Thermal [4 + 2] cycloadditions of 3-acetyl-, 3-carbamoyl-, and 3-ethoxycarbonyl-coumarins with 2,3-dimethyl-1,3-butadiene under solventless conditions: A structural study

Article abstract of DOI:10.3390/molecules15031513

The thermal [4+2] cycloadditions of 3-acetyl-, 3-carbamoyl, and 3-ethoxycarbonylcoumarins with 2,3-dimethyl-1,3-butadiene under solvent free conditions are reported, as well as the epoxidation reactions of some adducts. Discussion is focused on the struct

Full text of DOI:10.3390/molecules15031513

Molecules 201, 15, 1513-1530; doi:10.3390/molecules15031513
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Thermal [4 + 2] Cycloadditions of 3-Acetyl-, 3-Carbamoyl-, and
3-Ethoxycarbonyl-Coumarins with 2,3-Dimethyl-1,3-butadiene
under Solventless Conditions: A Structural Study
Irma Y. Flores-Larios 1, Lizbeth López-Garrido 2, Francisco J. Martínez-Martínez 1,*,
Jorge González 1, Efrén V. García-Báez 2, Alejandro Cruz 2 and Itzia I. Padilla-Martínez 2,*
1
Facultad de Ciencias Químicas, Universidad de Colima, km 9 Carretera Coquimatlán-Colima,
Coquimatlán Colima 28400, Mexico
2
Departamento de Química, Unidad Profesional Interdisciplinaria de Biotecnología del Instituto
Politécnico Nacional, Av. Acueducto s/n, Barrio la Laguna Ticomán 07340, México D. F., Mexico
* Authors to whom correspondence should be addressed; E-Mail: ipadillamar@ipn.mx (I.I.P.-M.);
fjmartin@ucol.mx (F.J.M.-M.)
Received: 4 December 2009; in revised form: 27 February 2010 / Accepted: 8 March 2010 /
Published: 9 March 2010
Abstract: The thermal [4+2] cycloadditions of 3-acetyl-, 3-carbamoyl, and 3-ethoxy-
carbonylcoumarins with 2,3-dimethyl-1,3-butadiene under solvent free conditions are
reported, as well as the epoxidation reactions of some adducts. Discussion is focused on
the structural features of the Diels-Alder adducts and their epoxides, based upon NMR,
X-ray, and mass spectral data, and supported by ab initio theoretical calculations.
Keywords: coumarins; Diels-Alder adducts; solventless reactions; 6a,7,7a,8a,9,9a-
hexahydro-7a,8a-dimethyl-6-oxo-6H-5,8-dioxacyclopropa[b]phenantrenes
1. Introduction
Coumarins are widely known to undergo pericyclic reactions like photodimerization [1]. On this
topic and in the context of crystal engineering, our group has reported the solid state photodimerization
of ethyl coumarin-3-carboxylate (1a) and its 6-Cl and 6-Br derivatives 1b and 1c [2]. In contrast, the
use of coumarins as 2 components in Diels-Alder (DA) cycloadditions has been less studied due to

Molecules 2010, 15
1514
their low reactivity in these reactions. Only 3-substituted coumarins with electron-withdrawing groups
like COOEt [3], NO2 [4], SO2Ph, or heterocyclic rings [5], and very recently with CN [6], have been
reported to undergo DA reactions under high pressure conditions.
The DA reaction of 1a with 2,3-dimethyl-1,3-butadiene was realized in water alone and in CH2Cl2
under 9 kbar pressure [5]. The use of HfCl4·2THF as catalyst, and solvent free conditions (SFC)
significantly improve selectivity and yields [7]. However, independent results, obtained from our
group, indicate that this reaction can be performed without catalyst under SFC [8]. Thus, in this work
the synthesis of the (6aR,10aR)-rel-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran
derivatives 6-10 from the DA reaction of 3-acetyl-, 3-carbamoyl-, and 3-ethoxycarbonyl-coumarins 1-
5 with 2,3-dimethyl-1,3-butadiene under SFC as well as the synthesis of some of their epoxides 11-15
is reported (Scheme 1). The molecular structure of the compounds obtained is discussed on the basis of
their NMR and X-ray data.
Scheme 1. Synthesis scheme and numbering.
O8
8a
9
9
10
8
7a
O
H
1
H
9a
7
1
7
10a
6a
5
4
X
9b
X
10b
10
9
X
3
(ii)
R
R
2
3
6a
(i)
R
2
3
6
6
6
2
O
O
4a
O5
O
4a O 5
O
7
4
4
O1
O
8
Y
Y
Y
6
7
8
9
10
11
12
13
14
15
R = OEt
NHCH2(C6H5)
1
2
3
4
5
NH(CH)CH3(C6H5)
NHCH2CH2(C6H5)
CH3
a
H
H
b
c
d
e
f
H
g
h
i
X =
Y =
Cl Br NO2 OMe
H
Cl Cl Br
H
H
H
OMe Cl Br OMe
(i) 2,3-Dimethyl-1,3- butadiene under SFC; (ii) m-Chloroperbenzoic acid in CHCl3
2. Results and Discussion
The synthesis of the cycloadducts was performed, starting from coumarins 1-5, in a sealed glass
ampoule with an excess of the diene (6 equivalents) at 160 ºC, to give the corresponding DA
cycloadducts 6-10, in moderate to good yields (60-85%). The isolated yield of the adduct 6a (80%),
after purification by column chromatography, is lower than that reported in CH2Cl2 at high pressure [5]
or under SFC in the presence of catalysts [7], but higher than that reported in water at 150 ºC (58%)
[5]. The cycloadduct 7a was obtained in 85% yield, which is higher than the reported value (76%)
using toluene as solvent [7].
In all cases racemic mixtures of the cis fused rings were formed, except in the case of 8a which was
synthesized using enantiopure (R)-1-phenylethylamine to generate coumarin 3a. Thus, it is assumed
that 8a was obtained as a 60:40 mixture of (6aS,10aS,1’R) and (6aR,10aR,1’R) diastereomers,
1
respectively. For this mixture, two sets of signals in the H-NMR spectrum are clearly observed at 

Molecules 2010, 15
1515
5.89, 1.21 (major) and 5.82, 1.37 (minor). They are doublets assigned to the NH and CH3 protons of
the amide moiety, respectively. In the former set, the signal for the CH3 protons appears shielded
because of the effect exerted by the coumarin aromatic ring diamagnetic currents. The ab initio
calculated molecular geometry of (6aS,10aS,1’R) and (6aR,10aR,1’R) diastereomers predicts that the
CH3 protons, in the former, are in the appropriate position to be shielded by diamagnetic currents of
the aromatic ring, with 1.24 kcal mol-1 in favour of the (6aS,10aS,1’R) diatereomer. These results are
in agreement with the preference of the diene approach to the less hindered face of the starting
coumarin 3a (Figure 1). However, the asymmetric induction of the chiral amine pendant group is poor
in comparison with the results obtained for bulkier 3-alkoxides [10], because of its relatively long
distance from the reactive double bond.
Figure 1. Calculated molecular structures of the (6aS,10aS,1’R) and (6aR,10aR,1’R)
diastereomers of the cycloadduct 8a. In the former (left) the methyl protons of the chiral
amine residue lie in the shielding cone of the coumarin benzenoid ring.
In order to test the stereofacial selectivity of the addition reaction on the cyclohexene ring, the
epoxidation of compounds 6a-10a and 10d,f,i with m-chloroperbenzoic acid (m-CPBA) was
performed. The reaction proceeded in moderate 70–80% (11a-15a) to very good yields 90-96%
(15d,f,i). The X-ray data (vide infra) show that the oxygen atom is stereoselectively added to the less
hindered face of the cyclohexene ring, opposite to the benzopyrone ring. Therefore, the racemic
mixture (6aR,7aR,8aS,9aR) and (6aS,7aS, 8aR,9aS) is formed except in the case of compound 13a,
which was obtained as a 60:40 mixture of diastereomers because of the presence of the amine moiety
stereocentre. Thus, the original diastereomeric ratio of the starting adduct 8a is preserved (vide supra).
1
13
The molecular structure in solution was analyzed by H- and C-NMR, the numbering scheme is
1
given in Figure 1. Several differences in the H-NMR spectra appear as a consequence of the
cycloaddition. The H-4 signal in coumarins 1-5 usually appears as a singlet between 8.0 and 8.4 ppm
[11], whereas in the cycloadducts 6-10 it becomes H-10a and appears as a doublet of doublets, by
coupling with H2-10, in the range 3.36–3.65 ppm. Irradiation of H-10a signal gave NOEs with H-1,
Heq-10, and alkyl protons of the R group, confirming the cis fusion between dihydropyrone and
cyclohexene rings. Besides NOE experiments, the assignments of all 1H signals were achieved through
COSY experiments. The mean values of the coupling constants of H-10a with Hax-10 (11.0–12.6 Hz)

