Angewandte
Chemie
DOI: 10.1002/anie.201002751
Asymmetric Catalysis
Asymmetric Nozaki–Hiyama Propargylation of Aldehydes:
Enhancement of Enantioselectivity by Cobalt Co-Catalysis**
Dmitry L. Usanov and Hisashi Yamamoto*
The addition of organochromium reagents to carbonyl com-
pounds, pioneered by Nozaki and Hiyama in late 1970s, has
been an important tool in contemporary organic synthesis
because of a number of unique features, such as mild reaction
conditions, high chemoselectivity, and compatibility with a
wide range of functional groups.[1,2] However, the necessity to
use superstoichiometric amounts of toxic chromium reagents
was among the major drawbacks. In 1996 Fꢀrstner and Shi
reported the first example of this reaction being catalytic in
chromium, which turned Nozaki–Hiyama chemistry into a
more environmentally benign methodology.[3] This seminal
report gave rise to a number of asymmetric applications of
catalytic Nozaki–Hiyama (NH) processes.[4]
However, the existing methods involve relatively high
catalyst loadings (10 mol%); as such, the development of a
protocol employing lesser amounts of chromium would be
highly desirable. In addition, room for improvement with
respect to enantioselectivity still remains for a range of
substrates. For instance, for aromatic aldehydes, enantiose-
lectivities exceeding 80% ee have not been achieved using
NH methodology.
Recently, our group developed a tethered bis(8-quinoli-
nato) (TBOx) chromium complex 1,[11] which was successfully
used as a highly stereoselective catalyst for asymmetric
pinacol coupling,[12] asymmetric NH allylation[13] and allenyl-
ation[14] of aldehydes, as well as for the asymmetric synthesis
of 1,3-butadien-2-ylcarbinols (Scheme 1).[15] In light of these
applications, we envisioned that 1 could potentially be used as
a catalyst in asymmetric NH propargylation reactions.
Chiral homopropargyl alcohols are among the products
which are potentially accessible using NH methodology. Most
of the asymmetric methods that provide access to these
compounds involve the use of chiral allenyl reagents.[5]
A
number of enantioselective procedures involving achiral
allenyl species have also been reported.[6] A catalytic enan-
tioselective NH propargylation reaction is thus an advanta-
geous alternative to these approaches owing to the ready
availability of propargyl halides as the propargyl moiety
sources.[7]
The first examples of enantioselective NH propargylation
were reported by Cozzi, Umani-Ronchi, and co-workers and
involved the use of chromium complexes derived from chiral
salen ligands (10 mol%, up to 56% ee).[8] In 2004, Inoue and
Nakada described a superior procedure involving a tridentate
carbazole ligand (10 mol%), which furnished most of the
products with 51–82% ee (the catalyst showed exceptional
enantiocontrol for pivalaldehyde, 98% ee).[9] Recently Kishi
and co-workers reported the implementation of NH prop-
Scheme 1. TBOx derivatives used in Nozaki–Hiyama chemistry.
We started our studies using the conditions previously
used for other NH processes:[12,13] 0.5 mmol of benzaldehyde,
3 equivalents of manganese, 1 equivalent of TESCl, and
1.5 equivalents of propargyl bromide were mixed in 2 mL of
solvent in the presence of 3 mol% of 1 for 40 hours at room
temperature. A solvent screen demonstrated that only a
limited number of solvents were suitable for the propargyla-
tion reaction; tetrahydrofuran appeared to be superior to the
majority of other common solvents (60% conversion after
40 h, 67% ee). Interestingly, 2-methyltetrahydrofuran showed
a slight increase of enantioselectivity compared to tetrahy-
drofuran (72% ee). However, the latter was used as a solvent
for the further preliminary screening experiments for reasons
of convenience.
argylation into the total synthesis of halichondrin.[10]
A
number of homopropargyl alcohols were obtained in 55–
94% yield and 46–93% ee using chiral sulfonamide ligands;
the scope of the study was mostly focused on aliphatic
substrates.
[*] D. L. Usanov, Prof. Dr. H. Yamamoto
Department of Chemistry, The University of Chicago
5735 South Ellis Avenue, Chicago, IL 60637 (USA)
Fax: (+1)773-702-0805
Tuning the size of the silyl group of the product scavenger
led to a bell-shaped dependence: increasing the size first
resulted in an enhancement of the enantioselectivity (Table 1,
entries 1–3); however, bulkier silyl chlorides (Table 1,
entries 4 and 5) furnished the product with inferior ee
values. An inverse dependence of the reactivity on the size
of the scavenger was observed over the tested range. These
E-mail: yamamoto@uchicago.edu
[**] This work was made possible by the generous support of the NSF
(CHE-0717618). We thank Dr. Guoyao Xia and Dr. Marina Naodovic
for their involvement in the preliminary stage of this project.
Supporting information for this article is available on the WWW
Angew. Chem. Int. Ed. 2010, 49, 8169 –8172
ꢀ 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
8169
