method) [53]. Healthy female
albino Wistar rats, nulliparous and not pregnant, were randomly divided into groups to be
given increasing doses. The animals were housed individually at room temperature (22 ± 3°
C) and 30-35% relative humidity. They were kept on a 12/12 h light/dark cycle, fed
conventional rodent laboratory diet (Rat Chow 5012 formula), and provided drinking water
ad libitum throughout the experiment.
The animals were acclimated to the lab conditions for 8 days prior to dosing. The day
before the initial dose, animals were fasted overnight. To determine toxicity (by up and

ACCEPTED MANUSCRIPT
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
down staircase), the compounds were administered orally via orogastric cannula,
employing increasing doses with a 0.5 progression factor (175, 350, 700, 1400 and 2000
mg/kg). Doses were selected according to the original protocol (annex 2, paragraph 2),
which states that in the absence of an available estimate of the lethality of a given
substance, dosing should be initiated at 175 mg/kg. In most cases this dose is sub lethal and
therefore serves to reduce the level of pain and suffering of the animals. The protocol also
specifies that in case animal tolerances to the chemical are expected to be highly variable,
an increase in the dose progression factor beyond the default 0.5 on a log dose scale (3.2
factor) should be considered. This led us to choose a 0.5 factor.
After administration of the compound, animals were watched to monitor their general
behavior and possible neurological behavioral disturbances. This surveillance was carried
out continuously for 5 h, frequently for another 5 h, and then occasionally for 24 or 48 h.
The animals were kept under observation for 14 days to register survival and death [53,54].
The LD50 was estimated with the formula of Reed Muench: LD50 = log (inferior dose) + B
x log A, where B = (50 – inferior mortality %) / (superior mortality % - inferior mortality
%), and A = maximum dose / minimum dose.
Results
Docking studies
One hundred and thirty derivatives were designed and tested. The derivatives had the polar
head of TZD and an aromatic mono and di-substituted body/tail portion. From 117 crystals
encoded for PPARγ that are available in PDB, entry 2PRG was the most complete. This
receptor was found co-crystallized with rosiglitazone as the ligand and SRC-1 as a

ACCEPTED MANUSCRIPT
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
coactivator. This murine PPARγ protein is homologous to human PPARγ, having 95%
identity at the amino acid level.
Like rosiglitazone, the head group of the tested compounds interacted with His323, His449,
Tyr473, Ser289 and Gln286. The partially lipophilic tail was inserted into the hydrophobic
pocket of the LBD (see Table 1).
Table 1. Docking scores for the pattern compounds and their derivatives.
In accordance with the physicochemical prediction, the proposed compounds proved to be
more hydrophilic than those employed as patterns (rosiglitazone, pioglitazone and
troglitazone), as well as having a lower molecular weight (Table 2).
Table 2. Physicochemical properties of the proposed compounds.
Chemical synthesis
For the chemical synthesis of compound 40 (C#40), the reagents were 1,3-thiazolidine-2,4-
dione and salicylaldehyde. The reaction was carried out in a solvent-free environment at
120° C for 2 h. The product obtained was a yellow dust with an Rf of 0.26 (hexane-ethyl
acetate, 6:4) and a final yield of 90.58%. It has a melting point at 275 ± 2°C and shows
good solubility in acetone, ethyl acetate, methanol and dimethyl sulfoxide. The presence of
the desired product was confirmed by IR, NMR and MS. IR (cm-1): OH (3413.4), NH
1
(3129), C=C-H (3015.3, 2795), C=O (1722.7, 1667) C=C (1590). H NMR (300 MHz,
2
DMSO-d6): δ/ppm 12.4 (a, 1H, OH), 10.52 (s, 1H, NH), 7.99 (s, 1H, H6), 7.31 (d, J=1,
3
2
2
13
1H, H12), 7.28 (t, J=3, 1H, H10), 6.94 (d, J=2, 1H, H11), 6.92 (d, J=1, 1H, H9). C

