Facile synthesis and preferred conformation analysis of cyclododeceno[b]indene

Article abstract of DOI:10.3390/molecules15020699

Using methanesulfonic acid as a catalyst, a series of cyclododeceno[b] indene derivatives were synthesized by the cyclization of α- benzylcyclododecanones, which were prepared by the reactions of cyclododecanones with a variety of substituted benzyl chlorides or bromides using NaH as a base. Their structures were confirmed by mp, IR spectra, ¹H-NMR, ¹³C-NMR, MS, and x-ray diffraction. The preferred conformations were analyzed by crystal structure, ,¹H-NMR and quantum chemistry calculations, and compared with the x-ray diffraction structure of 2,3,5,6-bis(ortho-1,10-decylidene)dihydropyrazine. The results showed that the cyclododecene moiety adopted a preferred [1ene2333] conformation, and the substituted groups at aromatic ring had no significant influence on the conformation.

Full text of DOI:10.3390/molecules15020699

Molecules 2010, 15, 699-708; doi:10.3390/molecules15020699
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Facile Synthesis and Preferred Conformation Analysis of
Cyclododeceno[b]indene
Chunyan Zhang, Shengyan Gong, Li Zhang, Daoquan Wang and Mingan Wang *
Department of Applied Chemistry, China Agricultural University, Beijing 100193, China
∗ Author to whom correspondence should be addressed; E-Mail: wangma@cau.edu.cn;
Tel.: +86-10-62734093.
Received: 23 December 2009; in revised form: 21 January 2010 / Accepted: 25 January 2010 /
Published: 1 February 2010
Abstract: Using methanesulfonic acid as a catalyst, a series of cyclododeceno[b]indene
derivatives were synthesized by the cyclization of α-benzylcyclododecanones, which were
prepared by the reactions of cyclododecanones with a variety of substituted benzyl
chlorides or bromides using NaH as a base. Their structures were confirmed by mp, IR
spectra, 1H-NMR, 13C-NMR, MS, and x-ray diffraction. The preferred conformations were
analyzed by crystal structure, 1H-NMR and quantum chemistry calculations, and compared
with the x-ray diffraction structure of 2,3,5,6-bis(ortho-1,10-decylidene)dihydropyrazine.
The results showed that the cyclododecene moiety adopted a preferred [1ene2333]
conformation, and the substituted groups at aromatic ring had no significant influence on
the conformation.
Keywords: α-benzylcyclododecanone; cyclododeceno[b]indene; synthesis; conformational
analysis
1. Introduction
Benzocyclopenta-1,3-diene (indene) is a compound with an 8π-electron system in a planar
conformation that makes it easy to lose one proton and form a 10π-electron aromatic system, and
therefore plays an important role in Organic Chemistry. Indene derivatives are widely used as useful
intermediates in the development of drug molecules, pesticides, and functional materials [1,2]. They
have also been used as metal ligands of Ziegler-Natta type catalysts, and these complexes are highly

Molecules 2010, 15
700
stable and have excellent catalytic efficacy in the polymerization of ethylene and propylene [3,4].
Cyclohexeno[b]indene in particular has been used as a Ziegler-Natta catalyst metal ligand [5]. In
another aspect, bi- and tricyclic compounds with bridge double bonds are very useful starting reagents
for the synthesis of macrocyclic compounds such as the fragrant macrocyclic lactone pentadecanolide
and related compounds [6,7]. Synthesis of indene derivatives containing cyclic olefins ranging from 5
to 12-membered rings have been reported, with the exception of the corresponding 11-membered ring
compounds. As for cyclododeceno[b]indene, it has been reported by Parham and coworkers [8] that
this compound can be synthesized in five steps using cyclododecanone and a Grignard reagent as
starting materials. However the reaction conditions are difficult to control, the intermediates are hard
to purify, and the overall yield is low. Zakharkin and coworkers [9] reported a convenient method in
which α-benzylcyclododecanones were synthesized by the reaction of cyclododecanone with benzyl
chloride under phase transfer catalysis, followed by cyclization of α-benzylcyclododecanone using
polyphosphoric acid as the catalyst. Recently, Miyamoto and coworker [10] reported a Rh(I)-catalyzed
reaction of 2-(chloromethyl)phenylboronic acid and cyclododecyne leading to cyclododeceno[b]indene
in 36%–54% yields, but cyclododecyne is not readily available.
