Fatty Acid Composition of Enriched Artemia salina
J. Agric. Food Chem., Vol. 55, No. 10, 2007 4045
Analysis of Fatty Acids by GC and GC-MS. Quantitative and
qualitative analyses of FAME obtained by transesterification were
performed on a Perkin-Elmer AutoSystem XL, gas chromatograph
(Perkin-Elmer, United States) equipped with an Elite-5 (crossbond 5%
diphenyl-95% dimethyl polysiloxane) capillary column (30 m × 0.53
mm i.d., 0.50 µm film thickness, Supelco, Bellfonte, PA) using a flame
ionization detector. The oven temperature ramp was 110 °C for 1.0
min, followed by an increase of 45 °C/min to 210 °C, where it was
held for 1.0 min, followed by an increase of 30 °C/min to 250 °C,
where it was held for 1.0 min, followed by an increase of 25 °C /min
to 285 °C, where it was held for 2.0 min, until all peaks had appeared.
For N-acyl pyrrolidide derivatives, the oven temperature was pro-
grammed to hold 160 °C for 1 min, and then increased at the rate of
10 °C/min up to 220 °C, and thereafter 5 °C/min up to 290 °C. Ultrahigh
purity He (99.99% purity) was used as the carrier gas at a flow rate of
1 mL/min. The injector temperature was maintained at 285 °C. It was
equipped with a split/splitless injector, which was used in split (1:15)
mode. The flow rate of He and air were maintained at 50 psi. The
injection volume was 1 µL. The detector was isothermal at 290 °C.
FAMEs were identified by comparison of retention times with the
known standards (37 component FAME Mix, PUFA-3, PUFA-1, and
BAME; Supelco). The shorthand notation used in fatty acid nomen-
clature is L:Bnx, where L is chain length, B is number of double bonds,
and nx is the position of the ultimate double bond from the terminal
methyl group. The fatty acid composition was expressed as weight
percent of the total fatty acids (TFA) of each fraction. Chromatograms
were analyzed using Perkin-Elmer Chromstation (version 4.02) soft-
ware.
prior to statistical analyses of FAME data expressed in percentages.
All measurements were performed in triplicate, and values were
averaged.
RESULTS
Spectroscopic Analyses of FAMEs and N-Acyl Pyrrolid-
ides. The molecular ions for saturated fatty acid (SFA) and
monounsaturated fatty acid (MUFA)-FAME were conspicuous
and as obvious from the mass spectra; hence, the molecular
weight was discernible from the EI-MS spectra. An ion at (M
- 31)+ represents the loss of the -OCH3 group, thus confirming
the molecular structure as methyl ester. In the mass fragmenta-
tion pattern of FAME, the base peak was assigned to be the
1-methoxyethenol moiety (m/z ) 74) obtained by McLafferty
rearrangement per se with the loss of the McLafferty ion (m/z
) 222). The results are similar to those obtained in earlier
studies (24). The molecular ion undergoes further rearrangement
to furnish 1-methoxyprop-2-en-1-ol (m/z ) 88). The spectra
further contained lower m/z fragment ions at a difference of
m/z ) 14, definitely supporting the general structure of FAME,
viz., [-CH3OCO(CH2)nCH3]+ in the homologous series. The
abundance of fragment ions in SFA and MUFA-FAME was
found to be higher than in the EI-MS spectra of PUFAs. The
EI-MS spectra of methyl octadeca-9,12-dienoate or methyl
linoleate have an abundant molecular ion (m/z ) 294) and base
peak as the McLafferty ion (m/z ) 74). In methyl octadeca-9,-
12,15-trienoate or methyl R-linolenate (18:3n3), a fragment ion
at m/z ) 150 was obvious, which is characteristic for fatty acids
with an n3 terminal moiety, while one at m/z ) 108 defines an
n3 terminal group as in methyl methyl eicosa-5,8,11,14,17-
pentaenoate or methyl eicosapentaenoate and methyl docosa-
4,7,10,13,16,19-hexaenoate or methyl docosahexaenoate. In the
mass fragmentation pattern of methyl eicosa-5,8,11,14-tet-
raenoate or methyl arachidonate, the molecular ion is barely
distinguishable, but the characteristic ion for the n3 moiety, at
m/z ) 108, is apparent. In the mass fragmentation pattern of
PUFAs with more double bonds (n g 4), the tropylium ion (m/z
) 91) does stand out as the diagnostic fragment ion. In the
mass fragmentation pattern of N-acyl pyrrolidides, the base peak
was assigned to be the McLafferty rearrangement ion, 1-(pyr-
rolidin-1-yl)-ethenol (m/z ) 113), with the concurrent loss of
the (M - 113) fragment ion. The molecular ion undergoes
further rearrangement to furnish 1-(pyrrolidin-1-yl)-prop-2-en-
1-ol (m/z ) 127). In the mass spectrum of 1-(pyrrolidin-1-yl)
octadeca-9,12,15-trien-1-one, the double bonds in positions 9
and 12 are located by the gaps of m/z ) 12 units between ions
at m/z ) 196, 208 and 236, 248, respectively.
