Modulating Hydrogen-Bond Basicity within the Context of Protein-Ligand
Binding: A Case Study with Thrombin Inhibitors That Reveals a Dominating
Role for Desolvation
a,b*
a,c
a*
Nader N Nasief , Ahmed M Said , and David Hangauer
a
Department of Chemistry, University at Buffalo, The State University of New York, Buffalo,
b
NY 14260, The Division of Pharmaceutical Chemistry, National Organization for Drug Control
c
and Research (NODCAR), Giza, Egypt, Pharmaceutical Organic Chemistry Department,
Faculty of Pharmacy, Helwan University, Ein Helwan, Helwan, Egypt
KEYWORDS: Thrombin, protein-ligand binding, desolvation, bioisosterism, hydrogen bond,
*
cooperativity, nonadditivity, B3LYP/6-31G
ABSTRACT
Understanding subtle aspects of hydrogen bonding is a challenging but crucial task to improve
our ability to design ligands with high affinity for protein hosts. To gain a deeper understanding
of these aspects, we investigated a series of thrombin inhibitors in which the basicity of the
ligand’s group that accepts an H-bond from Gly216 was modulated via bioisosterism; e.g., a
C=O acceptor was made electron deficient or rich via bioisosteric replacements of the adjacent
moiety. Although the ligand’s binding affinity was anticipated to improve when the H-bond
basicity is increased (due to stronger H-bonding with the protein), we herein present data that
unexpectedly revealed an opposite trend. This trend was attributed to a dominating role played
by desolvation in determining the relative binding affinity. For example, a decrease in the H-
bond basicity reduces the desolvation penalty and, as experimentally observed, improves the
binding affinity, given that the reduction in the desolvation penalty dominates the change in the
contribution of the ligand’s H-bond with the protein. The current study, therefore, reveals that
desolvation can be a major underlying cause for the apparently counterintuitive structure-activity
relationship (SAR) outcomes, and indicates that understanding this factor can improve our ability
to predict binding affinity and to design more potent ligands.
*
Correspondences should be addressed to N N N at nnnasief@yahoo.com or D H at hangauer@buffalo.edu
1

ACCEPTED MANUSCRIPT
1
. Introduction
The discovery of novel small molecules with specific biological activity is generally a
challenging task that often involves synthesizing a large number of chemical compounds in order
to obtain a lead molecule suitable for further development and optimization. One of the major
causes for this problem is our insufficient understanding of protein-ligand binding and how such
binding is affected by various structural aspects of the designed molecules. This significantly
impedes our ability to accurately predict binding affinity, and, in turn, causes extensive
experimentation to be the only reliable approach to discriminate between biologically active and
inactive compounds. Studies that investigate the intricate molecular aspects of protein-ligand
binding are therefore crucial for the field of drug discovery. Recently, various aspects of protein-
ligand binding, such as cooperativity [1-5], the role played by water networks and the
hydrophobic effect in binding [2][6-7], as well as enthalpy-entropy compensation [7], have been
extensively studied using two model biological systems: thermolysin and thrombin.
Thrombin is a serine protease that plays an important role in the coagulation cascade. Thrombin
is implicated in pathological coagulation that characterizes several thromboembolic diseases,
such as pulmonary embolism, stroke, and heart attacks. These diseases, collectively, are a
leading cause of mortality and morbidity, particularly among elderly patients [8]. Thrombin
inhibition, therefore, provides a validated approach for anticoagulation therapy; and over the past
decades, there have been significant efforts to discover small molecules that act as direct
thrombin inhibitors [9-11]. These efforts have resulted in the introduction of dabigatran, a direct
thrombin inhibitor, into the market as a prophylaxis to reduce the risk of thromboembolism [12].
Thrombin is an excellent model system to study protein-ligand binding, consequently, it is used
herein to investigate subtle aspects of hydrogen bonding that could, and frequently do, result in
unpredictable structure-activity relationships (SARs). Hydrogen bonding presented itself as a
major non-covalent interaction that is heavily involved in all of the binding aspects we have
previously studied [1-7]. Variations in the hydrogen bonding ability of different H-bond forming
groups, which is termed hydrogen-bond basicity in the case of H-bond acceptors, can
significantly affect protein-ligand binding. In the current study, the hydrogen-bond basicity in a
series of closely related thrombin inhibitors was modulated via bioisosteric replacements. The
2

ACCEPTED MANUSCRIPT
influence of such modulation on the binding affinity was then investigated and correlated to the
desolvation of the H-bond acceptor groups. The study presented herein and similar studies are
important for improving our understanding of protein-ligand binding in general, and the binding
of thrombin to its inhibitors in particular, which, in turn, could lead to a more efficient design of
direct thrombin inhibitors.
1
.1. Bioisosterism and hydrogen-bond basicity
Bioisosteric replacement of certain functional groups is an extensively used strategy for
optimizing lead compounds in terms of their biological activity, pharmacokinetic properties, and
toxicological profile [13-14]. Bioisosteres are substituents or groups that have chemical or
physical similarities, and which can produce broadly similar biological properties [15]. There are
two types of bioisosterism: classical [16-17] and nonclassical [18]. Classical isosteric
replacement includes replacements in which the isosteric atoms/groups have peripheral layers of
electrons that can be considered similar (e.g. –CH -, -NH-, -O-, and –S-) [19-20]. Nonclassical
2
bioisosterism, however, includes broader functional group replacements, which do not satisfy the
classical electronic requirements but can produce similar biological activities. Examples of
nonclassical bioisosteric replacements are the replacement of C=O with SO , COOH with
2
tetrazole, etc.
<
Insert Figure 1>
One of the bioisosteric replacements that can be carried out in previously reported thrombin
inhibitors [1][4] is the replacement of the C=O group, which accepts an H-bond from the –NH–
2
group of the thrombin Gly216 residue (Figure 1), with an SO moiety, which is anticipated to
also accept an H-bond from Gly216 (an amide-sulfonamide bioisosterism). This replacement
could be desirable in terms of improving the metabolic stability of a lead compound;
consequently, it is a common bioisosteric replacement in drug discovery. It is, however, difficult
to accurately predict the relative change in binding affinity caused by such replacement. For
example, in the most straightforward cases of protein-ligand binding, the H-bond formed by the
SO group needs to be at least as energetically favorable as that formed by the C=O in order to
2
maintain or improve binding affinity. This largely depends on many electronic and geometric
parameters that are difficult to evaluate quantitatively (e.g., the relative basicities of the
3

ACCEPTED MANUSCRIPT
bioisosteres; the H-bond distance, angles, etc.). In other cases, however, additional parameters,
such as desolvation, need to be taken into account. These parameters could significantly affect
the outcome of bioisosteric replacements of an H-bonding group, but are difficult to evaluate
quantitatively as well.
As noted above, one of the parameters that influence the contribution of an H-bond to the
binding free energy is the basicity of the H-bond acceptor. In order to rank various H-bond
acceptors according to their relative basicities, several H-bond basicity scales were proposed,
β
such as the pKHB and the logK scales [21-22]. Although an H-bond basicity scale is normally
constructed against a common reference H-bond donor that forms 1: 1 H-bonded complexes with
the acceptor series, there are basicity scales that were built against multiple donors [23], and
scales that considered solutes with polyfunctional acceptor moieties [24]. Recently, a numerical
database, the pKBHX database, was built based on the 4-fluorophenol basicity scale in a manner
that also took into account the difference in basicity among multiple basic sites in a
polyfunctional base [25].
Although the pKBHX database could be useful in determining the relative ability of various basic
groups to accept H-bonds, a correlation between H-bond basicity and biological activity is still
difficult to establish. This might be because there is a dearth of relevant literature examples, in
which the relationships between H-bond basicity and biological activity are systematically
explored [25-26]. One of the distinct features of the current study is that it explores the concept
of H-bond basicity in the context of protein-ligand binding. For example, the C=O→SO2
replacement described herein modulates the ligand basicity towards Gly216. Additionally, such
basicity can be modulated via bioisosteric replacements of groups that are adjacent to the
C=O/SO (e.g., CH CO→CF CO). The series of inhibitors investigated in the current study,
2
3
3
hence, provides a unique opportunity to evaluate the relationship between binding affinity and
the H-bond basicity. In the following sections, we describe the rationale behind the bioisosteric
replacements we carried out in the current study, as well as the synthesis and the evaluation of
various inhibitors in thrombin biochemical assay.
1
.2. Thrombin inhibitors with modulated H-bond basicity towards Gly216
Insert Figure 2>
<
4