So far, cyclododeceno[b]indene derivatives have not been evaluated for their catalytic efficacy as
metal ligands of Ziegler-Natta type catalysts. Moreover, it is not clear whether the conformation of the
cyclododecene ring in cyclododeceno[b]indene molecules has any significant impact on the catalytic
efficacy of these compounds. In order to resolve these issues and extend our research on the
stereochemistry of 12-membered ring systems [11–15], we have synthesized a series of
cyclododeceno[b]indene derivatives using methanesulfonic acid as catalyst and carried out the
conformational analysis of these compounds. The synthetic route is shown in Scheme 1. The
evaluation of the catalytic efficacy of these compounds are still in progress in our laboratory.
Scheme 1. The synthetic route of cyclododeceno[b]indene derivatives.
5
4
O
O
3 2
7 6
NaH
catalyst
+
ClH2C
R
12
11
R
8 9
CH2
1
R
10
1
2
A. R = H B. R = 4-Cl C. R = 4-F D. R = 4-CH3 E. R = 4-OCH3 F. R = 2, 4-Cl2
2. Results and Discussion
In the synthesis of the title compounds, we found that the cyclization of intermediates 1 did not take
place after several days using the Zakharkin method when n-hexane was used as solvent and PPA or
phosphoric acid as the catalysts [9]. We next used the more acidic p-methylbenzenesulfonic acid as the
catalyst, which enabled the reaction of α-benzylcyclododecanone (1A) to produce compound 2A in
30% yield, but para-fluoro- or para-chloro-α-benzylcyclododecanones 1B and 1C did not react under
similar conditions. This may be due to the heterogenous nature of these reactions because p-methyl-
benzenesulfonic acid remained in a solid state in the reaction mixtures, which resulted in poor catalytic
efficacy of the reagent. Then we used anhydrous aluminum chloride as the catalyst as in [5], where
Thomas reported the synthesis of cyclohexeno[b]indene by the cyclization reaction of α-benzylcyclo-

Molecules 2010, 15
701
hexanone in the presence of anhydrous aluminum chloride. The results showed that in hexane the
products were complex and difficult to purify when 1A–4A were used as the starting materials.
Considering the characteristics of the dehydration after the electrophilic cyclization, as indicated in
Scheme 2, we tried methanesulfonic acid as the catalyst in an amount that was 2–3 times the amount of
α-benzylcyclododecanone used. As a result, we found that the reaction time was shortened, the
products were relatively easier to isolate, and the yields were in the 5–16% range for 2A, 2C, 2D and
2E. Compound 2B was an exception. Encouraged by these results, we added a 10-fold excess of
methanesulfonic acid without changing the other conditions, and were able to achieve yields of 35–
90% for 2A, 2B, 2C, 2D and 2E, respectively. Compound 1F still did not afford 2F. Comparing these
results with the reaction yields and conditions used for α-benzylcyclohexanone [5], we found that it is
more difficult to obtain the cyclization products of α-benzylcyclododecanone, which may be attributed
to the conformational difference between the six-membered and twelve-membered ring ketones
involved [16].
Scheme 2. The cyclization mechanism of the title compounds.
OH
O
OH
-H+
acid
-H2O
CH2
CH2
R
R
R
R
2
1
The preferred conformation of cis-cyclododecene and its derivatives is [1ene2333], as discussed by
several research groups [17–20]，but research on the preferred conformation of trans-cyclododecene
is rather minimal [21] and a fundamental conclusion has not yet been reached. The title compounds
2B–2D are colorless crystals, but our attempts at growing a suitable single crystal in n-hexane and
cyclohexane were not successful, while 2A was successfully crystallized from n-hexane and subjected
to x-ray diffraction analysis. The results (Figure 1) show that a cis-configuration and the preferred
[1ene2333] conformation for the cis-cyclododecene moiety are present in the crystals of 2A, and the
benzocyclopenta-1,3-diene moiety adopts a planar structure. The preferred [1ene2333] conformation
of the cis-cyclododecene moiety was consistent with that seen in the crystals of other similar
molecules like 15-phenylbicyclo-[10,3,0]pentadec-1(12)-en-13-one [19], 1-methoxycarbonyloxyl-2-
phenoxy-
carbonyl-1,2-cyclododecene,
1-phenoxycarbonyloxyl-2-methoxycarbonyl-1,2-
cyclododecene [11], and 2,3,5,6-bis(ortho-1,10-decylidene)dihydropyrazine [15].