Fatty Acid Composition of Microalgae and Baker’s Yeast.
The abundance of the fatty acid content of the logarithmic phase
N. salina was 20:5n3 > 16:1n7 > 16:0 > 18:1n9 > 20:4n6 >
22:6n3, in decreasing order (Table 1). Among SFAs, 16:0 was
found to be the most dominant contributing 21% of TFAs in
N. salina. Among n3 fatty acids, EPA was found to be the most
abundant in the logarithmic phase of N. salina (25.8% TFA)
and C. calcitrans (18.7% TFA). The high DHA (4.18%) levels
in N. salina caused it to have a higher DHA:EPA ratio (0.16)
than C. calcitrans diet (Table 1). The highest levels of PUFAs
in N. salina were influenced by high percentages of EPA and
AA, with the EPA/AA ratio of 2.72. The C18 fatty acids were
present in small amounts in C. calcitrans (6.62% TFA), although
significant C16 PUFAs (like 16:2n4, 22.5% TFA) were apparent.
Chlorella salina had higher proportions of shorter carbon chain
PUFAs (18:2n6, 18:3n3) together with lower amounts of C16
fatty acids (Table 1). The highest levels of MUFAs were found
The qualitative GC-MS analyses were performed using electronic
impact (EI) ionization mode in a Varian GC (CP-3800) interfaced with
a Varian instrument 1200L single quaduple Mass Spectrometer for
confirmation of fatty acid identification. The GC apparatus was
equipped with WCOT fused silica capillary column of high polarity
(DB-5; 30 m × 0.25 mm i.d., 0.39 mm o.d., and 0.25 µm film thickness;
Varian). The polymeric stationary phase was nonpolar (VF-5MS, 5%
phenyl-substituted methylsiloxane). The carrier gas was ultrahigh purity
He (99.99% purity) with a constant flow rate of 1 mL/min. The injector
(type 1079) and detector temperatures were maintained at 300 °C. The
injection volume was 1 µL. Samples were injected in split (1:15) mode
at 300 °C into the capillary column similar to that used for the GC
analyses, and the oven was identically programmed. The ion source
and transfer line were kept at 300 °C. Electron ionization (E.I.) was
produced by accelerating electrons from a hot filament through a
potential difference at the standard value of 70 eV. The mass
spectrometer conditions were as follows: ion source temperature, 200
°C; scan, 10-800 atomic mass units (amu); centroid scan mode; scan
rate, 1250 amu/s; and dwell time, 1.5 s. Mass spectra were analyzed
using Varian Workstation (version 6.2) software. For example, the mass
spectrometric data of methyl eicosa-5,8,11,14,17-pentaenoate/methyl
eicosapentaenoate were as follows. EI-MS m/z (rel. int. %): 315 (M+,
1.67), 175 (6.67), 161 (8.33), 145 (11.67), 131 (18.33), 119 (31.67),
108 (31.67), 91 (70.00), 79 (100), 67 (68.33), 55 (48.33). The data for
methyl docosa-4,7,10,13,16,19-hexaenoate/methyl docosahexaenoate
were as follows. EI-MS m/z (rel. int. %): 342 (M+, 0.60), 145 (4.20),
131 (6.60), 119 (10.80), 108 (11.40), 91 (28.20), 79 (100), 67 (20.40).
The following are the mass spectrometric data of 1-(pyrrolidin-1-yl)
eicosa-5,8,11,14,17-pentaen-1-one. EI-MS m/z (rel. int. %): 355 (M+,
3.85), 286 (7.69), 232 (7.69), 126 (13.46), 113 (100), 85 (17.31), 72
(26.92), 55 (21.15). The data for 1-(pyrrolidin-1-yl) octadeca-9,12-dien-
1-one are as follows. EI-MS m/z (rel. int. %): 381 (M+, 3.91), 312
(7.05), 272 (7.29), 232 (16.22), 218 (15.76), 192 (8.24), 166 (23.67),
153 (22.85), 113 (100), 98 (46.62), 72 (21.98).
Statistical Analyses. The percentage composition of individual
FAMEs in the diets and Artemia sampled at different enrichment times
were subjected to a one-way analysis of variance (ANOVA), and
significant means were compared by Tukey’s multiple range tests.
Correlations between Artemia and microalgal fatty acids were inves-
tigated using SPSS (version 10.0) software. A significance level of
95% (p ) 0.05) was used throughout. Arc sin transformation was used
