Synthesis of New Azo Compounds Based on N-(4-
Hydroxypheneyl)maleimide and N-(4-Methylpheneyl)maleimide
Issam Ahmed Mohammed * and Asniza Mustapha
School of Industrial Technology, Universiti Sains Malaysia, 11800 Penang, Malaysia
 Author to whom correspondence should be addressed; E-Mail: issam@usm.my; Tel.: +604-6533888;
Fax: +604-6573678.
Received: 1 October 2010; in revised form: 14 October 2010 / Accepted: 18 October 2010 /
Published: 25 October 2010
Abstract: Maleic anhydride was reacted with p-aminophenol and p-toluidine in the presence
of di-phosphorus pentoxide (P2O5) as a catalyst to produce two compounds: N-(4-hydroxy-
phenyl)maleimide (I) and N-(4-methylphenyl)maleimide (II). The new azo compounds I(a-c)
and II(a-c) were prepared by the reaction of I and II with three different aromatic amines,
namely aniline, p-aminophenol and p-toluidine. The structures of these compounds were
confirmed by CHN, FT-IR, 1H-NMR, 13C-NMR, mass spectrum and UV/Vis spectroscopy.
Keywords: synthesis; azo compounds; aromatic amines; N-(4-hydroxylpheneyl)maleimide
1. Introduction
Small molecules and macromolecules containing imide groups exhibit great electrical properties, good
solubility in polar media, resistance to hydrolysis and high thermal stability [1-8]. Due to their excellent
properties many efforts have been made to produce different compounds containing imide groups
consisting of two carbonyl groups bound to nitrogen. The most common unsubstituted cyclic imides were
prepared by heating dicarboxylic acids or their anhydrides with reactants including ammonia, urea,
formamide lithium nitride or primary amines [9-12], but the reaction needs to be carried out at high
temperatures for efficient ring closure. Recently, attempts at preparing imide compounds either by the

Molecules 2010, 15
7499
conventional technique or via the microwave irradiation using various catalysts such as Lewis acids,
hexamethyldisilazane, carbonyldiimidazole, 4-N,N-dimethylaminopyridine, ammonium chloride,
hydroxylamine hydrochloride and sodium acetate to minimize the temperature and time of the reaction
have been published [13-18]. In this study, the conventional technique was used to synthesize two imides
by the reaction of maleic anhydride with p-aminophenol and p-toluidine, respectively, in the presence of
diphosphorus pentoxide (P2O5) as a catalyst, which decreased the temperature needed for ring closure
from 150–300 °C to 20–70 °C.
2. Results and Discussion
2.1. Synthesis and characterization
The preparation of compounds I, II, I(a-c) and II(a-c) is shown in Scheme 1. The structure of these
compounds was confirmed by elemental analysis (CHN), FT-IR, 1H-NMR, 13C-NMR, mass spectrum and
UV/Vis spectroscopy.
Scheme 1. Synthesis of N-(4-hydroxypheneyl)maleimide (I), N-(4-methylpheneyl)maleimide
(II), I(a-c) and II(a-c).

Molecules 2010, 15
7500
Scheme 1. Cont.
The FT-IR spectra of compounds I and II showed the presence of C=O absorbances at 1,702 cm−1,
alkene group (HC=CH) ones at 3,119 cm−1 and the presence of aromatic rings indicated by bands at 1,589,
1,600 and 1,512 cm−1. In addition a hydroxyl group at 3,481 cm−1 and a methyl group at 1,316 cm−1 were
seen for compounds I and II, respectively.
Figure 1. FT-IR spectrum of compound Ia.

Molecules 2010, 15
7501
All these peaks clearly proved that compounds I and II were produced. The FT-IR data for compounds
I(a-c) and II(a-c) showed the same characteristic bands of the coupling agents I and II, namely imide,
methyl, hydroxyl group, alkene, and p-substituted band while the presence of the azo (N=N) group band
in 1,630–1,575 cm−1 range confirmed the success of the synthesis. Besides, the o-substituted benzene ring
absorbtion at 750–775 cm−1 proved that the azo group was attached to the ortho position of the benzene
rings. The FT-IR spectrum of compound Ia as a typical example is shown in Figure 1.
