Reductive Bergman-Type Cyclizations of Cross-Conjugated
Enediynes to Fulvene and Fulvalene Anions: The Role of the
Substituent
Noach Treitel,† Lior Eshdat,†,‡ Tuvia Sheradsky,† Patrick M. Donovan,§
Rik R. Tykwinski,| Lawrence T. Scott,§ Henning Hopf, and Mordecai Rabinovitz*,†
Contribution from the Department of Organic Chemistry and The Lise Meitner MinerVa Center
for Computational Chemistry, Safra Campus, The Hebrew UniVersity of Jerusalem, GiVat Ram,
Jerusalem 91904, Israel, Department of Chemistry, UniVersity of Alberta, Edmonton, AB
T6G2G2, Canada, Merkert Chemistry Center, Department of Chemistry, Boston College,
Chestnut Hill, Massachusetts 02467-3860, and Organic Chemistry, Technical UniVersity of
Braunschweig, Hagenring 30 D-38106 Braunschweig, Germany
Received October 12, 2005; E-mail: mordecai@vms.huji.ac.il
Abstract: Various cross-conjugated enediynes undergo “Bergman-type” cycloaromatizations upon reduction
with potassium metal, generating anions of fulvenes and fulvalene derivatives. This new anionic cyclization
is considerably more facile than the classic Bergman cyclization with linear enediynes, creating highly reactive
diradicals at -78 °C. Not all cross-conjugated enediynes yield cyclized dianions upon reduction; some
give uncyclized, Y-shaped, cross-conjugated dianions, while others apparently yield radical-anions that
either dimerize or persist as monomers. One system yields both a cyclized and an uncyclized dianion. The
substituents are thus shown to be a critical factor in determining the outcome of the reduction. Cyclization
occurs within a specific “window of opportunity” that is governed by the substituents.
and molecular wires,11 conjugated polymers,11,12 carbon allot-
Introduction
ropes,12 and radialenes.13 Linear enediynes (1), containing a 1,2-
Recent years have witnessed a considerable surge in the study
of enediyne cyclizations. Many reactions, such as the Bergman,1
Myers-Saito,2 Schmittel3 and Schreiner4 cyclizations bring
about aromatic biradicals, with applications in pharmacology,
as these biradicals or their byproducts5 cause DNA cleavage,
ultimately destroying the DNA of viruses and bacteria. The
antitumor antibiotic drugs calicheamicin γ1,6 dynemicin,7 and
esperamicin A1
intermediates due to Bergman cyclizations, while a Myers-
Saito cyclization is the key step in the mechanism of action of
the antitumor agent neocarzinostatin.9
Additionally, enediynes serve as precursors for bowl-shaped
fullerene fragments10 and as building blocks of dendritic rods
diethynylethylene moiety with six π-electrons, undergo standard
Bergman cycloaromatizations (Scheme 1a). Indeed, this is the
(6) See, for instance: (a) Lee, M. D.; Dunne, T. S.; Siegel, M. M.; Chang, C.
C.; Morton, G. O.; Borders, D. B. J. Am. Chem. Soc. 1987, 109, 3464. (b)
Lee, M. D.; Dunne, T. S.; Chang, C. C.; Ellestad, G. A.; Siegel, M. M.;
Morton, G. O.; McGahren, W. J.; Borders, D. B. J. Am. Chem. Soc. 1987,
109, 3466. (c) Magnus, P.; Lewis, R. T.; Huffman, J. C. J. Am. Chem.
Soc. 1988, 110, 6921. (d) Haseltine, J. N.; Danishefsky, S. J. J. Am. Chem.
Soc. 1989, 111, 7638. (e) Magnus, P.; Fortt, S.; Pitterna, T.; Snyder, J. P.
J. Am. Chem. Soc. 1990, 112, 4986. (f) Nicolaou, K. C. Angew. Chem.,
Int. Ed. Engl. 1993, 32, 1377. (g) Hitchcock, S. A.; Chu-Moyer, M. Y.;
Boyer, S. H.; Olson, S. H.; Danishefsky, S. J. J. Am. Chem. Soc. 1995,
117, 5750. (h) Thornson, J. S.; Sievers, E. L.; Ahlert, J.; Shepard, E.;
Whitwam, R. E.; Onwueme, K. C.; Ruppen, M. Curr. Pharm. Design 2000,
6, 1841.
(7) For example: (a) Konishi, M.; Ohkuma, H.; Tsuno, T.; Oki, T.; VanDuyne,
G. D.; Clardy, J. J. Am. Chem. Soc. 1990, 112, 3715. (b) Nicolaou, K. C.;
Dai, W.-M. Angew. Chem., Int. Ed. Engl. 1991, 30, 1387. (c) Maier, M.
