Lower rim 1,3-di{bis(2-picolyl)}amide derivative of calix[4]arene (L) as ratiometric primary sensor toward Ag+ and the complex of Ag + as secondary sensor toward cys: Experimental, computational, and microscopy studies and INHIBIT logic gate properties of L

Article abstract of DOI:10.1021/jo901676s

(Figure Presented) Astructurally characterized lower rim 1,3-di{bis(2-picolyl)}amide derivative of calix[4]arene (L) exhibits high selectivity toward Ag⁺ by forming a 1:1 complex, among nine other biologically important metal ions, viz., Na⁺, K⁺, Mg ²⁺, Ca²⁺, Mn²⁺, Fe²⁺, Co ²⁺, Ni²⁺, and Zn²⁺, as studied by fluorescence, absorption, and ¹H NMR spectroscopy. The 1:1 complex formed between L and Ag⁺ has been further proven on the basis of ESI mass spectrometry and has been shown to have an association constant, K_a, of 11117 ± 190 M^-1 based on fluorescence data. L acts as a primary ratiometric sensor toward Ag⁺ by switch-on fluorescence and exhibits a lowest detectable concentration of 450 ppb. DFT computational studies carried out in mimicking the formation of a 1:1 complex between L and Ag ⁺ resulted in a tetrahedral complex wherein the nitrogens of all four pyridyl moieties present on both arms are being coordinated. Whereas these pyridyls are located farther apart in the crystal structure, appropriate dihedral changes are induced in the arms in the presence of silver ion in order to form a coordination complex. Even the nanostructural features obtained in TEM clearly differentiates L from its Ag⁺ complex. The in situ prepared silver complex of L detects Cys ratiometrically among the naturally occurring amino acids to a lowest concentration of 514 ppb by releasing L from the complex followed by formation of the cysteine complex of Ag⁺. These were demonstrated on the basis of emission, absorption, ¹H NMR, and ESI mass spectra. The INH logic gate has also been generated by choosing Ag ⁺ and Cys as input and by monitoring the output signal at 445 nm that originates from the excimer emission of L in the presence of Ag⁺. Thus L is a potential primary sensor toward Ag⁺and is a secondary sensor toward Cys. 2009 American Chemical Society.

Full text of DOI:10.1021/jo901676s

pubs.acs.org/joc
Lower Rim 1,3-Di{bis(2-picolyl)}amide Derivative of Calix[4]arene (L) as
Ratiometric Primary Sensor toward Ag+ and the Complex of Ag+ as
Secondary Sensor toward Cys: Experimental, Computational, and
Microscopy Studies and INHIBIT Logic Gate Properties of L‡
Roymon Joseph, Balaji Ramanujam, Amitabha Acharya, and Chebrolu P. Rao*
Bioinorganic Laboratory, Department of Chemistry, Indian Institute of Technology Bombay,
Mumbai 400 076, India
cprao@iitb.ac.in
Received July 31, 2009
A structurally characterized lower rim 1,3-di{bis(2-picolyl)}amide derivative of calix[4]arene (L) exhibits
high selectivity toward Ag+ by forming a 1:1 complex, among nine other biologically important metal
ions, viz., Na+, K+, Mg2+, Ca2+, Mn2+, Fe2+, Co2+, Ni2+, and Zn2+, as studied by fluorescence,
absorption, and 1H NMR spectroscopy. The 1:1 complex formed between L and Ag+ has been further
proven on the basis of ESI mass spectrometry and has been shown to have an association constant, Ka, of
11117 ( 190 M-1 based on fluorescence data. L acts as a primary ratiometric sensor toward Ag+ by
switch-on fluorescence and exhibits a lowest detectable concentration of 450 ppb. DFT computational
studies carried out in mimicking the formation of a 1:1 complex between L and Ag+ resulted in a
tetrahedral complex wherein the nitrogens of all four pyridyl moieties present on both arms are being
coordinated. Whereas these pyridyls are located farther apart in the crystal structure, appropriate
dihedral changes are induced in the arms in the presence of silver ion in order to form a coordination
complex. Even the nanostructural features obtained in TEM clearly differentiates L from its Ag+
complex. The in situ prepared silver complex of L detects Cys ratiometrically among the naturally
occurring amino acids to a lowest concentration of 514 ppb by releasing L from the complex followed by
formation of the cysteine complex of Ag+. These were demonstrated on the basis of emission, absorption,
1H NMR, andESI mass spectra. TheINH logicgate has also been generated by choosing Ag+ and Cys as
input and by monitoring the output signal at 445 nm that originates from the excimer emission of L in the
presence of Ag+. Thus L is a potential primary sensor toward Ag+ and is a secondary sensor toward Cys.
Introduction
enzymes, where Ag+ and Cys are not exceptions. Though
the Ag+ is not a biologically essential element, its complexes
are used in medicine and agriculture.1 The antimicrobial
Recognition of metal ions and amino acids are of prime
interest in the context of metalloproteins and metallo-
(1) (a) Jung, W. K.; Koo, H. C.; Kim, K. W.; Shin, S.; Kim, S. H.; Park,
Y. H. Appl. Environ. Microbiol. 2008, 74, 2171. (b) Silver, S.; Phung, L. T.;
Silver, G. J. Ind. Microbiol. Biotechnol. 2006, 33, 627.
‡ Dedicated to Professor Padmanabhan Balaram on the occasion of his 60th
birthday.
DOI: 10.1021/jo901676s
r
Published on Web 10/09/2009
J. Org. Chem. 2009, 74, 8181–8190 8181
2009 American Chemical Society

