Enantioselective vinylation of aldehydes with the vinyl Grignard reagent catalyzed by magnesium complex of chiral BINOLs

Article abstract of DOI:10.1002/chir.23038

Enantioselective vinylation of aldehydes via direct catalytic asymmetric Grignard reaction of aldehdyes and the vinyl Grinard reagent is a long-standing challenge. This work demonstrated that the magnesium (S)-3,3′-dimethyl BINOLate enantioselectively catalyze the direct vinylation of aldehydes with the deactivated vinylmagnesium bromide by bis(2-[N,N′-dimethylamino]ethyl) ether (BDMAEE) in the addition of n-butylmagnesium chloride. The highest ee of 63% was achieved up to date.

Full text of DOI:10.1002/chir.23038

Received: 10 August 2018
DOI: 10.1002/chir.23038
Revised: 29 October 2018
Accepted: 1 November 2018
R E G U L A R A R T I C L E
Enantioselective vinylation of aldehydes with the vinyl
Grignard reagent catalyzed by magnesium complex of chiral
BINOLs
Pei Wang1
| Guo‐Rong Ma1 | Sheng‐Li Yu2 | Chao‐Shan Da2,3
1 School of Basic Medical Sciences,
Ningxia Medical University, Yinchuan,
China
2 Institute of Biochemistry and Molecular
Biology, School of Life Sciences, Lanzhou
University, Lanzhou, China
3 State Key Laboratory of Organic
Chemistry, Lanzhou University, Lanzhou,
China
Abstract
Enantioselective vinylation of aldehydes via direct catalytic asymmetric Gri-
gnard reaction of aldehdyes and the vinyl Grinard reagent is a long‐standing
challenge. This work demonstrated that the magnesium (S)‐3,3′‐dimethyl
BINOLate enantioselectively catalyze the direct vinylation of aldehydes with
the deactivated vinylmagnesium bromide by bis(2‐[N,N′‐dimethylamino]ethyl)
ether (BDMAEE) in the addition of n‐butylmagnesium chloride. The highest ee
of 63% was achieved up to date.
Correspondence
Pei Wang, School of Basic Medical
Sciences, Ningxia Medical University,
Yinchuan 750004, China.
KEYWORDS
asymmetric catalysis, BINOL, deactivation, Grignard reaction, vinylation
Email: wangp13@lzu.edu.cn
Funding information
The Higher Education Scientific Research
Project of Ningxia, Grant/Award Number:
NGY2018‐92; The Ningxia High School
first‐class Disciplines (West China first‐
class Disciplines Basic Medical Sciences
at Ningxia Medical University), Grant/
Award Number: NXYLXK2017B07; The
Project of Ningxia Medical University,
Grant/Award Number: XT2017016
1 | INTRODUCTION
(Oi‐Pr)3, and then R‐Ti (Oi‐Pr)3 highly enantioselectively
delivered R group to aldehydes catalyzed by chiral diol‐Ti
Grignard reagents are among the most useful and impor-
tant organic metal reagents. The addition of Grignard
reagents to aldehydes is commonly used cost‐effective
methodology to construct secondary alcohols via carbon–
carbon bond formation. Because of greatly reactive,
however, the catalytic asymmetric addition of Grignard
reagents to aldehydes is typically challenging.1-10 Only
recently successful strategies were developed in access to
highly enantiopure secondary alcohols via catalytic asym-
metric Grignard reactions.11-13 The groups of Harada,14-16
Xu,17,18 and Yus19,20 utilized superstoichiometric Ti (Oi‐
Pr)4 to transmetallate RMgX (Br, Cl) to less reactive R‐Ti
(Oi‐Pr)2 complexes. Our group demonstrated that the addi-
tive bis([2‐[N,N′‐dimethylamino)]thyl) ether (BDMAEE)
effectively deactivated the reactivity of Grignard reagents
and then similarly transmetallated R functional group
of RMgBr to R‐Ti (Oi‐Pr)3 by using stoichiometric Ti (Oi‐
Pr)4.21-27 The complex of chiral BINOL‐Ti (Oi‐OPr)2 or
H8‐BINOL‐Ti (Oi‐OPr)2 highly catalyzed the enantiose-
lective delivery of R group to aldehydes. Irrespective of
the impressive advancement of catalytic alkylation and
aromatization of aldehydes with Grignard reagents, the
catalytic enantioselective vinylation of aldehydes to pro-
duce enaniopure allyl alcohols are far from exploration.
Chirality. 2018;1–8.
wileyonlinelibrary.com/journal/chir
© 2018 Wiley Periodicals, Inc.
1

2
WANG ET AL.
Only two examples were dispersed in the literature. In
the first example, stoichiometric chiral BINOL‐modified
divinylmagnesium was used, and only 12% of enantio-
selectivity was afforded (Equation 1, Scheme 1).28 In
the second examples, we also investigated deactivated
vinylmagnesium bromide with BDMAEE, but low 33% of
enantioselectivity was achieved by using substoichiometric
chiral catalyst (Equation 2, Scheme 1).21 The desired and
challenging highly enantioselective vinylation of alde-
hydes hopes novel strategy.