The 1H-NMR and 13C-NMR for azo compounds I and Ia have been chosen as typical examples and the
corresponding spectra are shown in Figures 2 and 3, respectively. In the 1H-NMR spectrum, the protons of
the alkene group (HC=CH) and the protons of aromatic ring appeared at 6.62–6.52 ppm and 6.75–7.39 ppm,
respectively. The new peak appeared at 6.93 ppm was assigned to the ortho position and that proved the
reaction between compound I and aniline has occurred. The broad peak at 9.45–9.75 ppm was assigned to
the free O-H proton.
13
In the C-NMR spectrum, the following signals are the characteristic of the structure; 167.43 ppm
(C=O), 155.44 ppm (C-O, aromatic), 134.87 ppm (HC=CH, alkene) and 122.56, 115.42 ppm (C=C,
aromatic).
Figure 2. 1H-NMR spectra of (A) compound I and (B) compound Ia in CD3OD.

Molecules 2010, 15
7502
Figure 2. Cont.
Figure 3. 13C-NMR spectra of (A) compound I and (B) compound Ia in CD3OD.

Molecules 2010, 15
7503
Figure 3. Cont.
The addition of other aromatic carbons proved that the pure azo compound Ia has been successfully
prepared. The mass spectrum (70 eV) of Ia (Figure 4) shows the presence of molecular ion peak as the
base peak at m/z 279 (100). The major fragmentation of molecular ion occurs through the loss of
phenyldiazonium at m/z 189 (58.0). On further fragmentation it gives peaks at m/z 172 (42.56), 161
(32.5), 133 (12.05), 132 (12.0), 116 (27.0), 107 (11.05), 105 (8.7), 94 (10.59), 93 (17.82), 90 (18.0), 77
(31.04).
Figure 4. Mass spectrum of compound Ia.

Molecules 2010, 15
7504
In the UV/Visible spectra, the azo group (N=N) usually gives an absorption in the 350–370 nm range
[19]. We expected compounds I(a-c) would exhibited higher λmax than compounds II(a-c) due to the
presence of an auxochrome group such as hydroxyl group in the compounds [20]. However, the results
showed the opposite, whereby they gave a lower absorption wavelength, which is in the range of
320–330 nm. This might be attributed to the tautomerism due to the polar or proton donor solvents, which
can stabilize the carbonyl group by dipolar association or hydrogen bonding and thus decrease the
magnitude of the enolization. As the result, the keto group will give a shorter wavelength [21]. The
appearance of a new peak at 164 cm−1 in the 13C-NMR spectrum (Figure 3) suggests that this phenomenon
could have indeed occurred. The UV/Vis data for the azo compounds I(a-c) and II(a-c) are given in the
Experimental section.
3. Experimental
3.1. Materials
Maleic anhydride (R&M Chemicals, UK), p-aminophenol (Sigma-Aldrich, UK), aniline (Fisher
Chemicals, UK), p-toluidine (Fluka, Germany), sulfuric acid 98% (Mallinckrodt, Mexico), hydrochloric
acid 37% (Fisher Chemicals, UK), sodium hydroxide (R&M Chemicals, UK), N,N-dimethylformamide
(Systerm®, Malaysia), diphosphorus pentoxide (Scharlau Chemie, Spain), sodium nitrite (Ajax
Chemicals, Australia), 2-propanol (R&M Chemicals, UK) and glacial acetic acid (Fisher Chemicals, UK).
All the chemicals were used as received without further purification except for aniline, was distilled
before use.
3.2. Instrumentation
FT-IR spectra were measured at room temperature using a Perkin-Elmer 2000 FT-IR equipped with a
1
high-purity dried potassium bromide (KBr) beam splitter. The H-NMR and 13C-NMR spectra were
obtained using a Bruker 400 MHz NMR spectrophotometer with tetramethylsilane (TMS) as the internal
reference. CHN microanalyses were performed using Perkin Elmer 2400 Series II Combustion Analyzer.