Molecules 2010, 15
1516
and Heq-10 (5.0–6.5 Hz), suggest a pseudo axial-axial and pseudo axial-equatorial relationship,
respectively, and thus an anchored conformation for the cyclohexene ring. The nature of the carbonyl
group at the 6a position exerts influence on the chemical shift of H-10a: for COOEt and COMe, H-10a
appears in the range of 3.36–3.47 ppm whereas for CONHR it appears more deshielded, in the range
3.58–3.65 ppm, due to the effect of the amide mesomerism. The chemical shift of Hax-7 in the
acetylated adducts 10 appears at higher field (2.04–2.38 ppm) than in the carbamoyl and
ethoxycarbonyl adducts 6a-8a (2.47–2.50 ppm). This trend could be explained by a syn or anti
conformational preference of the 3-CO with respect to the lactone carbonyl moiety. In compounds 6a-
1
8a the most populated conformer on the H- NMR time scale is the anti one with the 3-CO group
appropriately positioned to exert a deshielding effect on Hax-7, whereas the syn conformer is the
predominant form in adducts 10a-i. The chemical shift of Hax-7, in the adduct 9a, is out of range
( 2.30) because of the protective effect exerted by the phenyl ring of the 2-phenylethyl amine residue.
Finally, the chemical shift of Heq-7 is in the range of 2.78 to 2.91 ppm, due to the deshielding effect of
the dihydropyrone carbonyl moiety.
The change in the hybridization of C-3 and C-4 from sp2 in coumarins 1-5 to sp3 character in
adducts 6-10 shifts the corresponding carbon atoms C-6a and C-10a, to lower frequencies, from 118–
125 to 54–61 and from 147–149 to 36–37 ppm, respectively. The nature of the 3-substituent influences
the chemical shift of the carbon atom carrying the substituent: thus C-6a appears in the range of 54–55
ppm for amide and ester adducts 6a-9a and at 60–61 ppm for the acetylated adducts 10a-i. The
difference in chemical shifts is preserved from the starting coumarins: C-3 resonates at 118–120 ppm
in compounds 1a-4a9 and at 124–125 ppm in 5a-i.
Epoxidation changes the hybridation of C-8 and C-9 atoms from sp2 in the cycloadducts 6-10 to sp3
character in epoxides 11a-15a and 15d,f,i, shifting the corresponding C-7a and C-8a carbon atoms
1
approximately by 62 ppm to lower frequencies. Subtle changes are also observed in the H-NMR
spectra: the oxirane methyl protons, Hax-7, and Hax-9 (these last Hax-10 before the epoxidation) are
shifted to low frequencies by approximately 0.3 ppm, owing to the effect of the steric compression
exerted by the new formed three-membered ring.
Figure 2. Molecular structure of cycloadduct 10b and 15i. Thermal ellipsoids drawn at the
50% probability level.

Molecules 2010, 15
1517
The molecular structures of cycloadduct 10b and epoxide 15i, obtained by X-ray diffraction, are
shown in Figure 2. Selected bond lengths and angles are listed in Table 1. In consequence of the
transformation of C3―C4 double bond in coumarins to the single bond C6a―C10a in the adducts, this
bond length enlarges by 0.18(2) Å, from 1.359(2) in 5a [12] to 1.538(3) in 10b. Epoxidation of adducts
also changes the hybridation of C8 and C9 atoms enlarging C8―C9 bond length by 0.13(1) Å, in
agreement with their new sp3 character, from 1.331(3) in 10b to 1.462(7) in 15i (C7A―C8A),
respectively.
Table 1. Selected bond lengths and angles from X-ray data of compounds 10b and 15i.
Atoms
10b (X = Cl)
Bond lengths/Å
15i (X = Br)
O(5)C(6)
O(6)C(6)
1.373(3)
1.190(3)
1.526(3)
1.536(3)
1.538(3)
1.537(3)
1.509(3)
1.364(6)
1.195(6)
1.522(7)
1.541(6)
1.551(6)
1.527(6)
C(6)C(6A)
C(6A)C(7)
C(6A)C(10A)
C(6A)C(13)
C(7)C(8)
C(7)C(7A)
C(8)C(9)
1.501(7)
1.462(7)
1.505(6)
1.331(3)
1.500(3)
1.530(3)
1.742(2)
C(7A)C(8A)
C(9)C(10)
C(8A)C(9)
C(10)C(10A)
C(9)C(9A)
XC(2)a
1.523(6)
1.900(5)
Bond angles/º
C(4A)O(5)C(6)
C(6A)C(7)C(8)
C(9)C(10)C(10A)
C(8A)C(9)C(9A)
O(13)C(13)C(6A)
XC(2)C(1)a
120.94(16)
115.64(18)
112.61(18)
120.2(4)
117.2(4)
113.7(4)
121.1(5)
119.1(4)
120.30(19)
119.68(15)
Torsion angles/º
C(6)O(5)C(4A)C(10B)
C(7)C(6A)C(6)O(5)
O(5)C(6)C(6A)C(13)
C(6)C(6A)C(13)O(13)
O(13)C(13)C(6A)C(7)
O(8)C(9)C(10)C(10A)
O(8)C(8A)C(9)C(9A)
C(10A)C(10B)C(4A)O(5)
C(9A)C(9B)C(4A)O(5)
C(7)C(8)C(9)C(10)
20.4(3)
166.50(17)
74.9(2)
15.2(3)
104.8(2)
23.4(3)
23.2(6)
163.0(4)
77.6(5)
2.6(6)
116.7(5)
-42.6(5)
-1.6(7)
-3.2(3)
0.4(3)
C(7)C(7A)C(8A)C(9)
C(9B)C(1)C(2)X
0.9(7)
177.9(3)
179.04(13)

Molecules 2010, 15
1518
The X-ray structures of compounds 10b and 15i show that the CO of the acetyl group is pointing
towards the lactone ring [C(7)C(6A)C(13)O(13) torsion angles of -104.8(2), -and -116.7(5)º for 10b
and 15i, respectively. Thus, the syn conformation between both carbonyls is the preferred in the solid
state, the same conformational preference being observed in solution by NMR (vide supra). The
torsion angles C(10A)C(10B)C(4A)O(5) (10b) and C(9A)C(9B)C(4A)O(5) (15i) in dihydropyrone
ring, and C(7)C(8)C(9)C(10) (10b) and C(7)C(7A)C(8A)C(9) (15i) in cyclohexene ring, take values
near to zero, in agreement with a distorted twisted boat conformation for both rings. Epoxydation has a
negligible influence on the conformation of the cyclohexane ring as observed in compound 15i.
The supramolecular structure of DA adduct 10b and epoxide 15i is organized by weak CH···A
(A = O, ) interactions. Nevertheless, they are scarce in comparison with those encountered in the
crystal packing of the starting coumarins [12]. Thus, compound 15i is worthy to mention, since its
crystal network is organized by several CH···O and Br···Br polarization-induced interactions, in the
bc plane [Figure 3(a)], and CH··· bifacial contacts developing the third dimension along the (7 0 3)
direction [(Figure 3(b)]. The Br···Bri distance of 3.496(6) Å (symmetry code: (i) 1-x, 1-y, 2-z) is
shorter than the reported value of 3.618(4) Å for 6-bromo-N-(2-hydroxyethyl)-2-oxo-2H-1-
benzopyran-3-carboxamide [13]. The geometric parameters associated with non covalent interactions
are listed in Table 2, C—H···O [14] and C—H··· [15] interactions are in agreement with accepted
criteria and particularly with values reported for other coumarins [12,16].
Figure 3. Supramolecular structure of compound 15i. (a) View in the bc plane showing
CH···O and Br···Br contacts. (b) View of bifacial CH··· contacts developing the third
dimension along the (7 0 3) direction. Dashed lines represents intermolecular CH···A
(A = O, ) contacts.

Molecules 2010, 15
1519
Table 2. Geometric parameters associated with intermolecular hydrogen interactions in
compounds 10b and 15i.
Compound
D―H···A (symmetry code)
C(14)―H14B···Cg(2) (x, y+1, z)
C(10)―H(10)···O(13) (x, ½-y, z+½)
C(1)―H(1)···O(8) (-x, 1-y, 1-z)
C(9)―H(10A)···O(8) (-x, 1-y, 1-z)
C(14)―H(14A)···O(8) (-x, 1-y, 1-z)
C(9)―H(9A)···O(6) (1-x, 2-y, 1-z)
C(14)―H(14C)···Cg(3)a (x-1, y, z)
C(15)―H(15A)···Cg(3)a (1-x, 2-y, 2-
z)
D―H/Å H···A/Å D···A/Å D―H···A/°
10b
2.66
2.37
2.56
2.59
2.51
2.51
2.76
2.92
3.626(2)
3.199(2)
3.317(6)
3.491(6)
3.421(7)
3.428(6)
3.603(6)
3.764(6)
169
140
139
153
160
157
147
148
15i
0.93
0.98
0.96
0.97
a Cg(3) is the centroid of the benzenoid ring (C1-C4/C4a/C9B).
The molecular peaks of 3-acetylcoumarin adducts 10 and their epoxides 15a,d,f,i are barely
observed (1%) by mass spectrometry. Nevertheless all compounds are cleaved and rearranged
following the typical fragmentation path depicted in Scheme 2. Cycloadducts and epoxides give the
corresponding fragments, m/z 227 for 6a-10a and 243 for 11a-15a, by the loss of 3-ethoxycarbonyl,
3-carbamoyl, or 3-acetyl angular groups. The species derived from 6-10 are further broken by the loss
of CO and rearranged to the 2,3-dimethyl-1,4,4a,9b-tetrahydro-dibenzofuran ion (m/z 199) or by the
loss of dimethylacetylene (m/z 54) to form the oxacyclobutanaphtalene species (m/z 173). The species
derived from epoxides 11-15 mainly rearrange to the corresponding dibenzofuran (m/z 225) or
chromene species (m/z 211) after the loss of water or O2, respectively. Both fragmentation paths are in
agreement with those found for other coumarins [17]. It is worthy to mention that retro-DA conversion
was observed only in compound 10e.
Scheme 2. Typical fragmentation path of DA adducts 6a-10ai and epoxides 11a-15a-i by
mass spectrometry.
X
-CO
O
-28
Y
-COR
X
X
a, m/z = 199
R
+
O
O
O
O
O
X
-54
Y
Y
-
a, m/z = 227
CH3CCCH3
6a-10a-i
O
Y
a, m/z = 173
X
-H2O
-18
O
O
O
O
X
-COR
Y
X
a, m/z = 225
R
+
O
O
O
O
-32
-O2
Y
Y
11a-15a-i
a, m/z = 243
X
O
Y
a, m/z = 211