Reactions were monitored by thin‐layer chromatography
(TLC); column and preparative TLC purification were car-
ried out using silica gel. Melting points were recorded on
an X‐4 melting point apparatus and are uncorrected. Opti-
1
cal rotations were recorded on a polarimeter. H nuclear
magnetic resonance (NMR) and 13C NMR spectra were
measured on 200 and 100 MHz spectrometers, respec-
tively, in CDCl3 with TMS as an internal standard; chem-
ical shifts are reported in parts per million. The
determination of ee values was carried out using chiral
high‐performance liquid chromatography (HPLC) with
an OD‐H, OJ‐H, or AS‐H column.
Chiral allylic secondary alcohols are key structural
motifs in a considerable number of natural products and
pharmaceutically active compounds29-33 and an impor-
tant class of indispensable precursors of a wide range of
organic transformations.34-40 These chiral building blocks
are typically achieved by enzymatic or nonenzymatic
kinetic resolution of the corresponding racemic com-
pounds,41-44 vinylation of aldehydes with less reactive
vinyl metal reagents vinyl zinc,45-49 silane,50-52 boron,53-
2.1 | General procedure for the catalytic
asymmetric vinylation of aldehydes
Ligand L6 (0.15 mmol, 47.1 mg) and 2.0 mL of dry methyl
t‐butyl ether (MTBE) were introduced into a dry 10‐mL
round bottom flask A equipped with a clean stir bar
under an argon atmosphere. n‐BuMgCl (0.18 mmol,
0.2 mL) was slowly added to the flask A at 0°C, and the
mixture was stirred for 1 hour. The vinyl Grignard
reagent (2.14 mL, 1.5 mmol) and 7.56 mL of dry MTBE
were introduced into another dry 25 mL round bottom
flask B equipped with a clean stir bar under an argon
atmosphere. Bis(2‐[N,N′‐dimethylamino]ethyl) ether
(BDMAEE) (282 μL, 1.5 mmol) was slowly added to flask
B at 0°C, and the mixture was stirred 1.5 hours. Benzalde-
hyde (54 μL, 0.5 mmol) was added to the flask A. After
0.5 hour, the supernatant (6.0 mL, ~1.0 mmol) of flask
B was slowly added to the flask A for 30 minutes at
−20°C. The mixture was warmed to 0°C and stirred for
5 hours. The reaction was quenched with 1 N HCl at
0°C and extracted with ethyl acetate (5 mL x 3). The
55
bismuthine,56 and aluminum57 and hydroxylation via
asymmetric allylic substitution.58-62 Only Oppolzer and
coworker observed the simplest asymmetric vinylation
of aldehydes with divinylzinc.34 And while these methods
successfully affording highly enantiopure allylic alcohols,
their practicality was significantly hampered by cost‐
effectiveness. Herein, we firstly reported direct catalytic
asymmetric vinylation of aldehydes catalyzed chiral mag-
nesium BINOlate (Equation 3, Scheme 1).
2 | MATERIALS AND METHODS
All reactions were performed under an argon atmosphere,
and solvents were dried according to established proce-
dures prior to use. All of the reagents were commercial.
SCHEME 1 The asymmetric vinylation
of aldehydes with the vinyl Grignard
reagent

WANG ET AL.
3
2.1.4 | (S)‐1‐(4‐chlorophenyl)prop‐2‐en‐1‐
ol (3d)29
1
49% yield, 42% ee; [α]D20 = −5.0 (c 0.4, CHCl3); H NMR
(200 MHz, CDCl3): δ 7.31–7.26 (m, 4H), 6.09 to 5.92 (m,
1H), 5.38 to 5.18 (m, 3H); enantiometric excess was deter-
mined by HPLC with a Chiralpak OJ‐H column 1.0 mL/
min, (2‐propanol: hexane = 5:95), major enantiomer
tr = 14.6 minutes, minor enantiomer tr = 15.9 minutes.
SCHEME 2 The possible reaction process
2.1.5 | (S)‐1‐(4‐(trifluoromethyl)phenyl)
prop‐2‐en‐1‐ol (3e)29
combined organic layer was washed with saturated brine
and dried over Na2SO4, filtered, and concentrated. The
residue followed by flash column chromatography (Petro-
leum ether: ethyl acetate = 10:1) to give desired products.
41% yield, 48% ee; [α]D20 = −9.4 (c 0.32, CHCl3); 1H NMR
(200 MHz, CDCl3): δ 7.64 to 7.26 (m, 4H), 6.10 to 5.93 (m,
1H), 5.42 to 5.22 (m, 3H); enantiometric excess was deter-
mined by HPLC with a Chiralpak OJ‐H column 1.0 mL/
min, (2‐propanol: hexane = 5:95), major enantiomer
tr = 14.0 minutes, minor enantiomer tr = 15.3 minutes.
2.1.1 | (S)‐1‐phenylprop‐2‐en‐1‐ol (3a)28
20
Yield 49.8 mg; 47% yield, 61% ee; [α]D = −3.8 (c 0.8,
1
CHCl3); H NMR (200 MHz, CDCl3): δ 7.37 to 7.25 (m,
2.1.6 | (S)‐1‐(p‐tolyl)prop‐2‐en‐1‐ol (3f)28
5H), 6.13 to 5.97 (m, 1H), 5.38 to 5.17 (m, 3H);
enantiometric excess was determined by HPLC with a
Chiralpak OD‐H column 1.0 mL/min, (2‐propanol: hex-
ane = 5:95), minor enantiomer tr = 8.2 minutes, major
enantiomer tr = 9.9 minutes.