ACCEPTED MANUSCRIPT
In order to lay a foundation for this study, the contribution of the C=O group in the thrombin
inhibitors shown in Figure 1 to the binding free energy was examined and subsequently used as a
reference when the C=O was bioisosterically replaced. This information can be obtained via
comparing the binding free energies of ligands 1 and 2 (Figure 2). Although data for these
ligands were previously reported [27], the ligands were resynthesized and retested for the sake of
consistency of the data presented herein. As shown in Figure 2, ligand 1 does not have the C=O
which accepts an H-bond from Gly216; rather it has a CH . In contrast, ligand 2 has this C=O.
2
As a consequence of these structural features, the binding free energy contribution of the C=O
that forms an H-bond with Gly216 (relative to CH
2
) was determined by calculating ∆Gligand-2 -
∆Gligand-1 (i.e. the differential binding energy ∆∆GCH2→CO), and was found to be -3.2 kJ/mol.
<Insert Scheme 1>
Scheme 1 describes the design of the thrombin inhibitors studied herein. Firstly, the C=O group
of 2 was bioisosterically replaced with SO to give ligand 3. While the SO group is likely to
2
2
form an H-bond with the NH of Gly216, the strength of this H-bond might not be the same as
that formed by the C=O, because, based on the pKBHX database, the SO is predicted to be a
2
weaker H-bond acceptor (e.g., sulfonamides are less basic than amides) [25]. Secondly, the H-
bond basicities of both the C=O and the SO were further modulated through bioisosteric
2
replacements of adjacent groups. For example, in Scheme 1, the Me group of the terminal acetyl
in 2 was replaced by FCH , F CH, CF , and NH to give ligands 4, 5, 6, and 7, respectively. The
2
2
3
2
substitution of fluorines onto the α-C (e.g., 4, 5, and 6) was anticipated to decrease the basicity of
the C=O via an electron withdrawing effect, whereas the replacement of Me with NH in 7 was
2
expected to have an opposite influence on the C=O basicity. Similarly, the Me of the MeSO in 3
2
was replaced by CF and NH to give 8 and 9, respectively.
3
2
2
In order to further investigate the increase in the basicity of the C=O, the α-CH group in the
previously reported thrombin inhibitors, 10 and 11 [27], was replaced by O to give 12 and 13,
and by NH to give 14 and 15. This set of compounds is particularly important because it provides
2
a systematic comparison among the CH , O, and NH substitutions. This comparison is not
possible without an R side chain, such as the ones indicated in Scheme 1, because a carbamic
acid analogue of 2 (and 7) is not stable. In addition, compounds 10, 11, 14, and 15, together with
2
and 7, offer a basis for investigating the relationship between the R side chain, which binds in
5

ACCEPTED MANUSCRIPT
2 2
the S3 pocket, and the CH →NH/NH→CH replacement, with regard to additivity/cooperativity
of their contribution to the binding affinity/free energy. It should be emphasized herein that the
main questions the outlined design probes are whether modulating the H-bond basicity in various
ways would affect the binding affinity, and in what manner. To the best of our knowledge, the
compounds illustrated in Scheme 1 represent the largest set of systematically modified analogs
that investigate the effect of gradually altering the ligand’s tendency to form hydrogen bonds on
the binding affinity.
2
. Results and Discussions
2
.1. Chemistry
<
Insert Scheme 2>
Ligands 1, 2, 3, 4, 5, 6, 9, 10, 11, 14, and 15 were synthesized starting with the commercially
available -proline benzyl ester hydrochloride, which was reacted with a number of reagents as
follows (Scheme 2):
L
(
1) With ethyl iodide at 80°C in anhydrous DMF, and in the presence of potassium carbonate as
a base (N-alkylation). This was followed by hydrogenation of the product in methanol using
Pd-C as a catalyst to yield intermediate 1i, which was then used to synthesize ligands 1.
(
2) With either methanesulfonyl chloride or aminosulfonyl chloride in anhydrous DCM, and in
the presence of triethylamine (TEA) as a base. This was followed by hydrogenation of the
products in methanol using Pd-C as a catalyst to yield intermediates 3i and 9i, which were
used to synthesize ligands 3 and 9, respectively.
(
3) With either fluoroacetic acid, 3,3-dimethylbutyric acid, or hydrocinnamic acid in anhydrous
DMF using EDCI/HOBt as the coupling reagents and diisopropylethylamine (DIEA) as the
base. This was followed by hydrogenation of the products in methanol using Pd-C as a
catalyst to yield intermediates 4i, 10i, and 11i, which were used to synthesize ligands 4, 10,
and 11, respectively.
(
4) With either acetic anhydride, difluoroacetic anhydride or trifluoroacetic anhydride in
anhydrous pyridine. This acylation step was followed by hydrogenation of the products in
6

ACCEPTED MANUSCRIPT
methanol using Pd-C as a catalyst to yield intermediates 2i, 5i, and 6i, which were used to
synthesize ligands 2, 5 and 6, respectively.
(
5) With either tert-butyl isocyanate or benzyl isocyanate in anhydrous DCM, and in the
presence of TEA as a base. This was followed by hydrogenation of the products in methanol
using Pd-C as a catalyst to yield intermediates 14i and 15i, which were used to synthesize
ligands 14 and 15.
<Insert Scheme 3>
Intermediates 1i, 2i, 3i, 4i, 5i, 6i, 9i, 10i, 11i, 14i, and 15i were converted to the final products
via coupling these intermediates with 4-(aminomethyl)-benzonitrile hydrochloride using
EDCI/HOBt as coupling reagents and DIEA as a base, treating the products with hydroxylamine
hydrochloride (to give the N-hydroxybenzamidines), and stirring the N-hydroxyamidines with
acetic anhydride in glacial acetic acid followed by hydrogenation using Pd-C as a catalyst
(Scheme 2). Similarly, but starting with the commercially available 7i, 12i, and 13i, ligands 7,
1
2, and 13 were synthesized by coupling starting materials with 4-(aminomethyl)-benzonitrile
hydrochloride and treating the coupling products with hydroxylamine hydrochloride in presence
of DIEA (Scheme 3). The N-hydroxybenzamidine were then converted to the final products via
either hydrogenation using Pd-C as a catalyst (e.g., 7 and 12) or reduction using zinc dust in
glacial acetic acid (e.g., 13).
Ligand 8 was synthesized starting with the commercially available L-Proline-tert-butyl ester,
which was treated with trifluoromethanesulfonyl chloride in presence of TEA. The resulting tert-
butyl ester was exposed to trifluoroacetic acid at room temperature to yield the corresponding
acid, 8i. The acid was then coupled to 4-(aminomethyl)-benzonitrile hydrochloride, and the
product was treated with hydroxylamine hydrochloride to give the corresponding N-
hydroxybenzamidine. The final product was then obtained via stirring the N-
hydroxybenzamidine with acetic anhydride in glacial acetic acid and hydrogenation using Pd-C
as a catalyst (Scheme 4).
<Insert Scheme 4>
7

ACCEPTED MANUSCRIPT
It should be noted that all the final compounds were purified by reverse-phase HPLC to at least
9
5% purity.
2
.2. Thrombin inhibition data
All the ligands reported herein were tested for thrombin inhibition using a kinetic photometric
assay [28]. The assay was carried out in a 20 mM Hepes buffer, which contains 0.154 M NaCl, at
pH 7.4 using Pefachrome-tPA as a substrate. NaCl was included in the assay buffer as a source
+
of Na , which is the most important allosteric thrombin modulator that is required for enzyme
+
+
activation (i.e., Na -bound ‘fast’ thrombin has higher activity than Na -free ‘slow’ thrombin)
+
[
29-30]. The concentration of the Na in the assay buffer is the same as its concentration in the
plasma water (154 mEq/L). Initially, the IC50 values for the tested ligands were determined using
dose-response curves. These values were then utilized to obtain the inhibition constants “K ’s”
i
using the Cheng-Prusoff equation [31], and the inhibition constants were used to calculate the
binding free energies “ꢀG’s” of the tested ligands using the equation ꢀG = RTlnK . The K
i
i
values and their corresponding binding free energies are listed in Table 1. It is worth noting that
even though both the K and ꢀG values are reported in Table 1, in the following sections, we will
analyze relative/differential binding free energies among pairs of compounds; consequently,
more emphasis is placed on the free energy values, rather than the K ’s.
i
i
<Insert Table 1>
2
.3. The Replacement of the -C=O group with a -SO - functionality
2
As illustrated in Scheme 1, the C=O group of each of 2, 6, and 7 was replaced with SO
2
to give
3
, 8, and 9, respectively. Table 1 reveals that, in each pair of compounds (2/3, 6/8, and 7/9), there
is not much difference in binding affinity/free energy caused by the C=O→SO replacement. For
2
example, 2 and 3 have exactly the same K and ꢀG values. 6/8 and 7/9 show only differences in
i
an average range of 2-fold decrease or increase in K , which is translated into about 2.0 kJ/mol
i
2
average free energy change. Notably, the C=O→SO replacement is slightly favorable when an
electron withdrawing group, such as the -CF , is adjacent to the H-bond acceptor (e.g. (∆Gligand-8
-
3
∆
Gligand-6) or ∆∆GCF3CO→CF3SO2 = -1.6 kJ/mol: Ligand 8 with CF SO is more favorable than
3 2
ligand 6 with CF CO by 1.6 kJ/mol). On the contrary, an electron donating group, such as NH ,
3
2
8

