5.31 – 5.11 (m, 2H), 4.38 (d, J = 8.1 Hz, 1H), 3.98 – 3.85 (m, 2H),
– 1.95 (m, 6H), 1.74 – 1.52 (m, 3H), 1.44 (s, 3H), 1.37 (s, 3H),
1
2
3
4
5
6
7
8
3.51 (dd, J = 11.6, 4.9 Hz, 1H), 2.81 (s, 1H), 2.43 (d, J = 10.5 Hz,
1H), 2.21 (d, J = 14.2 Hz, 1H), 2.16 – 2.10 (m, 1H), 2.09 – 2.06
(m, 1H), 2.05 (s, 3H), 2.01 – 1.95 (m, 1H), 1.94 – 1.85 (m, 2H),
1.56 (dd, J = 11.7, 5.4 Hz, 1H), 1.51 (s, 3H), 1.35 (s, 3H), 1.30 (s,
3H), 1.29 – 1.27 (m, 1H) 1.26 (s, 3H), 1.21 (d, J = 7.1 Hz, 3H),
0.87 (s, 9H), 0.10 (s, 3H), 0.09 (s, 3H); 13C{1H} NMR (100 MHz,
CDCl3) δ 169.3, 138.4, 118.1, 117.8, 98.1, 92.1, 80.6, 78.0, 75.1,
61.1, 54.2, 45.7, 42.5, 35.6, 35.4, 35.1, 27.8, 27.4, 25.7, 22.2,
21.8, 20.8, 17.6, 16.6, -4.1, -5.4; HRMS (ESI+) m/z calcd for
C29H50N2O6SiNa (M+Na)+: 573.3336, found: 573.3331; IR (neat)
ν 3565, 2933, 2857, 1739, 1367, 1244, 1053, 835, 777 cm-1. SI-
23: Rf 0.30 (silica gel, 2:1 petroleum ether/ ethyl acetate, UV,
pink, p-anisaldehyde); 1H NMR (400 MHz, CDCl3) δ 5.72 (dt, J =
16.4, 10.0 Hz, 1H), 5.36 – 5.16 (m, 2H), 4.18 (d, J = 2.2 Hz, 1H),
4.10 (dd, J = 12.0, 3.5 Hz, 1H), 3.94 (d, J = 3.8 Hz, 1H), 3.66 (dd,
J = 12.0, 1.8 Hz, 1H), 3.16 (d, J = 9.6 Hz, 1H), 3.00 (ddd, J = 17.5,
6.1, 2.5 Hz, 1H), 2.85 (s, 1H), 2.73 (dd, J = 17.5, 1.7 Hz, 1H), 2.32
– 2.23 (m, 1H), 2.22 – 2.07 (m, 2H), 2.01 – 1.92 (m, 1H), 1.63 –
1.54 (m, 1H), 1.42 (s, 3H), 1.37 (s, 3H), 1.33 (s, 3H), 1.30 (s, 3H),
1.11 (d, J = 7.1 Hz, 3H), 0.87 (s, 9H), 0.12 (s, 3H), 0.10 (s, 3H);
13C{1H} NMR (100 MHz, CDCl3) δ 150.4, 149.2, 135.3, 120.0,
98.1, 92.1, 79.4, 77.8, 75.2, 60.4, 54.0, 47.3, 36.0, 35.6, 29.1,
28.4, 26.9, 25.7, 21.4, 20.5, 19.1, 17.7, 16.3, -4.3, -4.9; HRMS
(ESI+) m/z calcd for C27H47N2O4Si (M+H)+: 491.3305, found:
491.3297; IR (neat) ν 3501, 2930, 2859, 1379, 1194, 1089,
1075, 966, 833, 778 cm-1.
1.30 (s, 3H), 1.05 (d, J = 6.9 Hz, 6H), 0.24 (d, J = 12.1 Hz, 1H);
13C{1H} NMR (100 MHz, CDCl3) δ 170.8, 138.1, 117.5, 98.1, 80.1,
79.0, 77.9, 64.1, 60.9, 54.5, 44.9, 41.8, 39.8, 36.4, 36.1, 32.7,
29.0, 28.7, 25.2, 21.2, 19.9, 17.3, 15.9; HRMS (ESI+) m/z calcd
for C23H37O6 (M+H)+: 409.2590, found: 409.2588; IR (neat) ν
3534, 3384, 2957, 2935, 2871, 1733, 1373, 1221, 1194, 967,
912, 836 cm-1.