The MS were recorded on a Perkin Elmer Clarus 500 Gas Chromatography-Mass Spectrometry system
(GC-MS). UV/Vis Spectroscopy were determined using a Shimadzu UV-1601 PC instrument. The entire
sample was weighed and dissolved in methanol.
3.3. Synthesis of N-(4-hydroxyphenyl)maleimide (I)
P-aminophenol (16.37 g, 0.15 mol) and maleic anhydride (14.71 g, 0.15 mol) were dissolved separately
in DMF (50 mL) to yield solutions A and B, respectively. Solution B was added dropwise into solution A
to give solution C. Solution C was stirred for 2 hours at 20 °C in a water bath. P2O5 (12 g) was dissolved
in H2SO4 (10 mL) and DMF (70 mL). This mixture was added dropwise into solution C and was stirred
for 2 hours at 70 °C. The mixture was kept chilled in the ice bath and poured into cold water. A precipitate
formed that was filtered, washed with distilled water and finally recrystallized from 2-propanol and dried

Molecules 2010, 15
7505
in a vacuum oven at 65 °C for 24 hours. Yield was 84%; m.p. 182–184 °C; color: yellow; FT-IR (KBr
disc): 3,481 cm−1 (O-H), 3,108 cm−1 (HC=HC), 1,705 cm−1 (C=O), 1,601 cm−1 (aromatic ring) and
1
828 cm−1 (HC=CH of maleimide); H-NMR (CD3OD): 6.78–7.48 (aromatic), 6.90–7.15 (HC=CH of
13
maleimide), 6.31–6.58 (HC=CH) ppm; C-NMR (CD3OD): 170.79 (C=O), 157.44, 134.37 (HC=CH of
maleimide), 128.23, 112.00 (C=C, aromatic) ppm.
3.4. Synthesis of N-(4-methylphenyl)maleimide (II)
Compound II was prepared by following the procedure of the preparation of I except that p-toluidine
was substituted for p-aminophenol. Yield was 50% with a melting point of 148–150 °C; color: yellow;
FT-IR (KBr disc): 3,088 cm−1 (HC=CH), 1,708 cm−1 (C=O), 1,632 cm−1 (aromatic ring), 1,316 cm−1 (CH3)
1
and 823 cm−1 (p-substituted Ar); H-NMR (CD3OD): 7.17–7.57 (aromatic), 6.98–7.21 (HC=CH of
13
maleimide), 6.32–6.55 (HC=CH), 2.35 (CH3) ppm; C-NMR (CD3OD): 164.99 (C=O), 134.48 (HC=CH
of maleimide), 128.11, 126.36, 125.81, 120.71 (C=C, aromatic), 19.96 (CH3) ppm.
3.5. General procedure for preparation of the heterocyclic azo compounds I(a-c) and II(a-c)
Solution A was prepared by mixing pure aniline (a, 0.93 g, 0.01 mol) with concentrated HCl (3 mL)
and water (3 mL) and cooling at 5 °C in an ice bath. NaNO2 (0.69 g, 0.01 mol) was dissolved in water
(10 mL) at 5 °C to obtain solution B. Then solution A was added dropwise to solution B at 5 °C with
stirring. The mixture was then slowly added into the solution of compound I (1.89 g, 0.01 mol), which
was dissolved in 10% NaOH (20 mL) at 5 °C. The mixture was keep chilled in the ice bath and stirred
continuously for 10 min. The precipitate formed was filtered and recrystallized from glacial acetic acid,
and washed with methanol and finally dried in a vacuum oven at 65 °C for 24 hours. The procedure was
repeated by substituted I with II, where was substituted by p-aminophenol (b) and p-toluidine (c).
