84 RESEARCH PAPER
FEBRUARY, 84–86
JOURNAL OF CHEMICAL RESEARCH 2011
Synthesis of 6,8-diarylimino-7H-pyrano[3,2-c:5,6-c’]dicoumarins;
chemoselective hydrolysis of the ether- and imino-functions
Sourav Maiti, Suman Kalyan Panja and Chandrakanta Bandyopadhyay*
Department of Chemistry, R. K. Mission Vivekananda Centenary College, Rahara, Kolkata -700 118, West Bengal, India
POCl3-induced dehydration of 3,3′-methylenedi(2-arylamino-4H-chromen-4-ones) gives 6,8-diarylimino-7H-
pyrano[3,2-c:5,6-c’]dicoumarins, which undergo chemoselective hydrolysis of the imino function to form 7H-
pyrano[3,2-c:5,6-c’]dicoumarins by heating with HCl in methanol However, cleavage of the ether function occurs
upon heating in acetic acid to give 3,3′-methylenedi(2-arylamino-4H-chromen-4-ones).
Keywords: 2-aminochromone-3-carbaldehyde, coumarin, iminocoumarin, bischromone, 1-benzopyran, phosphorous
oxychloride
Iminocoumarins are an important class of compounds for a
variety of applications. Besides their antimicrobial activity,1
some iminocoumarin dyes act as photosensitisers for dye-
sensitised solar cells.2 Iminocoumarin-based zinc-sensors have
been developed, which are suitable for ratiometric fluores-
cence imaging of neuronal zinc.3 Recently, iminocoumarin-
based fluorescent probes have been developed for the selective
detection of dual specific protein-tyrosine phosphatases.4
Although derivatives of 3,3′-methylene-di(4-hydroxycou-
marin) (commonly known as dicoumarols) have been synthe-
sised readily from 4-hydroxycoumarin and an appropriate
aldehyde under various conditions,5 the corresponding di-
iminocoumarins are scarce in the literature. Iminocoumarins
are generally synthesised from salicylaldehyde by the action of
cyanoacetamide,1 malononitrile or ethyl cyanoacetate.6 They
have also been obtained by a Cu-catalysed multicomponent
reaction of o-hydroxyacetophenone, an appropriate alkyne and
an alkanesulfonyl azide.7
the synthesis of 3,3′-methylenedi(2-arylamino-4H-chromen-
4-ones) 2 by heating 2-arylaminochromone-3-carbaldehydes 1
with secondary amines such as sarcosine, piperidine or
diethylamine in the presence of formalin in DMF (Scheme 1).
We now report the synthesis of 6,8-diarylimino-7H-pyrano
[3,2-c:5,6-c′]dicoumarins 3 and their conversion into the
corresponding dicoumarins 4 which belong to the class of
nonpeptidic HIV protease inhibitors.10
On heating dichromones 2 in POCl3 at 60–80 °C for 5–6 h
subsequent work-up produced diiminocoumarins 3 in moder-
ate yields. The structure of the compounds was established on
1
the basis of IR, H and 13C NMR and mass spectral analyses.
Formation of 3 may be rationalised by considering the initial
attack of the vinylogous amide moiety in 2 on POCl3 to pro-
duce 5 which cyclises readily by the involvement of the second
vinylogus amide group (Scheme 1).
In an attempt to convert the central pyran ring in 3 into a
pyridine ring, compound 3a was heated with urea in AcOH for
1 h. But surprisingly, compound 3a only gave 2a. The same
reaction took place when 3 was heated with ammonium acetate
In continuation of our studies on the deformylative Mannich
reaction on chromone-3-carbaldehyde,8 we have reported9
Scheme 1
* Correspondent. E-mail: kantachandra@rediffmail.com

JOURNAL OF CHEMICAL RESEARCH 2011 85
Table 1 Chemoselective hydrolysis of 3 under different con-
266–268 °C; IR: νmax 3029, 1676, 1643, 1584 cm−1; 1H NMR:
δ (CDCl3) 2.39 (6 H, s, 2 × CH3), 3.42 (2 H, s, CH2), 6.91 (2 H, br. d,
J = 7.2 Hz, ArH), 7.10–7.16 (2 H, m, ArH), 7.21–7.24 (4 H, m, ArH),
7.28–7.39 (6 H, m, ArH), 7.50 (2 H, br. s, 1-H + 13-H); 13C NMR:
δ 20.4, 21.0, 105.0, 114.5, 115.6, 121.3, 123.3, 123.6, 128.3, 128.5,
133.2, 146.5, 147.9, 148.6, 150.6; MS (Positive ion electrospray): m/z
497 [M+H]+, 519 [M+Na]+. Anal. Calcd for C33H24N2O3: C, 79.82;
H, 4.87; N, 5.64. Found: C, 79.53; H, 4.79; N, 5.56%.