ACCEPTED MANUSCRIPT
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
NMR (75.4 MHz, DMSO-d6): δ/ppm 168.6 (C4), 168.0 (C2), 157.7 (C6), 132.7 (C11),
128.7 (C10), 127.4 (C12), 122.3 (C5), 120.3 (C9), 120.1 (C8), 116.5 (C7). MS= 221.01.
For the chemical synthesis of compound 81 (C#81), the reagents used were 1,3-
thiazolidine-2,4-dione and 3-chloro-2-fluorobenzaldehyde. The reaction was carried out in
a water solvent environment at 145° C for 7 h. The product obtained was a yellowish dust
with an Rf of 0.66 (hexane-ethyl acetate, 6:4), a yield of 57.87%, and a melting point of
155 ± 2°C. It displays good solubility in ethyl acetate, methanol and dimethyl sulfoxide.
The presence of the desired product was confirmed by IR, NMR and MS. IR (cm-1): NH
(3158.6), C=C-H (3031.2, 2755.2), C=O (1746.6, 1696.8), C=C-H (1608.6). 1H NMR (300
3
MHz, DMSO-d6): δ/ppm 12.69 (a, 1H, NH), 7.68 (s, 1H, H6), 7.55 (td, J (H-F)= 4, 1H,
3
5
4
13
H10), 7.48 (m, J (H-F)= 8, J (H-F)= 4, 1H, H12), 7.39 (ddd, J (H-F)= 8, 1H, H11). C
NMR (75.4 MHz, DMSO-d6): δ/ppm 167.6 (d, 5J (C-F)= 4, C4), 166.9 (s, C2), 159.4 (d, 1J
3
(C-F)= 2, C8), 134.4 (d, 2J (C-F)= 4, C7), 133.0 (d, J (C-F)= 8, C10), 132.1 (s, C5), 126.5
3
2
3
(d, J (C-F)= 2, C12), 123.7 (s, C11), 120.8 (d, J (C-F)= 14, C9), 115.8 (d, J (C-F)= 16,
C6). MS= 257.96.
Acute Oral Toxicity Study
C#40 or (5Z)-5-(2-hydroxybenziliden)-1,3-thiazolidine-2,4-dione
The compound was administered at the doses of 175, 350, 700, 1400 and 2000 mg/kg by
orogastric cannula. The vehicle was ethanol (10%) and isotonic saline solution (90%) in a
final volume of 1 ml. For all doses, the animals exhibited normal behavior and no physical
changes were observed. For the first dose (175 mg/kg), post-mortem analysis did not reveal
any significant findings (Figure 3A). For the rest of the doses (≥350 mg/kg), fat deposits
were found within the abdominal cavity (Figure 3B shows the 2000 mg/kg dose).

ACCEPTED MANUSCRIPT
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
The results (Table 3) suggest that C#40 is adipogenic and capable of increasing body
weight. By utilizing Reed Muench’s formula, the LD50 for C#40 was estimated to be
77090.34 mg/kg.
Figure 3. Acute oral toxicity. Gross necropsy of a rat that received C#40 at: A) 175 mg/kg,
and B) 2000 mg/kg.
Table 3. Trends in body weight and percentage of mortality for animals given C#40.
*Mean, n=6
C#81 or (5Z)-5-(3-chloro-2-fluorobenziliden)-1,3-thiazolidine-2,4-dione
The compound was administered at doses of 175, 350, 700, 1400 and 2000 mg/kg by
orogastric cannula, leading to distinct results according to the dose (Table 4). The vehicle
was dimethyl sulfoxide (2%) and isotonic saline solution (98%) in a final volume of 1 ml.
The animals given the 175 and 350 mg/kg doses exhibited normal behavior, with no
physical changes detected. The post-mortem analysis did not reveal anything significant
(Figure 4A). Three of the animals receiving 700 mg/kg (with the same vehicle used for the
previous animals) presented normal behavior with no observable physical changes. The
post-mortem analysis revealed nothing significant. The two remaining animals with the
same dose displayed severe lethargy immediately after administration, with sedation
beginning at 24 h and full recovery as of 48 h. Post-mortem analysis was carried out
without significant findings. The 1400 mg/kg dose was applied to two animals by following
the aforementioned procedure. The first animal with this dose had normal behavior and no
physical changes. Nothing significant was found with the post-mortem analysis. The other

