A reactive oxygen species-responsive dendrimer with low cytotoxicity for efficient and targeted gene delivery

Article abstract of DOI:10.1016/j.cclet.2019.03.040

Nonviral vectors have been attracting more attention for several advantages in gene delivery and the development of nonviral gene carriers with high delivery efficiency and low cytotoxicity has long been a key project. Starburst polyamidoamine dendrimers are a class of synthetic polymers with unique structural and physical characteristics. However, when they are used as gene carrier, the gene transfection efficiency is not satisfactory. Herein, a novel thioketal-core polyamidoamine dendrimer (i.e., ROS-PAMAM) was synthesized and characterized. Compared to ethylenediamine-core dendrimers or widely used cationic polymers of polyetherimide, ROS-PAMAM showed lower cytotoxicity. Moreover, ROS-PAMAM demonstrated reactive oxygen species responsive characteristics, which can facilitate the release of siRNA in the tumor microenvironment. In vitro gene transfection experiments based on A549 cells confirmed that siRNA/ROS-PAMAM exhibits high gene transfection efficiency. It is concluded that ROS-PAMAM shows great potential as a generalizable vehicle for gene therapy applications.

Full text of DOI:10.1016/j.cclet.2019.03.040

Accepted Manuscript
Title: A reactive oxygen species-responsive dendrimer with
low cytotoxicity for efficient and targeted gene delivery
Authors: Yueqi Wang, Changjian Li, Libo Du, Yang Liu
PII:
DOI:
Reference:
S1001-8417(19)30135-4
https://doi.org/10.1016/j.cclet.2019.03.040
CCLET 4876
To appear in:
Chinese Chemical Letters
Received date:
Revised date:
Accepted date:
14 February 2019
17 March 2019
25 March 2019
Please cite this article as: Wang Y, Li C, Du L, Liu Y, A reactive oxygen species-
responsive dendrimer with low cytotoxicity for efficient and targeted gene delivery,
Chinese Chemical Letters (2019), https://doi.org/10.1016/j.cclet.2019.03.040
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Please donot adjust the margins
Communication
A reactive oxygen species-responsive dendrimer with low cytotoxicity for efficient
and targeted gene delivery
Yueqi Wang a,b,#, Changjian Li a,b,#, Libo Du a, , Yang Liu a,*
a State Key Laboratory for Structural Chemistry of Unstable and Stable Species, Center for Molecular Science, Institute of Chemistry, Chinese Academy of
Sciences, Beijing 100190, China
b Graduate School, University of Chinese Academy of Sciences, Beijing 100049, China
———
 Corresponding author.
E-mail address: dulibo@iccas.ac.cn; yliu@iccas.ac.cn.
# These authors contributed equally to this work.

Please donot adjust the margins
Graphical Abstract
A novel reactive oxygen species-responsive polyamidoamine dendrimer was synthesized and characterized. As a targeted gene
carrier, it exhibited low cytotoxicity and high gene delivery efficiency.
ARTICLE INFO
ABSTRACT
Article history:
Nonviral vectors have been attracting more attention for several advantages in gene delivery and
the development of nonviral gene carriers with high delivery efficiency and low cytotoxicity has
long been a key project. Starburst polyamidoamine dendrimers are a class of synthetic polymers
with unique structural and physical characteristics. However, when they are used as gene carrier,
the gene transfection efficiency is not satisfactory. Herein, a novel thioketal-core polyamidoamine
dendrimer (i.e., ROS-PAMAM) was synthesized and characterized. Compared to
ethylenediamine-core dendrimers or widely used cationic polymers of polyetherimide, ROS-
PAMAM showed lower cytotoxicity. Moreover, ROS-PAMAM demonstrated reactive oxygen
species responsive characteristics, which can facilitate the release of siRNA in the tumor
microenvironment. In vitro gene transfection experiments based on A549 cells confirmed that
siRNA/ROS-PAMAM exhibits high gene transfection efficiency. It is concluded that ROS-
PAMAM shows great potential as a generalizable vehicle for gene therapy applications.