In the [1ene2333] conformation, the two protons of the 3-CH2 and 12-CH2 occupy side-exo and
side-endo-positions, respectively, and therefore they should display different chemical shifts in the 1H-
1
NMR spectrum. However, in the H-NMR spectra of 2A–2E, the two protons on each side of the
asymmetric 1,2-disubstituted cyclododecene appeared as equivalent protons which are coupled with
their adjacent protons to give triplet signals with 7.0 Hz coupling constants. These results are
consistent with the 1H-NMR characteristics of asymmetric 1,2-disubstituted cyclododecene reported in
our previous paper [11,15], and show that 2 may adopt two different [1ene2333] conformations like
other asymmetric 1,2-disubstituted cyclododecenes, which coexist in a dynamic equilibrium in

Molecules 2010, 15
702
1
solution [11,19,20]. The H-NMR spectra in solution are the averaged results of these two different
[1ene2333] conformations. Compound 2A adopted one of the two conformations in its crystal form.
Figure 1. The crystal structure of compound 2A.
In order to validate our conclusions, the quantum chemistry method was used to analyze the
conformation of the title compounds. The conformational optimization was performed for 2A–2E
using the Gaussian 03 software and the results compared with the x-ray diffraction structures of 2A
and 2,3,5,6-bis(ortho-1,10-decylidene)dihydropyrazine [15]. Vibrational frequencies were computed at
the same level, and the positive values of the first frequency for the title compounds showed the
optimized conformations were the local energy minimum conformations and located the stationary
points. Using 2A as example, its optimized structure was completely consistent with the obtained x-ray
structure and it also showed the same [1ene2333] conformation of 2,3,5,6-bis(ortho-1,10-
decylidene)dihydro-pyrazine, as seen in the superimposed diagrams in Figure 2(A). Similarly, we
analyzed the optimized structures of 2B–2E and superimposed them with that of 2A as seen in Figure
2(B). They all matched pretty well, and the conformational differences between the cis-cyclododecene
and the benzocyclopenta-1,3-diene moieties were insignificant. These results implied that the
cyclododecene moiety in the optimized structures of 2A–2E adopts a [1ene2333] conformation, and
the indene ring and its substituents have no significant influence on the conformation of the
cyclododecene moiety.
We also compared the torsion angles of 2A–2E (Table 1), and found that the changes of all twelve
torsion angles of 2A–2E are in the range of 0-1°, indicating that the structural differences between the
five compounds are minimal. Further, we compared the torsion angles of 2A–2E with those of 2,3,5,6-
bis(ortho-1,10-decylidene)dihydropyrazine, the changes of all twelve torsion angels are in the range of
0-9.1°, especially the angels C1-C2-C3-C4, C2-C3-C4-C5 and C3-C4-C5-C6 are 9.1, 6.7 and 3.8,
respectively. This may be due to the various influences of different rings connecting cyclododecene
and the relative distances near the double bond of cyclododecene. The larger the relative distance is,
the smaller the torsion angel changes. The other torsion angels showed only 0-3° difference. Again,
this comparison indicated that the cis-cyclododecene moiety in 2A–2E and 2,3,5,6-bis (ortho-1, 10-
decylidene) dihydropyrazine take the same [1ene2333] preferred conformation.

Molecules 2010, 15
703
Figure 2. Superimposed diagrams of 2A–2E and 2,3,5,6-bis(ortho-1,10-decylidene)-
dihydropyrazine.
A
B
2A: blue 2B: Green 2C: orange 2D: purple 2E: red
Table 1. The torsion angles of 2A-2E and 2,3,5,6-bis(ortho-1,10-decylidene)dihydropyrazine.
Torsion angle (°)
Angle
2A
2B
2C
2D
2E
Ref. [13]
C1-C2-C3-C4
C2-C3-C4-C5
-117.0(-118.1a)
162.0(166.6)
-65.2(-65.0)
-64.5(-64.5)
150.8(147.2)
-65.1(-64.6)
-62.7(-62.2)
175.6(178.9)
-74.3(-73.1)
-73.0(-71.2)
105.4(100.8)
-1.5(-2.4)
-117.0
162.7
-65.0
-64.2
150.1
-65.3
-63.1
176.0
-73.7
-73.0
105.0
-1.8
-117.1
162.5
-64.9
-64.3
150.3
-65.3
-63.3
175.7
-73.4
-73.1
105.4
-1.8
-117.0
162.8
-65.0
-64.2
150.0
-65.3
-63.0
176.1
-73.7
-72.9
104.8
-1.7
-117.2
162.6
-64.8
-64.2
150.2
-65.3
-63.4
175.8
-73.3
-73.0
105.2
-1.8
-126.1
168.7
-61.4
-63.3
148.9
-65.1
-61.5
177.8
-76.3
-74.2
102.4
-0.6
C3-C4-C5-C6
C4-C5-C6-C7
C5-C6-C7-C8
C6-C7-C8-C9
C7-C8-C9-C10
C8-C9-C10-C11
C9-C10-C11-C12
C10-C11-C12-C1
C11-C12-C1-C2
C12-C1-C2-C3
a These data are from the x-ray diffraction crystal structure of 2A.
