M. Carda, J. A. Marco et al.
quot was rechromatographed for analytical purposes, which led to an en-
richment in the E isomer: colourless oil; 1H NMR: d = 7.35–7.25 (m,
5H), 5.75–5.65 (m, 1H), 5.55–5.45 (m, 1H), 4.80–4.65 (brs, 2H, OH),
4.62 (d, J=12 Hz, 1H), 4.48 (d, J=12 Hz, 1H), 4.35 (dt, J=8.5, 4 Hz,
1H), 4.30 (brq, J ~5 Hz, 1H), 3.80 (m, 1H), 3.52 (brq, J ~4.5 Hz, 1H),
2.80 (dd, J=15.7, 9.2 Hz, 1H), 2.56 (dd, J=15.7, 4.5 Hz, 1H), 2.15–2.00
(brm, 3H), 1.82 (m, 2H), 1.55–1.40 (m, 5H), 1.18 ppm (d, J=6.5 Hz,
3H); 13C NMR: d = 175.3, 138.2 (C), 133.5, 129.1, 128.4 (ꢄ2), 127.8 (ꢄ
2), 127.7, 73.2, 71.6, 70.2, 68.1 (CH), 70.8, 38.4, 34.7, 32.2, 26.1, 25.0, 23.0
(CH2), 23.3 ppm (CH3); IR: nmax = 3400–2500 (br, COOH), 1722 cmꢀ1
(C=O); HR ESMS: m/z: calcd for C21H30O5Na: 385.1991; found:
385.1989 [M+Na+].
Yields and relative proportions of the two lactones depended on the re-
action time as indicated in Scheme 4.
When compound (Z)-17 was subjected to the same reaction conditions
with catalyst Ru-II (reaction time 16 h), 19 was formed in 76% yield
(based on recovered starting material) together with unreacted (Z)-17.
1
19: colourless oil; H NMR (signals from the major E isomer): d = 7.35–
7.25 (m, 5H), 5.45–5.30 (m*, 2H), 4.87 (m, 1H), 4.68 (d, J=12 Hz, 1H),
4.38 (d, J=12 Hz, 1H), 4.03 (brdt, J ~13, 4.5 Hz, 1H), 3.97 (brd, J
~11.5 Hz, 1H), 3.28 (brs, 1H), 2.77 (dd, J=14, 12 Hz, 1H), 2.68 (brq, J
~12 Hz, 1H), 2.30 (m, 1H), 2.20–1.90 (brm, 5H), 1.80–1.60 (brm, 4H),
1.17 ppm (d, J=6.5 Hz, 3H) (* the signals of each of the two olefinic pro-
tons may be interpreted as double doublets, each peak being further sub-
divided by many small coupling constants of less than 2 Hz; this makes
the extraction of the individual J values difficult, see Supporting Informa-
tion); 13C NMR (signals from the major E isomer): d = 170.6, 138.5 (C),
133.3, 128.3 (ꢄ2), 127.9 (ꢄ2), 127.6, 125.0, 73.3, 72.3, 70.0, 67.3 (CH),
(1S,5S,11R,14S)-14-(Benzyloxy)-5-methyl-4,15-dioxabicycloACTHNUGRTNEUNG[9.3.1]penta-
dec-9E-en-3-one [(E)-17] and (1S,5S,11R,14S)-14-(benzyloxy)-5-methyl-
4,15-dioxabicyclo [9.3.1]pentadec-9Z-en-3-one [(Z)-17]: A solution of
acid 16 (E/Z mixture, 181 mg, 0.5 mmol) in dry THF (4 mL) was cooled
to 08C under N2. Then, triethylamine (700 mL, 5 mmol) and 2,4,6-trichlor-
obenzoyl chloride (470 mL, 3 mmol) were added dropwise, followed by
stirring at room temperature for 1.5 h. The reaction mixture was then di-
luted with dry toluene (100 mL) and added dropwise along 6 h over a so-
lution of DMAP (733 mg, 6 mmol) in dry toluene (250 mL) at 508C.
Work-up (extraction with EtOAc) and column chromatography on silica
gel (hexanes/EtOAc 19:1 to 9:1) furnished first (Z)-17 (29 mg, 17%) and
then (E)-17 (69 mg, 40%). Physical and spectral properties of both com-
pounds described in ref. [6].
70.5, 39.3, 35.0, 34.0, 31.6, 22.1, 21.5 (CH2), 21.2 ppm (CH3); IR: nmax
=
1728 cmꢀ1 (C=O); HR ESMS: m/z: calcd for C21H28O4Na: 367.1885;
found: 367.1886 [M+Na+].