Preparation
of
(1S,3R,4R,5S,6R)-4-hydroxy-4-
((4aR,6S,7R,7aS)-7-hydroxy-2,2-dimethyl-7-(2-
methylallyl)hexahydrocyclopenta[d][1,3]dioxin-6-yl)-
3,7,7-trimethyl-5-vinylbicyclo[4.1.0]heptan-1-yl acetate
(35). To a stirred solution of secondary alcohol 67 (204 mg,
0.50 mmol, 1.00 equiv), 4Å MS (200 mg), 4-Methylmorpholine
N-oxide monohydrate (203 mg, 1.50 mmol, 3.00 equiv) in
CH2Cl2 (40 mL) at 0 °C was added TPAP (35 mg, 0.10 mmol, 0.20
equiv), and the reaction mixture was stirred at room
temperature for 5 h. The resulting mixture filtered through a
short pad of Florisil®, elution with CH2Cl2 (20 mL) and
concentrated in vacuo. The resulting oil was dissolved in THF
(10 mL), at -78 °C was added a solution of 2-Methylallylzinc
chloride (0.55 mmol, 1.10 equiv, prepared from 0.55 mL zinc
chloride (1.0 M in THF) and 1.10 mL 2-Methylallylmagnesium
chloride (0.5 M in THF)), and the reaction mixture was stirred
at -78 °C for 5 min. Then warmed to 0 °C, the resulting mixture
was quenched with sat. aq. ammonium chloride. Ethyl acetate
(3 x 10 mL) was added, and the upper organic layer was
separated. The organic layer was dried with anhydrous sodium
sulfate, the crude was purified by flash chromatography
(petroleum ether/ ethyl acetate 10:1) to give diene 35 (143 mg,
0.31 mmol, 62%, over 2 steps) as colorless oil. Rf 0.32 (silica
gel, 5:1 petroleum ether/ ethyl acetate, purple, p-
anisaldehyde); 1H NMR (400 MHz, CDCl3) δ 6.29 (ddd, J = 17.1,
10.4, 9.2 Hz, 1H), 5.12 (dd, J = 10.4, 8.7 Hz, 2H), 4.83 (s, 1H),
4.66 (s, 1H), 4.22 – 4.04 (m, 3H), 3.65 (d, J = 12.0 Hz, 1H), 3.40
(s, 1H), 2.75 (d, J = 14.3 Hz, 1H), 2.44 – 2.34 (m, 1H), 2.30 – 2.18
(m, 2H), 2.12 (dd, J = 8.7, 5.1 Hz, 1H), 2.01 (s, 3H), 1.97 (d, J =
14.3 Hz, 1H), 1.79 (s, 3H), 1.77 – 1.68 (m, 2H), 1.64 – 1.57 (m,
1H), 1.48 – 1.44 (m, 1H), 1.42 (s, 3H), 1.38 (s, 3H), 1.11 (s, 3H),
1.09 (s, 3H), 1.06 (d, J = 6.2 Hz, 3H), 0.74 (d, J = 5.1 Hz, 1H);
13C{1H} NMR (100 MHz, CDCl3) δ 172.0, 143.7, 141.0, 115.2,
114.2, 98.6, 82.0, 75.4, 73.3, 64.3, 60.6, 53.1, 49.6, 44.5, 36.7,
34.9, 31.5, 30.7, 29.2, 28.5, 24.8, 23.8, 23.0, 21.1, 19.1, 18.3,
15.8; HRMS (ESI+) m/z calcd for C27H42O6Na (M+Na)+:
485.2879, found: 485.2873; IR (neat) ν 3443, 2926, 1723, 1371,
1232, 1197, 1135, 969, 871 cm-1.
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Preparation
of
(1S,3R,4R,5S,6R)-4-hydroxy-4-
((4aR,6R,7S,7aS)-7-hydroxy-2,2-
dimethylhexahydrocyclopenta[d][1,3]dioxin-6-yl)-3,7,7-
trimethyl-5-vinylbicyclo[4.1.0]heptan-1-yl acetate (67)
and
(1R,3R,4R,5S,6R)-4-hydroxy-4-((4aR,6R,7S,7aS)-7-
hydroxy-2,2-
dimethylhexahydrocyclopenta[d][1,3]dioxin-6-yl)-3,7,7-
trimethyl-5-vinylbicyclo[4.1.0]heptan-1-yl acetate (68).