ACCEPTED MANUSCRIPT
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
animal with the same dose manifested severe lethargy that began immediately after
administration and lasted approximately 5 h. Hypnosis was seen at 10 h post-
administration, and then a coma state set in at 12 h post-administration, showing cyanotic
inferior extremities. Post-mortem analysis demonstrated stomach fundus hardening, which
was due to the jamming of the compound in the lumen of the gastroesophageal sphincter,
thus impairing the normal respiration of the animal.
Finally, the two animals receiving 2000 mg/kg (using the same procedure) exhibited severe
lethargy immediately after administration, followed by hyperventilation, cyanosis, and
death within 5 h. Post-mortem analysis evidenced stomach fundus hardening, mainly due to
the jamming of the compound in the lumen of the gastroesophageal sphincter, leading to
impaired respiration (Figure 4B). Since these results were derived from a physical rather
than toxicological mechanism, only doses 175-1400 mg/kg were considered.
Figure 4. Acute oral toxicity. Gross necropsy of a rat administered C#81 at: A) 175 mg/kg
and B) 2000 mg/kg. The latter dose highlights the hardening of the stomach fundus.
Table 4. Trends in body weight and percentage of mortality for animals given C#81.
*Mean, n=2
**Mean, n=3
By using Reed Muench’s formula, it was found that the estimated LD50 for C#81 is
1389.95 mg/kg. The results suggest that C#81 does not affect body weight.
Discussion and conclusion

ACCEPTED MANUSCRIPT
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
Pioglitazone is the only PPARγ agonist commercially available worldwide. In a few
countries, its sale has been restricted by the U.S. Food and Drug Administration (FDA)
because of being related to several cases of urinary bladder cancer. The other TZDs,
rosiglitazone and troglitazone, are no longer on the world market. Since rosiglitazone was
associated with a significant increase in myocardial infarction and death from
cardiovascular diseases, the European Medicines Agency withdrew approval for this
medication in 2010, and the FDA restricted its prescription in the United States [55-60].
For the in silico studies, the proposed compounds were substituted with electron-
withdrawing or electron-donating heteroatoms according to previous findings by Avupati,
et al. [20], who showed that an ortho, meta, and para substitution on the phenyl ring with a
hydroxyl group may enhance hypoglycemic activity. This was also found for a para
substitution with halogens such as chlorine [20]. Accordingly, the proposed compounds
C#40 and C#81 proved to be very good candidates.
The present results indicate that when the aromatic body is substituted with electron-
withdrawing heteroatoms, the compound attains a better interaction through hydrogen
bonding between the pharmacophore (TZD head) and the LBD of PPARγ. Approximately
2.3 Å in length, these hydrogen bonds are with the main residues Tyr473, Ser289, His323
and His449, notably changing the position of the H12 helix. This crucial helical component
of the receptor LBD provides a suitable surface for co-activator interaction and thereby
generates the transcriptional activity of the AF-2 domain [61,62]. Hence, the proposed
compounds interact in a way similar to the ones that served as patterns (rosiglitazone,
pioglitazone and troglitazone, as previously reported by several authors) [6,15,17,34,38,40],
meaning that they may also act in a comparable manner biologically.

ACCEPTED MANUSCRIPT
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
Since there are no heteroatoms susceptible to forming hydrogen bonding between the tail of
the compound and the LBD, the head of the compound (TZD) was directed toward the
main residues of this domain. Consequently, the aromatic tail assumed an equilibrated
position in relation to the hydrophobic residues in Arm I of the LBD, such as Leu, Ile, Ala
and Met, through Van der Waals forces [63].
Based on the current general synthesis methodology, the reaction was favored when the
benzaldehyde was substituted with electron-donating heteroatoms, and delayed in the cases
that the substituents were electron-withdrawing heteroatoms. This is mainly a consequence
of the two-step Knoevenagel condensation, in which a nucleophilic attack is followed by
dehydration. The nucleophilic attack is facilitated by the electron donors, and dehydration
by electron withdrawal [64-66]. It has been previously demonstrated that water, in the
presence of halogens, can facilitate the formation of nucleophilic species derived from the
acid head. For this reason, water was herein used as a solvent for the reaction of C#81, the
acid head in this case being TZD. The nucleophilic species could then attack the carbon of
the aldehyde [66].
According to the acute toxicity study, C#40 has adipogenic activity [7-9,15,19] at doses
over 350 mg/kg. This may result from the effect of PPARγ agonists on brown fat
differentiation, which was previously found with pioglitazone and other TZD-type drugs
[30,55]. However, there were no evident toxic effects in any animal except one that was
given 2000 mg/kg. Thus, the compound was classified as non-toxic and harmless at doses
under 2000 mg/kg, according to the Globally Harmonized System of Classification and
Labelling of Chemicals (GHS).
On the other hand, C#81 exhibited sedative effects at doses over 700 mg/kg, which could
be due to several factors. First, this compound is structurally similar to lamotrigine,

