3-Oxo-3-phenyl-2-(p-tolylhydrazono)propanal (1a) undergoes condensation with ethyl cyanoacetate in acetic acid in the presence of ammonium acetate to yield either 2-hydroxy-6-phenyl-5-p-tolylazonicotinic acid ethyl ester (6a) or 2-amino-6-phenyl-5-ptolylazonicotinic acid ethyl ester (8), depending on the reaction conditions. Similarly, other 3-oxo-3-aryl-2-arylhydrazonopropanals 1a,b condense with active methylene nitriles 2c,d to yield arylazonicotinates 6b,c. In contrast, 2-[(4-nitrophenyl)-hydrazono]-3-oxo-3-phenyl-propanal (1c) reacts with ethyl cyanoacetate to yield ethyl 6-(4-nitrophenyl)-2-oxo-2,6- dihydropyrido[3,2-c]cinnoline-3-carboxylate (11), via a novel 6π-electrocyclization pathway. Finally, 3-oxo-2-(phenylhydrazono)-3-p- tolylpropanal (1d) condenses with 2a-c to yield pyridazinones 13a-c.

Full text of DOI:10.3390/molecules17066557

Molecules 2012, 17, 6557-6568; doi:10.3390/molecules17066557
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Maturation of Murine Bone Marrow-Derived Dendritic Cells
Induced by Radix Glycyrrhizae Polysaccharide
Xiaobing Li 1,2,†, Xiaojuan He 2,†, Biao Liu 3, Li Xu 4, Cheng Lu 2, Hongyan Zhao 5, Xuyan Niu 2,
Shilin Chen 6 and Aiping Lu 2,7,
*
1
School of Basic Medicine, Henan University of Traditional Chinese Medicine,
Zhengzhou 450008, China
2
Institute of Basic Research in Clinical Medicine, China Academy of Chinese Medical Sciences,
Beijing 100700, China
3
4
School of Life Sciences, Hubei University, Wuhan 430062, China
College of Life Science and Technology, Beijing University of Chemical Technology,
Beijing 100029, China
5
6
Institute of Basic Theory, China Academy of Chinese Medical Sciences, Beijing 100700, China
Institute of Medicinal Plant Development, Chinese Academy of Medical Sciences &
Peking Union Medical College, Beijing 100193, China
7
School of Chinese Medicine, Hong Kong Baptist University, Hong Kong, China
†
These authors contributed equally to the work.
* Author to whom correspondence should be addressed; E-Mail: lap64067611@126.com;
Tel.: +86-10-6406-7611; Fax: +86-10-8403-2881.
Received: 23 March 2012; in revised form: 9 May 2012 / Accepted: 22 May 2012 /
Published: 30 May 2012
Abstract: Radix Glycyrrhizae polysaccharide (GP), the most important component of
Radix Glycyrrhizae, has been reported to have many immunopharmacological activities.
However, the mechanism by which GP affects dendritic cells (DCs) has not been elucidated.
In this study, we investigated the effect of GP on murine bone marrow-derived DCs and
the potential pathway through which GP exerts this effect. Mononuclear cells (MNCs) were
isolated from murine bone marrow and induced to become DCs by culturing with GM-CSF
and IL-4. Six days later, DCs were divided into three groups: control group, GP group and
LPS group. After 48 h of treatment, phenotypic figures and antigen uptake ability were
determined by FACS analysis. The proliferation of DC-stimulated allogenic CD3+ T cells
was detected by WST-1. IL-12 p70 and IFN-γ, which are secreted by DCs and CD3+ T

Molecules 2012, 17
cells respectively, were quantified by ELISA. Additionally, IL-12 p40 mRNA expression
6558
was determined by real-time PCR. Alterations in TLR4-related signaling pathways were
examined by performing an antibody neutralization experiment. Treatment of DCs with GP
resulted in the enhanced expression of the cell surface molecules CD80, CD86 and MHC
I-A/I-E. GP also increased the production of IL-12 p70 by DCs in a time-dependent
manner. The endocytosis of FITC-dextran by DCs was suppressed by GP administration.