20
1
43% yield, 42% ee; [α]D = −11.8 (c 0.34, CHCl3); H
NMR (200 MHz, CDCl3): δ 7.28 to 7.14 (m, 4H), 6.12 to
5.96 (m, 1H), 5.38 to 5.15 (m, 3H), 2.34 (s, 3H), 2.03 (s,
1H); enantiometric excess was determined by HPLC with
a Chiralpak OJ‐H column 1.0 mL/min, (2‐propanol: hex-
ane = 5:95), major enantiomer tr = 16.3 minutes, minor
enantiomer tr = 20.7 minutes.
2.1.2 | (S)‐1‐(naphthalen‐1‐yl)prop‐2‐en‐1‐
ol (3b)14
20
1
68% yield, 57% ee; [α]D = −14 (c 1.1, CHCl3); H NMR
(200 MHz, CDCl3): δ 8.19–8.16 (m, 1H), 7.89 to 7.78 (m,
2H), 7.63 to 7.42 (m, 4H), 6.32 to 6.16 (m, 1H), 5.93 (m,
1H), 5.48 to 5.25 (m, 2H); enantiometric excess was deter-
mined by HPLC with a Chiralpak OD‐H column 1.0 mL/
min, (2‐propanol: hexane = 10:90), major enantiomer
tr = 9.4 minutes, minor enantiomer tr = 15.3 minutes.
2.1.7 | (S)‐1‐(m‐tolyl)prop‐2‐en‐1‐ol (3g)34
1
45% yield, 46% ee; H NMR (200 MHz, CDCl3): δ 7.28 to
7.08 (m, 4H), 6.13 to 5.96 (m, 1H), 5.39 to 5.16 (m, 3H),
2.35 (s, 3H), 2.00 (s, 1H); enantiometric excess was deter-
mined by HPLC with a Chiralpak OD‐H column 1.0 mL/
min, (2‐propanol: hexane = 3:97), minor enantiomer
tr = 11.1 minutes, major enantiomer tr = 15.1 minutes.
2.1.3 | (S)‐1‐(naphthalen‐2‐yl)prop‐2‐en‐1‐
ol (3c)29
2.1.8 | (S)‐1‐(o‐tolyl)prop‐2‐en‐1‐ol (3h)28
1
66% yield, 35% ee; [α]D20 = + 2.0 (c 1.3, CHCl3); 1H NMR
(200 MHz, CDCl3): δ 7.84 to 7.81 (m, 4H), 7.49 to 7.45 (m,
3H), 6.20 to 6.03 (m, 1H), 5.44 to 5.20 (m, 3H);
enantiometric excess was determined by HPLC with a
Chiralpak AS‐H column 1.0 mL/min, (2‐propanol: hex-
ane = 3:97), minor enantiomer tr = 15.4 minutes, major
enantiomer tr = 17.7 minutes.
46% yield, 30% ee; H NMR (200 MHz, CDCl3): δ 7.46 to
7.43 (m, 1H), 7.23 to 7.17 (m, 3H), 6.12 to 5.95 (m, 1H),
5.42 to 5.18 (m, 3H), 2.36 (s, 1H), 1.92 (s, 1H);
enantiometric excess was determined by HPLC with a
Chiralpak OD‐H column 1.0 mL/min, (2‐propanol: hex-
ane = 3:97), minor enantiomer tr = 12.0 minutes, major
enantiomer tr = 13.6 minutes.

4
WANG ET AL.
2.1.9 | (S)‐1‐(2‐(trifluoromethyl)phenyl)
prop‐2‐en‐1‐ol (3i)34
2.1.14 | (S)‐5‐phenylpent‐1‐en‐3‐ol (3n)53
35% yield, 40% ee; [α]D = −5.0 (c 1.0, CHCl3);1H NMR
20
43% yield, 47% ee; [α]D20 = −11.8 (c 0.47, CHCl3); 1H NMR
(200 MHz, CDCl3): δ 7.75 to 7.26 (m, 4H), 6.12 to 5.95 (m,
1H), 5.66 (m, 1H), 5.43 to 5.19 (m, 2H); enantiometric excess
was determined by HPLC with a Chiralpak OD‐H column
1.0 mL/min, (2‐propanol: hexane = 3:97), minor enantio-
mer tr = 9.5 minutes, major enantiomer tr = 10.3 minutes.
(200 MHz, CDCl3): δ 7.32 to 7.18 (m, 5H), 5.99 to 5.82 (m,
1H), 5.28 to 5.11 (m, 2H), 4.14 to 4.11 (m, 1 H), 2.77 to
2.67 (m, 2H), 1.91 to 1.80 (m, 2H); enantiometric excess
was determined by HPLC with a Chiralpak OD‐H column
1.0 mL/min, (2‐propanol: hexane = 3:97), minor enantio-
mer tr = 18.2 minutes, major enantiomer tr = 27.1 minutes.
2.1.10 | (S)‐1‐(2‐chlorophenyl)prop‐2‐en‐1‐
3 | RESULTS AND DISCUSSION
ol (3j)45
Based upon previous results, BDMAEE was similarly
57% yield, 63% ee; [α]D = −6.0 (c 0.38, CHCl3);1H NMR
20
used
to
deactivate
vinylmagnesium
bromide
(200 MHz, CDCl3): δ 7.55 to 7.18 (m, 4H), 6.12 to 5.95 (m,
1H), 5.64 (m, 1H), 5.43 to 5.20 (m, 2H); enantiometric excess
was determined by HPLC with a Chiralpak OD‐H column
1.0 mL/min, (2‐propanol: hexane = 3:97), minor enantio-
mer tr = 11.3 minutes, major enantiomer tr = 13.8 minutes.