Received 15 February 2019
Received in revised form 17 March 2019
Accepted 18 March 2019
Available online
Keywords:
Dendrimer
Reactive oxygen species
Cancer
Gene therapy
Low cytotoxicity
Gene therapy is a promising tool for the treatment of human disease that cannot be cured by rational therapies [1, 2]. Over
the past few years, the clinical success of cancer gene therapy critically depends on the development of safe, efficient, and
targeted gene carriers [3, 4]. Synthetic non-viral vectors have attracted considerable interest as a promising alternative to
conventional viral vectors due to their lower risk of immunogenicity and larger gene delivery [5]. Among the vectors,
dendrimers, a class of synthetic polymers with well-defined structure and molecular weight, have attracted considerable
attention [6].
Dendrimers are highly branched macromolecules of low polydispersity that provide many opportunities for design of novel
drug-carriers, gene delivery systems and imaging agents [7, 8]. They show great promise in tissue targeting applications,
controlled drug release and so on [9, 10]. Dendrimers own advantages including their nanoscale spherical architecture, narrow
polydispersity and the multifunctional surface offering the possibility to tailor-make their surface chemistry [11]. However,
among most dendrimers that have been synthesized, despite few possible applications in medicine and pharmacy their
utilization is limited, mainly because of inherent toxicity associated with them [12].
It has been reported that the main mechanism of dendrimers toxicity is based on the interaction of surface cationic charge of
dendrimers with negatively charged biological membranes which results in membrane disruption and erosion [13]. Dendrimers
bearing -NH2 termini display concentration and usually generation-dependent cytotoxicity [11]. Previous studies had pointed
out that only dendrimers of high generations with positive charge, not negative or neutral or small cationic dendrimers,
contributed to aggregation of human platelets in vitro [14]. In another study, Duncan et al. had reported that up to the
concentration of 100 mg/mL tested, the cationic polyamidoamine (PAMAM) dendrimers of generation 4 was markedly
cytotoxic while PAMAM of generation 1 was not toxic at all towards B16F10 cells [15]. In addition, a cytotoxicity analysis
measured by MTT assay showed that cationic PAMAM of generation 2 had almost forty times higher IC50 value (the inhibitory
concentration diminishing viability by 50%) than that of generation 4 [11]. Accordingly, a possible explanation for these results

Please donot adjust the margins
may be that the smaller size and less surface charge distribution of low generations dendrimers contribute their low
cytotoxicity[16, 17].
Scheme 1. Synthetic route of ROS-PAMAM (G4.0).
In the past, a lot of work had focused on the effects of surface modification on cytotoxicity response of PAMAM, such as
guanidine, carboxylate, sulfonate, phosphonate, or PEGylated surfaces [18]. To the best of our knowledge, there was little
scientific information concerning the influences of structural changes on PAMAM cytotoxicity, especially caused by
intracellular stimuli. In this study, we synthesized a ROS (reactive oxygen species)-responsive PAMAM dendrimer that was
easily cleavable in ROS abundant conditions, which reduced the size and surface charge quantity of PAMAM. The ROS-
responsive dendrimer demonstrated low toxicity than non-responsive PAMAM or polyetherimide. What’s more, responding
to ROS offers a parameter for manipulating nanocarrier to achieve better targeting and efficacy in complicated
microenvironments [19]. The targeted delivery of siRNA to tumour cells was carried out to check the transport efficiency of
nanocarrier. The results showed that the ROS- responsive dendrimer was secure and effective as a gene carrier.
The cationic PAMAM dendrimers have primary amines groups on the surface and tertiary amine groups in their internal
cavities, which become ionized at low pH values. They can effectively accept protons in acidic environments. As is known,
the efficient intracellular gene delivery is mainly ascribed to strong electrostatic attraction between delivering carriers and
siRNA [20, 21], therefore PAMAM is a suitable candidate for gene delivery owing to its proton buffering capacity. Moreover,
various smart polymers capable of responding to intrinsic stimuli in a tumour environment, such as low extracellular pH and
matrix metalloproteinases, have been developed as efficient carriers for cancer treatment [22, 23]. It was reported that, cancer
cells can constantly generate high level of intracellular ROS, including H2O2, hydroxyl radial and superoxide, in comparison
with normal cells [24-26]. Accordingly, we speculated that intracellular ROS in cancer cells might be utilized as an effective
cancer-related stimulus to mediate intracellular gene release. It has been confirmed that the thioketal-based polymeric carrier
could be cleaved by intracellular ROS and then enhance the gene delivery efficiency in cancer cells [5]. Therefore, a ROS
(reactive oxygen species)- responsive dendrimer (G4.0), i.e., ROS-PAMAM was produced from methyl acrylate and
ethylenediamine using thioketal as the core (Scheme 1).
