High-Throughput Protein Glycomics: Combined
Use of Chemoselective Glycoblotting and
MALDI-TOF/TOF Mass Spectrometry**
Shin-Ichiro Nishimura,* Kenichi Niikura,
Masaki Kurogochi, Takahiko Matsushita,
Masataka Fumoto, Hiroshi Hinou, Ryousuke Kamitani,
Hiroaki Nakagawa, Kisaburo Deguchi, Nobuaki Miura,
Kenji Monde, and Hirosato Kondo
Glycosylation is one of the posttranslational modifications of
proteins in eukaryotes. This step is thought to modulate a
wide range of protein functions both on the cellular surfaces
[
6]
TOF mass spectrometry, allows for both facile purification
and precise analysis of common oligosaccharides and glyco-
peptides from native glycoproteins.
[
*] Prof. S.-I. Nishimura, Dr. K. Niikura, Dr. M. Kurogochi,
T. Matsushita, R. Kamitani, Dr. H. Nakagawa, Dr. K. Deguchi,
Dr. N. Miura, Dr. K. Monde
The concept of the “sugar family tree,” constructed by
[
7]
Fischer, motivated us to use the chemoselective “glycoblot-
ting” technique, which has become a key feature in the
efficient isolation of carbohydrates in this study. Fischer found
that the reaction of glucose, mannose, and major oligosac-
charides with phenylhydrazine proceeds smoothly to give the
corresponding stable phenylhydrazone derivatives under mild
basic and aqueous conditions. Once oligosaccharides are
released from glycoconjugates, they can be regarded as a
general class of the compound library which have an aldehyde
or ketone group at each reducing terminal. As indicated in
Scheme 1a, aldehydes preferentially react with reagents
bearing hydrazine-like functional groups. Fischer-type
reagents do not need any catalyst or reducing agent to
accelerate the reaction with sugars and the reactions usually
proceed under mild conditions. However, the reactions of
aldehydes with primary amino groups require some activating
reagent for the formation of stable products. As a result,
carbohydrates preferentially react with Fischer-type reagents
even in the presence of large amounts of peptides or amino
acids with primary amino groups.
Division of Biological Sciences
GraduateSchool of Sci en ce
Frontier Research Center for Post-Genome Science and Technology
Hokkaido University
N21, W11, Sapporo 001-0021 (Japan)
Fax: (+81)11-706-9042
E-mail: shin@glyco.sci.hokudai.ac.jp
Prof. S.-I. Nishimura, M. Fumoto, Dr. H. Hinou
Research Center for Glycoscience
National Institute of Advanced Industrial Science and
Technology (AIST)
Sapporo 062-8517 (Japan)
Dr. H. Kondo
Discovery Research Laboratories
Shionogi & Co. Ltd.
Osaka 553-0002 (Japan)
[
**] This work was partly supported by a grant for the National Project
on “Functional Glycoconjugate Research Aimed at Developing for
New Industry” from the Ministry of Education, Science, and Culture
of Japan. Part of this study was presented at the Annual Conference
of the Society for Glycobiology, December 3–6, 2003, San Diego, CA
(
USA).
The unique chemical characteristics of the sugar family
encouraged us to design novel polymers for capturing only
carbohydrates from crude samples on the basis of the
Supporting information for this articleis availableon theWWW
under http://www.angewandte.org or from the author.
Angew. Chem. Int. Ed. 2005, 44, 91 –96
DOI: 10.1002/anie.200461685
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
91

Communications
Scheme 1. Fischer’s concept and glycoblotting by Fischer-type polymer reagents. a) Reactions of carbohydrates with Fischer’s reagents. b) Synthe-
ses and reactions of Fischer-type polymer reagents: 1) liposomes prepared with phosphatidylcholine-related monomer, then UV (254 nm) irradia-
tion, 2) radical copolymerization (ammonium persulfate) with acrylamide, followed by deprotection with 4n HCl.
chemoselective ligation strategy. From considerations of the
chemical stability, the handling of reagents, and the feasibility
to the general synthesis of versatile polymer materials, we
have developed several Fischer-type polymer reagents with
reactive and stable oxylamino functional groups by polymer-
ization of a diacetylene-containing lipid derivative 1 or an
acrylamide-type derivative 2 (Scheme 1b). Liposomes com-
posed of diacetylene-containing reagent 1 and phospholipid
derivatives can be readily polymerized by UV irradiation to
produce polymer-based nanoparticles having a mean diame-
ter of 200–300 nm. Compound 2 gives a water-soluble
polymer on radical copolymerization with acrylamide. We
evaluated the feasibility of the polymers displaying oxylamino
functional groups as a useful platform for the “trap and
release” of the target oligosaccharides and glycopeptides.
The general protocol for the isolation and analysis of
carbohydrates proposed here is simple and easy: a) Trapping
carbohydrates by mixing polymers with unpurified proteo-
lytic digest; b) collecting polymers by spin filtration from a
crude mixture of peptides, salts, and other impurities; and
c) releasing and subsequent MALDI-TOF MS analysis of the
target carbohydrates (Figure 1). In this study we selected the
N-glycans of human IgG to test the efficiency of protein
glycomics in the strategy, since the importance of substantial
structural alteration of IgG N-glycans has been extensively
[
3,8]
investigated, The structural characterization of human IgG
N-glycans was carried out using crude IgG samples obtained
from human serum (100 mL, Figure 1). The merits of glyco-
blotting are evident since MALDI-TOF MS analysis of
oligosaccharides trapped on the polymer has proven to be
remarkably improved by using trapping and spin filtration
(Figure 2b). When the crude digest was directly subjected to
MALDI-TOF MS analysis we obtained an extremely com-
plex spectrum (Figure 2a). The precursor ion peaks, which
correspond to the N-glycans, cannot be distinguished from
numerous other signals in the spectrum because of an excess
amount of peptide impurities. As anticipated, highly sensitive
and singly charged precursor ion peaks were generated in the
presence of a-cyano-4-hydroxycinnamic acid (CHCA) and
these greatly facilitated the subsequent sequencing and
quantitative analysis of the oligosaccharides. In addition, it
was found that the fragmentation of the precursor ions by the
9
2
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
Angew. Chem. Int. Ed. 2005, 44, 91 –96

Angewandte
Chemie
Figure 1. General procedure for chemoselective glycoblotting
and MALDI-TOF mass analysis of carbohydrates.
[
6]
LIFT-TOF/TOF method allowed for the efficient and
precise sequencing of N-glycans. The TOF/TOF spectral
patterns of the product ion peaks could then be applied for
further data fitting with the known mass database of known
oligosaccharides. Fragmentation by the TOF/TOF technique
of an ion peak at m/z 1486 provided the typical fragment ion
series corresponding to that of a known pyridyl-aminated
[
9]
oligosaccharide (Figure 2c).
This result indicated that
carbohydrate mass fingerprinting (CMF) analysis by the
MALDI-TOF/TOF method allows for the precise structural
identification of oligosaccharides captured from glycopro-
teins by glycoblotting.
The CMF analysis based on TOF/TOF can also be used to
