Synthesis and x-ray absorption spectroscopy structural studies of Cu(I) complexes of HistidylHistidine peptides: The predominance of linear 2-coordinate geometry

Article abstract of DOI:10.1021/ja0708013

Modified His-His dipeptides have been reacted with copper(I) salts to model active-site Cu ions bound by contiguous His residues in certain oxygen-activating copper proteins, as well as amyloid β-peptide. Chelation of copper(I) by these ligands affords linear, two-coordinate complexes as studied structurally by X-ray absorption spectroscopy. The complexes are robust toward oxidation, showing limited to no reactivity with O₂, and they bind CO weakly. Reaction with a third ligand (N-methylimidazole) affords complexes with a markedly different structure (distorted T-shaped) and reactivity, binding CO and oxidizing rapidly upon exposure to dioxygen. Copyright

Full text of DOI:10.1021/ja0708013

Published on Web 04/06/2007
Synthesis and X-ray Absorption Spectroscopy Structural Studies of Cu(I)
Complexes of HistidylHistidine Peptides: The Predominance of Linear
2-Coordinate Geometry
Richard A. Himes,† Ga Young Park,† Amanda N. Barry,‡ Ninian J. Blackburn,‡ and
Kenneth D. Karlin*,†
Department of Chemistry, The Johns Hopkins UniVersity, 3400 N. Charles Street, Baltimore, Maryland 21218, and
Department of EnVironmental and Biomolecular Systems, OGI School of Science and Engineering at OHSU,
BeaVerton, Oregon 97006
Received February 4, 2007; E-mail: karlin@jhu.edu
The importance of protein-based ligand tuning of copper active
sites has been noted and recapitulated in model systems (e.g.,
sensitivity of Cu-O2 structure and reactivity to coordination
number, geometry, and bonding atoms).1,2 Several enzymessPHM,
DâH, and CcO3spossess active site Cu ions bound by contiguous
histidine residues, a binding motif unique to these redox/O2-
processing enzymes.4,5
We hypothesized that HisHis ligation of copper ion, in particular
CuI (the reduced form of the CuII/CuI redox pair) may enforce
structural/binding properties sin particular, a linear 2-coordinate
geometrysthat might also dictate particular redox properties and/or
reactivity patterns for the system, as has been observed in two-coor-
dinate CuI complexes of monodentate ligands (also see later).6-10
Thus, we set out to investigate these biologically relevant coordina-
tion aspects of HisHis. In this report, we describe the generation
of a series of such dipeptides and demonstrate via spectroscopic
Figure 1. EXAFS and XANES data and results carried out on copper(I)
complexes 1-4, and results of DFT calculations related to [LδCuI]+ (1).
interrogation and chemical behavior that indeed, strong preferences
for near-linear two-coordinate CuI geometries are observed.
Dipeptides with regioselectively substituted imidazole sidechains
(Nꢀ vs Nδ) have been synthesized by modifications of literature
procedures and standard solution-phase techniques.11 Tautomeric
preferences appear in Cu enzymes:12-14 Cu ion binds to NδNδ of
the HisHis fragment of the PHM CuH site,5,15,16 but NꢀNꢀ at the
cyt. c oxidase CuB site.4,12,17,18 The ligands synthesized for study
(diagram) were chosen in order to elucidate the implications of
these binding modes.
ligand scatterers with Cu-N ≈ 1.86-1.87 Å are indicative of linear
2-coordinate CuI. (Cu-N does not deviate from 1.86 to 1.88 Å for
known chemical examples.6-9,20) Three-coordinate complexes have
significantly longer Cu-N bond distances. Near-edge (XANES)
data (Figure 1) corroborate 2- and not 3-coordination, based on
strong precedent; the 2-coordinate [LδCuI]+ (1) near-edge absorption
is intense compared to 3-coordinate analogues (vide infra).21,22
DFT geometry optimization (B3LYP/6-311G**) supports the
experimental (i.e., EXAFS) structure analysis (Figure 1).11 A Cu-
HisNδHisNδ model minimizes to near-linear 2-coordinate geometry
with Cu-N bonds within 0.002-0.005 Å of the EXAFS values.23
In contrast, molecular mechanics and DFT calculations suggest that
an intramolecular 2-coordinate structure bound solely by the Nꢀ of
His imidazoles is thermodynamically disfavored, requiring severe
strain in the ligand. A dimeric Cu2L2 structure, that is, with
intermolecular Cu-HisNꢀ binding, is proposed to rationalize the
EXAFS data (also see below).
