Complete Photocatalytic Reduction of CO2 to Methane by H2 under
Solar Light Irradiation
Francesc Sastre, Alberto V. Puga, Lichen Liu, Avelino Corma,* and Hermenegildo García*
̀ ̀
Instituto Universitario de Tecnología Química CSIC-UPV, Universitat Politecnica de Valencia, Av. De los Naranjos s/n, 46022
Valencia, Spain
S
* Supporting Information
16 nm (Figures S2 and S3); furthermore, both Ni(0) and NiO
were found, based on lattice fringes. The role of silica−alumina
in this type of heterogeneous catalyst is to increase metal
dispersion and stability of the active NPs.
ABSTRACT: Nickel supported on silica−alumina is an
efficient and reusable photocatalyst for the reduction of
CO2 to methane by H2, reaching selectivity above 95% at
CO2 conversion over 90%. Although NiO behaves
similarly, it undergoes a gradual deactivation upon reuse.
About 26% of the photocatalytic activity of Ni/silica−
alumina under solar light derives from the visible light
photoresponse.
Under the experimental conditions, Ni/SiO2·Al2O3 gave the
highest photocatalytic activity without an apparent relationship
with the bandgap of the photocatalyst (see values in Table 1).
The products in the gas phase and their distribution depend on
CO2 conversion. It was observed that CO appears as a primary
but unstable product that converts in a subsequent step into
CH4 as a secondary and stable product. Trace amounts of
ethane were observed in some cases (see Table 1). It was also
noted that the mass balances of carbon, considering exclusively
the products in the gas phase, are lower than 100%, especially at
higher CO2 conversions.
During the photocatalytic CO2 reduction by H2, the
temperature measured at the photocatalyst bed was always
lower than 150 °C. We notice that the initial ambient
temperature increases rapidly when using Ni/SiO2·Al2O3 as
photocatalyst as CO2 is consumed, reaching a maximum at 140
°C in 15 min when CO2 disappears completely. This should
reflect the exothermicity in eq 1. Control experiments in an
autoclave showed that, in the dark, using Ni/SiO2·Al2O3 as
catalyst, CO2 reduction by H2 starts to occur at 180 °C, and at
this temperature a methane yield of 0.15% at 2.5 h was
observed (Figure S4). No temperature increase was recorded in
the autoclave at 180 °C, and CO2 conversion was negligible.
Notice that the results in Table 1 for Ni/SiO2·Al2O3
correspond to 15 min. Precedents in the literature report the
catalytic thermal reduction of CO2 on Ni−Pt and Ni−Pd alloys
performing the reaction at 300 °C, achieving high selectivity
toward CO with minor CH4 formation.14 Thus, all these data
support that CH4 formation is a photoactivated and not a
thermal process, although it could be accompanied by a thermal
catalytic contribution. Additionally, experiments using labeled
13CO2 as substrate lead to the formation of 13CH4, showing that
CH4 is the product of CO2 reduction (see Figure S5 for the
relative intensity of the peaks in the m/z range from 10 to 20
amu of the mass spectrum).
ow-temperature selective reduction of CO2 to methane
using solar light is a highly important process that could
L
alleviate the current dependence on fossils fuels and could be
neutral from the point of view of climate change and
atmospheric CO2 balance.1−10 Recently we have reported
that CO can be either oxidized to CO2 or reduced to CH4 using
n-type or p-type metal oxide semiconductors, respectively.11,12
In particular, and more related to the present work, p-type
semiconductors such as NiO, FeOx, CuO, and other transition
metal oxides are able to reduce CO to CH4 by water or, more
efficiently, by H2 using solar light.12 Working with 3.5 molar
excess of H2, selectivity to CH4 as high as 97% was achieved, at
essentially complete CO conversion, using bulk NiO as
photocatalyst. Considering the high importance of CH4 as a
potential solar fuel and that CO2 is a good feedstock from the
environmental point of view and in terms of availability, we
have conducted a study on the photocatalytic reduction of CO2
to CH4 by H2 with p-type semiconductors using visible light,
according to eq 1.
