James Gardiner* , Xuan Nguyen, Charlotte Genet, Mike D. Horne, Christian H. Hornung, John
Tsanaktsidis
†
†
CSIRO Manufacturing, Bayview Avenue, Clayton, VIC 3169, Australia
‡
CSIRO Mineral Resources, Bayview Avenue, Clayton, VIC 3169, Australia
Supporting Information Placeholder
Table of Contents Graphic
ABSTRACT: Catalytic static mixers (CSMs) were used for the efficient preparation of a key intermediate of the antimicrobial drug
Linezolid (Zyvox). The approach combines 3D printing and additive manufacturing techniques with continuous flow processing to
produce a general method for catalytic hydrogenations and the rapid production of the target molecule, without the need for catalyst
removal or recovery.
Keywords: Catalytic static mixer, continuous flow, hydrogenation, heterogeneous catalysis, Linezolid.
Linezolid (Zyvox)(Figure 1), developed by Pfizer and ap-
proved in 2000, is the first of a new class of antibiotics, the
oxazolidinones, to be introduced to the market in over 35
Linezolid, and other next generation oxazolidinone-based
antimicrobial drugs such as Radezolid and Torezolid (Figure
1), can be prepared in several ways. Most reported methods
2
1
years. It is highly effective in the treatment of severe Gram-
involve installing the oxazolidinone moiety via an isocyanate
or carbamate intermediate, both of which are derived from the
corresponding aromatic amine. Rivaroxaban (Xarelto, Bayer
positive infections including those caused by Streptococcus
pneumoniae, the challenging methicillin-resistant Staphylo-
coccus aureus (MRSA), and vancomycin resistant Enterococ-
cus faecium (VRE) organisms, for which it is often used as a
last line of defence. Linezolid is the only FDA approved med-
icine for the treatment of multi-drug resistant pneumonia and
MRSA skin infections and in 2013-2014 had annual sales of
US $1.35 billion.
2
AG). (Figure 1), an anticoagulant blood thinner with annual
3
sales of US$3.65B, is also prepared by similar means. Pfizer’s
second generation process for the manufacture of Linezolid is
4
shown in Scheme 1.
O
O
O
O
N
F
N
F
H
N
N
H
2
, Pd/C
CbzCl
N
O
NO
2
NH
2
O
2
3
F
catalytic hydrogenation in batch
1
Linezolid (Zyvox)
N
O
N
N
O
O
N
O
N
Cl
HN
N
F
OH
O
O
O
N
F
H
Cl
N
O
N
HCl
N
O
N
HN
2-
1
N
OBn
N
LiOtBu
Cl
OPO
3
O
H
N
F
F
5
N
4
N
N
Na+
2
Torezolid
Radezolid
O
N
O
O
Scheme 1. Pfizer’s second generation process for the synthesis
of Linezolid (1).
H
Cl
4
N
S
N
O
O
Rivaroxaban (Xarelto)
A key transformation in this process is the early stage palladi-
um-catalyzed hydrogenation of the substituted nitrobenzene 2
to the corresponding aniline 3 prior to its conversion to carba-
Figure 1. The oxazolidinone antimicrobial drugs Linezolid
Zyvox), Torezolid and Radezolid, and the anticoagulant
blood thinner Rivaroxaban (Xarelto).
(
ACS Paragon Plus Environment

Organic Process Research & Development
Page 2 of 5
mate 4. Nitro reductions of this type are a common transfor-
CSMs coated with palladium were selected to perform the
transformation of 2 to 3. The CSMs consist of 3-D printed
metal inserts (150mm x 6mm), designed for optimal mixing
under continuous flow conditions, onto which the metallic
catalyst is deposited using an axial flow cell and standard elec-
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
6
mation in many synthetic processes with a vast array of condi-
5
tions having been developed for this purpose. Flow processes
for this transformation have also been developed using hydro-
gen gas or transfer hydrogenation, utilizing catalyst plugs,
fixed beds, and microbeads however issues of pressure, uni-
form flow, heat transfer and optimal mixing still present chal-
12
troplating techniques. The tubular flow reactor itself is ap-
proximately the size of a loaf of bread and contains a set of 12
CSMs which are simply and easily inserted into the tubular
reactor and operated in series inside the temperature controlled
housing (Figure 2). The reactor volume is 39 mL and a hydro-
gen gas line is attached at the front end of the reactor to facili-
tate gas liquid/mixing with the substrate. A detailed descrip-
6
,7
lenges particularly on larger scale. Fixed bed reactors for
example result in large pressure drops over the course of the
reactor resulting in low flow rates. In the synthesis of Linezol-
id, preparation of 3 is typically carried out in a batch reactor
using Pd/C as the catalyst and a hydrogen atmosphere. Batch
reactions of this type often take between 8-24 hrs depending
on scale and require rigorous mixing of the gas and liquid
phases under increased pressure or temperature as well as sub-
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
1b
tion of the reactor and its use has recently been reported.