6,8-Di(N-phenylimino)-7H-pyrano[3,2-c:5,6-c′]dicoumarin (3b):
Pale yellow crystalline solid (295 mg, 63%); m.p. > 320 °C; IR: νmax
3010, 1680, 1650, 1560 cm−1; 1H NMR: δ (CDCl3) 3.62 (2 H, s, CH2),
7.10–7.15 (4 H, m, ArH), 7.19–7.29 (6 H, m, ArH), 7.31–7.47 (6 H, m,
ArH), 7.87 (2 H, br. d, J = 7.8 Hz, 1-H + 13-H); MS (Positive ion
electrospray): m/z 469 [M+H]+, 491 [M+Na]+. Anal. Calcd for
C31H20N2O3: C, 79.47; H, 4.30; N, 5.98. Found: C, 79.33; H, 4.22; N,
5.90%.
ditions
Entry R1
R2 Method Product
Yield / % M.p./ °C
(lit. M.p./ °C)
1
2
H
H
Ph
Ph
A
B
2b
4b
80
70
300–302
(300–302) 9
322–324
(321–323)11
314–316
322–324
268–270
(268–270) 9
>325
3
4
5
H
H
Ara
Ar
A
B
A
2c
4b
2a
78
72
77
Me Ph
6
7
Me Ph
Me Ar
B
A
4a
2d
66
77
304–306
(304–306) 9
>325
8
Me Ar
B
4a
70
6,8-Di[N-(4-methylphenyl)imino]-7H-pyrano[3,2-c:5,6-c′]dicou-
marin (3c): Pale yellow fine crystalline solid (225 mg, 45%);
aAr = 4-MeC6H4.
Method A: AcOH, reflux, 30 min.
1
m.p. 252–254 °C; IR: νmax 3014, 1672, 1640, 1570 cm−1; H NMR:
Method B: HCl/MeOH, reflux, 30 min.
δ (CDCl3) 2.37 (6 H, s, 2 × CH3), 3.57 (2 H, s, CH2), 7.12 (2 H, br. d,
J = 8.1 Hz, 4-H + 10-H), 7.13–7.19 (6 H, m, ArH), 7.23–7.28 (4 H, m,
ArH), 7.39–7.44 (2 H, m, 3-H + 11-H), 7.82 (2 H, br. d, J = 7.5 Hz,
1-H + 13-H); 13C NMR: 20.4, 21.0, 105.1, 114.8, 115.9, 121.4, 123.2,
123.5, 129.2, 130.9, 133.2, 143.5, 147.7, 148.2, 152.4. Anal. Calcd
for C33H24N2O3: C, 79.82; H, 4.87; N, 5.64. Found: C, 79.69; H, 4.80;
N, 5.50%.
in acetic acid or with thiourea in acetic acid. It appeared to be
a case of acid-catalysed hydrolysis of the central pyran ring
and AcOH was supposed to be responsible for this reversion.
Indeed, compound 3 gave 2 in good yields when heated in
glacial AcOH for only 0.5 h (Scheme 1, Method A) (Table 1,
entries 1, 3, 5 and 7).
