SYNTHETIC COMMUNICATIONSw
Vol. 34, No. 7, pp. 1259–1264, 2004
A New and Facile Method for the Synthesis
of Nitrocarbazoles by Urea Nitrate
Rajagopal Nagarajan, D. Muralidharan, and
*
Paramasivan T. Perumal
Organic Chemistry Division, Central Leather Research Institute,
Chennai, India
ABSTRACT
Urea nitrate in acetic acid is found to be an effective and mild nitrating
agent for the preparation of mono nitrocarbazoles.
Key Words: Acetylation; Urea nitrate; Nitration; Carbazoles;
Nitrocarbazoles.
INTRODUCTION
The synthesis of substituted carbazoles[1] has attracted considerable
attention in recent years as this class of compounds constitute structural
*
Correspondence: Paramasivan T. Perumal, Organic Chemistry Division, Central
Leather Research Institute, Adyar, Chennai 600 020, India; Fax: 91-44-24911589;
E-mail: ptperumal@hotmail.com.
1259
DOI: 10.1081/SCC-120030313
0039-7911 (Print); 1532-2432 (Online)
www.dekker.com
Copyright # 2004 by Marcel Dekker, Inc.

ORDER
REPRINTS
1260
Nagarajan, Muralidharan, and Perumal
frameworks of several naturally occurring bioactive alkaloids. In particular,
acetylcarbazoles have been used to synthesize condensed carbazole hetero-
cycles, alkaloids etc.
The acetylation of 9-ethyl carbazole with acetyl chloride catalyzed by
AlCl3 had been reported[2] to give a mixture of 3- and 3,6-diacetyl derivatives
and large amount of tarry products, which was attributed to high acidity of
AlCl3. In continuation of our interest on InCl3 catalyzed reactions,[3] the
acetylation of carbazoles was studied.
The reaction of 9-ethylcarbazole with excess acetic anhydride in the pres-
ence of 20 mol% InCl3 for 2 hr revealed (TLC), the 3-acetylated derivative
with no traces of diacetylcarbazole. In addition, a small quantity of tarry
material was observed. Similar results were observed with In(OTf)3.
Recently, we have found that urea nitrate is an efficient catalyst for imino
Diels–Alder reaction[4] and aromatization of 1,4-dihydropyridines.[5] In order
to evaluate the catalytic efficiency of urea nitrate for acetylation, the reaction
was repeated for 9-ethylcarbazole with acetic anhydride in the presence of
urea nitrate. TLC shows the formation of a new yellow product (16% yield
was obtained with 20 mol% of urea nitrate). Analysis of the new product
showed that the compound was 3-nitro-9-ethylcarbazole. Based on these find-
ings it was proposed that acetic acid formed or present in acetic anhydride may
be the proton source, which reacted with urea nitrate, thereby effected the
nitration (Sch. 1).
Literature survey[6] on nitration of carbazoles revealed that 3- and
6-positions of carbazole were the most reactive with the 1- and 8-positions
being less reactive particularly towards nitration. Lindeman[7] found that treat-
ment of carbazole in acetic acid with NaNO2 followed by nitric acid yielded
principally 3-nitro-9-nitrosocarbazole which on heating with KOH or glacial
acetic acid gave 3-nitrocarbazole. Other nitration methods include the use of
conc. HNO3 or C(NO2)4 under photochemical conditions.[9] Exhaustive
[8]
nitration gives 1,3,6,8-tetranitro carbazole.[10] The nitration of carbazole
with conc. nitric acid yielded dinitrocarbazoles.[11]
The methodology of nitration with acetic acid and urea nitrate was
extended to other substituted carbazoles. Most of carbazole derivatives
Scheme 1.

ORDER
REPRINTS
Synthesis of Nitrocarbazoles by Urea Nitrate
1261
underwent nitration reaction in a short period of time (except for 3-substituted
carbazoles which required acidic conditions achieved by addition of few drops
of 10% sulfuric acid in acetic acid) in good yields (Table 1). In mother liquor a
trace amount of 1-nitrocarbazoles was found.
Finally, we have shown that urea nitrate–acetic acid combination is a
mild, selective and efficient reagent for nitration of carbazole (Sch. 2).
EXPERIMENTAL
Analytical TLC was performed on precoated sheets of silica gel G of
0.25 mm thickness containing PF 254 indicator. Column chromatography
was performed with silica gel (60–120 mesh). IR spectra were recorded as
KBr pellets on FTIR spectrometer. 1H NMR spectra were recorded at
300 MHz in CDCl3 and the chemical shifts are given in d relative to the
solvent (77.0).
