Fentanyl family at the mu-opioid receptor: Uniform assessment of binding and computational analysis

Article abstract of DOI:10.3390/molecules24040740

Interactions of 21 fentanyl derivatives with μ-opioid receptor (μOR) were studied using experimental and theoretical methods. Their binding to μOR was assessed with radioligand competitive binding assay. A uniform set of binding affinity data contains val

Full text of DOI:10.3390/molecules24040740

molecules
Article
Fentanyl Family at the Mu-Opioid Receptor: Uniform
Assessment of Binding and Computational Analysis
Piotr F. J. Lipin´ski 1,
*
, Piotr Kosson 2, Joanna Matalin´ska 1, Piotr Roszkowski 3,
Zbigniew Czarnocki 3, Małgorzata Jaron´czyk 4 , Aleksandra Misicka 1,3
,
Jan Cz. Dobrowolski 4 and Joanna Sadlej 4,5,
*
1
Department of Neuropeptides, Mossakowski Medical Research Centre, Polish Academy of Sciences,
02-106 Warsaw, Poland; jmatalinska@imdik.pan.pl (J.M.); misicka@imdik.pan.pl (A.M.)
Toxicology Research Laboratory, Mossakowski Medical Research Centre, Polish Academy of Sciences,
02-106 Warsaw, Poland; pkosson@imdik.pan.pl
Faculty of Chemistry, University of Warsaw, 02-093 Warsaw, Poland; roszkowski@chem.uw.edu.pl (P.R.);
czarnoz@chem.uw.edu.pl (Z.C.); misicka@chem.uw.edu.pl (A.M.)
National Medicines Institute, 00-725 Warsaw, Poland; m.jaronczyk@nil.gov.pl (M.J.);
j.dobrowolski@nil.gov.pl (J.Cz.D.)
Faculty of Mathematics and Natural Sciences, University of Cardinal Stefan Wyszyn´ski, 1/3
Wóycickiego-Str., 01-938 Warsaw, Poland
2
3
4
5
*
Correspondence: plipinski@imdik.pan.pl (P.F.J.L.); j.sadlej@uksw.edu.pl (J.S.)
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 30 January 2019; Accepted: 15 February 2019; Published: 19 February 2019
Abstract: Interactions of 21 fentanyl derivatives with
µ-opioid receptor (
µOR) were studied using
experimental and theoretical methods. Their binding to
µOR was assessed with radioligand
competitive binding assay. A uniform set of binding affinity data contains values for two novel and
one previously uncharacterized derivative. The data confirms trends known so far and thanks to their
uniformity, they facilitate further comparisons. In order to provide structural hypotheses explaining
the experimental affinities, the complexes of the studied derivatives with µOR were modeled and
subject to molecular dynamics simulations. Five common General Features (GFs) of fentanyls’
binding modes stemmed from these simulations. They include: GF1) the ionic interaction between
D147 and the ligands’ piperidine NH+ moiety; GF2) the N-chain orientation towards the
µOR interior;
GF3) the other pole of ligands is directed towards the receptor outlet; GF4) the aromatic anilide
ring penetrates the subpocket formed by TM3, TM4, ECL1 and ECL2; GF5) the 4-axial substituent
(if present) is directed towards W318. Except for the ionic interaction with D147, the majority of
fentanyl-µOR contacts is hydrophobic. Interestingly, it was possible to find nonlinear relationships
between the binding affinity and the volume of the N-chain and/or anilide’s aromatic ring. This kind
of relationships is consistent with the apolar character of interactions involved in ligand–receptor
binding. The affinity reaches the optimum for medium size while it decreases for both large and
small substituents. Additionally, a linear correlation between the volumes and the average dihedral
angles of W293 and W133 was revealed by the molecular dynamics study. This seems particularly
important, as the W293 residue is involved in the activation processes. Further, the Y326 (OH) and
D147 (Cγ) distance found in the simulations also depends on the ligands’ size. In contrast, neither
RMSF measures nor D114/Y336 hydrations show significant structure-based correlations. They also
do not differentiate studied fentanyl derivatives. Eventually, none of 14 popular scoring functions
yielded a significant correlation between the predicted and observed affinity data (R < 0.30, n = 28).
Keywords: fentanyl; opioid receptors; molecular dynamics; designer drugs
Molecules 2019, 24, 740; doi:10.3390/molecules24040740
www.mdpi.com/journal/molecules

Molecules 2019, 24, 740
2 of 30
1. Introduction
Fentanyl (N-phenyl-N-[1-(2-phenylethyl)piperidin-4-yl]propanamide) is a very strong agonist
-opioid receptor ( OR) and as such it is one of the most important analgesics used in medicine.
Being highly lipophilic, it is 50–125 times more potent than morphine and it has a faster onset of
action [ ]. The compound’s applications include management of chronic and cancer pain as well as
of
µ
µ
1
postoperative pain and analgosedation in intensive care settings. Further, the substance is used for
surgery premedication or general anesthesia (or adjunct to general anesthesia) before minor and major
surgical procedures.
The compound is a prototype of a wider family of synthetic opioid analgesics: 4-anilidopiperidines.
Since the early 1960s, when fentanyl was invented by Paul Janssen and co-workers [2], numerous
members of the group have been synthesized and reported. This research played a key role in
developing our knowledge on structure–activity relationships (SAR) for opioid analgesics. It resulted
in a bunch of very interesting and useful compounds [3], including extremely potent derivatives such
as ohmefentanyl and carfentanil, or ultra-short acting opioids as remifentanil or alfentanil. A very
comprehensive review from the point of view of SAR and chemistry of the class was provided by
Vardanyan and Hruby [3]. Further interesting accounts can be found in other recent papers [2,4].
Even though fentanyl and its derivatives have been known for now almost 60 years, the compound
is still able to stimulate modern research in many subfields at the interface of chemistry and
pharmacology. For instance, Valdez et al. presented optimized syntheses of fentanyl and analogues [
and Jevtic´ et al. described a route for new derivatives via orthogonally protected (in positions 1 and 3)
3-amino-4-anilidopiperidines [ ]. Issues of formulation and drug delivery prompted several groups to
study fentanyl interactions with cyclodextrins in aqueous solutions [ ] or solid state interactions of
fentanyl citrate polymorphs and solvates [ ]. In a very interesting contribution, Bick et al. described
5]
6
7
8
design and synthesis of proteins binding fentanyl for purposes of creating environmental sensors [9].
Yet novel fentanyl derivatives continue to appear. Researchers of various groups reported novel
analogues, including those of norsufentanil [10], carfentanil amides [11] or acrylic derivatives [12].
Fentanyl scaffold has also been used in the design of bivalent (multitarget) compounds to create
mixed µ-/δ-OR ligands [13–15], or molecules joining even more distant pharmacophores like opioid
receptor agonist and FAAH/MAGL hydrolases inhibitors [16], or opioid and dopamine receptors
D2/D3 ligands [17]. Most excitingly, fentanyl has its place also in the most up-to-date trends of
pain pharmacology that is in the research on biased
strong analgesics without adverse effects. Although fentanyl itself or sufentanil are able to very
effectively elicit unwanted (connected to adverse effects) -arrestin recruitment [18], structurally
µOR agonists which holds promise for finding
β
close lie compounds with much higher preference for G-protein activation [19]. Another fascinating
possibility for developing safer analgesic agents opens up with pH-dependent opioid agonists.
Here, novel, computationally designed, fluorinated fentanyl derivatives showed injury-restricted
analgesia in rat models of inflammatory, postoperative or neuropathic pain [20–22], and for some
of them, a significant reduction of typical opioid adverse effects was reported [22]. For now, even
the long-known derivatives still have potential for therapeutic innovation, as testified to by a recent
(2018) FDA approval of sufentanil sublingual formulation (DsuviaTM by AcelRx Pharmaceuticals Inc.,
Redwood, CA, USA) for the treatment of acute pain [23].

Molecules 2019, 24, 740
3 of 30
Unfortunately, the excellent analgesics and research compounds of the fentanyl family have their
darker side, too. The substances bear a high potential for abuse and addiction, and because of narrow
difference between the active (be it for medical or abuse purposes) dose and the lethal one, they can
easily deprive an abuser of life. The issue has been a public health concern since as long ago as late
1970s, when α-methylfentanyl was part of the so-called ‘China White’ responsible for many hundred
deaths of street drug users. In recent years the toxicological significance of fentanyl has grown even
more. The United States is amid the opioid overdose crisis. According to the estimates by National
Centre For Health Statistics, US, in 2017 [24], more than two thirds of drug overdose deaths were caused
by opioids (49068 out of 72306), and among them these resulting from illicitly manufactured fentanyl
(or fentanyl derivatives) intake were the largest group (more than 50%) and the most sharply growing
one. Some alarming reports come also from European countries [25]. The reasons for this deplorable
popularity renaissance include relatively facile and cheap syntheses as well as high potencies of
fentanyl derivatives. From the point of view of chemical sciences, the fentanyl crisis increases the
demand for analytical capabilities to identify illicit substances [26–34], in particular novel derivatives.
This is due to not only the requirements of forensic medicine, but it is also important for regulatory,
preventive and, law enforcement purposes. Here, knowing the current abuse trends enables taking
proper countermeasures in a time-efficient manner.
Having regard to the importance of the fentanyl family in both medicinal and forensic chemistry,
we have set out to study the interactions of 21 fentanyl derivatives (Figure 1) with
by experiment and computations. Our aims were:
µ-opioid receptor
1.
2.
3.
to provide the readers with a uniform assessment (ranking) of the affinity of fentanyl derivatives
for the receptor,
to translate the observed experimental trends in structure–activity relationships into structural
terms by the means of molecular modeling, and
using our experimental values, to see whether the popular scoring methods would be able to
reproduce them with reasonable accuracy.
The molecular modeling protocol used here included determination of the binding pose, as well
as the confirmation of its stability by the means of molecular dynamics (MD), and finally assessing
the interaction energies by scoring functions. Molecular dynamics simulations allow for studying
dynamic behavior of molecules over time in atomic detail. This pertains also to biomolecules and their
complexes. Thus MD can be likened to a ‘computational microscope’ enabling to reliably peek at key
biochemical processes such as protein folding, membrane transport or the conformational changes
critical to protein function [35,36]. MD can be also used for assisting protein structure elucidation [37] or
deciphering atomic details of drug–receptor interactions and binding pose prediction [38]. On the other
hand, scoring functions are widely used for assessing the interaction energies in a high-throughput
manner. Thanks to simplifications used for their construction, they are very fast, yet not very accurate.
Nevertheless, even a moderately accurate ranking of potential drugs of abuse would have immense
significance for regulatory purposes [39], and this is why scoring functions were checked for their
ability to reproduce our experimental data.
Our aims determine the structure of the contribution, and so we first describe the results of the
binding assays for 21 compounds (Figure 1), including two novel derivatives. Then the modeling of the
fentanyl derivatives with the µOR is reported. We discuss binding modes and receptor characteristics
as found in molecular dynamics simulations, focusing on how they could explain the affinity trends.
Last, we recount our attempt to reproduce the binding data with popular scoring functions.

Molecules 2019, 24, 740
4 of 30
Figure 1. Structures of 21 fentanyl derivatives under the study and a logical disassembly of the parent
fentanyl into structural elements subject to variation in the set.
2. Results and Discussion
2.1. Receptor Binding Determination
The studied set of 21 fentanyl derivatives (Figure 1) was tested for affinity towards the µOR in a
competitive radioligand displacement assay. In order to ascertain the results’ uniformity, the assay
was performed in one laboratory, with one protocol, using homogenate, reagents and materials of
one batch, by a constant group of personnel, and in a few consecutive workdays. The results are
presented in Table 1 as IC50. The obtained values span from 0.19 nM for carfentanil (F15) to 977.2 nM

Molecules 2019, 24, 740
5 of 30
for 3”,4”-dimethoxyfentanyl (F07). For one derivative (3”,4”-dimethoxy-para-trifluoromethylfentanyl,
F08), the IC50 value could not be established as the compound did not exhibit any detectable
radioligand displacement at 1000 nM. The obtained results allow to reassess and mostly reconfirm the
known structure–activity trends for the fentanyl family. We shall now discuss them with respect to
several lines of structural variation seen in the derivatives under the study.
Table 1. IC50 values from competitive radioligand displacement assay for the derivatives under
the study.
1
Cmpd No
Name
fentanyl and acyclic derivative
fentanyl
IC50
SD 2
F01
F02
1.23
0.14
3.51
N-[3-(Methyl-phenethylamino)propyl]-N-phenyl propionamide
shorter N-chain
60.25
F03
F04
benzylfentanyl
489.7
245.5
28.6
12.9
thienylfentanyl
substitution at the N-chain
α-methylfentanyl
F05 3
F06 3
0.32
2.81
0.01
0.13
β-hydroxyfentanyl
substitution at the ring of the N-phenethyl
3”,4”-dimethoxyfentanyl
3”,4”-dimethoxy-para-trifluoromethylfentanyl
variations at the propionamide chain
cyclopropylfentanyl
ω-hydroxyfentanyl
F07
F08
977.2
43.11
-
>1000.0
F09
F10
0.77
97.7
0.04
5.80
F11 3
ω-1-hydroxyfentanyl
para-substitution
489.0
40.59
F12
F13
para-fluorofentanyl
0.48
95.5
0.03
6.2
para-trifluoromethylfentanyl
ohmefentanyl (β-OH, 3-Me)
ohmefentanyl
F14 3
0.27
0.03
4-substitution
F15
F16
F17
F18
F19
carfentanil
0.19
0.21
0.60
295.1
38.9
0.01
0.01
0.08
1.3
lofentanil
remifentanil
norcarfentanil
alfentanil
2.8
N-thioethyl
F20 3
3-methylothiofentanyl
sufentanil
1.10
0.40
0.10
0.03
F21
1
half maximal inhibitory concentration in nM, average of two independent experiments run in two replicas,
standard deviation, 3 tested as enantiomeric mixture.
2

