Novel and modified neutrophil elastase inhibitor loaded in topical formulations for psoriasis management

Article abstract of DOI:10.3390/pharmaceutics12040358

Human neutrophil elastase (HNE) is a serine protease that degrades matrix proteins. An excess of HNE may trigger several pathological conditions, such as psoriasis. In this work, we aimed to synthesize, characterize and formulate new HNE inhibitors with a 4-oxo-β-lactam scaffold with less toxicity, as well as therapeutic index in a psoriasis context. HNE inhibitors with 4-oxo-β-lactam scaffolds were synthesized and characterized by NMR, FTIR, melting point, mass spectrometry and elemental analysis. In vitro cytotoxicity and serine protease assays were performed. The compound with the highest cell viability (AAN-16) was selected to be incorporated in an emulsion (AAN-16 E) and in a microemulsion (AAN-16 ME). Formulations were characterized in terms of organoleptic properties, pH, rheology, droplet size distribution, in vitro drug release and in vivo psoriatic activity. All compounds were successfully synthesized according to analytical methodology, with good yields. Both formulations presented suitable physicochemical properties. AAN-16 E presented the most promising therapeutic effects in a murine model of psoriasis. Overall, new HNE inhibitors were synthesized with high and selective activity and incorporated into topical emulsions with potential to treat psoriasis.

Full text of DOI:10.3390/pharmaceutics12040358

Article
Novel and Modified Neutrophil Elastase Inhibitor
Loaded in Topical Formulations for
Psoriasis Management
Andreia Nunes 1, Joana Marto 2,*, Lídia Maria Gonçalves 2, Sandra Simões 2, Rita Félix 2,
Andreia Ascenso 2, Francisca Lopes 2 and Helena Margarida Ribeiro 2,*
1
Faculty of Pharmacy, Universidade de Lisboa, 1649-003 Lisbon, Portugal; andreia.a.nunes@campus.ul.pt
2
Research Institute for Medicine (iMed.ULisboa), Faculty of Pharmacy, Universidade de Lisboa,
1649-003 Lisbon, Portugal; lgoncalves@ff.ulisboa.pt (L.M.G.); ssimoes@ff.ulisboa.pt (S.S.);
ritafelix@ff.ulisboa.pt (R.F.); andreiaascenso@ff.ulisboa.pt (A.A.); fclopes@ff.ulisboa.pt (F.L.)
* Correspondence: jmmarto@ff.ulisboa.pt (J.M.); hribeiro@campus.ul.pt (H.M.R.)
Received: 7 March 2020; Accepted: 10 April 2020; Published: 14 April 2020
Abstract: Human neutrophil elastase (HNE) is a serine protease that degrades matrix proteins. An
excess of HNE may trigger several pathological conditions, such as psoriasis. In this work, we aimed
to synthesize, characterize and formulate new HNE inhibitors with a 4-oxo-β-lactam scaffold with
less toxicity, as well as therapeutic index in a psoriasis context. HNE inhibitors with 4-oxo-β-lactam
scaffolds were synthesized and characterized by NMR, FTIR, melting point, mass spectrometry and
elemental analysis. In vitro cytotoxicity and serine protease assays were performed. The compound
with the highest cell viability (AAN-16) was selected to be incorporated in an emulsion (AAN-16 E)
and in a microemulsion (AAN-16 ME). Formulations were characterized in terms of organoleptic
properties, pH, rheology, droplet size distribution, in vitro drug release and in vivo psoriatic
activity. All compounds were successfully synthesized according to analytical methodology, with
good yields. Both formulations presented suitable physicochemical properties. AAN-16 E presented
the most promising therapeutic effects in a murine model of psoriasis. Overall, new HNE inhibitors
were synthesized with high and selective activity and incorporated into topical emulsions with
potential to treat psoriasis.
Keywords: human neutrophil elastase inhibitors; emulsions; microemulsions; psoriasis; topical
application
1. Introduction
Psoriasis is a chronic inflammatory skin disease that affects at least 100 million individuals
worldwide. It is characterized by red, scaly and erythematous plaques that can be scattered over the
entire surface of the body or on a specific area, including the scalp, nails and joints. Psoriasis is
considered a non-communicable disease with no cure, and it may progressively worsen with age,
depending on the degree of severity [1–3]. The causes of psoriasis are not totally understood, but its
pathogenesis is associated with genetic and epigenetic modifications that can be triggered by
environmental factors [2,4]. Neutrophil chemokines, such as CXCL1, CXCL2 and CXCL8/IL-8, are
usually present in psoriatic skin [5,6].
Despite the effort to find biologic drugs for the treatment of moderate to severe plaque type
psoriasis based on the imunopathogenesis of the disease, the current treatment of psoriasis is mostly
based on control of symptoms. Currently, phototherapy (ultraviolet light), systemic and topical
therapies using corticosteroids, vitamin D analogous, retinoids and dithranol are commonly used
[3,4,7]. Nevertheless, these therapies have numerous disadvantages. Therefore, it is extremely
Pharmaceutics 2020, 12, 358; doi:10.3390/pharmaceutics12040358
www.mdpi.com/journal/pharmaceutics

Pharmaceutics 2020, 12, 358
2 of 19
important to keep searching for new alternatives and discover new active compounds that may be
able to manage this disease.
Human neutrophil elastase (HNE) is a serine protease with a single polypeptide chain that
belongs to the elastase-like serine proteases subfamily, being stored and secreted from
polymorphonuclear neutrophils [8–11]. Its activity depends on a catalytic triad consisting of Ser195,
His57 and Asp102, which are all at the active site of the enzyme [10,12,13].
In terms of biological function, HNE has bactericidal, tissue preservative and restorative
properties. Moreover, HNE is also involved in inflammation. In a normal inflammatory process,
neutrophils release a high concentration of HNE to the extracellular medium, where this enzyme can
modulate the immune response through degradation of pro-inflammatory cytokines, reducing the
intensity of the inflammation [13–15]. However, if an imbalance between HNE and its endogenous
inhibitors occurs during this process, the extracellular HNE in excess can degrade structural proteins
of the extracellular matrix, like elastin, proteoglycan, collagen and fibronectin. Hereupon, the excess
of HNE may trigger several pathological conditions and tissue injuries inducing chronic
inflammatory diseases, such as psoriasis and cystic fibrosis, among others.
Accordingly, HNE is a valuable therapeutic target, and the design of new HNE inhibitors able
to modulate the proteolytic activity of HNE represents a promising approach for psoriasis, where
there is an excess in the production of this serine protease [12].
Under physiological conditions, endogenous HNE inhibitors tightly regulate their activity,
avoiding degradation of connective tissue proteins [12,14]. These inhibitors can belong to two
different families depending on their tissue location—the serpins and the chelonianins [14,16]—and
can be categorized into non-covalent and covalent inhibitors, as well as reversible or irreversible
inhibitors [10,17,18]. It is worthy pointing out that elafin, one of the HNE inhibitors, was the first to
be isolated from the skin of psoriatic patients. This inhibitor has a second-order constant association
of 5 × 106 M−1.s−1 and is considered a potent reversible inhibitor of this enzyme [14,19]. Over the years,
numerous HNE inhibitors such as 4-oxo-β-lactams, benzoxazinones, diazo compounds or
haloketones have been developed [9,20,21]. In this context, it is necessary to consider not only the size
and chemical nature of the structure, to decide the route of administration, but also the enzyme
selectivity and appropriate pharmacokinetic and pharmacodynamic properties [14,18]. Synthetic
HNE inhibitors need to have some peptide character to act as effective drugs, since binding of an
aliphatic amino acid side chain in the S1 pocket is more favored. Notwithstanding, peptides usually
present chemical instability, poor pharmacological profile and low bioavailability. These properties
could be improved when low molecular weight drugs are synthesized (≤500 Da) and physicochemical
properties (log P = 2–3, ionization, etc.), drug concentration and diffusion through the skin are
optimized [18,22].
Recent studies showed that the structure of β-lactam inhibitors allows a great improvement on
the rate of serine acylation since they increase the intrinsic chemical reactivity, when compared to
other compounds [10,15,23]. The synthesis of new compounds with a β-lactam structure, such as
azetidine-2,4-diones, also known as 4-oxo-β-lactams, were demonstrated to be a very potent and
selective class of HNE acylating agents (Scheme 1). The structure-activity relationship (SAR) studies
performed by Mulchande, J. et al. [24] showed that substituents at C-3 of the four-membered ring are
very important for the potency of this inhibitor. Furthermore, these studies indicated that a diethyl
substitution in the 4-oxo-β-lactam scaffold, along with N-phenyl derivatization of this structure,
selectively improved the activity against HNE [24]. Accordingly, previous studies reported by our
group [24–26] also showed that these compounds could be quite promising regarding the inhibition
of serine proteases. In particular, ER143 (1) [21] showed high potency and selectivity for HNE but it
presented poor solubility and cell viability when tested in immortalized human keratinocyte (HaCaT)
cells [21]. Thus, these new HNE inhibitors were synthesized as an elaboration of ER143 (1) (3,3-
diethyl-1-(4-(((2-oxo-2H-chromen-7-yl)oxy)methyl)phenyl)-azetidine-2,4-dione), as reported in
Scheme 1, previously synthesized by our research group [21], and was used as a control [10,15,23].