(CH2 = CHMgBr) in this work. A class of chiral Ligands
L2‐L9 were synthesized except the commercially avail-
able (S)‐BINOL (L1). L1 was initially examined, and
BDMAEE was added to deactivate the reactivity of
CH2 = CHMgBr in dichloromethane, and it obtained very
low ee of 8% with modest yield (Table 1, entry 1). The
smaller dihedral angle H8‐BINOL (L2) obtained similar
result (entry 2). While TADDOL was used, yield
increased accompanying with the slightly reduced ee
(entry 3). Unfortunately, chiral amine L4 and L5 only
obtained racemic allylic alcohol. The 3,3′‐bissubstituted
BINOLs L6 and L7 and (S)‐3,3′‐dimethyl H8‐BINOL L9
as ligands were observed but the results were still unsat-
isfactory (entries 6‐9), and the highest ee of 13% was
afforded with L6 (entry 6). Another additive was then
intended to increase the enantioselectitivty, and a series
of metal reagents was examined with L6 (entries 10‐14).
Regretfully, only n‐BuMgCl afforded slightly improved
ee of 18% (entry 10). Then, solvents were observed, and
THF and methyl tert‐butyl ether (MTBE) obtained the
highest enantioselectivity (28%) and MTBE obtained
higher yield than THF (entries 10 and 16–18). Then, the
amount of L6 and n‐BuMgCl was optimized, and the
highest 60% of enantioselectivity was obtained (entries
16‐25), indicating a possible chloride Grignard reagent
2.1.11 | (S)‐1‐(2‐bromophenyl)prop‐2‐en‐1‐
ol (3k)29
51% yield, 47% ee; [α]D = −25.0 (c 0.42, CHCl3);1H NMR
20
(200 MHz, CDCl3): δ 7.55 to 7.11 (m, 4 H), 6.11 to 5.95 (m,
1 H), 5.61 (m, 1 H), 5.44 to 5.21 (m, 2 H); enantiometric excess
was determined by HPLC with a Chiralpak OD‐H column
1.0 mL/min, (2‐propanol: hexane = 3:97), minor enantiomer
tr = 12.0 minutes, major enantiomer tr = 15.8 minutes.
2.1.12 | (S)‐1‐(thiophen‐3‐yl)prop‐2‐en‐1‐ol
(3l)41
27% yield, 34% ee; [α]D = −19.0 (c 0.26, CHCl3);1H
20
NMR (200 MHz, CDCl3): δ 7.33 to 7.06 (m, 3H), 6.17 to
6.00 (m, 1H), 5.61 (m, 1H), 5.40 to 5.19 (m, 3H);
enantiometric excess was determined by HPLC with a
Chiralpak OD‐H column 1.0 mL/min, (2‐propanol: hex-
ane = 3:97), major enantiomer tr = 26.3 minutes, minor
enantiomer tr = 34.4 minutes.
complex
A (Scheme 2) effectively catalyzing the
asymmetric vinylation of aldehydes with the vinyl
Grignard reagent.
In order to test the role of the magnesium additive,
other magnesium salts were evaluated. When MgBr2
and MgCl2 was respectively added the reaction as addi-
tive, the adduct ee dramatically decrease (entries 26‐27).
Considering Grignard reagent acitivity, n‐BuMgCl was
replaced with n‐BuMgBr, resulted in noticeable decreases
in enantioselectivity (entry 28). Having a small amount
chloride anion in reaction system might facilitate halide
metathesis in the vinyl Grignard leading to a less reactive
vinylmagnesium chloride. To verify this possibility, we
2.1.13 | (S,E)‐1‐phenylpenta‐1,4‐dien‐3‐ol
(3m)50
33% yield, 27% ee; [α]D = − 5.6 (c 0.9, CHCl3);1H NMR
20
(200 MHz, CDCl3): δ 7.41 to 7.24 (m, 5H), 6.66 to 6.58 (m,
1H), 6.29 to 6.18 (m, 1H), 6.07 to 5.90 (m, 1H), 5.38 to 5.17
(m, 1H), 4.82 to 4.80 (m, 1H); enantiometric excess was
determined by HPLC with a Chiralpak AS‐H column
1.0 mL/min, (2‐propanol: hexane = 3:97), minor enantio-
mer tr = 12.6 minutes, major enantiomer tr = 14.5 minutes.

WANG ET AL.