Solution (acetone) conductivity data for all three complexes were
also acquired. Onsager plots for [LδCuI]ClO4 and [LHCuI]ClO4 have
slopes in the range expected for 1:1 (monomeric) electrolytes, that
is, consistent with the mononuclear complex formulation.24 How-
ever, the slope for the Lꢀ complex indicates a 2:1 electrolyte behav-
ior; that is, a dimer, [(Lꢀ)2CuI2](ClO4)2, persists in acetone, as was
formulated for the solid (vide supra). The preference for Lꢀ to form
a dimeric structure further demonstrates the favorability of the
2-coordinate near-linear geometry for these CuI-ligand systems.
Additionally, [LΗCuI]+, with unblocked imidazole N-atoms, gives
a 2-coordinate structure and 1:1 solution conductivity, suggesting
it may preferentially bind to Nδ nitrogens of adjacent His residues.
CuI complexes of Lδ, Lꢀ, and LH were synthesized in either CH2-
Cl2 or acetone using [CuI(MeCN)4]Y salts (Y ) ClO4-, B(C6F5)4-).11
Solid complexes were isolated by precipitation and purified by
recrystallization; they give satisfactory C,H,N combustion analysis,
ESI-MS mass envelope isotope patterns are consistent with the
[LCuI]+ cation formulations and small shifts in the imidazolyl C-H
resonances are observed by 1H NMR spectroscopy of [LCuI]+
compared to that of the free ligand.11
EXAFS analysis of the solid complexes provides unequivocal
evidence for a near-linear 2-coordinate geometry, with His ligation19
in all cases. For [LδCuI]+, the Fourier transform and the results/
data for all complexes are given in Figure 1.11 Fits to two NHis
-
† The Johns Hopkins University.
‡ OGI School of Science and Engineering at OHSU.
9
5352
J. AM. CHEM. SOC. 2007, 129, 5352-5353
10.1021/ja0708013 CCC: $37.00 © 2007 American Chemical Society

C O M M U N I C A T I O N S
Scheme 1
ments, such as occurs in CcO (vide supra) and also in the copper
binding portion of the amyloid beta (Aâ) peptide involved in
Alzheimer’s Disease.31
Acknowledgment. We gratefully acknowledge financial support
of this work (Grants NIH GM28962, K.D.K.; NIH Postdoctoral
Fellowship, R.A.H.; NIH NS27583, N.J.B.).
Supporting Information Available: Synthetic and computational
details, spectroscopic methods and data, and EXAFS fitting methods
are included. This material is available free of charge via the Internet
at http://pubs.acs.org.
References
The complexes’ properties were probed via reactivity with small
(1) Mirica, L. M.; Ottenwaelder, X.; Stack, T. D. P. Chem. ReV. 2004, 104,
1013-1045.
molecules (O2, CO) and electrochemistry (CV). All three complexes
are unreactive toward O2 as solids or in solution below 0 °C (with
only very slow oxidation occurring at room temperature). This
behavior is analogous to that observed for linear 2-coordinate CuI
complexes studied by Sorrell, Karlin, and others.6-8 The HisHis
[LCuI]+ complexes bind CO (as an O2-surrogate) weakly, with high-
frequency stretching vibrations (νCO ) 2110-2105 cm-1) of low
intensity.8,25 The complexes display irreversible redox behavior, to
be expected for two-coordinate copper, and a high Epa value ([Lδ-
CuI]+ in DMF: 325 mV vs Fc+/Fc) is consistent with resistance to
oxidation.
Three-coordinate derivatives, formed by the addition of N-
methylimidazole (MeIm) to the parent CuI-HisHis complexes,
exhibit starkly contrasting behavior (Scheme 1). [LδCuI(MeIm)]+
(4), characterized by C,H,N analysis and 1H NMR spectroscopy,11
for example, oxidizes rapidly with added O2.26 The complex binds
CO in CH2Cl2 solution with more pronounced backbonding (and
thus lowered νCO ) 2075 cm-1) and higher intensity compared to
2-coordinate [LδCuI]+. Complex 4 exhibits reVersible redox
behavior, E1/2 = -275 mV vs Fc+/Fc (DMF solvent).
