Synthesis and evaluation of strand and turn modified ring-extended
gramicidin S derivatives
Annemiek D. Knijnenburg a, Varsha V. Kapoerchan a, Gijsbert M. Grotenbreg a, , Emile Spalburg b,
Albert J. de Neeling b, Roos H. Mars-Groenendijk c, Daan Noort c, José M. Otero d,e, Antonio L. Llamas-Saiz f,
Mark J. van Raaij d,g, Bep Ravensbergen h, Peter H. Nibbering h, Gijs A. van der Marel a, Herman S. Overkleeft a,
Mark Overhand a,
⇑
a Leiden Institute of Chemistry, Leiden University, PO Box 9502, 2300 RA Leiden, The Netherlands
b National Institute of Public Health and the Environment, Laboratory for Infectious Diseases, PO Box 1, 3720 BA Bilthoven, The Netherlands
c TNO, Prins Maurits Laboratory, PO Box 45, 2280 AA Rijswijk, The Netherlands
d Departamento de Bioquímica y Biología Molecular, Facultad de Farmacia, Campus Vida, Universidad de Santiago, 15782 Santiago de Compostela, Spain
e Laboratoire des Proteines Membranaires, Institut de Biologie Structurale J. P. Ebel, 41 Rue Jules Horowitz, F-38027 Grenoble, France
f Unidad de Rayos X (RIAIDT), Laboratorio Integral de Dinámica y Estructura de Biomoléculas ‘José R. Carracido’, Edificio CACTUS, Campus Vida, Universidad de Santiago,
15782 Santiago de Compostela, Spain
g Laboratorio M-4, Departamento de Estructura de Macromoleculas, Centro Nacional de Biotecnologia, c/Darwin 3, Campus Cantoblanco, E-28049 Madrid, Spain
h Center for Infectious Diseases, Department of Infectious Diseases, Leiden University Medical Center, Leiden, The Netherlands
a r t i c l e i n f o
a b s t r a c t
Article history:
Received 25 February 2011
Revised 5 April 2011
Accepted 13 April 2011
Available online 22 April 2011
In this paper, we describe the crystal structure of previously reported ring-extended gramicidin S (GS)
derivative 2 (GS14K4), containing a
is in agreement with a previously reported modeling study of the same molecule. The polar side chain
of the additional -amino acid residue is positioned at the same face of the molecule as the hydrophobic
side chains, and we believe that because of this compound 2 is considerably less hydrophobic than
extended GS derivatives in which the strand regions are exclusively composed of -amino acids. Using
D-amino acid residue in one of the b-strand regions. This structure
D
L
Keywords:
this backbone structure as our benchmark we prepared a small series of ring-extended GS analogues fea-
turing sugar amino acid dipeptide isosteres of varied hydrophobicity at the turn region. We show that via
this approach hydrophobicity of extended GS analogues can be tuned without affecting the secondary
structure (as observed from NMR and CD spectra). Biological evaluation reveals that hydrophobicity cor-
relates to cell toxicity, but still bacteriolysis is induced with GS analogues that are too hydrophilic to effi-
ciently lyse human red blood cells.
Cationic antimicrobial peptides
Gramicidin S, GS14K4
Antibiotics
Secondary structure
Amphipathic peptides
Dipeptide isostere
Ó 2011 Elsevier Ltd. All rights reserved.
1. Introduction
two type II’ b-turns. The amino acid sequence and its secondary
structure render the molecule amphipathic with the cationic side
The increasing number of pathogenic bacteria that are resistant
to clinically applied antibiotics has led to a search for potent new
antibiotics with alternative targets.1 Cationic antimicrobial pep-
tides (CAPs) comprise a broad class of molecules that target the li-
pid bilayer of bacteria. Bacteria do not easily build up resistance
against such peptides,2 and therefore CAPs are considered as prom-
ising leads for the development of new antibiotics. A prominent
member of the CAP family is the cyclo-decapeptide gramicidin S
(GS) isolated from Aneurinibacillus migulans.3 Its secondary struc-
ture consists of a short antiparallel b-sheet interconnected by
chains oriented on one face of the b-sheet and the hydrophobic
side chains on the opposing face.4 The cationic amphipathic char-
acteristics of the peptide are responsible for its membrane disrupt-
ing properties, and GS is active against both Gram-positive and to a
lesser extent against Gram-negative bacteria.5 In combination with
the antibiotic agent framycetin, which targets Gram-negative bac-
teria, GS has proven to be an effective antibiotic against external
ear infections.6 The major drawback of GS, however, is that it is
hemolytic and therefore it is only used to treat topical infections.
Over the years many GS derivatives have been designed with the
aim to improve the therapeutic index, that is, decreasing hemolytic
activity while retaining potent antimicrobial activity.7 One promis-
ing strategy is modification of the b-turn region of the peptide with
unnatural amino acids8 or dipeptide isosteres.9 In this context,
sugar amino acids (SAAs) featuring a carboxylate and an amine10
⇑
Corresponding author. Tel.: +31 715274483; fax: +31 715274307.
E-mail address: overhand@chem.leidenuniv.nl (M. Overhand).
Present address: Department of Microbiology, National University of Singapore
CeLs, 28 Medical Drive, Singapore 117456, Singapore.
