Photostable lysosomal imaging of living cell with hyperspectral stimulated Raman scattering microscopy using a probe based on bisarylbutadiyne

Article abstract of DOI:10.1016/j.cclet.2019.03.046

We designed a lysosome-selective Raman probe by conjugating bisphenylbutadiyne with morpholine, a well-known lysosome targeting moiety. This probe, named Lyso-BADY, has a Raman peak 28 times more intense than that of 5-ethynyl-2′-deoxyuridine. Lysosome in

Full text of DOI:10.1016/j.cclet.2019.03.046

Accepted Manuscript
Title: Photostable lysosomal imaging of living cell with
hyperspectral stimulated Raman scattering microscopy using a
probe based on bisarylbutadiyne
Authors: Cong Ding, Yage Chen, Haozheng Li, Bingyao
Wang, Qi Wei, Huajun Tang, Shaokang Jia, Zhiyong He, Ping
Wang, Xiang Zhou
PII:
DOI:
Reference:
S1001-8417(19)30142-1
https://doi.org/10.1016/j.cclet.2019.03.046
CCLET 4882
To appear in:
Chinese Chemical Letters
Received date:
Revised date:
Accepted date:
26 February 2019
25 March 2019
26 March 2019
Please cite this article as: Ding C, Chen Y, Li H, Wang B, Wei Q, Tang H, Jia S, He
Z, Wang P, Zhou X, Photostable lysosomal imaging of living cell with hyperspectral
stimulated Raman scattering microscopy using a probe based on bisarylbutadiyne,
Chinese Chemical Letters (2019), https://doi.org/10.1016/j.cclet.2019.03.046
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Communication
Photostable lysosomal imaging of living cell with hyperspectral stimulated Raman
scattering microscopy using a probe based on bisarylbutadiyne
Cong Ding a,1, Yage Chen b,c,1, Haozheng Li b,c,1, Bingyao Wang a, Qi Wei a, Huajun Tangb,c, Shaokang Jiaa,
Zhiyong He a,*, Ping Wang b,c, Xiang Zhoua,*
aCollege of Chemistry and Molecular Sciences, Key Laboratory of Biomedical Polymers of the Ministry of Education, WuhanUniversity, Wuhan 430072, China
bBritton Chance Center for Biomedical Photonics, Wuhan National Laboratory for Optoelectronics−Huazhong University of Science and Technology, Wuhan
430074, China
cMoE Key Laboratory for Biomedical Photonics, Collaborative Innovation Center for Biomedical Engineering, School of Engineering Sciences, Huazhong
University of Science and Technology, Wuhan 430074, China
*Corresponding authors.
E-mail addresses: hezy@whu.edu.cn (Z. He), xzhou@whu.edu.cn (X. Zhou).
1 These authors contributed equally to this work.
ARTICLE INFO
Article history:
Received
Received in revised form
Accepted
Available online
Graphical abstract
Lysosome-selective Raman probe, Lyso-BADY, was created with improved Raman signal intensity, stability as well as specificity
under the visualization of hyperspectral stimulated Raman scattering (SRS) microscopy. Prolonged exposure to irradiation further
proved its photostability and potentiality for continuous imaging.
ABSTRACT
We designed a lysosome-selective Raman probe by conjugating bisphenylbutadiyne with morpholine, a
well-known lysosome targeting moiety. This probe, named Lyso-BADY, has a Raman peak 28 times more
intense than that of 5-ethynyl-2′-deoxyuridine. Lysosome in living cells was successfully visualized by
hyperspectral stimulated Raman scattering (SRS) microscopy with this extracellular probe. Further study
showed that the Raman signal of Lyso-BADY remained steady and strong even after a prolonged irradiation