Thomas [5] found that metallocenes containing indene were highly stable and efficient Ziegler-
Natta type catalysts for the polymerization of ethylene and propylene, but that lower polymer
molecular weights were obtained with the systems, which were attributed to the more indenyl-like
character of the systems or to the less rigid geometry of cyclohexene ring in the complexes. Based on
this observation, the relatively rigid [1ene2333] conformation of the cyclododecene ring in the
cyclododeceno[b]indene derivatives may be helpful to improve polymer molecular weights in the
polymerization of ethylene and propylene when using cyclododeceno[b]indene derivatives as Ziegler-
Natta type catalyst ligands. This is the subject of further studies being performed by our group.

Molecules 2010, 15
704
3. Experimental
3.1. General
Melting points were measured on a Yanagimoto NFG CO apparatus and are uncorrected; IR spectra
were determined on an IR-450 instrument; 1H-NMR and 13C-NMR spectra were recorded on a Brüker
DPX 300 NMR spectrometer with CDCl3 as solvent and TMS as internal standard. APCI-MS was
recorded with an Agilent LCQ LC-MSD ion-trap mass spectrometer. Cyclododecanone (99.8%) was
purchased from Acros Organics；p-chlorobenzyl chloride (99%) and p-fluorobenzyl chloride (99%)
were from Johnson Matthey；p-methylbenzyl chloride (99%) was from Alfa Aesar；o,p-
dichlorobenzyl chloride (98%) was from Avocado；p-methoxybenzyl alcohol (98%) was from
Merck；NaH (80%) was from Beijing Chemical Reagent Co.；PPA (80%, P2O5), anhydrous
aluminum chloride (99%) and methanesulfonic acid (98.5-101%) were from Beijing Yili Chemicals
Co.; p-methylbenzenesulfonic acid (98%) was from Shanghai Reagent factory; the solvents were
analytical grade and treated with sodium and benzophenone before usage.
3.2. Crystallographic Data
CCDC 759652 contains the supplementary crystallographic data for this paper. These data can be
obtained free of charge via www.ccdc.cam.ac.ck/conts/retrieving.html (or from CCDC, 12 Union Road,
Cambridge CB2 1EZ, UK. Fax: +44 1223 336033; E-Mail: deposit@ccdc.cam.ac.uk).
3.3. General Synthetic Method for Intermediates 1A–1F
Compounds 1A–1F were synthesized in 57–80% yields according to the procedure reported in
[12,22]. Among them, p-methoxybenzyl bromide was prepared using p-methoxybenzyl alcohol and
hydrogen bromide [23], and utilized in the next reaction without further purification. The mp, IR,
1H- and 13C-NMR of 1A were consistent with the data in the literature [12].
α-4-Chlorobenzylcyclododecanone (1B): Colorless crystal, yield 61%, mp: 80–82 °C. IR υ: 2930,
1710, 1590, 1490, 1430, 1400, 1355, 1105, 1020, 1000, 855, 810, 720, 700 cm-1. 1H-NMR δ: 7.20-7.26
(m, 2H), 7.06-7.10 (m, 2H), 2.85-2.94 (m, 2H), 2.49-2.62 (m, 2H), 2.16-2.25 (m, 1H), 1.54-1.76 (m,
13
4H), 1.29-1.25 (m, 14H). C-NMR δ: 213.62, 138.41, 131.91, 130.16, 128.48, 53.19, 38.46, 36.50,
29.31, 26.09, 25.76, 23.84, 23.67, 22.33, 22.24, 21.83.
α-4-Flurobenzylcyclododecanone (1C): Colorless crystal, yield 60%, mp: 68–69 °C. IR υ: 2920, 1715,
1
1595, 1490, 1435, 1400, 1355, 1105, 1020, 1000, 850, 810, 720, 705 cm-1. H-NMR δ: 7.07-7.13 (m,
2H), 6.91-6.98 (m, 2H), 2.85-2.92 (m, 2H), 2.47-2.65 (m, 2H), 2.16-2.26 (m, 1H), 1.54-1.75 (m, 4H),
13
1.29-1.26 (m, 14H). C- NMR δ: 213.88, 161.39 (1JFC = 240.0 Hz), 135.53 (4JFC = 3.1 Hz), 130.19
(3JFC = 7.8 Hz), 115.13 (2JFC = 21.1 Hz), 53.38, 38.52, 36.47, 29.35, 25.73, 24.10, 23.90, 23.75, 22.43,
22.24, 21.85.