The set of 12 CSMs used herein contain a total of 2.357g
Pd(0) with approximately 0.2g per insert. Figure 3 shows SEM
images of the Pd(0)-coated CSM surface highlighting high
surface area clumps of palladium particles arrayed over the
metal surface. The use of CSMs for catalytic reactions of this
type allows for a free flowing homogeneous solvent stream
throughout the reactor while removing the need for post reac-
tion workup or filtration of the catalyst from the product.
sequent removal/recovery of the Pd catalyst by filtration
8
(
Celite) during work up. Recently Vapourtec Ltd demonstrat-
ed that palladium on charcoal slurries can be used effectively
under continuous flow conditions for the catalytic transfer
hydrogenation of 2 to 3. An effective product yield of approx-
imately 6g/h of 3 was demonstrated with the preparation of 2
9
also having been achieved via continuous flow. However this
approach still requires the continuous pumping of a 30mg/ml
Pd-C slurry through the reactor, filtration of the catalyst, and
post reaction workup. Risk of blockage using slurries and re-
covery and reuse of the catalyst still present a challenge in this
regard.
As part of a wider aim, we have sought to develop strategies
for the more efficient and cost-effective preparations of key
life-saving and life-improving therapeutic compounds such as
Linezolid. A key aspect of this approach is the use of continu-
ous flow chemistry which has found value in research and
industry in recent years for improving methodology and effi-
10
ciency of industrial manufacturing processes. Recently we
have introduced a new approach to heterogeneous catalyst in
11
flow in the form of catalytic statics mixers (CSMs). CSMs
are designed to promote increased flow rate through the reac-
tor and offer significant advantages with respect to cost, de-
sign and processability compared with other current technolo-
gies. Herein we present the use of CSMs for the continuous
flow preparation of the key intermediate 3 in the synthesis of
Linezolid that is not only efficient and scalable, but produces
the product catalyst free without the need for post process
work up.
We apply the use of CSMs to carry out the efficient hetero-
geneous catalysis of 2 to 3 using an immobilised catalyst sys-
tem which also acts as the flow guide and mixer inside the
tubular reactor unit. This novel continuous flow hydrogenation
reactor contains a series of 3D printed catalytic static mixers
Figure 2. A schematic and image of the CSM reactor and the
individual CSMs housed within.
(
Figure 2) which can be coated with a variety of different het-
erogeneous catalysts. The CSMs were designed and printed in
house, and the catalyst was deposited via electroplating. Pre-
vious work from our group has shown the versatility of this
approach for liquid/gas hydrogenations of other nitro contain-
ing molecules and we envisage this as a general approach to
1
1
transformations of this type. Screening parameters such as
catalyst, temperature, gas and liquid feed rates, pressure and
concentration are all able to be simply varied using the reactor
allowing starting parameters to be easily devised. In addition
Figure 3. SEM images of the surface of a Pd(0)-coated cata-
lytic static mixer.
3
D printing allows for mixers of any size and design to be
tailored and fabricated rapidly at low cost.