Molecules 2010, 15
1520
3. Experimental
3.1. General methods
All chemicals and solvents were of reagent grade and used as received. Melting points were
measured on an Electrothermal IA 9100 apparatus and were uncorrected. IR spectra were recorded in
KBr disks using a Perkin-Elmer 16F PC IR spectrophotometer. Mass spectra were obtained in a
GC/MS system (Varian) with an electron ionization mode. Elemental analyses (EA) were performed
1
on a Perkin-Elmer 2400 elemental analyzer. H- and 13C-NMR spectra were recorded on a Varian
Mercury 300 (1H, 300.08; 13C, 75.46 MHz) instrument in CDCl3 solutions, unless otherwise specified,
n
1
measured with SiMe4 as the internal reference, are in ppm and coupling constants J in Hz. H- and
13C-NMR assignments were achieved on the basis of NOE, COSY and HETCOR experiments. Single-
crystal X-ray diffraction data for molecules 10b and 15i were collected on a Bruker Apex II area
detector diffractometer at 100 and 293 K, respectively, with Mo K radiation,  = 0.71073 Å. A
semiempirical absorption correction was applied using SADABS [18], and the program SAINT [18]
was used for integration of the diffraction profiles. The structures were solved by direct methods using
SHELXS97 [19] program of WinGX package [20]. The final refinement was performed by full-matrix
least-squares methods on F2 with SHELXL97 [19] program. H atoms on C, N and O were positioned
geometrically and treated as riding atoms, with C―H = 0.93-0.98 Å, and with Uiso(H) = 1.2Ueq(C).
Mercury was used for visualization, molecular graphics and analysis of crystal structures [21],
software used to prepare material for publication was PLATON [22]. Crystallographic data (excluding
structure factors) for the structures in this paper have been deposited with the Cambridge
Crystallographic Data Centre as supplementary publication CCDC numbers 735605 (10b) and 721872
(15i). Copies of the data can be obtained, free of charge, on application to CCDC, 12 Union Road,
Cambridge CB2 1EZ, UK, (Fax: +44-01223-336033 or E-Mail: deposit@ccdc.cam.ac.uk). Crystals
suitable for X-ray analysis were obtained from saturated CHCl3 solutions. The program GAUSSIAN98
[23] was used to perform the ab initio molecular orbital calculations at RHF-631G** level of theory.
3.2. General synthetic procedure for coumarins 1-5
The starting coumarins 1a-4a were synthesized according with the methodology reported elsewhere
[11,16,24]. 6-Substituted acetyl coumarins 5a-i were synthesized by Knoevenagel condensation of
ethyl acetoacetate and the corresponding 5-substituted 2-hydroxybenzaldehyde, the spectroscopic data
of 5a-d are in agreement with literature [25].
3-Acetyl-6-methoxy-2H-1-benzopyran-2-one (5e). Prepared from 0.41 mL (3.3 mmol) of 2-hydroxy-5-
methoxybenzaldehyde and 0.42 mL (3.3 mmol) of ethyl acetoacetate. Yellow solid 89% yield, mp
1
180–183 ºC. IR (cm-1): 1723 (OC=O), 1677 (C=O), 1226, 1197 (C-O). H-NMR: 8.44 (s, 1H, H4),
7.28 (d, 1H, 3J = 9.1, H8), 7.20 (dd, 1H, 3J = 9.1, 4J = 2.9, H7), 7.02 (d, 1H, 4J = 2.6, H5), 3.85 (s, 3H,
OCH3), 2.70 (s, 3H, CH3); 13C-NMR: 195.9 (CO), 159.7 (OCO), 156.6 (C6), 150.1 (C10), 147.6 (C4),
124.8 (C3), 123.2 (C7), 117.9 (C5), 118.7 (C9), 111.3 (C8), 56.1 (OCH3), 30.9 (CH3); EA (%)
calculated for C12H10O4: 66.05 C, 4.62 H; found: 66.04 C, 4.61 H.

Molecules 2010, 15
1521
3-Acetyl-8-methoxy-2H-1-benzopyran-2-one (5f). Prepared from 0.5 g (3.3 mmol) of 2-hydroxy-3-
methoxybenzaldehyde and 0.42 mL (3.3 mmol) of ethyl acetoacetate. Yellow solid, 88% yield, mp
1
171–174 °C. IR (cm-1): 1727 (OC=O), 1682 (C=O), 1278, 1197 (C-O). H-NMR: 8.42 (s, 1H, H4),
7.25 (d, 1H, 4J = 1.1, 3J = 5.7, H7), 7.14 (d, 1H, 4J = 2.0, 3J = 5.7, H5), 7.18 (t, 1H, 3J = 5.5, 4J = 2.0,
H6), 3.94 (s, 3H, OCH3), 2.68 (s, 3H, CH3); 13C-NMR: 195.8 (CO), 158.9 (OCO), 145.1 (C10), 147.9
(C4), 147.2 (C8), 125.0 (C5), 124.8 (C3), 121.5 (C6), 116.0 (C7), 118.9 (C9), 56.5 (OCH3), 30.8
(CH3); EA (%) calculated for C12H10O4: 66.05 C, 4.62 H; found: 66.15 C, 4.60 H.
3-Acetyl-6,8-dichloro-2H-1-benzopyran-2-one (5g). Prepared from 0.5 g (2.6 mmol) of 3,5-
dichlorosalicylaldehyde and 0.33 mL (2.6 mmol) of ethyl acetoacetate. White solid in 48% yield, mp
1
172–175 ºC. IR (cm-1): 1749 (OC=O), 1676 (C=O), 1217 (C-O), 769 (C-Cl). H-NMR: 8.37 (s, 1H,
4
4
13
H4), 7.54 (d, 1H, J = 2.4, H7), 7.66 (d, 1H, J = 2.4, H5), 2.71 (s, 3H, CH3); C-NMR 194.8 (CO),
157.7 (OCO), 149.7 (C10), 145.4 (C4), 122.9 (C8), 127.8 (C5), 126.2 (C3), 130.5 (C6), 134.2 (C7),
120.1 (C9), 30.7 (CH3); EA (%) calculated for C11H6O3Cl2: 51.39 C, 2.35 H; found: 51.53 C, 2.42 H.
3-Acetyl-8-bromo-6-chloro-2H-1-benzopyran-2-one (5h). Prepared from 0.5 g (2.1 mmol) of 3-bromo-
5-chloro-salicylaldehyde and 0.27 mL of ethyl acetoacetate (2.1 mmol). Yellow solid in 60% yield, mp
1
192–196 ºC. IR (cm-1): 1740 (OC=O), 1675 (C=O), 1202 (C-O), 760 (C-Cl), 556 (C-Br). H-NMR
(DMSO-d6): 8.55 (s, 1H, H4), 8.05 (d, 1H, 4J = 2.2, H7), 8.12 (d, 1H, 4J = 2.2, H5), 2.56 (s, 3H, CH3);
13C-NMR: 195.4 (CO), 158.0 (OCO), 150.7 (C10), 146.1 (C4), 110.5 (C8), 129.8 (C5), 126.6 (C3),
129.5 (C6), 136.5 (C7), 121.1 (C9), 30.7 (CH3); EA (%) calculated for C11H6O3ClBr: 43.82 C, 2.01 H;
found: 43.70 C, 2.12 H.
3-Acetyl-6-bromo-8-methoxy-2H-1-benzopyran-2-one (5i). Prepared from 0.5 g (2.2 mmol) de
5-bromo-2-hydroxy-3-methoxybenzaldehyde and 0.28 mL of ethyl acetoacetate (2.2 mmol). Yellow
solid in 89% yield, mp 215–218 ºC. IR (cm-1): 1735 (OC=O), 1674 (C=O), 1235, 1128 (C-O), 662
(C-Br). 1H-NMR: 8.36 (s, 1H, H4), 7.24 (d, 1H, 4J = 2.1, H7), 7.34 (d, 1H, 4J = 2.1, H5), 3.96 (s, 3H,
OCH3), 2.71 (s, 3H, CH3); 13C-NMR: 195.1 (CO), 158.0 (OCO), 144.0 (C10), 146.3 (C4), 147.6 (C8),
123.1 (C5), 125.5 (C3), 117.1 (C6), 118.8 (C7), 119.7 (C9), 56.5 (OCH3), 30.5 (CH3); EA (%)
calculated for C12H9O4Br: 48.5 C, 3.1 H; found: 48.45 C, 2.95.
3.3. General synthetic procedure for DA adducts 6-10
1 mmol (typically 100–300 mg) of the corresponding coumarin 1-5 and the appropriate volume
equivalent to 6 mmol of 2,3-dimethyl-1,3-butadiene (typically 0.3–1.0 mL) were placed in a glass
ampoule; the sealed ampoule was placed inside a metallic capsule and heated in a sand bath at 160 ºC
for a period of 24 hours. The ampoule content was dissolved in CHCl3 and evaporated to dryness. The
resultant solid was washed with hot hexane and the insoluble solid was purified by CC in SiO2–gel,
using CHCl3 as eluent. Cycloadducts 6a [5], 7a [9] are reported elsewhere.
(6aR,10aR)-
and
(6aS,10aS)-N-[(R)-1-Phenylethyl]-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxo-
dibenzo[b,d]pyran-6a-carboxamide (8a). White crystalline solid in 77% yield, mp 168.9–171.4 °C.

