those of bile acids, hormones, and, through its precursor 7-dehy-
drocholesterol (7-DH-Chol), vitamin D synthesis [10]. Nitro com-
pounds are very important and widely used chemicals [11] due
to their versatile reactivities and simplicity to prepare. In particu-
lar, the nitro functionality can readily be introduced into a choles-
tane ring. The cholesteryl-nitro compound has been widely utilized
as an intermediate for the preparation of 6-ketocholestane. In view
of the aforementioned facts and in continuation of our programme
on the synthesis of steroids [12], the present article embodies the
spectroscopic and single crystal characterization of the 3b-acet-
oxy-6-nitrocholest-5-ene. In addition, dielectrical, thermal, mor-
phological and optical behavior of the compound has also been
explored.
pellet, cp = capacitance of the specimen in Farad (F). Thin layer
chromatography (TLC) plates were coated with silica gel G and ex-
posed to iodine vapors to check the homogeneity as well as the
progress of reaction. Sodium sulfate (anhydrous) was used as a
drying agent.
2.2. Synthesis of 3b-acetoxy-6-nitrocholest-5-ene (2)
To a cooled mixture of cholesteryl acetate 1 (10 g) and conc. ni-
tric acid (250 mL, d = 1.42) sodium nitrite (10 g) was gradually
added with constant stirring over a period of about 45 min. After
complete addition of sodium nitrite stirring was continued for
additional 2 h. Cold water (300 mL) was added to reaction mixture,
yellow solid material separated out. The whole mass was extracted
with ether. The ethereal layer was washed with water, NaHCO3
solution (5%) (until washings become pink), water and dried over
anhydrous sodium sulfate. Removal of the solvents provided the
nitro compound as oil which was crystallized from methanol to
provide colorless crystals suitable for X-ray diffraction (Scheme 1)
(yield: 6.5 g), m.p. 104 °C (reported m.p. 102–104 °C) [13]. Anal.
Calc. for C29H47NO4: C, 73.53; H, 10.00; N, 2.96 (%). Found: C,
73.50; H, 10.06; N, 2.90 (%); IR (KBr, cmꢂ1): 2944, 2869 (CAH,
stretching), 1746 (C@O), 1519, 1301 (NO2, stretching), 1464,
1365 (CAH, bending), 1237 (CAO); 1H NMR (CDCl3, 400 MHz): d
2. Experimental section
2.1. General comments
All reagents and solvents were commercially available and used
as received. Melting point was determined on a Kofler apparatus.
The IR spectrum was recorded on KBr pellets with Interspec 2020
FT-IR Spectrometer spectro Lab and values are given in cmꢂ1. FT-
Raman spectra were recorded on WITec alpha 300 scanning Near
Field Optical Microscope (SNOM), Germany. 1H and 13C NMR spec-
tra were run in CDCl3 on a Bruker Avance II 400 NMR Spectrometer
at 400 MHz and 100 MHz respectively. Chemical shifts (d) are re-
ported in ppm relative to the TMS (1H NMR, 400 MHz) and to the
solvent signal (13C NMR spectra, 100 MHz). Elemental analyses of
the compound were recorded on Perkin Elmer 2400 CHN Elemental
Analyzer. X-ray diffraction (PXRD) pattern of powdered sample
was recorded on MiniFlex™ II benchtop XRD system (Rigaku Cor-
4.72 (1H, m, C3a-H, W1/2 = 16 Hz, axial), 2.01 (3H, s, OCOCH3),
1.10 (3H, s, 10-CH3) 0.67 (3H, s, 13-CH3), 0.90 and 0.85 (other
methyl protons); 13C NMR (CDCl3, 100 MHz): d 170.1 (C@O),
150.2 (C-5), 148.1 (C-6), 72.1 (CAO), 56.2, 52.9, 49.3, 42.2, 41.1,
39.6, 39.2, 38.3, 38.1, 35.7, 34.7, 33.3, 32.7, 31.8, 30.1, 29.7, 28.7,
28.1, 27.9, 25.2, 23.2, 20.2, 19.2, 17.2, 12.1; MS (ESI): m/z 473.35
[M+.].