b
100
90
80
70
60
50
40
30
20
4000 3500 3000 2500 2000 1500 1000 500
Wavenumber cm-1
1
Fig. 1. The characterization of ROS-PAMAM (G4.0). (a) H NMR, inset: a partial enlargement picture of (a); (b) FTIR; (c) Transmission electron
microscopy (TEM) images of ROS-PAMAM and (d) siRNA/ROS-PAMAM.

Please donot adjust the margins
1
1
The ROS-PAMAM was characterized by H NMR (Fig. 1a). The appearance of alkyl protons in the H NMR spectrum
(inset) indicates that the thioketal successfully served as the core. FTIR spectrum of ROS-PAMAM are shown in Figure 1b.
The characteristic absorption bands at 1731 cm-1 can be assigned to the ester carbonyl group of PAMAM. The molecular
weights of ROS-PAMAM were calculated to be 14.35 kDa by the above molecular formula. Then, transmission electron
microscopy (TEM), dynamic light scattering (DLS) and zeta potential measurements were performed to further characterize
their size, morphology and surface charge properties of ROS-PAMAM and siRNA/ROS-PAMAM complex. Firstly, TEM
images demonstrated that the size of siRNA/ROS-PAMAM was 10.1 nm, whereas that of ROS-PAMAM was only 6.7 nm
(Figs. 1c and d), indicating that siRNA effectively combined to ROS-PAMAM. Secondly, the zeta potential of ROS-PAMAM
and siRNA/ROS-PAMAM were 19.3 mV and 4.07 mV (Fig. S5 in Supporting information), further implying that siRNA had
linked to ROS-PAMAM. Then, DLS results showed that the hydrodynamic size of ROS-PAMAM was 29.2 nm, and that of
siRNA/ROS-PAMAM increased to 45.7 nm (Fig. S5). As comparison, the hydrodynamic diameters of siRNA/PAMAM and
siRNA/PEI were shown in Table S1 (Supporting information). Taken together, these results provide clear evidence for the
formation of ROS-PAMAM and siRNA/ROS-PAMAM.
PAMAM
a
PAMAM
A549 cells
ROS-PAMAM
ROS-PAMAM
b
MCF-7 cells
120
100
80
60
40
20
0
PEI
PEI
120
100
80
60
40
20
0
Ctrl
1
5
10 50 100 150 200 250 300
Ctrl
1
5
10 50 100 150 200 250 300
Concentration (μg/ml)
Concentration (μg/ml)
PAMAM
ROS-PAMAM
PEI
PAMAM
ROS-PAMAM
PEI
c
A549 cells
MCF-7 cells
d
150
100
50
150
100
50
0
0
Ctrl
1
5
10 50 100 150 200 250 300
Ctrl
1
5
10 50 100 150 200 250 300
Concentration (μg/ml)
Concentration (μg/ml)
Fig. 2. The cytotoxicity analysis of ROS-PAMAM dendrimers. Cell viability was assessed by MTT assay and LDH release assay upon exposure to
different concentrations of ROS-PAMAM dendrimers for 24 h. PAMAM and PEI were included for comparison. Results are presented as percent cell
viability (mean ± S.D.) from three independent experiments using A549 cells and MCF-7 cells. MTT assay (a) A549 cells, (b) MCF-7 cells; LDH
release assay (c) A549 cells, (d) MCF-7 cells.
