Non-catalyzed addition of secondary phosphine chalcogenides to divinyl chalcogenides under solvent-free conditions

Article abstract of DOI:10.1080/17415993.2016.1191635

Secondary phosphine chalcogenides, R₂PX (R═(CH₂)₂Ph, Ph; X = S, Se), react with divinyl chalcogenides, (CH₂═CH)₂Y (Y = S, Se, Te), at the 2:1 molar ratio (80–82°C, 56–80?h) in the absence of both cata

Full text of DOI:10.1080/17415993.2016.1191635

Journal of Sulfur Chemistry
ISSN: 1741-5993 (Print) 1741-6000 (Online) Journal homepage: http://www.tandfonline.com/loi/gsrp20
Non-catalyzed addition of secondary phosphine
chalcogenides to divinyl chalcogenides under
solvent-free conditions
Nina K. Gusarova, Nataliya A. Chernysheva, Svetlana V. Yas’ko, Lyudmila V.
Klyba & Boris A. Trofimov
To cite this article: Nina K. Gusarova, Nataliya A. Chernysheva, Svetlana V. Yas’ko, Lyudmila
V. Klyba & Boris A. Trofimov (2016): Non-catalyzed addition of secondary phosphine
chalcogenides to divinyl chalcogenides under solvent-free conditions, Journal of Sulfur
Chemistry, DOI: 10.1080/17415993.2016.1191635
To link to this article: http://dx.doi.org/10.1080/17415993.2016.1191635
Published online: 13 Jun 2016.
Submit your article to this journal
Article views: 10
View related articles
View Crossmark data
Full Terms & Conditions of access and use can be found at
http://www.tandfonline.com/action/journalInformation?journalCode=gsrp20
Download by: [University of California, San Diego]
Date: 27 June 2016, At: 03:50

JOURNAL OF SULFUR CHEMISTRY, 2016
http://dx.doi.org/10.1080/17415993.2016.1191635
Non-catalyzed addition of secondary phosphine
chalcogenides to divinyl chalcogenides under solvent-free
conditions
Nina K. Gusarovaa, Nataliya A. Chernyshevaa, Svetlana V. Yas’kob, Lyudmila V. Klybaa
and Boris A. Trofimova
aA. E. Favorsky Irkutsk Institute of Chemistry, Siberian Branch of the Russian Academy of Sciences, Irkutsk,
Russian Federation; bIrkutsk State Transport University, Irkutsk, Russian Federation
ABSTRACT
ARTICLE HISTORY
Received 8 March 2016
Accepted 16 May 2016
=
Secondary phosphine chalcogenides, R2PX (R (CH2)2Ph, Ph; X = S,
=
Se), react with divinyl chalcogenides, (CH2 CH)2Y (Y = S, Se, Te), at
the2:1molarratio(80–82°C, 56–80 h)intheabsenceofbothcatalysts
(initiators) and solvents to quantitatively afford the corresponding
anti-Markovnikov diadducts. Even at the equimolar reactant ratio,
the diadducts are the major products, though monoadducts are also
formed. When Y = Te, vinylphosphine chalcogenides and metal Te
are obtained, thus showing that divinyl telluride behaves as the
vinylating agent.
KEYWORDS
Secondary phosphine
chalcogenides; divinyl
chalcogenides; catalyst- and
solvent-free addition;
synthesis; α; ω-diphosphine
chalcogenides
1. Introduction
Tertiary α,ω-diphosphines and α,ω-diphosphine chalcogenides continue to attract sig-
nificant attention of researchers. Currently, these important organophosphorus com-
pounds find widespread application as prospective ligands for the design of metal com-
plex catalysts,[1–11] precursors of pharmaceutical compounds,[12–19] as well as special
solvents-stabilizers for the preparation of nano-sized semi-conducting materials.[20–28]
α,ω-Diphosphine chalcogenides bearing chalcogenoalkane moieties are of special interest
as polydentate hemilabile ligands.[29–40]
Among the most straightforward approaches to the synthesis of functional α,ω-
diphosphines and phosphine chalcogenides is the reaction of secondary phosphines and
CONTACT Boris A. Trofimov
boris_trofimov@irioch.irk.ru
A. E. Favorsky Irkutsk Institute of Chemistry, Siberian
Branch of the Russian Academy of Sciences, 1 Favorsky Str., 664033 Irkutsk, Russian Federation.
© 2016 Informa UK Limited, trading as Taylor & Francis Group