time. The photo-stability feature of Lyso-BADY rendered molecules of the similar structure as potentially
versatile probe for continuous imaging in the future
Keywords:
Raman probe
SRS
Cell imaging
Photo-stability feature
Hyperspectral stimulated Raman scattering (SRS) microscopy has been applied in biochemical field as an alternatively superior
imaging technique without fluorescent label. It uses scattered light that generated by vibrations of chemical bonds in biomolecules
instead [1-4]. The vibrational signals are specific to chemical bond, and thus provide a structure fingerprint by which molecules can be
identified [3,5,6]. Therefore, Raman imaging could avoid the drawbacks, such as the intense interference of cells or tissues’ auto
fluorescence, poor photo-stability and photo-bleaching effect, which are inevitable in fluorescence imaging technique.
There are intrinsic Raman signals of biomolecules within cells, and the wavenumber of vibrational signals of chemical bond in
these biomolecules locates at either lower than 1800 cm-1 or higher than 2800 cm-1. In order to minimize these background signals,
exogenous Raman probes or modified endogenous biomolecules whose signals appear in the Raman-silent region of cells (1800-2800
cm-1) have been explored as an alternative strategy for imaging [1,7]. Research along this orientation has developed two methods for
recognition of specific small molecules in vivo. One is isotopically modifying biomolecules, the other is modifying biomolecules with
triple bond (alkyne, nitrile, azide) [8-10]. Such as isotope or triple bond modified deoxyribonucleoside, amino acid, glucose and lipid
have been reported and incorporated into cells to test their metabolic process via Raman imaging [11-16]. Among these approaches,
alkyne or polyyne modified molecules show stronger Raman signal in the silent region of cell, free from the disturbing signals of
endogenous biomolecules.
Among all the cellular organelles, lysosomes are the terminal one in the endocytic pathway [17]. They are intracellular
membrane-bound organelles with a diameter of about 500 nm and contain more than 60 degradative enzymes, which enable cell to
break down various biomolecules, including peptides, nucleic acids, lipids, or even the invading virus particles and bacteria [18,19]. In
addition, some decomposed components were reused as available nutrients to the cell [19]. As a result, the versatile capacity for
degradation of lysosomes plays a fundamental and crucial role in cell maintenance. On the contrary, the dysfunction of lysosomes will
abate its ability to degrade endogenous biomolecules and invading compounds, and reduce lysosomal activity will further lead to an
increase in vulnerability and viral infectivity for cell [20,21]. Hence, it is of great value to monitor lysosomes and explore its cellular
function. Fluorescent-based methods employing lysosomes-targeting probes have been widely investigated [22-25]. All these probes
contain a secondary amine that is suited for the purpose because of their high sensitivity and specificity to the acidic microenvironment
of lysosomes [26]. Consequently, we envisioned that Raman-based approach could also be exploited as novel high-performance probes
for the visualization of lysosome when it was coupled with a secondary amine structure.
First, we surveyed the structure-Raman shift and intensity of different alkynes. Among these various alkynyl structures,
bisarylbutadiynes (BADY) has reported to be a good building block for generating strong Raman intensity, producing signal peaks
about 25 times stronger than that of 5-ethynyl-2′-deoxyuridine (EdU) on average (Fig 1) [7,27]. Therefore, we envisioned its
potentiality to be used as a sensitive and specific Raman tag for visualizing cellular organelles such as lysosome after conjugating with
a suitable targeting group. Here, we describe the synthesis of a lysosome-targeting Raman probe based on BADY (Lyso-BADY, Fig.
1a) and demonstrate its utility for imaging lysosome in living cells.
In this research, morpholine was employed as a lysosome-targeting moiety. Once it entered lysosome, the morpholine group will
be protonated and Lyso-BADY can subsequently accumulate in the acidic lysosome matrix. In this way, Lyso-BADY was endowed
high hydrophilicity and lysosomal retention. Lyso-BADY was easily synthesized from commercially available methyl
4-formylbenzoate and phenylacetylene (Scheme S1 in Supporting information). The bisarylbutadiynes moiety was constructed by
Sonogashira cross-coupling reaction. After the hydrolysis of methyl ester, the benzylic acid was activated by N,N′-disuccinimidyl
carbonate and subsequently converted to Lyso-BADY via the addition of 4-(2-Aminoethyl) morpholine under mild reaction condition.
In the Raman spectra (Fig. 1b), the signal peak of Lyso-BADY is at 2225 cm-1 and shows a relative Raman intensity versus EdU
(RIE) as high as 28 due to phenyl ring enhancement, which is in line with the previous report [27,28]. It is worth mentioning that the
bandwidth (full width at half maximum, FWHM) of Lyso-BADY was about 18 cm-1, and the narrower FWHM means less space will
be occupied in the spectrum, which indicates more molecules with different Raman shift can be differentiated in the spectrum with less
overlap. In addition, probes with narrower FWHM facilitate multi-color imaging.