Pharmaceutics 2020, 12, 358
3 of 19
O
O
Ser
Enz
N
O
O
O
O
O
HO Ser Enz
N
O
O
O
O
ER143 (1)
2
3
Scheme 1. Reaction between HNE and ER143 (1).
Topical delivery systems are used to vehiculate active substances across the skin barrier,
affecting not only the drug potency, but also the acceptability by the patient [27]. There are several
types of topical pharmaceutical forms, including creams, gels, ointments, pastes, etc. Emulsions are
thermodynamically unstable systems composed of two immiscible liquids (water and oil) stabilized
by surfactants that reduce the interfacial tension between those phases. The nature of the emulsion is
influenced by the water and oil ratio, the type and geometry of the surfactant used in the formulation
and the manufacturing process. Emulsions require a certain amount of energy, thus, rotor stators are
commonly used in the production of emulsions allowing the dispersion of the droplets [28–30].
Over time, the droplets, through Brownian movement, tend to collide with each other to reduce
the interfacial area. Consequently, coalescence will occur and continue until full phase separation
and the minimum free energy (equilibrium) are reached. For this reason, emulsions are one of the
most difficult and complex systems in the pharmaceutical field to develop and stabilize, requiring
expertise knowledge and experience [29,30]. To prepare emulsions with the shelf life stability
required for a pharmaceutical product (1–3 + years), the correct choice of surfactants, co-surfactants,
fatty alcohols, polymers (steric stabilization) or solid particles (Pickering emulsions), among other
excipients, must be made [29,31].
Microemulsions are considered to be dispersed colloidal systems consisting of two liquid phases
and with a clear and translucid macroscopic aspect mainly due to their reduced droplet size. These
formulations differ from emulsions in many aspects, such as macroscopic appearance, particle size,
stability, formation and composition [32,33]. In addition to the components mentioned above,
microemulsions further require a higher content of surfactant and a co-surfactant, usually a low
molecular weight alcohol, which may compromise their safety [33–35]. The formation process of
microemulsions is significantly easier since they form spontaneously (almost zero interfacial tension)
without the need for high energy input. In practice, only gentle agitation is required [29,33,34], which
makes these systems quite attractive for the industrial field.
In this work, the synthesis and full characterization of new HNE inhibitors with 4-oxo-β-lactam
scaffolds and less toxicity are reported. After compound selection, two different topical forms are
developed as O/W emulsions and microemulsions further characterized in terms of physicochemical
properties, in vitro drug release and in vivo antipsoriatic activity.
2. Materials and Methods
2.1. Materials
2.1.1. Synthesis of HNE Inhibitors
All reagents and solvents were purchased from Sigma-Aldrich (Munich, Germany), Alfa Aesar
(Heysham, Lancashire, UK) and TCI (Zwijndrecht, Belgium) and used without further purification.
Dichloromethane (DCM) and acetone were dried by distillation from calcium hydride and potassium
carbonate, respectively.

Pharmaceutics 2020, 12, 358
4 of 19
2.1.2. Formulation of HNE Inhibitor Loaded Emulsion and HNE Inhibitor Loaded Microemulsion
In this study, the AAN-16 (compound 16) was incorporated in an O/W emulsion and in a
microemulsion named “AAN-16 E” and “AAN-16 ME”, respectively.
In AAN-16 E, glycerin (Quimidroga, Portugal) was used as a humectant and methylparaben and
propylparaben (Nipagin™ M Sodium and Nipasol M Sodium™, Clariant, Muttenz, Switzerland) as
preservatives. In addition, hydrogenated lecithin (and) C12-16 alcohols (and) palmitic acid
(Biophilic™ H MB, IFF Lucas Meyer Cosmetics, Quebec City, QC, Canada), caprylic/capric
triglycerides (Tegosoft® CT, Evonik, Essen, Germany), C10-18 triglycerides (Lipocire™ A SG,
Gattefossé, Saint-Priest, France), isopropyl myristate (Tegosoft® M, Evonik, Essen, Germany), oleic
acid (Sigma-Aldrich, Munich, Germany), alpha bisabolol (Esperis, Milan, Italy), cetyl alcohol (DS
produtos químicos, Cascais, Portugal) were also added to AAN-16 E. On the other hand, C21-C28
alkane (Emosmart ™ C28, Seppic ™, La Garenne-Colombes, France), a plant-based and renewable
C15-19 alkane oil (Emogreen ™ L15, Seppic ™, La Garenne-Colombes, France) and caprylic/capric
triglycerides (Tegosoft® CT, Evonik, Essen, Germany) were added to AAN-16 ME. In addition, PEG-
20 glyceryl triisostearate (Cithrol™ 10GTIS, Croda Inc, Snaith, UK) was used as surfactant and
propylene glycol (Mosselman, Ghlin, Belgium) as humectant and co-surfactant, and finally,
methylparaben and propylparaben (Clariant, Muttenz, Switzerland) were used as preservatives.
Purified water was obtained by inverse osmosis (Millipore, Elix® 3, Merck, Darmstadt, Germany).
2.2. Methods
2.2.1. Synthesis and Characterization of HNE Inhibitors
The HNE inhibitors were synthesized according to the literature [21,24,26]. The synthesized
compounds were characterized by NMR techniques, FTIR and mass spectrometry, elemental analysis
and melting point as described in the Supplementary Materials.
Chemical reactions were followed by thin layer chromatography (TLC) using Merck aluminium
backed sheets coated with 60 F254 silica gel and visualized under a UV lamp or revealed using iodine,
potassium permanganate and vanillin. Compound purification was obtained by flash
chromatography using silica gel (0.040–0.063 mm) from Merck (Darmstadt, Germany).
NMR experiments were performed on a Bruker 300 ultra-Shield (Bruker, Massachusetts, NE,
USA) (1H 300 MHz; 13C 75 MHz) in chloroform-d or acetone-d
. All chemical shifts (δ) were quoted
6
in ppm scale and coupling constants (J) in Hz, and multiplicity was described with the following
abbreviations: s = singlet, d = doublet, t = triplet, m = multiplet.
FTIR spectra were obtained using a IRAffinity-1 (Shimadzu, Kyoto, Japan). Each compound was
previously blended with potassium bromide and pressed with a hydraulic press until a pellet was
formed.
Melting points (m.p.) were determined using a Bock-Monoscop (Kofler, Berlin, Germany).
The Log P was predicted using the ALOGPS 2.1 program [36].
2.2.2. Biological Assays of Synthesized HNE Inhibitors
Enzymatic Inhibition Assays and In Vitro Cytotoxicity
Fluorometric assays for HNE inhibition activity were conducted as previously described [37].
Briefly, the assays were carried out in 200 µL assay buffer (0.1 M HEPES pH 7.5 at 25 °C) containing
20 µL of 0.17 µM HNE in assay buffer, 155 µL of assay buffer and 5 µL of each concentration of the
tested inhibitors. The reaction was initiated by the addition of 20 µL of fluorogenic substrate at 200
µM (MeO-Suc-Ala-Ala-Pro-Val-AMC), and the inhibition activity was monitored for 30 min at 25 °C
on a microplate reader (FLUOstar Omega; BMG Labtech, Baden-Württemberg, Germany) (excitation
wavelength 380 nm and emission 460 nm). Inhibitor stock solutions were prepared in DMSO.
Controls were performed as follows: (1) enzyme; (2) substrate; (3) enzyme with DMSO and (4)
positive control with Sivelestat sodium salt hydrate. Assays were performed in triplicate and