Molecules 2019, 24, 740
6 of 30
The parent fentanyl (F01) has IC50 = 1.23 nM. According to other results from our laboratory,
this makes fentanyl as good a binder as peptidic biphalin (IC50 = 1.4 nM) [40], but better than morphine
(IC50 = 4.02 nM). The replacement of the rigid piperidine core for acyclic aliphatic topographic
equivalent brings about an almost 50 times larger IC50 value (F02, IC50 = 60.25 nM). Thus, the resulting
N-[3-(methyl-phenethylamino)propyl]-N-phenyl propionamide (F02) seems also to be able to place
properly the pharmacophoric elements in the receptor binding site, however only upon paying a
relatively high entropic penalty which gives a decrease of binding affinity. To the best of our knowledge,
the synthesis of F02 was reported before [41], however no data as to its analgesic activity or opioid
receptor affinity were disclosed. The here presented binding data are in line with pharmacological
characteristics of another acyclic derivative 2,3-seco-fentanyl for which it was found that it is about
40 times weaker an analgesic than fentanyl [42].
Shortening of the N-phenethyl chain is unfavorable for binding. The removal of only one –CH2–
group (N-benzyl derivative, F03) results in a nearly 400-fold drop in affinity (F03: IC50 = 489.7 nM).
An exchange for N-thienmethyl group gives also a significantly worse binding (F04: IC50 = 245.5),
however almost two times better compared to the derivative with the isosteric N-benzyl.
Regarding the substitutions at the N-phenethyl group, the introduction of the
a subnanomolar IC50 F05: IC50 = 0.32 nM), while the -hydroxy group gives a modest decrease of
this value (F06: IC50 = 2.81 nM). If however the -OH substitution is upgraded by a simultaneous
α-methyl yields
(
β
β
introduction of a methyl group at the position 3 of piperidine (F14), a 10-fold improvement of IC50
value is noted.
A dramatic drop is observed upon the 3”,4”-dimethoxy substitution at the N-chains’ phenyl (F07
IC50 = 977.2 nM) and the affinity is not restored with the simultaneous para-CF3 substitution at another
aromatic ring (F08: IC50 > 1000 nM). To the best of our knowledge, F07 and F08 derivatives are reported
for the first time. They seem to highlight adverse influence of polar groups at the N-phenethyl end.
A similar, unfavorable effect, yet not such a spectacular one, is found at the opposite propionamide
:
pole of the fentanyl structure. Here, the introduction of the hydroxy group at either
-1-position (F11) gives IC50 values of 97.7 nM and 489.0 nM, respectively. Contrarily, a modest apolar
expansion with one additional –CH2– in a cyclopropyl group (F09) yields a subnanomolar IC50 value,
and so the cyclopropylfentanyl (F09) binds to OR approximately 1.6 times better than the parent
ω-position (F10) or
ω
µ
fentanyl (F01). This result is also important due to the role cyclopropylfentanyl has in the ‘fentanyl
crisis’. The compound synthesized in 1960s by the group of Janssen never entered the clinic, and was
rather forgotten [43]. However, in recent years it has been associated with numerous cases of overdose
deaths in the USA [44], and also found in seized drug samples in Europe [45]. Binding data for F09
were unknown for many years, but while we were running our experiments, the DEA reported the
compound to be a very strong
µOR binder and agonist with EC50 better than that of fentanyl [44],
which is in line with our results.
As to the phenyl ring of the propionanilide part, isosteric replacement in the para-position for
the fluoro group is highly beneficial for binding, with IC50 value being 0.48 nM for F12, that is almost
2.6 times better than that for fentanyl. On the other hand, bulkier trifluoromethyl substituent in the
para-position (F13) brings about a significant drop of µOR-binding as its IC50 value is 95.5 nM.

Molecules 2019, 24, 740
7 of 30
A very favorable influence on
µOR affinity comes from the 4-carbomethoxy substitution at the
piperidine ring. The resulting carfentanil (F15) is one of the strongest synthetic opioids known and it is
the strongest OR binder in our dataset, with IC50 value of 0.19 nM. Lofentanil (F16), which contains an
µ
additional 3-methyl group in the piperidine core, is of similar affinity (0.208 nM). Remifentanyl (F17),
that is a carfentanil’s derivative with N-phenylethyl exchanged for N-(2-methoxycarbonylethyl) chain,
also has a subnanomolar IC50 of 0.60 nM. Still, some decrease of F17 affinity once again highlights the
superiority of the N-phenethyl chain. Dramatically, its role is seen in the case of norcarfentanil (F18
whose IC50 value equals 295.1 nM. This result can be considered in a twofold aspect. On the one hand,
4-carbomethoxy substituent seems insufficient to provide very strong OR-binding on its own. On the
)
µ
other hand however, anchoring obtained by this group is powerful enough to maintain relatively low
IC50 values, even in the absence of the seemingly crucial pharmacophoric element as N-phenethyl.
Among the 4-methoxymethyl derivatives in our set, sufentanil (F21) is the best µOR binder.
Its IC50 value of 0.40 nM is not much worse than that of carfentanil (F15). The addition of a 3-methyl
group at the piperidine core of sufentanil however yields a drop in the affinity to a similar level
as parent fentanyl (F20: IC50 = 1.1 nM). An even greater decrease is found for alfentanil (F19),
in which 4-methoxymethyl group in piperidine is accompanied by the exchange of N-phenethyl for
N-{1-[2-(4-ethyl-5-oxo-4,5-dihydro-1H-1,2,3,4-tetrazol-1-yl)ethyl]. In our study, we found alfentanil’s
IC50 to be 38.9 nM. It seems that this value is worse compared to fentanyl than what one could expect
based on the previous results in the literature [46].
2.2. Modeling of Fentanyl Derivatives Bound to the µ-Opioid Receptor
In order to provide the structural basis behind the observed structure–affinity relationships,
we have modeled the complexes of F01–F21 (including the stereoisomers, where applicable) with µOR.
Then the complexes were subject to short molecular dynamics simulations (three replicas of 50–80
ns length) so to determine stability of the obtained binding poses and to look for similarities and
dissimilarities in the dynamic behavior of the complexes.
2.2.1. Binding Modes
Previously we have proposed the binding mode for the parent fentanyl (F01) [47]. There is a
widely held assumption that similar ligands ought to bind in a similar manner. Following it, we found
the initial binding mode guess for compounds F02–F21 by superimposing their structures over the
fentanyl’s structure as found in the final snapshots of our simulations presented in the antecedent
paper [47]. Such complexes were subject to minimizations so to remove strain possibly introduced by
this specific manual docking procedure and ascertain even apportionment of water molecules in the
binding site. Then the complexes were passed to regular molecular dynamics.
In the case of majority of the studied derivatives, the ligand did not deviate much from the starting
pose during the simulations. The exceptions were three compounds with 3R,4S-stereochemistry at the
piperidine ring, for which a major rearrangement occurred: F14RRS, F14SRS, F20RS (however this
remark does not apply to another 3R,4S-derivative: F16). For most of the compounds we arrived at a
binding mode similar to the binding mode of the parent fentanyl. The general features (GF, Figure 2)
of this binding mode are:
•
•
•
•
GF1. ionic interaction between D147 and the protonable amine of the ligands’ piperidine,
GF2. orientation of the N-chain towards the interior of the receptor,
GF3. positioning of the other ligands’ pole towards the receptor outlet,
GF4. locating the aromatic ring of the anilide in the subpocket formed by transmembrane helices
(TM) TM3, TM4 and extracellular loops (ECL): ECL1 and ECL2,
•
GF5. 4-axial substituent (if present) directed towards W318.

Molecules 2019, 24, 740
8 of 30
Figure 2. Fentanyl (in yellow) in the binding pocket of µ-opioid receptor (µOR, in light ‘Tiffany’
blue). The receptor is presented in a simplified and schematic manner with only several residues
shown (labelled with black) and transmembrane helices (TM, labelled with light green) depicted as
cylinders. Marked are the general features (GF, red arrows) of the binding mode common to the studied
derivatives (see text for explanations).
The first feature (GF1) is obviously expected for all good binders of µOR or more generally of any
aminergic GPCR. In the past, site-directed mutagenesis experiments have shown the key importance
of NH+···D147 interaction for affinity of several
µOR agonists [48,49]. Such direct evidence is not
known for the fentanyl family, however most ‘carba’-derivatives synthesized so far were rather poor
µOR binders [50
,51]. In simulations of the majority of the studied compounds this interaction is
present (except for the suspected outliers F14RRS
,
F14SRS F20RS). It is also very stable throughout
,
the trajectories and in the last 10 ns it is populated for more than 99% of time for most derivatives
(Figures SM-DIS-1 and SM-DIS-2 in Supplementary Materials). In a few instances, the breaking of the
interaction occurs for some fraction of considered frames, however neither a pattern nor a relationship
with the (diminished) experimental binding affinity can be recognized. Only for F03 and F13, for which
the interaction is absent in 67% and 41% of times, respectively, it can be said that this fits the diminished
IC50 values for these derivatives. Apart from this key ionic interaction (GF1), the core piperidine of
fentanyls interacts also with receptor residues: Y148, W318, Q124, I322 and I144 (Figure 3).

Molecules 2019, 24, 740
9 of 30
Figure 3. Interactions of the core piperidine with the receptor residues. Red bars represent the mean
frequency of contacts with a particular residue, and blue bars show standard error of the mean. Data
are collected from last 10 ns of production in 3 replicas. In x-axis label given is the residue’s name and
number as well as type of the contact (Hb—hydrogen bond, Hy—hydrophobic, A—aromatic).
As to the second general feature (GF2) that is the positioning of the N-phenethyl (or another
N-chain in the cases of several derivatives) towards the receptor interior, we are not aware of any
direct experimental hint in its favor. If however one supposes that fentanyl’s N-phenethyl and this
moiety in N-phenethylmorphine are counterparts, and at the same time N-phenethylmorphine takes
the binding mode similar to that found for β-funaltrexamine in crystallographic structure 4DKL [52],
then such positioning is very likely.
In our simulations, the N-chain forms several hydrophobic contacts with the residues at the
binding site’s bottom: I296, I322, W293 and Y326 (Figure 4). The interaction with I296 is sampled for
over 75% of the analyzed simulation time in almost all derivatives with the N-substituent, the exception
being F17. I322 is also nearly always present as interaction partner for all derivatives but F19
.
This compound has on the other hand a 100% sampling of the contact with W293. It is also F07
and F08 that interact with W293 with 100% frequency. Among other derivatives, sampling of this
interaction varies. It is significantly below 25% for derivatives with shorter N-substituents (F03 or F04),
and also for those bearing the N-thioethyl chain (F20RS, F20SR and F21). As to the Y326, majority of
the studied compounds form the hydrophobic interaction with this residue approximately for more
than 75% of the analyzed frames. A notable exception is F19.

Molecules 2019, 24, 740
10 of 30
Figure 4. Interactions of the N-substituent with the receptor residues. Red bars represent the mean
frequency of contacts with a particular residue, and blue bars show standard error of the mean. Data are
collected from last 10 ns of production in 3 replicas. In x-axis label given is the residue’s name and
number as well as type of the contact (Hb—hydrogen bond, Hy—hydrophobic, A—aromatic).
Another ‘pole’ of the molecule—the propanamide chain is located up the binding pocket, towards
the receptor outlet (GF3). Predominantly it forms hydrophobic interactions with I144 and L219
(Figure 5). For L232 and T218, the interaction frequencies vary with the derivative. The compounds
which contain a hydroxy-function at this chain (F10, F11R and F11S) can also form hydrogen bonds
with L219 (backbone), S55 (hydroxyl) and T218 (hydroxyl). Notably however, F11R and F11S do not
hold H-bonds for more than 25% of the considered simulation time, while for F10 hydrogen bond
to L219 is present in slightly more than 50% of analyzed frames and, and to T218 in no more than
25% frames.
In our simulations, the aromatic ring of the propionanilide is located in a shallow ‘subpocket’
formed by TM3, TM4, ECL1 and ECL2 (GF4). This is a localization very close to the one occupied by
the phenyl of DAMGO’s N-Me-Phe4 residue, as seen in recently published experimental structures of
µOR (PDB accession codes: 6DDE and 6DDF; Figure 6 [53]). This ‘subpocket’ is confined by sidechains
of C217, I144, V143 and W133 as well as by D147. It is these residues that interact with the anilide’s
aromatic ring (Figure 7). Particularly frequent are contacts with C217, I144 and V143, while the
interaction with W133 is sampled less often.