α-4-Methylbenzylcyclododecanone (1D): Colorless crystal, yield 57%, mp: 68–70 °C. IR υ: 2925,
1718, 1605, 1495, 1430, 1405, 1360, 1100, 1020, 1010, 855, 805, 720 cm-1. 1H-NMR δ: 7.09-7.02 (m,

Molecules 2010, 15
705
4H), 2.94-2.83 (m, 2H), 2.63-2.44 (m, 2H), 2.30-2.22 (m, 4H), 1.71-1.57 (m, 4H), 1.28-1.27 (m, 14H).
13C-NMR δ: 214.35, 136.74, 135.62, 129.08, 128.71, 53.39, 38.51, 37.18, 29.44, 25.74, 24.20, 24.07,
23.96, 22.72, 22.33, 21.95, 20.98.
α-4-Methoxybenzylcyclododecanone (1E): Colorless crystal, yield 78%, mp: 75–76 °C. IR υ: 2920,
1700, 1590, 1500, 1450, 1430, 1250, 1170, 1100, 1050, 950, 800, 720, 690 cm-1. 1H-NMR δ: 7.09-7.04
(m, 2H), 6.83-6.78 (m, 2H), 3.78 (s, 3H), 2.91-2.80 (m, 2H), 2.62-2.57 (m, 1H), 2.52-2.42 (m, 1H),
2.29-2.19 (m, 1H), 1.71-1.28 (m, 4H), 1.27(m, 14H). 13C-NMR δ: 214.47, 158.00, 131.86, 129.74,
113.82, 55.20, 53.50, 38.60, 36.78, 29.45, 26.10, 25.69, 24.18, 24.06, 23.96, 22.71, 22.29, 21.94.
α-2,4-Dichlorobenzylcyclododecanone (1F): Colorless crystal, yield 76%, mp: 94–95 °C. IR υ: 2920,
1700, 1590, 1470, 1430, 1400, 1350, 1100, 1020, 1000, 850, 800, 720, 700 cm-1. 1H-NMR δ: 7.36-7.33
(m, 1H), 7.17-6.94 (m, 2H), 3.12-2.99 (m, 2H), 2.72-2.60 (m, 2H), 2.20-2.10 (m, 1H), 1.81-1.53 (m,
2H), 1.29-1.22 (m, 16H). 13C-NMR δ: 213.48, 136.31, 132.69, 132.44, 129.35, 126.98, 126.88, 50.44,
38.96, 34.32, 29.40, 26.01, 25.62, 24.16, 24.01, 23.86, 22.35, 22.33, 21.94.
3.4. General Synthetic Method for the Title Compounds 2A–2E
Taking 2D as an example: anhydrous n-hexane (30 mL) and 1.3 mL (0.02 mol) methylsulfonic acid
were added to a 100 mL three-necked bottle, then 0.6 g (0.002 mol) α-(4-methylbenzyl)
cyclododecanone was added into the bottle under stirring and heated to keep reflux. After the reaction
was completed (three days after TLC check), water (30 mL) was added to the mixture. The mixture
was extracted three times with n-hexane (3 × 30 mL), and the combined organic layer was washed
with saturated NaCl solution, dried with anhydrous MgSO4, filtered and evaporated under reduced
pressure to give an pale yellow oil. The oil was chromatographed on a silica gel column and washed
with redistilled petroleum ether. 0.5 g colorless crystal was afforded in 90% yield. Similarly, 2A–2E
was synthesized successfully, but 2F was an exception.
Cyclododeceno[b]indene (2A): Colorless crystals, mp 53–55 °C, 50% yield. IR υ: 2950, 1620, 1595,
1
1490, 1435, 1400, 1350, 1105 cm-1. H-NMR δ: 7.39-7.08 (m, 4H), 3.28 (s, 2H), 2.58 (t, J = 7.0 Hz,
13
2H), 2.47 (t, J = 7.2 Hz, 2H), 1.76-1.65 (m, 4H), 1.52-1.24 (m, 12H). C-NMR δ: 146.73, 143.79,
142.87, 136.93, 125.92, 123.47, 123.21, 118.85, 39.96, 27.17, 26.04, 25.30, 25.15, 25.08, 24.92, 23.69,
22.80, 22.33, 22.00. NMR data were consistent with the data in the literature [6, 8]. APCI-MS: 255
[M+H]+.