ACCEPTED MANUSCRIPT
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
bromazepam and clonidine, which are central nervous system (CNS) depressors with partial
sedative effects. Since doses over 700 mg/kg led to higher mortality of the animals, the
compound was classified as harmful in case of intake according to the GHS.
In conclusion, the two TZD derivatives, C#40 and C#81, were successfully designed,
synthesized and tested for safe usage in healthy animals. They acted as PPARγ agonists and
therefore may be beneficial for treating DM2. In a future study, these compounds will be
evaluated in a DM2 animal model.
Acknowledgments
The authors are grateful to the Consejo Nacional de Ciencia y Tecnología (CONACYT:
I010/0532/2014; 254600), the Comisión de Operación y Fomento de Actividades
Académicas/Secretaría de Investigación y Posgrado IPN (COFAASIP/IPN: 20160261,
20170539, 20171509, 20171323, 20171371), and the Programa Iberoamericano de Ciencia
y Tecnología para el Desarrollo (CYTED: 214RT0482) for their financial support. DAGD
thanks CONACYT for her PhD scholarship (No. 361927).
Conflict of interest
The authors have no conflict of interests concerning the use of any of the materials or
techniques mentioned herein. The authors alone are responsible for the content and writing
of the article.
References

ACCEPTED MANUSCRIPT
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
[1] World Health Organization, Department of noncommunicable disease surveillance.
Definition, diagnosis and classification of diabetes melllitus and its complications. Geneva,
1999.
[2] World Health Organization. Global status report on non-communicable diseases, 2014.
[3] American Diabetes Association. Standards of medical care in diabetes 2013, Position
statement. Diabetes Care, 2013; 36 (1): 11-66.
[4] American Diabetes Association. Classification and diagnosis of diabetes. Diabetes
Care, 2015, 38 (1): 8-16.
[5] American Diabetes Association. Standards of medical care in diabetes 2014. Diabetes
Care, 2014, 37 (1): 14-80.
[6] Elmazar MM, El-Abhar HS, Schaalan MF, Farag NA. Phytol/phytanic acid and insulin
resistance: Potential role of phytanic acid proven by docking simulation and modulation of
biochemical alterations. PLoS ONE, 2013; 8 (1): e45638.
[7] Parmenon C, Guillard J, Caignard DH, Hennuyer N, Staels B, Bouchez VA, Boutin JA,
Dacquet C, Ktorza A, Viaud MMC. 4,4-Dimethyl-1,2,3,4-tetrahydroquinoline-based PPAR
α/γ agonists. Part I: Synthesis and pharmacological evaluation. Bioorganic and Medicinal
Chemistry Letters, 2008; 18: 1617-1622.
[8] Kliewer SA, Sundseth SS, Jones SA, Brown PJ, Wisely GB, Koble CS, Devchand P,
Wahli W, Willson TM, Lenhard JM. Fatty acids and eicosanoids regulate gene expression
through direct interactions with peroxisome proliferator-activated receptors α and γ.
Biochemistry, 1997; 94: 4318-4323.
[9] Xu HE, Lambert MH, Montana VG, Parks DJ, Blanchard SG, Brown PJ, Sternbach DD,
Lehmann JM, Wisely GB, Willson TM, Kliewer SA, Milburn MV. Molecular recognition

ACCEPTED MANUSCRIPT
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
of fatty acids by peroxisome proliferator-activated receptors. Molecular Cell, 1999; 3: 397-
403.
[10] De los Ríos CJS, Sánchez SJJ, Barrios SP, Guerrero SV. Calidad de vida en pacientes
con diabetes mellitus tipo 2. Revista Médica del IMSS, 2004; 42 (2):109-116.
[11] Díaz FM, Baiza GLA, Ibáñez HMA, Pascoe LD, Guzmán GAM, Kumate RJ. Aspectos
moleculares del daño tisular inducido por la hiperglucemia crónica. Gaceta Médica de
México, 2004; 140 (4): 437-447.
[12] Fuster V, Ross R, Topol EJ. Aterosclerosis y enfermedad arterial coronaria. Ed.
Springer-Verlag Ibérica, Barcelona, 2007.
[13] Crepeau BE, Cohn ES, Boyt SBA. Terapia ocupacional. Ed. Médica Panamericana,
España, 10ª edición, 2008.
[14] Petersen RK, Christensen KB, Assimopoulou AN, Fretté X, Papageorgiou VP,
Kristiansen K, Kouskoumvekaki I. Pharmacophore-driven identification of PPARγ agonists
from natural sources. Journal of Computed-Aided Molecular Design, 2011; 25: 107-116.
[15] Medina G, Sewter C, Vidal PAJ. PPARγ y tiazolidinedionas, algo más que un
tratamiento contra la diabetes. Medicina Clínica Barcelona, 2000; 115: 392-397.
[16] Alemán GDD, Tamay CF, Álvarez AS, Mendieta WJE. Current advances in the
biochemical and physiological aspects of the treatment of type 2 diabetes mellitus with
thiazolidinediones. PPAR Research, 2016; Article ID 7614270.
[17] Gim HJ, Li H, Lee E, Ryu JH, Jeon R. Design and synthesis of alkoxyindolyl-3-acetic
acid analogs as peroxisome proliferator-activated recptor γ/δ agonists. Bioorganic &
Medicinal Chemistry Letters, 2013; 23: 513-517.
[18] Cronet P, Petersen JFW, Folmer R, Blomberg N, Sjöblom K, Karlsson U, Lindstedt
EL, Bamberg K. Structure of the PPARα and γ ligand binding domain in complex with