ACCEPTED MANUSCRIPT
2
slightly favors the C=O over the SO (e.g. (∆Gligand-9 - ∆Gligand-7) or ∆∆GH2NCO→H2NSO2 = +2.5
kJ/mol: Ligand 7 with H NCO is the one that is more favorable by 2.5 kJ/mol).
2
2
Data, therefore, indicate that the contribution of the SO to the binding affinity is almost the
same as the contribution of the C=O. For instance, in the case presented herein, as previously
noted, the net favorable contribution of the ligand’s hydrogen bonding with the NH of Gly216 is
3
.2 kJ/mol no matter whether the acceptor is C=O or SO , e.g., ∆∆GCH2→SO2 (∆Gligand-3 - ∆Gligand-
2
1)
= ∆∆GCH2→CO = -3.2 kJ/mol. Is this what the H-bond basicity scale for these two groups
predicts? Applying the basicity scale, with only the direct ligand interactions with thrombin in
mind, one would most likely predict an outcome that is different from what was experimentally
2
observed. For example, according to the pKBHX database, the SO is not as good of an H-bond
acceptor as the C=O is [25]. Also, in the PDB database, it has been found that the SO group
2
possesses the dual nature of a weakly polar group that can accept an H-bond, and also a
hydrophobic moiety that can exist in close proximity to aliphatic carbon atoms [32]. Considering
protein-ligand interactions as the sole, or the major, determinant of binding affinity would
2
therefore lead to the incorrect prediction that the SO , for instance in 3, would cause a reduction
in binding affinity. This is, however, not what was observed in the binding affinity data. On the
contrary, as will be shown, an in-depth analysis of the other factors that influence binding could
lead to a correct prediction of the binding affinity consequences of the C=O→SO
replacement.
2
<
Insert Figure 3>
In a C=O/SO comparison, one of the factors that need to be considered is whether the H-bonds
2
formed by the C=O and the SO have similar geometric parameters, because these parameters
2
affect the contribution of an H-bond to the binding affinity. For example, an optimum H-bond
would form with a specific distance between the donor and the acceptor atoms, a certain angular
preference with regard to the donor-hydrogen-acceptor angle, and a tendency for the H-bond to
form along the direction of the donated lone pair of the acceptor [32]. The geometric parameters
for the H-bond accepted by the C=O from Gly216 were therefore investigated using PDB ID:
2
ZI2, which is a crystallographic complex between thrombin and a ligand similar to 2 except for
a terminal butyryl side chain replacing the acetyl moiety. The ligand of this crystal structure was
changed to ligand 2, in-silico, through truncating the butyryl to acetyl and minimizing the acetyl
group. The H-bond parameters were as follows: NH--O = 3.00 Å (N to O heteroatom distance),
ꢀ
9

ACCEPTED MANUSCRIPT
∠N-H-O = 164°, and
ꢀ
2
∠H-O-C = 160° (Figure 3a). Would a SO moiety retain these parameters?
In order to answer this question, a modeling study was performed in which methanesulfonyl
replaced the acetyl in ligand 2’s constructed protein-ligand complex. Several conformations for
the methansulfonyl group were then generated and minimized while the rest of the ligand (and
the protein) were kept constrained. The minimized conformation that retains geometric
parameters closest to those of the acetyl group was selected for further investigations. A protein-
ligand complex with the ligand’s methansulfonyl adopting this conformation demonstrated the
following geometric parameters: NH--O = 2.83 Å (N to O heteroatom distance), ∠N-H-O =
1
66°, and ∠H-O-S = 139° (Figure 3b). Because these parameters are very close to those of the H-
bond formed by the acetyl group, it can be concluded that the SO is able to form an H-bond with
2
Gly216 that is topologically similar to the H-bond formed by the C=O. Given this similarity,
would the contributions of the two H-bonds to the protein-ligand interaction component of the
binding free energy (or enthalpy) be also similar?
To address this question, two model systems were constructed for the purpose of quantum
mechanical (QM) calculation of the energy of the H-bond accepted by the ligand from Gly216
(Note: energy in the context of QM calculations represents enthalpy rather than free energy).
One of these models, A , consisted of N,N-dimethylacetamide hydrogen bonded to N-
1
methylformamide [33]. The other, B , consisted of N.N-dimethyl methanesulfonamide bound to
1
the same N-methylformamide (Models A and B represent ligands 2 and 3, respectively,
1
1
accepting H-bonds from Gly216: Table 2). These models were subjected to PM3 [34] and
*
B3LYP/6-31G [35] calculations in order to determine their equilibrium geometries and energies.
The intermolecular interaction energies between the two components of each model (i.e., the N-
methylformamide and the N.N-dimethyl methanesulfonamide) were then calculated and were
assumed to represent the energies of the H-bonds we are interested in, because, in each model,
the investigated H-bond is the major intermolecular interaction in the system. Energy was found
to be 31.80 kJ/mol in case of the acetyl moiety and 19.08 kJ/mol in case of the methanesulfonyl
(the acetyl forms a stronger H-bond: Table 2). A stronger H-bond formed by the C=O could be
attributed to an increase in the availability of the unshared pair of electrons of the C=O due to
resonance, which is known to be greater in amides than in sulfonamides. QM calculations are
therefore in agreement with the notion that a sulfonamide SO is not as good of an H-bond
2
acceptor as an amide C=O, and had non-covalent protein-ligand interactions been the sole
10

ACCEPTED MANUSCRIPT
determinant of the binding affinity, ligand 3 would have been significantly less active than 2.
What then causes the SO to be as good as the C=O in terms of contribution to the binding
2
affinity?
First, it is important to note that the binding affinity/free energy contribution of a ligand
functional group is the sum of the contributions of multiple factors of which non-covalent
interactions formed between this group and the biological target is one. For example, the amount
of binding free energy contributed by a ligand functional group encompasses also a contribution
from the desolvation of the part of this group that is buried into the formed complex, as well as
contributions from any change induced by this group in the conformation, ionization, and/or
hydration status of any other group or amino acid residue in the protein-ligand complex.
Desolvation is particularly important in the case presented herein because, as Hunter previously
noted, the cost of desolvation nearly cancels out the effect of H-bond formation [36]. This is
apparent in the case of the activity improvement shown by the introduction of the carbonyl H-
bond acceptor into the ligand (CH →C=O). This improvement amounts to only 3.2 kJ/mol (i.e.,
2
∆∆GCH2→CO), which is significantly smaller than, for example, the H-bond energy calculated in
the N,N-dimethyl-acetamide model (i.e., 31.80 kJ/mol). It is likely, therefore, that most of the
contribution of the H-bond formed between ligand 2 and Gly216 is canceled out by the
desolvation penalty of the C=O. Similar cases in protein-ligand binding have been previously
reported. For example, Morgan and co-workers reported that, in thermolysin inhibitors, NH- and
2
CH -analogues have almost the same activity because the benefit of the H-bond formed by the
NH was canceled out by the desolvation penalty [37].
<Insert Table 2>
As previously described, the C=O is a better H-bond acceptor than the SO in the context of
2
protein-ligand binding, consequently, it can be hypothesized that the C=O should also be a better
H-bond acceptor in the context of an unbound hydrated ligand. It follows that the C=O would
most likely be harder to desolvate than the SO , or, in other words, the C=O would have a larger
2
desolvation penalty. This larger desolvation penalty could cancel out most of the additional
benefit contributed to binding by the H-bond formed between the C=O and Gly216. In order to
test this hypothesis, and to confirm that the C=O is a better H-bond acceptor towards water, the
N,N-dimethylacetamide and the N,N-dimethyl methanesulfonamide test molecules were used
11