The results for the conversion of 2 to 3 using Pd-coated
CSMs in a continuous flow process are shown in Table 1. Eth-
ACS Paragon Plus Environment

Page 3 of 5
Organic Process Research & Development
6
c
anol was initially selected as a solvent for consistency with
batch procedures. Other solvents were examined for increased
spectroscopic monitoring if desired. Increasing the liquid
8
-1
1
2
3
4
5
6
7
8
9
flow rate to 3 ml min also gave 100% conversion under the
solubility with ethyl acetate and THF proving superior, alt-
hough the maximum concentration achieved was 0.62M. As a
first attempt, a 0.1M solution of the substituted nitrobenzene 2
same conditions. Due to the limited solubility of 2 in ethanol
we searched for a more suitable solvent. Common organic
solvents such as acetonitrile and dichloromethane also gave
limited solubility however ethyl acetate and THF proved more
suitable. At 0.25M (entry 3) and at 0.42M (entry 4) in ethyl
-
1
in ethanol was passed through the reactor at 1 mL min with a
-
1
-1
hydrogen flow rate of 4 ml min (0.0024 mol min ), at a tem-
perature of 120 °C and a pressure of 20 bar. Pleasingly, this
resulted in 100% conversion to the corresponding amine 2
-
1
acetate, at a flow rate of 2.5 mL min , 100% conversion of 2
to 3 was successfully achieved. Mass balance analysis was
carried out indicating a 96% mass recovery of the product
after collection. At a concentration of 0.42M in ethyl acetate
this corresponds to a normalised space time yield (STY), of
(entry 1). The reaction can also be followed visually as the
solution of nitrobenzene 2 is a bright yellow colour which
turns colourless upon reduction to 3. Incomplete conversion
could be easily detected by observing the degree of yellow
colour present in the output stream and is amenable to in-line
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
6
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
-
1
-1
317 g L h .
Table 1. Solvents, concentrations, reaction conditions, conversion and throughput data for the hydrogenation of 2 to 3 using CSMs.
All reactions were carried out at 120 °C.
Entry
Solvent
Conc.
M]
P
L
G
G/L
Conv.
[%]
Flow rate prod
TOF
STY
Yieldprod
-
-
-1
-1
-1 -1
-1
[
[bar]
[ml min
[ml min
[mol/mol]
[mol h ]
[mol/mol*h ]
[g L h ]
[g h ]
1
1
]
]
1
2
3
4
5
6
7
8
9
EtOH
EtOH
EtOAc
EtOAc
EtOAc
EtOAc
THF
0.1
0.1
20
20
20
20
20
24
24
24
24
1
3
4
4
24
8
>99
>99
>99
>99
60
0.006
0.018
0.038
0.063
0.076
0.075
0.118
0.084
0.09
0.27
0.82
1.71
2.86
3.44
3.41
5.35
3.82
4.09
30
1.2
3.6
91
0.25
0.42
0.42
0.25
0.62
0.62
0.5
2.5
2.5
5
4
3.8
2.3
1.1
11.6
2.3
3.9
4.8
191
317
382
377
594
423
453
7.5
4
12.4
14.9
14.7
23.2
16.5
17.7
4
5
10
10
10
10
>99
63
5
THF
3
75
THF
3
>99
-
1
Reactor volume = 0.039 L; Mass of catalyst = 2.357 g ; ncat = 0.022 moles; Flow rate prod (mol h ) = Flow rate Subs x (conv. % / 100); Flow rate Subs (mol
-1
-1
-1 -1
h ) = (L /1000) x conc. x 60 min x conc.); TOF (molprod/molcat h ) = Flow rate prod / ncat; moles; STY (g L h ) = Flow rate prod / reactor volume x 1000 x
MWprod; Yieldprod = Flow rate prod x MWprod. Typical reaction runs were carried out using 20 mL of substrate solution giving a residence time of ~7 mins
-1
at a liquid flow rate of 3 mL min . Maximum volume of substrate used per run was 50 mL. Collected product streams includes an additional 1 reactor
volume of solvent for washing.
In an effort to increase throughput the liquid flow rate was
Under these conditions the effective STY was increased to 453
-
1
-1 -1
next increased to 5 mL min , however under these conditions
the conversion dropped to 60%. To address this and up the
g L h , giving our prototype laboratory scale flow reactor the
potential of multikilogram/litre/day, and the effective product
-
-1
conversion we increased the hydrogen flow rate to 10 mL min
yield was increased to 17.7g h corresponding to 425g of 3
1
-1
(
0.0073 mol min ) and the pressure to 24 bar, in line with
per day given the current reactor volume.