3-Chlorocyclododeceno[b]indene (2B): Colorless crystals, mp 78–80 °C, 35% yield. IR υ: 2960, 1625,
1
1590, 1495, 1430, 1405, 1350, 1110 cm-1. H-NMR δ: 7.27-7.23 (m, 2H), 7.08-7.05 (dd, J = 7.8,
2.0 Hz , 1H), 3.25 (s, 2H), 2.52 (t, J = 7.0 Hz, 2H), 2.47 (t, J = 7.2 Hz 2H), 1.74-1.64 (m, 4H), 1.50-
13
1.22 (m, 12H). C-NMR δ: 148.61, 145.88, 141.03, 136.57, 132.06, 123.99, 123.29, 119.11, 39.59,
27.14, 25.95, 25.42, 25.14, 25.12, 24.94, 23.75, 22.79, 22.28, 22.05. APCI-MS: 289 [M+H]+.
3-Flurocyclododeceno[b]indene (2C): Colorless crystals, mp 50–52 °C, 46% yield. IR υ: 2955, 1620,
1590, 1495, 1440, 1410, 1355, 1105 cm-1. 1H-NMR δ: 7.28-7.24 (m, 1H), 6.98-6.94 (m, 1H), 6.81-6.75
(m, 1H), 3.24 (s, 2H), 2.54 (t, J = 7.0 Hz, 2H), 2.47 (t, J = 7.2 Hz, 2H), 1.74-1.64 (m, 4H), 1.51-1.23

Molecules 2010, 15
706
13
(m, 12H). C-NMR δ: 162.45 (1JFC = 240.9 Hz), 148.75 (3JFC = 8.4 Hz), 146.38, 137.95 (4JFH = 2.5
Hz), 136.73 (4JFH = 2.9 Hz), 123.66 (3JFH = 9.1 Hz), 109.83 (2JFH = 22.9 Hz), 106.05 (2JFH = 22.9 Hz),
39.37, 27.14, 25.91, 25.46, 25.14, 25.10, 24.91, 23.72, 22.78, 22.31, 22.02. APCI-MS: 273 [M+H]+.
3-Methylcyclododeceno[b]indene (2D): Colorless crystals, mp 50–52 °C, 90% yield. IR υ: 2950, 1624,
1
1595, 1490, 1445, 1405, 1350, 1110 cm-1. H-NMR δ: 7.25 (d, J = 7.5 Hz, 1H), 7.10 (d, J = 1.5 Hz,
1H), 6.92 (dd, J = 7.5 1.5 Hz, 1H), 3.24 (s, 2H), 2.56 (t, J = 6.9 Hz, 2H), 2.46 (t, J = 7.2 Hz 2H),
2.39(s, 3H), 1.76-1.63 (m, 4H), 1.51-1.24(m, 12H). 13C-NMR δ: 146.99, 144.08, 139.92, 136.85,
135.44, 124.24, 122.89, 119.67, 39.58, 27.21, 26.10, 25.38, 25.19, 25.12, 25.00, 23.78, 22.85, 22.37,
22.06, 21.58. APCI-MS: 269 [M+H]+.
3-Methoxycyclododeceno[b]indene (2E): Light yellow oil, 62% yield. IR υ: 2960, 1625, 1592, 1495,
1450, 1415, 1340, 1115 cm-1. 1H-NMR δ: 7.26(d, J = 7.8 Hz, 1H), 6.85 (d, J = 2.4 Hz, 1H), 6.66 (dd,
J = 7.8,2.4 Hz, 1H), 3.83 (s, 3H), 3.23(s, 2H), 2.56 (t, J = 6.9 Hz, 2H), 2.46 (t, J = 7.2 Hz 2H), 1.73-
1.44 (m, 4H), 1.39-1.24 (m, 12H). 13C-NMR δ: 158.85, 148.25, 145.47, 136.83, 135.02, 123.44,
108.77, 105.34, 55.55, 39.22, 27.17, 26.04, 25.47, 25.18, 25.13, 24.96, 23.73, 22.84, 22.34, 22.04.
APCI-MS: 285 [M+H]+.
3.5. X-Ray Diffraction of Compound 2A
The crystal of compound 2A was obtained by slow evaporation of a hexane solution. X-ray
diffraction analysis: all measurements for 0.50 × 0.49 × 0.45 mm crystal were made with a Rigaku R-
axis RAPID IP four circle area detector using graphite monochromatized Mo Kα (λ = 0.071073 nm)
radiation at 73 K. Full spheres of data were collected to a 2θ limit of 25.00°. 19888 reflections were
collected with 5233 unique [R(int) = 0.0366], 4929 reflections were stronger than 2σ in intensity.
Space groups were determined from systematic absence and checked for higher symmetry. The
structures were solved by direct methods using SHELX, and refined on F2 using all data by full-matrix
least-squares procedures with SHELXL-97. All non-hydrogen atoms were refined with anisotropic
displacement parameters. An empirical absorption correction based on Xscans was made on all data.