b
10 mmol/L Lyso-BADY
10 mmol/L EdU
70
60
50
40
30
20
10
0
2000 2050 2100 2150 2200 2250 2300 2350
Raman shift (cm-1)
Fig 1. (a) Structures of EdU and Lyso-BADY; (b) SRS intensity of EdU and Lyso-BADY.
b
12
10 μmol/L
20 μmol/L
10
8
50 μmol/L
Control
6
4
2
0
2100
2150
2200
2250
2300
2350
Raman shift (cm-1)
Fig 2. Sequential SRS imaging of Lyso-BADY and fluorescence imaging of LTR in live cells. (a) HeLa cells were co-incubated with different concentrations of
Lyso-BADY (30 min) and Lyso-Tracker Red (200 nmol/L, 30 min). SRS images showed the distributions of C-H at 2885 cm-1 (blue) and Lyso-BADY at 2225
cm-1 (green) and fluorescence images showed it of LTR in live HeLa cells (red). Area of colocalization in the merged image appeared yellow. (b)The Raman
signal intensity profile of circled area in Lyso-BADY images. Scale bar is 20 μm.
After structure confirmation, the photophysical property of Lyso-BADY was further investigated. As shown in Fig. S1
(Supporting information), Lyso-BADY exhibited three absorption band at 297 nm, 316 nm, 338 nm which were red shifted than
phenylacetylene precursor, and the red shift can be attributed to the extension of π-conjugation.
To evaluate whether the Raman probe can serve as a lysosomal probe for living cell imaging, the biocompatibility of the probe is
of concern. The cytotoxicity of Lyso-BADY by CCK-8 assay in HeLa cell was firstly tested. The results illustrated that Lyso-BADY is
of scarce cytotoxic effect in the concentration range from 5 μmol/L to 100 μmol/L, and HeLa cell keeps its original form even at high
concentration of Lyso-BADY (Fig. S2 in Supporting information).
Next, we investigated the potentiality of Lyso-BADY as a living cell imaging probe. HeLa cells were incubated in presence of
different concentration of Lyso-BADY. At the same time, the commercial lysosomal probe, Lyso-Tracker Red (LTR), was applied as a
colocalization fluorescent dye to verify the specificity of our designed molecule. After incubating for 30 min, cells were then subjected
to fluorescence and SRS imaging with no precipitation disturbance during the cellular experiment. As presented in Fig. 2a and Fig. S3
(Supporting information), the distributions of C-H bond in lipid droplets and Lyso-BADY are clearly observed at 2885 cm-1 and 2225
cm-1, respectively. It could be easily spotted that the absence of Lyso-BADY led to no Raman signal in HeLa cells when excited by a
laser beam. However, the increase of incubating concentration directly accounted for the rising of Raman signal intensity in HeLa cells
(Fig. 2b). Specifically, the relative signal intensity was 5 when the concentration of Lyso-BADY was 10 μmol/L, but it reached 9 at 20
μmol/L and 10 at 50 μmol/L, respectively. On the other hand, the merge picture firmly illustrated that the SRS image of Lyso-BADY
overlapped perfectly with the fluorescence image of LTR. In addition, the fluorescence signal intensity profile of LTR was found to be
highly correlated with the corresponding Raman signal intensity profile (Fig. S5 in Supporting information). These SRS images firmly
proved that Lyso-BADY could selectively accumulate at lysosomes of cytoplasm, which means Lyso-BADY can be applied as a probe
for lysosomal imaging in living cell with high specificity.
To investigate whether the imaging quality depends on the incubation time, HeLa cells were cultured with 20 μmol/L Lyso-BADY
within various incubation time (10 min, 30 min, 90 min). As shown in Fig. 3, the contrast of Lyso-BADY could be observed within 10
min, indicating rapid ingestion by the cells, and the signal remained a steady state in 30 min, maintaining relatively stable for at least
90 min. The distribution and intensity of Lyso-BADY signal was further confirmed by intensity profile method (Fig. S4 in Supporting
information).

