Base-Mediated Cyclization Reaction of
2-Alkynylphenylphosphine Oxides:
Synthesis and Photophysical Properties
of Benzo[b]phosphole Oxides
Takanobu Sanji,* Kentaro Shiraishi, Taigo Kashiwabara, and Masato Tanaka*
Chemical Resources Laboratory, Tokyo Institute of Technology,
4259-R1-13, Nagatsuta, Midori-ku, Yokohama 226-8503, Japan
sanji@res.titech.ac.jp; m.tanaka@res.titech.ac.jp
Received April 12, 2008
ABSTRACT
The base-mediated intramolecular cyclization reaction of 2-alkynylphenylphosphine oxides affords benzo[b]phosphole oxides, which show
intense blue-green fluorescence. Benzo[b]phospholes are also prepared by the reduction of benzo[b]phosphole oxides.
Among the variety of π-conjugated systems with potential
applications as electronic materials, such as organic thin film
transistors and organic electroluminescent (EL) devices, main
group element-containing π-conjugated molecules have at-
tracted considerable interest recently.1 This is because the
orbital interaction of the main group element moiety plays
an intriguing role in the π-conjugated framework, and the
resultant π-systems reduce the HOMO-LUMO gaps com-
pared with the parent π-system. In this context, phosphacy-
clopentadienes (phospholes) form interesting building blocks
for the construction of conjugated systems, where an
interaction between the butadiene π* orbital and the low-
lying σ*(P-R) orbital takes place in the ring.2 In addition,
phosphorus-containing π-systems retain a versatile reactivity
of a central phosphorus atom, and this makes it possible to
tune the electronic and optical properties of the materials
using simple chemical modifications, such as oxidation.
Several reports have addressed the synthesis of phospholes,3,4
dibenzophospholes,5,6dithienophospholes,7andtheirderivatives.8
Indoles are basic skeletons in organic chemistry and are
found in natural products and biologically active sub-
stances.9,10 On the other hand, synthesis and properties of
benzo[b]phosphole, phosphorus analogues of indoles, have
not been explored to date.11,12 Here, we report the synthesis
and photophysical properties of benzo[b]phosphole oxides
and benzo[b]phospholes.13–15
Because the metal- and base-mediated cyclization reaction
of alkynylamines, which proceeds through intramolecular
addition of the N-H bond to the triple bond, is one of the
(1) (a) Mathey, F. Angew. Chem., Int. Ed. 2003, 42, 1578. (b) Hissler,
M.; Dyer, P. W.; Re´au, R. Coord. Chem. ReV. 2003, 244, 1. (c) Mathey, F.
Acc. Chem. Res. 2004, 37, 954. (d) Yamaguchi, S.; Tamao, K. Chem. Lett.
2005, 34, 2. (e) Baumgartner, T.; Re´au, R. Chem. ReV. 2006, 106, 4681.
(f) Hobbs, M. G.; Baumgartner, T. Eur. J. Inorg. Chem. 2007, 3611.
(2) (a) Delaere, D.; Dransfeld, A.; Nguyen, M. T.; Vanquickenborne,
L. G. J. Org. Chem. 2000, 65, 2631. (b) Nyula´szi, L. Chem. ReV. 2001,
101, 1229. (c) Delaere, D.; Nguyen, M. T.; Vanquickenborne, L. G. Phys.
Chem. Chem. Phys. 2002, 4, 1522. (d) Delaere, D.; Nguyen, M. T.;
Vanquickenborne, L. G. J. Organomet. Chem. 2002, 643, 194. (e) Ma, J.;
Li, S.; Jiang, Y. Macromolecules 2002, 35, 1109. (f) Delaere, D.; Nguyen,
M. T.; Vanquickenborne, L. G. J. Phys. Chem. A 2003, 107, 838. (g)
Chesnut, D. B.; Quin, L. D. Heteroatom Chem. 2007, 18, 754.
(3) Deschamps, E.; Ricard, L.; Mathey, F. Angew. Chem., Int. Ed. Engl.
1994, 33, 1158
.
(4) (a) Hay, C.; Vilain, D. L.; Deborde, V.; Toupet, L.; Re´au, R. Chem.
Commun. 1999, 345. (b) Hay, C.; Fischmeister, C.; Hissler, M.; Toupet,
L.; Re´au, R. Angew. Chem., Int. Ed. 2000, 39, 1812. (c) Hay, C.; Hissler,
M.; Fischmeister, C.; Rault-Berthelot, J.; Toupet, L.; Nyula´szi, L.; Re´au,
R. Chem. Eur. J. 2001, 7, 4222. (d) Hay, C.; Fave, C.; Hissler, M.; Rault-
Berthelot, J.; Re´au, R. Org. Lett. 2003, 5, 3467. (e) Fave, C.; Cho, T.-Y.;
Hissler, M.; Chen, C.-W.; Luh, T.-Y.; Wu, C.-C.; Re´au, R. J. Am. Chem.