5
TABLE 1 Optimization of reaction conditionsa, e
Entry
1
Ligand (Mol%)
L1 (15)
L2 (15)
L3 (15)
L4 (15)
L5 (15)
L6 (15)
L7 (15)
L8 (15)
L9 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (15)
L6 (20)
L6 (30)
L6 (40)
L6 (30)
L6 (30)
L6 (30)
L6 (30)
L6 (30)
L6 (30)
L6 (30)
Additive (Mol%)
‐
Solvent
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
CH2Cl2
Toluene
THF
Yield%b
47
ee%c
8
2
‐
48
6
3
‐
64
4
4
‐
43
<1
<1
13
9
5
‐
45
6
‐
49
7
‐
47
8
‐
48
6
9
‐
45
10
18
<1
<1
<1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
n‐BuMgCl (30)
Et2AlCl (30)
Al (me)3 (30)
ZnEt2 (30)
Ti (Oi‐Pr)4 (30)
Al (Oi‐Pr)3 (30)
n‐BuMgCl (30)
n‐BuMgCl (30)
n‐BuMgCl (30)
n‐BuMgCl (40)
n‐BuMgCl (60)
n‐BuMgCl (80)
n‐BuMgCl (48)
n‐BuMgCl (42)
n‐BuMgCl (36)
n‐BuMgCl (30)
MgBr2 (36)
MgCl2 (36)
n‐BuMgBr (36)
48
39
53
47
d
d
‐
‐
49
43
45
47
<1
22
28
28
45
50
48
55
58
60
58
14
16
15
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
MTBE
d
‐
d
‐
d
‐
d
‐
d
‐
d
‐
d
‐
45
46
61
aCondition: benzaldehyde (0.5 mmol), vinylmagnesium bromide (1.0 mmol), solvent (5 mL), BDMAEE (1.0 mmol), −20 to 0°C.
bIsolated yield.
cDetermined by chiral HPLC.
dNot determined.
eThe complexing agent was optimized, and see supporting information for the result.

6
WANG ET AL.
low eantioselectivity of 34% as well as low 27% of yield
(entry 12). The unsaturated aldehyde, ie, cinnamaldehyde,
obtained relatively yield and enantioselectivitie (entry 13).
Finally, the aliphatic aldehyde afforded yield of 35% and
enantioselectivity of 40% (entry 14).
SCHEME 3 The asymmetric vinylation of benzaldehyde with
vinylmagnesium chloride
4 | CONCLUSION
used vinylmagnesium chloride as starting material, but
enantioselectivity was not elevated, which was dropped
to 44% (Scheme 3). Therefore, halide metathesis is not
the main reason for enantioselectivity.
In summary, a new catalytic direct enantioselective
vinylation of aldehydes with vinyl Grignard reagent for
preparing chiral allylic alcohols was demonstrated.
Besides using BDMAEE as effective deactivating reagent,
n‐BuMgCl was found to be an indispensable additive in
improving the enantioselectivity of the reaction. MTBE
was the ideal solvent and (S)‐3,3′‐dimethyl‐BINOL was
the optimal ligand. The highest enantioselectivity is up
to 63%, and to the best our knowledge, this is the highest
enantioselectivity in the catalytic direct asymmetric addi-
tion of vinyl Grignard reagents to aldehydes. And this
work is the first case to systematically observe the cata-
lytic direct enantioselective vinylation of aldehydes with
a vinyl Grignard reagent. This protocol does not need to
transform the vinyl Grignard reagent into other less reac-
tive organometal reagent. Therefore, this work demon-
strates a cost‐effective and operationally convenient
method for the synthesis of chiral allylic alcohols.
With the optimized reaction conditions, the scope of
aldehydes for the Grignard reaction was examined. The
results were collected into Table 2. The results show that
various aldehydes are well suitable to this process. The
electron‐withdrawing and electron‐donating groups in
the benzene ring do not have remarkable effect on
enantioselectivity of the reaction. Naphthaldehydes
obtained good higher than 60% yield and modest
enantioselectivity (Table 2, entries 2‐3). 2‐Chloroben-
zaldehyde obtained the highest 63% enantioselectivity
(entry 10). To the best of our knowledge, this is the highest
enantioselectivity to date in the catalytic direct enantiose-
lective addition of vinyl Grignard reagent. Heterocyclic
aromatic aldehyde was also investigated, and it achieved
TABLE 2 Catalytic vinylation of aldehydesa
ACKNOWLEDGMENTS
The authors gratefully acknowledge the financial support of
The Higher Education Scientific Research Project of
Ningxia (NGY2018‐92), The Project of Ningxia Medical Uni-
versity (XT2017016), and The Ningxia High School first‐class
Disciplines (West China first‐class Disciplines Basic Medical
Sciences at Ningxia Medical University) (NXYLXK2017B07).
Entry
1
R
Allylic alcohol
Yield%b
47
ee%c
61
57
35
42
48
42
46
30
47
63
47
34
27
40
Ph
3a
3b
3c
3d
3e
3f
2
1‐naphthyl
2‐naphthyl
4‐cl‐C6H4
4‐CF3‐C6H4
4‐me‐C6H4
3‐me‐C6H4
2‐me‐C6H4
2‐CF3‐C6H4
2‐cl‐C6H4
2‐Br‐C6H4
3‐thiophene
(E)‐PhCH=CH
PhCH2CH2
68
3
66
4
49
5
41
ORCID
6
43
Pei Wang https://orcid.org/0000-0002-4177-9167
Chao‐Shan Da https://orcid.org/0000-0003-1306-4348
7
3g
3h
3i
45
8
46
9
43
REFERENCE
10
11
12
13
14
3j
57
1. Wakefield BJ (Ed). Organomagnesium Methods in Organic Syn-
thesis. Academic Press: San Diego. CA; 1995.
3k
3l
51
27
2. Franzén RG. Utilization of Grignard reagents in solid‐phase synthe-
sis: a review of the literature. Tetrahedron. 2000;56(5):685‐691.