ACCEPTED MANUSCRIPT
w w
again to construct two QM models (models A and B ), but, this time, instead of being bound to
N-methylformamide, each molecule is bound to a water molecule through a single H-bond. The
*
energy of the H-bond in each model was calculated using the B3LYP/6-31G method, and was
2
found to be -28.16 kJ/mol in case of the C=O and -20.56 kJ/mol in case of the SO (Table 2).
Calculations, therefore, indicate that, as expected, the C=O is a better H-bond acceptor towards
water. As a consequence, the desolvation penalty of a C=O group is likely larger than that of a
SO . We, hence, deal with two H-bond acceptor groups: one (i.e., C=O) forms a stronger H-bond
2
with the protein that would contribute more favorably to the binding affinity/free energy were it
2
not for a larger desolvation penalty that cancels out this contribution; and the other (i.e. SO )
forms a weaker H-bond that does not contribute as favorably to binding but does not cost as
much in terms of desolvation energy either. Consequently, the experimental data, which
demonstrate that the net contributions of the C=O and the SO to the binding affinity are
2
equivalent, can be rationalized if we look beyond the concept of noncovalent protein-ligand
interactions and take into account desolvation.
It should be noted, however, that the analysis presented herein is qualitative, not quantitative,
i.e., the calculations performed are not meant for a precise determination of, for example, the
desolvation penalty; rather, they were used to reveal qualitative trends. This is simply because,
although energy calculations may be correlated with enthalpy, they do not take into account
entropic factors. For instance, the -31.80 and -28.16 kJ/mol calculated for the H-bonds of the
acetamide models should not be interpreted as the actual amounts that should be added to, or
subtracted from, the binding free energy as a consequence of the presence of a hydrogen bonding
group in the ligand. The actual contribution to the binding free energies would be much smaller
because each of these calculated values is associated with a compensatory opposing entropic
contribution (e.g., binding which is favorable in terms of enthalpy is associated with motion
restriction which is unfavorable in terms of entropy). Previously, we have reported that up to
8
0% of the enthalpy associated with hydration water is compensated by entropy [7]. This means
that, for example, the -28.16 kJ/mol interaction energy, or enthalpy, calculated in model A is
w
likely compensated by about +22.53 kJ/mol entropy, and the amount left over (i.e., -5.63 kJ/mol)
is what may be subtracted in the binding free energy master equation [2] as a result of the C=O
desolvation. Calculations presented in this paper should therefore be considered within the
12

ACCEPTED MANUSCRIPT
context of enthalpy-entropy compensation effects, which often reduce the net contributions to the
associated free energy changes.
2
.4. The influence of adjacent bioisosteric replacements on the basicity of H-bond acceptors
Insert Figure 4>
<
According to the H-bond basicity rule, replacing the Me adjacent to the H-bond acceptor moiety
with a more electron withdrawing group (e.g. mono, di, and trifluoromethyl) is anticipated to
reduce the availability of the acceptor’s lone pair of electrons and, in turn, decrease the tendency
to accept H-bonds (Scheme 1). If the free energy contribution of the acceptor were solely
governed by the favorable contribution of hydrogen bonding with Gly216, we would experience
a gradual decrease in activity going from ligand 2 to ligands 4, 5, and 6, which would be
attributable to reducing the basicity and the strength of the H-bond accepted from Gly216.
Similarly, ligand 8 would be anticipated to be less active than 3. Surprisingly, an opposite trend
was experimentally observed. For instance, as demonstrated in Table 1 and Figure 4, activity
increases going from ligand 2 to 4, 5, and 6 (e.g., ∆G goes from -23.8 to -24.9, -27.1, then -27.8
kJ/mol: a negative shift indicates an improvement in activity). Also, ligand 8 was found to be
more active than 3, with a differential binding energy ∆∆GCH3SO2→CF3SO2 (∆Gligand-7 - ∆Gligand-2) of
-5.6 kJ/mol, an order of magnitude improvement if activity is expressed in terms of inhibition
constants.
The same trend of going against the potential direct correlation between the H-bond basicity and
the binding affinity was observed when an electron donating group is introduced next to the
acceptor moiety. For example, at first glance, it could be anticipated that 7 and 9 would be more
active than 2 and 3, respectively, because of the ability of the NH to donate electrons through
2
2
resonance to the C=O and the SO , and, thereby, to reinforce the hydrogen bonding properties of
these acceptors. Experimentally, however, as shown in Figure 4, there is no such improvement in
activity, e.g., the -0.3 kJ/mol improvement in the activity of 7 relative to 2 is insignificant. Even
9
was found to be less active than 3 by +2.2 kJ/mol (a positive ꢀꢀG indicates a decrease in
activity; +2.2 kJ/mol is equivalent to about 2-fold on the K scale). Because these data are not
i
sufficient to formulate a solid conclusion with regard to the influence of electron donating
substitutions on the binding affinity, the triads 10/12/14 and 11/13/15 were also investigated.
13

ACCEPTED MANUSCRIPT
2
Data in Figure 4 reveal that the replacement of the α-CH with O or NH decreases activity. For
example, the replacement of CH with O decreases activity by +2.6 kJ/mol in the 10/12 pair, and
2
by +4.2 kJ/mol in the 11/13. The replacement of CH with NH, which is a more electron
2
donating group, decreases activity even more, e.g., by +5.3 kJ/mol in the 10/14 pair and by +7.5
kJ/mol in the 11/15. Based on these data, it can be concluded that bioisosteric replacements,
which involve the introduction of groups that can donate electrons (e.g., via resonance) to H-
bond acceptors, might decrease binding affinity despite the anticipated reinforcement of the H-
bonds formed with the protein. On the contrary, groups that are capable of withdrawing electrons
from H-bond acceptors might improve binding affinity. The trends revealed by this collection of
data are the opposite of what many medicinal chemists might anticipate to observe in SAR
studies, and are therefore important to understand in more depth.
<Insert Table 3>
These counterintuitive results motivated us to initially verify our original assumption that
adjacent electron withdrawing and donating groups respectively decrease and increase the H-
1 1
bond basicity of an acceptor moiety. To do so, QM models similar to models A and B (Table 3:
QM models L-P1) were constructed (as described in the experimental section) for ligands 4, 5,
and 6 to account for the “withdrawing” bioisosterism, as well as for 12/13 and 14/15 to account
for the “donating” bioisosterism (i.e., NH in 14/15 is a better donor than O in 12/13). These
*
models were subjected to PM3 and B3LYP/6-31G calculations in order to determine
equilibrium geometries and energies, and the intermolecular interaction energies between the two
components of each model were calculated and assumed to represent the energies of the H-bonds
we are interested in. Upon evaluating the trend of the interaction/H-bond energies in models A
1
,
C , D , and E , we noticed that the magnitude of the interaction/H-bond energy inversely
1
1
1
correlates with the number of the fluorine atoms on the α-C, and, consequently, with the electron
withdrawing effect exerted on the C=O (more fluorine atoms cause a stronger electron
withdrawing effect). Considering models F and G , we noticed that the presence of an NH,
1
1
which is a better electron donor than an O, causes an increase in the magnitude of the interaction
energy.
These results confirmed that an adjacent electron withdrawing group can indeed decrease the
hydrogen bonding basicity of an acceptor moiety resulting in a weaker H-bond with the protein
14