2,12-Dimethyl-6,8-di[N-(4-methylphenyl)imino]-7H-pyrano[3,2-
c:5,6-c′]dicoumarin (3d): Yellow fine crystalline solid (245 mg,
1
47%); m.p. 280–282 °C; IR: νmax 3000, 1680, 1640, 1590 cm−1; H
Regarding the synthesis of 7H-pyrano[3,2-c:5,6-c′]
dicoumarins 4, an earlier report revealed that dicoumarol
cyclises to 4 on treatment with (PhO)2POCl/pyridine or KHSO4
or P/I2.11 Dicoumarols derived from 4-hydroxycoumarin and
an aldehyde other than formaldehyde can be cyclised to 4
(having a substituent at its 7-position) by pyridine-acetic
anhydride.12 Diglucosides of dicoumarol also produce 4 and
glucose when treated with Ba(OCH3)2 in methanol.13 All these
methods have shortcomings due to harsh reaction conditions,
tedious work-up or poor yields. The synthesis of 3 gave us
an impetus to check whether 4 can be obtained from 3 by
chemoselective hydrolysis. In compound 3, the arylimino
functions and the ether linkage are susceptible towards hydro-
lysis. The ether function was found to hydrolyse selectively by
heating in acetic acid (Table 1, entries 1, 3, 5 and 7). To hydro-
lyse the arylimino function, mineral acid was considered.
Indeed, compound 4 was obtained in good yield by heating 3
in methanol in the presence of HCl (Scheme 1, Method B)
(Table 1, entries 2, 4, 6 and 8).
NMR: δ (CDCl3) 2.36 (6 H, s, 2 × CH3), 2.46 (6 H, s, 2 × CH3), 3.55
(2 H, s, CH2), 7.01 (2 H, d, J = 8.4 Hz, 4-H + 10-H), 7.16–7.19 (8 H,
m, ArH), 7.21 (2 H, br. d, J = 8.4 Hz, 3-H + 11-H), 7.59 (2 H, br. s,
1-H + 13-H). Anal. Calcd for C35H28N2O3: C, 80.13; H, 5.38; N, 5.34.
Found: C, 79.95; H, 5.28; N, 5.26%.
Synthesis of 7H-pyrano[3,2-c:5,6-c′]dicoumarins 4 by hydrolysis of
3
Four drops of conc. HCl were added to a methanolic suspension
(25 mL) of 3 (1 mmol), at room temperature whereupon an orange-
yellow coloured, clear solution was formed. The resultant solution
was heated under reflux for 0.5 h; a white solid separated. The product
was filtered whilst hot, washed with methanol and crystallised from
benzene-light petroleum (2:1) to afford 4 in good yield. Compounds
3a and 3d produced the same compound, 4a in 66 and 70% yields,
respectively; similarly compounds 3b and 3c produced 4b in 70 and
72% yields, respectively.
2,12-Dimethyl-7H-pyrano[3,2-c:5,6-c′]dicoumarin (4a): White
crystalline solid (250 mg, 72%); m.p. > 325 °C; νmax 2987, 2910, 1725,
1
1630, 1590 cm−1; H NMR: δ (CDCl3) 2.55 (6 H, s, 2 × CH3), 3.57
(2 H, s, CH2), 7.31 (2 H, d, J = 7.8 Hz, 4-H + 10-H), 7.44 (2 H, br. d,
J = 7.8 Hz, 3-H + 11-H), 7.73 (2 H, br. s, 1-H + 13-H); MS (Positive
ion electrospray): m/z 347 [M+H]+, 369 [M+Na]+. Anal. Calcd for
C21H14O5: C, 72.83; H, 4.07. Found: C, 72.66; H, 3.98%.
In conclusion, we have achieved an easy route for the syn-
thesis of 6,8-diarylimino-7H-pyrano[3,2-c:5,6-c′]dicoumarins
3 and their chemoselective hydrolysis to 3,3′-methylenedi
7H-Pyrano[3,2-c:5,6-c′]dicoumarin (4b): White crystalline solid
(250 mg, 78%); m.p 322–324 °C (lit11 m.p. 321–323 °C); νmax 3060,
2924, 1724, 1619, 1586 cm−1; 1H NMR: δ (CDCl3) 3.61 (2 H, s, CH2),
7.38–7.48 (4 H, m, ArH), 7.61–7.69 (2 H, m, 3-H + 11-H), 7.99 (2 H,
dd, J = 7.8, 1.5 Hz, 1-H + 13-H); 13C NMR: 18.5, 102.1, 113.3, 117.2,
122.1, 124.6, 132.7, 152.5, 154.2, 179.6. Anal. Calcd for C19H10O5:
C, 71.70; H, 3.17. Found: C, 71.58; H, 3.25%.
(2-arylamino-4H-chromen-4-ones)
c:5,6-c′]dicoumarins 4.