2
N. K. GUSAROVA ET AL.
phosphine chalcogenides with available divinyl chalcogenides, easily prepared from acety-
lene and elemental sulfur, selenium and tellurium in the presence of superstrong bases of
the type KOH – polar non-hydroxylic solvent (DMSO, HMPA).[41–43]
Earlier it has been reported that diaddition of secondary phosphine and phosphine
chalcogenides to divinyl chalcogenides (divinyl sulfide,[9] divinyl selenide,[44] divinyl
telluride,[45,46] divinyl sulfoxide,[47] divinyl sulfone,[48,49] as well as divinyl ethers of
glycols [50]) proceeds in the presence of radical initiators [9,44–46] or bases [47–49,51,52]
and, as a rule, in organic solvents.
In recent years, catalyst- and solvent-free reactions attract a particular attention. This
is especially important in view of modern requirements of green chemistry. For exam-
ple, it has been shown that secondary phosphine and phosphine chalcogenides react with
diverse monoalkenes (including functionalized ones) under non-catalyst and non-solvent
conditions to afford anti-Markovnikov adducts.[53–57]
2. Results and discussion
To extend the preparative scope of the novel environmentally benign method for the syn-
thesis of functional phosphine chalcogenides and to gain additional knowledge about the
C–P bond formation from PH-addends and alkenes under non-catalytic solvent-free con-
ditions, in the present work, we have studied the reaction of secondary phosphine sulfides
and phosphine selenides with available [41–43] divinyl chalcogenides.
The experiments have shown that bis(2-phenethyl)phosphine sulfide 1, bis(2-
phenethyl)phosphine selenide 2 and diphenylphosphine sulfide 3 react with divinyl sulfide
4 and divinyl selenide 5 (molar ratio of the starting reagents is 2:1) upon heating (80–82°C,
56–80 h) in the absence of catalysts and solvents to afford the corresponding diadducts
6a–6d in almost quantitative yields (Table 1, Entries 1–4). It should be emphasized that
the radical scavengers (hydroquinone or TEMPO) do not inhibit the addition of phos-
phine chalcogenide 1 to divinyl sulfide 4 (Table 1, Entries 5, 6). Moreover, in the dark, this
reaction proceeds with the same efficiency as in the light (Table 1, Entry 7).
Using bis(2-phenethyl)phosphine oxide as an example, it has been found that secondary
phosphine oxides do not react with divinyl chalcogenides 4 and 5 under the conditions
elaborated.
The attempts to direct this reaction at the preferable formation of the monoadduct
by heating (at 43–45°; 50–53° or 80–82°C) phosphine sulfides 1, 3 with divinyl sulfide
4 or divinyl selenide 5 (their molar ratio 1:1) do not give the desired result. In all the
experiments, mixtures of mono – 7a,b,d and diadducts 6a,b,d are formed, the latter being
significantly (∼threefold times) prevailing. This indicates a much higher addition rate of
the phosphine chalcogenides to the monoadducts (Scheme 1).
Adducts 6d and 7d (obtained from divinyl selenide and phosphine sulfide 3) are easily
isolated from the reaction mixture in 22% and 57% yields, respectively. At the same time,
separation of mono- and diadducts 7a,7b and 6a,6b on a chromatographic column has
met with no success, since they have almost the same solubility in most organic solvents
(benzene, ether, chloroform, acetone and ethanol) and close Rf values.
The reaction mechanism is of a special interest. As far as the addition takes place with
equal efficiency both in the light and in the dark and radical scavenges such as TEMPO and
hydroquinone do not influence the process, one should decline the radical mechanism. As

JOURNAL OF SULFUR CHEMISTRY
3
a probable rationale of the mechanism, the electrophilic attack of the positively charged
phosphorus atom of the phosphine chalcogenides at the β-carbon of vinyl chalcogenides
may be admitted (Scheme 2). Such an attack should be facilitated by the negative charge
Table 1. Synthesis of α,ω-diphosphine chalcogenides 6a–6d under catalyst- and solvent-free
conditionsa.
Phosphine
chalcogenide
Divinyl
chalcogenide
Isolated yield
(%)
Entry
1
Time (h)
72
Product (6)
95
2
3
68
78
98
95
4
62
80
96
95
5b
6c
56
96
(continued).

4
N. K. GUSAROVA ET AL.
Table 1. Continued.
Phosphine
chalcogenide
Divinyl
chalcogenide
Isolated yield
(%)
Entry
7d
Time (h)
76
Product (6)
95
76
95
aStandard reaction condition: molar ratio phosphine chalcogenide/divinyl chalcogenide = 2:1, 80–82°C, argon.
bExperiment was carried out in the presence of hydroquinone (10 wt%).
cExperiment was carried out in the presence of TEMPO (5 wt%).
dExperiment was carried out in dark.
Scheme 1. Synthesis of monoadducts 7a,b,d.
Scheme 2. A possible generation of intermediate A.
at this atom and stabilization of the emerging positive charge at the α-carbon atom by the
lone electron pair of the chalcogen atom (intermediate A).
This process should be additionally favored by simultaneous hydrid transfer from the
phosphorus atom to the carbenium center. Consequently, all this is likely realized in the
four-membered transition state B. Of course, the six-membered transition state C with
the participation of two molecules of the phosphine chalcogenides, having more favorable
valence angles, should not be excluded.

JOURNAL OF SULFUR CHEMISTRY
5
Scheme 3. Reaction of divinyl telluride with secondary phosphine sulfides.
A higher rate of the addition to the mono-adducts (the advantageous formation of
the diadducts, see above) also requires rationalization. In terms of Scheme 1, this phe-
nomenon may be understood as an activation of the remaining double bond due to
its additional polarization under the intramolecular through-space influence from the
polarized phosphine chalcogenide moieties in the appropriate conformation D of the
mono-adduct.
It appears that the reaction of divinyl telluride with secondary phosphine sulfide under
similar conditions takes another direction. So, upon heating (80–82°C, 125 h) of divinyl
Figure 1. Ion fragmentation m/z 732
( 8 in MS/MS TOF/TOF laser
130Te) of diadduct
desorption/ionization spectrum.

