Large-Size Linear and Star-Shaped
Dihydropyrazine Fused Pyrazinacenes
Chenhua Tong,† Wenguang Zhao,†,§ Jing Luo,†, Hongying Mao,† Wei Chen,†,‡
Hardy Sze On Chan,*,† and Chunyan Chi*,†
Department of Chemistry, National University of Singapore, 3 Science Drive 3,
Singapore, 117543, and Department of Physics, National University of Singapore,
2 Science Drive 3, Singapore, 117542
chmcsoh@nus.edu.sg (Chan); chmcc@nus.edu.sg (Chi)
Received November 17, 2011
ABSTRACT
Linear and star-shaped pyrazinacenes 1aꢀb and 2 were synthesized via condensation between a new building block 11 and pyrene tetraones or
cyclohexaone. Compound 2 represents the largest star-shaped dihydropyrazine fused pyrazinacene reported so far. These largely expanded
pyrazinacenes show good solubility and have a strong tendency to aggregate in both solution and thin films, indicating their potential applications
for organic electronic devices.
Acene derivatives have attracted much attention be-
cause of their applications as semiconducting materials
for organic electronic devices.1 Long acenes are valuable in
view of their large orbital area for stacking, ambipolar
property, and possible diradical property; however, they are
usually unstable due to their high-lying HOMO energy level.2
Peripheral substitution by electron-withdrawing car-
boxylic imide, cyano, or fluorine groups can stabilize
the acenes and also offer n-type properties by lowering the
† Department of Chemistry.
‡ Department of Physics.
(5) (a) Winkler, M.; Houk, K. N. J. Am. Chem. Soc. 2007, 129, 1805.
(b) Ahmed, E.; Earmme, T.; Ren, G.; Jenekhe, S. A. Chem. Mater. 2010,
22, 5786–5796.
§ Present address: Institute of Chemical and Engineering Sciences, 1 Pesek
Road, Jurong Island, Singapore 627833.
Present address: School of Chemical and Material Engineering, Jiangnan
University, Wuxi 214122, PR China.
(1) (a) Bendikov, M.; Wudl, F.; Perepichka, D. F. Chem. Rev. 2004,
104, 4891. (b) Anthony, J. E. Chem. Rev. 2006, 106, 5028. (c) Anthony,
J. E. Angew. Chem., Int. Ed. 2008, 47, 452.
(2) (a) Anthony, J. E.; Facchetti, A.; Heeney, M.; Marder, S. R.;
Zhan, X.-W. Adv. Mater. 2010, 22, 3876. (b) Bendikov, M.; Durong,
H. M.; Starkey, K.; Houk, K. N.; Carter, E. A.; Wudl, F. J. Am. Chem.
Soc. 2004, 126, 7416.
(6) (a) Tonzola, C. J.; Alam, M. M.; Kaminsky, W.; Jenekhe, S. A.
J. Am. Chem. Soc. 2003, 125, 13548. (b) Nishida, J.-I.; Naraso; Murai, S.;
Fujiwara, E.; Tada, H.; Tomura, M.; Yamashita, Y. Org. Lett. 2004, 6,
2007. (c) Hu, J.; Zhang, D.; Jin, S.; Cheng, S. Z. D.; Harris, F. W. Chem.
Mater. 2004, 16, 4912. (d) Lemaur, V.; da Silva Filho, D. A.; Coropceanu,
V.; Lehmann, M.; Geerts, Y.; Piris, J.; Debije, M. G.; van de Craats,
A. M.; Senthilkumar, K.; Siebbeles, L. D. A.; Warman, J. M.; Bredas, J.-L.;
Cornil, G. J. Am. Chem. Soc. 2004, 126, 3271. (e) Jones, S. C.; Barlow,
ꢀ
F.; Domercq, B.; Amy, F.; Kahn, A.; Bredas, J.-L.; Kippelen, B.;
(3) (a) Sakamoto, Y.; Suzuki, T.; Kobayashi, M.; Gao, Y.; Fukai, Y.;
Inoue, Y.; Tokito, S. J. Am. Chem. Soc. 2004, 126, 8138. (b) Swartz,
C. R.; Parkin, S. R.; Bullock, J. E.; Anthony, J. E.; Mayer, A. C.;
Malliaras, G. G. Org. Lett. 2005, 7, 3163. (c) Qu, H.; Cui, W.; Li, J.;
Shao, J.; Chi, C. Org. Lett. 2011, 13, 924. (d) Katsuta, S.; Miyagi, D.;
Yamada, H.; Okujima, T.; Mori, S.; Nakayama, K.; Uno, H. Org. Lett.
