Noncontact ultrasound for mechanical property of cheese . . .
Table 6—Linear parameters for the relationship between
rectly related to the bulk modulus, it is significantly related with
mechanical properties, such as Young’s modulus, hardness, and
toughness, which is consistent with the findings of Benedito and
others (1999), indicating that ultrasound velocity is related to the
square root of the mechanical property values. The bulk modulus
could be assumed to be related to the Young’s modulus; however it
is not easy to find the physical reasons for the relationship between
other mechanical properties, such as hardness and toughness and
the bulk modulus which is a direct determinant of the ultrasound
velocity. In addition, the power of noncontact ultrasound is small
enough so that the rate of strain is linearly related to stress. Hence,
quantitative comparison between ultrasound parameters and the
mechanical properties defined by the large strain assumption is
not possible. Extended experiments with thoroughly characterized
samples would be necessary to investigate the precise physical
meaning of the relationship.
The correlation between the ultrasound attenuation coefficient
and the mechanical parameters showed high variability. Even
though the attenuation coefficient is assumed to be related to the
complicated combination of viscosity, density, and ultrasound ve-
locity, its sensitivity to sample surface unevenness, minor surface
defects, porosity, and uneven component distribution in sample
materials also make it difficult to find the relationship with the
mechanical property of cheeses.
ultrasound velocity and mechanical properties of cheeses
Parameter = 0 + 1×Velocity + 2×Velocity2
Content Young’s modulus
Hardness
Toughness



33395.28
–420.72
0.134
0.915
170.09
109811.31
–140.11
0.045
24830.96
–31.57
0.01
0
1
R22
0.995
14.36
0.995
2.74
SEEa
a
Standard error of estimation
Benedito J, Carcel J, Clemente G, Mulet A. 1999. Cheese maturity assessment
using ultrasonics. J Dairy Sci 83(2):248–54.
Bhardwaj MC. 2000. High transduction piezoelectric transducers and introduc-
tion of noncontact analysis. e-J Nondestruct Test Ultrasonics [serial online].
Cheeke JDN. 2002. Fundamentals and applications of ultrasonic waves. Boca
Raton: CRC Press. p 1-15.
Cho B, Irudayaraj JMK. 2003a. Foreign object and internal defect detection in
food materials using noncontact ultrasound imaging. J Food Sci 68(3):967–74.
Cho B, Irudayaraj JMK. 2003b. Design and application of a noncontact ultra-
sound measurement system with air instability compensation. Trans ASAE
46(3):901–9.
Dunn F, Edmonds PD, Fry WJ. 1969. Absorption and dispersion of ultrasound in
biological media. In: Schwan HP, editor. Biological engineering. New York:
McGraw-Hill. p 205–332.
Gunasekaran S, Ay C. 1996. Milk coagulation cut-time determination using ul-
trasonics. J Food Process Engr 19(1):63–73.
Conclusions
Haney MJ, O’Brien WD. 1986. Temperature dependency of ultrasonic propaga-
tion properties in biological materials. In: Greenleaf JF, editor. Tissue charac-
terization with ultrasound. Boca Raton: CRC Press. p 15–55.
Jack FR, Paterson A, Piggott JR. 1993. Relationships between rheology and com-
position of Cheddar cheeses and texture as perceived by consumers. Intl J Food
Sci Tech 28(3):293–302.
apid food thickness measurement using noncontact air insta-
R
bility ultrasound technique was possible with an accuracy of
above 99.9% (SE = 0.089 mm). Ultrasound parameters of different
types of cheeses could be measured and also correlated with me-
chanical properties of cheeses. Whereas the ultrasound velocity
showed high correlation (R2 > 0.9) with mechanical properties of
cheeses, no significant relationship between ultrasound energy at-
tenuation coefficient and mechanical properties was observed.
Even though mechanical properties of different types of cheeses
were highly related with the ultrasound velocity, further research
with controlled samples needs to be conducted to examine more
precisely the physical relationship between the ultrasound param-
eter and mechanical properties of cheese. This study demonstrated
that the noncontact air instability compensation ultrasound could
be a promising tool for nondestructive and rapid measurement of
cheese quality.
Kinsler LE, Frey AR, Coppens AB, Sanders JV. 2000. Fundamentals of acoustics.
4th ed. New York: John Wiley & Sons. 531 p.
Lawrence RC, Gilles J, Geurts TJ. 1993. Cheddar cheese and related dry-salted
cheese varieties. In: Fox PF, editor. Cheese: chemistry, physics, and microbiol-
ogy. 2nd ed. London: Chapman & Hall. p 1–44.
Lee HO, Luan H, Daut DG. 1992. Use of an ultrasonic technique to evaluate the
rheological properties of cheese and dough. J Food Engr 16(2):127–50.
Lizuka Y. 1998. High signal-to-noise ratio ultrasonic testing system using chirp
pulse compression. Insight 40(4):282–5.
Masi P. 1987. The collaborative compression tests on cheeses. In: Jowitt R, Escher
F, Kent M, McKenna B, Roques M, editors. Physical Properties of Foods: COST
90bis Final Seminar Proceedings. London: Elsevier. p 383–402.
[NASS-USDA] Natl. Agricultural Statistics Service, United States Dept. of Agri-
culture. 2001. Dairy products 2000 summary. Washington, D.C.: USDA. p 17.
Neter J, Kutner MH, Nachtsheim CJ, Wasserman W. 1996. Analysis of factor level
effects. In: Applied linear statistical models. 4th ed. New York: The McGraw-
Hill Companies. p 710–55.
Oppenheim AV, Schafer RW, Buck JR. 1999. Discrete-time signal processing. 2nd
ed. New Jersey: Prentice Hall. p 775-810.
Papadakis EP. 1976. Ultrasonic velocity and attenuation: measurement methods
with scientific and industrial applications. In: Mason WP, editor. Physical acous-
tics. New York: Academic Press. p 277–374.
Povey MJW, McClements DJ. 1988. Ultrasonics in food engineering. Part 1: In-
troduction and experimental methods. J Food Eng 8(4):217–45.
[USDA] United States Dept. of Agriculture. 2002. USDA nutrient database for
standard reference. Nutrient Data Laboratory Home Page. Washington, D.C.:
comp>. Accessed on August 10, 2002.
Acknowledgments
The authors would like to thank Dr. Virendra M. Puri for his ad-
vice on mechanical property measurement and use of the Instron
unit.
References
Association of Official Analytical Chemists [AOAC]. 1984. Official methods of
analysis. 14th ed. Washington, D.C.: AOAC.
Zeqiri B. 1989. Reference liquid for ultrasonic attenuation. Ultrasonics 27:314–5.