Molecules 2010, 15
1522
1
IR/ (cm-1): 3312 (NH), 1784 (OC=O), 1629 (NC=O), 1532 (C=C), 1222 (N-C), 1146 (C-O). H-
3
3
NMR: 7.30 (m, 1H, H3), 7.26 (t, 2H, J = 7.3 and 7.7, Hm), 7.13 (t, 1H, J = 7.3, Hp), 7.14 (d, 2H,
3J = 7.3, Ho), 7.07 (t, 1H, J = 8.1 and 8.4, H2), 7.00 (d, 1H, J = 8.1, H1), 6.83 (dd, 1H, J = 5.3,
4J = 2.2, H4), 5.89, 5.82 (d, 1H each, 3J = 7.5, N-H), 4.88 (dq, 1H, 3J = 7.3, CH3), 3.58 (m, 1H, H10a),
3
3
3
3
3
3
2.90 (t, 1H, J = 18.3, Heq-7), 2.49 (d, 1H, J = 17.4, Hax-7), 2.32 (t, 1H, J = 18.7 and 12.3, Heq-10),
2.02 (m, 1H, Hax-10), 1.67, 1.60 (s, 3H each, 2CH3), 1.37, 1.21 (d, 3H, J = 7.0, CH3); 13C-NMR:
3
170.6, 170.5 (NCO), 167.6, 167.4 (OCO), 150.2 (C4a), 142.5, 142.2 (Ci), 129.0 (C3), 128.7, 128.6
(Cm), 128.5, 128.4 (C1), 128.1 (C10b), 128.0, 127.7 (C2), 127.4, 126.1 (Cp), 125.5, 125.7 (Co), 123.5,
123.6 (C9), 123.2, 123.3 (C8), 116.8, 116.7 (C4), 55.0, 54.8 (C6a), 49.5, 49.2 (NCH), 37.0, 36.9 (C7),
36.8, 36.8 (C10), 36.3 (C10a), 21.6, 21.4 (CH3CH), 18.8, 18.8 (CH3); GC/MS m/z (%): 375 (M+, 24),
281 (38), 227 (100), 211 (5), 199 (3), 105 (29), 79 (12), 44 (5).
(6aR,10aR)-rel-N-(2-Phenylethyl)-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran-6a-
carboxamide (9a). White crystalline powder in 84% yield, mp 138.6–140.0 °C. IR/ (cm-1): 3333
1
(NH), 1771 (OC=O), 1634 (NC=O), 1546 (C=C), 1222 (C–O), 1144 (C–N). H-NMR: 7.25 (t, 2H,
3
3
3J = 7.3, Hm), 7.27 (d, 1H, J = 7.3, H1), 7.21 (dt, 1H, 7.0 Hz, H3), 7.11 (ddt, 1H, J = 7.2 and 7.7,
4J = 1.3, H2), 7.05 (dd, 2H, 3J = 7.1, Ho), 7.00 (dd, 1H, 3J = 7.5, H4), 5.79 (t, 1H, 3J = 5.4, NH), 3.58
3
3
4
(dd, 1H, J = 11.7 and 11.7, H10a), 3.34 (dt, 2H, J = 7.2 and 7.2, J = 2.0, NCH2), 2.79 (d, 1H,
3J = 17.1, Heq-7), 2.61 (m, 2H, CH2), 2.30 (d, 1H, 3J = 16.7, Hax-7), 2.26 (d, 1H, Heq-10), 2.00 (dd, 1H,
3J = 15.5 and 12.0, Hax-10), 1.58, 1.65 (s, 3H, 2CH3); 13C-NMR: 170.4 (NC=O), 168.4 (OC=O), 150.0
(C4a), 138.4 (Ci), 129.0 (C10b), 128.9 (Co,m), 128.6 (Cp), 128.4 (C3), 127.9 (C1), 126.8 (C3), 125.4
(C2), 123.7 (C9), 123.1 (C8), 116.8 (C4), 41.3 (NCH2), 37.3 (C7), 36.5 (C10a), 36.3 (C13), 35.5
(CH2), 18.8, 18.7 (CH3); GC/MS m/z (%): 375 (M+, 20), 227 (100), 199 (3), 173 (7); EA (%)
calculated for C24H25O3N: 76.77 C, 6.71 H, 3.73 N; found: 76.70C, 6.72 H, 3.82 N.
(6aR,10aR)-rel-6a-Acetyl-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran (10a). White
crystalline powder in 83% yield, mp 86–88 ºC. IR/(cm-1): 1763 (OC=O), 1702 (C=O), 1159, 1140 (C-
1
3
4
3
O). H-NMR: 7.25 (m, 1H, H3), 7.22 (dd, 1H, J = 12.1, J = 1.8, H1), 7.10 (td, 1H, J = 7.3,
4J = 1.2, H2), 7.03 (dd, 1H, J = 7.9, J = 1.1, H4), 3.47 (dd, 1H, J = 11.2 and 11.4, H10a), 2.87 (d,
3
4
3
3
3
3
1H, J = 17.3, Heq-7), 2.31 (dd, 1H, J = 18.0, Hax-7), 2.24 (d, 1H, J = 12.0, Heq-10), 2.12 (s, 3H,
CH3), 2.06 (dd, 1H, Hax-10), 1.70, 1.62 (s, 3H, CH3); 13C-NMR 204.1 (CO), 168.6 (OCO), 150.4
(C4a), 128.9 (C3), 127.6 (C1), 127.5 (C10b), 125.1 (C2), 123.5 (C9), 122.8 (C8), 117.2 (C4), 60.6
(C6a), 36.8 (C10a), 35.9 (C10), 34.8 (C7), 26.2 (C14), 18.8, 18.9 (CH3); GC/MS m/z (%): 270 (M+, 4),
227 (100), 199 (8), 185 (7), 173 (10), 43 (22); EA (%) calculated for C17H18O3: 75.53 C, 6.73 H;
found: 75.50, 6.70 H.
(6aR,10aR)-rel-6a-Acetyl-2-chloro-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran
(10b). Pale yellow solid in 50% yield, mp 102–106 ºC. IR/(cm-1): 1781 (OC=O), 1699 (C=O), 1212,
1
3
4
4
1139 (C-O), 814 (C-Cl). H-NMR: 7.27 (dd, 1H, J = 8.0, J = 1.98, H3), 7.19 (d, 1H, J = 2.0, H1),
6.94 (d, 1H, 3J = 8.0 Hz, H4), 3.43 (dd, 1H, 3J = 6.2, 11.3, H10a), 2.86 (d, 1H, 2J = 16.0, Heq-7), 2.28
2
3
2
(dd, 1H, J = 18.3, J = 6.2, Heq-10), 2.13 (d, 1H, J = 16.0, Hax-7), 2.11 (s, 3H, H14), 2.02 (dd, 1H,
2J = 18.3, J = 11.3, Hax-10), 1.67 (s, 3H, CH3), 1.59 (s, 3H, CH3); 13C-NMR: 203.5 (CO), 167.9
3