Pharmaceutics 2020, 12, 358
5 of 19
presented as log of inhibitor concentrations versus the percentage of activity. IC50 values were
determined by non-linear regression analysis in GraphPad PRISM® 5 software.
Compounds 1, 16 and 17 were evaluated for their ability to inhibit other human serine proteases,
namely trypsin, chymotrypsin, urokinase and kallikrein in 200 µL reaction volumes at 25 °C, as
follows: 0.05 M Tris-HCl and 0.138 M NaCl at pH 8.0, 30 or 2 nM human pancreas of each protease
and kallikrein respectively, and 50 or 100 µM substrate (Z-Gly-Gly-Arg-AMC.HCl for trypsine; Suc-
Ala-Ala-Pro-Phe-7-amino-4-methylcoumarin for chymotrypsin; Z-Gly-Gly-Arg-AMC.HCl for
urokinase; H-Pro-Phe-Arg-AMC acetate salt for kallikrein, from Bachem, Switzerland).
For all serine proteases, the activity was measured at excitation and emission wavelengths of
360 nm and 460 nm, respectively, in a microplate reader (FLUOstar Omega, BMG Labtech, Germany).
The IC50 was determined by non-linear regression as previously published [37].
The cell viability was evaluated with the endpoint MTT (3-(4,5-dimethyl-2-thiazolyl)-2,5-
diphenyl- 2H-tetrazolium bromide, Sigma Aldrich) assay performed on a human keratinocyte cell
line, HaCaT (Cell line Service GmbH, Eppelheim, Germany) [38]. These cells were seeded in sterile
flat bottom 96 well tissue culture plates in RPMI culture medium, supplemented with 10% FBS, 100
units of penicillin G (sodium salt), 100 µg of streptomycin sulfate and 2 mM L-glutamine and
incubated at 37 °C and 5% CO .
2
Cell viability was assessed after 24 h of incubation of HaCaT cells with 50 µM concentration of
each sample. DMSO diluted in culture medium was the negative control, whereas sodium dodecyl
sulfate at 1.0 mg/mL was the positive one. After exposure, the culture medium was replaced by
medium containing 0.5 mg/mL MTT. The cells were further incubated for 3 h. After removing the
media, the intracellular formazan crystals were solubilized and extracted with DMSO. After 15 min
at room temperature, the absorbance was measured at 570 nm in a microplate reader (FLUOstar
Omega). The cell viability (%) compared to control cells was calculated by [Absorbance]
sample/[Absorbance]control × 100, culture medium with the same amount of DMSO as the samples
used as control.
2.2.3. HNE Inhibitor Topical Formulations and Characterization Studies
Solubility Studies
According to biological studies of synthesized HNE inhibitors, the selected compound to
incorporate in final pharmaceutical formulations was compound 16 (2-((4-(3,3-diethyl-2,4-
dioxoazetidin-1-yl)benzyl)thio)-N-(3-((7nitrobenzo[c][1,2,5]oxadiazol-4-yl)amino)propyl)benzo[d]oxazole-5-
carboxamide). To perform the solubility studies, the oily phases of AAN-16 ME and AANN-16 E were
both saturated with 1 mg of compound 16 under stirring at room temperature. The solubility was
measured by a fluorescence method (excitation 380 nm; emission 460 nm) at 25 °C on a microplate
reader (FLUOstar Omega, BMG Labtech GmbH, Germany).
Preparation of HNE Inhibitor Loaded Emulsion and HNE Inhibitor Loaded Emulsion
Microemulsion
The AAN-16 E was prepared by a hot method (80 °C), adding the oily phase previously melted,
where the compound 16 was dissolved, to the aqueous phase under stirring using an Ultra Turrax®
(IKA® T25 Digital, Staufen, Germany) at 7000 rpm for 1 min. On the other hand, the AAN-16 ME was
prepared by dissolving the compound 16 in the oily phase with subsequent addition of the aqueous
phase under stirring with a glass rod at room temperature. All formulations were carried out using
a digital scale (VWR, Portugal) and their composition is shown in Table 1.

Pharmaceutics 2020, 12, 358
Table 1. Qualitative and quantitative composition of formulations.
6 of 19
Formulations (%, w/w)
Disperse Phase
Ingredients (INCI)
AAN-16 AAN-16 ME
Water
Hydrogenated lecithin (and) C12-16
alcohols (and) palmitic acid
Glycerin
72.79
5.97
6.00
-
5.00
-
-
40.27
5.97
0.11
0.01
15.90
15.90
15.90
-
Aqueous phase
PEG-20 glyceryl triisostearate
Propylene glycol
-
Methylparaben
0.18
0.02
2.50
-
Propylparaben
Caprylic/capric triglycerides
C15-19 alkane
C21-C28 alkane
-
C10–18 triglycerides
Isopropyl myristate
Oleic acid
4.00
5.00
1.00
1.00
2.50
0.01
Oily Phase
-
-
Alpha bisabolol
-
Cetyl alcohol
-
Compound 16
0.01
The composition of both emulsions and microemulsions was selected by taking previous studies
performed by our group into account (data not shown). In those studies, several topical delivery
systems (emulsions and microemulsions) were developed, optimized and characterized. Different
humectants and preservatives were studied as well as the influence of different concentrations of
cetyl alcohol on the final properties of the O/W emulsions. Oils containing different carbon chains
were incorporated into microemulsions to mimic the skin lipid layer. At the end, the formulations
with the most suitable physicochemical and sensorial properties and higher stability were chosen.
Characterization Studies of HNE Inhibitor Loaded Emulsion and HNE Inhibitor Loaded
Microemulsion
The pH values were determined at room temperature using a potentiometer (Mettler Toledo,
Columbus, OH, USA) 24 h after the production of each formulation.
To test the physical stability of AAN-16 E, an accelerated stability test based on centrifugation
(Heraeus Sepatech, Hanau, Germany) for 10 min at 3000 rpm was used.
The AAN-16 ME physical stability was evaluated by observing the macroscopic appearance
(translucent or opaque) of each formulation immediately after preparation.
The rheological characteristics of the formulations were examined at high shear rates using a
continuous shear technique and oscillation technique in the viscoelastic region. These experiments
were performed with a controlled stress Kinexus Lab+ Rheometer (Malvern, UK) using cone
geometry (truncated cone angle 4° and radius 40 mm). All measurements were performed at room
temperature. The shear rate method was carried out using a destructive measurement, where the
shear stress of each formulation was obtained by increasing the shear rate from 0.1 s−1 to 100 s−1 and
using 8 samples per decade. First, in the oscillatory method, an amplitude sweep test was performed
where the shear strain ranged between 0.01 and 100 Hz, and the frequency was set at 1 Hz. Then, a
frequency sweep test was performed with a shear strain of 0.1 and 5% for AAN-16 E and AAN-16
ME respectively, and a frequency range between 0.01 and 10 Hz. Ten samples per decade were
evaluated in each method.
The mean droplet sizes of emulsions and microemulsions were determined using Malvern
Mastersizer (with Hydro 2000S module) and Malvern Zetasizer Nano (Kassel, Germany),
respectively.

Pharmaceutics 2020, 12, 358
7 of 19
To visualize the internal structure of AAN-16 E, an optical fluorescence microscope with video
camera (Bresser, Rhede, Germany) was used.
In Vitro Release Studies
In vitro release studies were performed using vertical Franz diffusion cells (receptor volume: 4
mL, release area: 1 cm2) with synthetic membranes (Tuffryn® 0.45 µm, hydrophilic polysulfone
membrane filter; Pall Corporation (East Hills, NY, USA)) and silicone membranes (Sil-Tec, reff 500-2,
0.002”; Technical Products Inc. of Georgia (Lawrenceville, GA, USA). The samples were evenly
applied (0.2 to 0.4 g of formulation correspondent to 0.02 to 0.04 mg of compound (16) on the surface
of the membrane in the donor compartment, and sealed with Parafilm® (Bemis Company, Inc,
Neenah, WI, USA) to prevent water evaporation. Water:ethanol (50:50 w/w) with 2.5% of PEG-40
Hydrogenated Castor Oil was used as a receptor phase (approx. solubility: 0.39 mg/mL). The study
was performed for 6 h at 32–37 °C under stirring, and each sample was collected (200 µL) with an
interval of one hour. The amount of compound 16 released was analyzed as previously described on
a Fluorescence Microplate Reader FLUOstar Omega (BMG Labtech GmbH, Germany), and the data
was expressed as the cumulative released drug amount as a function of time. The data obtained was
computed using DDSolver [39] (Excel-plugin module) and fitted to different kinetic models, such as:
zero order, first order, the Higuchi model and the Korsmeyer–Peppas model [40,41].
In Vivo Antipsoriatic Activity
The experiments were conducted using female BALB/c mice at 6 weeks of age provided by
Charles River Laboratories (Écully, France). Animals were housed in polypropylene cages at ambient
temperature (20–24 °C), relative humidity (55 ± 5%), 12 h’ light/dark cycle and given standard diet
and water ad libitum. All animal experiments were performed according to the animal welfare organ
of the Faculty of Pharmacy, University Lisbon, approved by the competent national authority
(Direção-Geral de Alimentação e Veterinária—DGAV) and in accordance with the EU Directive
(2010/63/EU), the Portuguese laws (DL 113/2013, 2880/2015, 260/2016 and 1/2019) and all relevant
legislation.
The in vivo studies regarding the imiquimod (IMQ)-induced psoriasis-like inflammation model
were performed according to Pivetta et al. [42]. The psoriasis-inflammation evaluation criteria were
assessed, based on the clinical Psoriasis Area and Severity Index (PASI), as previously described [42].
Erythema, scaling and thickening were scored from 0 to 4 (0: none; 1: slight; 2: moderate; 3: marked;
4: very marked). In the first day, all mice were shaved in the dorsum and kept in individual cages
throughout the experiment. Animals were randomly selected, and five groups of animals were tested:

Group 1 (n = 5) was treated with 60 mg of Dermovate® (GSK, Algés, Portugal) (containing 0.05%
clobetasol propionate) as a positive control of inflammation inhibition;
Group 2 (n = 4) was treated with 60 mg of emulsion placebo;





Group 3 (n = 4) was treated with 60 mg of microemulsion placebo;
Group 4 (n = 5) was treated with 60 mg of AAN-16 E;
Group 5 (n = 5) was treated with 60 mg of AAN-16 ME;
Group 6 (n = 2) was used for control of non-induced and non-treated skin.
All tested formulations were spread over the mice back skin with a spatula in an average amount
of 26.7 mg/cm2. The two placebo formulations were used as control, since they present the same
composition of AAN-16 E and AAN-16 ME, without any active compound. Five hours after the
treatment, 60 mg of Aldara® cream (Meda AB, Solna, Sweden) containing 5% of imiquimod was
applied on the back skin. This treatment lasted for 5 consecutive days. Apart from the 1st day, the
animals were always subjected to daily visual inspection and measurement of body weight and skin
thickness, which was measured in the application zone using a digital calliper (Fisherbrand,
Leicestershire, UK). On the 6th day, the mice were sacrificed, and their dorsal skin exposed to the test
compounds was preserved in a 10% formalin solution and sent for histopathological analysis. The
psoriasis-inflammation evaluation criteria were assessed according to the clinical Psoriasis Area and

Pharmaceutics 2020, 12, 358
8 of 19
Severity Index (PASI) as previously described [42]. Erythema, scaling and thickening were scored
from 0 to 4 (0: none; 1: slight; 2: moderate; 3: marked; 4: very marked).
Formalin-fixed tissues were trimmed into longitudinal sections. Samples were then paraffin-
embedded, sectioned at 4 µm and stained with heamtoxylin and eosin. Lesions were evaluated by a
pathologist blinded to experimental groups. Measurements were performed in slides digitally
scanned in the NanoZoomerSQ with NDP.view2 software (Hamamatsu, Japan) corresponding to the
mean value obtained from 7 to 12 different points for epidermis and dermis layers.
2.2.4. Statistical Analysis
One-way analysis of variance (ANOVA) and the Tukey–Kramer post-hoc multiple comparison
test was used to identify the significant differences between the groups, and were performed using
GraphPad PRISM® 5 software. An alpha error of 5% was chosen to set the significance level. Results
were expressed as mean ± standard deviation.
3. Results and Discussion
3.1. Synthesis of 4-oxo-β-Lactams
4-oxo-β-lactams, and in particular ER143 (1), showed high potency and selectivity for HNE.
However, they presented some toxicity when tested in HaCaT cells. To improve efficacy and decrease
cytotoxicity, we synthesized additional analogues of ER143 (1) with varied physicochemical
properties. As depicted in Scheme 2, the 4-oxo-β-lactam core was synthesized by reaction of
diethylmalonyl dichloride with an appropriate aniline. The target compound 6 was prepared through
radical bromination of intermediate 5 using NBS and benzoyl peroxide. Compound 8 was
synthesized by a cyclization reaction between aniline 7 and diethylmalonyl dichloride, and
subsequently, debenzylated using a palladium and hydrogen atmosphere to yield the carboxylic acid
derivative compound 9.
Scheme 2. Synthesis of compound 6, 8 and 9. Reagents and conditions: (i) p-toluidine, NEt
3, DCM, r.t;
(ii) NBS, benzoyl peroxide, ACN, reflux; (iii) Intermediate 7, NEt , DCM, r.t; (iv) H , Pd/C, MeOH.
3
2
To improve solubility of compound 6, derivative 12 was synthesized as follows (Scheme 3). The
carboxylic acid derivative 12 was prepared as depicted in Scheme 3, starting with the cyclization
reaction between 3-amino-4-hydroxybenzoic acid 10 and potassium ethyl xanthate to form the
benzoxazole 11, which then reacted with compound 6 in the presence of potassium carbonate to
obtain the target compound 12.

Pharmaceutics 2020, 12, 358
9 of 19
HO2C
NH2
OH
HO2C
N
O
i)
SH
10
11
ii)
iii)
O
N
N
S
O
O
O
OH
COEt, EtOH:H O (6:1), reflux;
12
Scheme 3. Synthesis of compound 12. Reagent and conditions: (i) KS
2
2
(ii) K CO , acetone, 20min.; (iii) Intermediate 6, acetone, reflux.
2
3
To allow identification and quantification of 4-oxo-β-lactams in biological assays, a synthetic
scheme was devised to incorporate a fluorophore in inhibitors 9 and 12 (Scheme 4). First, intermediate
14 was synthesized by reacting amine 13 with NBD-Cl. Removal of the Boc protecting group with
trifluoroacetic acid in dry dichloromethane yielded intermediate 15, which was then converted to
compounds 16 and 17, by an amide coupling reaction with 12 and 9, respectively, in the presence of
TBTU and DIPEA. Compounds 6, 8, 9, 12, 16 and 17 were fully characterized by 1H and 13C-NMR and
mass spectrometry.
O
N
N
Boc
Boc
i)
N
NH2
N
NH
NO2
H
H
13
14
ii)
O
O
N
N
N
H2N
NH
15
NO2
N
O
S
iii)
iv)
O
O
O
NH
N
N
O
HN
16
NH
HN
N
NO2
O
N
O
N
O
17
NO2
Scheme 4. Synthesis of compound 16 and 17. Reagents and conditions: (i) NBD-Cl, MeOH, r.t; (ii)
TFA; (iii) Compound 12, TBTU, DIPEA, DCM, 0 °C; (iv) Compound 9, TBTU, DIPEA, DCM, 0 °C
ER143 (1) was also synthesized as described elsewhere [21] to be used as a control.
3.2. Biological Assays of Synthesized HNE Inhibitors
Enzymatic Inhibition Assays and In Vitro Cytotoxicity
To understand the activity of synthesized compounds against HNE, enzymatic inhibition assays
were assessed as shown in Table 2.

Pharmaceutics 2020, 12, 358
10 of 19
Table 2. Enzymatic inhibition assays.
Compounds
Structure
IC50 ± SD (nM)
O
6
0.64 ± 0.03
N
O
Br
ER 143 (1)
0.42 ± 0.09
0.96 ± 0.13
14.71 ± 5.55
8
9
12
0.38 ± 0.05
By analyzing these data, 4-oxo-β-lactam was revealed to be essential for this activity, as IC50
values were obtained at a sub-nanomolar range, except for compound 9. Thus, it was possible to
confirm the importance of the β-lactam ring in the structure of these molecules, allowing a great
improvement on the rate of serine acylation, as confirmed in [26].
From these results, none of the synthesized compounds with the oxo-β-lactam moiety could be
excluded, and thus a cell viability assay was carried out with HaCat cells to choose the compounds.
All compounds presented lower cell viability than the negative control (DMSO), except
compounds 9 and 12 (>50%) (Figure 1). The lower cell viability of compound 6 might be due to the
presence of a bromine atom that is described as potentially cytotoxic, causing a decrease in cell
viability [43]. Compound 8 showed the lowest cell viability among all compounds. The only
difference with compound 9 was the presence of an ester group which improved the cytotoxicity.
140
120
100
80
60
40
20
0
ER143
(1)
6
8
9
12
Negative Positive
Control Control
Figure 1. Cell viability assay at 50 µM concentration of compounds ER143 (1), 6, 8, 9 and 12 in HaCaT
cells for 24 h of exposition time.
Due to optimal inhibition activity against HNE and good cell viability of compounds 9 and 12,
fluorescent derivatives were also synthesized (compounds 17 and 16, respectively) for the posterior
drug assay.