11a
previous optimisation processes. We also found that THF
gave increased solubility of 2 up to 0.62M, and subsequently
adopted this solvent system for applying the new reaction
conditions. At this higher concentration in THF, and at a liquid
During these experiments high catalytic activity was ob-
served with quantitative conversion observed in most cases.
-1
Turn-over frequencies (TOF) ranged from <1 h for lower
-1
substrate concentrations (0.1M) to 7.5 h for higher concentra-
-
1
flow rate of 5 ml min , a conversion of 63% was achieved
although this was still not ideal. Dropping the liquid flow rate
tions (0.5M). While we have previously demonstrated higher
throughputs with our reactor using higher concentrations of
more soluble substrates, the low solubility of 2 has been a
limiting factor in this case. For example, our previous studies
on the reduction of cinnamaldehyde gave TOF’s of >20 and
-
1
to 3 mL min led to a slight increase to 75% conversion and
after a little optimisation and a lowering of the substrate con-
centration to 0.5M, >99% conversion of 2 to 3 was achieved
-
1
-1 11b
(
entry 9). Subsequent evaporation of the solvent gave the
amine 3 as a white solid. For a 20 mL sample of substrate at
.5 M this gave 1.88g of 3 at 96% mass recovery. NMR and
LC-MS analysis showed that the product 3 was obtained in
99% purity. Examination of the gas stoichiometry shows that
the molar ratio of hydrogen to substrate was 4.8:1 (Table 1).
STY values of 0.7 Kg L h ,
values superior to other re-
7b,c
ported flow methods. In addition nitro reductions are also
known to be exothermic, however under all conditions de-
scribed here it is notable that no exotherm was observed via
0
>
ACS Paragon Plus Environment

Organic Process Research & Development
Page 4 of 5
the thermocouple closest to the reactor inlet (one of 3 monitor-
ing temperature along the reactor path).
The Supporting Information is available free of charge on the
ACS Publications website.
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
6
Typical side products of nitro reductions such as condensa-
tion products were not observed, nor were any desfluorinated
products, however a minute trace (<0.1%) of the hydroxyla-
mine byproduct was observed by LC-MS. Hydroxylamines are
genotoxic and potentially explosive if concentrated, however
Pt(V)/C catalysts have been especially developed to avoid the
Characterization data, reactor design and operation (PDF).
AUTHOR INFORMATION
Corresponding Author
* Email: james.gardiner@csiro.au
13
formation of such byproducts. CSMs with such doped cata-
lyst coatings are currently under development. ICP-OES anal-
ysis also showed that leaching of the Pd catalyst is very low
with values detected < 1ppb, indicating that the Pd catalyst is
exceptionally well bound to the surface of the static mixer.
Pleasingly we found that the CSMs are also catalytically ro-
ORCID
James Gardiner: 0000-0003-0298-5790
Christian H. Hornung: 0000-000203678-6565
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
Notes
1
1
The authors declare no competing financial interest.
bust observing that with regular activation, a single set of 12
Pd-coated CSM inserts were able to be used almost continu-
ously for hydrogenation reactions for over a year without sig-
nificant loss of catalytic activity. Further CSM design and
catalyst optimisation of this and related processes are ongoing.
ACKNOWLEDGMENT
The authors thank Oliver Hutt, Dayalan Gunasegaram, Andrew
Urban and Darren Fraser for helpful discussions.
This general approach of using CSMs in continuous flow
offers several advantages, namely (a) tubular reactor technolo-
gy is simple and well understood offering excellent control
over liquid and liquid/gas reactions conditions (b) 3D printing
allows for rapid design and manufacture of tailored mixer
solutions for many different liquid and gas flow applications;
REFERENCES
(
1) (a) S. J. Brickner, M. R. Barbachyn, D. K. Hutchinson, P. R.