A
(20):
Asymmetric allylation of aldehyde 9 was carried out under the same con-
ditions followed for the preparation of 12, except that (+)-Ipc2BCl was
now the chiral reagent. Column chromatography on silica gel (hexanes/
EtOAc 9:1) afforded alcohol 20, still contaminated with boron-containing
side products, which was used as such in the next step. An aliquot was
carefully purified for analytical purposes: colourless oil. [a]D = ꢀ20.9 (c
= 2, CHCl3); 1H NMR: d = 7.75–7.70 (m, 4H), 7.50–7.30 (brm, 11H),
5.85 (ddt, J=17.2, 10.3, 7 Hz, 1H), 5.20–5.10 (m, 2H), 4.72 (d, J=
11.5 Hz, 1H), 4.56 (d, J=11.5 Hz, 1H), 3.85 (dd, J=10.6, 5.5 Hz, 1H),
3.74 (dd, J=10.6, 5 Hz, 1H), 3.65–3.55 (m, 2H), 2.30–2.25 (m, 1H), 2.20–
2.15 (m, 1H), 2.00 (brs, 1H, OH), 1.80–1.70 (m, 2H), 1.60–1.50 (m, 2H),
1.14 ppm (s, 9H); 13C NMR: d = 138.7, 133.5 (ꢄ2), 19.2 (C), 135.6 (ꢄ4),
134.9, 129.6 (ꢄ2), 128.3 (ꢄ2), 127.8 (ꢄ2), 127.7 (ꢄ4), 127.5, 79.5, 70.6
(CH), 117.8, 72.0, 66.1, 41.9, 32.4, 27.7 (CH2), 26.9 ppm (ꢄ3) (CH3); IR:
nmax = 3415 cmꢀ1 (br, OH); HR ESMS: m/z: calcd for C31H40O3SiNa:
511.2644; found: 511.2645 [M+Na+].
(1S,5S,11,14S)-14-Hydroxy-5-methyl-4,15-dioxabicycloACTHNUTRGNE[NUG 9.3.1]pentadec-
9E-en-3-one (aspergillide B, 2): A solution of lactone (E)-17 (62 mg,
0.18 mmol) was dissolved in CH2Cl2/H2O 10:1 (15 mL) and treated with
DDQ (1.22 g, 5.4 mmol). The reaction mixture was stirred for 20 h at
room temperature. Work-up (extraction with CH2Cl2) and column chro-
matography on silica gel (hexane/EtOAc 7:3) furnished 2 (24 mg, 51%).
Physical and spectral properties described in ref. [6] (see also correction).
(S)-Hept-6-en-2-yl 2-[(2S,3S,6R)-3-(benzyloxy)-6-(prop-1E,Z-enyl)tetra-
hydro-2H-pyran-2-yl]acetate (18):
A solution of acid 5 (174 mg,
0.6 mmol) in dry THF (15 mL) was cooled to 08C under N2. Then, trie-
thylamine (210 mL, 1.5 mmol) and 2,4,6-trichlorobenzoyl chloride
(188 mL, 1.2 mmol) were added dropwise, followed by stirring at room
temperature for 2 h. Alcohol 4 (82 mg, 0.72 mmol) and DMAP (183 mg,
1.5 mmol) were dissolved in dry THF (9 mL) and added slowly via sy-
ringe to the reaction mixture, with further stirring for 16 h at room tem-
perature. Work-up (extraction with Et2O) and column chromatography
on silica gel (hexanes/EtOAc 19:1) furnished 18 (174 mg, 75%) as a ca.
9:1 E/Z mixture: colourless oil; 1H NMR (signals from the major E
isomer): d = 7.35–7.25 (m, 5H), 5.85–5.60 (m, 2H), 5.50–5.40 (m, 1H),
5.05–4.90 (m, 3H), 4.60 (d, J=12 Hz, 1H), 4.55–4.40 (m, 2H), 4.20 (m,
1H), 3.58 (m, 1H), 2.76 (dd, J=15.2, 9 Hz, 1H), 2.60 (dd, J=15.2, 5 Hz,
1H), 2.05 (m, 2H), 1.95–1.60 (brm, 3H), 1.69 (brd, J ~6.2 Hz, 3H), 1.60–
1.30 (brm, 5H), 1.29 ppm (d, J=6.3 Hz, 3H); 13C NMR (signals from the
major E isomer): d = 171.5, 138.4 (C), 138.5, 130.8, 128.3 (ꢄ2), 127.6 (ꢄ
2), 127.5, 127.4, 73.7, 70.9 (ꢄ2), 70.6 (CH), 114.7, 70.7, 35.4, 34.1, 33.5,
27.7, 24.6, 23.6 (CH2), 20.0, 17.8 ppm (CH3); IR: nmax = 1730 cmꢀ1 (C=
O); HR ESMS: m/z: calcd for C24H34O4Na: 409.2355; found: 409.2357
[M+Na+].