Molecules 2019, 24, 740
11 of 30
Figure 5. Interactions of the propanamide chain with the receptor residues. Red bars represent the
mean frequency of contacts with a particular residue, and blue bars show standard error of the mean.
Data are collected from last 10 ns of production in 3 replicas. In x-axis label given is the residue’s name
and number as well as type of the contact (Hb—hydrogen bond, Hy—hydrophobic, A—aromatic).
Figure 6. Imposition of fentanyl (red, our simulations) and DAMGO (yellow, PDB structure: 6DDF [53])
in
residue of DAMGO.
µ
OR (blue), with focus on similar positioning of fentanyl anilide’s phenyl and phenyl of N-Me-Phe4

Molecules 2019, 24, 740
12 of 30
Figure 7. Interactions of the anilide’s aromatic ring with the receptor residues. Red bars represent the
mean frequency of contacts with a particular residue, and blue bars show standard error of the mean.
Data are collected from last 10 ns of production in 3 replicas. In x-axis label given is the residue’s name
and number as well as type of the contact (Hb—hydrogen bond, Hy—hydrophobic, A—aromatic).
The last general feature of the binding modes (GF5) is shared by those derivatives that have
a 4-axial substituent (F15–F19, F21). The substituent is directed towards W318 and forms frequent
interactions with this residue (Figure 8). Other frequent partners for this part of the studied molecules
include residues: I322 and S55. Furthermore, in the case of F21 and F18, it is also I296 that interacts
with the 4-axial substituent, and for F18, we observe also some contacts with V300.
Figure 8. Interactions of the 4-axial substituent with the receptor residues. Red bars represent the
mean frequency of contacts with a particular residue, and blue bars show standard error of the mean.
Data are collected from last 10 ns of production in 3 replicas. In x-axis label given is the residue’s name
and number as well as type of the contact (Hb—hydrogen bond, Hy—hydrophobic, A—aromatic).
As to the outliers mentioned at the beginning of this section (F14RRS
that their positioning found in the simulations does not represent a true binding mode. It is a common
opinion that all potent binders of OR should have an ionic interaction between piperidine’s nitrogen
, F14SRS, F20RS), we assume
µ

Molecules 2019, 24, 740
13 of 30
and D147. In our simulations of
µ
OR with F14RRS
,
F14SRS
,
F20RS, this interaction was disrupted
and the piperidine was oriented upside down with the piperidine’s NH+ completely inaccessible for
interactions with D147. While not necessarily false from the fundamental point of view, such a situation
is highly unlikely in the light of the knowledge gathered on
when we recall that F14RRS and F14SRS belong to the most potent fentanyl’s derivatives and most
potent OR binders at all [54 55]. With these objections, we rather do not comment on the results of
µOR/GPCR pharmacology. In particular,
µ
,
these outlying simulations, nevertheless keeping them in the Figures for the sake of comprehensiveness.
2.2.2. Binding Modes Compared to SAR Data
The presented binding mode is in our opinion able to rationally explain many of the trends
observed in fentanyl’s SAR data, including the ones provided in the present contribution and those
reported previously. Particularly interesting comments can be made about the N-substituent and
anilide’s aromatic.
With regard to the N-substituent, our experimental data show decrease of binding with shortening
of the N-chain (F01
> F04 and F03; F15 >> F18). Consistently, the simulations show less apolar
interactions of the N-chain in the case of shorter derivatives. On the other hand, a significant increase
of the N-chain volume is rather unfavorable for binding. For instance, upon the introduction of
3”,4”-dimethoxy modification to the ring (F07 and F08), the IC50 value drops dramatically. According
to simulations, the methoxy substituents do not participate in hydrogen bonds, however, their presence
increases the packing and the number of hydrophobic contacts (Figure 4).
This increase in intermolecular interactions between the N-chain and the receptor can be reconciled
with the experimental lowering of affinity, by recalling a so-called ‘55%-rule’, formulated in the
field of supramolecular chemistry [56]. The rule states that the optimal situation for apolar binding
occurs when 55% of the available host space is occupied by the guest. This reasoning has been
successfully applied also for several cases of biological molecular recognition [57
,58]. For our purposes,
we resign from calculating of what precisely the optimal 55% of packing in OR subsites is. This is
µ
because these ‘subsites’ are not well-confined, besides due to dynamic behavior of the ligand and
binding site side chains, appropriate calculation must not be straightforward. The rule can be
however translated into a qualitative description that both under- and overpacking is not favorable for
binding (underpacking due to suboptimal number of interactions and overpacking due to entropically
unfavorable rigidification of binding partners). This is what seems in fact present in our data. If we
plot the pIC50 values against the N-chain volume (calculated as average over last 10 ns of simulations
in three replicas, in order to take into account the flexibility of the chain, see Methods for explanations),
the data can be approximately modeled by two linear curves, ascending and descending, suggesting
that up to a certain optimum of substituent’s volume, the pIC50 improves, and beyond it declines
(Figures SM-VOL-1 and SM-VOL-2). For 4-axially substituted derivatives, one can fit a quadratic curve,
with perfect coefficient of correlation R = 0.99 (Figure SM-VOL-3).
As to anilide’s aromatic, majority of the compounds in the present contribution contain a simple
undecorated phenyl ring. However, F12 as well as F13 and F08 have para-substituents (pF or pCF3).
Experimental data order this small ‘subseries’ the following way: F12 (pF) > F01 (H) > F13 (pCF3) >>
F08 (pCF3, and 3”,4”-diMeO). As described in Section 2.2.1, the aromatic ring is predicted to locate in
an apolar subsite according to our simulations. The ring forms several hydrophobic contacts, and their
frequency increases with pF substitution, but increases even further with the bulkier pCF3 substituent.
This group is however so large that it provides full, unfavorable, packing of the subsite. In the case
of F13, this overpacking can be partially relieved by a slight exsertion of the aromatic out of the
subsite, accompanied however by the simultaneous loosening and breaking of the key ionic contact
NH+···D147 (Figure 3; Figures SM-DIS-1 and SM-DIS-2). This is impossible in the case of F08, which
apart from pCF3 substitution contains a voluminous modification (3”,4”-diMeO) at the phenyl of
the N-phenethyl. The provided reasoning fits well with other experimental data on para-substituted
fentanyl derivatives [59].

Molecules 2019, 24, 740
14 of 30
It seems that the volume/affinity relationships considered separately from the perspective of
N-substituent and anilide’s aromatic, can be effectively joined together. Summing volumes of both
these pharmacophoric elements into one variable and plotting it with the affinity data, gives a clear
relationship between these two values, further supporting our qualitative reasoning provided above
(Figure 9). Again the data can be modeled for 4-axially unsubstituted derivatives by two linear curves,
ascending and descending, while for those bearing a 4-axial substituent, there is a quadratic curve
that can be fitted with a perfect R = 0.99. Thus, in approximation, expanding the molecule volume by
expanding either the N-substituent or anilide’s aromatic, or both, is favorable to a certain point.
Figure 9. Plot of pIC50 against sum of dynamic volumes of N-substituent and anilide’s aromatic:
(A) without 4-axially substituted derivatives, (B) for 4-axially substituted derivatives. Volume data are
collected from last 10 ns of production in 3 replicas. Chiral compounds excluded. pIC50 value for F08
(a point in brackets) arbitrary (experimental pIC50 < 6.0).
Another important trend observed in fentanyl’s structure–activity relationships is that many
4-axial substitutions are not only tolerated but also highly beneficial for binding. According to our
simulations, 4-axial position of piperidine can have relatively large (long) substituents, as there is
plenty of space for their accommodation (F15
–F19, F21). The literature knows of fentanyl derivatives
exhibiting strong OR binding, with 4-axial substituents such as carbomethoxy (carfentanil F15),
µ
methoxymethyl (sufentanil F21), phenyl, pirymidynyl [60] and even larger ones are associated with
not so pronounced decreases of affinity. The simulations do not seem however to point to any particular
preference with respect to which substituent would be optimal.
As to the
ω-modifications, ω-hydroxy (F10) and ω-1-hydroxy (F11R and F11S) groups are
unfavorable to binding, since they do not form stable hydrogen bonds. On the other hand in the
receptor there are some partners available for hydrogen bonding in these environs. Thus it is not
surprising that some other derivatives with functions able to participate in H-bonding in this part
of the fentanyl structure are not so bad binders. Such cases include derivatives where –C2H5 of the
propanamide were replaced with –CH2OCH3 or furoyl [61,62]. Another ω-modification in our dataset,
that is addition of –CH2– and cyclisation to yield a cyclopropyl substituent (F09), is favorable to
binding by the virtue of increasing frequency of lipophilic contacts (Figure 5).
Here, we shall restrain from discussing the important issue of structural basis of stereochemical
preferences in ohmefentanyl (or other 3-substituted derivatives) isomers. As stated in Section 2.2.1,
we assume that we have not identified the binding modes of F14RRS and F14SRS.
2.2.3. Receptor Characteristics from MD Simulations
As a next step in our analysis, we wanted to see whether the presence of particular derivatives is
associated with some changes in receptor characteristics. We compare:
1.
2.
3.
the RMSF of protein helices,
side chain dihedral angles of key residues,
the length of the so-called ‘3-7 lock’ and

Molecules 2019, 24, 740
15 of 30
4.
the hydration of D114 and Y336.
All analyses are done on data from the last 10 ns of three simulations for each derivative.
RMSF of Protein Helices
The RMSF (root mean square fluctuation) of protein backbone or RMSF of the backbone of separate
helices expresses numerically to what extent a given protein part deviates (fluctuates) over time. It thus
gives some measure of system flexibility which is connected to receptor action. For example, Chan et al
analysis of protein (or protein’s helices) RMSFs derived from simulations of β2-adrenergic receptor
with agonists, inverse agonists and antagonists, found statistically significant differences between the
values obtained for these groups [63].
.
In simulations for our derivatives, the RMSF values of the protein backbone (Table SM-RMS-1,
Figure SM-RMS-1) are on average 0.93 Å with a standard deviation of 0.05 Å. It means that the
protein backbone RMSF does not provide a strong differentiation within the fentanyl family, as for
the majority of cases the difference between the means for single derivatives is smaller than the
intra-derivative differences. Indeed, both Kruskall–Wallis test and less conservative one-way ANOVA
find that medians/means do not differ significantly at
α = 0.05. The same applies to RMSFs of each
single TM helix (Tables SM-RMS-2 to SM-RMS-8, Figures SM-RMS-2 to SM-RMS-8). We were also not
able to find any structure- or affinity-based trend for these values (Table SM-RMS-9). Perhaps the only
clear regularity is that in as much as five out of eight cases (H1, H2, H5, H6 and protein RMSFs) the
highest mean RMSF is found for the F08 which is the weakest binder and at the same time the most
voluminous derivative in our set.
Side Chain Dihedral Angles of Key Residues
Regarding the side chain dihedral angles of key residues we have considered the amino acids:
1.
2.
3.
4.
5.
interacting with the fentanyl piperidine (or close to it: D147, Y148),
close to 4-axial substituent (W318, H319),
close to the N-substituent (M151, W293, H297, Y326),
close to anilide’s aromatic (Y133) or even
outside the binding pocket (Y336).
The distributions as well as time evolutions for these dihedrals are given in Supplementary
Materials (Figures SM-DIH-1 to SM-DIH-40). Short descriptions are given in Table SM-DIH-1. For most
of the analyzed dihedrals the values are stable during the analyzed periods and belong to a single
cluster (Y148 X1, W318 X1, W318 X2, H319 X1, W293 X1, W293 X2, H297 X1, H297 X2, Y326 X1, W133
X1, W133 X2, Y336 X1). For a few, another minor cluster appears (D147 X1, H319 X2, M151 X1, Y326 X1,
Y336 X2) or more clusters are present (D147 X2, Y148 X2, M151 X1). The analyzed dihedrals do not
seem to differentiate the derivatives except for W318 X2, W293 X2 and W133 X2. Regarding the first of
º
º
93.2 (F11R). The order
these, W318 X2, the mean value can be as different as
−
116.0 (F06R) and
−
however does not seem to be straightforwardly related to structure of the derivatives. On the contrary,
the remaining two dihedrals (W293 X2 and W133 X2) are clearly related to derivatives’ volume.
º
º
111.7 (F03). There is a
In the case of W293 X2, the values vary between
−
92.0 (F19) and
−
correlation between the dihedral measure and the sum of dynamic volumes of the N-substituent and
the anilide’s aromatic (correlation coefficient R = 0.75, n = 28, Figure SM-VOL-4; upon exclusion of
4-axially substituted derivatives R = 0.89, n = 18, Figure 10A). The correlation states that the larger
is the ligand the less negative is the value of the dihedral. Speaking structurally, it means that larger
derivatives “push” the tryptophan ring to a conformation more perpendicular to TM6 axis, while for
smaller derivatives the ring is slightly kinked into the binding cavity (Figure 11). The relationship
between fentanyl core substituents and the W293 X2 dihedral value seems most interesting as the
W293 is commonly known to be involved in the receptor activation processes. GPCRs activation