Furthermore, GP-treated DCs enhanced both the proliferation and IFN-γ secretion of
allogenic CD3+ T cells. Finally, the effects of GP on DCs were partially reduced by using
inhibitors of TLR4, NF-κB, p38 MAPK or JNK. In conclusion, GP can induce the
maturation of DCs, and does so, in part, by regulating a TLR4-related signaling pathway.
Keywords: Radix Glycyrrhizae polysaccharide; dendritic cells; maturation; immune regulation
1. Introduction
Glycyrrhiza glabra is a well-known Chinese herb that has been used in food and medicinal
remedies for thousands of years [1]. This herb has long been valued as a demulcent (soothing, coating
agent), and serves to relieve respiratory ailments (such as allergies, bronchitis, colds, sore throats and
tuberculosis), stomach burn (including heartburn from acid reflux or other causes), gastritis,
inflammatory disorders, skin diseases and liver problems [2]. The medicinal and pharmacological uses
of Glycyrrhiza glabra have been described in several studies [3–5]. Radix Glycyrrhizae Polysaccharide
(GP), one of main bioactive components in Radix Glycyrrhizae, has many pharmacological effects.
Recently, GP has been reported to participate in multiple processes, including the regulation of
immunity [6] and phagocytosis [7], as well as anti-complement [8], anti-viral [9], and anti-tumorigenic [10]
processes. Additionally, GP exhibits low cellular toxicity [10]. Prior to this study, the mechanism by
which GP exerts its immunoregulatory activity remained unclear. In particular, it was previously unknown
whether GP elicited its effects through modulating important immune cells such as dendritic cells (DCs).
DCs are the most potent antigen presenting cells, possessing the unique ability to link innate and
adaptive immunity. DCs act as immune sentinels to initiate T cell responses against microbial pathogens,
inflammation and tumors [11,12]. The maturation process is central to the function of DCs [13]. DC
maturation can be initiated both in vivo and in vitro by many stimuli, including pro-inflammatory
cytokines and bacterial products, such as lipopolysaccharide (LPS) [14–16]. Fully mature DCs exhibit
an increase in the surface expression of MHC II and costimulatory molecules (such as CD80 and
CD86) but a decrease in the capacity to internalize antigens [17]. The induction of DC maturation is
critical for the generation of Ag-specific T lymphocyte responses and may be essential for the
development of human vaccines that rely on T cell immunity. Additionally, IL-12 production is an
important marker of DC maturation and can be used to identify Th1-inducing adjuvants [18]. LPS
recognized by TLR4 in DC, the nuclear transcription factor (NF-κB) and the MAPK signaling pathway
also play important role in DC maturation [19,20]. Recent reports have identified a number of
polysaccharides that participate in the process of DC maturation and induced the MAPK signaling
pathway in monocyte-derived DCs [21,22]. The present study is the first to examine the consequence

Molecules 2012, 17
6559
of GP on the maturation of murine bone marrow-derived DCs and to investigate a potential mechanism
by which GP exerts it effects.
2. Results and Discussion
2.1. GP Induces Phenotypic Maturation of DCs
Hematopoietic progenitor cells from the bone marrow of C57BL/6 mice were cultured in the
presence of GM-CSF and IL-4 for 6 days to induce DCs. The cells were observed with inverted phase
contrast microscope. Figure 1A shows that mature DCs are large cells with oval or irregularly shaped
nuclei and abundant cytoplasm. Some cells exhibited the formation of dendrites. Six days later, DCs
were stimulated with GP (100 μg/mL) or LPS (100 ng/mL) for 48 h. The expression of CD80, CD86
and MHC I-A/I-E was examined. As shown in Figure 1B, GP increased the expression of CD80, CD86
and MHC I-A/I-E, which are established surface markers used to identify mature DCs.