Typical Procedure for Acetylation
To a stirred mixture of carbazole (0.5 g, 2.56 mmol) and acetic anhydride
(7.69 mmol) in CH2Cl2 (10 mL), InCl3 or In(OTf)3 (0.51 mmol) was added and
stirred for appropriate time. Water (50 mL) was added to the reaction mixture,
extracted with CH2Cl2 (3 Â 10 mL) and dried with anhydrous Na2SO4. The
solvent was distilled off and the residue chromatographed over silica gel by
eluting with ethyl acetate : petroleum ether (1 : 9) to give the acetyl carbazoles.
3-Acetyl-9-ethylcarbazole (2). 0.358 g (59%) of colorless needles; m.p.
115–1168C (Lit.[2] 115); IR: 3046, 2921, 1667, 1593, 1495, 1351, 1170,
Table 1. Synthesis of nitrocarbazoles.
Substituents
Time
(min)
Yield
(%)
Carbazole
R1
R2
1a
1b
1c
1d
1e
H
CH3
H
10a
20
86
83
81
92
85
H
C2H5
C2H5
C2H5
H
20
CH3
CHO
10b
15b
aDue to limited solubility of carbazole at r.t., the reaction is conducted at 708C.
bThe three substituted carbazole requires few drops (0.4 mL) of 10% conc.
H2SO4 in glacial acetic acid.

ORDER
REPRINTS
1262
Nagarajan, Muralidharan, and Perumal
Scheme 2.
1
838 cm21; H NMR (300MHz, CDCl3): d 8.75 (d, 1H, J ¼ 1.2 Hz), 8.18
(m, 2H), 7.50 (t, 1H, J ¼ 7.1 Hz), 7.46–7.26 (m, 3H), 4.42 (q, 2H,
J ¼ 7.2 Hz), 2.73 (s, 3H), 1.46 (t, 3H, J ¼ 7.2 Hz); 13C NMR (75 MHz,
CDCl3): d 197.2, 142.2, 140.2, 128.3, 126.0, 122.8, 122.2, 121.4, 120.2,
119.5, 108.5, 107.6, 107.4, 37.3, 26.1, 13.3; Mass m/z 237 (Mþ); Anal. Calcd
for C16H15NO; C, 80.98; H, 6.37; N, 5.90; Found, C, 81.22; H, 6.48; N, 6.76.
Typical Procedure for Nitration of Carbazoles
To a stirred solution of carbazole (3 mmol) in acetic acid (10 mL), urea
nitrate (3 mmol) was added and stirred for appropriate time. After the reaction
was over, the precipitate formed by the addition of water was filtered and
dried. The crude product was recrystallized from acetic acid to give
nitrocarbazoles.
3-Nitrocarbazole (3a). 0.547 g (86%) of yellow crystals; m.p. 215–
2168C (Lit.[12] 215–216); IR: 3334, 3033, 1605,1580, 1500, 1457, 1313,
1
722 cm21; H NMR (300 MHz, DMSO-d6): d 12.05 (brs, 1H, NH), 9.14
(d, 1H, J ¼ 2.4 Hz), 8.36 (d, 1H, J ¼ 10.4 Hz), 8.30 (dd, 1H, J1 ¼ 2.4 Hz,
J2 ¼ 11.6 Hz), 7.63–7.47 (m, 3H), 7.30 (t, 1H, J ¼ 9.6 Hz); 13C NMR
(75 MHz, DMSO-d6): d 143.3, 141.0, 139.8, 127.3, 122.5, 122.2, 121.4,
121.3, 120.3, 117.4, 111.9, 111.1; Mass m/z 212 (Mþ); Anal. Calcd for
C12H8N2O2; C, 67.92; H, 3.80; N, 13.20; Found, C, 67.76; H, 3.87; N, 13.09.
3-Nitro-9-methylcarbazole (3b). 0.563 g (83%) of yellow needles; m.p.
174–1758C (Lit.[12] 173–174); IR: 3082, 2924, 1593, 1510,1472, 1317,
1
744 cm21; H NMR (300 MHz, CDCl3): d 8.82 (d, 1H, J ¼ 2.1 Hz), 8.27
(dd, 1H, J1 ¼ 2.2 Hz, J2 ¼ 9.0 Hz), 8.00 (d, 1H, J ¼ 7.8 Hz), 7.51 (t, 1H,
J ¼ 7.4 Hz), 7.36–7.17 (m, 4H), 3.77 (s, 3H); 13C NMR (75 MHz, CDCl3):
d 143.8, 142.0, 140.4, 127.4, 122.6, 122.3, 121.5, 120.8, 120.7, 117.1,
109.4, 107.9, 29.5; Mass m/z 226 (Mþ); Anal. Calcd for C13H10N2O2; C,
69.02; H, 4.46; N, 12.38; Found, C, 69.39; H, 4.38; N, 12.12.