ACCEPTED MANUSCRIPT
(e.g. Gly216), whereas an electron donating group has an opposite effect. Because the binding
affinity data reveal an opposite trend (i.e., adjacent electron withdrawing and donating groups
cause an increase and a decrease in the binding affinity, respectively), it can be concluded that, in
the present case, biological activity is inversely correlated with the H-bond basicity of the
acceptor and with the strength of H-bond formed between the ligand and Gly216.
Secondly, we investigated if the strength of the H-bond formed by the acceptor moiety (e.g., the
C=O) is the only aspect of protein-ligand interaction that changes due to bioisosterism in an
adjacent group. This is important because any change in the contribution of protein-ligand
interaction to the binding affinity across a series of ligands is determined not by the change in the
strength of a single non-covalent interaction, such as the H-bond between the ligand and Gly216,
but by the net change in the overall protein-ligand interaction network. To investigate this, we
constructed new QM models which incorporate not only the NH of Gly216, as in models L-P1,
but also the C=O of this amino acid residue (e.g., models L-P2). This Gly216 C=O is the only
additional group that may be strongly influenced by the bioisosteric replacements of the ligand’s
2 3
α-CH /CH , given that no other group (e.g., besides the NH of Gly216) lies within a 5.00 Å
sphere centered on the ligand’s α-CH in the crystallographic construct of ligand 2. Models with
3
formylglycinamide instead of N-methylformamide as the protein representative (i.e., models L-
P2) should therefore be a reasonable compromise between accuracy and computational effort
when it comes to qualitative investigation of other aspects of protein-ligand interaction besides
hydrogen bonding to the NH of Gly216. Table 3 includes these models, which represent ligands
2
, 4, 5, and 6 (models A , C , D , and E , respectively), and the interaction energies associated
2 2 2 2
*
with them as calculated using the B3LYP/6-31G method.
As demonstrated in Table 3, the interaction energies calculated for these models (i.e., L-P2’s) are
significantly different from those of the corresponding L-P1 models. For example, comparing A1
to A , the magnitude of the interaction energy (i.e., E ) decreases from 31.80 to 22.67 kJ/mol,
2
int
most likely because of electrostatic repulsion caused by the close proximity of the Gly216 C=O
and the ligand’s C=O (Gly216-C=O--O=C-ligand 2 = 3.15 Å). Similarly, for ligands 4 and 5
(models C and D), the magnitude of Eint decreases going from L-P1 to L-P2, but to a lesser
extent, probably because the electron withdrawing effect of the increasing number of fluorine
atoms on the α-C decreases the electrostatic charge on the O of the ligand’s C=O (e.g., from -
15

ACCEPTED MANUSCRIPT
0
3 2 2
.57 (CH CO) to -0.52 (FCH CO) and then to -0.49 (F CHCO)) and, consequently, reduces the
O-O electrostatic repulsion. The end result is that variations in the magnitude of E observed in
int
models L-P1 among ligands 2, 4, and 5 are almost canceled out in models L-P2 (Table 3). In the
2
case of 6, the L-P2 model (i.e., E ) demonstrates dramatic decrease in the magnitude of Eint
relative to the corresponding L-P1 model (e.g., from -24.75 to -13.32 kJ/mol). This decrease
might be attributed to electrostatic repulsion between the additional fluorine on the α-C and the
C=O of Gly216 ((Gly216-C=O--F-CF -ligand 6 = 2.82 Å). This additional repulsive interaction
2
does not exist in any of ligands 2, 4, or 5, e.g., 4 and 5 likely adopt conformations in which the
fluorine atoms are far from the C=O of Gly216. In the case of 6, despite the significant decrease
in the magnitude of E in model E , this ligand is the most active among ligands 2, 4, 5, and 6;
int
2
consequently, it could be speculated that this ligand might have a different binding mode which
avoids the O--F repulsive interaction. To test this hypothesis, an X-ray crystal structure for this
ligand is needed, but this is beyond the scope of the current study. Overall, does the protein-
ligand calculated interaction energy correlate with the binding affinity? It appears from the data
included in Table 3 that there is no significant correlation. This is more visually depicted in
Figure S1 (supplementary data), which represents a plot between Eint for five L-P2 models and
2
ꢀ
G for the corresponding ligands. This figure demonstrates an R of 0.54, which indicates a
weak correlation at best.
If the binding affinity has no (or little) correlation with protein-ligand noncovalent interactions,
what then causes the observed trend in activity? The desolvation factor was investigated next, as
was previously done with ligands 2 and 3. We therefore constructed QM models, each of which
consists of a water molecule hydrogen bonded to an acylated N,N-dimethylamine (Table 3:
models L-W). The acyl group of the acylated N,N-dimethylamine was varied in-silico according
to the ligand each model represents (e.g., monofluoroacetyl in model C to represent 4;
w
w
difluoroacetyl in D to represent 5; etc.). Next, the interaction energy between the acylated N,N-
dimethylamine and the water molecule in each model (i.e., the H-bond energy) was calculated
*
using B3LYP/6-31G and the results are listed in Table 3. Data for models L-W reveal that,
among models A
w w w w
, C , D , and E , the model that possesses the most favorable H-bond energy
is A which represents 2 (-28.16 kJ/mol). H-bond energy, then, gradually becomes less favorable
w
as the fluorination of the α-C is increased (e.g. A
w w w w
→C →D →E : -28.16→-25.73→-23.42→-
2
1.19). These data are in agreement with what was observed in models L-P1, wherein successive
16

ACCEPTED MANUSCRIPT
fluorination of the α-C and the resulting increase in the electron withdrawing effect on the C=O
cause decease in the basicity and strength of the H-bond accepted by this C=O. Contrary to
models L-P1, this effect would impact the binding free energy in an inverse manner, e.g., a more
favorable H-bond with water is associated with a weaker binding (i.e., a less negative ꢀG)
because it signifies a larger desolvation penalty. Conversely, a less favorable H-bond with water
signifies a smaller desolvation penalty and would be associated with a better binding. This is
exactly what we observe in the 2, 4, 5, and 6 series, where 2, the weakest binder, demonstrates
the most favorable interaction with water (e.g., in model A ); and 6, the strongest binder,
w
w
demonstrates the least favorable interaction with water (e.g., in model E ). This trend can be
clearly perceived when ꢀG is plotted in Figure 5 against -Eint (representing the desolvation
w
penalty) for A , C
w w w
, D , E , and H
w
(an additional model representing the interaction of 7 with
2
water). First, this plot reveals a remarkable linear correlation between ꢀG and -E with an R
int
value of 0.92. Second, the correlation is positive (i.e., a positive slope), which means that when
the desolvation penalty increases, ꢀG increases, in other words, becomes less negative (i.e.,
weaker binding); and vice versa.
The data in Table 3 for models F and G also demonstrate that a more electron donating group,
w
w
such as an NH relative to an O isostere, causes a stronger H-bond with water (-31.68 vs. -28.46
kJ/mol), which translates into a larger desolvation penalty. As previously described, a larger
desolvation penalty results in a weaker binding, and this is what is experimentally observed in 12
vs. 14 and 13 vs. 15 (e.g., 14 and 15 are weaker binders than 12 and 13, respectively).
<
Insert Figure 5>
Overall, there are a number of conclusions that can be drawn based on the data presented in this
section. First, a decrease in the basicity of the C=O due to bioisosterism causes not only a
decrease in the strength of the H-bond formed with Gly216 in the protein-ligand complex, but
also a decrease in the strength of the H-bonds of this group with water and a subsequent
reduction in the desolvation penalty (and vice versa). Second, a change in the strength of the H-
bond formed with Gly216 in the protein-ligand complex is not the major determinant of the
associated change in the binding free energy within the series of the thrombin inhibitor studied
herein. Third, the change in desolvation penalty of the C=O dominates the differential/relative
binding free energy in this series of thrombin inhibitors and is therefore the factor that produces
17

ACCEPTED MANUSCRIPT
the inverse correlation that was observed between the H-bond basicity of the C=O and the
binding affinity. For example, the improvement in the binding free energy which accompanies
the reduction in the C=O basicity (e.g., 2→5) can be attributed to a reduction in the desolvation
penalty, and vice versa (e.g., 12→14). Fourth, the desolvation factor dominates the differential
binding because the change in the free energy contribution of the H-bond formed with Gly216 in
the protein-ligand complex can be masked by other changes caused by bioisosterism in the array
of the noncovalent protein-ligand interactions (e.g., 2 and 5). This masking effect occurs due to
spatial restrictions in the protein-ligand complex, which sometimes prevents groups with
unfavorable interactions from moving away from each other (e.g. the two C=O groups of the
ligand and Gly216). This is not likely to occur in the unbound state where water molecules can
freely move and adopt optimal positions. It should be noted that it is the change in the free
energy contribution of the H-bond that is being overcome by the change in the desolvation
contribution (e.g., in a series of ligands all of which can form this H-bond such as 2, 4, and 5),
not the H-bond’s contribution to ꢀG itself. When it comes to the absolute contributions of the H-
bond with Gly216 and the desolvation of the ligand’s H-bond acceptor, there is still enough
favorable contribution derived from the H-bond with Gly216 to overcome the desolvation
penalty even if this penalty might be large as in 2. Otherwise, there would be no free energy
benefit from having the C=O group in the ligand molecule, which is contrary to what was
experimentally observed in 2 vs. 1 (Figure 2). Overall, the data highlight the importance of
explicitly considering the desolvation differences among analogs in a SAR study. A further
analysis of the data presented herein would require X-ray crystal structures of several analogs,
but this is beyond the scope of the current study.
2
.5. Functional group cooperativity and bioisosterism
Functional group cooperativity, also termed nonadditivity or synergism/antagonism, is an
important concept in drug design and SAR studies. This is mainly because this phenomenon can
account for 1-2 or even 3 orders of magnitude unforeseeable increase in binding affinity. We
have previously studied functional group cooperativity in both thrombin [1][4] and thermolysin
[2-3] and discovered that cooperativity is a common finding in lead optimizations [3], which
should be taken into account in scoring functions [1][4], and which can arise from variations in
the free energy contributions of different players in the protein-ligand binding process [2]. Other
18