Figure 1. Effects of GP on phenotypic maturation of DCs. Hematopoietic progenitor cells
from the bone marrow of C57BL/6 mice were cultured in the presence of GM-CSF and IL-4
for 6 days. Then, day 6 BMDCs were stimulated with GP (100 μg/mL) or LPS (100 ng/mL)
for 48 h. Cells were then stained with two Abs, the first Ab was PE-conjugated CD11c, and
the second Ab was FITC-CD80, FITC-CD86 or FITC-MHC I-A/I-E. Cells were analyzed
by flow cytometry. The results are representative of three independent experiments.
(A) Morphological characteristics of BMDCs (×200). The left picture is that bone morrow
cells induced by GM-CSF and IL-4 for 1 day; the right picture is that bone morrow cells
induced by GM-CSF and IL-4 for 6 days; (B) Flow cytometry results.

Molecules 2012, 17
6560
Figure 1. Cont.
B
2.2. GP Inhibits the Endocytic Activity of DCs
Immature DCs have a high endocytic capacity, but during differentiation they lose their endocytic
activity towards antigens and mature into potent immunostimulatory antigen presenting cells (APC) [23].
To assess whether GP has an effect on the endocytic activity of DCs, BMDCs cultured in the presence
or absence of GP (100 μg/mL) were incubated with the fluorescent marker dextran-FITC. The results
are shown in Figure 2. Compared with the control group, the endocytic activity of GP-treated DCs was
significantly decreased. Parallel experiments were performed at 4 °C to examine the non-specific
uptake of dextran-FITC into DCs.
Figure 2. Effects of GP on the endocytotic capacity of DCs. Day 6 BMDCs were stimulated
with GP (100 μg/mL) or LPS (100 ng/mL) for 48 h; and then incubated with FITC-dextran
for 1 h at 37 °C. As a control, cells were also incubated at 4 °C. (A) 4 °C control; (B) 37 °C
control; (C) GP; (D) LPS. The results are representative of three independent experiments.

Molecules 2012, 17
6561
2.3. GP-Treated DCs Enhance Allogenic T Cell Proliferation
Mature DCs can activate T cells. We examined the ability of the GP-treated DCs to induce a T-cell
response. As shown in Figure 3A, after co-culture for 5 days, the capacity of DCs treated with GP
(100 μg/mL) or LPS (100 ng/mL) to induce the proliferation of allogeneic T cells was similar, and it
was markedly higher than that of untreated DCs. Furthermore, in order to determine whether GP-treated
DCs modulate cytokine secretion of allogeneic T cells, we measured IFN-γ expression in the
supernatants after co-culture for 2 days. As shown in Figure 3B, GP-treated DCs significantly
increased secretion of the cytokine IFN-γ (p < 0.01).
Figure 3. GP-treated DCs strengthen allogenic T cell proliferation and IFN-γ secretion.
Day 6 BMDCs were stimulated with LPS (100 ng/mL) or GP (100 µg/mL) for 48 h.
Allogeneic CD3+ T cell proliferation was measured after 5 days of co-culture with DCs.
DCs were cultured with CD3+ T cells at a ratio of 1:5, 1:10, 1:20 or 1:40. After co-culturing
DCs with T cells at a ratio of 1:10 for 48 h, the culture supernatants were collected and IFN-γ
was measured. (A) GP-treated DCs strengthen allogenic T cell proliferation; (B) GP-treated
DCs increase IFN-γ secretion of allogeneic T cells. Compared with the control group,
* p < 0.05, ** p < 0.01. The results are representative of three independent experiments.
2.4. GP Enhances IL-12 Production in DCs
IL-12, which exists as a disulfide-linked p35/p40 heterodimer, is a functional DC maturation
marker [24]. To investigate the effects of GP on IL-12 p70 expression in DCs, BMDCs were incubated
with GP (100 μg/mL) for different time. As shown in Figure 4A, GP significantly increased the
production of IL-12 p70 in BMDCs at 48 h and 68 h. Additionally, IL-12 p40 mRNA expression was
determined by quantitative RT-PCR. As shown in Figure 4B, GP increased IL-12 p40 mRNA
expression in DCs in a time-dependent manner.