6
N. K. GUSAROVA ET AL.
telluride with phosphine sulfide 1, instead of the expected diadduct 8, vinylphosphine sul-
fide 9 is formed in 72% yield, metal tellurium being also isolated. This reaction likely occurs
via the initial generation of diadduct 8, which further decomposes to give vinylphosphine
sulfide 9 and metal tellurium (Scheme 3). Thus, in this case, divinyl telluride is a vinylating
agent relative to secondary phosphine sulfides.
Diadduct 8 has been detected in the reaction mixture by using the MSMS technique
(Figure 1).
3. Conclusion
In conclusion, a convenient, efficient and atom-economic method for the synthesis of
functionalized diphosphine chalcogenides via the catalyst- and solvent-free reaction of
secondary phosphine sulfides and phosphine selenides with divinyl sulfide and divinyl
selenide has been elaborated. The products obtained represent polydentate multifaceted
ligands, intermediates for drug design as well as for the generation of nano-sized semi-
conductors.
4. Experimental
4.1. General
The C, H, S microanalyses were performed on a Flash EA 1112 CHNS-O/MAS analyzer,
while the P and Se content were determined by combustion method. IR spectra were run on
a Bruker Vertex 70 instrument. The 1H, 13C, 31P and 77Se NMR spectra were recorded on a
Bruker DPX 400 and Bruker AV-400 spectrometer (400.13, 100.61, 161.98 and 76.31 MHz,
respectively). 85% H3PO4/H2O was employed as external standard for 31P NMR; hexam-
ethyldisiloxane was used for 1H, 13C NMR and Me2Se was the external standard for 77Se
NMR. Melting points (uncorrected) were measured on a Kofler micro hot-stage apparatus.
Laser desorption ionization MS/MS TOF/TOF mass spectrum was recorded on UltraFlex
III TOF/TOF (Bruker Daltonics GmbH, Germany), equipped with a pulse nitrogen laser
(337 nm) using FlexControl (Bruker Daltonics, Germany) software (version 3.3) in a reflec-
tron modi. The spectra were processed using FlexAnalysis 3.3 software (Bruker Daltonics,
Germany). Positively charged ions were fixed. Metastable ion peaks (PSD), decomposed in
field-free space, were determined in LIFT mode. Mass spectra were calibrated using Proteo
Mass set (Sigma, Germany). Samples were prepared by the Dried-Drop Method: 0.5 μL of
the sample (2.3 pMol) solution in CHCl3 (Merk, Germany) was deposited onto the target
NALDITM (Nanosys, Inc. Palo Alto, CA, USA), having a nano-structured surface allowing
to study the analyte without matrix, and allowed to air-dry (for several minutes) at room
temperature.
All steps of the experiment were carried out in argon atmosphere. Divinyl chalco-
genides were readily prepared according to the published procedure.[41–43] Secondary
phosphine chalcogenides 1, 2 were synthesized by oxidation of the corresponding phos-
phines with powdered sulfur or selenium. The initial phosphine was prepared from red
phosphorus and styrene as described in the literature.[58] Diphenylphosphine sulfide 3
was prepared by oxidation of commercially available diphenylphosphine (Aldrich) with
elemental sulfur.

JOURNAL OF SULFUR CHEMISTRY
7
4.2. General procedure for synthesis of α,ω-diphosphine chalcogenides 6a–6d
A mixture of secondary phosphine chalcogenide 1–3 and divinyl chalcogenide 4, 5 (molar
ratio 2:1) was stirred at 80–82°C for 56–80 h under argon atmosphere. The reaction was
monitored by 31P NMR following the disappearance of the signal of the starting phos-
phine chalcogenide (δ = 3 ÷ 23 ppm) and simultaneous appearance of a new signal at
P
38 ÷ 49 ppm, corresponding to tertiary phosphine chalcogenide 6a–6d. After the reac-
tion completion, the crude product was dissolved in a small amount of chloroform and
reprecipitated to hexane to give compounds 6a–d in 95–98% yields.
4.2.1. 2-[2-(Diphenethylphosphorothioyl)ethyl]sulfanylethyl(diphenethyl)phosphine
sulfide (6a)
1
Colorless oil; yield: 0.38 g (95%). H NMR (400.13 MHz, CDCl3): δ = 2.13 [m, 12 H,
CH2P(CH2)2], 2.81 (m, 4 H, CH2S), 2.93 (m, 8 H, PhCH2), 7.18–7.31 (m, 20 H, Ph). 13
C
NMR (100.61 MHz, CDCl3): δ = 24.97 (d, 2JPC = 2.0 Hz, SCH2), 28.59 (d, 2JPC = 3.1 Hz,
PhCH2), 31.04 (d, 1JPC = 45.5 Hz, PCH2CH2S), 33.29 (d, 1JPC = 48.2 Hz, PCH2CH2Ph),
126.65 (Cp, Ph), 128.24, 128.76 (Co,m, Ph), 140.33 (d, 3JPC = 14.2 Hz, Ci, Ph). 31P NMR
(161.98 MHz, CDCl3): δ = 48.8. IR (neat, cm−1): 3084, 3061, 3026, 3001 (ν CH of phenyl
=
=
rings), 2922, 2904, 2861 (ν CH), 1952, 1878, 1809, 1753, 1602, 1584, 1496 (ν C C of phenyl
rings), 1452, 1404 (δ CH2), 1274, 1214, 1137, 1072, 1027, 1008, 951, 911, 836 (δ CH of
phenyl rings), 752 br.c (ν P–C), 699 (δ CH of phenyl rings), 598 (ν P S). Anal. Calcd for
C36H44P2S3: C, 68.11; H, 6.99; P, 9.76; S, 15.15. Found: C, 68.19%; H, 7.23%; P, 9.67%; S,
14.85%.
=
4.2.2. 2-[2-(Diphenethylphosphorothioyl)ethyl]selanylethyl(diphenethyl)phosphine
sulfide (6b)
1
Colorless oil; yield: 0.54 g (98%). H NMR (400.13 MHz, CDCl3): δ = 2.17 (m, 12 H,
CH2PCH2), 2.82 (m, 4 H, CH2Se), 2.94 (m, 8 H, PhCH2), 7.18–7.25 (m, 20 H, Ph). 13
C
NMR (100.61 MHz, CDCl3): δ = 15.20 (d, 2JPC = 3.7 Hz, CH2Se), 28.53 (PhCH2), 32.08
1
1
(d, JPC = 44.2 Hz, PCH2CH2Se), 32.93 (d, JPC = 47.5 Hz, PhCH2CH2P), 126.61 (Cp,
Ph), 128.23, 128.71 (Co,m, Ph), 140.30 (d, 3JPC = 13.4 Hz, Ci, Ph). 31P NMR (161.98 MHz,
CDCl3): δ = 49.5. 77Se NMR (76.31 MHz, CDCl3): δ = 249 (CH2SeCH2). IR (neat,
cm−1): 3084, 3061, 3026, 3001 (ν CH of phenyl rings), 2925, 2854 (ν CH), 1602, 1583,
=
=
1496 (ν C C of phenyl rings), 1453, 1405 (δ CH2), 1254, 1214, 1179, 1121, 1081, 1047,
1029, 1006, 949, 910, sh 888, 873, sh 832, sh 808 (δ CH of phenyl rings), br.c 750 (ν P–C),
=
698 (δ CH of phenyl rings), sh 612, 596 (ν P S). Anal. Calcd for C36H44P2S2Se: C, 63.40; H,
6.51; P, 9.11; S, 9.39; Se, 11.61. Found: C, 63.46%; H, 6.59%; P, 8.96%; S, 9.48%; Se, 11.51%.
Physical-chemical and spectral data (NMR 1H, 31P) were identical to those for the com-
pound obtained previously from phosphine sulfide 1 and divinyl selenide under radical
initiation (75°C, AIBN, 1,4-dioxane).[44]
4.2.3. 2-[2-(Diphenethylphosphoroselenoyl)ethyl]selanylethyl(diphenethyl)
phosphine selenide (6c)
Light yellow oil; yield: 0.55 g (95%). 1H NMR (400.13 MHz, CDCl3): δ = 2.28 (m, 12 H,
CH2PCH2), 2.83 (m, 8 H, PhCH2), 2.94 (m, 4 H, CH2Se), 7.19–7.25 (m, 20 H, Ph). 13
C
NMR (100.61 MHz, CDCl3): δ = 15.72 (d, 2JPC = 2.7 Hz, CH2Se), 29.04 (PhCH2), 31.35