Generally, the cytotoxicity of nanoparticles should be firstly considered before they are used in vivo [27, 28]. To investigate
the cytotoxicity of ROS-PAMAM, both MTT assay and LDH release assay were used. Two cell lines (A549 cells and MCF-7
cells) were exposure to different concentrations of ROS-PAMAM dendrimers for 24 h and the same concentrations of PAMAM
and Polyethyleneimine (PEI) were included for comparison. PAMAM has a core of ethylenediamine instead of thioketal, as a
result, it is not responsive to reactive oxygen species. PEI as a model gene transfection vector is often used in daily experiments,
which however is considered too toxic [29]. Fig. 2 shows the viability of A549 cells and MCF-7 cells after 24 h of incubation
with ROS-PAMAM, PAMAM and PEI. As expected, A549 cells and MCF-7 cells treated with ROS-PAMAM showed no
cytotoxicity even at a concentration of 200 µg/mL in comparison with the IC50 value of PAMAM is about 100 µg/mL and that
of PEI is about 50 µg/mL, confirming the low cytotoxicity of ROS-PAMAM. The results from both methods were consistent.
Such results suggest that ROS-PAMAM demonstrated low toxicity than non-responsive PAMAM or PEI, and it is more secure
to be used as a gene carrier for siRNA delivery. To explain the low toxicity of ROS-PAMAM, the particle size (hydrodynamic
diameter) and zeta potential changes of ROS-PAMAM before and after treated with ROS were measured. As shown in Fig. S6
(Supporting information), both particle size and zeta potential were reduced after treated with ROS. Dendrimers bearing -NH2
termini display concentration and usually generation-dependent cytotoxicity, the smaller size and less surface charge
distribution of ROS-PAMAM in ROS-abundant conditions, as the characters of low generations dendrimers, may contribute
its low cytotoxicity [11, 14-17].
To investigate the cell uptake behaviour of ROS-PAMAM, FITC labelled ROS-PAMAM was synthesized according to our

Please donot adjust the margins
previous studies [30]. Then, the cellular uptake of ROS-PAMAM was calculated by observing the location of FITC-ROS-
PAMAM in subcellular compartments of A549 cells by confocal laser scanning microscopy (CLSM). As shown in Figure S7,
the green fluorescence intensity increased by extending the incubation time from 1 h to 6 h, suggesting that the ROS-PAMAM
could be endocytosed continuously in a time-dependent manner. Next, we co-stained FITC-ROS-PAMAM in A549 cells with
LysoTracker Red DND-99 (lysosomal marker). After 6 h incubation, the green and red fluorescence signals from FITC-ROS-
PAMAM and lysosome marker, respectively, were found to overlap (Fig. S7 in Supporting information). This overlap indicated
that the internalized ROS-PAMAM was translocated via lysosomal pathway after entering cells. Based on these results, it could
be inferred that ROS-PAMAM can be efficiently translocated to endosomes in A549 cells.
d
pH 5.5
pH 5.5 + ROS
pH 7.4
80
pH 7.4 + ROS
60
40
20
0
0
3
6
9
12
15
18
21
24
Time (h)
Fig. 3. (a-c) Analysis of siRNA/ROS-PAMAM complex formation at various mass ratios by agarose gel electrophoresis using 2% agarose in Tris-
acetate running buffer. The siRNA/ROS-PAMAM complexes were prepared at pH 7.4. (a) Agarose gel retardation assay of siRNA/ROS-PAMAM
complexes under various vector/siRNA mass ratios (0.5:1, 1.25:1, 2.5:1, 5:1, 7.5:1, and 10:1 from left to right). (b) Protection of siRNA against RNase
digestion. (c) siRNA release from complexes by competitive binding of SDS with vehicles after enzymatic degradation. Naked siRNA was used as a
control (first lane from the left) (d) siRNA release profile of siRNA/ROS-PAMAM complex under different conditions.