Molecules 2019, 24, 740
16 of 30
includes a series of structural rearrangements of the hydrophobic residues in the core of the receptor
that lead to major rearrangements of the helices enabling the binding of the intracellular partners,
including G-proteins or
orthosteric binding site and the hydrophobic receptor core. In the past, it had been postulated that
the residue functions as a rotameric micro-switch [64 65], and for many GPCRs mutating this residue
(X6.48, where mostly X = W or F) affects signaling [66 68]. Interestingly, for a closely-related -opioid
receptor, it has been found that a W6.48L mutation almost abolishes agonist-dependent -arrestin
β-arrestins. W293 is a residue that transmits communication between the µOR
,
–
δ
β
recruitment, while having only a moderate impact on G-protein signaling [69]. It is then tempting to
hypothesize based on the relationship we observe here and on the knowledge on the importance of
W293 for signaling that manipulating the size of the core substituents (at least in the fentanyl family)
may provide means to rationally influence the signaling efficacies.
Figure 10. Correlation of volumes with receptor characteristics: A) mean W293 X2 dihedral measures
against the sum of dynamic volumes of N-substituent and anilide’s aromatic. R = 0.89, n = 18. Excluded
are 4-axially substituted derivatives as well as F14 stereoisomers,
B) mean distance between OH Y326
and C of D147 against the sum of dynamic volumes of N-substituent and anilide’s aromatic. R = 0.70,
γ
n = 24. Excluded are F14RRS, F14SRS and F20RS (suspected binding mode outliers).
Figure 11. Average dihedral W293 X2 for simulations with F08 (red ligand, blue W293) and
benzylfentanyl (F03, green ligand, yellow W293) shown with the respective ligands and a simplified
representation of µOR binding site.
In the case of W133 X2, the spread of mean values is less pronounced and they vary between
º
º
–95.2 (F18) and 104.3 (F08). Here again, we observe a correlation between the sum of substituents’
volumes and the dihedral value (R = 0.70, n = 28, Figure SM-VOL-5; upon exclusion of 4-axially
substituted derivatives, R = 0.74, n = 18, Figure SM-VOL-6). For this dihedral, the relationship is

Molecules 2019, 24, 740
17 of 30
inverse compared to the one just discussed above and the larger is the ligand the more negative is the
dihedral value.
Length of the so-Called ‘3-7 lock’
Another receptor characteristic that had been considered important from the point of view
of opioid receptor activation is the hydrogen bond between D147 and Y326, the so-called ‘3-7
lock’ [64,65,70]. As the hydrogen bosnd is present in both inactive [52] and active [53
structures of OR, the experimental data does not allow a simple reception of older hypotheses inferred
by comparison with rhodopsin and from modeling that the breaking of this ‘lock’ participates (or even
initiates) the OR activation [65]. Furthermore, in our previous work [47] we observed the breaking of
the lock in simulations with both the activated as well as inactive structure of the empty (unliganded)
receptor. Still, we consider the distance between OH Y326 and C of D147 an informative descriptor
,71] experimental
µ
µ
γ
of the binding site. The mean values for this characteristic differ in the range 5.14 to 6.13 Å, meaning
that there is no hydrogen bond between the two residues. Notably again, we observe a relationship
between the summed substituents volume and the value of this characteristic (R = 0.70, n = 24). Thus,
in first approximation, the bulkier the substituents at the piperidine core, the larger the distance
between OH Y326 and Cγ of D147 (Figure 10B).
Hydration of D114 and Y336
The last element of our analysis of receptor dynamic characteristics is the hydration of two
key residues connected to activation (D114) and intracellular interactions (Y336). The MD-derived
hydration of these residues (or of their counterparts in other GPCRs) have been reported to be
associated with receptor function and ligands’ activity [63,72–74]. We have monitored the hydration
by counting the number of water molecules within 5.0 Å from any of the atom of a given residue.
The distributions and time evolutions of these values are given in Figures SM-WAT-1 to SM-WAT-4,
and the mean values in Tables SM-WAT-1 and SM-WAT-2. It seems that the hydration of these residues
is not much influenced by the presence of particular derivative (no significant difference between the
means in one-way ANOVA at α = 0.05).
2.3. Scoring
Having gathered a uniform experimental data on binding of the derivatives to µOR, we were
curious if they can be reproduced computationally by 14 scoring functions used for molecular docking.
Scoring is a simplified way of estimating the strength of interaction between ligands and proteins.
It is widely used in docking since it is very fast but due to simplifications in most cases, it is also very
inaccurate [75]. Most scoring functions can be relatively successful for screening purposes to choose
probable binders out of a variety of chemotypes. Unfortunately, frequently they cannot properly order
closely related compounds as to their binding affinity against a particular target [76].
The same holds true for our dataset. None of the tested scoring functions were able to rank
the derivatives so that the correlation coefficient between the experimental and predicted data
was R > 0.30 (n = 28, Figure SM-SCO-1). Upon exclusion of chiral compounds (for which it is
not straightforward to select proper experimental values as we have performed binding assays
for enantiomeric mixtures), the correlation between experiment and prediction did not improve
much (Figure SM-SCO-2). Particularly striking was the fact the most of the scorings estimated
the poorest binder F08 (IC50 > 1000 nM) as a very strong one, even as the best in the whole set.
With excluding yet this derivative as well as F07 and F18 (which were frequent outliers in correlations
experiment/prediction), we were able to arrive at R = 0.64 (n = 13, Figure 12) for correlation between
PLP1 scoring and the experiment.
Interestingly, considering components constituting the scoring functions, we found that the
LUDI3_LIPSCO element which describes the contribution to binding coming from lipophilic
interactions, is by far the best estimator of the binding in this limited subset (R = 0.78, n = 13, Figure 12).

Molecules 2019, 24, 740
18 of 30
Therefore we decided to reweight the components of LUDI3 scoring function equation so that it
better fit the experimental data. An expression for reweighted function (LUDI3_reweighted) is given
in Supplementary Information (Figure SM-SCO-3). The coefficient optimization obviously brought
improvement in internal validation (R = 0.84, Figure SM-SCO-4), however the reweighted function
(LUDI3_reweighted) failed in even very modest external validation tests. For example, we wanted to see
if it would at least correctly classify several very strong µOR binders (morphine, biphalin, gu-biphalin,
PZM21, endomorphine-1, endomorphine-2; IC50 obtained in our laboratory in 0.8–10 nM range) as of
similar affinity to that of fentanyl, however, LUDI3_reweighted was not able to do so.
Figure 12. Plots of binding estimation by scoring functions (arbitrary units) against the experimental
pIC50. The above plots include only the limited subset (without chiral compounds, F07, F08 and F18)
See Methods Section for scoring functions labels.
Importantly to note, while we were working on this paper, an interesting paper appeared whose
authors set themselves aims similar to ours. They wanted to see whether a scoring function could
accurately reproduce experimental binding data [39]. This attempt included 23 opioids among which
there were eight fentanyl derivatives, eight morphine derivatives and seven other µOR ligands of
rather further structural similarity to fentanyl (‘fentanyl congeners’ as per authors’ term). By the
means of Molecular Operating Environment suite (GBVI/WSA scoring function) [77], they docked and
scored their set and compared it to the experimental data. The fentanyl-binding pose that they found
is different than the one we report here. While the N-phenethyl chain is also directed towards the
receptor interior as in our work, it interacts with H297 (aromatic stacking) and in our model the chain is
closer to Y326. Further, contrarily to the results of ours, the authors found a strong correlation between
the score and experimental binding constants for fentanyl derivatives and ‘congeners’. With their
approach, it was possible to separate fentanyl derivatives into three strength classes (strong, moderate,
weak binders) based on the scoring result. On the other hand, the method gave rather poor correlation
for the group of morphine derivatives. Nevertheless, the workflow described in that paper holds
some promise of practical utility for assisting in preliminary characterization of newly identified
designer drugs.

Molecules 2019, 24, 740
19 of 30
3. Materials and Methods
3.1. Fentanyl Derivatives
Compounds F01
,
F03
–
F06
,
F10
–
F12 and F14
–
F21 were purchased from Toronto Research
Chemicals, North York, ON, Canada and used without further processing. Compounds F02
F09 F13 were synthesized at our facilities as presented in Figure 13. Among them, F07 and F08 have
never been reported before, as per our knowledge. Synthetic details for derivatives F02 F09 and F13
, F07, F08,
,
,
are given in Supplementary Materials. Some of the steps reported therein include previously described
procedures or data [41,43,59,78,79].
A)
O
NH2
toluene,
CH3COOH cat.
N
NaBH4,
MeOH
N
+
N
R
R1
F22
R1 = H or CF3
F23 R1 = H
F24 R1 = CF3
O
R2
H
N
N
O
toluene
Et3N
R2
+
N
N
Cl
R1
R1
F09 R1 = H, R2 = cyclopropyl
F13 R1 = CF3, R2 = C2H5
F25 R1 = H
F26 R1 = CF3
R2= cyclopropyl or C2H5
B)
CH3CN,
80 oC
CH2Cl2,
Et3N
NH2
Br
HN
Br
Cl
+
+
rt
O
Br
F27
NH
CH3CN,
60 oC
O
N
N
O
N
Br
+
F28
F02
O
C)
dioxane
7% HClaq
K2CO3,
acetone
O
O
O
N
O
Br
O
N
+
reflux
90 oC
O
O
N
F29
H
F30
F31
NH2
O
NaBH4,
MeOH
toluen,
CH3COOH cat.
O
N
+
O
N
O
O
F33 R1 = H
F32
R1
R1 = H or CF3
F34 R1 = CF3
H
O
N
CH2Cl2,
Et3N
N
O
Cl
O
O
N
R1
+
O
O
N
R1
F07 R1 = H
F35 R1 = H
F08 R1 = CF3
F36 R1 = CF3
Figure 13. Syntheses of fentanyl derivatives A) F09 and F13, B) F02 C) F07 and F08.

Molecules 2019, 24, 740
20 of 30
3.2. Chemistry
All reagents were purchased from commercial suppliers and used without further purification.
The NMR spectra were recorded on a Bruker Avance spectrometer (Bruker, Karlsruhe, Germany)
operating at 300 MHz for 1H-NMR and 75 MHz for 13C-NMR. The spectra were measured in CDCl3
and are given as δ values (in ppm) relative to TMS. Mass spectra were collected on LCT Micromass
TOF HiRes apparatuses (Micromass UK Limited, Manchester, UK). Melting points were determined
on a Melting Point Meter KSP1D (A. Krüss Optronic, Hamburg, Germany) and were uncorrected.
TLC analyses were performed on silica gel plates (Merck Kiesegel GF254, Merck, Darmstadt, Germany)
and visualized using UV light or iodine vapor. Column chromatography was carried out at atmospheric
pressure using Silica Gel 60 (230–400 mesh, Merck, Darmstadt, Germany) using appropriate eluents.
3.3. Synthesis
3.3.1. 8-[2-(3,4-Dimethoxyphenyl)ethyl]-1,4-dioxa-8-azaspiro[4.5]decane (F31)
The suspension of 1,4-dioxa-8-azaspiro[4.5]decane F30 (0.219 g, 1.53 mmol, 1 equiv) and potassium
carbonate (1.06 g, 7.65 mmol, 5 equiv) in acetone (15 mL) was stirred at 23–24 ◦C for 1 h. After this
time 3,4-dimethoxyphenethyl bromide F29 (0.40 g, 1.84 mmol, 1.2 equiv) was added and the resulting
suspension was stirred at reflux for 4 h. The solvent was evaporated in vacuum and to residue CH2Cl2
(20 mL) and water (15 mL) were added. After phase separation the water phase was additionally
extracted with CH2Cl2 (2
×
20 mL). The organic extract was dried over MgSO4, filtered and the solvent
was removed in vacuo. The product was isolated by column chromatography on silica gel (CHCl3) as
white solid (0.32 g, 68%). mp = 92–93 ◦C.
1H-NMR (300 MHz, CDCl3)
δ 6.77 (m, 3H), 3.96 (bs, 4 H), 3.87 (s, 3H), 3.85 (s, 3H), 2.75 (m, 2H),
2.61 (m, 4H), 1.78 (t, J = 5.7 Hz, 2H). 13C-NMR (75 MHz, CDCl3)
δ 148.8, 147.3, 133.1, 120.5, 112.0, 111.3,
107.2, 64.2, 60.3, 55.9, 55.8, 51.3, 34.9, 33.6. LR-MS (ESI): 308.3 (M + H)+.
3.3.2. 1-(3,4-Dimethoxyphenethyl)-piperidin-4-one (F32)
◦
To a stirred at 23–24 C solution of F31 (0.230 g, 0.748 mmol, 1 equiv) in dioxane (1.5 mL) distilled
water (6 mL) and concentrated hydrochloric acid (1.5 mL) were added and the resulting solution was
heated at 90 ◦C for 4.5 h. After cooling to reaction mixture water (8 mL) was added, alkalized with
solid potassium carbonate and extracted with chloroform (3
over MgSO4, filtered and the solvent was removed in vacuo. The product was isolated by column
×
20 mL). The organic extract was dried
◦
chromatography on silica gel (CHCl3) as colorless solid (0.18 g, 91%). mp = 80–81 C (lit. mp =
76–78.5 ◦C [80]).
1H-NMR (300 MHz, CDCl3)
δ
6.73 (m, 3H), 3.87 (s, 3H), 3.85 (s, 3H), 2.79 (m, 6H), 2.70 (m, 2H),
2.47 (t, J = 6.0 Hz, 2H). 13C-NMR (75 MHz, CDCl3)
208.9, 148.9, 147.4, 132. 6, 120.5, 112.0, 111.3, 59.4,
55.9, 55.8, 53.1, 41.2, 33.7. LR-MS (ESI): 264.3 (M + H)+.
δ
3.3.3. N-(1-Phenethyl-4-piperidinyl)-(3,4-dimethoxyphenyl)amine (F35)
F35 was prepared as reported in Ref. [78]. A solution of 1-(3,4-dimethoxyphenethyl)-piperidin-4-one
F32 (0.270 g, 1.02 mmol, 1 equiv), aniline (0.094 mL, 1.02 mmol, 1 equiv) and acetic acid (1 drop) in
toluene (12 mL) was heated under reflux with a Dean-Stark apparatus for 24 h. The toluene was
removed in vacuo and the residue was used for the next step without further purification.
The crude imine F33 was dissolved in methanol (10 mL) and NaBH4 (0.078 g, 2.05 mmol, 2 equiv)
was added gradually at 23 ◦C to the stirred solution during 10 min. The obtained solution was stirred
◦
for 1 h at 60 C. After evaporation of the solvent, water (5 mL) was added and the mixture was
extracted with chloroform (3
solvent was removed in vacuo. The product F35 was isolated by column chromatography on silica gel
×
15 mL). The organic extract was dried over MgSO4, filtered and the
(CHCl3:MeOH, 0–1% MeOH) as solidifying oil (0.28 g, 81%).