ACCEPTED MANUSCRIPT
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
AZ242; ligand selectivity and agonist activation in the PPAR family. Structure, 2001; 9:
699-706.
[19] Berger J, Leibowitz MD, Doeber TW, Elbrecht A, Zhang B, Zhou G, Biswas C,
Cullinan CA, Hayes NS, Li Y, Tanen M, Ventre J, Wu MS, Sahoo SP, Tolman RL, Smith
RG, Moller DE. Novel peroxisome proliferator-activated receptor (PPAR) γ and PPAR δ
ligands produce distinct biological effects. Journal of Biological Chemistry, 1999; 274
(10): 6718-6725.
[20] Avupati VR, Yejella RP, Akula A, Guntuku GS, Doddi BR, Vutla VR, Anagani SR,
Adimulam LS, Vyricharla AK. Synthesis, characterization and biological evaluation of
some novel 2,4-thiazolidinediones as potential cytotoxic, antimicrobial and
antihyperglycemic agents. Bioorganic & Medicinal Chemistry Letters, 2012; 22: 6442-
6450.
[21] Tan NS, Michalik L, Desvergne B, Wahli W. Multiple expression control mechanisms
of peroxisome proliferator-activated receptors and their target genes. Journal of Steroid
Biochemistry & Molecular Biology, 2005; 93: 99-105.
[22] Michalik L, Wahli W. Peroxisome proliferator-activated receptors: three isotypes for a
multitude of functions. Current Opinion in Biotechnology, 1999; 10: 564-570.
[23] Hidalgo FS, Ramírez EJJ, Estrada SS, Almanza PJC, Román RR, Alarcón AFJ,
Hernández RJV, Moreno DH, Díaz CD, Navarrete VG. Discovery of thiazolidine-2,4-
dione/biphenylcarbonitrile hybrid as dual PPARα/γ modulator with antidiabetic effect: In
vitro, in Silico and in vivo approaches. Chemical Biology & Drug Design, 2013; 81: 474-
483.
[24] Ye XY, Li YX, Farrelly D, Flynn N, Gu L, Locke KT, Lippy J, O´Malley K, Twamley
C, Zhang L, Ryono DE, Zahler R, Hariharan N, Cheng PTW. Design, synthesis, and

ACCEPTED MANUSCRIPT
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
structure-activity relationship of piperidine and dehydropiperidine carboxylic acids as
novel, potent dual PPARα/γ agonists. Bioorganic & Medicinal Chemistry Letters, 2008; 18:
3545-3550.
[25] Ye J. Regulation of PPARγ function by TNFα. Biochemical and Biophysical Research
Communications, 2008; 374: 405-408.
[26] Montanari R, Saccoccia F, Scotti E, Crestani M, Godio C, Gilardi F, Loiodice F,
Fracchiola G, Laghezza A, Tortorella P, Lavecchia A, Novellino E, Mazza F, Aschi M,
Pochetti G. Crystal structure of the peroxisome proliferator-activated receptor γ (PPARγ)
ligand binding domain complexed with a novel partial agonist: A new region of the
hydrophobic pocket could be exploited for drug design. Journal of Medicinal Chemistry,
2008; 51: 7768-7776.
[27] Wang W, Devasthale P, Farrelly D, Gu L, Harrity T, Cap M, Chu C, Kunselman L,
Morgan N, Ponticiello R, Zebo R, Zhang L, Locke K, Lippy J, O’Malley K, Hosagrahara
V, Zhang L, Kadiyala P, Chang C, Muckelbauer J, Doweyko AM, Zahler R, Ryono D,
Hariharan N, Cheng PTW. Discovery of azetidinone acids as conformationally-constrained
dual PPAR α/γ agonists. Bioorganic & Medicinal Chemistry Letters, 2008; 18: 1939-1944.
[28] García RP, Antaramian A, González DL, Villarroya F, Shimada A, Varela EA, Mora
O. Induction of peroxisomal proliferator-activated receptor γ and peroxisomal proliferator-
activated receptor γ coactivator 1 by unsaturated fatty acids, retinoic acid, and carotenoids
in preadipocytes obtained from bovine white adipose tissue. Journal of Animal Science,
2010; 88: 1801-1808.
[29] Prashantha BR, Soni M, Kumar SS, Singh K, Patil M, Baig RBN, Adhikary L.
Synthesis, glucose uptake activity and structure-activity relationships of some novel

