A.E.M. Crotti, et al.
InorganicaChimicaActa508(2020)119654
C7H7Br]+, 32.
Compound
2
(4-bromo-N,N,N-trimethyl-benzeneaminium hexa-
fluorophosphate) was synthesized according to the literature [36] with
some modifications (Scheme 2). To a 250 mL sealed round-bottom
flask, 4-bromo-N,N-dimethyl-aminebenzene (3082 g, 15.4 mmol),
acetone (100 mL), and methyl iodide (2.8 mL, 6.384 g, 44.9 mmol)
were added. The reaction was stirred overnight at 70 °C under a ni-
trogen atmosphere. The reaction mixture was filtered under reduced
pressure and the collected solid washed with ice-cold acetone and dried
under vacuum overnight to afford compound II [4-Br(C4H6)NMe3][I]
(4.616 g, yield 88%) as a white fluffy solid. A salt metathesis was
performed with NaPF6 mixing a saturated aqueous solution of II
(4.052 g, 11.8 mmol) with a saturated aqueous solution of NaPF6 and
stirring for 30 min to give product 2 [4-Br(C6H4)NMe3][PF6] (1.962 g,
yield 46%). 1H NMR (300 MHz, DMSO‑d6): δ (ppm): 7.95 (d, 2H,
J = 8.6 Hz), 7.85 (d, 2H, J = 8.6 Hz), 3.59 (s, 9H). 13C NMR (75 MHz,
DMSO‑d6): δ (ppm): 146.6 (C), 132.7 (CH), 122.8 (CH), 122.0 (C), 56.4
(CH3). LR-ESI-MS/MS (m/z, % rel. int.): 214.2 [M]+, 30; 199.2 [M –
Me]+, 100; 198.3 [M – CH4]+, 80.
Compound 3 (trans-3-(p-benzyl-4-phenyl-3-methoxycarbonyl-γ-bu-
tyrolactone) was synthesized as previously reported by Le Floch and co-
workers (Scheme 2) [33]. Briefly, zinc dust (3.0 g, 46 mmol) was added
to a dried 100-mL round-bottomed flask previously flushed with argon
and charged with acetonitrile (20 mL). Dimethyl itaconate (7.9 g,
50 mmol), benzaldehyde (1.0 mL, 10 mmol), and an aryl bromide
(15 mmol; bromobenzene, 2.35 g, 1.57 mL for compound 3) were
added whilst stirring. Next, cobalt bromide (0.44 g, 2 mmol), tri-
fluoroacetic acid (0.1 mL), and 1,2-dibromoethane (0.2 mL) were added
successively to the mixture, which was heated to 60 °C for 2 h. The
reaction mixture was filtered through Celite, which was exhaustively
washed with diethyl ether. The combined organic fractions were con-
centrated in vacuo. The resulting crude reaction product was purified
by flash column chromatography over silica gel (hexane:ethyl acetate
7:3 v/v) to provide a mixture of stereoisomers of the γ–lactone 3
(1.086 g, 35% yield) as a white powder. 1H NMR (300 MHz, CDCl3): δ
(ppm) 7.45 (2H, m, H-11 and H-17), 7.43 (2H, m, H-16 and H-18), 7.35
(2H, m, H-15 and H-19), 7.23 (2H, m, H-10 and H-12), 6.95 (2H, m, H-9
and H-13), 5.67 (1H, s, H-4), 3.75 (3H, s, H-6), 3.12 (1H, d,
J2b,2a = 17.6, H-2b), 2.86 (1H, d, J7b,7a = 13.9, H-7b), 2.71 (1H, d,
J2a,2b = 17.6, H-2a), 2.17 (1H, d, J7a,7b = 13.9, H-7a); 13C NMR
(75 MHz, CDCl3): δ (ppm) 174.5 (C, C-1), 173.0 (C, C-5), 135.7 (C, C-8),
134.3 (C, C-14), 129.5 (CH, C-9 = C-13), 129.1 (CH, C-11 = C-17),
128.5 (CH, C-16 = C-18), 127.3 (CH, C-10 = C-12), 126.5 (CH, C-
15 = C-19), 85.7 (CH, C-4), 56.3 (C, C-3), 52.9 (CH3, C-6), 39.0 (CH2,
C-7), 35.6 (CH2, C-2); ESI-MS/MS m/z (% rel. int.) 311 [M + H]+, 15;
293 [M + H-H2O]+, 10; 279 [M + H-MeOH]+, 50; 251 [M + H-
MeOH-CO]+, 10; 261 [M + H-H2O-MeOH]+, 80; 233 [M + H-H2O-
C2H4O2]+, 100.