Pharmaceutics 2020, 12, 358
11 of 19
These new compounds also showed enzymatic activity against HNE at the sub-nanomolar range
(Table 3). It is also important to notice that compound 17 showed a higher activity than the parent
compound 9.
Since these new derivatives presented very similar activities, further studies of specificity were
performed to select the best compound. In this study (Table 3), different enzymes were used, such as:
trypsin, chymotrypsin, urokinase and kallikrein.
All the enzymes tested belong to the serine protease group, thus allowing evaluation if the
compounds act only on HNE or other enzymes of the same group. The results showed that the tested
compounds were specific for enzyme inhibition at a higher range like the control ER143 (1). In other
words, due to the high potency of these compounds, only a small amount was required to reveal
activity against HNE (Table 3) which was not sufficient to act on other enzymes of the same class.
Table 3. Results of enzymatic inhibition and specificity assays for compounds 16 and 17. Compound
ER143 (1) was used as reference.
IC50 ± SD
IC50 ± SD (µM)
Compounds
ER143 (1)
16
Structure
(nM)
HNE
Trypsin Chymotrypsin Urokinase Kallikrein
0.42 ± 0.09
0.85 ± 0.10
>1
>1
>8
>1
>50
>2
>8
>5
O
N
O
O
N
S
N
H
N
NO2
O
H
N
N
O
17
0.64 ± 0.03
>1
>0.5
>2
>3
Compound 17 was more cytotoxic (38% of cell viability) than compound 9 (80% of cell viability),
and both had higher cell viability than compound ER143 (1) (15% of cell viability) (Figure 2).
Nevertheless, compound 16 showed a cell viability (%) comparable to the negative control. Thus, this
compound was selected to be incorporated into the topical formulations.
140
120
100
80
60
40
20
0
ER143 (1)
16
17
Negative
Control
Positive
Control
Figure 2. Cell viability assay at 50 µM concentration of fluorescent compounds ER143 (1), 16 and 17
in HaCaT cells for 24 h of exposition time.

Pharmaceutics 2020, 12, 358
12 of 19
3.3. HNE Inhibitor Loaded Emulsion and HNE Inhibitor Loaded Microemulsion
3.3.1. Solubility Studies
According to previous results, compound 16 (AAN-16) was selected to be incorporated in an
O/W emulsion (AAN-16 E) and in a microemulsion (AAN-16 ME).
The results showed that 0.1 mg/g of compound 16 was the maximum drug concentration
solubilized in both oil blends, composed by caprylic/capric triglycerides, C15-19 alkane and C21-C28
alkane oils for AAN-16 ME and caprylic/capric triglycerides and isopropyl myristate for AANN-16
E. Therefore, these formulations were prepared at the same concentration of active compound (0.1
mg/g of formulation).
These final formulations were fully characterized as described below.
3.3.2. Characterization Studies of AAN-16 Loaded Emulsion and AAN-16 Loaded Microemulsion
AAN-16 E revealed a yellow and opaque appearance with some consistency unlike the AAN-16
ME corresponding to a clear and homogenous formulation with liquid appearance.
AAN-16 E and AAN-16 ME presented a pH of 6.7 and 7.5, respectively. These values were
appropriate for topical application, respecting the physiological pH according to the literature [44,45].
Comparing with the pH obtained in placebos, there were no significant changes.
The rheological characterization was performed by continuous shear and oscillation
experiments. AAN-16 E had a much higher viscosity (182.5 Pa.s) than AAN-16 ME (0.05 Pa.s) at the
same shear rate (at 0.1 s−1), as supposed for these systems. These values remained constant without
any significant differences, when compared with placebos for both formulations.
In addition, AAN-16 ME was a Newtonian fluid in which viscosity does not change when a
shear rate is applied, whereas AAN-16 E was a shear-thinning fluid characterized by a viscosity
decrease with increasing shear rate owing to the orientation of the molecules in the structure [46,47].
These results were in agreement with placebo studies that others had reported [29,34,48–51].
Figure 3 represents the oscillatory frequency study, in which the system response is measured
as a function of frequency with constant shear strain. From these results, it is possible to obtain the
storage modulus (G’) (elastic component) and the loss modulus (G’’) (viscous component) in which
the energy lost is reflected [52].
6
5
4
3
2
1
0
2500
2000
1500
1000
500
AAN-16 ME G'
AAN-16 ME G''
AAN-16 E G'
AAN-16 E G''
0
0.01
0.1
1
10
0.01
0.1
1
10
Frequency (Hz)
(b)
Frequency (Hz)
(a)
Figure 3. Oscillatory results of (a) AAN-16 E and (b) AAN-16 ME.
In this case, the values of the elastic modulus of AAN-16 E overcame the values of the viscosity
modulus (G’ > G’’) and the loss tangent values were lower than 1 [52], indicating a solid-like behavior
with a strong network. In this structure type, the molecules are more bound (e.g., by Van der Walls
interactions) and organized than in liquids, but less than in solids. On the contrary, the elastic
modulus of AAN-16 ME was lower than the viscous modulus (G’ < G’’) and the loss tangent values
were lower than 1, thus presenting a liquid-like structure with a weak and easily disturbed network.
As a consequence, these formulations presented a suitable spreadability.
The d(50) for AAN-16 E was 23.52 µm with a span of 5.028, while AAN-16 ME presented a d(50)
of 9.92 nm with a Pdi of 0.834. The droplet size obtained here was also concordant with the literature

Pharmaceutics 2020, 12, 358
13 of 19
related to these pharmaceutical forms [29,34,51]. Although AAN-16 ME had droplets in the nano
range, the Pdi value was high, indicating heterogeneity of droplet size within AAN-16 ME, or,
probably a bicontinuous system. Microemulsions typically exist in the form of micellar and
bicontinuous structures. However, it is very complex and difficult to characterize these systems at
the molecular level.
Fluorescence microscopy was used to visualize the internal structure of these formulations with
compound 16 (Figure 4).
Figure 4. The inside structure of AAN-16 E (a) and emulsions’ placebo (b) using a fluorescence
microscope.
It was only possible to observe the emulsion (E) droplets due to the respective size. In the AAN-
16 E, it was possible to observe the drug both dispersed and dissolved in the formulation, as shown
in Figure 4. Thus, the formulation droplets were fluorescent owing to this labeled compound.
3.3.3. In Vitro Release Studies
In vitro AAN-16 release studies were performed in both final formulations using Franz Cells
with a synthetic membrane (Tuffryn®) (Figure 5).
10
AAN-16 E
AAN-16 ME
8
6
4
2
0
0
2
4
6
Time (h)
Figure 5. Drug release studies of AAN-16 E and AAN-16 ME using a synthetic membrane (Tuffryn®).
Results expressed as average ± SD, n = 6.
After 6 h, the amount of the compound 16 released was different, i.e., 7.2 ± 2.1 µg/cm2 and 3.3 ±
1.2 µg/cm2 for AAN-16 E and AAN-16 ME, respectively. The emulsion released a higher amount of
drug than the microemulsion, despite the higher bulk viscosity of the AAN-16 E. In fact, the structure
of vehicles plays an important role in the release of the active compound [53].

Pharmaceutics 2020, 12, 358
14 of 19
Regarding drug properties, compound 16 is mainly lipophilic (log P (predicted) = 4.68),
uncharged and with a high molecular weight (M = 643.68 g.mol−1), thus its diffusion into the receptor
aqueous phase could be compromised.
AAN-16 E and AAN-16 ME present a structure type with aqueous and occlusive lipidic phases.
It was further noted that AAN-16 was dissolved in the oily phase of the microemulsion, while it was
both dispersed and dissolved in the emulsion.
AAN-16 E is an O/W emulsion, where the drug is incorporated in the internal phase of the
formulation. To reach the membrane and the receptor phase, the compound needs to pass through
the structure of the external aqueous phase.
The diffusivity of compound 16 in the formulations was an inverse function of the surfactant
concentration. In addition, several studies [54–56] indicate that drug flow is inversely proportional
to the amount of surfactant.
Diffusion was the drug release mechanism for both formulations, where the Higuchi (R2ajusted
=
0.934 ± 0.029) and First order models (R2ajusted = 0.784 ± 0.069) could be applied for AAN-16 E and
AAN-16 ME, respectively. Finally, no drug was detected in the receptor phase when a silicone
membrane was used.
The use of synthetic membranes is useful in quality assurance, but it does not represent how a
formulation will behave once applied on skin. Many drugs developed for the topical treatment of
skin disease are poorly water-soluble and difficult to formulate. Thus, certain strategies can be used.
For example, AAN 16 was composed by permeation enhancers (isopropyl myristate, propylene
glycol and oleic acid) and 6% emulsifiers (hydrogenated lecithin (and) C12-16 alcohols (and) palmitic
acid), which may affect the solubility and/or interact with the membrane used [34,53,57].
Consequently, AAN-16 E exhibited higher drug release over time when compared to AAN-16 ME
formulated with 40% of a non-ionic surfactant (PEG-20 glyceryl triisostearate).
3.3.4. In Vivo Antipsoriatic Activity
The imiquimod (IMQ)-induced psoriasis-like inflammation model was used in this study to
evaluate the antipsoriatic activity of AAN-16 E and AAN-16 ME topically applied. In this model,
stratum corneum disturbance by imiquimod dramatically promotes the cutaneous drug absorption
[58]. After treatment with test compounds and commercial corticosteroid control, several parameters
were assessed as erythema, scaling, and skin thickness (Figure 6).
Figure 6. Results of the in vivo antipsoriatic activity: erythema, scaling and skin thickness of mice
challenged with imiquimod (IMQ) and treated with each formulation (Dermovate®, AAN-16 E and
emulsion placebo). Score 0–4 (none to marked). Results expressed as average ± SD.