0968-0896/$ - see front matter Ó 2011 Elsevier Ltd. All rights reserved.
doi:10.1016/j.bmc.2011.04.031

A. D. Knijnenburg et al. / Bioorg. Med. Chem. 19 (2011) 3402–3409
3403
can be used to influence conformational behavior, and at the same
2. Results and discussion
2.1. Synthesis
time allow the introduction of additional functionalities and thus
modulation of the overall physical properties. An alternative strat-
egy to improve the therapeutic index of GS is to adjust the amphi-
pathic nature by modifying the b-strand regions.11 In this context,
the design and evaluation of tetradecameric GS analogues have
been reported, including derivatives containing six apolar and four
cationic residues. These appeared to behave as ring-extended GS
analogues in that they adopt stable cyclic b-hairpin conformations
in solution with altered amphipathicity.12 Kondejewski and co-
workers reported the substitution of several amino acids in both
the b-turn and b-strand regions without significantly changing sec-
The precursors of peptides 213a and 4 were assembled on the
highly acid sensitive HMPB–BHA-resin using a standard step-wise
solid phase Fmoc-based peptide synthesis protocol.15 After mild
acidic cleavage from the solid support, the linear peptides having
the basic side chains protected with Boc-groups were cyclized un-
der high dilution and purified using gel filtration. Boc deprotection
under strong acidic conditions and purification by preparative
HPLC afforded peptides 2 and 4. Peptides 8–10 were synthesized
according to a previous described procedure14 using the appropri-
ately functionalized SAA building blocks 1116 and 12 (Scheme 1).
SAA 12 was prepared by treating known SAA 11 with excess so-
dium hydride and 1.2 equiv of benzyl bromide (Scheme 1). SAAs
11 and 12 were coupled to preloaded HMPB-BHA-resin (13) yield-
ing peptide 14 and 15, respectively. After reducing the azide func-
tionalities using aqueous trimethylphosphine the sequences were
elongated by solid phase peptide synthesis after which the ensuing
linear peptides 16 and 17 were cleaved from resin and converted to
the cyclic peptides 18 and 19. The benzyl group in Boc-protected
peptide 19 were removed using 10% palladium hydroxide on char-
coal in a hydrogen gas atmosphere yielding Boc protected cyclic
peptide 20. Removal of the Boc protective groups of peptides 18–
20 was accomplished using trifluoroacetic acid in the presence of
triethylsilane and the target peptides were purified using prepara-
tive HPLC. Compounds 2, 4 and 8–10 were obtained in 25–40%
overall yield. Peptides 1, 3 and 5–7 were prepared as reported
previously.14
ondary structure characteristics.13 Single
D-amino acid substitution
of the fourth position in the b-strand of tetradecameric GS ana-
logues such as in 2 (GS14K413a, Figure 1), led to a compound with
a reported improved therapeutic index compared to the
acid substituted 1 (GS14, Fig. 1). Molecular modeling studies on
2 indicate that the inserted -amino acid in the sequence has no
L-amino
D
major influence on the cyclic b-hairpin secondary structure.
Recently, we reported the incorporation of furanoid SAAs as b-
turn mimetic in tetradecameric GS derivatives (3 and 5–7,
Fig. 1).14 NMR- and CD spectroscopy showed that these peptides
adopt cyclic b-hairpin structures. Variation of the substitution pat-
tern on the furanoid core provided derivatives that displayed an in-
creased antibacterial activity and reduced hemolytic activity
compared to 3. Compared to GS and 3, these analogues display en-
hanced antimicrobial activity against Gram-negative bacterial
strains. Because of these promising results we decided to synthe-
size tetradecameric GS parent compound 4 that contains an addi-
tional D-amino acid in the sequence and the furanoid SAAs b-turn
modified derivatives 8–10 (Fig. 1). The new peptides were sub-
jected to a detailed study of their structural features and these
were compared with those of 1–3 and 5–7. The entire series 1–
10 was evaluated for their bactericidal properties against an ex-
tended panel of bacterial strains, as well as their hemolytic
properties.
2.2. X-ray crystallography
Thus far no crystal structure of any cyclic tetradecameric GS
analogue has been reported. We were therefore pleased to see that
compound 2 gave crystals, which was used to determine the atom-
ic structure by high resolution X-ray crystallography. The side
chain of the
D
-lysine residue situated at the 4-position cleary re-
H
N
O
O
O
R2
H
N
H
N
H
N
N
H
N
H
N
H
N
O
OR3
O
O
O
R1
R1
R1
R1
O
OR4
O
O
O
H
N
H
N
H
N
N
O
N
N
H
N
H
O
H
R2
O
O
O
5
1, GS14: R1 = (CH2)4NH2, R2 = OH
, R1 = (CH2)3NH2, R2 = H, R3 = R4 = Bn
3
6, R1 = (CH2)3NH2, R2 = R4 = H, R3 = Bn
7, R1 = (CH2)3NH2, R2 = R3 = R4 = H
, R1 = (CH2)3NH2, R2 = H
O
O
H
O
H
N
R2
H
N
H
N
N
N
H
N
H
N
H
N
O
OR3
O
O
O
R1
R1
R1
R1
O
O
O
O
OR4
H
N
H
N
H
N
N
O
N
N
H
N
H
O
H
R2
O
O
O
2,
8
, R1 = (CH2)3NH2, R2 = H, R3 = R4 = Bn
9, R1 = (CH2)3NH2, R2 = R4 = H, R3 = Bn
10, R1 = (CH2)3NH2, R2 = R3 = R4 = H
GS14K4: R1 = (CH2)4NH2, R2 = OH
4, R1 = (CH2)3NH2, R2 = H
Figure 1. Structures of the tetradecameric Gramicidin S derivatives 1–4 and analogues with a SAA modified b-turn (5–10). Numbering of amino acids N ? C: cyclo-(Val1-