ACCEPTED MANUSCRIPT
cases of functional group cooperativity have been reported within the context of SAR studies
[38-42]. Functional group cooperativity can be described as the dependency of the functional
group contributions to the binding affinity on the structural features of the rest of the ligand
molecule. Notably, the ligand C=O group we are evaluating in the current study has previously
demonstrated cooperativity. For example, in bicyclic thrombin inhibitors, the contribution of this
group to the binding affinity was found to be -3.4 kJ/mol [43], which is the same as the
contribution we report herein. In pyrrolidine-based inhibitors with side chains capable of binding
in the S3 pocket, however, the contribution of this group was reported to range from -10.0 to -
2
3.0 kJ/mol [4][44-45]. Given that cooperativity is a common phenomenon in SAR studies,
albeit typically not recognized as such, it was expected that cases of cooperativity would be
discovered in the course of our investigation into the concepts of bioisosterism and H-bond
basicity in thrombin inhibitors. In the supplementary materials of this paper, these cases of
cooperativity are outlined and evaluated through double mutant (double transformation) cycles.
It is important to note that the reason behind the reported cases of cooperativity is currently
under investigation and will be reported in due course.
3
. Conclusions
In this study, the basicity of the H-bond accepted by thrombin inhibitors from Gly216 was
modulated via bioisosteric replacement of either the C=O group, which accepts this H-bond, or
an adjacent group that influences the acceptor moiety electronically (via either electron
withdrawing or donating effect). A correlation between the basicity of the investigated H-bond
acceptor and the ligand’s binding affinity was surprisingly found to be absent in case of the C=O
replacement with SO . For example, ligands featuring an SO moiety, a weaker H-bond acceptor
2
2
than the C=O, are not significantly different in terms of binding affinity from their C=O
analogues. QM calculations revealed that this observed equipotency is largely due to a smaller
desolvation penalty in case of the SO , and a larger one that cancels out the stronger binding
2
contribution of the H-bond to Gly216 in case of the C=O.
Desolvation was also found to play a dominant role when the basicity of the H-bond acceptor is
modulated via bioisosteric replacement of an adjacent group. In this case a counterintuitive
inverse correlation between the binding affinity and the H-bond basicity, which could not be
19

ACCEPTED MANUSCRIPT
explained by modulating the strength of the ligand’s H-bond with the protein, was observed. This
inverse correlation could rather be explained only when desolvation is considered. For example,
a decrease in the H-bond basicity reduces the strength of the ligand’s H-bond(s) not only with the
protein but also with hydration waters in the unbound state. This, in turn, reduces the desolvation
penalty. If the effect on desolvation is more prominent than the effect on the direct protein-ligand
interaction, a decrease in H-bond basicity will be advantageous to the binding affinity (inverse
correlation). This explanation was supported by QM calculations wherein ligands with a more
favorable binding suffered less of an energy penalty from breaking their H-bonds with a probe
solvation water molecule, and vice versa. Furthermore, a plot of the ligand binding free energy
vs. the calculated energy for breaking such H-bonds with water yielded a linear relationship with
2
an R value of 0.92.
In summary, this study explores the interconnected roles of bioisosteric replacements, H-bond
basicity, and desolvation in the context of protein-ligand binding. The study, therefore,
contributes significantly to understanding important aspects of the structure activity relationships
of closely related analogues. Although the current study was carried out using thrombin as a
model system, the key findings of this study are likely to be applicable to many other protein-
ligand drug discovery systems. Three such findings are emphasized herein. First, bioisosterism,
an important concept in drug discovery, can yield counterintuitive experimental outcomes;
therefore, to predict the outcome of bioisosterism, it is crucial to investigate the changes caused
by bioisosteric replacements in the structural and thermodynamic features of both the complexed
and uncomplexed ligand systems, e.g., changes in the desolvation, conformational, or ionization
status. Second, desolvation is a key factor that, as in the present case, can correlate well with
binding affinity but in an unanticipated manner. More attention should therefore be paid to this
factor whenever unexpected SAR results are encountered. Furthermore, desolvation should be
accurately accounted for in binding affinity prediction algorithms (e.g., scoring functions) that
are used for in-silico screening of compound libraries. Third, QM models can be successfully
employed to study trends in binding affinity (or binding thermodynamics) and determine the
factor(s) that may be responsible for these trends. These calculations can also provide important
insights into effects that are rarely taken into account in drug design, such as polarizations and
charge redistributions.
20

ACCEPTED MANUSCRIPT
Notably, the findings presented herein point towards an improved molecular design methodology
wherein structural modifications that can reduce the ligand desolvation penalty are explicitly
considered when optimizing lead compounds. This methodology could significantly improve the
process of lead optimization, and might lead to the discovery of more potent ligands with
enhanced biological or therapeutic responses against relevant drug discovery targets.
4
. Experimental
4
.1. Biological assay
The inhibition constants of the thrombin inhibitors 1-15 were determined photometrically at 405
nm using Pefachrom tPa (CH SO -D-CHA-Gly-Arg-pNA.AcOH; DSM Nutritional Products Ltd
3
2
Branch Pentapharm, Switzerland) as a chromogenic substrate. The assay was performed using a
SpectraMax Plus 384 UV/VIS microplate spectrophotometer at 25 ± 0.2 ºC. The stock solutions
of the enzyme, substrate, and inhibitors were prepared from accurately weighted samples of
respective species. All the measurements were carried out in a buffer containing 0.02 M Hepes,
0
.154 M NaCl and a final DMSO concentration of 6.5 % at pH 7.4 ± 0.05. The enzyme
concentration in all the final assay solutions was approximately 8-12 nM, the substrate
concentration in the final assay solutions was 100 ꢁM, and the concentrations of each inhibitor
were in the range of 0.5 IC – 10 IC (a preliminary IC for each inhibitor was determined by
5
0
50
50
an initial screening). The assay was always initiated by adding the enzyme to a premixed
solution of the substrate and the inhibitor. The absorbance was then monitored kinetically every
2
0 s. for 30 min, and the reaction rate (OD/s) was used to construct a dose-response curve, which
was subsequently used to determine the IC value. GraphPad Prism was used for data fitting and
5
0
IC50 determination. Inhibition constants (K ’s) were then calculated from the experimentally
i
m
determined IC50’s using Cheng-Prusoff equation [31] (K = 289 ± 6 ꢁM), and were subsequently
employed to calculate the binding free energies (ꢀG’s) using the equation (ꢀG = RTlnK , R is
i
the gas constant and T is the temperature in Kelvin). The reported average inhibition constants
i
and binding free energies (K ’s and ꢀG’s) and their standard deviations were obtained from at
least three experimental measurements (e.g. triplicate) for each inhibitor.
4
.2. Molecular modeling and QM calculations
21

ACCEPTED MANUSCRIPT
4
.2.1. Construction of thrombin-2 and thrombin-3 model complexes
The crystal structure 2ZI2 was downloaded and used to construct the thrombin-2 model complex.
Atoms and molecules other than the protein and the ligand were deleted (e.g., water molecules).
Using SYBYL-X software, Tripos Inc., hydrogen atoms were added to both the ligand and the
protein. The atom and bond types as well as the protonation statuses for the ligand and the active
site residues were checked and modified as necessary. Gasteiger-Huckel charges for the ligand
and Kollman-All Atom charges for the protein’s atoms were then calculated. This was followed
by minimizing the added hydrogen atoms with Tripos force field using the default parameters
with the exception of using the charges that were previously loaded on the protein-ligand
complex atoms, and using a value of 80 for the dielectric constant. It should be noted that during
this minimization procedure, all the heavy atoms were kept constrained in order not to lose the
crystallographic information (e.g., ligand binding mode, conformations of flexible amino acid
residues, etc.). The ligand’s terminal butyryl was then replaced with an acetyl moiety through
deleting the γ-CH and the β-CH , and converting the α-CH to CH . Gasteiger-Huckel charges
3
2
2
3
were recalculated for the ligand; then the acetyl moiety, together with all the hydrogen atoms,
was minimized with Tripos force field as described above.
To construct the thrombin-3 model complex, the acetyl group in thrombin-2 construct was
replaced with methanesulfonyl. Gasteiger-Huckel charges were recalculated for the modified
ligand; then the methanesulfonyl, together with all the hydrogen atoms, was minimized with
Tripos force field as previously described (all other heavy atoms were kept constrained during
minimization). This was followed by generating several conformations for the methanesulfonyl
2
group via rotating the CH -N-S=O dihedral angle 30° at a time. Conformations that
demonstrated steric clashes with the protein were excluded, while other conformations were
minimized as described. For each minimized conformation, the distance NH--O (N to O
heteroatom distance) and the angles ∠N-H-O and ∠H-O-S were evaluated, and the model with
the conformation that demonstrated the closest H-bond distance and angles to those of the
thrombin-2 model was considered the final thrombin-3 model complex. It is worth mentioning
that the chosen model is the only model that satisfied all of the following criteria: NH--O = 3.00
±
0.20 Å, ∠N-H-O = 164 ± 10°, and ∠H-O-S = 160 ± 25°, noting that 3.00 Å, 164°, and 160° are
the NH--O, ∠N-H-O, and ∠H-O-C of the thrombin-2 model, respectively.
22