Pharmaceutics 2020, 12, 358
15 of 19
Mice treated with AAN-16 E and placebo obtained similar and higher scores, for all parameters
in opposition to the results of the positive control group (treated with Dermovate® containing
clobetasol propionate). Unexpectedly, mice exposed to AAN-16 ME had to be sacrificed within 5 days
of application due to the presence of physiological and behavioral signs of distress (humane
endpoints). In addition, it was not possible to verify any significant difference between
microemulsions’ placebo and AAN-16 ME.
IMQ-induced psoriasis-like model is a commonly used model to test antipsoriatic drugs. In
BALB/c mice, IMQ topical application induces psoriasis-like dermatitis mediated via the IL-23/IL-17
axis [59]. However, in mice, this model causes not only plaque psoriasis, but also systemic disease
comprising more severe symptoms, like anorexia, malaise, and pain [60]. These severe systemic
features are usually only observed in non-treated animals in contrast to animals treated with
antipsoriatic drugs, like clobetasol propionate cream (Dermovate®—Figure 6), which show
amelioration in the development of IMQ-induced psoriasis-like signs. In this study, we treated mice
with ME-based formulations containing approximately 40% (w/w) of PEG-20 glyceryl triisostearate.
This compound is considered safe for cosmetic use, being favorably used as a penetration enhancer
[61]. Surfactants have effects on the permeability of several biological membranes including skin
mainly due to their potential to solubilize lipids within the stratum corneum. Some authors tested
the cytotoxicity and inflammation potency of several surfactants on reconstructed human epidermis
tissues, and concluded that PEG ethers appeared to be more toxic than PEG esters. The results also
revealed the mildness of polyoxyethylene sorbitan esters independently of their alkyl chain length
[62]. Frequently, the cleansing and leave-on products contain up to 20% and 5% PEG-20 glyceryl
triisostearate, respectively [61]. Considering the results obtained in this work, we are convinced that
the exacerbated systemic effects observed in mice treated with ME-based formulations are related to
the enhanced IMQ transdermal absorption and not to the in vivo toxicity of ME-based formulation
per se.
Figure 7 shows the histopathology results of mice skin previously exposed to imiquimod, and
thereafter, to Dermovate®, emulsion placebo and AAN-16 E.
Figure 7. Representative microphotographs of skin (dorsum) of mice previously (a) treated with
Dermovate®; (b) emulsion placebo; (c) AAN-16 E. Changes were characterized by epidermal
hyperplasia (black arrowhead), and focally extensive inflammation expanding the dermis (white
arrowhead). Hematoxylin and eosin stain. Original magnification, 10× (bar, 250 µm).
Histopathological changes were evaluated by means of epidermal and dermal thickness.
Through the present study, it could be observed (Figure 7b,c) that the skin changes were
characterized by diffuse epidermal hyperplasia resulting in increased thickness (73.91 µm and 63.48
µm for AAN-16 E and emulsion placebo, respectively) of the Malpighian layer (highlighted with a
black arrow, Figure 7c,d), which is composed of stratum basale and stratum spinosum. A focally
extensive minimal to mild inflammation expanding the dermis (237.13 µm and 204.79 µm for AAN-
16 E and emulsion placebo, respectively) was observed promoting a diffuse thickening (highlighted
with a white arrow, Figure 7). In this inflammation model, the infiltrates corresponded to a mixed

Pharmaceutics 2020, 12, 358
16 of 19
cell population with a marked mononuclear-cell component. It is important to notice that the edema
was minimal, and no changes were found in the untreated animals (data not show).
Therefore, the results are in accordance with the literature [42,59,63,64], where the application
of IMQ causes epidermal hyperplasia resulting in increased thickness. Comparing the visual score of
the emulsion placebo and AAN-16 E it is not possible to find a significant difference between these
two groups. In other studies, using the same animal model, higher scores were obtained for the
different parameters evaluated when placebo formulations were tested (negative control groups)
[42,59,64,65]. In this study, even if it is not possible to distinguish between the AAN-16 E and the
placebo results, both by visual score or by histology analysis, the results do not show high severity
on skin lesions if compared to the data presented in the literature. Further studies are required to
clarify the role of the placebo emulsion and its components on the inflammation control.
4. Conclusions
From the results presented in this work, we can conclude that these new synthesized inhibitors
showed high in vitro activity and selectivity against HNE, constituting promising scaffolds.
According to biological assays, only two compounds were selected (9 and 12), to synthesize new ones
(16 and 17) with fluorescence labeling. As compound 16 presented higher cell viability, it was chosen
to be further incorporated into topical emulsion and microemulsion formulations (AAN-16 E and
AAN-16 ME, respectively). The in vitro AAN-16 release studies showed a great dependence on the
formulation type. In particular, a higher release rate was obtained for emulsion compared to
microemulsion.
Finally, according to in vivo antipsoriatic activity data, no significant differences between the
placebo and AAN-16 E were observed. Moreover, results obtained for the tested formulations were
not equivalent or superior to those of the reference formulation (Dermovate®), indicating that the
therapeutic effect was not detected in this model. Consequently, future in vivo studies will provide
a clarification of the mechanism of action of this compound among others within this scaffold.
Supplementary Materials: The following are available online at www.mdpi.com/xxx/s1, the characterization of
all compounds is presented in the Supplementary Materials.
Author Contributions: A.N., J.M., R.F., L.M.G. and S.S. contributed to the conceptualization, methodology,
validation, formal analysis, and investigation; A.N. contributed to the writing—original draft preparation; A.A.,
J.M., F.L. and H.M.R. contributed to supervision, writing—review and editing; F.L. and H.M.R. contributed to
project administration, resources, and funding acquisition. All authors have read and agreed to the published
version of the manuscript.
Funding: This work was supported by Fundação para a Ciência e a Tecnologia, Portugal (UID/DTP/04138/2019
to iMedUlisboa and and PTDC/MEC-DER/30198/2017) and Labodidática, Equipamentos de Laboratório e
Didácticos L.da.
Conflicts of Interest: The authors declare no conflict of interest. The funders had no role in the design of the
study; in the collection, analyses, or interpretation of data; in the writing of the manuscript, or in the decision to
publish the results.
References
1.
Hawkes, J.E.; Chan, T.C.; Krueger, J.G. Psoriasis pathogenesis and the development of novel targeted
immune therapies. J. Allergy Clin. Immunol. 2017, 140, 645–653, doi:10.1016/j.jaci.2017.07.004.
Parisi, R.; Symmons, D.P.M.; Griffiths, C.E.M.; Ashcroft, D.M. Global epidemiology of psoriasis: A
systematic review of incidence and prevalence. J. Investig. Dermatol. 2013, 133, 377–385,
doi:10.1038/jid.2012.339.
2.
3.
4.
5.
Noncommunicable
Diseases
and
Their
Risk
Factors.
Psoriasis.
Available
online:
https://www.who.int/ncds/management/psoriasis/en/(accessed on 22 April 2019).
Deng, Y.; Chang, C.; Lu, Q. The Inflammatory Response in Psoriasis: A Comprehensive Review. Clin. Rev.
Allergy Immunol. 2016, 50, 377–389, doi:10.1007/s12016-016-8535-x.
Kim, J.; Krueger, J.G. The Immunopathogenesis of Psoriasis. Dermatol. Clin. 2015, 33, 13–23,
doi:10.1016/j.det.2014.09.002.