Manninen, Linezolid (ZYVOX), the First Member of a Completely
New Class of Antibacterial Agents for Treatment of Serious Gram-
Positive Infections. J. Med. Chem., 2008, 51, 1981-1990. (b) G.
Devasahayam, W. M. Scheld, P. S. Hoffman Newer Antibacterial
Drugs for a New Century. Expert Opin. Investig. Drugs, 2010, 19,
215-234. (c) K. L. Leach, S. J. Brickner, M. C. Noe, P. F. Miller
Linezolid, The First Oxazolidinone Antibacterial Agent. Ann. N. Y.
Acad. Sci., 2011, 1222, 49-54.
(c) the potential to mass manufacture CSMs is a major benefit
over existing complex multicomponent catalyst systems. The
cost of manufacture of our 3D printed mixers is estimated to
be lower by a factor of 10 to 100 compared to commercial
metallic static mixers of similar dimensions due to the absence
of labour intensive welding, cutting, bending or joining steps;
(d) changeover of catalyst is straightforward, leading to a ver-
satile and easily maintained continuous flow reactor system
with greatly reduced downtimes (e) scale-up from laboratory
to production can be achieved in less time with less labour
than classical batch scale-up
(
2) Xarelto was originally developed by Bayer AG and is marketed
in the US by Jannsen Pharmaceuticals.
3) (a) J. Zhang, J. Crawford, Rivaroxaban (Xarelto): A Factor Xa
(
Inhibitor for the Treatment of Thrombotic Effects. In Modern Drug
Synthesis, Eds. J. J. Li, D. S. Johnson, Wiley, New Jersey, 2010,
Chapter 14. (b) E. Perzborn, S. Roehrig, A. Straub, D. Kubitza, F.
Misselwitz The Discovery and Development of Rivaroxaban, an Oral,
Direct Factor Xa Inhibitor. Nature Rev. Drug. Disc. 2011, 10, 61-75.
In summary, we have used palladium-coated 3D printed
catalytic static mixers (CSMs) to demonstrate a versatile and
efficient method for the continuous flow hydrogenation of the
key intermediate 3 in the synthesis of the antimicrobial drug
Linezolid (Zyvox). A simple reactor housing the CSMs was
successfully applied to carry out the reduction of the substitut-
ed nitrobenzene 2 to its corresponding amine 3 with potential
for a half-kilogram per day output. This is 3 times the output
of current continuous flow methods for the preparation of this
intermediate. Our continuous process makes use of 3D print-
ing and additive manufacturing techniques to produce static
mixers capable of both highly efficient mixing and heteroge-
neous catalysis, and crucially eliminates the need for catalysis
removal or recovery post processing. We present this as a
general, low-cost and efficient method for this type of trans-
formation for the production of 3 and similar pharmaceutical
and industrially relevant intermediates and products. The de-
velopment of larger more commercially relevant reactors in-
corporating more porous, high surface area CSMs coated with
a range of catalytic substrates are ongoing in our laboratories.
(
4) W. R. Perrault, J. B. Keeler,, W. C. Snyder, C. L. Clark, M. R.
Reeder, R. J. Imbordino, R. M. Anderson, N. Ghazal, S. L. Secreast,
B. A. Pearlman, The Development of a Convergent Synthesis of
Linezolid, an Oxazolidionone Antibacterial Agent. In Scalable Green
Chemistry; S. G. Koenig, Ed.; New York, Pan Stanford; 2013, Chpt 7.
(5) (a) S. Nishimura, Handbook of Heterogeneous Catalytic Hy-
drogenation for Organic Synthesis, 2001, Wiley, New York, Chapter
9, pp 315-347. (b) H. Arnold, F. Dobert, J. Gaube, Handbook of Het-
erogeneous Catalysis. Wiley-Interscience, New York, 2008, pp. 3266-
3
284. (c) A. Corma, P. Serna Chemoselective Hydrogenation of Nitro
Compounds With Supported Gold Catalysts. Science, 2006, 313, 332-
34. (d) R. V. Jagadeesh, A.-E. Surkus, H. Junge, M.-M. Pohl, J.