E.; Bosse, F.; Niestroj, A. J. Eur. J. Org. Chem. 1999, 1.
(8) For instance: (a) Golik, J.; Clardy, J.; Dubay, G.; Groenewold, G.;
Kawaguchi, H.; Konishi, M.; Krishnan, B.; Ohkuma, H.; Saitoh, K.-i.;
Doyle, T. W. J. Am. Chem. Soc. 1987, 109, 3461. (b) Golik, J.; Dubay, G.;
Groenewold, G.; Kawaguchi, H.; Konishi, M.; Krishnan, B.; Ohkuma, H.;
Saitoh, K.-i.; Doyle, T. W. J. Am. Chem. Soc. 1987, 109, 3462.
(9) Myers, A. G.; Dragovich, P. S.; Kuo, E. Y. J. Am. Chem. Soc. 1992, 114,
9369.
(10) Zimmermann, G.; Nu¨chter, U.; Hagen, S.; Nu¨chter, M. Tetrahedron Lett.
1994, 35, 4747.
(11) Schenning, A. P. H. J.; Arndt, J.-D.; Ito, M.; Stoddart, A.; Schreiber, M.;
Siemsen, P.; Martin, R. E.; Boudon, C.; Gisselbrecht, J.-P.; Gross, M.;
Gramlich, V.; Diederich, F. HelV. Chim. Acta 2001, 84, 296 and references
therein.
(12) See, for instance: (a) Diederich, F.; Rubin, Y. Angew. Chem., Int. Ed. Engl.
1992, 31, 1101. (b) Zhao, Y.; Tykwinski, R. R. J. Am. Chem. Soc. 1999,
121, 458. (c) Diederich, F. Pure Appl. Chem. 1999, 71, 265.
(13) For example: (a) Lange, T.; Gramlich, V.; Amrein, W.; Diederich, F.; Gross,
M.; Boudon, C.; Gisselbrecht, J.-P. Angew. Chem., Int. Ed. Engl. 1995,
34, 805. (b) Eisler, S.; Tykwinski, R. R. Angew. Chem. Int. Ed. 1999, 38,
1940.
6c-e,8
all become active p-benzyne biradical
† The Hebrew University of Jerusalem.
‡ Present address: Liquid Crystal Materials Research Center, Department
of Chemistry and Biochemistry, University of Colorado at Boulder, Boulder,
CO 80309-0215.
§ Boston College.
| University of Alberta.
Technical University of Braunschweig.
(1) (a) Jones, R. R.; Bergman, R. G. J. Am. Chem. Soc. 1972, 94, 660. (b)
Bergman, R. G. Acc. Chem. Res. 1973, 6, 25. (c) Lockhardt, T. P.; Commita,
P. B.; Bergman, R. G. J. Am. Chem. Soc. 1981, 103, 4082.
(2) (a) Myers, A. G.; Kuo, E. Y.; Finney, N. S. J. Am. Chem. Soc. 1989, 111,
8057. (b) Saito, K.; Watanabe, T.; Takahashi, K. Chem. Lett. 1989, 2099.
(3) Schmittel, M.; Strittmatter, M.; Kiau, S. Tetrahedron Lett. 1995, 36, 4975.
(4) (a) Prall, M.; Wittkopp, A.; Schreiner, P. R. J. Phys. Chem. A 2001, 105,
9265. (b) Prall, M.; Wittkopp, A.; Fokin, A. A.; Schreiner, P. R. J. Comput.
Chem. 2001, 22, 1605.
(5) Under physiological conditions, a likely alternative mechanism of the
biradical transforming into a quinone exists: Jones, L. H.; Harwig, C. W.;
Wentworth, P., Jr.; Simeonov, A.; Wentworth, A. D.; Py, S.; Ashley, J.
A.; Lerner, R. A.; Janda, K. D. J. Am. Chem. Soc. 2001, 123, 3607.
9
10.1021/ja0566477 CCC: $33.50 © 2006 American Chemical Society
J. AM. CHEM. SOC. 2006, 128, 4703-4709
4703

A R T I C L E S
Treitel et al.
Scheme 3. Systems Under Investigation in This Research
Scheme 1. (a) Standard Bergman Cyclization Observed for a Six
π-Electron Linear Enediyne and (b) Not Observed for a Six
π-Electron Cross-Conjugated Enediyne
Scheme 2. Cyclizations of 3 under (route a) Thermal Conditions,