ACCEPTED MANUSCRIPT
4
.2.2. Construction of QM models and interaction energy calculations
Models A and A were constructed using coordinates derived from the thrombin-2 model
1
2
1
complex. Model B was constructed using coordinates derived from the thrombin-3 complex.
Equilibrium geometries were then calculated for the models using the semi-empirical PM3
method [34] (note: heavy atoms whose optimization was likely to significantly change the
crystallographic coordinates were constrained). Models L-P2 were constructed via replacing the
Me group in the MeCON(CH ) of model A with the corresponding variable moiety (e.g.,
3
2
2
2 2
FCH - F CH-, etc.). For each model, several conformations were generated for the variable
moiety via rotating the αC-CO bond 30° at a time. Duplicate conformations were ignored; e.g.
conformations of the CF
3
in E
2
degenerate into only two conformations. Each conformation was
*
then optimized using PM3, energy was calculated using B3LYP/6-31G method [35], and the
conformation that gives the lowest energy (most stable) model was retained and considered final.
Models C -E were constructed form the corresponding L-P2 models via truncating the protein
1
1
representative formylglycinamide to N-methylformamide. Models F and G were constructed
1
1
via initially replacing the acetyl in thrombin-2 with either methoxycarbonyl or
methylaminocarbonyl and optimizing these groups, then using the coordinates of resulting
protein-ligand complexes to build the QM models, which were further subjected to PM3
geometry optimization. Models L-W (e.g. A -H ) were built using the corresponding L-P1 or L-
w
w
P2 wherein the NH of the protein representative was used to guide placing the water molecule at
an H-bond distance from the ligand. Equilibrium geometries were then calculated using the semi-
empirical PM3 method. For each model, the interaction energy was calculated in the following
*
manner: first, total energy was calculated using B3LYP/6-31G method; second, the two
components of each model, A and B, were separated (e.g., each component in a file), and the
*
energy of each component was calculated using B3LYP/6-31G ; and, finally, the interaction
energy was calculated using the formula E = E – (E + E ), where E is the total energy of
int
tot
a
b
tot
the model, E is the energy of component A, and E is the energy of component B. All the QM
a
b
calculations were performed using Spartan software, Wavefunction, Inc.
4
4
.3. Chemistry
.3.1. General methods
23

ACCEPTED MANUSCRIPT
Reagents were obtained from commercial suppliers and used without further purification.
Anhydrous solvents were purchased as sealed bottles from either Fisher-Acros (AcroSeal) or
Aldrich (Sure-seal) and were maintained under an argon atmosphere. Dichloromethane (DCM)
was distilled from a calcium hydride still and used immediately. Solvent removal was performed
on a rotary evaporator equipped with a 20-60 °C water bath and a self-contained aspirator. Thin-
layer chromatography (TLC) was performed on Analtech (Newark, DE) 200 micron Silica Gel F
coated on polyethylene sheets. Visualization was accomplished with 254 nm UV light or iodine
staining. The silica gel used in the flash chromatography was 40-75 ꢁm flash grade purchased
from Sorbent Technologies (Atlanta, GA). All amino acids used are
L unless otherwise noted.
Proton and carbon nuclear magnetic resonance was performed in deuterated solvents purchased
from Cambridge Isotope Laboratories, Inc (Andover, MD) on one of the following instruments:
1
Varian Gemini 300 MHz, Varian Inova 400 MHz, or Varian Inova 500 MHz. H NMR data are
reported in the following format: chemical shift (ppm values in relation to TMS or the
appropriate solvent peak), multiplicity (s = singlet, d = doublet, t = triplet, q = quartet, dd =
doublet of doublet, dt = doublet of triplet, dq = doublet of quartet, m = multiplet, br s = broad
singlet), coupling constant(s), and integration. Whenever fractions of chemically equivalent
protons appear at widely-spaced chemical shifts, like when the compound exists in multiple
conformations, the chemical shifts are reported; followed by the multiplicity(ies) preceded by the
number of peaks (e.g. 2 s, 2 d, etc.), the coupling constant(s), and the sum of the integrations of
these peaks. Low resolution ESI mass spectrometry was performed on a Thermo Finnigan LCQ
Advantage instrument using 60% methanol in water with 1% acetic acid or 60% acetonitrile in
water with 0.1% trifluoroacetic acid as the mobile phase. Preparative and semi-preparative
HPLC instrumentation included a Milton Roy gm4000 gradient programmer, Milton Roy
Constametric I and III pumps, a Rheodyne 7125 injector with a 5.00 mL sample loop, and a
Knauer Variable Wavelength Detector set at 254 nm with a preparative flow cell. The HPLC
column used was a Phenomenex LUNA C18(2), 5 ꢁm, 100A pore, 21 mm X 250 mm with
Security Guard cartridge used with a flow rate of 8 mL/min. All final compounds used to acquire
biological data were at least 95% pure as determined by HPLC analysis.
4
.3.2. General procedure for sulfonamide and sulfonylurea formation
24

ACCEPTED MANUSCRIPT
A solution of the free amine (or its hydrochloride salt: 1.0 equiv.) and TEA (3.0 equiv.) in
anhydrous DCM was prepared, cooled to 0 °C, and stirred using a magnetic stir bar. A 0.36 M
solution of either methylsulfonyl chloride or aminosulfonyl chloride in anhydrous DCM was
gradually added to the amine solution (note: the amount of the added solution was calculated to
deliver 1.2 equiv. of the sulfonyl chloride to the reaction medium). The reaction mixture was
allowed to warm up to room temperature. It was then stirred for 8 h, diluted with ethyl acetate
(
50 mL for every 5 mL DCM) and extracted with 1 M HCl (3X), saturated sodium bicarbonate
3X), and brine (2X). The organic layer was then dried with anhydrous sodium sulfate and the
(
solvent was evaporated under vacuum to give the product. The products of this reaction were
used in the next step without further purification.
4
.3.3. General procedure for amide coupling
A solution or suspension of the carboxylic acid (1.0 equiv.), the free amine (or its hydrochloride
salt: 1.0-1.1 equiv.), EDCI.HCl (1.2 equiv.), and HOBt (1.2 equiv.) in anhydrous DMF was
prepared, cooled to 0 °C, and stirred using a magnetic stir bar. DIEA (2.2 equiv. in case of
coupling to a free amine and 3.3 equiv. in case of coupling to a hydrochloride salt) was gradually
added to this solution/suspension. The reaction mixture was then allowed to warm up to room
temperature, and was stirred overnight. This was followed by dilution with ethyl acetate (50 mL
for every 5 mL DMF) and extraction with 1 M HCl (3X), saturated sodium bicarbonate (3X), and
brine (2X). The organic layer was then dried with anhydrous sodium sulfate and the solvent was
evaporated under vacuum to give the product. The products of the amide couplings were purified
by flash chromatography or semi-preparative reverse phase HPLC whenever needed.
4
.3.4. General procedure for acylation using acid anhydride
Either the free amine or its hydrochloride salt (1.0 equiv.) was dissolved in a sufficient amount of
anhydrous pyridine. The solution was then cooled to 0 °C using crushed ice. The acid anhydride
(3.0 equiv.) was added to the amine solution gradually, and the reaction mixture was allowed to
warm up to room temperature. The mixture was then stirred for 5-7 h. This was followed by
dilution with ethyl acetate (50 mL for every 3 mL pyridine) and extraction with 1 M HCl (3X),
saturated sodium bicarbonate (3X), and brine (2X). The organic layer was then dried with
25