To a stirred solution of diazene 66 (100 mg, 0.18 mmol, 1.00
equiv) in ethyl acetate (20 mL), was irradiated using 300W
mercury lamp at 25 °C. After 12 h, the reaction mixture was
concentrated under reduced pressure. To a solution of the
resulting residue in THF (20 mL) was added TBAF (0.36 mL, 1.0
M in THF, 0.36 mmol, 2.00 equiv) and the reaction mixture was
stirred at 0 °C for 2 h. The resulting mixture was then quenched
with sat. aq. ammonium chloride. Ethyl acetate (5 x 10 mL) was
added, and the upper organic layer was separated. The organic
layer was dried with anhydrous sodium sulfate, the crude
product was purified by flash chromatography (petroleum
ether/ ethyl acetate 2:1) to give alcohol 67 (58 mg, 0.14 mmol,
79%) as colorless foam and trans isomer 68 (8 mg, 0.019 mmol,
11%) as white solid (m.p. 130-133 °C). 67: Rf 0.78 (silica gel,
1:1 petroleum ether/ ethyl acetate, dark blue, p-anisaldehyde);
1H NMR (400 MHz, CDCl3) δ 6.29 (dt, J = 17.2, 9.9 Hz, 1H), 5.23
(s, 1H), 5.11 – 4.98 (m, 2H), 4.62 (dd, J = 8.8, 2.0 Hz, 1H), 4.04
(dd, J = 6.4, 2.0 Hz, 1H), 3.92 (dd, J = 11.6, 5.4 Hz, 1H), 3.52 (dd,
J = 11.6, 5.4 Hz, 1H), 3.31 (s, 1H), 2.28 – 2.16 (m, 1H), 2.13 – 1.98
(m, 3H), 2.04 (s, 3H), 1.72 – 1.56 (m, 2H), 1.44 – 1.40 (m, 1H),
1.38 (s, 3H), 1.35 – 1.31 (m, 1H), 1.30 (s, 3H), 1.15 (s, 3H), 1.08
(s, 3H), 0.89 (d, J = 6.2 Hz, 3H), 0.62 (d, J = 3.9 Hz, 1H); 13C{1H}
NMR (100 MHz, CDCl3) δ 173.3, 140.0, 115.1, 98.2, 79.3, 77.5,
73.6, 62.9, 61.4, 50.7, 44.8, 36.5, 35.9, 32.5, 30.6, 27.9, 27.3,
23.6, 22.3, 21.2, 21.1, 16.5, 15.3; HRMS (ESI+) m/z calcd for
C23H36O6Na (M+Na)+: 431.2410, found: 431.2401; IR (neat) ν
3396, 2935, 2243, 1719, 1369, 1248, 1049, 994, 913, 849, 730
cm-1. 68: Rf 0.66 (silica gel, 1:1 petroleum ether/ ethyl acetate,
Preparation
of
(1R,2aS,3aR,3bS,6aR,6bS,10aR,11aS,11bR)-6a,11b-
dihydroxy-1,3,3,5,8,8-hexamethyl-
1,3,3a,3b,6,6a,6b,10,10a,11,11a,11b-
dodecahydrocyclopropa[3',4']benzo[1',2':4,5]azuleno[1,2
-d][1,3]dioxin-2a(2H)-yl acetate (69). To a stirred solution
of 35 (50 mg, 0.11 mmol, 1.00 equiv) in toluene (5 mL) was
added Grubbs 2nd generation catalyst (37.4 mg, 0.043 mmol,
0.4 equiv) under argon, and the resultant mixture was stirred
at 110 °C (oil bath) for 12 h. The mixture was concentrated to
dryness and the residue was purified by flash chromatography
(petroleum ether/ ethyl acetate 5:1) to give 69 (34 mg, 0.078
mmol, 71%) as pale yellow solid (m.p. 138-141 °C), and
recovered starting material 35 (10 mg, 0.022 mmol, 20%). Rf
0.15 (silica gel, 5:1 petroleum ether/ ethyl acetate, brown, p-
anisaldehyde); 1H NMR (400 MHz, CDCl3) δ 5.43 – 5.31 (m, 1H),
3.96 (dd, J = 11.6, 4.5 Hz, 1H), 3.70 (d, J = 6.1 Hz, 1H), 3.61 (dd,
J = 11.6, 5.1 Hz, 1H), 3.42 (s, 1H), 2.50 (t, J = 6.1 Hz, 1H), 2.45 (d,
J = 17.0 Hz, 1H), 2.13 (d, J = 17.0 Hz, 1H), 2.10 – 2.05 (m, 1H),
2.03 (s, 3H), 2.02 – 1.88 (m, 3H), 1.89 – 1.79 (m, 2H), 1.73 (s,
3H), 1.58 (dd, J = 15.7, 5.3 Hz, 1H), 1.43 (s, 3H), 1.39 (s, 3H),
1
dark blue, p-anisaldehyde); H NMR (400 MHz, CDCl3) δ 6.44
(ddd, J = 16.7, 10.5, 6.0 Hz, 1H), 5.32 – 5.18 (m, 2H), 4.28 (d, J =
7.5 Hz, 1H), 4.10 (dd, J = 11.6, 4.4 Hz, 2H), 3.67 (dd, J = 12.0, 2.5
Hz, 1H), 3.23 (dd, J = 12.0, 6.0 Hz, 1H), 2.39 – 2.24 (m, 3H), 2.17