ACCEPTED MANUSCRIPT
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
glitazones incorporated with glycine, aromatic and alicyclic amine moieties via two carbon
acyl linker. European Journal of Medicinal Chemistry, 2011; 46: 835-844.
[30] Willson TM, Cobb JE, Cowan DJ, Wiethe RW, Correa ID, Prakash SR, Beck KD,
Moore LB, Kliewer SA, Lehmann JM. The structure-activity relationship between
peroxisome proliferator-activated receptor γ agonism and the antihyperglycemic activity of
thiazolidinediones. Journal of Medicinal Chemistry, 1996; 39: 665-668.
[31] Willson TM, Brown PJ, Sternbach DD, Henke BR. The PPARs: From orphan
receptors to drug discovery. Journal of Medicinal Chemistry, 2000; 43 (4): 527-550.
[32] Vosper H, Khoudoli GA, Graham TL, Palmer CAN. Peroxisome proliferator-activated
receptor agonists, hyperlipidaemia, and atherosclerosis. Pharmacology & Therapeutics,
2002; 95: 47-62.
[33] Willson TM, Wahli W. Peroxisome proliferator-activated receptor agonists. Current
Opinion in Chemical Biology, 1997; 1: 235-241.
[34] Zoete V, Grosdidier A, Michielin O. Peroxisome proliferator-activated receptor
structures: Ligand specificity, molecular switch and interactions with regulators.
Biochimica et Biophysica Acta, 2007; 1771: 915-925.
[35] Sheu SH, Kaya T, Waxman DJ, Vajda S. Exploring the binding site structure of the
PPARγ ligand-binding domain by computational solvent mapping. Biochemistry, 2005; 44:
1193-1209.
[36] Xiao B, Yin J, Park M, Liu J, Lin LJ, La KE, Hong J, Young CH, Jung JH. Design and
synthesis of marine fungal phtalide derivatives as PPARγ agonists. Bioorganic &
Medicinal Chemistry, 2012; 20: 4954-4961.

ACCEPTED MANUSCRIPT
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
[37] Osman ABSMG, Sylte I. Molecular recognition of docosahexaenoic acid by
peroxisome proliferator-activated receptors and retinoid-X receptor α. Journal of Molecular
Graphics and Modelling, 2008; 27: 217-224.
[38] Gim HJ, Cheon YJ, Ryu JH, Jeon R. Design and synthesis of benzoxazole containing
indole analogs as peroxisome proliferator-activated receptor γ/δ dual agonists. Bioorganic
& Medicinal Chemistry Letters, 2011; 21: 3057-3061.
[39] Cho MC, Lee DH, Kim EJ, Lee JY, Kang JW, Song JH, Chong Y, Kim Y, Hong JT,
Yoon DY. Novel PPARγ partial agonists with weak activity and no cytotoxicity, identified
by a simple PPARγ ligand screening system. Molecular and Cell Biochemistry, 2011; 358:
75-83.
[40] Salam NK, Huang THW, Kota BP, Kim MS, Li Y, Hibbs DE. Novel PPAR-gamma
agonists identified from a natural product library: A virtual screening, induced-fit docking
and biological assay study. Chemical Biology and Drug Design, 2008; 71: 57-70.
[41] Bourguet W, Germain P, Gronemeyer H. Nuclear receptor ligand-binding domains:
three-dimensional structures, molecular interactions and pharmacological implications.
TiPS, 2000; 21: 381-388.
[42] Frisch MJ, Trucks GW, Schlegel HB, Scuseria GE, Robb MA, Cheeseman JR,
Zakrzewski VG, Montgomery JA Jr, Stratmann RE, Burant JC, Dapprich S, Millan JM,
Daniels AD, Kudin KN, Strain MC, Farkas O, Tomasi J, Barone V, Cossi M, Cammi R,
Mennucci B, Pomelli C, Adamo C, Clifford S, Ochterski J, Peterson GA, Ayala PY, Cui Q,
Morokuma K, Malick DK, Rabuck AD, Raaghavachari K, Foresman JB, Cioslowski J,
Ortiz JV, Baboul AG, Stefanov BB, Liu G, Liashenko A, Piskorz P, Komaromi I, Gomperts
R, Martin RL, Fox DJ, Keith T, Al-Laham MA, Peng CY, Nanayahkara A, González C,