Soc. 2003, 125, 9254. (f) Fave, C.; Hissler, M.; Ka´rpa´ti, T.; Rault-Berthelot,
J.; Deborde, V.; Toupet, L.; Nyula´szi, L.; Re´au, R. J. Am. Chem. Soc. 2004,
126, 6058. (g) Sanji, T.; Shiraishi, K.; Tanaka, M. Org. Lett. 2007, 9, 3611
.
10.1021/ol800841v CCC: $40.75
Published on Web 05/29/2008
2008 American Chemical Society

most powerful tools for synthesizing indoles,16 our synthetic
strategy for the benzophosphole oxides was the base-
mediated intramolecular cyclization reaction of 2-alky-
nylphenylphosphine oxides 1.17,18 Scheme 1 shows the
reaction of 2a-dwith trichlorosilane in toluene at 110 °C
afforded benzo[b]phospholes 3a-d in 56-90% yields. The
structures of 2a-d and 3a-d were fully characterized using
1H, 13C, and 31P NMR, MS, and elemental analysis.
The base-mediated intramolecular addition reaction of
H-P(O) compounds to alkynes was employed for π-extend-
ed starting materials with two alkyne parts, as shown in
Scheme 2. For example, the reaction of 4, which has two
H-P(O) groups at the central benzene ring, gave 5 as a
mixture of cis and trans isomers with respect to the directions
of the PdO bonds.21 The isomers were easily separated from
Scheme 1
(5) (a) Aitken, R. A. In Fused FiVe-Membered Hetarenes with One
Heteroatom; Thomas, E. J., Eds. Thieme: New York, 2001; Vol. 10, pp
817-838. (b) Wittig, G.; Geissler, G. Liebigs Ann. Chem. 1953, 580, 44.
(c) Allen, D. W.; Millar, I. T.; Mann, F. G. J. Chem. Soc. A 1969, 1101.
(d) Hughes, A. N.; Kleemola, D. J. Heterocycl. Chem. 1976, 13, 1.
(6) Recent examples, see (a) Makioka, Y.; Hayashi, T.; Tanaka, M.
Chem. Lett. 2004, 33, 44. (b) Su, H.-C.; Fadhel, O.; Yang, C.-J.; Cho, T.-
Y.; Fave, C.; Hissler, M.; Wu, C.-C.; Re´au, R. J. Am. Chem. Soc. 2006,
128, 983.
(7) (a) Baumgartner, T.; Neumann, T.; Wirges, B. Angew. Chem., Int.
Ed. 2004, 43, 6197. (b) Baumgartner, T.; Bergmans, W.; Ka´rpa´ti, T.;
Neumann, T.; Nieger, M.; Nyula´szi, L. Chem.-Eur. J. 2005, 11, 4687. (c)
Neumann, T.; Dienes, Y.; Baumgartner, T. Org. Lett. 2006, 8, 495. (d)
Baumgartner, T.; Wilk, W. Org. Lett. 2006, 8, 503. (e) Durben, S.; Dienes,
Y.; Baumgartner, T. Org. Lett. 2006, 8, 5893. (f) Dienes, Y.; Eggenstein,
M.; Neumann, T.; Englert, U.; Baumgartner, T. Dalton Trans. 2006, 1424.
(g) Dienes, Y.; Durben, S.; Ka´rpa´ti, T.; Neumann, T.; Englert, U.; Nyula´szi,
L.; Baumgartner, T. Chem.-Eur. J. 2007, 13, 7487. (h) Matano, Y.;
Miyajima, T.; Nakabuchi, T.; Imahori, H.; Ochi, N.; Sakaki, S. J. Am. Chem.
Soc. 2006, 128, 11760. (i) Matano, Y.; Miyajima, T.; Imahori, H.; Kimura,
Y. J. Org. Chem. 2007, 72, 6200.
synthesis of benzobphosphole oxides 2a-d. For example, the
reaction of 1a (R ) Ph) in the presence of potassium
t-butoxide (20 mol %) as a base in DMSO at 70 °C for 24 h
led to a phosphole oxide 2a in 79% yield.19,20 The reaction
of 1b (R ) 4-MeOC6H4) and 1d (R ) 2-thienyl) gave 2b
and 2d, respectively, in good yields, but the reaction of 1c
(R ) 4-CF3C6H4) gave 2c only in 15% yield. Subsequently,
reduction of the benzophosphole oxides was examined. The
(8) (a) Mao, S. S. H.; Tilley, T. D. Macromolecules 1997, 30, 5566. (b)
Morisaki, Y.; Aiki, Y.; Chujo, Y. Macromolecules 2003, 36, 2594. (c)
Sebastian, M.; Hissler, M.; Fave, C.; Rault-Berthelot, J.; Odin, C.; Re´au,
R. Angew. Chem., Int. Ed. 2006, 45, 6152. (d) Morisaki, Y.; Na, H.-S.;
Aiki, Y.; Chujo, Y. Polym. Bull. 2007, 58, 777. (e) Na, H.-S.; Morisaki,
Y.; Aiki, Y.; Chujo, Y. Polym. Bull. 2007, 58, 645. (f) Na, H.-S.; Morisaki,
Y.; Aiki, Y.; Chujo, Y. J. Polym. Sci. A, Polym. Chem. 2007, 45, 2867.
