10.1002/cmdc.201800393
ChemMedChem
FULL PAPER
1
mg, 44%), mp.: 58 °C. H NMR (CDCl3): 7.57 (1H, s), 7.39 (2H, t, J =
1H-imidazole-1-carboxamide 8k (90 mg, 0.317 mmol) was added MCPBA
(149 mg, 0.475 mmol) at 20-25 ºC in one portion. The reaction was allowed
to stir at 20-25 ºC for 20 h. The mixture was evaporated to dryness, the
residue was then triturated in diethyl ether. The resulting white crystals
were collected, dried on air and recrystallized from isopropanol to afford 8l
(46 mg, 48% yield). mp.: 227.5 °C. 1H NMR (DMSOd6): 8.70 (1H, t, J =
1.5 Hz), 8.28 (1H, s), 8.20 (1H, s), 8.11 (1H, d, J = 6.5 Hz), 7.78 (1H, d, J
= 8.1 Hz), 7.45 (1H, d d, J = 6.5, 8.1 Hz), 3.80 (1H, m), 2.92 (3H, s), 1.77
(4H, m), 1.56 (3H, m), 1.30 (2H, m), 1.11 (1H, m). 13C NMR (DMSOd6):
DMSO: 150.4, 138.3, 137.1, 135.7, 134.7, 132.8, 126.7, 121.2, 117, 56.8,
31.4, 29, 25.1, 24.8. Elemental analysis: (C16H20N4O2): Calc: C, 63.98; H,
6.71; N, 18.65. Found: C, 63.76; H, 6.94; N, 18.74.
7.7 Hz), 7.32 (1H, t, J = 7.3 Hz), 7.13 (2H, d, J = 7.7 Hz), 6.85 (1H, s), 6.81
(1H, s), 3.50 (3H, s). 13C NMR (CDCl3): 150.2, 142.9, 137.7, 130.3, 129,
128, 125.9, 118.4, 40.1. Elemental analysis: (C11H11N3O): Calc: C, 65.66;
H, 5.51; N, 20.88. Found: C, 65.68; H, 5.11; N, 21.03.
N-Methyl-N,4-diphenyl-1H-imidazole-1-carboxamide (8b). To a stirred
solution of 4-phenyl-1H-imidazole 7b (433 mg, 3.0 mmol) in THF (10 mL)
was added DIPEA (0.78 mL, 4.5 mmol) followed by a solution of
methyl(phenyl)carbamic chloride (534 mg, 3.15 mmol) in toluene (4 mL).
The reaction mixture was stirred at room temperature for 1 h, then was
heated at 80 °C for 1 h. After being cooled to room temperature the
reaction was evaporated and partitioned between DCM and water. The
organic layer was separated, dried over MgSO , filtered and evaporated.
(4,4-Dimethyloxazolidin-3-yl)(4-phenyl-1H-imidazol-1-yl)methanone
(8f). To a stirred solution of 4-phenyl-1H-imidazole 9b (433 mg, 3.00 mmol)
in THF (10 mL) at 0 ºC was added dropwise a solution of 4,4-
dimethyloxazolidine-3-carbonyl chloride (515 mg, 3.15 mmol) in THF (10
mL) followed by pyridine (0.48 mL, 5.93 mmol). The reaction was allowed
to stir at room temperature for 1 h, then heated at reflux for 4 h. The mixture
was cooled to room temperature and evaporated. The residue was
partitioned between DCM and water. The organic phase was separated,
washed with 2N HCl, water and brine, then dried over MgSO4, filtered and
evaporated in vacuum. Column chromatography (petroleum ether–ethyl
acetate, 2:1) followed by recrystallization from isopropanol afforded the
title compound as a white powder (120 mg, 14 %). mp.: 89 °C. 1H NMR
(CDCl3): 7.96 (1H, d, J = 1.3 Hz), 7.79 (2H, m, J = 8.3 Hz), 7.52 (1H, d,
J = 1.3 Hz), 7.41 (2H, m, J = 7.9 Hz), 7.30 (1H, m, J = 7.3 Hz), 5.13 (2H,
s), 3.88 (2H, s), 1.62 (6H, s). 13C NMR (CDCl3): 146.5, 142.6, 136.2,
132.7, 128.7, 127.7, 125.2, 112, 81.1, 80.3, 61.8, 22.8. Elemental analysis:
(C15H17N3O2): Calc: C, 66.40; H, 6.32; N, 15.49. Found: C, 65.59; H, 6.35;
N, 15.32.