Phenylazo-3-N-(4-hydroxyphenyl)maleimide (Ia). Color: pale yellow; yield: 85%; melting point:
199–200 °C; FT-IR (KBr disc): 3,290 cm−1 (O-H), 3,116 cm−1 (HC=CH), 1,703 cm−1 (C=O), 1,618 cm−1
1
(aromatic ring), 1,547 cm−1 (N=N), 836 cm−1 and 770 cm−1; H-NMR (CD3OD): 7.20–7.43 (aromatic),
6.93–7.25 (HC=CH of maleimide), 6.26–6.52 (HC=CH) ppm; 13C-NMR (CD3OD): 167.43 (C=O), 165.01
(C=O), 155.44, 134.87 (HC=CH of malemide), 122.56, 115.42 (C=C, aromatic) ppm; elemental analysis:
found: C, 62.76; H, 7.65; N, 13.86, (C16H23N3O3), calc.: C, 62.92; H, 7.60; N, 13.77; UV/Vis λmax (nm):
327.00 (N=N); 302.50 (C=O); 230.00 (Ar-CN); 208.50 (Ar-OH).
4-Hydroxyphenylazo-3-N-(4-hydroxyphenyl)maleimide (Ib). Color: yellow; yield: 81%; melting point:
210–212 °C; FT-IR (KBr disc): 3,302 cm−1 (O-H), 3,166 cm−1 (HC=CH), 1,701 cm−1 (C=O), 1,618 cm−1
(aromatic ring) and 1,580 cm−1 (N=N), 835 cm−1 and 716 cm−1; 1H-NMR (CD3OD): 7.17–7.57 (aromatic),
6.96–7.21 (HC=CH of maleimide), 6.30–6.51 (HC=CH) ppm; 13C-NMR (CD3OD): 170.95 (C=O),
155.71, 155.36, 134.77 (HC=CH of maleimide), 129.93, 122.84, 112.00 (C=C, aromatic) ppm; elemental
analysis: found: C, 60.12; H, 6.98; N, 13.10, (C16H23N3O4), calc.: C, 60.01; H, 6.93; N, 13.17; UV/Vis
λ
max (nm): 326.50 (N=N); 302.50 (C=O); 230.50 (Ar-CN); 210.00 (Ar-OH).

Molecules 2010, 15
7506
4-Methylphenylazo-3-N-(4-hydroxyphenyl)maleimide (Ic). Color: yellow; yield: 80%; melting point:
203–204 °C; FT-IR (KBr disc): 3,302 cm−1 (O-H), 3,202 cm−1 (HC=CH), 1,703 cm−1 (C=O), 1,618 cm−1
1
(aromatic ring), 1,511 cm−1 (N=N), 835 cm−1 and 719 cm−1; H-NMR (CD3OD): 7.17–7.52 (aromatic),
13
6.90–7.20 (HC=CH of maleimide), 6.29–6.53 (HC=CH), 2.35 (CH3) ppm; C-NMR (CD3OD): 170.11
(C=O), 155.20, 134.48 (HC=CH of maleimide), 133.66, 129.74, 127.00, 125.00, 122.76, 112.00 (C=C,
aromatic), 20.01 (CH3) ppm; elemental analysis: found: C, 64.09; H, 7.84; N, 13.18, (C17H25N3O3), calc.:
C, 63.91; H, 7.89; N, 13.16; UV/Vis λmax (nm): 330.00 (N=N); 302.50 (C=O); 231.50 (Ar-CN); 210.00
(Ar-CH3).
Phenylazo-3-N-(4-methylphenyl)maleimide (IIa). Color: yellow; yield: 82%; melting point: 185–186 °C;
FT-IR (KBr disc): 3,092 cm−1 (HC=CH), 1,703 cm−1 (C=O), 1,630 cm−1 (aromatic ring), 1,540 cm−1
(N=N), 758 cm−1 and 1,314 cm−1 (CH3); 1H-NMR (CD3OD): 7.17–7.53 (aromatic), 6.96–7.19 (HC=CH of
13
maleimide), 6.32–6.59 (HC=CH), 2.35 (CH3) ppm; C-NMR (CD3OD): 164.99 (C=O), 134.75 (HC=CH
of maleimide), 135.29, 133.55, 129.43, 128.11, 126.36, 125.81, 120.71 (C=C, aromatic), 19.96 (CH3)
ppm; elemental analysis: found: C, 67.46; H, 8.14; N, 13.91, (C17H25N3O2), calc.: C, 67.28; H, 8.31; N,
13.86; UV/Vis λmax (nm): 340.50 (N=N); 225.50 (Ar-CN); 205.50 (phenyl).