CO2 + 4H2 → CH4 + 2H2O ΔHr = −165 kJ/mol
(1)
In a preliminary catalyst study, a series of transition metal
oxides were tested for the reduction of CO2 by H2 with
simulated sunlight as the source of energy. The results achieved
after 1 h reaction time with a conventional solar simulator are
presented in Table 1. As can be seen there, while very low
conversions were observed for micrometric Fe3O4 or CuO,
other photocatalysts and particularly NiO gave much higher
conversions. The series of samples also included Ni supported
on silica−alumina (Ni/SiO2·Al2O3). According to X-ray
diffraction (XRD; Figure S1, Supporting Information), this
sample contains a mixture of Ni(0) and NiO nanoparticles
(NPs). The size distribution of these NPs based on
transmission electron microscopy (TEM) is between 7 and
Previously we found that, in the photocatalytic reduction of
CO, some elemental C can deposit on the photocatalyst
surface. In the present case, combustion chemical analyses of
the photocatalysts before and after their use reveal that, while
the fresh material does not contain a detectable percentage of C
Received: January 27, 2014
Published: April 11, 2014
© 2014 American Chemical Society
6798
dx.doi.org/10.1021/ja500924t | J. Am. Chem. Soc. 2014, 136, 6798−6801

Journal of the American Chemical Society
Communication
Table 1. Photocatalytic Activity for CO2 Conversion, Including Molar Balances and Selectivities of CH4, CO, and C2H6, in the
a
Presence of Metal Oxide Semiconductors as Photocatalysts
c
selectivity (%)
b
c
d
catalyst
particle size (nm)
conversion (%)
molar balance (%)
C (%)
CH4
CO
C2H6
TiO2 (3.2 eV)
Ni/SiO2·Al2O3
NiO (3.5 eV)
20−30
7−16
7−30
12−50
120−200
<50
0
99.0
89.1
91.9
89.4
98.2
99.9
99.9
100
0.1
1.32
1.6
−
−
2.8
−
−
−
−
−
−
0.7
2.8
−
e
94.9
89.8
15.0
1.9
97.2
100
88.1
100
4.3
f
NiO
1.1
11.9
f
NiO
0.47
0.5
−
Fe2O3 (2.2 eV)
Fe3O4
51.0
12.3
0
95.0
96.7
−
<50
0.3
0.5
CuO (1.7 eV)
CoO (2.6 eV)
<50
0.04
0.11
−
38.7
<50
27.4
99.1
60.5
0.8
a
Irradiation conditions: mixture of CO2 (3.7 mmol, 15%), H2 (17 mmol, 70%), and N2 (3.7 mmol, 15%); irradiation time, 1 h; photocatalyst mass,
250 mg; irradiation source, solar simulator. Blank controls illuminated in the absence of any solid or contacting the solid and gas phase in the dark
b
did not lead to any product. See Supporting Information for the origin and characterization data of these commercially available photocatalysts. The
c
values in parentheses correspond to the reported bandgap energy of the semiconductor in ref 13. Calculated by considering exclusively the products
d
in the gas phase. Weight percentage of carbon on the solid after the photocatalytic experiment determined by combustion chemical analyses.
e
f
Irradiation time, 0.25 h. Newly synthesized materials; see preparation procedures in the Experimental Details.
by combustion chemical analysis, after photocatalytic reaction a
few percent of C is present in the used catalyst (see Table 1).
Considering the amounts of deposited carbon, mass balances
become satisfactory (>96.6%). In analogous experiments,
whereby CO2 and water were submitted to irradiation under
otherwise identical conditions, only trace amounts of CO and
CH4 were detected after very long irradiation times, indicating
that essentially no photocatalytic reforming of carbon takes
place under the present conditions.
The benefits of using Ni/SiO2·Al2O3, combining the
photocatalytic activity of NiO with a large surface area support
that stabilizes the semiconductor NPs, are revealed by the fact
that Ni/SiO2·Al2O3 exhibits a remarkable reusability that was
not achieved with NiO, which undergoes a gradual deactivation
upon reuse. Studies on the recyclability of the photocatalysts
are presented in Table 2. It can been seen there that Ni/SiO2·
Al2O3 was stable for six uses. Reuses were done by removing
the reaction gases and adding fresh CO2 and H2 into the
photoreactor at the end of each irradiation time (0.25 h). In
contrast, in the case of NiO, a significant decay in the activity
was observed. Notice that, in this latter case, regeneration of the
catalyst by calcination under air at 450 °C results in a gradual
decrease of activity in the first three consecutive cycles,
followed by an abrupt deactivation during the fourth use. This
is due to the sintering of NiO NPs during the reaction/
regeneration cycle, as shown by the decrease in surface area. To
support this hypothesis, larger particle sizes of NiO were
synthesized and tested (12−50 nm NPs or 120−200 nm
hexagonal nanoplates; see the Experimental Details for
synthesis and TEM micrographs in Figures S6 and S7,
respectively). They led to noticeably lower conversions (15.0
and 1.9% for NiO of 12−50 and 120−200 nm, respectively, see
Table 1), thus confirming the influence of particle size on
activity. As commented earlier, low CO2 conversion is
characterized by product distributions containing a large
percentage of CO to the detriment of CH4.
Table 2. Photocatalytic Activity for CO2 Conversion,
The above experiments were carried out with simulated
sunlight that is known to contain a small percentage of UV light
(about 4%). It has been frequently observed that, even though
the percentage of UV light in the solar light is low, it can
contribute largely or even completely (in the case of TiO2) to
the observed overall photocatalytic activity.15 In order to
increase the photocatalytic efficiency, there is an ongoing
interest in searching for photocatalysts that are active with
visible light. Since NiO has been reported previously to exhibit
some visible light photoresponse,12,16−18 and Ni-based NPs
have been shown to display activity for electrocatalytic CO2
reduction,18,19 it is of interest to assess if the photocatalytic
CO2 reduction by H2 can take place to some extent exclusively
with visible irradiation on NiO. To investigate this point, we
performed a set of irradiations using UV-free light (λ > 450 nm;
see transmittance spectrum in Figure S8). It was noticed that
NiO exhibits some residual photocatalytic activity with visible
light irradiation, requiring, however, much longer reaction
times. In contrast, as we can see in Table 3, Ni/SiO2·Al2O3
exhibited a much better visible light photoresponse than NiO,
although longer times were needed as compared to UV-
containing irradiations. In any case, conversions above 90%
with very high selectivity toward CH4 could be obtained using
Including Molar Balances and Selectivities of CH4, CO, and
C2H6, for Reuses of the Catalyst