8
N. K. GUSAROVA ET AL.
1
1
(d, JPC = 36.5 Hz, PCH2CH2Se), 32.23 (d, JPC = 40.4 Hz, PhCH2CH2P), 126.36 (Cp,
Ph), 127.99, 128.44 (Co,m, Ph), 139.80 (d, 3JPC = 13.6 Hz, Ci, Ph).31P NMR (161.98 MHz,
CDCl3): δ = 38.9. 77Se NMR (76.31 MHz, CDCl3): δ = -387 (d, JP−Se = 702.0 Hz,
1
P=Se), 252 (CH2SeCH2). IR (neat, cm−1): 3084, 3061, 3026, 3001 (ν CH of phenyl
=
=
rings), 2924, 2854 (ν CH), 1602, 1583, 1496 (ν C C of phenyl rings), 1454, 1404 (δ CH2),
sh 1269, 1254, 1214, 1178, 1120, 1082, 1029, 1006, 949, 910, 888, 873 (δ CH of phenyl
rings), br.c 753 (ν P–C), 698 (δ CH of phenyl rings), sh 572, 575 (ν P Se). Anal. Calcd for
=
C36H44P2Se3: C, 55.78; H, 5.70; P, 7.97; Se, 30.57. Found: C, 56.01%; H, 5.69%; P, 7.84%;
Se, 30.46%.
Physical-chemical and spectral data (NMR 1H, 31P) were identical to those for the com-
pound obtained previously from phosphine sulfide 2 and divinyl selenide under radical
initiation (75°C, AIBN, 1,4-dioxane).[44]
4.2.4. 2-[2-(Diphenylphosphorothioyl)ethyl]selanylethyl(diphenyl)phosphine sulfide
(6d)
White powder, m.p. 146–148°C; yield: 0.49 g (96%) prepared from diphenylphosphine
1
sulfide 3 (1.5 mmol, 0.412 g) and divinyl selenide 4 (0.75 mmol, 0.100 g). H NMR
(400.13 MHz, CDCl3): δ = 2.76 (m, 8 H, PCH2CH2Se), 7.45–7.86 (m, 20 H, Ph). 13C NMR
2
1
(100.61 MHz, CDCl3): δ = 14.60 (d, JPC = 3.0 Hz, CH2Se), 33.91 (d, JPC = 49.8 Hz,
2
3
4
CH2P), 128.7 (d, JPC = 12.2 Hz, Co), 131.1 (d, JPC = 10.3 Hz, Cm), 131.5 (d, JPC
=
3.0 Hz, Cp). 31P NMR (161.98 MHz, CDCl3): δ = 42.5. IR (KBr, cm−1): 3053 (ν CH);
=
=
2926, 2892 (ν CH), 1477 (ν C C of phenyl rings), 1463, 1430 (δ CH2), 1317, 1268, 1172,
1102, 1010, 920, 873, sh 776 (δ CH of phenyl rings), 751 (ν P–C); 737, 719, 698 (δ CH of
phenyl rings), sh 619, 603 (ν P S). Anal. Calcd for C28H28P2S2Se: C, 59.05; H, 4.96; P,
10.88; S, 11.26; Se, 13.86. Found: C, 59.42%; H, 4.99%; P, 10.98%; S, 10.77%; Se, 13.84%.
Physical-chemical and spectral data (NMR 1H, 31P) were identical to those for the com-
pound obtained previously from phosphine sulfide 3 and divinyl selenide under radical
initiation (75°C, AIBN, 1,4-dioxane).[44]
=
4.3. Synthesis of monoadducts (7a,b,d)
A mixture of phosphine sulfide 1 (1.0 mmol) and divinyl chalcogenide 4, 5 (1.0 mmol) was
stirred at 80–82°C for 40–70 h (argon) following the disappearance of the signal of the
starting phosphine sulfide 1 (31P NMR) to give a mixture of mono-7a,7b and diadducts
6a,6b in a ratio of 70% and 30%, respectively, (31P NMR data).
Separation of mono- and diadducts 6a, 7a and 6b, 7b on a chromatographic column has
met with no success, since they have almost the same solubility in most organic solvents
(benzene, ether, chloroform, acetone, and ethanol) and close Rf values.
4.3.1. The mixture of adducts (6a and 7a)
1H NMR (400.13 MHz, CDCl3): δ = 2.14 (m, 18 H, CH2P(CH2)2 in 6a and 7a), 2.83
(m, 6 H, CH2S in 6a and 7a), 2.94 (m, 12 H, PhCH2 in 6a and 7a), 5.15 (d, 1 H,
3
3
=
=
JHH = 16.7 Hz, CH2 in 7a), 5.23 (d, 1 H, JHH = 10.1 Hz, CH2 in 7a), 6.25 (dd, 1
H, CH in 7a), 7.14–7.26 (m, 30 H, Ph in 6a and 7a). 31P NMR (161.98 MHz, CDCl3):
δ = 48.5 (7a), 48.8 (6a).
=