b
8
7
6
5
4
3
2
1
10 min
30 min
90 min
0
2100
2150
2200
2250
2300
2350
Raman shift (cm-1)
Fig. 3. Sequential SRS imaging of Lyso-BADY and fluorescence imaging of LTR in live cells. (a) HeLa cells were co-incubated with Lyso-BADY (20 μmol/L)
at various time and Lyso-Tracker Red (200 nmol/L, 30 min). (b) The SRS spectra of circled area in Lyso-BADY images. Scale bar is 20 μm.
b
1.0
0.9
0.8
0.7
0.6
0.5
0.4
Lyso-BADY
Lyso-Tracker Red
0
20 40 60 80 100 120 140 160 180 200
Time (s)
Fig. 4. Photostability assay of Lyso-BADY and LTR for cellular imaging. (a) SRS images (green) of Lyso-BADY and fluorescence images (red) of LTR at
different imaging time. (b) Relative intensity of Lyso-BADY and LTR at different imaging time. Scale bar is 20 μm.
Photostability is considered as one of the key factors in evaluating the performance of cell imaging probes. The photostability of
Lyso-BADY was investigated by monitoring the Raman signal intensity via SRS microscopy after being continuously scanned by laser.
Meanwhile, LysoTracker assay was carried out utilizing the fluorescence imaging as a contrast. In our test, after 180 seconds scanning,
fluorescence intensity was 50 % off, whereas Raman signal intensity remained almost invariable during this time (Fig. 4). What is
more, one hour’s exposure to laser irradiation totally erased the fluorescence signal of LysoTracker but the left signal of Lyso-BADY
was steady and strong (Fig. S6 in Supporting information). This may be attributed to the fact that the diyne moiety was photostable and
did not decay upon irradiation for a prolonged time. This feature makes it a valuable alternative for continuous cell imaging since
photobleaching effect of fluorophore is problematic for fluorescence imaging.
In summary, we have synthesized and characterized a novel lysosome-targeting Raman probe called Lyso-BADY and applied it to
lysosomal imaging of living cell. It boasts of a Raman signal intensity 28 times stronger than that of EdU because the
bisphenyl-substituted diyne intensify the vibration of alkyne dramatically. In addition, the signal of Lyso-BADY locates at 2225 cm-1,
the Raman-silent region of cells, which means the Raman images are definitely free from signal disturbance of endogenous molecules.
Lyso-BADY also possessed features of nontoxicity, good specificity and high photostability. All these merits render molecules of the
same structure as potentially versatile probe for imaging and analysis of organelle or other specific cellular and tissue domain when
conjugated with other locating moieties. This work will potentially promote the development of novel Raman probes with varied
intracellular targeting with development of the SRS microscopy.
Acknowledgement
We thank the National Natural Science Foundation of China (No. 21432008, 91753201 and 21721005).
References
[1] L. Wei, Z. Chen, L. Shi, et al., Nature 544 (2017) 465-470.
[2] L. Wei, F. Hu, Y. Shen, et al., Nat. methods. 11 (2014) 410-412.
[3] Z. Zhao, Y. Shen, F. Hu, W. Min, Analyst 142 (2017) 4018-4029.
[4] C.W. Freudiger, W. Min, B.G. Saar, et al., Science 322 (2008) 1857-1861.
[5] H. Lei, Y. Hu, G. Li, Chin. Chem. Lett. 29 (2018) 509-512.
[6] H. Zhang, L. Sun, Y. Zhang, et al., Chin. Chem. Lett. 29 (2018) 981-984.
[7] F. Hu, C. Zeng, R. Long, et al., Nat. methods. 15 (2018) 194-200.
[8] L. Wei, F. Hu, Z. Chen, Acc. Chem. Res. 49 (2016) 1494-1502.

[9] Z. Chen, D.W. Paley, L. Wei, et al., J. Am. Chem. Soc. 136 (2014) 8027-8033.
[10] Z.L. Song, Z. Chen, X. Bian, et al., J. Am. Chem. Soc. 136 (2014) 13558-13561.
[11] L. Wei, Y. Shen, F. Xu, et al., ACS Chem. Biol. 10 (2015) 901-908.
[12] H. Yamakoshi, K. Dodo, M. Okada, et al., J. Am. Chem. Soc. 133 (2011) 6102-6105.
[13] F. Hu, Z. Chen, L. Zhang, et al., Angew. Chem. Int. Ed. 54 (2015) 9821-9825.
[14] L. Wei, Y. Yu, Y. Shen, M. C. Wang, W. Min, Proc. Natl. Acad. Sci. U. S. A. 110 (2013) 11226-11231.
[15] L. Lin, X. Tian, S. Hong, Angew. Chem. Int. Ed. 52 (2013) 7266-7271.
[16] Y. Shen, Z. Zhao, L. Zhang, Proc. Natl. Acad. Sci. U. S. A. 114 (2017) 13394-13399.
[17] A.C. Johansson, H. Appelqvist, C. Nilsson, et al., Apoptosis 15 (2010) 527-540.
[18] C. Settembre, A. Fraldi, D.L. Medina, A. Ballabio, Nature Rev. Mol. Cell Biol. 14 (2013) 283-296.
[19] H. Xu, D. Ren, Annu. Rev. Physiol. 77 (2015) 57-80.
[20] F.M. Platt, B. Boland, A.C. van der Spoel, J. Cell Biol. 199 (2012) 723-734.
[21] B.L. Wei, P.W. Denton, E. O'Neill, et al., J. Virol. 79 (2005) 5705-5712.
[22] X.J. Cao, L.N. Chen, X. Zhang, et al., Anal. Chim. Acta 920 (2016) 86-93.
[23] M. Li, H. Ge, V. Mirabello, et al., Chem. Commun. 53 (2017) 11161-11164.
[24] X.L. Shi, G.J. Mao, X.B. Zhang, et al., Talanta 130 (2014) 356-362.
[25] X. Zhou, F. Su, H. Lu, et al., Biomaterials 33 (2012) 171-180.
[26] J.A. Mindell, Annu. Rev. Physiol. 74 (2012) 69-86.
[27] H. Yamakoshi, K. Dodo, A. Palonpon, et al., J. Am. Chem. Soc. 134 (2012) 20681-20689.
[28] J. Zhang, S. Yan, Z. He, et al., J. Phys. Chem. Lett. 9 (2018) 4679-4685.