Joseph et al.
JOCArticle
action of silver mainly takes place through its interactions
with sulfur in the case of amino acids and peptides,2 and Ag+
ions are inactive toward other amino acids. A side effect of
silver originating from its prolonged use is irreversible
darkening of the skin and mucous membrane.3 Accumula-
tion of silver by microbial species could also act as a source
for this element.4 Among the 20 naturally occurring amino
acids, Cys plays an important role in living cells.5 Both the
deficiency and excess accumulation of Cys are detrimental to
life.6 Therefore, the detection and sensing of silver and Cys,
by a single molecular system with dual functionality, are
certainly challenging and are intriguing to the current re-
searchers. Owing to the ubiquitous nature of calix[4]arenes7
by possessing hydrophilic and hydrophobic characters to-
gether in the same structure, these molecules can act as good
mimics of enzymes8 and also provide a suitable platform for
building appropriate binding cores. There are some reports
in the literature for the selective recognition of silver either by
recognition by calix[4]arene derivatives is rather limited, and
the recognitions were mainly carried out by mass spectro-
scopy,12 calorimetry,13 1H NMR studies,13b,c,14 and HPLC;15
detection by fluorescence spectroscopy16 is scarce. Coleman
et al. reported several p-sulfonatocalix[4]arenes for amino
acid recognition and were able to establish the structure of
these calixarene amino acid complexes even in the solid
state.17 There are few reports available in the literature in
which amino acid recognition was achieved by chemo sen-
sing ensemble.12b,18 Though there are several receptors to
recognize Agþ and Cys individually, to the best of our
knowledge, there has been no report of any calix[4]arene
molecular system that would detect selectively Agþ followed
by Cys by acting as primary as well as secondary sensor. Thus
the present paper reports the synthesis, characterization, and
ratiometric silver-sensing properties of a lower rim functio-
nalized calix[4]arene possessing dipicolyl moiety connected
through an amide linkage (L) and the recognition of Cys by
the corresponding silver complex. Thus L acts as a primary
sensor toward Agþ and as a secondary sensor toward Cys
and thereby exhibits INH logic gate properties. The sensor
property of L toward Agþ has been proven to be due to the
formation of the complex on the basis of different experi-
mental and computational studies. Experimental evidence
has also been provided for the release of L from the reaction