ACCEPTED MANUSCRIPT
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
Challacombe M, Gill PMW, Johnson B, Chen W, Wong MW, Andres JL, Head-Gordon M,
Replogle ES, Pople JA Gaussian 98 Revision A.7. Gaussian Inc, Pittsburgh PA, 1998.
[43] Morris GM, Huey R, Lindstrom W, Sanner MF, Belew RK, Goodsell DS, Olson AJ.
AutoDock4 and AutoDockTools4: Automated docking with selective receptor flexibility.
Journal of Computational Chemistry, 2009; 30(16): 2785-2791.
[44] Phillips JC, Braun R, Wang W, Gumbart J, Tajkhorshid E, Villa E, Chipot C, Skeel
RD, Kalé L, Schulten K. Journal of Computational Chemistry, 2005; 26(16): 1781-1802.
[45] Interactive Structure based Sequences Alignment Program (STRAP):
http://www.bioinformatics.org/strap/
[46] Protein Data Bank (PDB): http://www.rcsb.org/pdb/home/home.do/
[47] Morris GM, Goodsell DS, Halliday RS, Huey R, Hart WE, Belew RK, Olson AJ.
Automated docking using Lamarckian genetic algorithm and an empirical binding free
energy function. Journal of Computational Chemistry, 1998; 19: 1639–1662.
[48] Humphrey W, Dalke A, Schulten K. VMD – Visual Molecular Dynamics. Journal of
Molecular Graphics, 1996; 14: 33-38.
[49] Molinspiration Cheminformatics: http://www.molinspiration.com/
[50] Osiris Property Explorer: http://www.organic-chemistry.org/prog/peo/
[51] Mi HY, Jung PY, Kim JA, Park D, Young PJ, Jin LH, Yeon LJ, Ryong MH, Young
CH. Design and synthesis of 5-(substituted benzylidene)thiazolidine-2,4-dione derivatives
as novel tyrosinase inhibitors. European Journal of Medicinal Chemistry, 2012; 49: 245-
252.
[52] Shah S, Singh B. Urea/thiourea catalyzed, solvent-free synthesis of 5-
arylidenethiazolidine-2,4-diones and 5-arylidene-2-thioxothiazolidin-4-ones. Bioorganig &
Medicinal Chemistry Letters, 2012; 22: 5388-5391.

ACCEPTED MANUSCRIPT
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
[53] OECD. Guideline for the testing of chemicals No. 425: Acute Oral Toxicity: Up and
Down Procedure. 2008.
[54] Nain P, Saini V, Sharma S, Nain J. Antidiabetic and antioxidant potential of Emblica
officinalis Gaertn. Leaves extract in streptozotocin-induced type 2 diabetes mellitus
(T2DM) rats. Journal of Ethnopharmacology, 2012; 142: 65-71.
[55] Wright HM, Clish CB, Mikami T, Hauser S, Yanagi K, Hiramatsu R, Serchan CN,
Spiegelman BM. A synthetic antagonist for the peroxisome proliferator-activated receptor γ
inhibits adipocyte differentiation. Journal of Biological Chemistry, 2000; 275: 1873-1877.
[56] Balakumar P, Mahadevan N. Interplay between statins and PPARs in improving
cardiovascular outcomes: a double-edged sword? British Journal of Pharmacology, 2012;
165: 373-379.
[57] Balakumar P, Kathuria S. Submaximal PPARγ activation and endothelial dysfunction:
new perspectives for the management of cardiovascular disorders. British Journal of
Pharmacology, 2012; 166: 1981-1992.
[58] Grygiel GB. Peroxisome proliferator-activated receptors and their ligands: nutritional
and clinical implications – a review. Nutrition Journal, 2014; 13 (17): 1-10.
[59] Atamer Y, Atamer A, Can AS, Hekimoglu A, Ilhan N, Yenice N, Koҫyigit Y. Effects
of rosiglitazone on serum paraoxonase activity and metabolic parameters in patients with
type 2 diabetes mellitus. Brazilian Journal of Medical and Biological Research, 2013; 46:
528-532.
[60] García RP, Antaramian A, González DL, Villarroya F, Shimada A, Varela EA, Mora
O. Induction of peroxisomal proliferator-activated receptor γ and peroxisomal proliferator-
activated receptor γ coactivator 1 by unsaturated fatty acids, retinoic acid, and carotenoids