Molecules 2010, 15
1523
(OCO), 148.9 (C4a), 130.1 (C10b), 129.3 (C2), 128.8 (C3), 127.6 (C1), 123.8 (C9), 122.9 (C8), 118.5
(C4), 60.2 (C6a), 36.6 (C10a), 35.7 (C10), 34.8 (C7), 26.3 (C14), 18.8, 18.9 (CH3); GC/MS m/z (%):
306 (M+, 1), 261 (100), 233 (11), 219 (11), 207 (10), 165 (5), 70 (7), 43 (26); EA (%) calculated for
C17H17O3Cl-0.4H2O: 65.45 C, 5.75 H; found 65.58 C, 5.79 H.
(6aR,10aR)-rel-6a-Acetyl-2-bromo-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran
(10c). Pale yellow solid in 55% yield, mp 50–54 °C. IR/(cm-1): 1773 (OC=O), 1711 (C=O), 1205,
1138 (C-O), 821 (C-Br). 1H-NMR: 7.30 (dd, 1H, 3J = 7.2, 4J = 1.7, H3), 7.27 (d, 1H, 4J = 1.7 Hz, H1),
6.86 (d, 1H, 3J = 7.2, H4), 3.41 (dd, 1H, 3J = 6.4, 11.4 Hz, H10a), 2.83 (d, 1H, 2J = 16.8, Heq-7), 2.14
2
(dd, 1H, 2J = 16.9, 3J = 11.4, Heq-10), 2.09 (s, 3H, H14), 2.04 (d, 1H, J = 16.9, Hax-7), 1.92 (dd, 1H,
2J = 16.8, 3J = 6.4, Hax-10), 1.57 (s, 3H, CH3), 1.66 (s, 3H, CH3);13C-NMR: 203.6 (CO), 167.9 (OCO),
149.4 (C4a), 130.4 (C1), 131.8 (C3), 129.6 (C2), 123.4 (C9), 122.8 (C8), 118.9 (C4), 117.7 (C10b),
60.3 (C6a), 36.5 (C10a), 35.7 (C10), 34.7 (C7), 26.2 (C14), 18.8, 18.9 (CH3); GC/MS m/z (%): 348
(M+, 1), 305 (100), 277 (5), 251 (6), 198 (10), 165 (10), 43 (58); EA (%) calculated for C17H17O3Br: C
58.47 C, 4.91 H; found: C 58.43 C, 4.82 H.
(6aR,10aR)-rel-6a-Acetyl-6a,7,10,10a-tetrahydro-8,9-dimethyl-2-nitro-6-oxodibenzo[b,d]pyran (10d).
Pale yellow powder in 81% yield, mp 142–147 C. IR/(cm-1): 1782 (OC=O), 1726 (C=O), 1525
1
4
3
4
(NO2), 1339, 1230 (C-O). H-NMR: 8.16 (d, 1H, J = 2.5, H1), 8.14 (dd, 1H, J = 9.3, J = 2.5, H3),
3
3
2
7.15 (d, 1H, J = 9.3, H4), 3.60 (dd,1H, J = 6.4, 11.1, H10a), 2.90 (d, 1H, J = 17.3, Heq-7), 2.38 (d,
1H,
2J = 17.3, Hax-7), 2.27 (dd, 1H, 2J = 16.7, 3J = 6.2, Heq-10), 2.15 (s, 3H, H14), 2.05 (dd, 1H, 2J = 16.7,
3J = 11.1, Hax-10), 1.62 (s, 3H, CH3), 1.71 (s, 3H, CH3); C-NMR: 202.7 (CO), 166.9 (OCO), 154.7
13
(C4a), 144.6 (C2), 128.9 (C10b), 124.8 (C3), 123.6 (C1), 123.3 (C9), 122.9 (C8), 118.1 (C4), 60.1
(C6a), 36.5 (C10a), 35.6 (C10), 34.6 (C7), 26.1 (C14), 18.8, 18.9 (CH3); GC/MS m/z (%): 315 (M+, 1),
272 (100), 244 (8), 230 (8), 218 (8), 204 (6), 67 (7), 43 (25); EA (%) calculated for C17H17O5N: 64.75
C, 5.43 H, 4.44 N; found 65.10 C, 5.65 H, 4.20 N.
(6aR,10aR)-rel-6a-Acetyl-6a,7,10,10a-tetrahydro-2-methoxy-8,9-dimethyl-6-oxodibenzo[b,d]pyran
(10e). Pale yellow solid in 55% yield, m.p 44–46 ºC. IR/(cm-1): 1761 (OC=O) 1710 (C=O) 1190,
1
4
3
1147 (C-O). NMR: H-NMR: 6.89 (d, 1H, J = 3.5, H1), 6.87 (d, 1H, J = 6.5, H4), 6.68 (dd, 1H,
3J = 6.5, 4J = 3.2, H3), 3.71 (s, 3H, OCH3), 3.36 (dd,1H, 3J = 6.5, 11.0, H10a), 2.78 (d, 1H, 2J = 16.7,
Heq-7), 2.19 (dd, 1H, 2J = 18.2, 3J = 6.5, Heq-10), 2.06 (s, 3H, H14), 2.09 (d, 1H, 2J = 16.7, Hax-7), 2.00
2
3
13
(dd, 1H, J = 18.2, J = 11.0, Hax-10), 1.59 (s, 3H, CH3), 1.63 (s, 3H, CH3); C-NMR: 203.7 (CO),
168.3 (OCO), 156.2 (C2), 143.8 (C4a), 128.0 (C3), 123.0 (C9), 122.4 (C8), 117.5 (C1), 113.2 (C10b),
112.3 (C4), 60.0 (C6a), 55.4 (OCH3), 36.7 (C10a), 35.4 (C10), 34.4 (C7), 25.9 (C14), 18.4, 18.5
(CH3); GC/MS m/z (%): 300 (M+, 1), 218 (80), 190 (5), 175 (15); EA (%) calculated for C18H20O4:
71.98 C, 6.71 H; found: 71.91 C, 6.65 H.
(6aR,10aR)-rel-6a-Acetyl-6a,7,10,10a-tetrahydro-4-methoxy-8,9-dimethyl-6-oxodibenzo[b,d]pyran
(10f). Pale yellow powder 85% yield, mp 115–119 ºC. IR (cm-1): 1769 (OC=O), 1706 (C=O), 1196,
1
3
3
1095 (C-O). H-NMR: 7.03 (dd, 1H, J = 8.4, 7.7 H2), 6.82 (d, 1H, J = 8.4, Hz, H1), 6.78 (d, 1H,

Molecules 2010, 15
3J = 7.7, H3), 3.85 (s, 3H, OCH3), 3.44 (dd, 1H, J = 6.4, 11.4, H10a), 2.88 (d, 1H, J = 16.7, Heq-7),
1524
3
2
2
3
2
2.21 (dd, 1H, J = 18.2, J = 6.4, Heq-10), 2.12 (s, 3H, H14), 2.11 (d, 1H, J = 16.7, Hax-7), 2.03 (dd,
2
3
13
1H, J = 18.5, J = 11.4, Hax-10), 1.68 (s, 3H, CH3),1.59 (s, 3H, CH3); C-NMR: 203.9 (CO), 167.9
(OCO), 147.8 (C10), 139.9 (C8), 128.7 (C9), 125.2 (C6), 123.5 (C9), 122.8 (C8), 119.1 (C7), 111.6
(C5), 60.4 (C6a), 56.2 (OCH3), 36.9 (C10a), 35.8 (C10), 34.9 (C7), 26.4 (C14), 18.8, 18.9 (CH3);
GC/MS m/z (%): 300 (M+, 1), 257 (100), 229 (7), 203 (8), 105 (2), 105 (2), 91 (4), 77 (4), 43 (17); EA
(%) calculated for C18H20O4: 71.98 C, 6.71 H; found: 72.25 C, 6.80 H.
(6aR,10aR)-rel-6a-Acetyl-2,4-dichloro-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-oxodibenzo[b,d]pyran
(10g). Pale yellow powder in 71% yield, mp 148–151 ºC. IR/(cm-1): 1787 (OC=O), 1703 (C=O),
1
4
4
1233, 1192 (C-O), 810 (C-Cl). H-NMR: 7.28 (d, 1H, J = 2.4, H3), 7.11 (d, 1H, J = 2.4, H1), 3.47
(dd, 1H, 3J = 6.2, 11.5, H10a), 2.89 (d, 1H, 2J = 17.0, Heq-7), 2.28 (dd, 1H, 2J = 17.9, 3J = 6.2, Heq-10),
2.17 (d, 1H, 2J = 18.7, Hax-7), 2.14 (s, 3H, H14), 1.97 (dd, 1H, 2J = 18.9, 3J = 9.3, Hax-10), 1.69 (s, 3H,
13
CH3), 1.59 (s, 3H, CH3); C-NMR: 202.8 (CO), 166.8 (OCO), 144.9 (C4a), 130.7 (C4), 130.1 (C2),
129.2 (C3), 126.1 (C1), 123.3 (C9), 122.9 (C8), 60.1 (C6a), 36.9 (C10a), 35.5 (C10), 34.9 (C7), 26.5
(C14), 18.8, 18.9 (CH3); GC/MS m/z (%): 339 (M+, 1), 296 (100), 268 (9), 253 (12), 241 (12), 232 (9),
91 (5), 67 (8), 43 (37); EA (%) calculated for C17H16O3Cl2: 60.19 C, 4.75 H; found 60.15 C, 4.85 H.
(6aR,10aR)-rel-6a-Acetyl-4-bromo-2-chloro-6a,7,10,10a-tetrahydro-8,9-dimethyl-6-
oxodibenzo[b,d]pyran (10h). Pale yellow powder in 62% yield, mp 152–155 ºC. IR (cm-1): 1785
(OC=O), 1703 (C=O), 1232, 1131 (C-O), 787 (C-Cl), 524 (C-Br). 1H-NMR: 7.45 (d, 1H, 4J = 2.4, H1),
7.15 (d, 1H, 4J = 2.4, H3), 3.46 (dd,1H, 3J = 6.4, 11.4, H10a), 2.89 (d, 1H, 2J = 17.1, Heq-7), 2.31 (dd,
2
3
2
1H, J = 17.6, J = 6.4, Heq-10), 2.19 (d, 1H, J = 16.9, Hax-7), 2.14 (s, 3H, H14), 1.99 (dd, 1H,
2J = 17.6, J = 11.4, Hax-10), 1.69 (s, 3H, CH3), 1.60 (s, 3H, CH3); 13C-NMR: 202.8 (CO), 166.9
3
(OCO), 146.1 (C4a), 132.0 (C3), 130.6 (C2), 130.4 (C4), 126.8 (C1), 123.3 (C9), 122.9 (C8), 111.4
(C10b), 60.1 (C6a), 37.0 (C10a), 35.5 (C10), 34.9 (C7), 26.6 (C14), 18.8, 18.9 (CH3); GC/MS m/z (%):
384 (M+, 1), 341 (100), 325 (5), 313 (6), 287 (10), 232 (15), 67 (16), 43 (27); EA (%) calculated for
C17H16O3ClBr: 53.22 C, 4.2 H; found 53.60 C, 4.25 H.
(6aR,10aR)-rel-6a-Acetyl-2-bromo-6a,7,10,10a-tetrahydro-4-methoxy-8,9-dimethyl-6-oxodibenzo-
[b,d]pyran (10i). Pale yellow powder in 83% yield, mp 160–164 ºC. IR/(cm-1): 1769 (OC=O), 1706
1
(C=O), 1275, 1196 (C-O), 506 (C-Br). H-NMR: 6.94 (s, 1H, H1), 6.94 (s, 1H, H3), 3.84 (s, 3H,
3
2
OCH3), 3.41(dd, 1H, J = 6.2, 11.3, H10a), 2.88 (d, 1H, J = 16.9, Heq-7), 2.36 (dd, 1H,
2J = 17.0, 3J = 6.2, Heq-10), 2.18 (d, 1H, 2J = 16.9, Hax-7), 2.13 (s, 3H, H14), 1.97 (dd, 1H, J = 17.0,
2
3J = 11.3, Hax-10), 1.68 (s, 3H, CH3), 1.59 (s, 3H, CH3); 13C-NMR: 203.4 (C=O), 167.4 (OCO), 148.4
(C4a), 138.5 (C4), 130.3 (C2), 123.4 (C9), 122.8 (C8), 121.9 (C3), 117.6 (C10b), 114.9 (C1), 60.2
(C6a), 56.5 (s, 3H, OCH3), 36.7 (C10a), 35.6 (C10), 34.9 (C7), 26.4 (C14), 18.8, 18.8 (CH3); GC/MS
m/z (%): 380 (M+, 1), 337 (100), 309 (4), 283 (8), 256 (8), 228 (14), 115 (5), 91 (5), 43 (31); EA (%)
calculated for C18H19O4Br: 57.01 C, 5.05 H; found 57.20 C, 5.06 H.