poration, Tokyo, Japan) operating at 40 kV and a current of
2.3. X-ray diffraction
0
30 mA with Cu Ka radiation (k = 1.54 ÅA). The diffracted intensities
were recorded from 20° to 80° 2h angles with scan rate of 2°/min
and a step size of 0.02°. XRD measurements were performed at
ambient temperature. The surface morphology of the compound
was monitored using JEOL JSM-6510LV scanning electron micro-
scope (SEM). Topographical images of the synthesized compound
were taken using AFM, with a uniform thin film in acetonitrile
on a 10 ꢁ 2.5 cm glass slide. To evaporate excess solvent, the slide
was kept in vacuum at room temperature for 24 h. The sample was
scanned using non-contact tapping mode and obtained 3D topo-
logical images. The thermal study of the compound was carried
out using TGA/DTA-60H and DSC-60 instrument (SHIMADZU) at
Three dimensional intensity data for the compound 2 were col-
lected at 100 K on Bruker KAPPA APEXII DUO diffractometer using
0
Cu Ka radiation (k = 1.54178 ÅA). The structure was solved by direct
methods using SHELXS-97 software (SHELDRICK, 1990). Isotropic
refinement of the structure by least-squares methods was carried
out by using SHELXL-97 (SHELDRICK, 1997) followed by aniso-
tropic refinement on F2 of all the non-hydrogen atoms. Crystallo-
graphic data (excluding structure factors) for the structures
reported in this article have been deposited with the Cambridge
Crystallographic Data Centre (CCDC) as deposition No. CCDC
896096. All H-atom positions were calculated geometrically with
0
a
heating rate of 20 °C minꢂ1 from ambient temperature to
Uiso (H) = 1.2–1.5 ÅA Ueq (parent atom). A riding model was used in
0
800 °C (for DSC 500 °C). UV–Vis spectrum was recorded on UV–
Vis spectrophotometer (Perkin Elmer Life and Analytical Sciences,
CT, USA) in the wavelength range of A200 to 700 nm. The fluores-
cence spectrum was collected at 37 °C with a 1 cm path length cell
using a Hitachi spectrofluorometer (Model 2500) equipped with a
PC and the emission slit were set at 5 nm. The emission spectrum
was recorded in the range of 300–400 nm. The CD spectra of the
crystal was collected a JASCOJ815 spectropolarimeter equipped
with a Peltier-type temperature controller at 37 °C. Spectra were
collected from 200 to 600 nm with 20 nm/min scan speed and a re-
sponse time of 2 s. Respective blanks were subtracted. The Dielec-
tric property was determined using impedance spectroscopy. The
powder was pressed into pellets of 13 mm diameter and
0.84 mm thickness. Dielectric spectroscopy measurement was car-
ried out in the frequency range 1 kHz to 1 MHz using LCR meter
(Agilent 48). The pellets were coated on adjacent faces with silver
paste, thereby forming parallel plate capacitor geometry. The value
of dielectric constant (e0) is calculated using the formula, as fol-
their refinement (CAH = 0.98–1.00 ÅA).
3. Results and discussion
The experimental procedure followed in this manuscript [13] is
almost similar to that reported by A.T. Rowland [11]. Here conc. ni-
tric acid and sodium nitrite were taken without any other solvent
while A.T. Rowland had used conc. nitric acid and potassium nitrite
with ether as solvent.
HNO3 / Sodium nitrite
stirring/cold conditions
O
O
O
O
NO2
(1)
(2)
lows: e0= cp d/eo A, Where,
ness of pellet, A = cross sectional area of the flat surface of the
eo = permittivity of free space, d = thick-
Scheme 1. Synthesis of 3b-acetoxy-6-nitrocholest-5-ene.