2.5. GP Induces IL-12 p70 Synthesis through TLR4 Signaling Pathways
DCs express surface receptors, including TLR family members, which allow them to recognize
pathogen associated molecular patterns (PAMP). The TLR family member TLR4 is involved in the
detection of bacterial LPS [25]. To determine whether TLR4 recognized GP, neutralization experiments
were performed. Cell surface TLR4 receptors were blocked by the addition of a neutralizing antibody
before BMDCs were treated with GP. As shown in Figure 5A, the addition of an anti-TLR4 mAb

Molecules 2012, 17
6562
blocked GP-induced and LPS-induced IL-12 p70 production. Compared with the unblocked group,
which did not receive anti-TLR4 mAb, the expression of IL-12 p70 decreased 35.6% in the GP group,
and 39.8% in the LPS group. To further investigate the effect of GP on TLR4-downstream signaling
pathways, a second blocking experiment was performed. BMDCs were pre-treated with various blocking
antibodies for 1 h and subsequently stimulated with GP for 24 h. As shown in Figure 5B, GP induced
significant production of IL-12 p70, which was substantially blocked by inhibiting NF-κB, p38 MAPK
or JNK. In contrast, ERK inhibition had little effect on the GP-induced production of IL-12 p70.
Figure 4. Effects of GP on IL-12 p70 production in DCs. For the IL-12 p70 assay, DCs
were established in culture as described in materials and methods. GP was then added to
the wells for 48 h, and the culture supernatants were harvested at various times for
measurement of IL-12 p70 concentration using ELISA. IL-12 p40 mRNA expression was
measured using real-time PCR. (A) Concentration of IL-12 p70 produced by GP-treated
DCs; (B) IL-12 p40 mRNA expression in GP-treated DCs. Compared with the control
group, ** p < 0.01. The results are representative of three independent experiments.
Figure 5. Effects of TLR4-related signaling pathways on IL-12 p70 production in GP-treated
DCs. Day 6 BMDCs were pre-treated with inhibitors of TLR4, NF-κB, p38 MAPK, ERK
or JNK for 1 h and then incubated with GP for 24 h. Isotype control mAb was added into
control group. The supernatant was then collected for IL-12 p70 detection by ELISA. (A)
Effect of anti-TLR4 mAb on IL-12 p70 production of GP-treated DCs. Compared with the
no anti-TLR4 mAb group, ** p < 0.01; (B) Effect of TLR4 downstream signaling pathways
on IL-12 p70 production of GP-treated DCs. Compared with the GP group, * p < 0.05,
** p < 0.01. The results are representative of three independent experiments.

Molecules 2012, 17
6563
2.6. Discussion
In previous studies, research has focused on the biological effects of GP in macrophages [26,27], as
well as the effects of GP on the proportion of Treg cells in tumor-bearing mice [28]. This is the first
report to demonstrate that GP can induce the maturation of murine DCs through a mechanism that
partially involves a TLR4-related signaling pathway.
DC maturation can be divided into four stages [21,22]: precursor DCs, immature DCs, migration
DCs and mature DCs. Among these stages, immature DCs and mature DCs are the main focus of
research. Immature DCs exhibit low expression of MHC-II, co-stimulatory molecules and adhesion
molecules, while mature DCs exhibit high expression of these molecules. Additionally, immature DCs
are particularly efficient at antigen uptake and processing, while mature DCs are characterized by
enhanced antigen presenting capacity. Our results demonstrated that, after 8 days in culture,
morphologically typical DCs were present and expressed high levels of the cell surface molecules
CD80, CD86 and MHC I-A/I-E. GP further enhanced expression of these cell surface molecules and
decreased DCs endocytic capacity.