JOURNAL OF SULFUR CHEMISTRY
9
4.3.2. The mixture of adducts (6b and 7b)
1H NMR (400.13 MHz, CDCl3): δ = 2.18 (m, 18 H, CH2PCH2 in 6b and 7b), 2.84
(m, 6 H, CH2Se in 6b and 7b), 2.94 (m, 12 H, PhCH2 in 6b and 7b), 5.54 (d, 1 H,
3
3
=
=
JHH = 16.9 Hz, CH2 in 7b), 5.78 (d, 1 H, JHH = 9.8 Hz, CH2, in 7b), 6.62 (dd, 1
H, CH in 7b), 7.19–7.26 (m, 30 H, Ph in 6b and 7b). 31P NMR (161.98 MHz, CDCl3):
δ = 49.3 (7b), 49.5 (6a).
=
4.3.3. Diphenyl[2-(vinylselanyl)ethyl]phosphine sulfide (7d)
A mixture, prepared from diphenylphosphine sulfide 3 (1.0 mmol, 0.218 g) and divinyl
selenide 4 (1.0 mmol, 0.133 g), containing mono-7d and diadduct 6d in a ratio of 70%
and 30%, respectively (31P NMR data), was dissolved in cold ether. Upon storage, a white
powder, diadduct 6d (0.226 g, 57%), was precipitated from the mixture. The ether solution
was decanted, concentrated under reduced pressure and passed through a thin (5 mm)
layer of Al2O3. The solvent was evaporated and the residue was dried at 1 mm Hg to
1
give viscous monoadduct 7d as light-yellow oil (0.054 g, 22%). H NMR (400.13 MHz,
3
=
CDCl3): δ = 2.87 (m, 4 H, PCH2CH2Se), 5.46 (d, 1 H, JHH = 16.7 Hz, CH2), 5.73
(d, 1 H, 3JHH = 9.6 Hz, CH2), 6.64 (dd, 1 H, CH ), 7.53 (m, 6 H, Ph), 7.89 (m, 4 H,
=
=
Ph). 13C NMR (100.61 MHz, CDCl3): δ = 16.26 (d, JPC = 2.0 Hz, CH2Se), 33.96 (d,
2
1
2
=
=
JPC = 49.2 Hz, CH2P), 118.12 ( CH2), 125.40 (CH ), 128.6 (d, JPC = 12.06 Hz, Co),
130.9 (d, 3JPC = 10.2 Hz, Cm), 131.6 (d, 4JPC = 2.0 Hz, Cp), 132.1 (d, 1JPC = 74.4 Hz, Ci).
31P NMR (161.98 MHz, CDCl3): δ = 41.9. Anal. Calcd for C16H17PSSe: C, 54.70; H, 4.88;
P, 8.82; S, 9.13; Se, 22.48. Found: C, 54.75%; H, 4.90%; P, 8.96%; S, 9.01%; Se, 22.38%.
Physical-chemical and spectral data (NMR 1H, 31P) were identical to those for the com-
pound obtained previously from phosphine sulfide 3 and divinyl selenide under radical
initiation (75°C, AIBN, 1,4-dioxane).[44]
4.4. Reaction of phosphine sulfide 1 with divinyl telluride
A mixture of secondary phosphine sulfide 1 (1.5 mmol, 0.412 g) and divinyl telluride
(0.75 mmol, 0.136 g) was stirred at 80–82°C for 125 h (argon) following the disappearance
in the 31P NMR of the signal of the starting phosphine sulfide 1 at 21.3 ppm and simul-
taneous appearance of new signals at 51.3 ppm (the expected diadduct 8) and 43.1 ppm
(vinylphosphine sulfide 9). As the reaction proceeded, the intensity of the signal corre-
sponding to vinylphosphine sulfide 9 increased, while the intensity of the signal corre-
sponding to diadduct 8 dropped. The presence of the expected diadduct 8 in the reaction
mixture was proved by MSMS analysis: the spectrum showed a characteristic cluster of iso-
topic peaks of the molecular ion with m/z 732 (for 130Te). After complete disappearance of
the signal of the starting phosphine sulfide 1 in the 31P NMR spectrum, the reaction mix-
ture contained diadduct 8 (51.3 ppm) and vinylphosphine sulfide 9 (43.1 ppm), the signal
intensity being 5% and 95%, respectively. The crude product represents a viscous mass
containing black inclusions (elemental tellurium). Ether (5 ml) was added to the product
obtained, and the residue precipitated was separated and washed many times with ether to
give 0.081 g of elemental tellurium.
The ether extracts were combined and evaporated under reduced pressure; the residue
was dissolved in a small amount of ether and passed through thin layers of Al2O3, and the
ether was distilled to give 0.336 g (yield 72%) of vinylphosphine sulfide 9.