ORDER
REPRINTS
Synthesis of Nitrocarbazoles by Urea Nitrate
1263
3-Nitro-9-ethylcarbazole (3c). 0.583 g, (81%) of yellow crystalline
solid; m.p. 127–1288C (Lit.[12] 126–127); IR: 3048, 2930, 1591, 1510,
1
1471, 1313, 749 cm21; H NMR (300 MHz, CDCl3): d 8.96 (d, 1H, J ¼
1.9 Hz), 8.38 (dd, 1H, J1 ¼ 2.0 Hz, J2 ¼ 12.5 Hz), 8.13 (d, 1H, J ¼ 7.8 Hz),
7.60 (t, 1H, J ¼ 7.6 Hz), 7.48 (m, 3H), 4.43 (q, 2H, J ¼ 7.1 Hz), 1.47 (t, 3H,
J ¼ 7.2 Hz); 13C NMR (75 MHz, CDCl3): d 143.0, 141.1, 140.6, 127.4, 122.9,
122.6, 121.6, 121.0, 120.7, 117.3, 109.4, 107.9, 38.1, 13.8; Mass m/z 240
(Mþ); Anal. Calcd for C14H12N2O2; C, 69.99; H, 5.03, N, 11.66; Found, C,
70.24; H, 4.93; N, 11.53.
3-Methyl-6-nitro-9-ethylcarbazole (3d). 0.701 g (92%) of yellow solid;
m.p. 89–908C; IR: 3093, 2965, 1598, 1487, 1385, 1307, 800 cm21; 1H NMR
(300 MHz, CDCl3): d 8.88 (d, 1H, J ¼ 2.2 Hz), 8.32 (dd, 1H, J1 ¼ 2.2 Hz,
J2 ¼ 9.0 Hz), 8.06 (d, 1H, J ¼ 7.7 Hz), 7.57 (t, 1H, J ¼ 8.1 Hz), 7.44–7.24
(m, 2H), 4.36 (q, 2H, J ¼ 7.2 Hz), 2.56 (s, 3H), 1.43 (t, 3H, J ¼ 7.2 Hz);
13C NMR (75 MHz, CDCl3): d 142.7, 140.9, 140.2, 127.2, 122.6, 122.3,
121.3, 120.8, 120.5, 117.0, 109.3, 107.8, 37.9, 21.5, 13.7; Mass m/z 254
(Mþ); Anal. Calcd for C15H14N2O2; C, 70.85; H, 5.55; N, 11.02; Found, C,
70.66; H, 5.61; N, 10.86.
6-Nitro-9-ethylcarbazole-3-aldehyde (3e). 0.683 g (85%) of yellow
solid; m.p. 247–2488C (Lit.[13] 248) IR: 3076, 2964, 1687, 1627, 1593,
1509, 1483, 1383, 1311, 723 cm21 1H NMR (300 MHz, DMSO-d6): d
;
10.14 (s, 1H, CHO), 9.04 (s, 1H), 8.65 (s, 1H), 8.46 (d, 1H, J ¼ 8.5 Hz),
8.14 (d, 1H, J ¼ 8.0 Hz), 7.60–7.49 (m, 2H), 4.89 (q, 2H, J ¼ 7.1 Hz), 1.53
(t, 3H, J ¼ 7.1 Hz); 13C NMR (75 MHz, DMSO-d6): d 192.2, 144.7, 143.9,
141.1, 129.9, 128.1, 125.6, 122.7, 122.5, 122.4, 118.2, 111.1, 110.5, 38.4,
14.1; Mass m/z 268 (Mþ); Anal. Calcd for C15H12N2O3; C, 67.16; H, 4.51;
N, 10.44; Found, C, 66.89; H, 4.65; N, 10.23.
ACKNOWLEDGMENT
We thank the Council of Scientific and Industrial Research, New Delhi,
India for financial support.
REFERENCES
1. (a) Knolker, H.-J.; Reddy, K.R. Isolation and synthesis of biologically
active carbazole alkaloids. Chem. Rev. 2002, 102, 4303–4427;
(b) Knolker, H.-J. Transition metal complexes in organic synthesis. Part
47. Organic synthesis via tricarbonyl (h4-diene) iron complexes. Chem.
Soc. Rev. 1999, 28, 151–157.