Mature DCs are capable of increasing allogeneic T cell stimulation and producing IL-12 [18],
which is a T cell stimulating factor and involved in the differentiation of Th0 cells into Th1 cells [29].
Our results showed that GP could enhance the expression of IL-12 by DCs in a time-dependent
manner, and that GP could significantly strengthen the proliferation of CD3+ T cells and initiate Th1
responses. CD3+ T cells stimulated with GP-treated DCs produced elevated levels of IFN-γ. Taken
together, these data strongly suggest that GP functions to induce not only phenotypic, but also
functional maturation of DCs.
TLR4 detects LPS on Gram-negative bacteria and is thus important in the activation of the innate
immune system. TLR4 has been shown to interact with MyD88, a Toll/IL-1 receptor (TIR)-containing
intracellular adaptor protein [30,31]. The MyD88-dependant signaling pathway activates JNK, MAPKs
and NF-κB. In this study, GP induced significant production of IL-12 p70, which was strongly
inhibited by TLR4, NF-κB, p38 MAPK or JNK inhibitors. The results indicated that GP could be
recognized at least in part by TLR4, and that the induction of the NF-κB and MAPKs signaling
pathways might contribute to the enhancement of DCs maturation. Certainly, it is worthy of further
studies to investigate the role of other TLRs and signaling pathways involving in the activities of GP.
3. Experimental
3.1. Mice
Female C57BL/6 and BALB/c mice (6–8 weeks of age) were obtained from The Military Medical
Science Academy of the PLA, China. The animals were housed in a regulated environment (22 ± 1 °C,
relative humidity 60 ± 5%) under a 12 h light/dark cycle. All animals were acclimatized for at least one
week prior to the experiments. Food and water were administrated ad libitum. The approval of the
Institutional Animal Ethics Committee was obtained prior to carrying out animal experiments.

Molecules 2012, 17
6564
3.2. GP and Other Chemicals
Radix Glycyrrhizae Polysaccharide (GP) was purchased from Pharmagenesis, Inc. (Redwood City,
CA, USA). The percentage of polysaccharide of GP was about 93.52%. The molecular weights of GP
were estimated to be 80,000 Daltons based on high performance gel filtration chromatography with
pullulans as standards. There was no detectable endotoxin (<0.10 endotoxin units/mL) in the GP
samples, as deternined by Endospecy. Escherichia coli LPS (026:B6, E. coli) was purchased from
Sigma. (St. Louis, MO, USA).
3.3. Induction of Mouse Bone Marrow-Derived DCs
Bone marrow-derived DCs (BMDCs) were induced from bone marrow (BM) cells obtained from
6–8 week-old mice [32]. Briefly, a single cell suspension was prepared from BM obtained from femurs
and tibias. After lysing red blood cells, whole BM cells (2 × 106 cells/mL) were cultured in RPMI 1640
medium in six-well flat bottom plates (Orange Scientific, Braine-l’Alleud, Belgium) at 37 °C, 5% CO2,
supplemented with 10% fetal calf serum (FCS), 2 mM L-glutamine, 100 U/mL penicillin G, 100 mg/mL
streptomycin, 30 ng/mL reconstructive mouse GM-CSF (Peprotech, Rocky Hill, USA) and 20 ng/mL
reconstructive mouse IL-4 (Peprotech). Cells were incubated for 24 h. Plates were then gently swirled and
the medium containing non-adherent cells was removed and replaced with nutrient medium as described
above. Supplemented medium was replaced every three days. On day 6, non-adherent and loosely
adherent DCs were purified using MACS columns (Miltenyi Biotec, Bergisch Gladbach, Germany).
3.4. Flow Cytometric Analysis
Phenotypic maturation of DCs was analyzed by flow cytometry. Day 6 BMDCs were first incubated
in the presence or absence of GP (100 μg/mL) for 48 h. Cells were then washed twice by 1% BSA-PBS.