10
N. K. GUSAROVA ET AL.
4.4.1. Diphenethyl(vinyl)phosphine sulfide (9)
Light yellow viscous substance; yield: 0.336 g (72%). H NMR (400.13 MHz, CDCl3):
1
δ = 2.16–2.28 (m, 4 H, CH2PCH2), 2.84–3.05 (m, 4 H, PhCH2), 6.21–6.57 (m, 3 H,
CH CH2), 7.19–7.32 (m, 10 H, Ph). 31P NMR (161.98 MHz, CDCl3): δ = 43.1. Anal.
=
Calcd for C18H21PS: C, 71.82; H, 6.99; P, 10.91; S, 10.51. Found: C, 71.93%; H, 7.03%; P,
10.47%; S, 10.57%.
Physical-chemical and spectral data were identical to the literature ones.[59]
Acknowledgements
This work has been performed using the equipment of Baikal Analytical Center for collective use
Siberian Branch of the Russian Academy of Sciences.
References
[1] Brauer DJ, Kottsieper KW, Nickel T, Sheldrick WS. Novel electron-rich hydrophilic phosphanes
with carboxylated cyclohexyl substituents. Eur J Inorg Chem. 2001;2001:1251–1259.
[2] Imamoto T, Oohara N, Takahashi H. Optically active 1,1ꢀ-di-tert-butyl-2,2ꢀ-diphosphetanyl
and its application in rhodium-catalyzed asymmetric hydrogenations. Synthesis. 2004;9:
1353–1358.
[3] Subasi E, Senturk OS, Ugur FZ. Photochemical reactions of Re(CO)5Br with Ph2P(S)(CH2)n
P(S)Ph2 (n = 1, 2, 3). Naturforsch. 2004;59b:836–838.
[4] Aizawa S, Tamai M, Sakuma M, Kubo A. Readily regenerative and air-stable palladium(0) cat-
alyst with tris[2-(diphenylphosphino)ethyl]phosphine tetrasulfide for C–C coupling reactions.
Chem Lett. 2007;36:130–131.
[5] Börner A. editor. Phosphorus ligands in asymmetric catalysis: synthesis and applications.
Weinheim: Wiley-VCH; 2008. p. 1.
[6] Pop A, Silvestru A, Gimeno MC, et al. New group 11 complexes with metal-selenium bonds of
methyldiphenylphosphane selenide: a solid state, solution and theoretical investigation. Dalton
Trans. 2011;40:12479–12490.
[7] Dutta DK, Deb B. Potential rhodium and ruthenium carbonyl complexes of phosphine-
chalcogen (P-O/S/Se) donor ligands and catalytic applications. Coord Chem Rev. 2011;255:
1686–1712.
[8] Chatterjee S, Patel SK, Tirkey V, Mobin SM. Synthesis and characterization of bridged and
chelated diphosphine coordinated transition metal chalcogenide clusters, [(CO)18Fe6(μ -
Te)4{μ-PPh2(CH2)2PPh2}] and [(CO)nFe2(μ -Y)2M{PPh2-R-PPh2}], [Y = Se, Te; M = P3d,
3
Fe; n = 6, 8; R = {(η5-C5H4)2Fe}, {(CH2)2}]. J Organomet Chem. 2012;699:12–17.
[9] Persson R, Stchedroff MJ, Gobetto R, et al. Synthesis, characterization, and dynamic behaviour
of triosmium clusters containing the tridentate ligand {Ph2PCH2CH2}2S (PSP). Eur J Inorg
Chem. 2013;2013:2447–2459.
[10] Canales S, Villacampa MD, Laguna A, Gimeno MC. Coordination studies of the ferrocenyl
phosphine selenide ligand FcCON(CH2CH2PPh2Se)2. J Organomet Chem. 2014;760:84–88.
[11] Mottalib MA, Haukka M, Nordlander E. Chiral diphosphine derivatives of alkylidyne tri-
cobalt carbonyl clusters – a comparative study of different cobalt carbonyl (pre)catalysts for
(asymmetric) intermolecular Pauson–Khand reactions. Polyhedron. 2016;103:275–282.
[12] Berners-Price SJ, Sadler PJ. Phosphines and metal phosphine complexes: relationship of
chemistry to anticancer and other biological activity. Berlin: Springer-Verlag; 1988. p. 102.
[13] Bollmark M, Stawinski J. A new selenium-transferring reagent – triphenylphosphine selenide.
Chem Commun. 2001;8:771–772.
[14] Rackham O, Nichols SJ, Leedman PJ, Berners-Price SJ, Filipovska A. A gold(I) phosphine com-
plex selectively induces apoptosis in breast cancer cells: implications for anticancer therapeutics
targeted to mitochondria. Biochem Pharmacol. 2007;74:992–1002.

