Chemistry of Heterocyclic Compounds, Vol. 40, No. 11, 2004
CONCERNING THE PRODUCT
OF [2 + 2] CYCLODIMERIZATION
OF 9-ALLENYLCARBAZOLE
1
2
2
1
1
O. I. Kharaneko , S. V. Shishkina , O. V. Shishkin , A. V. Kibalnyi , and V. I. Dulenko
The isomerization of 9-propargylcarbazole in alcoholic alkali leads to the product of dimerization of
-allenylcarbazole, 1,2-bis(9-carbazolylmethylene)cyclobutane, the structure of which was established
9
by X-ray diffraction analysis.
Keywords: allenylcarbazole, 1,2-bis(9-carbazolylmethylene)cyclobutane, cyclodimerization.
We have synthesized 9-propargylcarbazole 1 with the aim of studying its properties and application in
synthesis of acetylene derivatives of carbazole. This was achieved by the action of propargyl bromide on
carbazolylsodium, prepared in 80% yield by heating metallic sodium and carbazole in dioxane. This compound
was obtained previously by the action of propargyl bromide on the sodium derivative of carbazole in liquid
ammonia [1,2], in DMF [3], or in acetonitrile [4]. The patented procedure [5] differed in the use of potassium
derivative of carbazole.
1
2
. Na
. BrCH C
CH
2
Dioxane
N
N
H
H
1
Both on carrying out the synthesis and on studying the Favorsky rearrangement of 9-propargylcarbazole
(heating in alcoholic alkali) we noted the formation of a difficultly soluble product, which became
1
predominant on boiling compound 1 in alcoholic KOH solution for 8 h. The formation of difficultly soluble solid
on rearranging compound 1 has been observed previously. For example, the authors of [1], while studying the
isomerization of N-propargyl-substituted heterocycles, assumed it to be a polymer. We have established that
under the conditions indicated above the main product of isomerization of carbazole 1 is an individual compound
having the same elemental composition as the initial carbazole 1. The structures of the isomeric
9
-allenylcarbazole 2 and 9-propynylcarbazole 3 are excluded according to the spectral characteristics, by the
_
_________________________________________________________________________________________
1
L. M. Litvinenko Institute of Physical Organic and Coal Chemistry, National Academy of Sciences of
2
Ukraine, 70 R. Luxemburg St, Donetsk 83114, Ukraine; e-mail: kibalny@infou.donetsk.ua. Department of
Alkali Halide Crystals STC, Institute for Single Crystals, National Academy of Sciences of Ukraine, 60 Lenina
Ave, Kharkov 61001, Ukraine; e-mail: shishkin@xray.isc.kharkov.com. Translated from Khimiya
Geterotsiklicheskikh Soedinenii, No. 11, pp. 1652-1661, November, 2004. Original article submitted April 13,
2
001.
0
009-3122/04/4011-1427©2004 Springer Science+Business Media, Inc.
1427

lack of carbonyl group absorption band, and also of allenic and acetylenic bonds (at 1950-1980 and
-
1
1
2
100-2200 cm ) and by the presence in the H NMR spectrum of a complete set of signals for the aromatic
protons of carbazole nucleus substituted at position 9.
_
_
OH
OH
1
N
N
Dimer
2
4
3
The compound obtained is neither an oxidation product of propargylcarbazole 1, nor the hydrolysis
product of allene 2, nor the cyclization product of the latter into a derivative of pyrrolocarbazole, which might
have been expected on the basis of the results of [6]. The molecular weight measured by the Rast method,
proving to be double the molecular weight of the initial compound 1, enabled the dimeric structure to be
proposed, i.e. bis(9-carbazolylmethylene)cyclobutane (4), the product of [2 + 2] cyclodimerization of
9
-allenylcarbazole 2. The significant predominance of allene 2 in the equilibrium mixture compared with the
other isomers 1 and 3, recorded by the authors of [1] on carrying out the isomerization using alkaline catalysts,
also points in favor of allene dimer. According to the data of the same authors, this special feature is probably
most widely expressed among carbazole derivatives. On isomerizing propargylcarbazole under certain other
conditions (potassium hydroxide in DMSO at room temperature) used by the authors of [3,7], 9-allenylcarbazole
2
was isolated in almost quantitative yield.
We have shown that in the simpler and more convenient way dimer 4 may be obtained from the
available [8] epoxypropylcarbazole 5, as shown in the Scheme.
_
SOCl2
OH
2
4
N
N
Cl
5
O
Cl
6
The dimerization of allenes [8] may lead to 1,2- and 1,3-disubstituted derivatives of cyclobutane, and on
the basis of the data obtained it is not possible to make an unequivocal choice between the structures of 1,2- and
1
,3-bis(9-carbazolylmethylene)cyclobutane (4a and 4b respectively). We therefore carried out an X-ray
diffraction investigation of the dimerization product 4, showing unequivocally that the obtained dimer
corresponds to structure 4a (Fig. 1, Tables 1-3).
N
N
N
N
4b
4a
1
428

Fig. 1. Structure of 1,2-bis(9-carbazolylmethylene)cyclobutane 4a molecule.
4
TABLE 1. Coordinates (×10 ) and Equivalent Isotropic Thermal Parameters
3
(
×10 ) of the Non-hydrogen Atoms in the Structure of Compound 4a
2
Atom
1
x
y
z
Ueq, Å
2
3
4
5
N(1A)
6189(7)
6316(7)
7760(9)
8749(9)
3687(2)
4418(2)
3805(3)
3595(3)
3768(3)
4138(3)
4339(3)
4176(3)
4278(3)
4599(3)
4598(3)
4284(3)
3961(3)
3961(3)
3325(2)
3272(2)
2835(3)
3072(2)
3525(2)
3976(3)
4642(3)
4497(3)
4800(3)
5218(3)
5355(3)
5063(2)
9927(5)
12725(6)
10852(8)
12177(7)
12885(7)
12277(9)
10955(9)
10223(7)
8810(7)
7662(8)
6447(7)
6327(7)
7430(7)
8650(7)
10146(7)
11310(6)
11721(7)
13224(7)
12706(6)
13342(6)
11373(8)
10422(7)
