REACTION OF SILICON TETRAFLUORIDE WITH CALCIUM HYDRIDE
7
T, °C
300
T, °C
300
CCT
2
1
4
τ1
3
τ2
τ3
τ4
250
200
150
100
τ5
250
200
150
100
0
50 100 150 200 250 300 350 400 450 500
Time, min
1
2
3
4
5
CCT no.
Fig. 3. Spatial profile of the reaction wave in different time
moments (τ < τ < τ < τ < τ ). The distance between
Fig. 2. Thermoanalytical curves for the reaction of silicon
tetrafluoride with calcium hydride (cocurrent wave):
1−4 are the numbers the CCTs.
1
2
3
4
5
CCTs is 5 cm.
conductivity detector on a column packed with the
Polisorb PS-1 polymeric sorbent using helium as a car-
rier gas and a thermostat temperature of 70°ë.
profile. This corresponds to the representation of the
regime of the reaction in the form of a propagating local
zone.
The chromatographic analysis of the gas phase at
the outlet of the reactor showed a considerable amount
of silane. In addition, the chromatogram contained
peaks presumably attributed to fluorosilanes. Gravi-
metric analysis showed a considerably decreased effec-
tive formula weight of the gaseous products (FW =
30.6), which was, however, somewhat larger than cal-
culated for the complete conversion of silicon tetraflu-
oride to silane (FW = 26).
RESULTS AND DISCUSSION
In a control experiment, the initial temperature of
the reactor was chosen to be 100°ë, a temperature at
which, according to [5], no reaction occurred. After a
mixture of 80 mol % SiF4 + 20 mol % ç2 was fed, the
temperature in the reactor remained unchanged and the
qualitative and quantitative composition of the gas
phase at the outlet of the reactor corresponded to the
initial composition.
The generation and propagation of the reaction
wave cocurrent with the gas flow were observed in the
experiments described. To check the possibility of the
counterflow propagation of the reaction zone, the fur-
nace for process initiation was placed at the end of the
reaction opposite to the inlet of the gaseous reactant.
The temperature on CCT 4 (Fig. 4) increased some time
after the reactor and initiating ovenfurnace were heated
to the corresponding temperatures and the flow of a
mixture of silicon tetrafluoride and dihydrogen was fed
and then on CCT 3, CCT 2, and CCT 1. Thus, in this
experiment the reaction wave propagated in the coun-
tercurrent flow with the gaseous reactant.
In the next experiment, the ignition furnace was
placed in the region of the reactor near the gas inlet
(Fig. 1) and the local region of the reactor was heated to
180°ë. At this temperature, silicon tetrafluoride con-
verts to silane within a short time (~10 s) [5]. Therefore,
it was assumed that the reaction is initiated in the heated
region. Indeed, after the reaction mixture was fed, a con-
siderable temperature (to about 280°C) increase was first
recorded by CCT 1, then by CCT 2, CCT 3, etc. (Fig. 2).
After achieving the maximum, the temperature gradu-
ally decreased in all cases. The temperature wave prop-
agation observed along the reactor can be explained
only by the appearance and propagation of a local
region of the exothermic reaction between silicon tet-
rafluoride and calcium hydride.
It is of interest that the processes did not stop after
the reaction wave reached the lowest end of the reactor.
After some time (~10 min), the temperature on CCT 1
increased again. Then, the reaction wave propagated up
the reactor in the concurrent flow with the gaseous reac-
tant, which was detected by the successive temperature
increase on CCT 1, CCT 2, CCT 3, CCT 4, CCT 5, and
The same experiment was carried out using a block
of five CCTs arranged at 5 cm from each other to mea-
sure temperature. This made it possible to record the
spatial profile of the temperature wave. The results of
the measurements are presented in Fig. 3. At least in a
short segment of the reactor length, the wave propa- CCT 6. The observed phenomenon is related to the so-
gates in the steady-state regime retaining the geometric called reflection of the wave of the self-propagating
RUSSIAN JOURNAL OF INORGANIC CHEMISTRY Vol. 53 No. 1 2008