JOURNAL OF SULFUR CHEMISTRY
11
[15] Tian S, Siu FM, Kiu SCF, Lok CN, Che CM. Anticancer gold(I)–phosphine complexes as potent
autophagy-inducing agents. Chem Commun. 2011;47:9318–9320.
[16] Wetzel C, Kunz PC, Kassack MU, Hamacher A, Böhler Ph, Watjen W, Ott I, Rubbiani R, Spin-
gler B. Gold(I) complexes of water-soluble diphos-type ligands: synthesis, anticancer activity,
apoptosis and thioredoxin reductase inhibition. Dalton Trans. 2011;40:9212–9220.
[17] Hatfield DL, Berry MJ, Gladyshev VN. Selenium: its molecular biology and role in human
health. New York: Springer; 2012.
[18] Khalladi K, Touil S. Synthesis of novel fused thienodiazaphosphorine derivatives from 2-
amino-3-cyanothiophenes and Lawesson’s reagent. J Sulfur Chem. 2012;33:27–32.
[19] Elkhaldy AAS, Hussien AR, Abu Shanab AM, Wassef MA. Synthesis, spectroscopic,
and antimicrobial studies on O,Oꢀ-dialkyl and alkylene dithiophosphate cyclopentadienyl-
zirconium(IV) hydride. J Sulfur Chem. 2012;33:295–302.
[20] Cauzzi D, Graiff C, Massera C, Predieri G, Tiripicchio A. Easy access to phosphido-
selenido clusters. Reaction of [Ru3(CO)12] with Ph2(pyth)PSe {pyth = 5-(2-Pyridyl)-2-
Thienyl} and crystal structure of [Ru3(μ3-Se)(μ-PPh2)(μ-pyth)(CO)6{P(pyth)Ph2}]. J Clus-
ter Sci. 2001;12:259–271.
[21] Belletti D, Graiff C, Lostao V, Pattacini R, Predieri G, Tiripicchio A. Sulfido–carbonyl
ruthenium clusters derived from tertiary phosphine sulfides. Inorg Chim Acta. 2003;347:
137–144.
[22] Sashchiuk A, Amirav L, Bashouti M, Krueger M, Sivan U, Lifshitz E. PbSe nanocrys-
tal assemblies: synthesis and structural, optical, and electrical characterization. Nano Lett.
2004;4:159–165.
[23] Snee PT, Somers RC, Nair G, Zimmer JP, Bawendi MG, Nocera DG. A ratiometric CdSe/ZnS
nanocrystal pH sensor. J Am Chem Soc. 2006;128:13320–13321.
[24] Liu H, Owen JS, Alivisatos AP. Mechanistic study of precursor evolution in colloidal group
II−VI semiconductor nanocrystal synthesis. J Am Chem Soc. 2007;129:305–312.
[25] Koh W, Yoon Y, Murray CB. Investigating the phosphine chemistry of Se precursors for the
synthesis of PbSe nanorods. Chem Mater. 2011;23:1825–1829.
[26] Vaughn DD, In S-II, Schaak RE. A precursor-limited nanoparticle coalescence pathway for
tuning the thickness of laterally-uniform colloidal nanosheets: the case of SnSe. ACS Nano.
2011;5:8852–8860.
[27] Boercker JE, Foos EE, Placencia D, Tischler JG. Control of PbSe nanorod aspect ratio by
limiting phosphine hydrolysis. J Am Chem Soc. 2013;135:15071–15076.
[28] García-Rodríguez R, Liu H. Mechanistic insights into the role of alkylamine in the synthesis of
CdSe nanocrystals. J Am Chem Soc. 2014;136:1968–1975.
[29] Deb B, Dutta DK. Influence of phosphorus and oxygen donor diphosphine ligands on the
reactivity of rhodium(I) carbonyl complexes. J Mol Catal A: Chem. 2010;326:21–28.
[30] Cantat T, Mezailles N, Ricard L, Jean Y, Le Floch PA. A bis(thiophosphinoyl)methanediide
palladium complex: coordinated dianion or nucleophilic carbene complex? Angew Chem Int
Ed Engl. 2004;43:6382–6385.
[31] Matulova V, Man S, Necas M. Binuclear complexes of 4-methoxyphenyltellurium trichloride
with variably linked diphosphine disulfide ligands. Polyhedron. 2007;26:2569–2573.
[32] Kling C, Ott H, Schwab G, Stalke D. Heteroaromatic substituted phosphoranes with enhanced
hemilabile character. Organometallics. 2008;27:5038–5042.
[33] Warad I, Al-Othman Z, Al-Resayes S, Al-Deyab S, Kenawy E. Synthesis and characteriza-
tion of novel inorganic-organic hybrid Ru(II) complexes and their application in selective
hydrogenation. Molecules. 2010;15:1028–1040.
[34] Warad I, Al-Resayes S, Al-Othman Z, Al-Deyab SS, Kenawy ER. Synthesis and spectrosopic
identification of hybrid 3-(triethoxysilyl)propylamine phosphine ruthenium(II) complexes.
Molecules. 2010;15:3618–3633.
[35] Wang HT, Su FH, Hu QM, Song YL, Gao YC. Synthesis, characterization and properties
of transition metal Pd/Pt [60] fullerene complexes containing phosphane ligands − crystal
structure of [Pd(η2-C60){Ph2PCH2(CH2OCH2)2CH2PPh2}]. Eur J Inorg Chem. 2004;2004:
866–871.