of Cys with the silver complex.
1
potentiometry,9 by H NMR,10 or by fluorescence techni-
que11 using calix[4]arene derivatives. Similarly, amino acid
(2) Mcdonnell, G.; Russell, D. A. Clin. Microbiol. Rev. 1999, 12, 147.
(3) (a) Butkus, M. A.; Labare, M. P.; Starke, J. A.; Moon, K.; Talbot, M.
Appl. Environ. Microbiol. 2004, 70, 2848. (b) Petering, H. G. Pharmaolc.
Ther. A 1976, 1, 127. (c) Russell, A. D.; Hugo, W. B. Prog. Med. Chem. 1994,
31, 351.
(4) Slawson, R. M.; Van Dyke, M. I.; Lee, H.; Trevors, J. T. Plasmid 1992,
27, 72.
Results and Discussion
(5) (a) Ball, R. O.; Courtney-Martin, G.; Pencharz, P. B. J. Nutr. 2006,
136, 1682S. (b) Griffith, W. Method Enzymol. 1987, 143, 366.
(6) (a) Shahrokhian, S. Anal. Chem. 2001, 73, 5972. (b) Heafield, M. T.;
Fearn, S.; Steventon, G. B.; Waring, R. H.; Williams, A. C.; Sturman, S. G.
Neurosci. Lett. 1990, 110, 216. (c) Puka-Sundvall, M.; Eriksson, P.; Nilsson,
M.; Sandberg, M.; Lehmann, A. Brain Res. 1995, 705, 65.
Receptor Molecule L. The receptor molecule, L, has been
synthesized by four known steps starting from p-tert-butyl
calix[4]arene as given in Scheme 1,19 (see also Experimental
Section). The acid chloride derivative 4 was prepared by
reacting 3 with SOCl2, followed by coupling with bis(2-picolyl)-
amine to result in the receptor molecule, L. All of these
molecules including L were characterized satisfactorily by 1H
NMR, 13C NMR, ESI MS, FTIR, and elemental analysis. The
(7) (a) Gutsche, C. D. Acc. Chem. Res. 1983, 16, 161. (b) Shinkai, S.
Tetrahedron 1993, 49, 8933.
(8) (a) Izzet, G.; Douziech, B.; Prange, T.; Tomas, A.; Jabin, I.; Mest,
Y. L.; Reinaud, O. Proc. Natl. Acad. Sci. U.S.A. 2005, 102, 6831.
(b) Rondelez, Y.; Bertho, G.; Reinaud, O. Angew. Chem., Int. Ed. 2002,
41, 1044. (c) Cacciapaglia, R.; Casnati, A.; Mandolini, L.; Reinhoudt, D. N.;
Salvio, R.; Sartori, A.; Ungaro, R. J. Am. Chem. Soc. 2006, 128, 12322.
(d) Molenveld, P.; Engbersen, J. F. J.; Reinhoudt, D. N. J. Org. Chem. 1999,
64, 6337. (e) Molenveld, P.; Stikvoort, W. M. G.; Kooijman, H.; Spek, A. L.;
Engbersen, J. F. J.; Reinhoudt, D. N. J. Org. Chem. 1999, 64, 3896.
(f) Molenveld, P.; Engbersen, J. F. J.; Reinhoudt, D. N. Angew. Chem.,
Int. Ed. 1999, 38, 3189.
(9) (a) Kumar, M.; Mahajan, R. K.; Sharma, V.; Singh, H.; Sharma, N.;
Kaur, I. Tetrahedron Lett. 2001, 42, 5315. (b) Zeng, X.; Weng, L.; Chen, L.;
Leng, X.; Zhang, Z.; He, X. Tetrahedron Lett. 2000, 41, 4917. (c) Zeng, X.;
Weng, L.; Chen, L.; Leng, X.; Ju, H.; He, X.; Zhang, Z.-Z. J. Chem. Soc.,
Perkin Trans. 2 2001, 545.
1