Molecules 2010, 15
1525
3.4. General synthetic procedure for epoxides 11-15
Prepared from 200 mg of compounds 6-10 and two equivalents of m-CPBA dissolved in CHCl3
(25 mL) and refluxed for 24 h. The CHCl3 solution was extracted with an aqueous saturated NaHCO3
solution. The organic layer was dried with Na2SO4, then filtered and concentrated.
Ethyl (6aR,7aR,8aS,9aR)-rel-6a,7,7a,8a,9,9a-hexahydro-7a,8a-dimethyl-6-oxo-5,8-dioxacyclopropa-
[b]phenantrene-6a(6H)-carboxylate (11a). White crystalline solid in 73% yield, mp 79.8–82.5 °C.
1
IR/ (cm-1): 1772 (OC=O), 1735 (EtOC=O), 1248, 1230, 1150 (C-O). H-NMR: 7.19 (ddd, 1H,
4
3
4
3
4
3J = 7.7, 7.7, J = 1.8 Hz, H3), 7.09 (dd, 1H, J = 7.5, J = 1.8, H1), 7.03 (dd, 1H, J = 7.5, J = 1.1,
3
3
H2), 6.98 (d, 1H, J = 8.6, H4), 3.87 (m, 2H, OCH2), 3.36 (dd, 1H, J = 12.4 and 5.5, H9a), 2.83 (d,
1H, 3J = 15.2, Heq-7), 2.24 (d, 1H, 3J = 15.4, Hax-7), 2.21 (dd, 1H, 3J = 10.3 and 5.5, Heq-9), 1.60 (dd,
1H, 3J = 15.6 and 12.5, Hax-9), 1.40, 1.24 (s, 3H c/u, 2CH3), 0.83 (t, 3H, CH3-CH2). C-NMR: 169.9
13
(OCO), 167.4 (OCO lactone), 150.9 (C4a), 129.1 (C1), 127.8 (C3), 126.4 (C9b), 125.1 (C2), 117.0
(C4), 62.3 (CH2-O), 61.7 (C8a), 60.3 (C7a, 53.3 (C6a), 35.6 (C9a), 34.5 (C9), 34.4 (C7), 21.0 (CH3-
C8a), 19.2 (CH3-C7a), 13.9 (CH3-CH2); GC/MS m/z (%): 316 (M+, 2), 259 (38), 243 (100), 225 (50),
214 (34), 199 (24), 145 (11), 115 (17), 91 (6), 43 (52); EA (%) calculated for C18H20O5: 68.34 C, 6.37
H; found: 68.35 C, 6.32 H.
(6aR,7aR,8aS,9aR)-rel-N-benzyl-6a,7,7a,8a,9,9a-hexahydro-7a,8a-dimethyl-6-oxo-5,8-dioxacyclo-
propa[b]phenantrene-6a(6H)-carboxamide (12a). White crystalline solid in 78% yield, mp 205.4–207 °C.
1
IR/ (cm-1): 3342 (NH), 1773 (OC=O), 1637 (NC= O), 1538 (C=C), 1234 (C-O), 1152 (C-N). H-
NMR: 7.27 (m, 1H, H3), 7.21 (m, 5H, 5H-C6H5), 7.12 (t, 1H, 3J =7.4, H6), 7.01 (d, 1H, 3J = 8.0, H5),
2
3
6.82 (m, 1H, H4), 5.82 (t, 1H, NH), 4.22 (m, 2H, AA’BB’, NCH2), 3.52 (dd, 1H, J = 12.5, J = 5.3,
2
2
3
2
H9a), 2.94 (d, 1H, J = 15.5, Heq-7), 2.32 (dd, 1H, J = 15.5, J = 5.2, Heq-9), 2.27 (d, 1H, J = 15.5,
2
3
13
Hax-7), 1.69 (dd, 1H, J = 15.6, J = 12.7, Hax-9), 1.43 (s, 3H, CH3), 1.30 (s, 3H, CH3); C-NMR:
169.4 (NCO), 168.0 (OCO lactone), 150.3 (C4a), 137.4 (Ci), 128.9 (C-m and C1), 128.0 (C3), 127.8
(Cp), 127.5 (Co), 127.0 (C9b), 125.6 (C2), 117.0 (C4), 61.8 (C8a), 60.5 (7a), 54.6 (C6a), 43.9 (NCH2),
36.0 (C9a), 35.7 (C9), 34.7 (C8a), 21.0 (CH3-C8a), 19.1 (CH3-C7a); GC/MS m/z (%): 377 (M+, 2), 318
(10), 243 (40), 227 (15), 225 (30), 211 (32), 199 (8), 173 (8), 150 (100), 131 (10), 91 (95), 43 (30); EA
(%) calculated for C23H23O4N: 73.19 C, 6.14 H; found: 73.09 C, 6.14 H.
(6aR,7aR,8aS,9aR)- and (6aS,7aS,8aR,9aS)-6a,7,7a,8a,9,9a-hexahydro-7a,8a-dimethyl-6-oxo-N-[(R)-
1-phenylethyl]-5,8-dioxacyclopropa[b]phenantrene-6a(6H)-carboxamide (13a). White crystalline
powder in 78% yield, mp 163.9–165.0 °C; IR  (cm-1): 3256 (NH), 1759 (OC=O), 1638 (NC=O),
1230, 1161, 1151 (C-O); GC/MS m/z (%) 391 (M+, 4), 332 (15), 243 (58), 227 (28), 225 (35), 211
1
(42), 199 (8), 173 (15), 105 (100), 43 (20). Minor (6aR,7aR,8aS,9aR) isomer 13a: H-NMR: 7.3–6.9
3
3
3
2
(m, 9H, ArH), 5.67 (d, 1H, J = 1.5, NH), 3.48 (dd, 1H, J = 5.1, J = 12.0, H9a), 2.92 (dd, 1H, J =
15.4, Heq-7), 2.27 (d, 1H, 2J = 15.6, Hax-7), 2.29 (m, 1H, Heq-9), 1.68 (dd, 1H, 2J = 15.6, 3J = 5.6, Hax-
3
3
9), 4.84 (dq, 1H, J = 6.9, CHCH3), 1.43 and 1.30 (two s, 2 × 3H, 7a- and 8a-CH3), 1.26 (d, 3H, J =
7.0, CHCH3); 13C-NMR: 169.6 (NCO), 167.1 (C-6), 150.3 (C-4a), 142.0 (C-1’), 128.8 (C-3’,5’), 128.0
(C-1), no (C-3), 127.6 (C-9b), 127.0 (C-4’), 125.9 (C-2’,6’), 125.5 (C-2), 117.0 (C-4), 61.8 (C-8a),