4
Trituration in a mixture of petroleum ether–ethyl acetate (3:1) followed by
filtration and drying gave 8b as a beige powder (465 mg, 56%), mp.: 104-
1
105 °C. H NMR (CDCl3): 7.60 (2H, d, J = 7.7 Hz), 7.53 (1H, s), 7.40
(2H, t, J = 7.7 Hz), 7.34 (1H, m), 7.32 (2H, t, J = 7.6 Hz), 7.25 (1H, m), 7.19
(2H, m), 7.18 (1H, s), 3.52 (3H, s). 13C NMR (CDCl3): 150.1, 142.9, 141.4,
137.7, 132.8, 130.4, 128.5, 128.2, 127.4, 126, 125, 113.5, 40.2. Elemental
analysis: (C17H15N3O): Calc: C, 73.63; H, 5.45; N, 15.15. Found: C, 73.25;
H, 5.29; N, 15.05.
N-Methyl-N,2-diphenyl-1H-imidazole-1-carboxamide (8c). To a stirred
suspension of sodium hydride (166 mg, 4.15 mmol, 60% dispersion in
mineral oil) in THF (10 mL) at 0 ºC was added a solution of 2-phenyl-1H-
imidazole 7e (500 mg, 3.47 mmol) in tTHF (5 mL). The mixture was stirred
in the cold for 30 min then was allowed to stir at room temperature for 2 h.
The mixture was cooled again to
0
ºC and
a
solution of
methyl(phenyl)carbamic chloride (616 mg, 3.63 mmol) in THF (5 mL) was
added dropwise. The reaction was stirred in the cold for 0.5 h, then was
allowed to stir at room temperature for 2 days. Thereupon, water was
added at 0 ºC and the solvent was evaporated and then the oily residue
was partitioned between DCM and water. The organic phase was
separated, washed with water and brine, then dried over MgSO4, filtered
and evaporated to leave an oily solid. Chromatography (petroleum ether–
ethyl acetate, 2:1) allowed the separation of the product as a pale yellow
solid (166 mg, 17%), mp.: 123-125 °C. 1H NMR (CDCl3): 7.43-7.24 (6H,
m), 7.14-6.93 (4H, m), 6.33 (2H, br), 3.37 (3H, s br). 13C NMR (CDCl3):
151.9, 146.5, 141.4, 130.3, 129.3, 129, 128.9, 128.3, 127.3, 126.9, 124.1,
120, 38.9. Elemental analysis: (C17H15N3O): Calc: C, 73.63; H, 5.45; N,
15.15. Found: C, 73.83; H, 5.74; N, 14.82.
N-(2,4-Difluorophenyl)-N-methyl-1H-benzo[d][1,2,3]triazole-1-
carboxamide (10b). To a stirred solution of phosgene (15 mL, 28.5 mmol,
20 % solution in toluene) at 0 ºC was added a solution of 1H-
benzo[d][1,2,3]triazole 9a (1 g, 8.39 mmol) in THF (20 mL) dropwise. The
resulting mixture was stirred in the cold for 0.5 h, then allowed to stir at
room temperature overnight. A strong stream of nitrogen was bubbled
through the mixture for 0.5 h, then the solvent was removed by evaporation
under
reduced
pressure
to
give
the
intermediate
1H-
benzo[d][1,2,3]triazole-1-carbonyl chloride as a clear oil that solidified on
standing (762 mg, 4.2 mmol). The above intermediate was suspended in
THF (20 mL), cooled to 0 ºC and treated with pyridine (0.36 mL, 4.41 mmol)
followed by dropwise addition of 2,4-difluoro-N-methylaniline (601 mg,
4.20 mmol). The reaction mixture was allowed to stir at room temperature
overnight, then cooled to 0 ºC, diluted with water and ethyl acetate. The
organic layer was separated, washed with 1N HCl and brine, then dried
over MgSO4 filtered and evaporated. Recrystallization from isopropanol
gave 10b as a white solid (378 mg, 31%), mp.: 91-92 °C. 1H NMR (CDCl3):
8.10 (1H, d, J = 8.4 Hz), 8.01 (1H, d, J = 8.1 Hz), 7.63 (1H, m, J = 7.8
Hz), 7.45 (1H, t, J = 7.7 Hz), 7.30 (1H, m), 6.88 (1H, m), 6.84 (1H, m), 3.60
(3H, s). 13C NMR (CDCl3): 161.8 (d d, J = 11.5, 251.0 Hz), 157.7 (d d, J
= 12.5, 252.0 Hz), 150.1, 144.9, 132.7, 129.6, 129.3 (d d, J = 1.5, 10.0 Hz),
127.7 (d d, J = 5.0, 12.0 Hz), 125.4, 119.9, 113.5, 112.1 (d d, J = 4.0, 23.0
N-Cyclohexyl-N-methyl-4-(pyridin-3-yl)-1H-imidazole-1-carboxamide
(8k). To
a
stirred suspension of 3-(1H-imidazol-4-yl)pyridine
dihydrochloride 7f (0.654 g, 3 mmol) in THF (10 mL) was added potassium
tert-butoxide (0.673 g, 6.00 mmol) and the mixture was refluxed for 1 h.