The interaction between negatively charged siRNA and cationic vehicles is known to strongly influence its loading efficiency
of vehicles [31, 32]. To investigate whether ROS-PAMAM could complex with siRNA, agarose gel electrophoresis was
performed at different mass ratios of vector to siRNA (w/w) ranging from 0.5:1 to 10:1 (Figs. 3a-c) [33]. As Fig. 3a shows, in
comparison with the motility of naked siRNA, the movement of siRNA loaded on ROS-PAMAM was gradually retarded. The
fluorescence intensity of un-complexed siRNA decreased with increasing w/w ratio from 0.5 to 10 and nearly disappeared
when the w/w ratio was greater than 5, suggesting that ROS-PAMAM has strong condensation ability towards siRNA and
higher w/w ratios are favourable. The stability of siRNA/ROS-PAMAM complexes were then examined by RNase digestion
to mimic physiological condition. Un-complexed siRNA was detected with ethidium bromide stain. Once siRNA was either
degraded by RNase or completely bound with gene vehicles, the ethidium bromide fluorescence disappeared. Fig. 3b shows
that the fluorescence of siRNA/ROS-PAMAM complexes disappeared after RNase digestion, which means that within the
complexes there is no naked gene present. Then, as Fig. 3c shows, after SDS treatment, siRNA was released from vehicle by
SDS replacement. The fluorescence intensity gradually increased with the mass ratio from 0.5 to 7.5, indicating increasing
number of siRNA was released from ROS-PAMAM. These results further suggested that complexed siRNA was protected by
ROS-PAMAM instead of being degraded by RNase. However, we also found that the fluorescence intensity decreased at the
mass radio of 10, it was possibly because that the vehicle was over dosage, as a result, a little siRNA on the surface of ROS-
PAMAM was degraded. Thus, gene delivery experiments were carried out at an optimized w/w ratio of 7.5.
Then, we investigated the release behaviour of siRNA from siRNA/ROS-PAMAM complexes [34]. We used 100 mmol/L
H2O2 and 1.6 μmol/L CuCl2 in PBS buffer to produce ROS according to a previous report [35]. Fig. 3d shows the amount of
siRNA cumulatively released under different conditions. In the pH 7.4 and absence of ROS, we observed that there is no
apparent siRNA (about 30%) release after 24 h. Then, under a single stimulus of ROS or partial acidic environment (pH 5.5),
the amount of siRNA released was slightly improved to 40% but the effect was not obvious. In contrast, in the presence of
ROS under slightly acidic environment, the siRNA release rate significantly increased, and nearly 80% siRNA was released
within 12 h. For intracellular release of siRNA from ROS-PAMAM, it is known that cationic particles bind with high affinity
to lipid groups on the surface membrane and are endocytosed in the tight-fitting vesicles. Once ROS-PAMAM nanoparticles
enter into an acidifying lysosomal compartment (pH 5.5) [36], the unsaturated amino groups of ROS-PAMAM are capable of
sequestering protons that are supplied by the v-ATPase (proton pump). This process keeps the pump functioning and leads to
the retention of one Cl− ion and one water molecule per proton, which causes lysosomal swelling and rupture, leading to particle
deposition in the cytoplasm[37]. The protonation of the central tertiary amines can increase the volume of internal cavity of
ROS-PAMAM, which promotes siRNA release from siRNA/ROS-PAMAM complexes [38]. Then, cancer cells can constantly
generate high level of intracellular ROS, including H2O2, hydroxyl radial and superoxide, in comparison with normal cells [39,
40]. As a result, the internalized ROS-PAMAM disassembles, which further promotes the release of siRNA into the cytoplasm.

Please donot adjust the margins
c
**
50
40
30
20
10
0
##

Ctrl
Free siRNA PAMAM ROS-PAMAM
PEI
Fig. 4. (a) Confocal microscope images of intracellular uptake of cy5-labeled siRNA (red) complexed with PEI, PAMAM, ROS-PAMAM after
incubation with A549 cells for12 h, Free siRNA was used as a control; (b) The A549 cells were incubated with free p53 siRNA, PEI, PAMAM and
ROS-PAMAM complexed with p53 siRNA for 12 h, respectively. The p53 knockdown efficacy was detected by western blot. (c) Quantitative analysis
of p53 knockdown efficacy.
To investigate the siRNA delivery efficacy by ROS-PAMAM, confocal laser scanning microscopy (CLSM) were used to
measure the uptake of cy5-labeled siRNA. We used PAMAM as a reference to investigate whether ROS-PAMAM responded
to ROS and facilitated the release of siRNA in vivo. As shown in Figure 4a, siRNA/ROS-PAMAM complexes exhibited strong
fluorescence intensity in A549 cells, while the cy5-labeled siRNA delivered by PEI or PAMAM showed relatively weak
fluorescence. Moreover, the fluorescence intensities of cy5-labelled siRNA uptake by A549 cells were determined by flow
cytometry analysis (Fig. S8 in Supporting information), The results were in agreement with the above data determined by
confocal laser scanning microscopy. That is, after treatment with siRNA/ROS-PAMAM, the fluorescent intensity of A549 cells
increased much more than the other two carriers, suggesting that ROS-PAMAM can increase the transfection efficiency.