4-Hydroxyphenylazo-3-N-(4-methylphenyl)maleimide (IIb). Color: yellow; yield: 83%; melting point:
190–191 °C; FT-IR (KBr disc): 3,210 cm−1 (O-H), 3,093 cm−1 (HC=CH), 1,703 cm−1 (C=O), 1,630 cm−1
1
(aromatic ring), 1,541 cm−1 (N=N), 758 cm−1 and 1,312 cm−1 (CH3); H-NMR (CD3OD): 7.19–7.57
13
(aromatic), 6.95–7.20 (HC=CH of maleimide), 6.32–6.48 (HC=CH), 2.35 and 2.40 (CH3) ppm; C-NMR
(CD3OD): 167.12 (C=O), 155.68, 143.19, 136.46, 136.01, 134.78 (HC=CH of maleimide), 129.11,
128.26, 127.43, 112.01 (C=C, aromatic), 19.93 (CH3) ppm; elemental analysis: found: C, 63.83; H, 7.89;
N, 13.12, (C17H25N3O3), calc.: C, 63.91; H, 7.89; N, 13.16; UV/Vis λmax (nm): 366.50 (N=N); 225.50 (Ar-
CN); 207.00 (Ar-OH).
4-Methylphenylazo-3-N-(4-methylphenyl)maleimide (IIc). Color: pale yellow; yield: 85%; melting point:
186–187 °C; FT-IR (KBr disc): 3,091 cm−1 (HC=CH), 1,703 cm−1 (C=O), 1,630 cm−1 (aromatic ring),
1,540 cm−1 (N=N), 778 cm−1 and 1,315 cm−1 (CH3); 1H-NMR (CD3OD): 7.20–7.59 (aromatic), 6.90–7.19
(HC=CH of maleimide), 6.32–6.55 (HC=CH), 2.39 (CH3) ppm; 13C-NMR (CD3OD): 165.36 (C=O),
144.33, 134.80 (HC=CH of maleimide), 128.08, 127.11, 126.47, 112.33 (C=C, aromatic), 20.10, 20.03,
19.96 (CH3) ppm; elemental analysis: found: C, 68.01; H, 8.72; N, 13.19, (C18H27N3O2); calc.: C, 68.14;
H, 8.58; N, 13.24; UV/Vis λmax (nm): 352.00 (N=N); 225.50 (Ar-CN); 206.00 (Ar-CH3).
4. Conclusions
Six new azo compounds based on N-(4-hydroxyphenyl)maleimide and N-(4-methylphenyl)maleimide
have been successfully synthesized and characterized. The use of P2O5 as catalyst has minimized the
reaction temperature from 150–300 °C to 20–70 °C as well as giving high yields.

Molecules 2010, 15
7507
Acknowledgements
The authors would like to thank Universiti Sains Malaysia for the RU Grant 1001/PTEKIND/811017
and the Fellowship Scheme.
References
1. Bojarski, A.J.; Mokrosz, M.J.; Duszynska, B.; Bugno, R. New imide 5-HT1A receptor ligands –
modification of terminal fragment geometry. Molecules 2004, 9, 170-177.
2. Alaa, A.M.; Aziz, A. Novel and versatile methodology for synthesis of cyclic imides and evaluation
of their cytotoxic, DNA binding, apoptotic inducing activities and molecular modeling study. Eur. J.
Med. Chem. 2007, 42, 614-626.
3. Langmuir, M.E.; Yang, J.R.; Moussa, A.M.; Laura, R.; Lecompte, K.A. New naphthopyranone based
fluorescent thiol probes. Tetrahedron Lett. 1995, 36, 3989-3992.