ORDER
REPRINTS
1264
Nagarajan, Muralidharan, and Perumal
2. Buu-Hoi, Ng.Ph.; Royer, R. Potential nitrogen-heterocycle carcinogens.
III. New derivatives of N-ethyl carbazole. J. Org. Chem. 1950, 15,
123–157.
3. (a) Babu, G.; Perumal, P.T. Synthetic applications of indium trichloride
catalyzed reactions. Aldrichim. Acta 2000, 33, 16–22; (b) Babu, G.;
Perumal, P.T. Imino Diels–Alder reactions catalyzed by indium trichlo-
ride (InCl3). Facile synthesis of quinoline and phenanthridinone deriva-
tives. Tetrahedron Lett. 1997, 38, 5025–5026; (c) Babu, G.;
Nagarajan, R.; Natarajan, R.; Perumal, P.T. Indium trichloride-catalyzed
imino Diels–Alder reactions: synthesis of new indolylquinoline deriva-
tives. Synthesis 2000, 661–666.
4. Anniyappan, M.; Nagarajan, R.; Perumal, P.T. Urea nitrate catalyzed
imino Diels–Alder reactions: synthesis of cyclopentaquinolines, pyrano-
quinolines and furoquinolines derivatives. Synth. Commun. 2002,
32, 99–103.
5. Anniyappan, M.; Muralidharan, D.; Perumal, P.T. A novel application of
the oxidizing properties of urea nitrate and peroxydisulfate-cobalt(II):
aromatization of NaD(P)H model Hantzsch 1,4-dihydropyridines. Tetra-
hedron 2002, 58, 5069–5073.
6. Storrie, F.R.; Tucker, S.H. Syntheses in the carbazole series. Alleged syn-
thesis of 3-nitro-N-ethylcarbazole. J. Chem. Soc. 1931, 2255–2263.
7. Lindemann, R. Chemistry of carbazole. Ber. 1924, 57B, 555–559.
8. Morgan, G.T.; Mitchell, J.G. Search for trypanocidal activity. Derivatives
of dehydrothio-p-toluidinesulfonic acid and of 3-aminocarbazoledisulfo-
nic acid. J. Chem. Soc. 1931, 3279–3283.
9. Iles, D.H.; Ledwith, A. Charge transfer spectrums and reaction intermedi-
ates: photochemical nitration of carbazoles with tetranitromethane.
J. Chem. Soc. D. Chem. Commun. 1969, 9, 364–365.
10. Ziersch, P. Carbazole derivatives. Ber. 1910, 42, 3977–3980.
11. Grotta, H.M.; Riggle, C.J.; Bearse, A.E. Dinitrocarbazoles. J. Org. Chem.
1964, 29, 2474–2476.
12. Kyziol, J.B.; Dasziewicz, Z.; Hetper, J. Fragmentation of some nitrocar-
bazoles and their 9-alkyl derivatives. Org. Mass Spectrom. 1987, 22 (1),
39–42.
13. Buu-Hoi, Hg.Ph.; Hoan, Ng. Potential nitrogen-heterocycle carcinogens.
XII. 9-Ethyl carbazole-3-aldehyde and its derivatives. J. Org. Chem.
1951, 16, 1327–1332.
Received in India October 17, 2003

Request Permission or Order Reprints Instantly!
Interested in copying and sharing this article? In most cases, U.S. Copyright
Law requires that you get permission from the article’s rightsholder before
using copyrighted content.
All information and materials found in this article, including but not limited
to text, trademarks, patents, logos, graphics and images (the "Materials"), are
the copyrighted works and other forms of intellectual property of Marcel
Dekker, Inc., or its licensors. All rights not expressly granted are reserved.
Get permission to lawfully reproduce and distribute the Materials or order
reprints quickly and painlessly. Simply click on the "Request Permission/
Order Reprints" link below and follow the instructions. Visit the
U.S. Copyright Office for information on Fair Use limitations of U.S.
copyright law. Please refer to The Association of American Publishers’
Fair Use in the Classroom.
(AAP) website for guidelines on
The Materials are for your personal use only and cannot be reformatted,
reposted, resold or distributed by electronic means or otherwise without
permission from Marcel Dekker, Inc. Marcel Dekker, Inc. grants you the
limited right to display the Materials only on your personal computer or
personal wireless device, and to copy and download single copies of such
Materials provided that any copyright, trademark or other notice appearing
on such Materials is also retained by, displayed, copied or downloaded as
part of the Materials and is not removed or obscured, and provided you do
not edit, modify, alter or enhance the Materials. Please refer to our
Website
User Agreement for more details.
Request Permission/Order Reprints
Reprints of this article can also be ordered at
http://www.dekker.com/servlet/product/DOI/101081SCC120030313