(9) (a) Gribble, G. W. J. Chem. Soc., Perkin Trans. 1 2000, 1045. (b)
Gribble, G. W. ComprehensiVe Heterocyclic Chemistry II; Katritzky, A. R.,
Rees, C. W., Scriven, E. F. V., Ed Pergamon Press: Oxford UK, 1996;
Vol. 2, p 207.
(10) (a) Cacchi, S.; Fabrizi, G. Chem. ReV. 2005, 105, 2873. (b)
Humphrey, G. R.; Luethe, J. T. Chem. ReV. 2006, 106, 2875.
Scheme 2
(11) (a) Chan, T. H.; Wong, L. T. L. Can. J. Chem. 1971, 49, 530. (b)
Collins, D. J.; Rowley, L. E.; Swan, J. M. Aust. J. Chem. 1974, 27, 831.
(c) Winter, W. Tetrahedron Lett. 1975, 16, 3913. (d) Holah, D. G. H.; Alan,
N. H.; Daniel, K. J. Heterocycl. Chem. 1977, 14, 705. (e) Balthazor, T. M.
J. Org. Chem. 1980, 45, 2519. (f) Nief, F.; Charrier, C.; Mathey, F.; Simalty,
M. NouVeau J. Chim. 1981, 5, 187. (g) Nief, F.; Charrier, C.; Mathey, F.;
Simalty, M. Phosphorus Sulfur 1982, 13, 259. (h) Butters, T.; Winter, W.
Chem. Ber. 1984, 117, 990. (i) Quin, L. D.; Rao, N. S.; Topping, R. J.;
McPhail, A. T. J. Am. Chem. Soc. 1986, 108, 4519. (j) Ma¨rkl, G.; Jin, G. Y.;
Berr, K.-P. Tetrahedron Lett. 1993, 34, 3103. (k) Kurita, J.; Ishii, M.;
Yasuike, S.; Tsuchiya, T. J. Chem. Soc., Chem. Commun. 1993, 1309. (l)
Deckn, A.; Bottomley, F.; Wilkins, B. E.; Grill, E. D. Organometallics 2004,
23, 3683. (m) Cordaro, J. G.; Stein, D.; Gru¨tzmacher, H. J. Am. Chem.
Soc. 2006, 128, 14962.
(12) The synthesis of benzo[c]phosphole has also been reported: (a)
Chan, T. H.; Nwe, K. T. Tetrahedron Lett. 1973, 48, 4815. (b) Chan, T. H.;
Nwe, K. T. Tetrahedron 1975, 31, 2537. (c) Schmidpeter, A.; Thiele, M.
Angew. Chem., Int. Ed. Engl. 1991, 30, 308. (d) Miyajima, T.; Matano, Y.;
Imahori, H. Eur. J. Org. Chem. 2008, 255.
(13) Recent examples for extended fused π-conjugated compounds: (a)
Takimiya, K.; Ebata, H.; Sakamoto, K.; Uzawa, T.; Otsubo, T.; Kunugi,
Y. J. Am. Chem. Soc. 2006, 128, 12604. (b) Ebata, H.; Miyazaki, E.;
Yamamoto, T.; Takimiya, K. Org. Lett. 2007, 9, 4499. (c) Oyaizu, K.;
Iwasaki, T.; Tsukahara, Y.; Tsuchida, E. Macromolecules 2004, 37, 1257.
(d) Yamaguchi, S.; Xu, C.; Tamao, K. J. Am. Chem. Soc. 2003, 125, 13662.
(e) Xu, C.; Wakamiya, A.; Yamaguchi, S. Org. Lett. 2004, 6, 3707. (f)
Boudreault, P.-L. T.; Wakim, S.; Blouin, N.; Simard, M.; Tessier, C.;
Leclerc, M. J. Am. Chem. Soc. 2007, 129, 9125. (g) Tsuji, H.; Mitsui, C.;
Illies, L.; Sato, Y.; Nakamura, E. J. Am. Chem. Soc. 2007, 129, 11902. (h)
Gao, J.; Li, R.; Li, L.; Meng, Q.; Jiang, H.; Li, H.; Hu, W. AdV. Mater.
2007, 19, 3008. (i) Kawaguchi, K.; Nakano, K.; Nozaki, K. J. Org. Chem.
2690
Org. Lett., Vol. 10, No. 13, 2008

Scheme 3
Figure 1. ORTEP drawing of 5-cis (major isomer).