Molecules 2019, 24, 740
21 of 30
1H-NMR (300 MHz, CDCl3)
δ
7.16 (t, J = 7.8 Hz, 2H), 6.77 (m, 3H), 6.68 (t, J = 7.5 Hz, 1H), 6.60 (d,
J = 7.8 Hz, 2H), 3.87 (s, 3H), 3.85 (s, 3H), 3.48 (bs, 1H), 3.32 (m, 1H), 2.96 (d, J = 11.7 Hz, 2H), 2.76 (m,
2H), 2.59 (m, 2H), 2.20 (t, J = 11.4 Hz, 2H), 2.09 (d, J = 12.6 Hz, 2H), 1.51 (m, 2H). 13C-NMR (75 MHz,
CDCl3)
δ 148.8, 147.3, 147.1, 133.0, 129.3, 120.5, 117.2, 113.2, 112.0, 111.3, 60.8, 55.9, 55.8, 52.5, 49.9, 33.5,
32.6. LR-MS (ESI): 341.4 (M + H)+.
3.3.4. 3”,4”-Dimethoxyfentanyl, N-(1-Phenethyl-4-piperidinyl)-N-(3,4-dimethoxyphenyl)-
propionamide (F07)
◦
To a stirred at 23–24 C solution of F35 (0.144 g, 0.423 mmol, 1 equiv) and triethylamine
(0.065 mL, 0.465 mmol, 1.1 equiv) in dichloromethane (8 mL) solution of propanoic acid chloride
(0.041 mL, 0.465 mmol, 1.1 equiv) in dichloromethane (1 mL) was added and the resulting solution
was additionally stirred for 30 min. After this time, CH2Cl2 (10 mL) and water (4 mL) were
added, the mixture was shaken and the phases were separated. The organic extract was dried
over MgSO4, filtered and the solvent was removed in vacuo. The product F07 was isolated by column
chromatography on silica gel (CHCl3) as white solid (0.130 g, 78%). mp = 78–79 ◦C.
1H-NMR (300 MHz, CDCl3)
δ 7.38 (m, 3H), 7.08 (m, 2H), 6.77 (m, 1H), 6.69 (m, 2H), 4.70 (tt, J =
12.3, 3.9 Hz, 1H), 3.84 (s, 3H), 3.82 (s, 3H), 2.99 (d, J = 11.7 Hz, 2H), 2.67 (m, 2H), 2.52 (m, 2H), 2.16 (t,
J = 11.4 Hz, 2H), 1.93 (q, J = 7.5 Hz, 2H), 1.81 (d, J = 12.0 Hz, 2H), 1.43 (m, 2H), 1.02 (t, J = 7.5 Hz, 2H).
13C-NMR (75 MHz, CDCl3)
δ 173.5, 148.8, 147.3, 138.8, 132.9, 130.43, 129.3, 128.2, 120.4, 112.0, 111.2,
60.5, 55.9, 55.8, 53.1, 52.1, 33.4, 30.5, 29.7, 28.5, 9.6. LR-MS (ESI): 397.5 (M + H)+.
3.3.5. N-(1-Phenethyl-4-piperidinyl)-(4-trifluoromethylphenyl)amine (F36)
F36 was prepared as reported in Ref. [78]. A solution of 1-(3,4-dimethoxyphenethyl)-piperidin-4-one
F32 (0.270 g, 1.02 mmol, 1 equiv), trifluoromethylaniline (0.129 mL, 1.02 mmol, 1 equiv) and acetic acid
(1 drop) in toluene (12 mL) was heated under reflux with a Dean-Stark apparatus for 24 h. The toluene
was removed in vacuo and the residue was used for the next step without further purification.
The crude imine F34 was dissolved in methanol (10 mL) and NaBH4 (0.078 g, 2.05 mmol, 2 equiv)
was added gradually at 23 ◦C to the stirred solution during 10 min. The obtained solution was stirred
◦
for 1 h at 60 C. After evaporation of the solvent, water (5 mL) was added and the mixture was
extracted with chloroform (3
solvent was removed in vacuo. The product F36 was isolated by column chromatography on silica gel
×
15 mL). The organic extract was dried over MgSO4, filtered and the
(CHCl3:MeOH, 0%–2% MeOH) as colorless oil (0.26 g, 62%).
1H-NMR (300 MHz, CDCl3)
δ
7.39 (d, J = 9.0 Hz, 2H), 6.80 (m, 1H), 6.75 (m, 2H), 6.58 (d, J = 9.0
Hz, 2H), 3.87 (s, 3H), 3.86 (s, 3H), 3.35 (m, 1H), 2.97 (d, J = 12.0 Hz, 2H), 2.77 (m, 2H), 2.61 (m, 2H), 2.22
(t, J = 12.0 Hz, 2H), 2.08 (d, J = 12.0 Hz, 2H), 1.53 (m, 2H). 13C-NMR (75 MHz, CDCl3)
149.5, 148.8,
δ
147.4, 132.9, 126.6 (q, J = 3.0 Hz), 123.2, 118.5 (q, J = 33.0 Hz), 112.1, 112.05, 111.3, 60.7, 55.9, 55.8, 52.3,
49.6, 33.5, 32.2. LR-MS (ESI): 409.3 (M + H)+.
3.3.6. 3”,4”-Dimethoxy-para-trifluoromethylfentanyl, N-(1-Phenethyl-4-piperidinyl)-N-
(4-trifluoromethylphenyl)-propionamide (F08)
To a stirred at 60 ◦C solution of F36 (0.120 g, 0.294 mmol, 1 equiv) and triethylamine (0.049 mL,
0.352 mmol, 1.2 equiv) in toluene (6 mL) solution of propanoic acid chloride (0.031 mL, 0.352 mmol,
1.2 equiv) in toluene (1 mL) was added and the resulting solution was additionally stirred for 30 min.
After this time, toluene (8 mL) and water (4 mL) were added, the mixture was shaken and the phases
were separated. The organic extract was dried over MgSO4, filtered and the solvent was removed in
vacuo. The product F08 was isolated by column chromatography on silica gel (CHCl3:Me)H, 0%–2%
MeOH) as white solid (0.104 g, 76%). mp = 102–103 ◦C.
1H-NMR (300 MHz, CDCl3)
δ 7.68 (d, J = 9.0 Hz, 2H), 7.23 (t, J = 9.0 Hz, 2H), 6.76 (m, 1H), 6.69
(m, 2H), 4.72 (t, J = 12.0 Hz, 1H), 3.84 (s, 3H), 3.83 (s, 3H), 3.00 (d, J = 12.0 Hz, 2H), 2.68 (m, 2H), 2.51
(m, 2H), 2.16 (t, J = 12.0, 2.1 Hz, 2H), 1.92 (q, J = 9.0 Hz, 2H), 1.82 (d, J = 12.0 Hz, 2H), 1.38 (m, 2H),

Molecules 2019, 24, 740
22 of 30
1.04 (t, J = 9.0 Hz, 2H). 13C-NMR (75 MHz, CDCl3)
δ
172.9, 148.8, 147.3, 142.3, 132.8, 131.0, 126.5 (q,
J = 3.7 Hz), 125.5, 120.4, 117.4, 112.0, 111.2, 60.5, 55. 9, 55.7, 53.0, 52.3, 33.4, 30.7, 28.7, 9.5. LR-MS (ESI):
465.4 (M + H)+.
3.4. Binding Assays
The binding affinity of compounds F01–F21 for µOR was determined in competitive radioligand
binding assays in rat brain homogenates [40]. The homogenates were prepared as follows. Brain
tissue, obtained from rats euthanized by decapitation (cerebellum removed), was homogenized in
a hand glass homogenizer and suspended in Tris-HCl (pH 7.4). The preparation was centrifuged
(
at 23,000 rpm, 4 ◦C for 15 min) and the supernatant was disposed. The remaining precipitate was
resuspended in Tris-HCl buffer and incubated at 25 ◦C for 30 min, after which the centrifugation and
resuspension were repeated again.
◦
The so-obtained membrane fractions (containing opioid receptors) were incubated at 25 C
for 60 min in the presence of 0.5 nM [3H]DAMGO (a radioligand specific for
µ
OR) bought from
PerkinElmer, USA, and the increasing concentrations of the assayed compounds (3.0
10−10 up to
10−5 M, each concentration in duplicate). The assay buffer was made of 50 mM Tris-HCl (pH 7.4),
bovine serum albumin (BSA, 0.1 mg/mL), bacitracin (50 g/mL), bestatin (30 M), captopril (10 M)
and phenylmethane sulfonyl fluoride (PMSF, 30 g/mL) in a total volume of 1 mL. Additionally,
×
µ
µ
µ
µ
for measuring non-specific binding, 10 µM naltrexone was added.
After the incubation, a rapid filtration with a M-24 Cell Harvester (Brandel, Biomedical Research &
Development Laboratories, Inc., Gaithersburg, MD, USA) through GF/B Whatman glass fiber strips
was done. The filters were soaked with 0.5% PEI just before harvesting so that the extent of non-specific
binding be minimized. After placing filter discs separately in 24-well plates, Optiphase Supermix
scintillation solution (Perkin Elmer, Inc., Waltham, MA, USA) was added to each well. Radioactivity
was measured in a scintillation counter MicroBeta LS, Trilux (Perkin Elmer, Inc., Waltham, MA, USA).
The experiments were performed in duplicate.
3.5. Molecular Modeling
3.5.1. Receptor and Ligand Preparation
For the purposes of molecular modeling, complexes of studied fentanyl derivatives (F01
OR were built. The protein structure was taken from our previous work [47]. It was a processed
5C1M (active-state OR crystal) [71] structure after 2.1 s of full-atom molecular dynamics simulations
–F21)
with
µ
µ
µ
with fentanyl in the binding site (receptor embedded in lipid bilayer). Originally, the protein structure
was downloaded from the OPM (Orientation of Proteins in Membranes) database [81] that contains
structures pre-oriented with respect to the membrane normal. The protein included neither the
nanobody nor crystallographic adjuvants found in the original 5C1M PDB entry [71]. A few missing
atoms were added automatically and unnatural amino acid cysteine-s-acetamide (YCM) found in
position 57 was manually changed to cysteine.
This protein structure served as a template for fentanyls-
µOR complexes. The complexes were
formed by imposing structures of F02 F21 over the respective fentanyl F01 atoms in the template.
–
Such initial complexes were subjected to minimization so as to remove possible strain resulting from
manual docking and to ascertain even apportionment of water molecules in the binding site. Regarding
the ligand structures, the piperidine N-atoms were protonated as expected at physiological pH values.
In order to obtain force field parameters for the ligands, they were submitted to ParamChem service
that produces parameters compatible with CHARMM force-field (CHARMM CGenFF approach [82]).
In case of chiral compounds, enantiomers were included in modeling as follows: (a) for
-1-positions both R and S isomers, (b) for isomerism connected to two chiral centers at positions
3 and 4 of the piperidine: only cis-isomers.
α- and β-
and
ω

