ylation of alkyl radicals with CO under high pressure (up to
80 atm).[5e] Although this approach is effective toward gen-
eration of branched acyl radicals, the applicability is limited to
unsubstituted cyclic alkanes because of an issue with site
specificity in generating carbon radicals from substituted
cyclic or acyclic alkanes. More recently, Caddick and co-
workers have taken the aldehyde auto-oxidation approach to
generate acyl radicals.[8] However, this approach was effective
only for linear aldehydes, and issues such as low reactivity,
major decarbonylation of acyl radicals, as well as prolonged
reaction times, with respect to branched aldehydes, need to be
addressed.
ation of acyl radicals from branched aldehydes and its
subsequent trapping with electrophiles have not been pre-
viously developed to a synthetically useful level.[11] To our
delight, catalytic use of DIB (4a) under the irradiation by
visible light gave the hydroacylation product 7a in 32% yield
with high selectivity for ketone formation (7a/8a = 8.0:1;
entry 1). Only trace amounts of reaction products were
detected in the absence of 4a (entry 2) or visible light
(entry 3) under the given conditions. These results strongly
indicate that the reaction undergoes a radical pathway, thus
generating acyl radicals in the reaction mixture. In addition,
the reaction can be conveniently conducted using pyrex
glassware, so use of an expensive quartz reactor is not
necessary. We also investigated other iodine(III) catalysts
(4b–e; entries 4–7), and found that 4b and 4e gave satisfac-
tory results (entries 4 and 7), whereas 4c and 4d exhibited
lower reactivity and selectivity (entries 5 and 6). In general,
we prefer the use of 4e because of the high solubility in
CH3CN. Use of a light source containing a short-wavelength
UV light (100 W high-pressure mercury lamp or l = 365 nm
black light) accelerated the overall reaction rate, however, it
increased the amount of the alkylated product 8a (entries 8
and 9). Among the various solvents screened, CH3CN
provided the best result. The concentration of the reaction
mixture is also important for obtaining the high yield as well
as selectivity, and indeed use of a more concentrated CH3CN
(1.6m) solution significantly enhanced both the selectivity
(> 24:1) and the yield (89%) in favor of 7a (entry 10).
Lowering the catalyst loading decelerates the reaction
progress, however, high yield was obtained with a prolonged
reaction time (entry 11).
We believe the key to minimizing the decarbonylation of
branched acyl radicals lies in an appropriate choice of radical
À
catalyst, which can effectively activate the C(O) H bond
under mild reaction conditions. Accordingly, we are inter-
ested in the possibility of using hypervalent iodine(III)
catalysts,[9] which easily undergo photodecomposition by
weak UV light or visible light to furnish iodanyl and carboxyl
radicals, for the smooth generation of acyl radicals.[10]
To probe the potency on the effective use of hypervalent
iodine(III) reagents with visible light, the hydroacylation
reaction between 2-ethylbutyraldehyde (5a) and dimethyl
maleate (6a) was investigated (Table 1). The in situ gener-
Table 1: Hydroacylation of 2-ethylbutylaldehyde with dimethyl maleate by
hypervalent iodine(III) catalysts (4a–e).[a]
With the optimum reaction conditions in hand, we
examined the applicability of other branched aldehydes as
well as electrophilic olefins (Table 2). First, various branched
aldehydes were screened against dimethyl maleate. None of
the alkylated product 8b was obtained in the reaction with
cyclohexanecarbaldehyde (5b), thus giving the hydroacyla-
tion product 7b almost exclusively in 98% yield. In contrast,
the same reaction using an aerobic protocol gave a mixture of
7b and 8b in 56 and 21% yield, respectively, after ten days.[8c]
Introduction of a heteroatom into the cyclohexane ring can be
tolerated (7c), and does not affect stereocenters on hetero-
cyclic rings (7d). The alteration of ring geometry has no effect
on the yield (7e). It is noteworthy that the stereocenter in
endo-5e was maintained during the reaction, thus giving
endo-7e in nearly quantitative yield. 2-Ethylhexanal was
previously reported to give a significant amount of the
alkylated product 8 f.[8c] However, the extremely high prefer-
ence for the hydroacylation product 7 f was observed when
using our mild approach. No benzylic oxidation of the
substrate 5g was observed under the given reaction con-
ditions (7g). Having confirmed the tolerance to various
branched aldehydes, we screened substituted alkenes having
distinct geometries as well as different electrophilicities. The
high selectivity toward hydroacylation appears to be inde-
pendent of the alkene geometry, as dimethyl fumarate (6h;
R3 = R6 = H; R4 = R5 = CO2Me) resulted in high selectivity
for hydroacylation (7h). No alkylation was observed with the
trisubstituted alkene 6i (R3 = H; R4 = Me; R5 = R6 = CO2Et),
Entry
Catalyst
Yield [%][b]
7a/8a[c]
1
2
4a
none
4a
4b
4c
32
8.0:1
n.d.
n.d.
trace
trace
39
24
11
3[d]
4
8.1:1
7.9:1
7.6:1
8.1:1
3.2:1
5.3:1
>24:1
>24:1
5
6
7
8
9
10
11
4d
4e
41
4e[e]
4e[f]
4e
>98
97
89 (82)[h]
83
4e[i]
[a] Unless otherwise specified, reaction of 5a (0.75 mmol) and 6a
(0.5 mmol) was conducted in the presence of the catalyst 4 (10 mol%) in
CH3CN (0.5m) with irradiation by visible light under the given
conditions. [b] Yield was obtained for crude reaction mixture of 7a and
8a by 1H NMR spectroscopy using 1,1,2,2-tetrachloroethane as internal
standard. [c] The ratio of the hydroacylation versus alkylation product
was obtained by 1H NMR spectroscopy using 1,1,2,2-tetrachloroethane
as an internal standard. [d] Reaction in the dark. [e] Use of 100 W
mercury lamp in quartz reactor. [f] Use of l=365 nm black light.
[g] Reaction in 1.6m CH3CN. [h] Yield of isolated product. [i] Reaction
with 5 mol% 4e for 20 h.