Molecules 2010, 15
60.6 (C-7a), 54.6 (C-6a), 49.1 (NCH), 35.9 (C-9a), 34.9 (C-9), 34.8 (C-7), 21.1, 21.0, and 19.1
1526
1
3
(3 × CH3). Major (6aS,7aS,8aR,9aS) isomer 13a: H-NMR: 7.3–6.9 (m, 9H, ArH), 5.71 (d, 1H, J =
3
3
2
2
1.5, NH), 3.44 (dd, 1H, J = 5.1, J = 12.0, H-9a), 2.90 (dd, 1H, J = 15.4, Heq-7), 2.19 (d, 1H, J =
2
3
3
15.6, Hax-7), 2.29 (m, 1H, Heq-9), 1.68 (dd, 1H, J = 15.6, J = 5.6, Hax-9), 4.83 (dq, 1H, J = 6.9,
3
13
CHCH3), 1.42 and 1.29 (two s, 2 × 3H, 7a- and 8a-CH3), 1.22 (d, 3H, J = 7.0, CHCH3); C-NMR:
169.3 (NCO), 167.1 (C-6), 150.4 (C-4a), 142.1 (C-1’), 129.0 (C-3’,5’), no (C-1), 127.9 (C-3), 127.7
(C-9b), 126.8 (C-4’), 126.1 (C-2’,6’), 125.5 (C-2), 117.0 (C-4), 61.8 (C-8a), 60.6 (C-7a), 54.5 (C-6a),
49.2 (NCH), 36.0 (C-9a), 35.5 (C-9), 34.8 (C-7), 21.1, 21.0, and 19.1 (3 × CH3).
(6aR,7aR,8aS,9aR)-rel-6a,7,7a,8a,9,9a-Hexahydro-7a,8a-dimethyl-6-oxo-N-(2-phenylethyl)-5,8-
dioxacyclopropa[b]phenantrene-6a(6H)-carboxamide (14a). White crystalline powder in 78% yield,
mp 189.4–191.6 °C. IR/ (cm-1): 3322 (NH), 1789 (OC=O), 1640 (CONH), 1146 y 1129 (C-O).
1H- NMR: 7.25(m, 5H, Ph), 7.15 (dd, 1H, 3J = 7.4, 4J = 1.9, H3), 7.10 (dd, 1H, 3J = 7.4, 4J = 1.2, H2),
3
3
3
7.03 (d, 1H, J = 6.7, H1), 7.00 (d, 1H, J = 8.1, H4), 5.54 (a, 1H, NH), 3.48 (dd, 1H, J = 5.2,
3J = 12.6, H9a), 3.29 (q, 2H, 3J = 7.2, NCH2), 2.81 (d, 1H, 3J =5.5, Heq-7), 2.56 (t, 2H, 3J = 7.2, CH2),
3
2
3
3
2.28 (dd, 1H, J = 5.2, J = 15.7, Heq-9), 2.11 (d, 1H, J = 15.7, Hax-7), 1.65 (dd, 1H, J = 5.5 Hz,
3J= 12.6, Hax-9), 1.40, 1.29 (s, 3H c/u, 2CH3); C-NMR: 169.5 (NCO), 167.9 (OCO), 150.2 (C4a),
13
138.3 (Ci), 128.9 (Cm), 128.9 (Co), 128.8 (C1), 127.9 (C3), 126.9 (Cp), 125.7 (C2), 116.9 (C4), 127.1
(C9b), 61.8 (C8a), 60.5 (C7a), 54.4 (C6a), 41.2 (NCH2), 36.0 (CH2), 35.9 (C9a), 35.4 (C9), 34.5 (C7),
21.0 (CH3C8a), 19.1 (CH3C7a); GC/MS m/z (%) 391 (M+, 8), 332 (20), 243 (100), 227 (43), 225 (95),
211 (68), 173 (43); EA (%) calculated for C24H25O4N: 73.64 C, 6.44 H, 3.58 N; found: 73.27 C, 6.24
H, 3.44 N.
(6aR,7aR,8aS,9aR)-rel-6a-Acetyl-6a,7,7a,8a,9,9a-hexahydro-7a,8a-dimethyl-6-oxo-6H-5,8-
dioxacyclopropa[b]phenantrene (15a). White crystalline powder in 70% yield, mp 125.6–126.9 °C.
IR/ (cm-1): 1772 (OC=O), 1699 (C=O), 1300, 1258, 1150 (C-O). 1H-NMR: 7.25 (dd, 1H, 3J = 7.6, 7.4,
3
3
3
H2), 7.16 (d, J = 7.6, H1), 7.09 (dd, 1H, J= 7.4, 8.1, H3), 7.02 (d, 1H, J = 8.1, H4), 3.45 (dd, 1H,
3J = 12.2, 5.0, H9a), 2.83 (d, 1H, J = 15.0, Heq-7), 2.31 (dd, 1H, J = 15.4, J = 5.0, Heq-9), 2.08 (d,
1H, 2J = 15.0, Hax-7), 2.02 (s, 3H, CH3O), 1.68 (dd, 1H, 2J = 15.4, 3J = 12.2, Hax-9), 1.45, 1.31 (s, 3H
c/u, 2CH3); 13C-NMR: 203.5 (COCH3), 170.4 (OCO), 150.6 (C4a), 134.9 (C9b), 130.5 (C1), 128.5
(C2), 125.4 (C3), 117.4 (C4), 62.0 (C8a), 60.4 (C7a), 60.3 (C6a), 35.9 (C9a), 34.3 (C9), 33.2 (C7),
25.5 (CH3CO), 21.0 (CH3C8a), 19.2 (CH3C7a); GC/MS m/z (%): 286 (M+, 1), 243 (16), 225 (28), 211
(100), 184 (14), 114 (17), 91 (9), 43 (60); EA (%) calculated for C17H18O4: 71.31 C, 6.34 H; found:
71.28 C, 6.44 H.
2
2
3
(6aR,7aR,8aS,9aR)-rel-6a-Acetyl-6a,7,7a,8a,9,9a-hexahydro-7a,8a-dimethyl-2-nitro-6-oxo-6H-5,8-
dioxacyclopropa[b]phenantrene (15d). White solid in 96% yield, mp 216–220 °C. IR/(cm-1): 1786
(OC=O), 1700 (C=O), 1526 (NO2), 1338, 1237, 1142 (C-O). 1H-NMR: 8.18 (dd, 1H, 4J = 2.6, 3J = 8.8,
H3), 8.15 (d, 1H, 4J = 2.6, H1), 7.18 (d, 1H, 3J = 8.8, H4), 3.63 (dd, 1H, 3J = 5.2, 12.1, H9a), 2.89 (d,
2
2
3
2
1H, J = 15.5, Heq7), 2.38 (dd, 1H, J = 15.5, J = 5.2, Heq-9), 2.15 (d, 1H, J = 15.5, Hax-7), 2.09 (s,
2
3
13
3H, H14), 1.70 (dd, 1H, J = 15.5, J = 12.1, Hax-9), 1.35 (s, 3H, CH3), 1.48 (s, 3H, CH3); C-NMR:
202.2 (CO), 166.8 (OCO), 154.8 (C4a), 144.7 (C2), 127.4 (C9b), 125.2 (C3), 123.6 (C1), 118.2 (C4),

Molecules 2010, 15
1527
61.6 (C6a), 60.0 (C8a), 59.9 (C7a), 35.6 (C9), 34.2 (C9a), 32.9 (C7), 25.4 (C14), 20.9, 19.0 (CH3);
GC/MS m/z (%): 331 (M+, 1), 288 (19), 256 (100), 230 (26), 115 (5), 91 (4), 43 (78); EA (%)
calculated for C17H17O6N: 61.63 C, 5.17 H, 4.23 N; found: 61.44 C, 5.25 H, 4.14 N.
(6aR,7aR,8aS,9aR)-rel-6a-Acetyl-6a,7,7a,8a,9,9a-hexahydro-4-methoxy-7a,8a-dimethyl-6-oxo-6H-
5,8-dioxacyclopropa[b]phenantrene (15f). White solid in 92% yield, mp 188–192 °C. IR/(cm-1):
1
3
1764 (OC=O), 1702 (C=O), 1281, 1153, 1095 (C-O). H-NMR: 7.05 (t, 1H, H2, J = 7.9), 6.85 (dd,
1H,
3J = 7.9, H1), 6.74 (dd, 1H, 3J = 7.9, H3), 3.85 (s, 3H, OCH3), 3.44 (dd, 1H, 3J = 5.0, 12.3, H9a), 2.85
(d, 1H, 2J = 15.2, Heq-7), 2.31 (dd, 1H, 2J = 15.5, 3J = 5.0, Heq-9), 2.07 (d, 1H, 2J = 15.2, Hax-7), 2.04
2
3
13
(s, 3H, H14), 1.70 (dd, 1H, J = 15.5, J = 12.3, Hax-9), 1.45 (s, 3H, CH3), 1.31 (s, 3H, CH3); C-
NMR: 203.4 (CO), 167.8 (OCO), 147.8 (C4a), 139.6 (C4), 127.2 (C9b), 125.5 (C2), 118.9 (C1), 111.9
(C3), 61.9 (C6a), 60.3 (C8a), 60.1 (C7a), 56.3 (OCH3), 35.6 (C9), 34.4 (C9a), 33.2 (C7), 25.6 (C14),
19.2, 21.0 (CH3); GC/MS m/z (%): 316 (M+, 1), 273 (53), 255 (100), 245(4), 241 (60), 211 (11), 115
(13), 91 (8), 43 (47); EA (%) calculated for C18H20O5: 68.34 C, 6.37 H; found: 64.83 C, 6.28 H.
(6aR,7aR,8aS,9aR)-rel-6a-Acetyl-2-bromo-6a,7,7a,8a,9,9a-hexahydro-4-methoxy-7a,8a-dimethyl-6-
oxo-6H-5,8-dioxacyclopropa[b]phenantrene (15i). White powder in 95% yield, mp 169–172 °C.
1
IR/(cm-1): 1768 (OC=O), 1702 (C=O), 1198, 1154, 1123 (C-O), 512 (C-Br). H-NMR: 6.97 (d, 1H,
3
4J = 2.1, H1), 6.91 (d, 1H, 4J = 2.1, H3), 3.86 (s, 3H, OCH3), 3.42 (dd, 1H, J = 5.0, 12.3, H9a), 2.85
2
2
3
(d, 1H, J = 15.5, Heq-7), 2.30 (dd, 1H, J = 15.5, J = 5.0, Heq-9), 2.07 (s, 3H, H14), 2.06 (d, 1H,
2J = 15.5, Hax-7), 1.68 (dd, 1H, 2J = 15.5, 3J = 12.3, Hax-9), 1.45 (s, 3H, CH3), 1.32 (s, 3H, CH3); 13C-
NMR: 202.8 (CO), 167.2 (OCO), 148.5 (C4a), 138.7 (C4), 128.8 (C2), 121.7 (C3), 117.8 (C9b), 115.4
(C1), 61.7 (C8a), 60.2 (C7a), 59.9 (C6a), 56.4 (OCH3), 35.4 (C9), 34.3 (C9a), 33.2 (C7), 25.7 (C14),
20.9, 19.2 (CH3); GC/MS m/z (%): 395 (M+, 1), 351 (27), 334 (10), 321 (100), 255 (8), 240 (28), 115
(12), 91 (5), 43 (80); EA (%) calculated for C18H19O5Br: 54.70 C, 4.85 H; found: 54.26 C, 4.74 H.
3.5. Crystal structures
Compound 10b: C17H17C O3, colorless crystals, monoclinic, P21/c, Z = 4, a = 18.809(2) Å,
b = 7.1461(9) Å, c = 11.4261(14) Å,  = 90º,  = 105.493(2)º,  = 90º, V = 1480.0(3) Å3,
Dcalcd = 1.368 g/cm3,  = 0.265 mm-1, 10086 reflections collected, 2603 independent (Rint = 0.025),
2414 observed, R1 = 0.0411, wR2 = 0.1198 (I > 2(I)).
Compound 15i: C18H19BrO5, colorless crystals, triclinic, P-1, Z = 2, a = 7.3676(18) Å,
b = 10.851(3) Å, c = 12.154(3) Å,  = 108.055(4)º,  = 97.784(4)º,  = 106.789(4)º, V = 857.0(4) Å3,
Dcalcd = 1.532 g/cm3,  = 2.423 mm-1, 8373 reflections collected, 3017 independent (Rint = 0.046), 2455
observed, R1 = 0.0575, wR2 = 0.1149 (I > 2(I)).