Molecules 2019, 24, 740
23 of 30
The crystal structure for the modeling is of murine origin, while our experimental data were
acquired with rat brain preparations and fentanyl derivatives are widely used in human medicine.
However, as the sequence identity of human/murine/rat µOR is very high, and the singular sequence
differences are rather conservative and remote from the binding site, we have assumed they should
have no impact on simulations and scoring results. In the Supplementary Materials (SM-SEQ section)
we provide the sequences’ alignment and a comment thereon.
3.5.2. Molecular Dynamics
The MD simulations were performed in GROMACS 5.1.2 [83]. The systems subject to dynamics
contained ligands, µOR protein, POPC membrane (145 lipid molecules), water (about 13,000 water
−
molecules, TIP3P), as well as Na+ and Cl ions that were added so as to obtain 0.154 M concentration.
For the protein, lipids, water, and ions, CHARMM 36 force field was used, while for ligands CHARMM
CGenFF. The complexes built were subject to minimization and equilibration, after which the
production step (NPT ensemble, 303.15 K, integration step = 2 fs, cut-off scheme Verlet, Nose-Hoover
thermostat, Parrinello–Rahman barostat, LINCS H-bonds constraints) followed. The production was
run so to obtain at least 50 ns of equilibrated trajectory.
3.5.3. Analysis of Data from Molecular Dynamics
For the purposes of MD data analysis, we have created a snapshot pool for each derivative
containing 3000 snapshots. They were extracted from last 10 ns of three production runs, 100 snapshots
per 1 ns. The snapshot pool was subject to further analyses, that is to calculation of receptor/ligand
characteristics, dynamic volume or scoring.
The characteristics computed on the snapshot pools included:
•
root-mean-square-deviation (RMSD) of protein backbone atoms with a 0.0 ns structure taken
as reference; RMSDs were calculated for separate helices, or for all them together; the residues
considered for each helix are: 72-92 (H1), 104-128 (H2), 139-169 (H3), 185-204 (H4), 227-260 (H5),
275-304 (H6), 314-338 (H7);
•
•
•
•
distance between ligands’ protonable nitrogen and Cγ atom of D147;
X1 and X2 dihedral angles of: W133, D147, Y148, W293, H297, W318, H319, Y326, W336;
distance between Cγ atom of D147 and OH atom of Y326;
hydration of D114 and Y336 residues, understood as a number of water molecules found within
5.0 Å of any atom of a given residue.
These characteristics were gathered by the means of GROMACS utilities [83] (RMSD, distances,
dihedrals) or by our in-house scripts (hydration).
For each considered property, we provide its time evolutions in the Supplementary Materials. It is
also there that we give for each derivative distributions of the properties’ values in the snapshot pool.
For comparative purposes, the properties were averaged (arithmetic means for distances, RMSDs,
number of water molecules; circular means for dihedral angle values). RMSDs and hydrations were
subject to the Kruskall–Wallis test and one-way ANOVA analysis (at
α = 0.05), using in-house Python
scripts based on numpy and scipy libraries.
3.5.4. Volume Calculations
For the purposes of volume calculations, ligand geometries were extracted from the MD snapshot
pool (100 snapshots per 1 ns, from the final 10 ns of three replicas). The ligands were fragmented into
five parts: piperidine, N-chain, anilide’s aromatic ring, propanamide. The fragments were subject to
a single point quantum mechanical calculation at the HF/6-31G* with PCM implicit solvent model,
in Gaussian 09 [84]. Electronic spatial extent (ESE) value (in atomic units) was gathered for each
snapshot and the averaged. The average ESE was taken as a measure of ‘dynamic volume’ of a given

Molecules 2019, 24, 740
24 of 30
element. Calculation for many snapshots, followed by averaging, was undertaken in order to account
for rotational flexibility and this is why we call the average ESE a ‘dynamic volume’.
3.5.5. Scoring
The snapshots of MD trajectories (snapshot pool) for each derivative were scored using 14 different
scoring functions. The structures were taken directly from MD trajectories and after removal of water
molecules, they were subject to default processing (with default parameters) in particular programs.
The following scoring functions were used:
•
•
•
•
•
•
•
•
Jain scoring function (Jain) [85],
Piecewise Linear Potential (PLP1 and PLP2) [86],
Potential of Mean Force (PMF and PMF04) [87,88],
LigScore scoring function (LigScore1 and LigScore2) [89],
Ludi scoring function (Ludi1, Ludi2 and Ludi3) [90],
VINA scoring function (VINA) [91],
DSX scoring function (DSX) [92],
DOCK continuous and grid scores (DOCK_CS and DOCK_GS) [93].
The scoring preceded with any required preparatory procedures (grid calculations, atom
typing etc.) was performed using Accelrys Discovery Studio suite (Jain, PLP1, PLP2, PMF, PMF04,
LigScore1, LigScore2, Ludi1, Ludi2, Ludi3) [94], AutoDock VINA (VINA) [91], DSX standalone
program (DSX) [92], or DOCK 6.8 (DOCK_CS and DOCK_GS) [93]. For each scoring function,
the optimal score was collected and used for further analyses. The optimal here means maximum
or minimum depending on the type of scoring function. Analyses with averaged scores were also
performed but as they gave qualitatively similar results they are not discussed in the paper.
3.5.6. Regression Analysis and Molecular Graphics
Regression analysis was performed using in-house scripts built in Python scripts, based on numpy
and scipy libraries, as well as in Microsoft Excel. Coefficient optimization of LUDI scoring function
was done in Microsoft Excel. Molecular graphics were prepared in PyMol 2.1.1 (open source project
maintained by Schrödinger, LLC, New York, NY, USA), [95].
4. Conclusions
To sum up, we analyzed interactions of 21 fentanyl derivatives with
µOR by the means of
experimental and theoretical methods. First, a uniform assessment of fentanyls’ binding to
µOR was
performed with competitive radioligand binding assay. Two of the studied derivatives have never
been published before, and the binding affinity data are also novel for one compound previously
known. In general, our binding assay results confirm the structure–activity trends reported before.
However thanks to uniform conditions, our dataset is placed on a uniform scale what supports and
facilitates comparisons.
Molecular modeling performed provides us with hypothetical structural basis behind the observed
trends. Based on the results of molecular dynamics we propose that the binding modes of the studied
derivatives share five common General Features (GFs): GF1) ionic interaction between D147 and
the protonable amine of the ligands’ piperidine moiety, GF2) orientation of the N-chain towards
the receptor interior, GF3) positioning of the other ligands’ pole towards the receptor outlet, GF4
)
locating the aromatic ring of the anilide in the subpocket formed by TM3, TM4, ECL1 and ECL2,
GF5) positioning of the 4-axial substituent (if present) towards W318. Apart from a single ionic
interaction (GF1), most contacts with the receptor are hydrophobic. Consistently with the apolar
character of the binding, it seems that there is a relationship between the volume of the N-chain and/or
anilide’s aromatic ring and the binding affinity. The relationships appear to be nonlinear, with optima

Molecules 2019, 24, 740
25 of 30
for medium substituents and decreasing of affinity for both smaller and larger ones. According to
molecular dynamics, smaller N-chains participate in a lower number of interactions (underpacking and
hence lower binding affinity), while for the larger ones, the number of contacts can increase, however
it should result in larger entropic penalty due to rigidification of interacting partners (overpacking).
Furthermore, molecular dynamics of fentanyls-µOR complexes reveal several interesting
relationships between receptor characteristics and the volumes of the fentanyls’ N-chain and anilide’s
aromatic ring. For instance there is a linear correlation between the volumes and average dihedral angles
of W293 and W133 from simulations. In particular, the link between ligands’ volume and the W293 X2
dihedral seems most interesting, as this residue is commonly known to be involved in the activation
processes. Another receptor characteristic dependent of the ligands’ size is the distance between the
OH atom of Y326 and the Cγ atom of D147. On the other hand, we found neither statistically significant
differences in RMSF measures among the derivatives nor any affinity-/structure-based correlations
with these measures. No such differences and no correlations could be established for the hydration of
D114 or Y336.
We have also performed an attempt to reproduce our experimental binding data with 14 popular
scoring functions. None of the tested functions performed in a satisfactory manner (correlation
coefficient between predicted and observed data R < 0.30, n = 28). Only after excluding a few points,
we were able to reach correlation of R = 0.64 (n = 13) for PLP1 or R = 0.78 (n = 13) for the LUDI3_LIPSCO
component. Reweighting the components of the LUDI3 scoring function yielded an improvement in
the internal validation, however an attempt to apply the reweighted equation to score a few good
µOR
binders other than fentanyl derivatives resulted in a very poor performance. Thus, the tested scoring
functions leave a lot to be desired, at least in the case of fentanyls-
recent contribution [39] gives more hope in this realm.
µOR binding. Promisingly, another
Supplementary Materials: Supplementary Materials (SM) are available online, SM file is divided into sections
that contain data pertaining to particular analysis subjects. Items in each section are independently numbered.
The sections are: SM-SYN (synthetic details for compounds F02, F09 and F13) SM-DIS (time evolutions and
distributions of distances derived from MD, 4 Figures), SM-VOL (correlations of volumes with affinity data,
as well as with dihedral angle values, 6 Figures), SM-RMS (root-mean-square deviations of protein backbone,
as well as of single helices; distributions, time evolutions and means; 8 Tables and 9 Figures), SM-DIH (dihedral
angles derived from MD, summary, time evolutions and distributions, 1 Table and 40 Figures), SM-WAT
(hydration derived from MD, time evolutions, distributions and means, 2 Tables and 4 Figures), SM-SCO
(scoring results; correlations of predicted vs. observed values, expression for reweighted scoring function, 1 Table
and 4 Figures) and SM-SEQ (sequence alignment of human, rat and murine µOR).
Author Contributions: Conceptualization, J.S., J.Cz.D. and P.F.J.L.; methodology, P.F.J.L., P.K., Z.C., P.R., M.J.,
A.M.; investigation, P.F.J.L., P.K., J.M., P.R., M.J.; writing—original draft preparation, P.F.J.L.; writing—review and
editing, P.F.J.L., J.S., J.Cz.D., M.J., A.M., Z.C., P.R.; project administration, J.S.; funding acquisition, J.S., J.Cz.D.,
P.F.J.L.
Funding: This research was funded by National Science Centre, Poland, grant number 2013/11/B/ST4/00785.
Acknowledgments: The calculations were performed at Interdisciplinary Centre for Mathematical and
´
Computational Modelling (ICM), Warsaw, Poland (computational grant GB65-21) and at Swierk Computing
´
Centre, National Centre for Nuclear Research, Swierk, Poland.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Cortazzo, M.H.; Copenhaver, D.; Fishman, S.M. Major Opioids and Chronic Opioid Therapy. In Practical
Management of Pain; Elsevier: Amsterdam, The Netherlands, 2014; pp. 495.e3–507.e3, ISBN 9780323083409.
Stanley, T.H. The Fentanyl Story. J. Pain 2014, 15, 1215–1226. [CrossRef] [PubMed]
Vardanyan, R.S.; Hruby, V.J. Fentanyl-related compounds and derivatives: Current status and future
prospects for pharmaceutical applications. Future Med. Chem. 2014, 6, 385–412. [CrossRef] [PubMed]
Burns, S.M.; Cunningham, C.W.; Mercer, S.L. DARK Classics in Chemical Neuroscience: Fentanyl. ACS Chem.
Neurosci. 2018, 9, 2428–2437. [CrossRef] [PubMed]
2.
3.
4.