3m
3n
33
35
3. Richey HG (Ed). New Developments: Grignard Reagents. Chich-
aCondition: aldehyde (0.5 mmol), vinylmagnesium bromide (1.0 mmol), L6
(0.15 mmol), MTBE (5 mL), n‐BuMgCl (0.18 mmol), BDMAEE (1.0 mmol),
−20 to 0°C for 5 hours.
bIsolated yield.
cDetermined by chiral HPLC.
ester, UK: Wiley; 2000.
4. Seebach D, Behrendt L, Felix D. Titanate‐catalyzed enantioselective
addition of dialkylzinc compounds‐generated in situ from Grignard
reagents in ether‐to aldehydes. Angew Chem Int Ed Engl.
1991;30(8):1008‐1009.

WANG ET AL.
7
5. von dem Bussche‐Hüennefeld JL, Seebach D. Enantioselective
preparation of sec. Alcohols from aldehydes and dialkyl zinc
compounds, generated in situ from Grignard reagents, using
substoichiometric amounts of TADDOL‐titanates. Tetrahedron.
1992;48(27):5719‐5730.
20. Fernandez‐Mateos E, Maciá B, Yus M. Catalytic enantioselective
addition of alkyl Grignard reagents to aliphatic aldehydes. Adv
Synth Catal. 2013;355(7):1249‐1254.
21. Da CS, Wang JR, Yin XG, Fan XY, Liu Y, Yu SL. Highly catalytic
asymmetric addition of deactivated alkyl Grignard reagents to
aldehydes. Org Lett. 2009;11(24):5578‐5581.
6. Kim JG, Walsh PJ. From aryl bromides to enantioenriched ben-
zylic alcohols in a single flask: catalytic asymmetricarylation of
aldehydes. Angew Chem Int Ed. 2006;45:4175‐4178. Angew.
Chem. 2006; 118: 4281–4284
22. Liu Y, Da CS, Yu SL, et al. Catalytic highly enantioselective
alkylation of aldehydes with deactivated Grignard reagents and
synthesis of bioactive intermediate secondary arylpropanols.
J Org Chem. 2010;75(20):6869‐6878.
7. Côté A, Charette AB. General method for the expedient synthe-
sis of salt‐free diorganozinc reagents using zinc methoxide. J Am
Chem Soc. 2008;130(9):2771‐2773.
23. Liu XY, Wu X, Chai Z, Wu YY, Zhao G, Zhu SZ. Highly effective
and recyclable dendritic ligands for the enantioselective aryl trans-
fer reactions to aldehydes. J Org Chem. 2005;70(18):7432‐7435.
8. Soai K, Kawase Y, Oshio A. Enantioselective phenylation of
prochiral aldehydes using
complex between Grignard‐zinc halide reagent and N,N‐
dibutylnorephedrine. J Chem Soc, Perkin Trans. 1991;1:1613‐1615.
a
kinetically formed chiral
24. Fan XY, Yang YX, Zhuo FF, et al. Highly enantioselective addi-
tion of in situ prepared arylzinc to aldehydes catalyzed by a
series of atropisomeric binaphthyl‐derived amino alcohols.
Chem A Eur J. 2010;16(27):7988‐7991.
9. Hatano M, Mizuno T, Ishihara K. Catalytic enantioselective syn-
thesis of sterically demanding alcohols using di(2°‐alkyl) zinc
prepared by the refined Charette's method. Chem Commun.
2010;46(30):5443‐5445.
25. Zhang L, Sun L, Li YY, et al. Catalytic asymmetric arylation of
enals to enantioenriched linear trisubstituted allylic secondary
alcohols by using aryl lithiums generated in situ from aryl bro-
mides. ChemCatChem. 2013;5(12):3516‐3519.
10. Hatano M, Mizuno T, Ishihara K. A concise synthesis of (S)‐(+)‐
Ginnol based on catalytic enantioselective addition of commer-
cially unavailable di(n‐alkyl)zinc to aldehydes and ketones.
Synlett. 2010;13:2024‐2028.
26. Yang YX, Liu Y, Zhang L, et al. Aryl bromides as inexpensive
starting materials in the catalytic enantioselective arylation of
aryl aldehydes: the additive TMEDA enhances the
enantioselectivity. J Org Chem. 2014;79(21):10696‐10702.
11. Luderer MR, Bailey WF, Luderer MR, Fair JD, Dancer RJ,
Sommer MB. Asymmetric addition of achiral organomagnesium
reagents or organolithiums to achiral aldehydes or ketones: a
review. Tetrahedron: Asymmetry. 2009;20(9):981‐998.
27. Wang P, Liu Y, Zhang YL, Da CS. The inexpensive additive N‐
methylmorpholine effectively decreases the equivalents of
nucleophiles in the catalytic highly enantioselective arylation
of aryl aldehydes. Chirality. 2017;29(8):443‐450.
12. Harada T. Development of highly active chiral titanium catalysts
for the enantioselective addition of various organometallic
reagents to aldehydes. Chem Rec. 2016;16(3):1256‐1273.
28. Noyori R, Suga S, Kawai K, Okada S, Kitamura M.
Enantioselective alkylation of carbonyl compounds. From stoi-
chiometric to catalytic asymmetric induction. Pure Appl Chem.
1988;60:1597‐1606.