2 and 7H-pyrano[3,2-
Experimental
The recorded melting points are uncorrected. IR spectra were recorded
in KBr on a Beckman IR 20A spectrophotometer. H and 13C NMR
1
spectra were obtained on a Bruker spectrometer at 300 MHz and
75 MHz respectively. Mass spectra were recorded on a Qtof Micro
YA 263 instrument and elemental analysis on a Perkin Elmer 240c
elemental analyser. Light petroleum refers to the fraction with b.p.
60–80 °C. All chemicals used were of commercial grade and were
used as such.
Hydrolysis of 3 to produce 2
Compound 3 (1 mmol) was heated in glacial acetic acid (15 mL) for
0.5 h under reflux. On cooling, the reaction mixture afforded a white
solid. The precipitated solid was filtered off, washed with methanol,
dried in air and crystallised from benzene-petroleum ether (10:1) to
afford 2a–d, which were found to be identical in all respects with the
corresponding compounds 2 from which compound 3 was obtained by
treatment with POCl3.
Reaction of dichromone 2 with POCl3; general procedure
Dichromone 2 (1 mmol) was heated with POCl3 (10 mL) in an oil bath
at 60–80 °C for 5–6 h. The reaction mixture was cooled to room tem-
perature and poured into crushed ice (100 g). The separated solid
was filtered, washed with water, dried in air and crystallised from
benzene-light petroleum (6:1) to afford 3.
2,12-Dimethyl-6,8-di(N-phenylimino)-7H-pyrano[3,2-c:5,6-c′]
dicoumarin (3a): Pale yellow crystalline solid (285 mg, 57%); m.p.
We gratefully acknowledge CSIR, New Delhi [project no.
01(2206)/07/EMR-II] for financial assistance; IICB, Jadavpur
for spectral analysis and finally the college authority for
providing research facilities.

86 JOURNAL OF CHEMICAL RESEARCH 2011
5
6
W.R. Sullivan, C.F. Huebner, M.A. Stahmann and K.P. Link, J. Am. Chem.
Soc., 1943, 65, 2288.
J. Volmajer, R. Toplak, S. Bittner, I. Leban and A.M. Le Marechal,
Tetrahedron Lett., 2003, 44, 2363.
Received 21 September 2010; accepted 2 December 2010
Paper 1000367 doi: 10.3184/174751911X12964930076485
Published online: 10 February 2011
7
8
S.-L. Cui, X.-F. Lin and Y.-G. Wang, Org. Lett., 2006, 8, 4517.
S.K. Panja, S. Maiti, M.G.B. Drew and C. Bandyopadhyay, Tetrahedron,
2009, 65, 1276.
9
S. Maiti, S.K. Panja, and C. Bandyopadhyay, Tetrahedron Lett., 2009, 50,
3966.
References
1
2
3
4
S.V. Ukhov, M.E. Kon′shin and T.F. Odegova, Pharm. Chem. J., 2001, 35,
364.
V. Kandavelu, H.-S. Huang, J.-L. Jian, T.C.-K. Yang, K.-L. Wang and S.-T.
Huang, Solar Energy, 2009, 83, 574.
K. Komatsu,Y. Urano, H. Kojima and T. Nagano, J. Am. Chem. Soc., 2007,
129, 13447.
T.-I. Kim, M.S. Jeong, S.J. Chung and Y. Kim, Chem. Eur. J., 2010, 16,
5297.
10 A.K. Mitra, A. De, N. Karchaudhuri, S.K. Misra and A.K. Mukhopadhyay,
J. Ind. Chem. Soc., 1998, 75, 666.
11 C.F. Huebner, W.R. Sullivan, M.A. Stahmann and K.P. Link, J. Am. Chem.
Soc., 1943, 65, 2292.
12 M.A. Stahmann, L.H. Graf, C.F. Huebner, S. Roseman and K.P. Link,
J. Am. Chem. Soc., 1944, 66, 900.
13 C.F. Huebner, S.A. Karjala, W.R. Sullivan and K.P. Link, J. Am. Chem.
Soc., 1944, 66, 906.

Copyright of Journal of Chemical Research is the property of Science Reviews 2000 Ltd. and its content may
not be copied or emailed to multiple sites or posted to a listserv without the copyright holder's express written
permission. However, users may print, download, or email articles for individual use.