ACCEPTED MANUSCRIPT
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
in preadipocytes obtained from bovine white adipose tissue. Journal of Animal Science,
2010; 88: 1801-1808.
[61] Moras D, Gronemeyer H. The nuclear receptor ligand-binding domain: structure and
function. Current Opinion in Cell Biology, 1998; 10: 384-391.
[62] Torchia J, Glass C, Rosenfeld MG. Co-activators and co-repressors in the integration
of transcriptional responses. Current Opinion in Cell Biology, 1998; 10: 373-383.
[63] Winterton RHS. Van der Waals forces. Contemporary Physics, 1970; 11 (6): 559-574.
[64] Jenner G. Steric effects in high pressure Knoevenagel reactions. Tetrahedron Letters,
2001; 42: 243-245.
[65] Bigi F, Carloni S, Ferrari L, Maggi R, Mazzacani A, Sartori G. Clean synthesis in
water. Part 2: Uncatalyzed condensation of Meldrum´s acid and aldehydes. Tetrahedrom
Letter, 2001; 42: 5203-5205.
[66] Calvino CV, Martín ARM, López PAJ, Sobczak I, Ziolek M. Catalytic properties of
alkali metal-modified oxide supports for the Knoevenagel condensation: Kinetic aspects.
Catalysis Today, 2009; 142: 278-282.

ACCEPTED MANUSCRIPT
Compound
Molecular
formula
Docking
(kcal/mol)
No. of H bonds, residues and distances
C
18
H
19
N
3
O
3
S
S
-10.68
5 (His323/1.99 Å, His449/2.09 Å, Tyr473/3.01 Å,
Ser289/1.72 Å, Gln286/1.86 Å)
Rosiglitazone
C19
H
20
N
2
O3
-11.03
-11.67
-7.26
5 (His323/1.92 Å, His449/2.00 Å, Tyr473/3.07 Å,
Ser289/1.70 Å, Gln286/1.88 Å)
Pioglitazone
C
24
H
27NO
NO
ClFNO
5
S
5 (His323/1.80 Å, His449/1.83 Å, Tyr473/3.35 Å,
Ser289/1.88 Å, Gln286/2.24 Å)
Troglitazone
C
10
H
7
3
S
5 (His323/1.91 Å, His449/2.06 Å, Tyr473/3.01 Å,
Ser289/2.07 Å, Gln286/1.83 Å)
40
81
C10
H
5
2
S
-7.51
5 (His323/1.85 Å, His449/1.85 Å, Tyr473/2.89 Å,
Ser289/1.72 Å, Gln286/2.01 Å)

ACCEPTED MANUSCRIPT
Compound
Molecular
formula
Molecular
weight
Polar
surface (Å)
H
donors
H
log P
acceptors
C
C
18
19
H
19
20
N
3
2
O
3
3
S
S
357.435
356.447
441.546
221.237
257.673
71.533
68.295
84.865
70.161
49.933
1
1
2
2
1
6
5
6
4
3
2.346
3.071
5.031
1.423
2.228
Rosiglitazone
Pioglitazone
Troglitazone
40
H
N
O
C
24
10
10
H
27NO
NO
ClFNO
5S
C
H
7
3S
C
H
5
2S
81

ACCEPTED MANUSCRIPT
Dose
(mg/kg)
175
Initial
Final
Weight
Dead Alive
Mortality
weight (g) weight (g) increase (g)
%
0
183.6
195.3
216.2
222.0
234.7*
204.3
218.7
263.3
274.4
286.1*
20.7
23.4
47.1
52.4
51.4*
0
0
0
0
1
1
1
1
1
5
0
350
0
700
0
1400
2000
20

ACCEPTED MANUSCRIPT
Dose
(mg/kg)
175
Initial
Final
Weight
Dead Alive
Mortality
weight (g) weight (g) increase (g)
%
0
186.1
189.5
204.3
211.9
18.2
22.4
0
0
0
1
1
1
3
1
0
350
204.6**
212.2*
231.7**
232.6*
27.1**
20.4*
0
700
50
1400

ACCEPTED MANUSCRIPT