13. Collados JF, Solà R, Harutyunyan SR, Maciá B. Catalytic synthesis
of enantiopure chiral alcohols via addition of Grignard reagents to
carbonyl compounds. ACS Catal. 2016;6(3):1952‐1970.
29. Radin NS, Muramatsu Y, Harada T. Sphingolipids as coenzymes
in anion transfer and tumor death. Bioorg Med Chem.
2004;12(23):6029‐6037.
14. Muramatsu Y, Harada T. Catalytic asymmetric alkylation of
aldehydes with Grignard reagents. Angew Chem Int Ed.
2008;47:1088‐1090. Angew. Chem. 2008; 120: 1104–1106
30. Liang Y, Jiang X, Yu ZX. Enantioselective total synthesis of (+)‐
asteriscanolideviaRh(I)‐catalyzed [(5+2)+1] reaction. Chem
Commun. 2011;47(23):6659‐6661.
15. Muramatsu Y, Harada T. Catalytic asymmetric aryl transfer
reactions to aldehydes with Grignard reagents as the aryl source.
Chem A Eur J. 2008;14(34):10560‐10563.
31. Sreedhar E, Venkanna A, Chandramouli N, Babu KS, Rao JM.
The first total synthesis of topsentolide B3. Eur J Org Chem.
2011;2011(6):1078‐1083.
16. Muramatsu Y, Kanehira S, Tanigawa M, Miyawaki Y, Harada T.
Catalytic enantioselective alkylation and arylation of aldehydes by
using Grignard reagents. Bull Chem Soc Jpn. 2010;83(1):19‐32.
32. Fujii K, Maki K, Kanai M, Shibasaki M. Formal catalytic asym-
metric total synthesis of Fostriecin. Org Lett. 2003;5(5):733‐736.
17. Gao G, Bai XF, Yang HM, Jiang JX, Lai GQ, Xu LW. Ar‐
BINMOLs with axial and sp3 central chirality‐characterization,
chiroptical properties, and application in asymmetric catalysis.
Eur J Org Chem. 2011;2011(26):5039‐5046.
33. Legigan T, Clarhaut J, Renoux B, et al. Synthesis and antitumor
efficacy of
a β‐Glucuronidase‐responsive albumin‐binding
prodrug of doxorubicin. J Med Chem. 2012;55(9):4516‐4520.
18. Zheng LS, Jiang KZ, Deng Y, et al. Synthesis of Ar‐BINMOL
ligands by [1,2]‐Wittig rearrangement to probe their catalytic
activity in 1,2‐addition reactions of aldehydes with Grignard
reagents. Eur J Org Chem. 2013;2013(4):748‐755.
34. Lumbroso A, Cooke ML, Breit B. Catalytic asymmetric synthesis
of allylic alcohols and derivatives and their applications in
organic synthesis. Angew Chem Int Ed. 2013;52:1890‐1932.
Angew. Chem. 2013; 125: 1942‐1986
19. Fernandez‐Mateos E, Maciá B, Ramon DJ, Yus M. Catalytic
enantioselective addition of MeMgBr and other Grignard reagents
to aldehydes. Eur J Org Chem. 2011;2011(34):6851‐6855.
35. Tian GQ, Kaiser T, Yang J. Diastereoselective synthesis of syn‐
1,3‐diols by titanium‐mediated reductive coupling of propargylic
alcohols. Org Lett. 2010;12(2):288‐290.

8
WANG ET AL.
36. Adam W, Nestler B. Photooxygenation of chiral allylic alcohols:
hydroxy‐directed regio‐ and diastereoselective ene reaction of
singlet oxygen. J Am Chem Soc. 1992;114(16):6549‐6550.
52. Aikawa K, Hioki Y, Mikami K. Highly enantioselective
alkenylation of glyoxylate with vinylsilane catalyzed by chiral
dicationic palladium (II) complexes.
J Am Chem Soc.
2009;131(39):13922‐13923.
37. Nicolaou KC, Sun YP, Korman H, Sarlah D. Asymmetric total syn-
thesis of cylindrocyclophanes A and F through cyclodimerization
53. Tomita D, Kanai M, Shibasaki M. Nucleophilic activation of
alkenyl and aryl boronates by a chiral cu(I) F complex: catalytic
enantioselective alkenylation and arylation of aldehydes. Chem
Asian J. 2006;1(1‐2):161‐166.
and
a Ramberg‐Bäcklund reaction. Angew Chem Int Ed.
2010;49:5875‐5878. Angew. Chem. 2010; 122: 6011–6014
38. Donohoe TJ, Callens CKA, Lacy AR, Winter C. Tethered
aminohydroxylation reaction and its application to Total synthe-
sis. Eur J Org Chem. 2012;2012(4):655‐663.
54. Shintani R, Inoue M, Hayashi T. Rhodium‐catalyzed asymmet-
ric addition of aryl‐ and alkenylboronic acids to isatins. Angew
Chem Int Ed. 2006;45:3353‐3356. Angew. Chem. 2006; 118:
3431–3434
39. Berenguer R, Cavero M, Garcia J, MuCoz M. Enantioselective
synthesis of α‐hydroxy thioesters via oxazaborolidine‐mediated
reduction of α‐phenylthio enones. Tetrahedron Lett.
1998;39(15):2183‐2186.
55. Shono T, Harada T. Catalytic enantioselective synthesis of sec-
ondary allylic alcohols from terminal alkynes and aldehydes
via 1‐Alkenylboron reagents. Org Lett. 2010;12(22):5270‐5273.