ACCEPTED MANUSCRIPT
anhydrous sodium sulfate and the solvent was evaporated under vacuum to give the product. The
products of this reaction were used in the next step without further purification.
4
.3.5. General procedure for benzyl ester deprotection
The ester was dissolved in methanol in a Parr flask. The flask was charged with 0.05 equiv. of
0% Pd/C, and was then put on a Parr hydrogenation apparatus. The flask was subjected to 3
1
charge/purge cycles with hydrogen gas, and was then charged with 50-55 psi hydrogen. The
reaction mixture was shaken overnight, then filtered using Celite. The flask and the Celite were
washed several times with methanol, and the methanol fractions were combined and evaporated
under vacuum to give the desired product, which did not normally need any further purification.
4
.3.6. General procedure for the conversion of benzonitrile derivatives to N-
hydroxybenzamidines
The benzonitrile derivative (1.0 equiv.) and hydroxylamine hydrochloride (3.0 equiv.) were
dissolved in anhydrous methanol and stirred for 15 min. DIEA (3.0 equiv.) was then added
gradually to the reaction mixture, and the mixture was stirred at room temperature overnight.
Upon the completion of the reaction, methanol was removed in vacuo, and the residue was taken
up in n-butanol. The n-butanol solution was washed with an equal amount of water (3X).
Acetonitrile was then added to the n-butanol fraction (three times the amount of the n-butanol),
and the solvents were removed under vacuum to give the desired product which was purified
with semi-preparative reverse phase HPLC. Alternatively, upon reaction completion, the mixture
was applied directly to semi-preparative reverse phase HPLC to separate the product in a pure
form.
4
.3.7. General procedure for the conversion of N-hydroxybenzamidines to benzamidines
using hydrogenation
The N-hydroxybenzamidine (1.0 equiv.) was dissolved in glacial acetic acid. Acetic anhydride
(3.0 equiv.) was then added, and the reaction mixture was stirred for 30 min. The mixture was
then transferred to a barr flask, which was charged with 0.05 equiv. of 10% Pd/C, and was then
put on a Parr hydrogenation apparatus. The flask was subjected to 3 charge/purge cycles with
hydrogen gas and then charged with 50-55 psi hydrogen. The reaction mixture was shaken
26

ACCEPTED MANUSCRIPT
overnight and then filtered using Celite to remove the Pd/C. Acetonitrile was then added to the
mixture (3 x the amount of the glacial acetic acid), and the solvents were removed under vacuum
to give the desired product, which was purified by reverse phase HPLC (e.g. using a mobile
phase that has 1% acetic acid).
4
4
.3.8. Synthesis of compounds 1, 2, 3, 8, 11, 13, and 15
.3.8.1. (S)-1-Ethylpyrrolidine-2-carboxylic acid (1i)
The commercially available
dissolved in 5.0 ml DMF. Anhydrous potassium carbonate (1.04 g, 7.5 mmol) and ethyl iodide
468 mg, 3.0 mmol) were added, and the mixture was heated to 80˚C and stirred overnight. Upon
reaction completion, the mixture was diluted with ethyl acetate (50 ml) and washed with water
2X) and brine (2X). The organic layer was then dried over anhydrous sodium sulfate and
L-proline benzyl ester hydrochloride (604 mg, 2.5 mmol) was
(
(
concentrated under vacuum. The residue was purified with reverse phase HPLC to give 420 mg
of the product (yield: 72%). The product obtained from this reaction, which is the benzyl ester of
1
i, was subjected to hydrogenation to remove the benzyl group according to the general
procedure for benzyl ester deprotection. 248 mg of the desired product (1i) was obtained and
1
used without further purification (96%). H NMR (DMSO-d
6
) δ 1.14 (m, 3H), 1.80 (m, 2H),
2
.02-2.41 (m, 4H), 2.75 (m, 2H), 4.18 (m, 1H), 10.70 (br, 1H); m/z (LCMS, ESI): found 144.1
+
+
[
M + H] ; [C H NO + H] requires 144.1
7 13 2
4
.3.8.2. (S)-N-(4-Carbamimidoylbenzyl)-1-Ethylpyrrolidine-2-carboxamide diacetate (1)
Following the general procedure for amide coupling, with only slight modifications, compound
1
i (243 mg, 1.7 mmol) was reacted with 4-(aminomethyl)benzonitrile hydrochloride (320 mg,
1
.9 mmol) in anhydrous DMF (5.0 mL), using EDCI.HCl (384 mg, 2.0 mmol) and HOBt (270
mg, 2.0 mmol) as coupling reagents, and DIEA (720 mg, 5.6 mmol) as a base. Modifications in
the general procedure for amide coupling included using n-butanol instead of ethyl acetate to
dilute the reaction mixture, and performing the extraction with 1 M HCl (2X) and water (2X).
3
6
01 mg of the benzonitrile derivative was obtained and used without further purification (yield:
9%). This product was then reacted with hydroxylamine hydrochloride (243 mg, 3.5 mmol) in
the presence of DIEA (450 mg, 3.5 mmol) according to the general procedure for the conversion
27

ACCEPTED MANUSCRIPT
of benzonitrile derivatives to N-hydroxybenzamidines. The N-hydroxybenzamidine (232 mg, 0.8
mmol) was then reacted with acetic anhydride (260 mg, 2.5 mmol) and hydrogenated according
to the general procedure for the conversion of N-hydroxybenzamidines to benzamidines. 258 mg
1
of the final product was obtained after purification with reverse phase HPLC (yield: 82%). H
NMR (CD OD) δ 1.39 (m, 3H) 1.81 (s, 6H), 2.20 (m, 3H), 2.59 (m, 1H), 3.24 (m, 2H) 3.75 (m,
3
1
3
2
H) 4.18 (m, 1H) 4.59 (s, 2H) 7.58 (d, J = 8.4 Hz, 2H) 7.82 (d, J = 8.4 Hz, 2H). C NMR
(
(
CD OD) δ 9.96, 22.6, 29.5, 42.5, 50.3, 54.2, 67.1, 127.9, 128.0, 144.8, 167.9, 174.1; m/z
3
+
+
LCMS, ESI): found 275.2 [M + H] ; [C H N O + H] requires 275.2
1
5
22
4
4
.3.8.3. (S)-1-Acetyl-pyrrolidine-2-carboxylic acid (2i)
Following the general procedure for acylation, the commercially available L-proline benzyl ester
hydrochloride (604 mg, 2.5 mmol) was reacted with acid anhydride (770 mg, 7.5 mmol) in
anhydrous pyridine (4.0 ml). 315 mg of the product was obtained (yield: 51%). The product
obtained from this reaction, which is the benzyl ester of 2i, was subjected to hydrogenation to
remove the benzyl group according to the general procedure for benzyl ester deprotection. 194
1
mg of the desired product (2i) was obtained and used without further purification (97%). H
NMR (CD OD) δ 2.06 (m, 6H), 2.27 (m, 1H), 3.50-3.69 (m, 2H), 4.43 (m, 1H); m/z (LCMS,
3
+
+
ESI): found 158.1 [M+H] , [C
.3.8.4. (S)-1-Acetyl-N-(4-Carbamimidoylbenzyl) pyrrolidine-2-carboxamide acetate (2)
Following the general procedure for amide coupling, with only slight modifications, compound
7 3
H11NO + H] requires 158.1
4
2
i (188 mg, 1.2 mmol) was reacted with 4-(aminomethyl)benzonitrile hydrochloride (222 mg,
1
.3 mmol) in anhydrous DMF (5.0 mL), using EDCI.HCl (276 mg, 1.4 mmol) and HOBt (194
mg, 1.4 mmol) as coupling reagents, and DIEA (510 mg, 4.0 mmol) as a base. Modifications in
the general procedure for amide coupling included using n-butanol instead of ethyl acetate to
dilute the reaction mixture, and performing the extraction with 1 M HCl (2X) and water (2X).
2
8
60 mg of the benzonitrile derivative was obtained and used without further purification (yield:
0%). The product was then reacted with hydroxylamine hydrochloride (200 mg, 2.9 mmol) in
the presence of DIEA (370 mg, 2.9 mmol) according to the general procedure for the conversion
of benzonitrile derivatives to N-hydroxybenzamidines. The N-hydroxybenzamidine (213 mg, 0.7
mmol) was then reacted with acetic anhydride (220 mg, 2.1 mmol) and hydrogenated according
28