AHCTUNGTRENGN(UN 4S,7S)-7-Benzyloxy-8-(tert-butyldiphenylsilyloxy)-4-(triethylsilyloxy)oct-
1-ene (21): The silylation of alcohol 20 was carried out under the same
conditions followed for alcohol 12. Column chromatography on silica gel
(hexanes/Et2O 49:1) furnished 21 (69% overall yield from 9). Colourless
oil. [a]D = ꢀ10.5 (c = 2.4, CHCl3); 1H NMR: d = 7.75–7.70 (m, 4H),
7.45–7.30 (brm, 11H), 5.82 (ddt, J=17.2, 10.3, 7 Hz, 1H), 5.10–5.00 (m,
2H), 4.68 (d, J=11.7 Hz, 1H), 4.54 (d, J=11.7 Hz, 1H), 3.78 (dd, J=
10.6, 5.5 Hz, 1H), 3.75–3.65 (m, 2H), 3.53 (m, 1H), 2.25–2.20 (m, 2H),
1.65–1.45 (m, 4H), 1.10 (s, 9H), 0.98 (t, J=8 Hz, 9H), 0.62 ppm (q, J=
8 Hz, 6H); 13C NMR: d = 139.1, 133.6 (ꢄ2), 19.2 (C), 135.6 (ꢄ4), 135.2,
129.6 (ꢄ2), 128.2 (ꢄ2), 127.7 (ꢄ2), 127.6 (ꢄ4), 127.4, 80.0, 72.0 (CH),
116.7, 71.9, 66.3, 41.9, 32.5, 27.3, 5.1 (ꢄ3) (CH2), 26.9 (ꢄ3), 7.0 ppm (ꢄ3)
(CH3); HR ESMS: m/z: calcd for C37H54O3Si2Na: 625.3509; found:
625.3510 [M+Na+].
AHCTUNGTRENGN(UN 4S,7S)-7-Benzyloxy-8-(tert-butyldiphenylsilyloxy)-4-(triethylsilyloxy)oct-
2E,Z-ene (22): The double-bond isomerization in olefin 21 to yield 22
was carried out under the same conditions followed for the conversion of
8 into 7. Column chromatography on silica gel (hexanes/Et2O 49:1) gave
22 (88%) as a ca. 9:1 E/Z mixture: colourless oil. 1H NMR: d = 7.75–
7.70 (m, 4H), 7.50–7.30 (brm, 11H), 5.55–5.45 (m, 1H), 5.40–5.30 (m,
1H), 4.65 (d, J=11.8 Hz, 1H), 4.50 (d, J=11.8 Hz, 1H), 4.00 (m, 1H),
3.73 (dd, J=10.6, 3.5 Hz, 1H), 3.64 (dd, J=10.6, 4.4 Hz, 1H), 3.50 (m,
1H), 1.65 (brd, J ~6.3 Hz, 3H), 1.65–1.40 (brm, 4H), 1.05 (s, 9H), 0.92
(t, J=7.7 Hz, 9H), 0.57 ppm (q, J=7.7 Hz, 6H); 13C NMR (signals from
the major E isomer): d = 139.1, 133.6 (ꢄ2), 19.2 (C), 135.6 (ꢄ4), 134.7,
129.6 (ꢄ2), 128.2 (ꢄ2), 127.7 (ꢄ2), 127.6 (ꢄ4), 127.4, 125.3, 80.0, 73.6
(CH), 72.0, 66.3, 34.1, 27.3, 5.0 (ꢄ3) (CH2), 26.8 (ꢄ3), 17.5, 6.9 ppm (ꢄ3)
(CH3); HR ESMS: m/z: calcd for C37H54O3Si2Na: 625.3509; found:
625.3502 [M+Na+].
Ring-closing metathesis of 18: a) With catalyst Ru-I: Grubbs ruthenium
catalyst Ru-I (16.5 mg, ca. 0.02 mmol) was dissolved under N2 in dry, de-
oxygenated CH2Cl2 (90 mL). After heating the solution to reflux, diene
18 (39 mg, ca. 0.1 mmol) dissolved in dry, deoxygenated CH2Cl2 (10 mL)
was added slowly via syringe (within 1 h) to the reagent solution. The re-
action mixture was then additionally stirred at reflux for 2 h. After cool-
ing to room temperature, the reaction was quenched through addition of
DMSO[46] (75 mL) followed by stirring overnight. Removal of all volatiles
under reduced pressure and column chromatography of the residue on
silica gel (hexanes/EtOAc 19:1 to 9:1) yielded first (Z)-17 (16.5 mg,
48%) and then (E)-17 (11 mg, 33%).
b) With catalyst Ru-II: the reaction was carried out under the same con-
ditions as above. Column chromatography on silica gel (hexanes/EtOAc
19:1 to 9:1) gave first (Z)-17 and then 19 as a ca. 85:15 E/Z mixture.
AHCTUNGTERG(NNUN 2S,5S)-2-(Benzyloxy)-oct-6E,Z-ene-1,5-diol (23): Desilylation of com-
pound 22 was carried out under the same conditions followed for the
preparation of 13. Column chromatography on silica gel (hexanes/EtOAc