Molecules 2019, 24, 740
26 of 30
5.
6.
7.
Valdez, C.A.; Leif, R.N.; Mayer, B.P. An Efficient, Optimized Synthesis of Fentanyl and Related Analogs.
PLoS ONE 2014, 9, e108250. [CrossRef] [PubMed]
Jevtic´, I.; Došen-Mic´ovic´, L.; Ivanovic´, E.; Todorovic´, N.; Ivanovic´, M. Synthesis of Orthogonally Protected
(±)-3-Amino-4-anilidopiperidines and (±)-3-N-Carbomethoxyfentanyl. Synthesis (Stuttg.) 2017, 49, 3126–3136.
Ogawa, N.; Furuishi, T.; Nagase, H.; Endo, T.; Takahashi, C.; Yamamoto, H.; Kawashima, Y.; Loftsson, T.;
Kobayashi, M.; Ueda, H. Interaction of fentanyl with various cyclodextrins in aqueous solutions. J. Pharm.
Pharmacol. 2016, 68, 588–597. [CrossRef] [PubMed]
8.
9.
Barbas, R.; Prohens, R.; Bauzá, A.; Franconetti, A.; Frontera, A. H-Bonded anion–anion complexes in fentanyl
citrate polymorphs and solvates. Chem. Commun. 2019, 55, 115–118. [CrossRef]
Bick, M.J.; Greisen, P.J.; Morey, K.J.; Antunes, M.S.; La, D.; Sankaran, B.; Reymond, L.; Johnsson, K.;
Medford, J.I.; Baker, D. Computational design of environmental sensors for the potent opioid fentanyl. Elife
2017, 6, e28909. [CrossRef]
10. Nami, M.; Salehi, P.; Dabiri, M.; Bararjanian, M.; Gharaghani, S.; Khoramjouy, M.; Al-Harrasi, A.; Faizi, M.
Synthesis of novel norsufentanil analogs via a four-component Ugi reaction and in vivo, docking, and QSAR
studies of their analgesic activity. Chem. Biol. Drug Des. 2018, 91, 902–914. [CrossRef]
11. Váradi, A.; Palmer, T.C.; Haselton, N.; Afonin, D.; Subrath, J.J.; Le Rouzic, V.; Hunkele, A.; Pasternak, G.W.;
Marrone, G.F.; Borics, A.; et al. Synthesis of Carfentanil Amide Opioids Using the Ugi Multicomponent
Reaction. ACS Chem. Neurosci. 2015, 6, 1570–1577. [CrossRef]
12. Li, S.; Cohen-Karni, D.; Kovaliov, M.; Tomycz, N.; Cheng, B.; Whiting, D.; Averick, S. Synthesis and biological
evaluation of fentanyl acrylic derivatives. RSC Adv. 2017, 7, 20015–20019. [CrossRef]
13. Petrov, R.R.; Lee, Y.S.; Vardanyan, R.S.; Liu, L.; Ma, S.; Davis, P.; Lai, J.; Porreca, F.; Vanderah, T.W.; Hruby, V.J.
Effect of anchoring 4-anilidopiperidines to opioid peptides. Bioorg. Med. Chem. Lett. 2013, 23, 3434–3437.
[CrossRef] [PubMed]
14. Deekonda, S.; Wugalter, L.; Rankin, D.; Largent-Milnes, T.M.; Davis, P.; Wang, Y.; Bassirirad, N.M.; Lai, J.;
Kulkarni, V.; Vanderah, T.W.; et al. Design and synthesis of novel bivalent ligands (MOR and DOR) by
conjugation of enkephalin analogues with 4-anilidopiperidine derivatives. Bioorg. Med. Chem. Lett. 2015, 25,
4683–4688. [CrossRef] [PubMed]
15. Deekonda, S.; Rankin, D.; Davis, P.; Lai, J.; Vanderah, T.W.; Porecca, F.; Hruby, V.J. Design synthesis
and structure–activity relationship of 5-substituted (tetrahydronaphthalen-2yl)methyl with N-phenyl-N-
(piperidin-2-yl)propionamide derivatives as opioid ligands. Bioorg. Med. Chem. 2016, 24, 85–91. [CrossRef]
[PubMed]
16. Monti, L.; Stefanucci, A.; Pieretti, S.; Marzoli, F.; Fidanza, L.; Mollica, A.; Mirzaie, S.; Carradori, S.;
De Petrocellis, L.; Schiano Moriello, A.; et al. Evaluation of the analgesic effect of 4-anilidopiperidine
scaffold containing ureas and carbamates. J. Enzyme Inhib. Med. Chem. 2016, 31, 1638–1647. [CrossRef]
17. Jevtic, I.; Penjisevic, J.; Ivanovic, M.; Kostic-Rajacic, S. Synthetic route towards potential bivalent ligands
possessing opioid and D2/D3 pharmacophores. J. Serbian Chem. Soc. 2018, 105. [CrossRef]
18. Schmid, C.L.; Kennedy, N.M.; Ross, N.C.; Lovell, K.M.; Yue, Z.; Morgenweck, J.; Cameron, M.D.;
Bannister, T.D.; Bohn, L.M. Bias Factor and Therapeutic Window Correlate to Predict Safer Opioid Analgesics.
Cell 2017, 171, 1165.e13–1175.e13. [CrossRef]
19. Kennedy, N.M.; Schmid, C.L.; Ross, N.C.; Lovell, K.M.; Yue, Z.; Chen, Y.T.; Cameron, M.D.; Bohn, L.M.;
Bannister, T.D. Optimization of a Series of Mu Opioid Receptor (MOR) Agonists with High G Protein
Signaling Bias. J. Med. Chem. 2018, 61, 8895–8907. [CrossRef]
20. Rodriguez-Gaztelumendi, A.; Spahn, V.; Labuz, D.; Machelska, H.; Stein, C. Analgesic effects of a novel
pH-dependent µ-opioid receptor agonist in models of neuropathic and abdominal pain. Pain 2018, 159,
2277–2284. [CrossRef]
21. Spahn, V.; Del Vecchio, G.; Rodriguez-Gaztelumendi, A.; Temp, J.; Labuz, D.; Kloner, M.; Reidelbach, M.;
Machelska, H.; Weber, M.; Stein, C. Opioid receptor signaling, analgesic and side effects induced by a
computationally designed pH-dependent agonist. Sci. Rep. 2018, 8, 8965. [CrossRef]
22. Spahn, V.; Del Vecchio, G.; Labuz, D.; Rodriguez-Gaztelumendi, A.; Massaly, N.; Temp, J.; Durmaz, V.;
Sabri, P.; Reidelbach, M.; Machelska, H.; et al. A nontoxic pain killer designed by modeling of pathological
receptor conformations. Science 2017, 355, 966–969. [CrossRef]
23. Fisher, D.M.; Chang, P.; Wada, D.R.; Dahan, A.; Palmer, P.P. Pharmacokinetic Properties of a Sufentanil
Sublingual Tablet Intended to Treat Acute Pain. Anesthesiology 2018, 128, 943–952. [CrossRef] [PubMed]

Molecules 2019, 24, 740
27 of 30
24. National Institute on Drug Abuse Overdose Death Rates. Available online: https://www.drugabuse.gov/
related-topics/trends-statistics/overdose-death-rates (accessed on 4 January 2019).
25. Mounteney, J.; Giraudon, I.; Denissov, G.; Griffiths, P. Fentanyls: Are we missing the signs? Highly potent
and on the rise in Europe. Int. J. Drug Policy 2015, 26, 626–631. [CrossRef] [PubMed]
26. Pearson, J.; Poklis, J.; Poklis, A.; Wolf, C.; Mainland, M.; Hair, L.; Devers, K.; Chrostowski, L.; Arbefeville, E.;
Merves, M. Postmortem Toxicology Findings of Acetyl Fentanyl, Fentanyl, and Morphine in Heroin Fatalities
in Tampa, Florida. Acad. Forensic Pathol. 2015, 5, 676–689. [CrossRef] [PubMed]
27. Poklis, J.; Poklis, A.; Wolf, C.; Mainland, M.; Hair, L.; Devers, K.; Chrostowski, L.; Arbefeville, E.; Merves, M.;
Pearson, J. Postmortem tissue distribution of acetyl fentanyl, fentanyl and their respective nor-metabolites
analyzed by ultrahigh performance liquid chromatography with tandem mass spectrometry. Forensic Sci. Int.
2015, 257, 435–441. [CrossRef] [PubMed]
28. Mayer, B.P.; DeHope, A.J.; Mew, D.A.; Spackman, P.E.; Williams, A.M. Chemical Attribution of Fentanyl
Using Multivariate Statistical Analysis of Orthogonal Mass Spectral Data. Anal. Chem. 2016, 88, 4303–4310.
[CrossRef] [PubMed]
29. Shaner, R.L.; Schulze, N.D.; Seymour, C.; Hamelin, E.I.; Thomas, J.D.; Johnson, R.C. Quantitation of fentanyl
analogs in dried blood spots by flow-through desorption coupled to online solid phase extraction tandem
mass spectrometry. Anal. Methods 2017, 9, 3876–3883. [CrossRef] [PubMed]
30. Hikin, L.; Smith, P.R.; Ringland, E.; Hudson, S.; Morley, S.R. Multiple fatalities in the North of England
associated with synthetic fentanyl analogue exposure: Detection and quantitation a case series from early
2017. Forensic Sci. Int. 2018, 282, 179–183. [CrossRef] [PubMed]
31. Maher, S.; Elliott, S.P.; George, S. The analytical challenges of cyclopropylfentanyl and crotonylfentanyl:
An approach for toxicological analysis. Drug Test. Anal. 2018, 10, 1483–1487. [CrossRef] [PubMed]
32. Vandergrift, G.W.; Hessels, A.J.; Palaty, J.; Krogh, E.T.; Gill, C.G. Paper spray mass spectrometry for the
direct, semi-quantitative measurement of fentanyl and norfentanyl in complex matrices. Clin. Biochem. 2018
54, 106–111. [CrossRef] [PubMed]
,
33. Skov-Skov Bergh, M.; Bogen, I.L.; Wilson, S.R.; Øiestad, Å.M.L. Addressing the Fentanyl Analog Epidemic
by Multiplex UHPLC-MS/MS Analysis of Whole Blood. Ther. Drug Monit. 2018, 40, 738–748. [CrossRef]
[PubMed]
34. Seymour, C.; Shaner, R.L.; Feyereisen, M.C.; Wharton, R.E.; Kaplan, P.; Hamelin, E.I.; Johnson, R.C.
Determination of Fentanyl Analog Exposure Using Dried Blood Spots with LC–MS-MS. J. Anal. Toxicol. 2018
.
[CrossRef] [PubMed]
35. Latorraca, N.R.; Venkatakrishnan, A.J.; Dror, R.O. GPCR Dynamics: Structures in Motion. Chem. Rev. 2017
,
117, 139–155. [CrossRef] [PubMed]
36. Dror, R.O.; Dirks, R.M.; Grossman, J.P.; Xu, H.; Shaw, D.E. Biomolecular Simulation: A Computational
Microscope for Molecular Biology. Annu. Rev. Biophys. 2012, 41, 429–452. [CrossRef] [PubMed]
37. Bermudez, M.; Mortier, J.; Rakers, C.; Sydow, D.; Wolber, G. More than a look into a crystal ball: Protein
structure elucidation guided by molecular dynamics simulations. Drug Discov. Today 2016, 21, 1799–1805.
[CrossRef] [PubMed]
38. Sabbadin, D.; Ciancetta, A.; Moro, S. Bridging Molecular Docking to Membrane Molecular Dynamics To
Investigate GPCR–Ligand Recognition: The Human A 2A Adenosine Receptor as a Key Study. J. Chem. Inf.
Model. 2014, 54, 169–183. [CrossRef] [PubMed]
39. Ellis, C.R.; Kruhlak, N.L.; Kim, M.T.; Hawkins, E.G.; Stavitskaya, L. Predicting opioid receptor binding
affinity of pharmacologically unclassified designer substances using molecular docking. PLoS ONE 2018
13, e0197734. [CrossRef]
,
˙
40. Dyniewicz, J.; Lipin´ski, P.F.J.; Kosson, P.; Les´niak, A.; Bochyn´ska-Czyz, M.; Muchowska, A.; Tourwé, D.;
Ballet, S.; Misicka, A.; Lipkowski, A.W. Hydrazone Linker as a Useful Tool for Preparing Chimeric
Peptide/Nonpeptide Bifunctional Compounds. ACS Med. Chem. Lett. 2017, 8, 73–77. [CrossRef]
41. Wright, W.B.; Brabander, H.J.; Hardy, R.A. Synthetic Analgesics. III. Basic Anilides and Carbanilates
Containing the Phenalkyl Moiety 1. J. Org. Chem. 1961, 26, 485–490. [CrossRef]
42. Ivanovic, M.; Micovic, I.V.; Vuckovic, S.; Prostran, M.; Todorovic, Z.; Ivanovic, E.; Kiricojevic, V.;
Djordjevic, J.B.; Dosen-Micovic, L. The synthesis and pharmacological evaluation of ( )-2,3-seco-fentanyl
±
analogues. J. Serb. Chem. Soc. 2004, 69, 955–968. [CrossRef]