(2) Hatcher, L. Q.; Karlin, K. D. J. Biol. Inorg. Chem. 2004, 9, 669-683.
(3) Abbreviations: PHM ) peptidylglycine R-hydroxylating monooxygenase;
DâH ) dopamine â-hydroxylase; CcO ) cytochrome c oxidase.
(4) Kim, E.; Chufan, E. E.; Kamaraj, K.; Karlin, K. D. Chem. ReV. 2004,
104, 1077-1133.
(5) Blackburn, N. J.; Rhames, F. C.; Ralle, M.; Jaron, S. J. Biol. Inorg. Chem.
2000, 5, 341-353.
(6) Sanyal, I.; Strange, R. W.; Blackburn, N. J.; Karlin, K. D. J. Am. Chem.
Soc. 1991, 113, 4692-4693.
(7) Sanyal, I.; Karlin, K. D.; Strange, R. W.; Blackburn, N. J. J. Am. Chem.
Soc. 1993, 115, 11259-11270.
(8) Sorrell, T. N.; Jameson, D. L. J Am. Chem. Soc. 1983, 105, 6013-6018.
(9) Tan, G. O.; Hodgson, K. O.; Hedman, B.; Clark, G. R.; Garrity, M. L.;
Sorrell, T. N. Acta Cryst. C 1990, 46, 1773-1775.
(10) Le Clainche, L.; Giorgi, M.; Reinaud, O. Eur. J. Inorg. Chem. 2000, 1931-
1933.
(11) See Supporting Information.
(12) Karlin, S.; Zhu, Z. Y.; Karlin, K. D. Biochemistry 1998, 37, 17726-
17734.
(13) Karlin, K. D.; Zhu, Z. Y.; Karlin, S. J. Biol. Inorg. Chem. 1998, 3, 172-
187.
(14) Karlin, S.; Zhu, Z. Y.; Karlin, K. D. Proc. Natl. Acad. Sci. U.S.A. 1997,
94, 14225-14230.
(15) Prigge, S. T.; Kolhekar, A. S.; Eipper, B. A.; Mains, R. E.; Amzel, L. M.
Science 1997, 278, 1300-1305.
(16) Prigge, S. T.; Eipper, B. A.; Mains, R. E.; Amzel, L. M. Science 2004,
304, 864-867.
(17) Iwata, S.; Ostermeier, C.; Ludwig, B.; Michel, H. Nature 1995, 376, 660-
EXAFS and XANES data obtained for [(Lδ)CuI(MeIm)] confirm
a 3-coordinate structure (Scheme 1); the near-edge absorption is
of characteristically lower intensity compared to the 2-coordinate
parent (Figure 1).21 The complex adopts a distorted T-shaped
geometry, in which the Cu-NHis bonds (presumably) have slightly
lengthened (by 0.02 Å), and MeIm provides a Cu-N scatterer at a
longer distance (2.008 Å) from CuI.
In conclusion, we have synthesized a series of CuI complexes
of HisHis dipeptides showing that linear 2-coordinate NδNδ ligation
is very favorable, but the site is NOT redox active. The geometry
resembles that found by EXAFS for reduced PHM CuH (vide supra).
We have here also demonstrated that addition of a third N-donor
to these complexes activates the Cu ion for redox activity. This
may have significance for a detailed understanding of the function-
ing of the CuH electron-transfer site of PHM. Changes in CuH
coordination are known to occur upon oxidation of the enzyme.5
CuH coordination and CO-binding characteristics are also influenced
if substrate is added (and binds to the CuM site ∼11 Å away),27,28
or when Met314 at this CuM site is mutated.29 Further, enzyme
activity and possibly its mechanism are altered by mutations of
His172 (the third ligand).30
All these factors are relatively poorly understood; our new
peptide models in further studies may shed light on the significance
of the geometry and coordination of the PHM CuH site (e.g, what
subtle tuning of CuI-coordination facilitates electron-transfer chem-
istry). In addition, these results have encouraged us that studies of
CuI-model peptide complexes may yield insights into Cu-redox
properties and CuI-O2 reactivity that have not been forthcoming
with studies of other model systems. Future investigations include
CuI oxidative chemistry in these unique HisHis Cu-binding environ-
669.