Pharmaceutics 2020, 12, 358
17 of 19
6.
7.
Liang, Y.; Sarkar, M.K.; Tsoi, L.C.; Gudjonsson, J.E. Psoriasis: A mixed autoimmune and autoinflammatory
disease. Curr. Opin. Immunol. 2017, 49, 1–8, doi:10.1016/j.coi.2017.07.007.
Current and Potential New Therapies for the Treatment of Psoriasis. Available online:
https://www.pharmaceutical-journal.com/news-and-analysis/news/current-and-potential-new-therapies-
for-the-treatment-of-psoriasis/11013061.article?firstPass=false (accessed on 19 July 2019).
8.
9.
Hansen, G.; Gielen-haertwig, H.; Reinemer, P.; Schomburg, D.; Harrenga, A.; Niefind, K. Unexpected
Active-Site Flexibility in the Structure of Human Neutrophil Elastase in Complex with a New
Dihydropyrimidone Inhibitor. J. Mol. Biol. 2011, 409, 681–691, doi:10.1016/j.jmb.2011.04.047.
Shreder, K.R.; Cajica, J.; Du, L.; Fraser, A.; Hu, Y.; Kohno, Y.; Lin, E.C.; Liu, S.J.; Okerberg, E.; Pham, L.; et
al. Synthesis and optimization of 2-pyridin-3-yl-benzo[d][1,3]oxazin-4-one based inhibitors of human
neutrophil elastase. Bioorganic Med. Chem. Lett. 2009, 19, 4743–4746, doi:10.1016/j.bmcl.2009.06.053.
10. Lucas, S.D.; Costa, E.; Guedes, R.C.; Moreira, R. Targeting COPD: Advances on Low-Molecular-Weight
Inhibitors of Human Neutrophil Elastase. Med. Res. Rev. 2013, 33, E73–E101, doi:10.1002/med.20247.
11. Heutinck, K.M.; ten Berge, I.J.M.; Hack, C.E.; Hamann, J.; Rowshani, A.T. Serine proteases of the human
immune
system
in
health
and
disease.
Mol.
Immunol.
2010,
47,
1943–1955,
doi:10.1016/j.molimm.2010.04.020.
12. Crocetti, L.; Giovannoni, M.P.; Schepetkin, I.A.; Quinn, M.T.; Khlebnikov, A.I.; Cilibrizzi, A.; Dal Piaz, V.;
Graziano, A.; Vergelli, C. Design, synthesis and evaluation of N-benzoylindazole derivatives and
analogues as inhibitors of human neutrophil elastase. Bioorganic Med. Chem. 2011, 19, 4460–4472,
doi:10.1016/j.bmc.2011.06.036.
13. Giovannoni, M.P.; Schepetkin, I.A.; Quinn, M.T.; Cantini, N.; Crocetti, L.; Guerrini, G.; Iacovone, A.; Paoli,
P.; Rossi, P.; Bartolucci, G.; et al. Synthesis, biological evaluation, and molecular modelling studies of potent
human neutrophil elastase (HNE) inhibitors. J. Enzyme Inhib. Med. Chem. 2018, 33, 1108–1124,
doi:10.1080/14756366.2018.1480615.
14. Korkmaz, B.; Horwitz, M.S.; Jenne, D.E.; Gauthier, F. Neutrophil Elastase, Proteinase 3, and Cathepsin G
as
Therapeutic
Targets
in
Human
Diseases.
Pharmacol.
Rev.
2010,
62,
726–759,
doi:10.1124/pr.110.002733.726.
15. Santana, A.B.; Lucas, S.D.; Gonçalves, L.M.; Correia, H.F.; Cardote, T.A.F.; Guedes, R.C.; Iley, J.; Moreira,
R. N-Acyl and N-sulfonyloxazolidine-2,4-diones are pseudo-irreversible inhibitors of serine proteases.
Bioorganic Med. Chem. Lett. 2012, 22, 3993–3997, doi:10.1016/j.bmcl.2012.04.093.
16. Yang, X.; Yan, H.; Zhai, Z.; Hao, F.; Ye, Q.; Zhong, B. Neutrophil elastase promotes proliferation of HaCaT
cell line and transwell psoriasis organ culture model. Int. J. Dermatol. 2010, 49, 1068–1074, doi:10.1111/j.1365-
4632.2010.04500.x.
17. Zhong, J.; Groutas, W. Recent Developments in the Design of Mechanism-based and Alternate Substrate
Inhibitors of Serine Proteases. Curr. Top. Med. Chem. 2005, 4, 1203–1216, doi:10.2174/1568026043387971.
18. Leung, D.; Abbenante, G.; Fairlie, D.P. Protease inhibitors: Current status and future prospects. J.
Med.Chem. 2000, 43, 305–341, doi:10.1021/jm990412m.
19. Guyot, N.; Butler, M.W.; McNally, P.; Weldon, S.; Greene, C.M.; Levine, R.L.; O'Neill, S.J.; Taggart, C.C.;
McElvaney, N.G. Elafin, an elastase-specific inhibitor, is cleaved by its cognate enzyme neutrophil elastase
in sputum from individuals with cystic fibrosis. J. Biol. Chem. 2008, 283, 32377–32385,
doi:10.1074/jbc.M803707200.
20. Powers, J.C.; Asgian, J.L.; Ekici, O.D.; James, K.E. Irreversible inhibitors of serine, cysteine, and threonine
proteases. Chem. Rev. 2002, 102, 4639–4750, doi:10.1021/cr010182v.
21. Marto, J.; Ruivo, E.; Lucas, S.D.; Gonçalves, L.M.; Simões, S.; Gouveia, L.F.; Felix, R.; Moreira, R.; Ribeiro,
H.M.; Almeida, A.J. Starch nanocapsules containing a novel neutrophil elastase inhibitor with improved
pharmaceutical performance. Eur. J. Pharm. Biopharm. 2018, 127, 1–11, doi:10.1016/j.ejpb.2018.01.011.
22. Maryanoff, B.E.; Costanzo, M.J. Inhibitors of proteases and amide hydrolases that employ an α-
ketoheterocycle as
a key enabling functionality. Bioorganic Med. Chem. 2008, 16, 1562–1595,
doi:10.1016/j.bmc.2007.11.015.
23. Groutas, W.C.; Dou, D.; Alliston, K.R. Neutrophil Elastase Inhibitors. Expert Opin. Ther. Pat. 2012, 21, 339–
354, doi:10.1517/13543776.2011.551115.
24. Mulchande, J.; Oliveira, R.; Carrasco, M.; Gouveia, L.; Guedes, R.C.; Iley, J.; Moreira, R. 4-Oxo-β-lactams
(Azetidine-2, 4-diones) Are Potent and Selective Inhibitors of Human Leukocyte Elastase. J. Med. Chem.
2010, 53, 241–253, doi:10.1021/jm901082k.
25. Mulchande, J.; Simões, S.I.; Gaspar, M.M.; Eleutério, C.V.; Oliveira, R.; Cruz, M.E.M.; Moreira, R.; Iley, J.
Synthesis, stability, biochemical and pharmacokinetic properties of a new potent and selective 4-oxo-β-
lactam inhibitor of human leukocyte elastase. J. Enzyme Inhib. Med. Chem. 2011, 26, 169–175,
doi:10.3109/14756366.2010.486794.