Molecules 2010, 15
1528
4. Conclusions
The thermal reactions of ethyl coumarin-3-carboxylate (1a), 3-carboxyamides 2a-4a and
3-acetylcoumarins 5a-i with 2,3-dimethyl-1,3-butadiene under SFC yielded the corresponding DA
adducts in 60 to 85%, as a racemic mixture of the cis fused rings. Poor asymmetric induction is
observed when the enantiopure compound 3a was used. Epoxidation of DA cycloadducts 6a-10a
proceeded in 70–80% yield, whereas starting from 10d, 10f, and 10i, the isolated yields were in the
90–96% range. NMR and X-ray data demonstrated that the oxygen atom is stereoselectively added to
the less hindered face of the cyclohexene ring, opposite to the benzopyrone ring fusion. 1H-NMR and
X-ray data supported an anchored twisted boat conformation for both dihydropyrone and cyclohexene
rings. Data on the supramolecular structure of DA adducts and epoxides is scarce, although it is
directed by CH···A (A = O, ) and, in the case of 15i, also by Br···Br interactions.
Acknowledgements
This work was supported by SIP-IPN (Secretaría de Investigación y Postgrado del Instituto
Politécnico Nacional), CGIC-UC (Coordinación General de Investigación Científica de la Universidad
de Colima), and CONACYT-83378. Thanks to UAEH (Universidad Autónoma del Estado de Hidalgo)
for the access to the elemental analyzer.
References and Notes
1. Mustafa, A.; Kamel, M.; Allam, M.A. Dimerization reactions in eunlight. V. Photodimerization of
substituted coumarins. J. Org. Chem. 1957, 22, 888–891.
2. Ayala-Hurtado, S.; Flores-Larios, I.Y.; Padilla-Martínez, I.I.; Martínez-Martínez, F.J.; García-
Báez, E.V.; Cruz, A.; Höpfl, H. From solid state photodimers of ethyl coumarin-3-carboxylate to
their alcoholysis derivatives. A supramolecular study. Supramol. Chem. 2007, 19, 629–640.
3. Ohkata, K.; Lee, Y.-G.; Utsumi, Y.; Ishimaru, K.; Akiba, K.-Y. Diels-Alder reactions of 2-
[(trialkylsilyl)oxy]pyrylium cations of 2H-pyran-2-one and 2H-1-benzopyran-2-one derivatives.
J. Org. Chem. 1991, 56, 5052–5059.
4. Amantini, D.; Fringuelli, F.; Pizzo, F. Uncatalyzed [4 + 2] cycloadditions of 3-nitrocoumarins
with vinyl ethers in solventless conditions. A new entry to chromene derivatives. J. Org. Chem.
2002, 67, 7238–7243.
5. Girotti, R.; Marrocchi, A.; Minuti, L.; Piermatti, O.; Pizzo, F.; Vaccaro, L. Diels-Alder reactions
of 3-substituted coumarins in water and under high-pressure condition. An uncatalyzed route to
tetrahydro-6H-benzo[c]chromen-6-ones. J. Org. Chem. 2006, 71, 70–74.
6. Ballerini, E.; Minuti, L.; Piermatti, O.; Pizzo, F. High pressure Diels-Alder approach to hydroxy-
substituted 6a-cyano-tetrahydro-6H-benzo[c]chromen-6-ones: A route to Δ6-cis-cannabidiol. J.
Org. Chem. 2009, 74, 4311–4317.
7. Fringuelli, F.; Girotti, R.; Pizzo, F.; Zunino, E.; Vaccaro, L. Hafnium chloride tetrahydrofuran
complex-catalyzed Diels–Alder cycloadditions of 3-ethoxycarbonylcoumarins with 1,3-dienes
under solvent-free Conditions. Adv. Synth. Catal. 2006, 348, 297–300.

Molecules 2010, 15
1529
8. López-Garrido, L.; García-Báez, E.V.; Martínez-Martínez, F.J.; Padilla-Martínez I.I. 3-Acyl
coumarin derivatives. [2 + 2] and [2 + 4] cycloaddition reactions. In proceeding of XXVI Latin-
American Congress of Chemistry and 27 Annual Meeting of the Brazilian Chemical Society,
Salvador Bahia, Brazil, May 30–June 2, 2004; Abstract QO-039.
9. Gotthardt, H.; Hoffmann, N. Synthese und neue [4 + 2]-Cycloadditionen von Cumarin-
Abkömmlingen. Liebigs Ann. Chem. 1985, 901–912.
10. Ohkata, K.; Miyamoto, K.; Matsumura, S.; Akiba, K.-Y. Highly asymmetric induction in the
Diels-Alder reaction of 3-alkoxycarbonyl-substituted coumarin. Tetrahedron Lett. 1993, 34,
6575–6578.
1
13
11. Martínez-Martínez, F.J.; Padilla-Martínez, I.I.; Trujillo-Ferrara, J. H and C NMR assignments
of 2-oxo-2H-1-benzopyran-3-acyl and 3-amide derivatives. Magn. Res. Chem. 2001, 39, 765–767.
12. Munshi, P.; Venugopala, K.N.; Jayashree, B.S.; Guru-Row, T.N. Concomitant polymorphism in
3-acetylcoumarin: Role of weak C−H···O and C−H···π interactions. Cryst. Growth Des. 2004, 4,
1105–1107.
13. Santos-Contreras, R.J.; Martínez-Martínez, F.J.; Mancilla-Margalli, N.A.; Peraza-Campos, A.L.;
Morín-Sánchez, L.M.; García-Báez, E.V.; Padilla-Martínez, I.I. Competition between OH···O and
multiple halogen-dipole interactions on the formation of intramolecular three centred hydrogen
bond in 3-acyl coumarins. CrystEngComm 2009, 11, 1451–1461.
14. Desiraju, G.R. The C−H···O hydrogen bond: structural implications and supramolecular design.
Acc. Chem. Res. 1996, 29, 441–449.
15. Umezawa, Y.; Tsuboyama, S.; Honda, K.; Uzawa, J.; Nishio, M. CH/π interaction in the crystal
structure of organic compounds. A database study. Bull. Chem. Soc. Jpn. 1998, 71, 1207–1213.
16. García-Báez, E.V.; Martínez-Martínez, F.J.; Höpfl, H.; Padilla-Martínez, I.I. -Stacking
interactions and CH···X (X = O, aryl) hydrogen bonding as directing features of the
supramolecular self-association in 3-carboxy and 3-amido coumarin derivatives. Cryst. Growth
Des. 2003, 3, 35–45.
17. El-Deen, I.M.; Abd El-Fattah, M.; Ibrahim, H.K.; El-Gohary, A. Synthesis and investigation of
mass spectra of 3-[5′-(2′-substituent)thienyl]benzo[5,6]coumarins. Phosphor. Sulfur. Silicon 2003,
178, 1463–1476.
18. Bruker. APEX II, SAINT, SADABS and SHELXTL. Bruker AXS Inc.: Madison, WI, USA, 2004.
19. Sheldrick, G.M. A short history of SHELX. Acta Crystallogr. A 2008, A64, 112–122.
20. Farrugia, L.J. WinGX suite for small-molecule single-crystal crystallography. J. Appl. Crystallogr.
1999, 32, 837–838.
21. Macrae, C.F.; Edgington, P.R.; McCabe, P.; Pidcock, E.; Shields, G.P.; Taylor, R.; Towler, M.;
van de Streek, J. Mercury: Visualization and analysis of crystal structures. J. Appl. Crystallogr.
2006, 39, 453–457.
22. Spek, A.L. Single-crystal structure validation with the program PLATON. J. Appl. Crystallogr.
2003, 36, 7–13.

Molecules 2010, 15
1530
23. Frisch, M.J.; Trucks, G.W.; Schlegel, H.B.; Scuseria, G.E.; Robb, M.A.; Cheeseman, J.R.;
Zakrzewski, V.G.; Montgomery J.A.; Stratmann, R.E., Jr.; Burant, J.C.; Dapprich, S.; Millam,
J.M.; Daniels, A.D.; Kudin, K.N.; Strain, M.C.; Farkas, O.; Tomasi, J.; Barone, V.; Cossi, M.;
Cammi, R.; Mennucci, B.; Pomelli, C.; Adamo, C.; Clifford, S.; Ochterski, J.; Peterson, G.A.;
Ayala, P.Y.; Cui, Q.; Morokuma, K.; Malick, D.K.; Rabuck, A.D.; Raghavachari, K.; Foresman,
J.B.; Cioslowski, J.; Ortiz, J.V.; Baboul, A.G.; Stefanov, B.B.; Liu, G.; Liashenko, A.; Piskorz, P.;
Komaromi, I.; Gomperts, R.; Martin, R.L.; Fox, D.J.; Keith, T.; Al-Laham, M.A.; Peng, C.Y.;
Nanayakkara, A.; Challacombe, M.; Gill, P.M.W.; Johnson, B.; Chen, W.; Wong, M.W.; Andres,
J.L.; Gonzalez, C.; Head-Gordon, M.; Replogle, E.S.; Pople, J.A. Gaussian 98, Revision A.9;
Gaussian, Inc.: Pittsburgh, PA, USA, 1998.
24. Bonsignore, L.; Cottiglia, F.; Maccioni, A.M.; Secci, D.; Lavagna, S.M. Synthesis of coumarin-3-
O-acylisoureas by dicyclohexylcarbodiimide. J. Heterocycl. Chem. 1995, 32, 573–577.
25. Bonsignore, L.; Cottiglia, F.; Maccioni, A.M.; Secci, D.; Lavagna, S.M. Synthesis of coumarin-3-
O-acylisoureas by dicyclohexylcarbodiimide. J. Heterocycl. Chem. 1995, 32, 573–577.
Sample Availability: Samples of compounds 10a, 11-12a and 15a are available from the authors.
© 2010 by the authors; licensee Molecular Diversity Preservation International, Basel, Switzerland.
This article is an open-access article distributed under the terms and conditions of the Creative
Commons Attribution license (http://creativecommons.org/licenses/by/3.0/).