12
N. K. GUSAROVA ET AL.
[36] Major Q, Lough AJ, Gusev DG. Substituents effects in POP pincer complexes of ruthenium.
Organometallics. 2005;24:2492–2501.
[37] Duffey CH, Lake CH, Gray GM. Metallacrown ethers with trans-tetracarbonylmolybdenum(0)
centers. X-ray crystal structures of trans-Mo(CO)4{Ph2P(CH2CH2O)nCH2CH2PPh2-P,Pꢀ} (n
= 3, 5) and trans-Mo(CO)4{Ph2P(CH2CH2O)2-1-C6H4-2-(OCH2CH2)2PPh2-P,Pꢀ}. Inorg
Chim Acta. 2001;317:199–210.
[38] Smith DC, Lake CH, Gray GM. Synthesis and characterization of [Pd2X2(μ-X)2{Ph2
P(CH2CH2O)nCH2CH2PPh2-P,Pꢀ}]m (n = 3, 5, X = Cl, I) dimetallacrown ethers and
the related dinuclear [Pd2Cl2(μ-Cl)2{Ph2P(CH2)12PPh2-P,Pꢀ}]m and [Pd2X2(μ-X2){Ph2
P(CH2CH2O)2CH2CH3-P)2}](X = Cl, I) complexes. Dalton Trans. 2003;14:2950–2955.
[39] Owens SB, Smith DC, Lake CH, Gray GM. Synthesis, characterization, and cis-trans isomer-
ization studies of cis-[PdCl2{Ph2P(CH2CH2O)3CH2CH2PPh2-P,Pꢀ}] and trans-[PtCl2{Ph2
P(CH2CH2O)3CH2CH2PPh2-P,Pꢀ}] metallacrown ethers. Eur J Inorg Chem. 2008;2008:
4710–4718.
[40] Owens SB, Gray GM. Study of the effects of alkali metal salts on styrene hydroformyla-
tion reactions catalyzed by rhodium(I) complexes of bis(phosphite) ligands. Organometallics.
2008;27:4282–4287.
[41] Trofimov BA, Amosova SV, Gusarova NK, Musorin GK. Reactions of triads S8 – KOH – DMSO,
Se8 – KOH – DMSO, Te – KOH – HMPA with acetylenes. Tetrahedron. 1982;38:713–718.
[42] Trofimov BA. Chalcogenation in multiphase superbase systems. Sulfur Rep. 1992;11:207–227.
[43] Gusarova NK, Tatarinova AA, Sinegovskaya LM. Vinyl tellurides: synthesis and properties.
Sulfur Rep. 1991;11:1–50.
[44] Gusarova NK, et al. Reaction of divinyl selenide with secondary phosphine chalcogenides. Rus
J Gen Chem. 2010;80:1602–1608.
[45] Gusarova NK, Chernysheva NA, Yas’ko SV, Klyba LV, Trofimov BA. Reaction of divinyl
telluride with secondary phosphine chalcogenides. Rus J Gen Chem. 2011;81:2506–2509.
[46] Gusarova NK, et al. Mass spectrometry and quantum chemical studies of the reaction of
divinyl telluride with secondary phosphine sulfides: synthesis of adducts. J Organomet Chem.
2013;745–746:126–132.
[47] Malysheva SF, Gusarova NK, Belogorlova NA, Trofimov BA. Addition of secondary phosphine
oxides to divinyl sulfoxide. Sulfur Lett. 1998;21:263–268.
[48] Malysheva SF, Gusarova NK, Belogorlova NA, Afonin AV, Arbuzova SN, Trofimov BA.
A new method for the synthesis of diorganylvinylphosphine oxides. Rus Chem Bull.
1997;46:1799–1801.
[49] Gusarova NK, et al. Interaction of secondary phosphine and phosphinoxides with divinylsul-
fone. Rus J Org Chem. 1998;34:1107–1108.
[50] Oparina LA, Gusarova NK, Vysotskaya OV, Kolyvanov NA, Artem’ev AV, Trofimov BA.
Atom-economic, metal- and halogen-free synthesis of podands: α,ω-diphosphines and their
chalcogenides separated by alkane diol spacers. Synthesis. 2012;44:2938–2946.
[51] Arbuzova SN, Gusarova NK, Trofimov BA. Nucleophilic and free-radical additions of phos-
phines and phosphine chalcogenides to alkenes and alkynes. ARKIVOC. 2006;2006(5):12–36.
[52] Gusarova NK, Arbuzova SN, Trofimov BA. Novel general halogen-free methodology for the
synthesis of organophosphorus compounds. Pure Appl Chem. 2012;84:439–459.
[53] Alonso F, Moglie Y, Radivoy G, Yus M. Solvent- and catalyst-free regioselective hydrophospha-
nation of alkenes. Green Chem. 2012;14:2699–2702.
[54] Malysheva SF, et al. Facile non-catalyzed synthesis of tertiary phosphine sulfides by regioselec-
tive addition of secondary posphine sulfides to alkenes. Eur J Org Chem. 2014;2014:2516–2521.
[55] Malysheva SF, et al. Catalyst- and solvent-free addition of P(Se)-H species to alkenes: a
straightforward access to tertiary phosphine selenides. Synthesis. 2014;46:2656–2662.
[56] Gusarova NK, Chernysheva NA, Yas’ko SV, Trofimov BA. Green synthesis of tertiary alkylse-
lanylphosphine chalcogenides via catalyst- and solvent-free addition of secondary phosphine
chalcogenides to vinyl selenides. J Sulfur Chem. 2015;36:526–534.
[57] Artem’ev AV, Chernysheva NA, Yas’ko SV, Gusarova NK, Bagryanskaya IYu, Trofimov BA.
Straightforward solvent-free synthesis of tertiary phosphine chalcogenides from secondary

JOURNAL OF SULFUR CHEMISTRY
13
phosphines, electron-rich alkenes and elemental sulfur or selenium. Heteroatom Chem.
2016;27:48–53.
[58] Trofimov BA, Brandsma L, Arbuzova SN, Malysheva SF, Gusarova NK. Nucleophilic addition
of phosphine to aryl- and hetarylethenes. A convenient synthesis of bis(2-aralkyl)- and bis(2-
hetaralkyl)phosphines. Tetrahedron Lett. 1994;35:7647–7650.
[59] Malysheva SF, Gusarova NK, Belogorlova NA, Kashik TV, Krivdin LB, Fedorov SV. One-pot
vinylation of secondary phosphine chalcogenides with vinyl sulfoxides. Phosphorus, Sulfur
Silicon Relat Elem. 2010;185:1838–1844.