40. Breit B, Demel P, Grauer D, Studte C. Stereospecific and
stereodivergent construction of tertiary and quaternary carbon
centers through switchable directed/nondirected allylic substitu-
tion. Chem Asian J. 2006;1(4):586‐597.
56. Sato I, Asakura N, Iwashita T. A highly enantioselective synthe-
sis of chiral allylic alcohols by asymmetric addition of novel
mixed reagents of trialkenylbismuthines/dialkylzincs to alde-
hydes. Tetrahedron: Asymmetry. 2007;18(22):2638‐2642.
41. Martin VS, Woodard SS, Katsuki T, Yamada Y, Ikeda M, Sharp-
less KB. Kinetic resolution of racemic allylic alcohols by
enantioselective epoxidation. A route to substances of absolute
enantiomeric purity? J Am Chem Soc. 1981;103(20):6237‐6240.
57. Biradar DB, Gau HM. Highly enantioselective vinyl additions of
vinylaluminum to ketones catalyzed by a titanium (IV) catalyst
of (S)‐BINOL. Org Lett. 2009;11(3):499‐502.
42. Burgess K, Jennings LD. Enantioselective esterifications of
unsaturated alcohols mediated by a lipase prepared from Pseu-
domonas sp. J Am Chem Soc. 1991;113(16):6129‐6139.
58. Kanbayashi N, Onitsuka K. Ruthenium‐catalyzed regio‐ and
enantioselective allylic substitution with water: direct synthesis
of chiral allylic alcohols. Angew Chem Int Ed.
2011;50:5197‐5199. Angew. Chem. 2011; 123: 5303–5305
43. Ruble JC, Latham HA, Fu GC. Effective kinetic resolution of
secondary alcohols with
4‐(Dimethylamino)pyridine. Use of the Fe(C5Ph5) group in
asymmetric catalysis. J Am Chem Soc. 1997;119(6):1492‐1493.
a
planar−chiral analogue of
59. Lyothier I, Defieber C, Carreira EM. Iridium‐catalyzed
enantioselective synthesis of allylic alcohols: silanolates as
hydroxide equivalents. Angew Chem Int Ed. 2006;45:6204‐6207.
Angew. Chem. 2006; 118: 6350–6353
44. Vedejs E, MacKay JA. Kinetic resolution of allylic alcohols using
a chiral phosphine catalyst. Org Lett. 2001;3(4):535‐536.
60. Gärtner M, Mader S, Seehafer K, Helmchen G. Enantio‐ and
regioselective iridium‐catalyzed allylic hydroxylation. J Am
Chem Soc. 2011;133(7):2072‐2075.
45. Oppolzer W, Nadinov RN. Enantioselective synthesis of sec‐
allylalcohols by catalytic asymmetric addition of divinylzinc to
aldehydes. Tetrahedron Lett. 1988;29(44):5645‐5648.
61. Bouziane A, Hélou M, Carboni B, et al. Ruthenium‐catalyzed
synthesis of allylic alcohols: boronic acid as a hydroxide source.
Chem A Eur J. 2008;14(18):5630‐5637.
46. Soai K, Takahashi K. Asymmetric alkenylation of chiral and
prochiral aldehydes catalysed by chiral or achiral amino alco-
hols: catalytic diastereoselective synthesis of protected erythro‐
sphingosine and enantioselective synthesis of chiral diallyl alco-
hols. J Chem Soc, Perkin Trans. 1994;1:1257‐1258.
62. Miyabe H, Matsumura A, Yoshida K, Takemoto Y. Synthesis of
chiral oxime ethers based on regio‐ and enantioselective allylic
substitution catalyzed by iridium–pybox complex. Tetrahedron.
2009;65(23):4464‐4470.
47. Shibata T, Nakatsui K, Soai K. Highly enantioselective catalytic
isopropenylation of aldehydes using diisopropenylzinc. Inorg
Chim Acta. 1999;296(1):33‐36.
SUPPORTING INFORMATION
48. Lurain AE, Maestri A, Kelly AR, Carroll PJ, Walsh PJ. Highly
enantio‐ and diastereoselective one‐pot synthesis of acyclic
epoxy alcohols with three contiguous Stereocenters. J Am Chem
Soc. 2004;126(42):13608‐13609.
Additional supporting information may be found online
in the Supporting Information section at the end of the
article.
49. Li H, Walsh PJ. Catalytic asymmetric vinylation and dienylation
of ketones. J Am Chem Soc. 2005;127(23):8355‐8361.
50. Tomita D, Wada R, Kanai M, Shibasaki M. Enantioselective
alkenylation and phenylation catalyzed by a chiral CuF com-
plex. J Am Chem Soc. 2005;127(12):4138‐4139.
How to cite this article: Wang P, Ma G‐R, Yu S‐L,
Da C‐S. Enantioselective vinylation of aldehydes
with the vinyl Grignard reagent catalyzed by
magnesium complex of chiral BINOLs. Chirality.
2018;1–8. https://doi.org/10.1002/chir.23038
51. Evans DA, Aye Y. Enantioselective scandium‐catalyzed
vinylsilane additions: a new approach to the synthesis of
enantiopure β,γ‐unsaturated α‐Hydroxy acid derivatives. J Am
Chem Soc. 2006;128(34):11034‐11035.