Hydrogen atoms were located from the difference map and were constrained to geometrical estimates.
Final refinement was carried out with isotropic displacement parameters applied to hydrogen atoms.
The crystal structure parameters for 2A was: C19H26, Mr = 254.40, monoclinic, space group P2(1)/c,
a = 1.4406(3), b = 1.6472(3), c = 1.2580(3) nm, β = 93.36(3)°, V = 2.9799(10) nm3, Dc = 1.134 g/cm3,
Z = 8, F(000) = 1120, μ(Mo Kα) = 0.063 mm-1, final R = 0.0653, wR = 0.1725.
3.6. Conformational Optimization of Compounds 2A–2E
The geometry optimizations were performed by the DFT method using the B3LYP functional
[24,25]. A standard valence double-zeta with polarization function 6-31G (d, p) basis set [26] was used
for all kinds of atoms involved in five target molecules (2A–2E). Vibration frequencies were
computed at the B3LYP/6-31G (d, p) levels to characterize stationary points. All calculations were
performed using the Gaussian 03 software [27].

Molecules 2010, 15
707
4. Conclusions
Five cyclododeceno[b]indene derivatives were easily prepared in good yields using α-benzyl-
cyclododecanone as the raw material, and a 10-fold excess of methanesulfonic acid as catalyst. The
1
preferred conformations were analysized by x-ray diffraction, H-NMR and quantum chemistry
calculations, and compared with the X-ray diffraction structure of 2,3,5,6-bis(ortho-1,10-decylidene)-
dihydropyrazine. The results have shown that the cis-cyclododecene moiety in the title compounds
adopts a preferred [1ene2333] conformation, and that while two asymmetric [1ene2333] conformations
coexist in a dynamic equilibrium in solution, only one [1ene2333] conformation is present in the
crystal solid, and the substituted groups at aromatic ring do not have significant influence on the
conformation of the cyclododecene moiety.
Acknowledgements
The authors are grateful to the National Natural Science Foundation of China (Nos. 20772150,
20072053) and the Foundation of China Agricultural University (No. 2005011).
References
1. Muller, O.; Gourzoulidou, E.; Carpintero, M.; Karaguni, I.M.; Langerak, A.; Herrmann, C.;
Moroy, T.; Waldmann, H. Identification of potent Ras signaling inhibitors by pathway-selective
phenotype-based screening. Angew. Chem. Int. Ed. 2004, 43, 450–454.
2. Barbera, J.; Raitin, O.A.; Ros, M.B.; Torroba, T. Breaking the mold of discotic liquid crystals.
Angew. Chem. Int. Ed. 1998, 37, 296–299.
3. Austin, R.N.; Clark, T.J.; Dickson, T.E.; Killian, C.M.; Nile, T.A.; Schabacker, D.J.; McPhail
A.T. Synthesis and properties of novel substituted 4,5,6,7-tetrahydroindenes and selected metal
complexes. J. Organomet. Chem. 1995, 491, 11–18.
4. Alt, H.G.; Koppl A. Effect of the nature of metallocene complexes of Group IV metals on their
performance in catalytic ethylene and propylene polymerization. Chem. Rev. 2000, 100,
1205–1221.
5. Thomas, E.J.; Rausch, M.D.; Chien, J.C.W. Synthesis of novel tetrahydrofluorenyl-containing
group IV metallocenes for the Ziegler-Natta type polymerization of α-olefins. Organometallics
2000, 19, 5744–5749.
6. Bertram, H.; Koch, O.; Woerner, P.; Surburg, H. Preparation and use of macrocyclic lactones as
fragrances. EP 862911, 1998.
7. Griesbaum, K.; Frank, A.; McCullough, K.J. Syn- and anti-isomers of a O-methyloxime-
substituted tricyclic ozonide. Eur. J. Org. Chem. 2006, 1978–1980.
8. Parham, W.E.; Rinehert, J.K. 1, 3-Bridged aromatic systems. II. New synthesis of metacyclo-
phanes. J. Am. Chem. Soc. 1967, 89, 5668–5673.
9. Zakharkin, L.I.; Churiliva, I.M.; Pryanishnikov, A.P. Some transformations of 2-
benzylcyclodode- canones, prepared by alkylation of cyclododecanone with benzyl halides, under
phase-transfer catalysis. Izv. Akad. Nauk Ser. Khim. 1993, 5, 905–907.
10. Miyamoto, M.; Harada, Y.; Tobisu, M.; Chatani, N. Rh(I)-Catalyzed Reaction of 2-(Chloromethyl)
phenylboronic Acids and Alkynes Leading to Indenes. Org. Lett. 2008, 10, 2975–2978.