Pharmaceutics 2020, 12, 358
18 of 19
26. Mulchande, J.; Guedes, R.C.; Tsang, W.; Page, M.I.; Moreira, R.; Iley, J. Azetidine-2,4-diones (4-Oxo-β-
lactams as Scaffolds for Designing Elastase Inhibitors. J. Med. Chem. 2008, 51, 1783–1790,
)
doi:https://doi.org/10.1021/jm701257h.
27. Carneiro, R.; Salgado, A.; Raposo, S.; Marto, J.; Simões, S.; Urbano, M.; Ribeiro, H.M. Topical emulsions
containing ceramides: Effects on the skin barrier function and anti-inflammatory properties. Eur. J. Lipid
Sci. Technol. 2011, 113, 961–966, doi:10.1002/ejlt.201000495.
28. Raposo, S.C.; Simões, S.D.; Almeida, A.J.; Ribeiro, H.M. Advanced systems for glucocorticoids’ dermal
delivery. Expert Opin. Drug Deliv. 2013, 10, 857–877, doi:10.1517/17425247.2013.778824.
29. Simões, S.; Ribeiro, H.M.; Almeida, A.J. Microemulsões e nanoemulsões. In Novas Formas Farmacêuticas para
Administração de Fármacos, 1st ed.; Souto, E.B., Lopes, C.M., Eds.; Edições Universidade Fernando Pessoa:
Porto, Portugal, 2011; pp. 271–296.
30. Sakamoto, K.; Lochhead, R.Y.; Maibach, H.I.; Yamashita, Y. Cosmetic Science and Technology: Theoretical
Principles and Applications, 1st ed.; Elseivier: Amsterdam, The Netherlands, 2017; pp. 1–835,
doi:10.7334/psicothema2011.192.
31. Marto, J.; Ascenso, A.; Simões, S.; Almeida, A.; Ribeiro, H. Pickering emulsions: Challenges and
opportunities in topical delivery. Expert Opin. Drug Deliv. 2016, 13, 1093–1107,
doi:10.1080/17425247.2016.1182489.
32. Anton, N.; Vandamme, T.F. Nano-emulsions and micro-emulsions: Clarifications of the critical differences.
Pharm. Res. 2011, 28, 978–985, doi:10.1007/s11095-010-0309-1.
33. Kogan, A.; Garti, N. Microemulsions as transdermal drug delivery vehicles. Adv. Colloid Interface Sci. 2006,
123, 369–385, doi:10.1016/j.cis.2006.05.014.
34. Lopes, L.B. Overcoming the cutaneous barrier with microemulsions. Pharmaceutics 2014, 6, 52–77,
doi:10.3390/pharmaceutics6010052.
35. Tadros, T.F. Microemulsions. In Applied Surfactants: Principles and Applications, 1st ed.; Wiley-VCH Verlag
GmbH & Co. KGaA: Weinheim, Germany, 2005; pp. 309–334, doi:10.1002/3527604812.
36. Virtual
Computational
Chemistry
Laboratory.
Available
online:
http://www.virtuallaboratory.org/lab/alogps/ (accessed on 24 March 2020).
37. Lucas, S.D.; Gonçalves, L.M.; Cardote, T.A.F.; Correia, H.F.; Moreira, R.; Guedes, R.C. Structure Based
Virtual Screening for Discovery of Novel Human Neutrophil Elastase Inhibitors. Med. Chem. Commun. 2012,
3, 1299–1304, doi:10.1039/C2MD20090B.
38. Strober, W. Trypan Blue Exclusion Test of Cell Viability. Curr. Protoc. Immunol. 2015, 111,
doi:10.1002/0471142735.ima03bs21.
39. Zhang, Y.; Huo, M.; Zhou, J.; Zou, A.; Li, W.; Yao, C.; Xie, S. DDSolver: An add-in program for modeling
and comparison of drug dissolution profiles. AAPS J. 2010, 12, 263–271, doi:10.1208/s12248-010-9185-1.
40. Mateus, D.; Marto, J.; Trindade, P.; Gonçalves, H.; Salgado, A.; Machado, P.; Melo-Gouveia, A.; Ribeiro,
H.M.; Almeida, A.J. Improved morphine-loaded hydrogels for wound-related pain relief. Pharmaceutics
2019, 11, 1–16, doi:10.3390/pharmaceutics11020076.
41. Costa, P.; Lobo, J.M.S. Modeling and comparison of dissolution profiles. Eur. J. Pharm. Sci. 2001, 13, 123–
133, doi:10.1016/S0928-0987(01)00095-1.
42. Pivetta, T.P.; Simões, S.; Araújo, M.M.; Carvalho, T.; Arruda, C.; Marcato, P.D. Development of
nanoparticles from natural lipids for topical delivery of thymol: Investigation of its anti-inflammatory
properties. Colloids Surf B Biointerfaces 2018, 164, 281–290, doi:10.1016/j.colsurfb.2018.01.053.
43. Centers for Disease Control and Prevention: Facts about Bromine. Available online:
https://emergency.cdc.gov/agent/bromine/basics/facts.asp (accessed on 26 July 2019).
44. Baroni, A.; Buommino, E.; De Gregorio, V.; Ruocco, E.; Ruocco, V.; Wolf, R. Structure and function of the
epidermis
related
to
barrier
properties.
Clin.
Dermatol.
2012,
30,
257–262,
doi:10.1016/j.clindermatol.2011.08.007.
45. Lambers, H.; Piessens, S.; Bloem, A.; Pronk, H.; Finkel, P. Natural skin surface pH is on average below 5,
which is beneficial for its resident flora. Int. J. Cosmet. Sci. 2006, 28, 359–370, doi:10.1111/j.1467-
2494.2006.00344.x.
46. Barnes, H.A.; Hutton, J.F.; Walters, K. An Introduction to Rheology, 1st ed.; Elsevier Science: Amsterdam, The
Netherlands, 1989; pp. 1–200.
47. Schramm, G. A Practical Approach to Rheology and Rheometry, 2nd ed.; Thermo Electron: Waltham, MA, USA,
2004; pp. 1–259.
48. Gilbert, L.; Picard, C.; Savary, G.; Grisel, M. Rheological and textural characterization of cosmetic emulsions
containing natural and synthetic polymers: Relationships between both data. Colloids Surfaces A
Physicochem. Eng. Asp. 2013, 421, 150–163, doi:10.1016/j.colsurfa.2013.01.003.

Pharmaceutics 2020, 12, 358
19 of 19
49. Eccleston, G.M. Emulsions and microemulsions. In Encyclopedia of Biomedical Polymers and Polymeric
Biomaterials, 1st ed.; Mishra, M., Ed.; CRC Press: Boca Raton, FL, USA, 2015; Volume 11, pp. 3259–3276,
doi:10.1016/j.cocis.2012.07.004.
50. Ribeiro, H.M.; Morais, J.A.; Eccleston, G.M. Structure and rheology of semisolid o/w creams containing
cetyl alcohol/non-ionic surfactant mixed emulsifier and different polymers. Int. J. Cosmet. Sci. 2004, 26, 47–
59, doi:10.1111/j.0412-5463.2004.00190.x.
51. Callender, S.P.; Mathews, J.A.; Kobernyk, K.; Wettig, S.D. Microemulsion utility in pharmaceuticals:
Implications for multi-drug delivery. Int. J. Pharm. 2017, 526, 425–442, doi:10.1016/j.ijpharm.2017.05.005.
52. Lippacher, A.; Müller, R.H.; Mäder, K. Liquid and semisolid SLNTM dispersions for topical application:
Rheological characterization. Eur. J. Pharm. Biopharm. 2004, 58, 561–567, doi:10.1016/j.ejpb.2004.04.009.
53. Otto, A.; Du Plessis, J.; Wiechers, J.W. Formulation effects of topical emulsions on transdermal and dermal
delivery. Int. J. Cosmet. Sci. 2009, 31, 1–19, doi:10.1111/j.1468-2494.2008.00467.x.
54. Dalvi, U.G.; Zatz, J.L. Effect of nonionic surfactants on penetration of dissolved benzocaine through hairless
mouse skin. J. Soc. Cosmet. Chem. 1981, 32, 87–94.
55. Florence, A.T.; Gillan, J.M.N. Biological implications of the use of surfactants in medicines and the biphasic
effects of surfactants in biological systems. Pestic. Sci. 1975, 6, 429–439.
56. Sarpotdar, P.P.; Zatz, J.L. Evaluation of penetration enhancement of lidocaine by nonionic surfactants
through hairless mouse skin in vitro. J. Pharm. Sci. 1986, 75, 176–181.
57. Mohammed, D.; Hirata, K.; Hadgraft, J.; Lane, M.E. Influence of skin penetration enhancers on skin barrier
function and skin protease activity. Eur. J. Pharm. Sci. 2014, 51, 118–122, doi:10.1016/j.ejps.2013.09.009.
58. Lin, Y.K.; Yang, S.H.; Chen, C.C.; Kao, H.C.; Fang, J.Y. Using imiquimod-induced psoriasis-like skin as a
model to measure the skin penetration of anti-psoriatic drugs. PLoS ONE 2015, 10, e0137890,
doi:10.1371/journal.pone.0137890.
59. Van der Fits, L.; Mourits, S.; Voerman, J.S.A.; Kant, M.; Boon, L.; Laman, J.D.; Cornelissen, F.; Mus, A.M.;
Florencia, E.; Prens, E.P.; et al. Imiquimod-Induced Psoriasis-Like Skin Inflammation in Mice Is Mediated
via the IL-23/IL-17 Axis. J. Immunol. 2009, 182, 5836–5845, doi:10.4049/jimmunol.0802999.
60. Alvarez, P.; Jensen, L.E. Imiquimod Treatment Causes Systemic Disease in Mice Resembling Generalized
Pustular Psoriasis in an IL-1 and IL-36 Dependent Manner. Mediators Inflamm. 2016, 2016, 6756138,
doi:10.1155/2016/6756138.
61. Jang, H.J.; Shin, C.Y.; Kim, K.B. Safety Evaluation of Polyethylene Glycol (PEG) Compounds for Cosmetic
Use. Toxicol. Res. 2015, 31, 105–136, doi:10.5487/TR.2015.31.2.105.
62. Lémery, E.; Briançon, S.; Chevalier, Y.; Bordes, C.; Oddos, T.; Gohier, A.; Bolzinger, M.A. Skin toxicity of
surfactants: Structure/toxicity relationships. Colloids Surfaces A Physicochem. Eng. Asp. 2015, 469, 166–179,
doi:10.1016/j.colsurfa.2015.01.019.
63. Sun, J.; Zhao, Y.; Hu, J. Curcumin Inhibits Imiquimod-Induced Psoriasis-Like Inflammation by Inhibiting
IL-1beta and IL-6 Production in Mice. PLoS ONE 2013, 8, e67078, doi:10.1371/journal.pone.0067078.
64. Chen, Y.H.; Wu, C.S.; Chao, Y.H.; Lin, C.C.; Tsai, H.Y.; Li, Y.R.; Chen, Y.Z.; Tsai, W.H.; Chen, Y.K.
Lactobacillus pentosus GMNL-77 inhibits skin lesions in imiquimod-induced psoriasis-like mice. J. Food
Drug Anal. 2017, 25, 559–566.
65. Grine, L.; Dejager, L.; Libert, C.; Vandenbroucke, R.E. Dual Inhibition of TNFR1 and IFNAR1 in
Imiquimod-Induced Psoriasiform Skin Inflammation in Mice. J. Immunol. 2015, 194, 5094–5102,
doi:10.4049/jimmunol.1403015.
© 2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