Moreover, to further evaluate the effectiveness of siRNA transfection by ROS-PAMAM in vitro, we used p53 siRNA that specifically
knockdown p53 protein [41]. p53 siRNA was delivered via ROS-PAMAM, PAMAM, PEI, and the level of p53 was measured by Western
Blot (Fig. 4b). In A549 cells treated with p53 siRNA/ROS-PAMAM at a mass ratio of 7.5, significant p53 knockdown was observed and
the level of p53 was reduced by nearly 83% (Fig. 4c), compared to a slight reduction in the cells treated with siRNA/PEI (62%) and
siRNA/PAMAM (51%). From those results, it can be concluded that ROS-PAMAM is an effective non-viral gene carrier.
With the advent of nanotechnology, concerns about the potential adverse health effects of nanomaterials have been expressed.
It is of great importance to find nanomaterials with lower toxicity, or to make appropriate improvements to reduce nanotoxicity.
Here, we prepared a ROS (reactive oxygen species)-responsive dendrimer, which exhibits low cytotoxicity than non-responsive
PAMAM or polyethyleneimine. The low toxicity mechanism of ROS-PAMAM may be attributed to its easily cleavable
capability in ROS abundant conditions, which reduced the size and surface charge quantity of PAMAM. Dendrimers bearing
-NH2 termini display concentration and usually generation-dependent cytotoxicity, the smaller size and less surface charge
distribution of ROS-PAMAM in ROS-abundant conditions, as the characters of low generations dendrimers, may contribute
its low toxicity.
High siRNA transfection efficiency is the most important factor in gene modification of cells. The targeted delivery of siRNA
to tumour cells was carried out to check the transport efficiency of ROS-PAMAM. Results showed that this vector
demonstrated high siRNA binding affinity and protected siRNA from enzyme degradation. Moreover, confocal laser scanning
microscopy demonstrate the high gene delivery efficiency of ROS-PAMAM at a vector/siRNA w/w ratio of 7.5:1. Furthermore, the
targeted knockdown effect on p53 expression was much higher than that of PEI and non-responsive PAMAM using our new delivery
carrier. This indicates that ROS-PAMAM has the potential to be used as an efficient in vivo gene carrier. We believe that ROS-PAMAM
is a promising delivery vehicle and can contribute to the design of novel carriers with low cytotoxicity and high delivery efficiency.
Acknowledgment
This project was supported by the National Natural Sciences Foundation of China (Nos. 31571020, 31570856 and 31300697).
References

Please donot adjust the margins
[1] Y. Deng, C.C. Wang, K.W. Choy, et al., Gene 538 (2014) 217-227.
[2] X. Li, L. Zhao, Q. Liang, et al., J. Biomed. Nanotechnol. 13 (2017) 280-289.
[3] W.W. Wang, W.Z. Li, N. Ma, G. Steinhoff, Curr. Pharm. Biotechnol. 14 (2013) 46-60.
[4] Q. Zheng, D. Lin, L. Lei, et al., J. Biomed. Nanotechnol. 13 (2017) 1565-1580.
[5] M.S. Shim, Y. Xia, Angew. Chem. Int. Ed. 52(2013) 6926-6929.
[6] P. Kesharwani, A. Gothwal, A.K. Iyer, et al., Drug Discov. Today 23 (2018) 300-314.
[7] H. R. Ihre, O. L. Padilla De Jesús, F. C. Szoka, et al., Bioconjugate Chem. 13 (2002) 443-452.
[8] J. Wang, G.S. Williamson, M.G. Lancina Iii, H. Yang, J. Biomed. Nanotechnol. 13 (2017) 1089-1096.
[9] Y. Fan, S. Yuan, M. Huo, et al., Nanomed-Nanotechnol. 13 (2017) 1399-1410.
[10] V.M. Thanh, T.H. Nguyen, T.V. Tran, et al., Mat. Sci. Eng. C-Mater. 82 (2018) 291-298.
[11] N. Malik, R. Wiwattanapatapee, R. Klopsch, et al., J. Control Release. 65 (2000) 133-148.