Radnik, J. Rabeah, H. Huan, V. Schunemann, A. Bruckner, M. Beller,
Nanoscale Fe -Based Catalysts for Selective Hydrogenation of
3
2
O
3
Nitroarenes to Anilines. Science, 2013, 342, 1073-1076. (e) R. A. W.
Johnstone, A. H. Wilby, I. D. Entwistle, Heterogeneous Catalytic
Transfer Hydrogenation and its Relation to Other Methods for Reduc-
tion of Organic Compounds. Chem. Rev. 1985, 85, 129-170.
(6) (a) T. Ouchi, C. Battilocchio, J. M. Hawkins, S. V. Ley, Pro-
cess Intensification for the Continuous Flow Hydrogenation of Ethyl
Nicotinat. Org. Process Res. Dev., 2014, 18, 1560-1566. (b) M. Or-
landi, D. Brenna, R. Harms, S. Jost, M. Benaglia, Recent Develop-
ments in the Reduction of Aromatic and Aliphatic Nitro Compounds
to Amines. Org. Process Res. Dev. 2018, 22, 430-445. (c) M. B. Said,
T. Baramov, T. Herrmann, M. Gottfried, J. Hassfeld, S. Roggan, Con-
tinuous Selective Hydrogenation of Refametinib Iodo-nitroaniline
Key Intermediate DIM-NA Over Raney Cobalt Catalyst at kg/day
Scale with Online UV-Visible Conversion Control. Org. Process Res.
Dev. 2017, 21, 705-714. (d) T. Baramov, J. Hassfeld, M. Gottfried, H.
ASSOCIATED CONTENT
Supporting Information
ACS Paragon Plus Environment

Page 5 of 5
Organic Process Research & Development
Bauer, T. Herrmann, M. B. Said, S. Roggan, Continuous Platinum-
(10) (a) T. Glasnov, Continuous-Flow Chemistry in the Research
Laboratory, Springer New York, Dordrecht, Heidelberg, London,
2016. (b) A. J. Blacker, J. R. Breen, R. A. Bourne, C. A. Hone, The
Growing Impact of Continuous Flow Methods on the Twelve Princi-
ples of Green Chemistry. In Green and Sustainable Medicinal Chem-
1
2
3
4
5
6
7
8
9
Mediated Hydrogenation of Refametinib Iodo-nitroaniline Key Inter-
mediate DIM-NA: The Combined Challenges of Selectivity and Cata-
lyst Deactivation. Eur. J. Org. Chem. 2017, 3921-3928. (e) M. Irfan,
T. Glasnov, C. O. Kappe, Heterogeneous Catalytic Hydrogenation
Reactions in Continuous-Flow Reactors. ChemSusChem 2011, 4, 300-
316. (f) M. Ruta, G. Laurenczy, P. J. Dyson, L. Kiwi-Minsker, Pd
Nanoparticles in a Supported Ionic Liquid Phase: Highly Stable Cata-
lysts for Selective Acetylene Hydrogenation Under Continuous-Flow
Conditions. J. Phys. Chem. C, 2008, 112, 17814-17819. (g) D. Cantil-
lo, M. Baghbanzadeh, C. O. Kappe In Situ Generated Iron Oxide
Nanocrystals as Efficient and Selective Catalysts for the Reduction of
Nitroarenes Using a Continuous Flow Method. Angew. Chem. Int. Ed.
st
istry: Methods, Tools and Strategies for the 21 Century Pharmaceu-
tical Industry; Green Chemistry Series; Royal Society of Chemistry,
Cambridge, UK, 2016, Chapter 12, pp 140-155. (c) B. Gutmann, D.
Cantillo, C. O. Kappe Continuous-Flow Technology – A Tool for the
Safe Manufacturing of Active Pharmaceutical Ingredients. Angew.
Chem. Int. Ed. 2015, 54, 6688-6728. (c) S. G. Newman, K. F. Jensen
The Role of Flow in Green Chemistry and Engineering. Green Chem.
2013, 15, 1456-1472. (d) L. Malet-Sanz, F. Susanne, Continuous
Flow Synthesis. A Pharma Perspective, J. Med. Chem., 2012, 55,
4062-4098. (e) P. Anastas, N. Eghbali Green Chemistry: Principles
and Practice. Chem. Soc. Rev. 2010, 39, 301-312.