Scheme 1. Mediated-cobalt synthesis of 2,3-di- and 2,2,3-trisubstituted-3-
methoxycarbonyl-γ-lactones [33].
successfully used to characterize the intermediates of several MCRs,
such as the Mannich reaction [28], the Hantzsch reaction [28,29], the
Ugi reaction [4], the Petasis Borono-Mannich reaction [30], the Bigi-
In this paper, the potential of PSI-ESI-MS to investigate MCR me-
chanisms of heterogeneous catalytic systems was explored. For this
purpose, we have chosen as a model the like-Barbier cobalt-mediated
one-pot transition metal-catalyzed MCR (Scheme 1), which was first
reported by Le Floch and co-workers for the synthesis of 2,3-di- and
2,2,3-trisubstituted-3-methoxycarbonyl-γ-lactones and related com-
2. Experimental section
2.1. Chemicals
Solvents and chemicals were purchased from Sigma-Aldrich. THF
was HPLC grade, previously purified on a Grubbs-type (MBraun SPS-
800) solvent purification system. Acetone was purified by distillation
from potassium carbonate [34]. Acetonitrile was HPLC grade, purified
by distillation from calcium hydride [34]. Triethylamine was purified
by distillation from calcium hydride [34]. Deionized water was ob-
tained from a Millipore Milli-DI water purification system.
2.2. Nuclear magnetic resonance (NMR)
The 1H and 13C NMR spectra were recorded on a Bruker Avance
300 MHz spectrometer as solutions prepared in DMSO‑d6 or CDCl3.
NMR data were processed using Bruker TopSpin 3.6.0 software.
2.3. Synthesis of charge-tagged compounds 1 and 2 and γ-lactone 3
Compound
1
(4-bromo-N,N,N-triethyl-benzenemethanaminium
hexafluorophosphate) was synthesized according to the methodology
proposed by Roiser and co-workers [35] with some modifications
(Scheme 2). To a 250-mL screw-capped round-bottom flask, p-bromo-
benzyl bromide (3.060 g, 12.2 mmol), THF (100 mL), and triethylamine
(4.5 mL, 3.267 g, 32.3 mmol) were added. The resulting solution was
stirred at room temperature for 24 h, during which time the product
precipitated as a white fluffy solid. The mixture was cooled to 0 °C,
filtered under reduced pressure, and the collected solid dried under
vacuum to yield the benzyl ammonium salt I [4-Br(C6H4)CH2NEt3][Br]
(3.67 g, yield 85%) as a white fluffy solid. A salt metathesis was per-
formed with NaPF6 by mixing a saturated aqueous solution of I (3.54 g,
10 mmol) with a saturated aqueous solution of NaPF6 and stirring for
30 min, followed by filtration and dryness under vacuum to produce 1
[4-Br(C6H4)CH2NEt3][PF6] (2.727 g, yield 65%). 1H NMR (300 MHz,
DMSO‑d6): δ (ppm): 7.71 (d, 2H, J = 8.4 Hz), 7.47 (d, 2H, J = 8.4 Hz),
4.48 (br s, 2H), 3.15 (6H, 4, J = 7.4 Hz), 1.28 (9H, t, J = 7.4 Hz). 13C
NMR (75 MHz, DMSO‑d6): δ (ppm): 134.7 (CH), 131.9 (CH), 127.1 (C),
123.9 (C), 66.6 (CH2), 58.6 (CH2), 7.44 (CH3). LR-ESI-MS/MS (m/z, %
rel. int.): 270.3 [M]+, 36; 169.1 [M – NEt3]+, 100; 100.3 [M –
2.4. MCR monitoring by FTIR
Fourier transform-infrared (FTIR) experiments were performed on
Bruker Alpha FTIR in a Harrick demountable transmission flow cell
with BaF2 windows, a 100 μm path length and a 5 μL cell volume. Prior
to the MCR investigation, a series of benzaldehyde and γ-lactone 3
solutions in acetonitrile were prepared by two-fold serial dilution and a
calibration curve was plotted based on absorption bands at 1704 cm−1
and 1791 cm−1, respectively, which corresponding to their carbonyl
stretching. A background spectrum using acetonitrile was recorded
before running the experiments. Next, 100 µL aliquots were sampled
from the reaction mixture every 10 min, 15 min, or 30 min for 6 h. An
initial sample was also collected at 5 min. Acetonitrile was added to
these samples to make them up to 1 mL. The samples were filtered using
a Pasteur pipet with cotton, transferred to 3 mL vials and added to 1 mL
MeCN. Finally, a 10 µL aliquot of this sample was transferred to an
Eppendorf vial, diluted to 1 mL acetonitrile and then introduced onto