Molecules 2019, 24, 740
28 of 30
43. N.V. Research Laboratorium Dr P. Janssen N-(1-alkyl-4-piperidyl)-N-arylalkanoamides 1961. Available
online: https://worldwide.espacenet.com/publicationDetails/originalDocument?CC=FR&NR=1517671A&
KC=A&FT=D&ND=3&date=19680322&DB=EPODOC&locale=en_EP# (accessed on 18 January 2019).
44. U.S. Drug Enforcement Administration. Three Factor Analysis for Temporary Scheduling of Cyclopropyl Fentanyl;
U.S. Drug Enforcement Administration: Springfield, VA, USA, 2017.
45. European Monitoring Centre for Drugs and Drug Addiction. EMCDDA–Europol Joint Report on a New
Psychoactive Substance: N-phenyl-N-[1-(2-phenylethyl)piperidin-4-yl]cyclopropanecarboxamide (cyclopropylfentanyl);
European Monitoring Centre for Drugs and Drug Addiction: Lisbon, Portugal, 2018.
46. Volpe, D.A.; McMahon Tobin, G.A.; Mellon, R.D.; Katki, A.G.; Parker, R.J.; Colatsky, T.; Kropp, T.J.;
Verbois, S.L. Uniform assessment and ranking of opioid
µ receptor binding constants for selected opioid
drugs. Regul. Toxicol. Pharmacol. 2011, 59, 385–390. [CrossRef] [PubMed]
47. Lipin´ski, P.F.J.; Jaron´czyk, M.; Dobrowolski, J.C.; Sadlej, J. Molecular dynamics of fentanyl bound to
receptor. J. Mol. Model. 2019. under review.
µ-opioid
48. Li, J.G.; Chen, C.; Yin, J.; Rice, K.; Zhang, Y.; Matecka, D.; de Riel, J.K.; DesJarlais, R.L.; Liu-Chen, L.Y.
ASP147 in the third transmembrane helix of the rat mu opioid receptor forms ion-pairing with morphine
and naltrexone. Life Sci. 1999, 65, 175–185. [CrossRef]
49. Surratt, C.K.; Johnson, P.S.; Moriwaki, A.; Seidleck, B.K.; Blaschak, C.J.; Wang, J.B.; Uhl, G.R. mu opiate
receptor: Charged transmembrane domain amino acids are critical for agonist recognition and intrinsic
activity. J. Biol. Chem. 1994, 269, 20548–20553.
50. Weltrowska, G.; Lemieux, C.; Chung, N.N.; Guo, J.J.; Wilkes, B.C.; Schiller, P.W. ‘Carba’-carfentanil (trans
isomer): A
µ opioid receptor (MOR) partial agonist with a distinct binding mode. Bioorg. Med. Chem. 2014,
22, 4581–4586. [CrossRef] [PubMed]
51. Weltrowska, G.; Chung, N.N.; Lemieux, C.; Guo, J.; Lu, Y.; Wilkes, B.C.; Schiller, P.W. “Carba”-Analogues of
Fentanyl are Opioid Receptor Agonists. J. Med. Chem. 2010, 53, 2875–2881. [CrossRef]
52. Manglik, A.; Kruse, A.C.; Kobilka, T.S.; Thian, F.S.; Mathiesen, J.M.; Sunahara, R.K.; Pardo, L.; Weis, W.I.;
Kobilka, B.K.; Granier, S. Crystal structure of the µ-opioid receptor bound to a morphinan antagonist. Nature
2012, 485, 321–326. [CrossRef]
53. Koehl, A.; Hu, H.; Maeda, S.; Zhang, Y.; Qu, Q.; Paggi, J.M.; Latorraca, N.R.; Hilger, D.; Dawson, R.;
Matile, H.; et al. Structure of the -opioid receptor–Gi protein complex. Nature 2018, 558, 547–552. [CrossRef]
µ
54. Wang, Z.-X.; Zhu, Y.-C.; Jin, W.-Q.; Chen, X.-J.; Chen, J.; Ji, R.-Y.; Chi, Z.-Q. Stereoisomers of
N-[1-(2-Hydroxy-2-phenylethyl)-3-methyl-4-piperidyl]-N-phenylpropanamide: Synthesis, Stereochemistry,
Analgesic Activity, and Opioid Receptor Binding Characteristics. J. Med. Chem. 1995, 38, 3652–3659.
[CrossRef]
55. Jin, W.Q.; Wang, Z.X.; Chen, J.; Chen, X.J.; Chi, Z.Q. Analgesic activity and selectivity for opioid receptors of
enantiomers of ohmefentanyl. Zhongguo Yao Li Xue Bao 1996, 17, 421–424.
56. Mecozzi, S.; Rebek, J., Jr. The 55% Solution: A Formula for Molecular Recognition in the Liquid State.
Chem. A Eur. J. 1998, 4, 1016–1022. [CrossRef]
57. Zürcher, M.; Diederich, F. Structure-Based Drug Design: Exploring the Proper Filling of Apolar Pockets at
Enzyme Active Sites. J. Org. Chem. 2008, 73, 4345–4361. [CrossRef] [PubMed]
58. Zürcher, M.; Gottschalk, T.; Meyer, S.; Bur, D.; Diederich, F. Exploring the Flap Pocket of the Antimalarial
Target Plasmepsin II: The “55% Rule” Applied to Enzymes. ChemMedChem 2008, 3, 237–240. [CrossRef]
[PubMed]
59. Casy, A.F.; Huckstep, M.R. Structure-Activity Studies of Fentanyl. J. Pharm. Pharmacol. 1988, 40, 605–608.
[CrossRef]
60. Kudzma, L.V.; Severnak, S.A.; Benvenga, M.J.; Ezell, E.F.; Ossipov, M.H.; Knight, V.V.; Rudo, F.G.;
Spencer, H.K.; Spaulding, T.C. 4-Phenyl- and 4-heteroaryl-4-anilidopiperidines. A novel class of analgesic
and anesthetic agents. J. Med. Chem. 1989, 32, 2534–2542. [CrossRef] [PubMed]
61. Bagley, J.R.; Wynn, R.L.; Rudo, F.G.; Doorley, B.M.; Spencer, H.K.; Spaulding, T. New 4-(heteroanilido)
piperidines, structurally related to the pure opioidagonist fentanyl, with agonist and/or antagonist properties.
J. Med. Chem. 1989, 32, 663–671. [CrossRef]
62. Lalinde, N.; Moliterni, J.; Wright, D.; Spencer, H.K.; Ossipov, M.H.; Spaulding, T.C.; Rudo, F.G. Synthesis
and pharmacological evaluation of a series of new 1,4-disubstituted 3-methyl-piperidine analgesics. J. Med.
Chem. 1990, 33, 2876–2882. [CrossRef]

Molecules 2019, 24, 740
29 of 30
63. Chan, H.C.S.; Filipek, S.; Yuan, S. The Principles of Ligand Specificity on beta-2-adrenergic receptor. Sci. Rep.
2016, 6, 34736. [CrossRef]
64. Trzaskowski, B.; Latek, D.; Yuan, S.; Ghoshdastider, U.; Debinski, A.; Filipek, S. Action of Molecular Switches
in GPCRs—Theoretical and Experimental Studies. Curr. Med. Chem. 2012, 19, 1090–1109. [CrossRef]
65. Kolinski, M.; Filipek, S. Molecular Dynamics of
µ Opioid Receptor Complexes with Agonists and Antagonists.
Open Struct. Biol. J. 2008, 2, 8–20. [CrossRef]
66. Hulme, E.C. GPCR activation: A mutagenic spotlight on crystal structures. Trends Pharmacol. Sci. 2013, 34,
67–84. [CrossRef] [PubMed]
67. Stoddart, L.A.; Kellam, B.; Briddon, S.J.; Hill, S.J. Effect of a toggle switch mutation in TM6 of the human
adenosine A 3 receptor on Gi protein-dependent signalling and Gi-independent receptor internalization.
Br. J. Pharmacol. 2014, 171, 3827–3844. [CrossRef] [PubMed]
68. Kaiser, A.; Hempel, C.; Wanka, L.; Schubert, M.; Hamm, H.E.; Beck-Sickinger, A.G. G Protein Preassembly
Rescues Efficacy of W 6.48 Toggle Mutations in Neuropeptide Y 2 Receptor. Mol. Pharmacol. 2018, 93, 387–401.
[CrossRef] [PubMed]
69. Sun, X.; Laroche, G.; Wang, X.; Ågren, H.; Bowman, G.R.; Giguère, P.M.; Tu, Y. Propagation of the Allosteric
Modulation Induced by Sodium in the
[PubMed]
δ-Opioid Receptor. Chem. A Eur. J. 2017, 23, 4615–4624. [CrossRef]
70. Kolinski, M.; Filipek, S. Study of a structurally similar kappa opioid receptor agonist and antagonist pair by
molecular dynamics simulations. J. Mol. Model. 2010, 16, 1567–1576. [CrossRef]
71. Huang, W.; Manglik, A.; Venkatakrishnan, A.J.; Laeremans, T.; Feinberg, E.N.; Sanborn, A.L.; Kato, H.E.;
Livingston, K.E.; Thorsen, T.S.; Kling, R.C.; et al. Structural insights into µ-opioid receptor activation. Nature
2015, 524, 315–321. [CrossRef]
72. Yuan, S.; Hu, Z.; Filipek, S.; Vogel, H. W2466.48 opens a gate for a continuous intrinsic water pathway during
activation of the adenosine A2A receptor. Angew. Chem. Int. Ed. 2015, 54, 556–559.
73. Yuan, S.; Palczewski, K.; Peng, Q.; Kolinski, M.; Vogel, H.; Filipek, S. The mechanism of ligand-induced
activation or inhibition of µ- And κ-opioid receptors. Angew. Chem. Int. Ed. 2015, 54, 7560–7563. [CrossRef]
74. Yuan, S.; Vogel, H.; Filipek, S. The role of water and sodium ions in the activation of the µ-opioid receptor.
Angew. Chem. Int. Ed. 2013, 52, 10112–10115. [CrossRef]
75. Plewczynski, D.; Łaz´niewski, M.; Augustyniak, R.; Ginalski, K. Can we trust docking results? Evaluation of
seven commonly used programs on PDBbind database. J. Comput. Chem. 2011, 32, 742–755. [CrossRef]
76. Enyedy, I.J.; Egan, W.J. Can we use docking and scoring for hit-to-lead optimization? J. Comput. Aided Mol.
Des. 2008, 22, 161–168. [CrossRef] [PubMed]
77. Corbeil, C.R.; Williams, C.I.; Labute, P. Variability in docking success rates due to dataset preparation.
J. Comput. Aided Mol. Des. 2012, 26, 775–786. [CrossRef] [PubMed]
78. Vardanyan, R.; Vijay, G.; Nichol, G.S.; Liu, L.; Kumarasinghe, I.; Davis, P.; Vanderah, T.; Porreca, F.; Lai, J.;
Hruby, V.J. Synthesis and investigations of double-pharmacophore ligands for treatment of chronic and
neuropathic pain. Bioorg. Med. Chem. 2009, 17, 5044–5053. [CrossRef] [PubMed]
79. Thansandote, P.; Raemy, M.; Rudolph, A.; Lautens, M. Synthesis of Benzannulated N-Heterocycles by a
Palladium-Catalyzed C
[PubMed]
−
C/C N Coupling of Bromoalkylamines. Org. Lett. 2007, 9, 5255–5258. [CrossRef]
−
80. Ganellin, C.R.; Spickett, R.G.W. Compounds Affecting the Central Nervous System. I. 4-Piperidones and
Related Compounds. J. Med. Chem. 1965, 8, 619–625. [CrossRef]
81. Lomize, M.A.; Lomize, A.L.; Pogozheva, I.D.; Mosberg, H.I. OPM: Orientations of proteins in membranes
database. Bioinformatics 2006, 22, 623–625. [CrossRef] [PubMed]
82. Vanommeslaeghe, K.; Hatcher, E.; Acharya, C.; Kundu, S.; Zhong, S.; Shim, J.; Darian, E.; Guvench, O.;
Lopes, P.; Vorobyov, I.; et al. CHARMM general force field: A force field for drug-like molecules compatible
with the CHARMM all-atom additive biological force fields. J. Comput. Chem. 2009, 31, 671–690. [CrossRef]
[PubMed]
83. Abraham, M.J.; Murtola, T.; Schulz, R.; Páll, S.; Smith, J.C.; Hess, B.; Lindahl, E. GROMACS: High
performance molecular simulations through multi-level parallelism from laptops to supercomputers.
SoftwareX 2015, 1, 19–25. [CrossRef]

Molecules 2019, 24, 740
30 of 30
84. Frisch, M.J.; Trucks, G.W.; Schlegel, H.B.; Scuseria, G.E.; Robb, M.A.; Cheeseman, J.R.; Scalmani, G.; Barone, V.;
Mennucci, B.; Petersson, G.A.; et al. Gaussian 09, Revision D.01 2013; Gaussian, Inc.: Wallingford, CT,
USA, 2013.
85. Jain, A.N. Scoring noncovalent protein-ligand interactions: A continuous differentiable function tuned to
compute binding affinities. J. Comput. Aided Mol. Des. 1996, 10, 427–440. [CrossRef]
86. Gehlhaar, D.K.; Verkhivker, G.M.; Rejto, P.A.; Sherman, C.J.; Fogel, D.R.; Fogel, L.J.; Freer, S.T. Molecular
recognition of the inhibitor AG-1343 by HIV-1 protease: Conformationally flexible docking by evolutionary
programming. Chem. Biol. 1995, 2, 317–324. [CrossRef]
87. Muegge, I.; Martin, Y.C. A general and fast scoring function for protein-ligand interactions: A simplified
potential approach. J. Med. Chem. 1999, 42, 791–804. [CrossRef] [PubMed]
88. Muegge, I. PMF scoring revisited. J. Med. Chem. 2006, 49, 5895–5902. [CrossRef] [PubMed]
89. Krammer, A.; Kirchhoff, P.D.; Jiang, X.; Venkatachalam, C.M.; Waldman, M. LigScore: A novel scoring
function for predicting binding affinities. J. Mol. Graph. Model. 2005, 23, 395–407. [CrossRef] [PubMed]
90. Böhm, H. Prediction of binding constants of protein ligands: A fast method for the prioritization of hits
obtained from de novo design or 3D database search programs. J. Comput. Aided Mol. Des. 1998, 12, 309–323.
[CrossRef] [PubMed]
91. Trott, O.; Olson, A.J. AutoDock Vina: Improving the speed and accuracy of docking with a new scoring
function, efficient optimization, and multithreading. J. Comput. Chem. 2010, 31, 455–461. [CrossRef]
[PubMed]
92. Neudert, G.; Klebe, G. DSX: A Knowledge-Based Scoring Function for the Assessment of Protein–Ligand
Complexes. J. Chem. Inf. Model. 2011, 51, 2731–2745. [CrossRef] [PubMed]
93. Allen, W.J.; Balius, T.E.; Mukherjee, S.; Brozell, S.R.; Moustakas, D.T.; Lang, P.T.; Case, D.A.; Kuntz, I.D.;
Rizzo, R.C. DOCK 6: Impact of new features and current docking performance. J. Comput. Chem. 2015, 36,
1132–1156. [CrossRef] [PubMed]
94. Accelrys Software Inc. Discovery Studio Modeling Environment 2013; Accelrys Software Inc.: San Diego, CA,
USA, 2013.
95. The PyMOL Molecular Graphics System. Available online: www.pymol.org (accessed on 9 April 2018).
Sample Availability: Samples of the compounds F02, F07, F08, F09 and F13 are available from the authors.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