[12] S.P. Gautam, R.K. Keservani, T. Gautam, et al., Ars Pharmaceutica 56 (2015) 155-159.
[13] M.A. Dobrovolskaia, A.K. Patri, J. Simak, et al., Mol. Pharmaceut. 9 (2012) 382-393.
[14] C.C. Lee, J.A. MacKay, J.M. Fréchet, F.C. Szoka, Nat. Biotechnol. 23 (2005) 1517-1526.
[15] R. Duncan, L. Izzo, Adv. Drug Deliver. Rev. 57 (2005) 2215-2237.
[16] Kolhatkar R B, Kitchens K M, Swaan P W, et al., Bioconjugate Chem. 18 (2007) 2054-2060.
[17] B.H. Zinselmeyer, S.P. Mackay, A.G. Schatzlein, I.F. Uchegbu, Pharmaceut. Res. 19 (2002) 960-967.
[18] V. Mishra, U. Gupta, N. Jain, J. Biomat. Sci.-Polym. E 20 (2009) 141-166.
[19] Y. Shen, X. Ma, B. Zhang, et al., Chem-Eur J. 17 (2011) 5319-5326.
[20] M.W. Amjad, P. Kesharwani, M.C.I.M. Amin, A.K. Iyer, Prog. Polym. Sci. 64 (2017) 154-181.
[21] D.W. Pack, A.S. Hoffman, S. Pun, P.S. Stayton, Nat. Rev. Drug Discov. 4 (2005) 581-593.
[22] H. Hatakeyama, H. Akita, H. Harashima, Adv. Drug Deliver. Rev. 63 (2011) 152-160.
[23] K. Chen, H. Cai, H. Zhang, et al., Acta Biomater. 84 (2019) 339-355.
[24] S. Tripathy, P.K. Mohanty, Int J Pharm Sci Res. 8 (2017) 1-16.
[25] I.I.C. Chio, D.A. Tuveson, Trends Mol. Med. 23 (2017) 411-429.
[26] H.Y. Lee, E.I. Parkinson, C. Granchi, et al., ACS Chem. Biol. 12 (2017) 1416-1424.
[27] T. Liao, Q. Deng, B. Wu, et al., Biomed. Mater. 12 (2017) 015018.
[28] K. Luo, B. He, Y. Wu, Y. Shen, Z. Gu, Biotechnol. Adv. 32 (2014) 818-830.
[29] G. Guo, M. Tortorella, B. Zhang, Y. Wang, J. Colloid Interf. Sci. 504 (2017) 633-644.
[30] L.B. Du, X.X. Miao, Y.L. Gao, H.Y. Jia, K. Liu, Nanomed. Nanotechnol. 10 (2014) 1411-1420.
[31] A. Sizovs, P.M. McLendon, S. Srinivasachari, T.M. Reineke, Top. Curr. Chem. 296 (2010) 131-190.
[32] L.M. Guan, S.P. Huang, Z. Chen, et al., J. Nanopart. Res. 17 (2015) 1-9.
[33] L. Han, J. Zhao, X. Zhang, et al., ACS Nano 6 (2012) 7340-7351.
[34] V. Dehousse, N. Garbacki, S. Jaspart, et al., Int. J. Biol. Macromol. 46 (2010) 342-349.
[35] E. Fadillioglu, Z. Kurcer, H. Parlakpinar, et al., Arch. Pharm. Res. 31 (2008) 705-712.
[36] W.L. Chen, F. Li, Y. Tang, et al., Int. J. Nanomed. 12 (2017) 4241-4256.
[37] A.E. Nel, L. Mädler, D. Velegol, et al., Nat. Mater. 8 (2009) 543-557.
[38] F. Joris, L. De Backer, T. Van de Vyver, et al., J. Control Release 269 (2018) 266-276.
[39] D. Trachootham, J. Alexandre, P. Huang, Nat. Rev. Drug Discov. 8 (2009) 579-591.
[40] Z. Zhou, J. Song, L. Nie, X. Chen, Chem. Soc. Rev. 45 (2016) 6597-6626.
[41] Z.C. Edwards, E.W. Trotter, P. Torres-Ayuso, et al., Cancer Res. 77 (2017) 4961-4972.