(18) Tsukihara, T.; Aoyama, H.; Yamashita, E.; Tomizaki, T.; Yamaguchi,
H.; Shinzawaitoh, K.; Nakashima, R.; Yaono, R.; Yoshikawa, S. Science
1995, 269, 1069-1074.
(19) Mulitple scattering definitively reveals the patterns known for NHis metal
coordination.11
(20) (a) Okkersen, H.; Groeneve, Wl.; Reedijk, J. Recl. TraV. Chim. Pays-Bas
1973, 92, 945-953. (b) Lewin, A. H.; Cohen, I. A.; Michl, R. J. J. Inorg.
Nucl. Chem. 1974, 36, 1951-1957. (c) Agnus, Y.; Louis, R.; Weiss, R.
J. Chem. Soc., Chem. Commun. 1980, 867-869. (d) Engelhardt, L. M.;
Pakawatchai, C.; White, A. H.; Healy, P. C. J. Chem. Soc., Dalton Trans.
1985, 117-123. (e) Munakata, M.; Kitagawa, S.; Shimono, H.; Masuda,
H. Inorg. Chim. Acta 1989, 158, 217-220. (f) Habiyakare, A.; Lucken,
E. A. C.; Bernardinelli, G. J. Chem. Soc., Dalton Trans. 1991, 2269-
2273.
(21) Blackburn, N. J.; Strange, R. W.; Reedijk, J.; Volbeda, A.; Farooq, A.;
Karlin, K. D.; Zubieta, J. Inorg. Chem. 1989, 28, 1349-1357.
(22) Kau, L. S.; Spira-Solomon, D. J.; Penner-Hahn, J. E.; Hodgson, K. O.;
Solomon, E. I. J. Am. Chem. Soc. 1987, 109, 6433-6442.
(23) See Supporting Information for discussion and comparisons to recently
published calculations: Raffa, D. F.; Rickard, G. A.; Rauk, A. J. Biol.
Inorg. Chem. 2007, 12, 147-164.
(24) Geary, W. J. Coord. Chem. ReV. 1971, 7, 81-122.
(25) (a) Voo, J. K.; Lam, K. C.; Rheingold, A. L.; Riordan, C. G. J. Chem.
Soc., Dalton Trans. 2001, 1803-1805. (b) Casella, L.; Gullotti, M.;
Pallanza, G.; Rigoni, L. J. Am. Chem. Soc. 1988, 110, 4221-4227. (c)
Pasquali, M.; Floriani, C.; Gaetanimanfredotti, A. Inorg. Chem. 1980, 19,
1191-1197. (d) Cole, A. P.; Mahadevan, V.; Mirica, L. M.; Ottenwaelder,
X.; Stack, T. D. P. Inorg. Chem. 2005, 44, 7345-7364. (e) Chou, C. C.;
Su, C. C.; Yeh, A. Inorg. Chem. 2005, 44, 6122-6128.
(26) In fact, we have observed Cu-O2 adducts at low (-80°C) temperature in
solution, to be reported elsewhere.
(27) Jaron, S.; Blackburn, N. J. Biochemistry 2001, 40, 6867-6875.
(28) Jaron, S.; Mains, R. E.; Eipper, B. A.; Blackburn, N. J. Biochemistry 2002,
41, 13274-13282.
(29) Siebert, X.; Eipper, B. A.; Mains, R. E.; Prigge, S. T.; Blackburn, N. J.;
Amzel, L. M. Biophys. J. 2005, 89, 3312-3319.
(30) Evans, J. P.; Blackburn, N. J.; Klinman, J. P. Biochemistry 2006, 45,
15419-15429.
(31) Gaggelli, E.; Kozlowski, H.; Valensin, D.; Valensin, G. Chem. ReV. 2006,
106, 1995-2044.
JA0708013
9
J. AM. CHEM. SOC. VOL. 129, NO. 17, 2007 5353