Then, N,N-dimethyl formamide (1 mL) was added and the heating was
continued for additional 30 min The resultant brown suspension was
cooled to room temperature and treated with pyridine (0.37 mL, 4.50 mmol)
and N,N-dimethylpyridin-4-amine (0.037 g, 0.300 mmol) followed by
addition of cyclohexyl(methyl)carbamic chloride (0.553 g, 3.15 mmol). The
reaction was heated to 90 °C overnight. After cooling the mixture was
diluted with water and extracted with ethyl acetate. The organic phase
was dried over MgSO4 and filtered. After evaporation, the crude product
was recrystallized from 2-propanol, crystals were collected and dried
under vacuum to afford 8k (62 mg, 6.9 % yield). mp.: 161-163 °C. 1H NMR
(CDCl3): 9.01 (1H, d d, J = 0.8, 2.3 Hz), 8.53 (1H, d d, J = 1.7, 4.8 Hz),
8.12 (1H, d d d, J = 1.8, 2.2, 8.0 Hz), 7.94 (1H, d, J = 1.3 Hz), 7.58 (1H, d,
J = 1.3 Hz), 7.34 (1H, d d d, J = 0.8, 4.9, 8.0 Hz), 3.95 (1H, m), 3.01 (3H,
s), 1.87 (4H, m), 1.71 (1H, d br, J = 13.5 Hz), 1.59 (2H, d q, J = 3.5, 12.5
Hz), 1.38 (2H, t q, J = 3.5, 13.0 Hz), 1.13 (1H, t q, J = 3.5, 13.5 Hz). 13C
NMR (CDCl3): 151, 148.5, 146.7, 139.2, 137.3, 132.4, 129, 123.6, 114,
57.6, 31.4, 30, 25.4, 25.2. Elemental analysis: (C16H20N4O): Calc: C,
67.58; H, 7.09; N, 19.7. Found: C, 66.77; H, 7.36; N, 19.95.
Hz), 105.1 (d d,
J = 24.0, 26.5 Hz), 39.7. Elemental analysis:
(C14H10F2N4O) Calc: C, 58.33; H, 3.5; N, 19.44. Found: C, 58.66; H, 3.52;
N, 19.75.
N-(2,4-Difluorophenyl)-1H-benzo[d][1,2,3]triazole-1-carboxamide
(10d). To an ice-cooled stirred solution of benzotriazole 9a (300 mg, 2.52
mmol) in DCM (18 mL) was added 2,4-difluoro-1-isocyanatobenzene (410
mg, 2.64 mmol) dropwise. After being stirred for 6 h at room temperature
the solvent was evaporated. Recrystallization from
a mixture of
isopropanol-DCM afforded 10d as a white solid (209 mg, 30%), mp.:148-
150 °C. 1H NMR (CDCl3): 9.28 (1H, s), 8.32 (1H, m, J = 8.3 Hz), 8.27
(1H, m, J = 6.0, 8.9 Hz), 8.17 (1H, m, J = 8.3 Hz), 7.70 (1H, m, J = 8.2 Hz),
7.53 (1H, m, J = 8.1 Hz), 7.0 (2H, m). 13C NMR (CDCl3): 160.6 (d d, J =
11.5, 248.0 Hz), 153.4 (d d, J = 12.0, 249.0 Hz), 146.5, 146.4, 131.5, 130.5,
3-(1-(Cyclohexyl(methyl)carbamoyl)-1H-imidazol-4-yl)pyridine
1-
oxide (8l). To a stirred solution of N-cyclohexyl-N-methyl-4-(pyridin-3-yl)-
9