Molecules 2010, 15
708
11. Han, X.Y.; Wang, M.A.; Liang, X.M.; Wang, D.Q. Synthesis and conformation of cis-1,2-
disubstituted cyclododecene. Chin. J. Chem. 2004, 22, 563–567.
12. Wang, D.Q.; Yang, X.L.; Wang, M.A.; Liang, X.M.; You, T.P. Conformation of α-monosubsti-
tuted cyclododecanones. Acta Chim. Sinica 2002, 60, 475–480.
13. Wang, M.A.; Zhang, N.; Lu, H.Z.; Wang, D.Q. Conformation of α,α,α'-trisubstituted cyclodode-
canone. Chin. J. Chem. 2007, 25, 1196–1201.
14. Wang, M.A.; Tu, G.Z.; Ma, Z.C.; Zhang, N.; Wang, D.Q. Synthesis and structural characteristic
of two novel bicyclododecyl derivatives. Chin. J. Chem. 2006, 24, 205–209.
15. Wang, M.A.; Zhang, N.; Hou, X.T.; Wang, D.Q. Crystal and molecular structure of 2,3,5,6-bis-
(ortho-1,10-decylidene)dihydropyrazine. Chin. J. Struct. Chem. 2005, 24, 1254–1258.
16. Yang, X.L.; Wang, M.A.; Liang, X.M.; Wang, X.F.; You, T.B.; Wang, D.Q. Conformational
effect on the keto-enol tautomerism of α-carbonylcyclododecanones. Chin. J. Org. Chem. 2005,
25, 1279–1282.
17. Anet, F.A.L.; Rawdah T.N. The conformations of cis-cyclododecene. Evidence from dynamic
NMR spectroscopy and iterative force-field calculations. Tetrahedron Lett. 1979, 1943–1946.
18. Tetsuya, A.; Bieri, J.H.; Manfred, H. Structures of Ring-Enlargement Products. Helv. Chim. Acta
1985, 68, 1033–1053.
19. Wang, X.L.; Xue, J.Y.; Hu, Z.; Tang, S.X.; Wang, R.J. The crystal structure and conformation of
15-phenylbicyclo[10.3.0]pentadec-1(12)-en-13-one. Chin. J. Chem. 1990, 8, 385–389.
20. Tang, J.W.; Liu, J.J.; Hu, Z.; Wang, X.L.; Yao, X.K.; Wang, J.R. Crystal structure of 15-methyl
bicyclo[10.3.0]pentadec-1(12)-en-13-one and its stable molecular conformation. Chem. J. Chin.
Univ. 1991, 12, 902–905.
21. Pawar, D.M.; Davis, K.L.; Brown, B.L.; Simith, S.V.; Noe, E.A. Conformational study of trans-
cyclododecene by dynamic NMR spectroscopy and computational methods. J. Org. Chem. 1999,
64, 4580–4585.
22. Tsuji, J.; Yamada, T.; Shimizu, I. Syntheses of muscone and exaltone by three-carbon ring
expansion. J. Org. Chem. 1980, 45, 5209–5212.
23. Li, K.; Ran, L.; Yu, Y.H.; Tang, Y. Synthesis and Characterization of Pentaerythritol-Derived
Oligoglycol and Their Application to Catalytic Wittig-Type Reactions. J. Org. Chem. 2004, 69,
3986–3989.
24. Becke, A.D. A new mixing of Hartree-Fock and local density-functional theories. J. Chem. Phys.
1993, 98, 1372–1377.
25. Becke, A.D. Density-functional thermochemistry. III. The role of exact exchange. J. Chem. Phys.
1993, 98, 5648–5652.
26. Petersson, G.A.; Bennett, A.; Tensfeldt, T.G.; Al-Laham, M.A.; Shirley, W.A.; Mantzaris, J. A
complete basis set model chemistry. I. The total energies of closed-shell atoms and hydrides of
the first-row elements. J. Chem. Phys. 1988, 89, 2193–2218.
27. Frisch, M. J.; Trucks, G. W.; Schlegel, H. B.; Scuseria, G. E.; Robb, M. A. Gaussian 03, Revision
B.03; Gaussian, Inc.: Pittsburgh, PA, USA, 2003.
Sample Availability: Samples of the compounds 2A–2E are available from the authors.
© 2010 by the authors; licensee Molecular Diversity Preservation International, Basel, Switzerland.
This article is an open-access article distributed under the terms and conditions of the Creative
Commons Attribution license (http://creativecommons.org/licenses/by/3.0/).