(11) (a) C. H. Hornung, X. Nguyen, A. Carafa, J. Gardiner, A. Ur-
ban, D. Fraser, M. D. Horne, D. R. Gunasegaram, J. Tsanaktsidis Use
of Catalytic Static Mixers for Continuous Flow Gas-Liquid and
Transfer Hydrogenation in Organic Synthesis. Org. Proc. Res. Dev.,
2017, 21, 1311-1319. (b) A. Avril, C. H. Hornung, A. Urban, D. Fra-
ser, M. D. Horne, J.-P. Veder, J. Tsanaktsidis, T. Rodopoulos, C.
Henry, D. R. Gunasegaram Continuous Flow Hydrogenations Using
Novel catalytic Static Mixers Inside a Tubular Reactor. React. Chem.
Eng., 2017, 2, 180-188. (c) C. Genet, X. Nguyen, B. Bayatsarmadi,
M. D. Horne, J. Gardiner, C. H. Hornung, Reductive Amination Us-
ing a 3D Printed Supported Catalyst System. J. Flow. Chem., 2018,
DOI: 10.1007/s41981-018-0013-6
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
6
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
2
012, 51, 10190-10193. (h) R. V. Jones, L. Godorhazy, N. Varga, D.
Szalay, L. Urge, F. Darvas Continuous-Flow High Pressure Hydro-
genation Reactor for Optimisation and High-Throughput Synthesis. J.
Comb. Chem. 2006, 8, 110-116.
(7) (a) J. Wegner, S. Ceylan, A. Kirschning, Ten Key Issues in
Modern Flow Chemistry. Chem. Commun., 2011, 47, 4583-4592. (b)
A. Müller, M. Ludwig, M. Arlit, R. Lange, Evaluation of reactor con-
cepts for the continuous production of fine chemicals using the selec-
tive hydrogenation of cinnamaldehyde over palladium catalysts. Cata-
lyst Today, 2015, 241, 214-220. (c) Y. Bai, N. Cherkasov, S. Huband,
D. Walker, R. I. Walton, E. Rebrov, Highly selective continuous flow
2
hydrogenation of cinnamaldehyde to cinnamalcohol in a Pt/SiO coat-
ed tube reactor. Catalysts, 2018, 8, 58-75.
(
8) (a) P. Wang, Q. Pan, Y. Li, D. Zheng, (2011), Method for pre-
paring linezolid and intermediates thereof, US20110275805. (b) R. J.
Imbordino, W. R. Perrault, M. R. Reeder, Process for Preparing
Linezolid, WO2007116284 A1. (c) D. G. Sathe, N. B. Bhise, A. V.
Naidu, K. D. Sawant, A. S. Bhattacharyya, T. A. Naik, Process for
the Preparation of (S)-(N-[[3-[3-Fluoro-4-(4-morpholinyl)phenyl]-2-
oxo-5-oxazolidinyl] methyl]acetamide. WO2009063505 A3. (d) O. A.
Phillips, R. D’Silva, T. O. Bahta, L. H. Sharaf, E. E. Udo, L. Benov,
D. E. Walters, Synthesis and biological evaluation of novel 5-
(12) Y. D. Gamburg, G. Zangari, Theory and Practice of Metal
Electrodeposition; Springer: New York, 2011.
(13) P. Baumeister, H.-U. Blaser, M. Studer, Strong reduction of
hydroxylamine accumulation in the catalytic hydrogenation of ni-
troarenes by vanadium promoters. Catalysis Letters, 1997, 49, 219-
222.
(
hydroxamic acid) methyl oxazolidinone derivatives. Eur. J. Med.
Chem., 2015, 106, 120-131.
9) (a) Vapourtec Application Note 51: Palladium on Charcoal
(
Slurries in Continuous Flow for Transfer Hydrogenation.
www.vapourtec.com. (b) Vapourtec Application Note 29: Process
Scale
N
S Ar Reaction Under Solvent Free (Neat) Conditions.
www.vapourtec.com
ACS Paragon Plus Environment