4. Ohkubo, M.; Nishimura, T.; Jona, H.; Honma, T.; Morishima, H. Practical synthesis of
Indolopyrrolocarbazoles. Tetrahedron Lett. 1996, 52, 8099-8112.
5. Hamper, B.C.; Dukesherer, D.R.; South, M.S. Solid-phase synthesis of proline analogs via a three
component 1,3-dipolar cycloaddition. Tetrahedron Lett. 1996, 37, 3671-3674.
6. Iijima, T.; Suzuki, N.; Fukuda, W.; Tomoi, M.J. Toughening of aromatic diamine-cured epoxy resins
by modification with n-phenylmaleimide-styrene-p-hydroxystyrene terpolymers. Eur. Polym. J. 1995,
31, 775-783.
7. Bharel, R.; Choudhary, V.; Varma, I.K. Thermal and mechanical properties of copolymers of methyl
methacrylate with N-phenyl maleimide. J. Appl. Polym. Sci. 1993, 49, 31-38.
8. Walter, W.W.; Michael, H.A. Polyimides. In Ullmann's Encyclopedia of Industrial Chemistry;
Wiley-VCH: Weinheim, Germany, 2002.
9. Handley, G.J.; Nelson, E.R.; Somers, T.C. Compounds derived from β-substituted glutaric acids:
glutarimides, glutaramic acids, 1,5-pentanediols. Aust. J. Chem. 1960, 13, 127-144.
10. Polonaski, T.; Milewska, M.J.; Gdaniec, M. Synthesis, structure and chiroptical spectra of the
bicyclic α-diketones, imides and dithioimides related to santenone. Tetrahedron: Asymmetry 2000,
11, 3113-3122.
11. Gordon, A.J.; Ehrenkaufer, R.L.E. Chemistry of imides. II. Cyclic imides and some unusual products
from some diacid chlorides and lithium nitride. J. Org. Chem. 1971, 36, 44-45.
12. Wu, C.S.; Liu, Y.L.; Hsu, K.Y. Maleimide-epoxy resins: Preparation, thermal properties, and flame
retardance. Polymer 2003, 44, 565-573.
13. Reddy, P.Y.; Kondo, S.; Toru, T.; Ueno, Y. Lewis acid and hexamethyldisilazane-promoted efficient
synthesis of N-Alkyl- and N-Arylimide derivatives. J. Org. Chem. 1997, 62, 2652-2654.
14. Muller, G.W.; Konnecke, W.E.; Smith, A.M.; Khetani, V.D. A concise two-step synthesis of
thalidomide. Org. Process Res. Dev. 1999, 3, 139-140.
15. Bon, E.; Reau, R.; Bertand, G.; Bigg, D.C.H. Aluminum trichloride-promoted aminolysis of cyclic
imides and oxazolidinones. Tetrahedron Lett. 1996, 37, 1217-1220.

Molecules 2010, 15
7508
16. Benjamin, E.; Hijji, Y. The synthesis of unsubstituted cyclic imides using hydroxylamine under
microwave irradiation. Molecules 2008, 13, 157-169.
17. Jaskowska. J.; Kowalski, P. N-alkylation of imides using phase transfer catalysts under solvent-free
conditions. J. Heterocyclic Chem. 2008, 45, 1371-1375.
18. Kavitha, K.; Vangala, R.R.; Khagga, M.; Sarbani, P. Lewis acid free high speed synthesis of
nimesulide-based novel n-substituted cyclic imides. J. Braz. Chem. Soc. 2010, 21, 1060-1064.
19. Allcock, H.R.; Sarah D.; Karen M.K. Poly(organophosphazenes) with chromophores as substituent
groups. Macromolecules 1978, 11, 357-359.
20. Bruice, P.Y. Organic Chemistry, 4th ed.; Pearson Education International: Upper Saddle River, NJ,
USA, 2004.
21. Rao, C.N.R. Ultra-Violet and Visible Spectroscopy: Chemical Applications, 2nd ed.; Butterworths:
London, UK, 1967.
Sample Availability: Contact the authors.
© 2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