2011, 13, 1454.
(4) (a) Maliakal, A.; Raghavachari, K.; Katz, H.; Chandross, E.;
Siegrist, T. Chem. Mater. 2004, 16, 4980. (b) Chien, S.-H.; Cheng, M.-F.;
Lau, K. C.; Li, W. K. J. Phys. Chem. A 2005, 109, 7509.
Marder, S. R. J. Am. Chem. Soc. 2005, 127, 16358. (f) Nishida, J.;
Murakami, S.; Tada, H.; Yamashita, Y. Chem. Lett. 2006, 35, 1236.
(g) Kojima, T.; Nishida, J.; Tokito, S.; Tada, H.; Yamashita, Y. Chem.
Commun. 2007, 14, 1430. (h) Kaafarani, B. R.; Lucas, L. A.; Wex, B.;
Jabbour, G. E. Tetrahedron Lett. 2007, 48, 5995. (i) Nakagawa, T.;
Kumaki, D.; Nishida, J.; Tokito, S.; Yamashita, Y. Chem. Mater. 2008,
20, 2615. (j) Lee, D.-C.; Jang, K.; McGrath, K. K.; Uy, R.; Robins,
K. A.; Hatchett, D. W. Chem. Mater. 2008, 20, 3688. (k) Lucas, L. A.;
DeLongchamp, D. M.; Richter, L. J.; Kline, R. J.; Fischer, D. A.;
Kaafarani, B. R.; Jabbour, G. E. Chem. Mater. 2008, 20, 5743.
r
10.1021/ol2030839
Published on Web 01/04/2012
2012 American Chemical Society

Scheme 1. Synthetic Route of Pyrazinacene Derivatives 1a, 1b, and 2
LUMO/HOMO energy level.3 An alternative strategy is
to introduce N-atoms into an acene framework. The
electronegative imine N-atoms can enhance the stability
of acenes and prevent photooxidization and DielsꢀAlder
reaction.4 Moreover, they can also serve as H-bond
acceptors to increase the intermolecular interactions in
the solid state.5
Owing to the high electron deficiency, imine N-atoms
are usually utilized in the design of n-type semiconducting
molecules.6 To achieve n-type behavior, a large number of
imine N-atoms should be incorporated into the acene
framework.5 Thus, pyrazine-containing acenes, namely,
pyrazinacenes, are highly desired. Some linear pyrazin-
acenes have been reported.6,7 However, pyrazinacenes with
high pyrazine unit density but without an electron-donating
group can only be marginally obtained or they are very
sensitive to even weak nucleophiles.8 Moreover, fused
pyrazine derivatives are also readily reduced.9 On the other
hand, a dihydropyrazine (reduced pyrazine) unit has been
applied for the design of p-type semiconductors,10 and they
can also act as H-bond donors. Therefore, some aza-acene
derivatives containing both imine and dihydropyrazine
N-atoms have been prepared to adjust their stability and
electronic properties.11 An ambipolar behavior was ex-
pected for pyrazinacenes composed of both pyrazine and
dihydropyrazine units.8 Besides the linear structures, star-
shaped pyrazinacenes such as hexaazatriphenylene (HAT)
and hexaazatrinaphthalene (HATN) derivatives are also
of interest because they can self-organize into columnar
structures in the solid state and allow one-dimensional
charge transport along the column.12 Larger linear and
star-shaped acenes containing both pyrazine and dihy-
dropyrazine units are interesting because they are sup-
posed to show more extended π-conjugation and a higher
tendency to aggregate, which are essential for material
applications in electronic devices such as organic field-
effect transistors (OFETs). However, synthesis of higher
order (dihydro)pyrazinacenes is challenging because (1)
the large rigid molecules usually show poor solubility if