Cells were subsequently labeled with PE-CD11c, and FITC-CD80 or CD86 or MHC I-A/I-E
antibodies (Biolegend, San Diego, CA, USA) for 30 min at 4 °C. Finally cells were washed twice with
washing buffer and detected by flow cytometry (Becton Dickinson, San Jose, CA, USA). The obtained
data were analyzed by the CellQuest software package (BD Biosciences, San Jose, CA, USA).
3.5. Endocytosis Assay
To analyze the endocytosis of DCs, day 6 BMDCs were first incubated in the presence or absence
of GP for 48 h. Then, 2 × 105 cells were incubated at 37 °C for 1 h with 1 mg/mL FITC-dextran
(42,000 Da; Sigma-Aldrich, St. Louis, MO, USA). After incubation, cells were washed twice with cold
washing buffer (HBSS) and FITC-dextran stained DCs were analyzed by flow cytometry. In the
parallel experiment, 2 × 105 DCs were incubated at 4 °C for 1 h.
3.6. Cytokine Assays
Levels of IL-12p70 and IFN-γ in culture supernatants were quantified using an enzyme-linked
immunosorbent assay (ELISA) kit according to the manufacturer’s instructions (Genetimes
Technology, Inc., Shanghai, China).

Molecules 2012, 17
6565
3.7. Mixed Lymphocyte Reaction (MLR)
CD3+ T cells from splenocytes of BALB/c mice were isolated using MACS columns (Miltenyi
Biotec). Purity was greater than 96%. Day 6 BMDCs were incubated in the presence or absence of GP
for 48 h, subsequently treated with 25 mg/mL mitomycin C (AppliChem, Darmstadt, Germany) for
45 min, and then washed twice with PBS. CD3+ T cells were added to each well and cultured for an
additional 120 h at 37 °C. CD3+ T cell proliferation was determined using a WST-1 assay (Roche,
Basel, Switzerland). Results are expressed as the mean of three wells from three individual experiments.
3.8. Real-Time PCR
Total RNA was isolated from DCs using a Trizol Reagent Kit (CWBIO Co., Ltd., Beijing, China),
according to the manufacturer’s instructions. Single-strand cDNA was synthesized from 2 μg
RNA using the HiFi-MMLV cDNA Kit (CWBIO Co., Ltd.). Real-time PCR was performed using
the QIAGEN Rotor gene Q and Real SYBR Mixture Commercial Kits (CWBIO Co., Ltd.). GAPDH
was used as a control. The primers used to detect IL-12 p40 were the forward primer
5'-TGTGCTCGTGGCCTGATC-3' and the reverse primer 5'-CTACGCAGCCCTGATTGA-3'. The
primers used to detect GAPDH were the forward primer 5'-CTCATGACCACAGTCCATGC-3' and
the reverse primer 5'-CACATTGGGGGTAGGAACAC-3'. The cycling profile for each run was 94 °C
for 2 min and 40 cycles of 94 °C for 10min followed by 60 °C for 30 s. All samples were measured in
triplicate. The relative mRNA levels of target genes were calculated by using the comparative
2−ᇞᇞCt methods.
3.9. Neutralization Experiments
To examine the effect of GP on TLR4 and TLR4-downstream signal pathways, day 6 BMDCs were
pre-treated with 20 µg/mL WTS510 (TLR4 neutralization antibody) (Biolegend), 20 µM PDTC (a
specific blocker of NF-B), 20 µM SB203580 (a specific blocker of p38 MAPK), 40 µM PD98059 (an
inhibitor of the ERK pathway) or 20 µM JNK inhibitor (an inhibitor of the JNK pathway) (Beyotime
Institute of Biotechnology, Haimen, Jiangsu, China) for 1 h and subsequently stimulated with GP
(100 μg/mL) for 24 h. Isotype control mAb was added into control group. The cell culture supernatants
were collected and IL-12 p70 was analyzed by ELISA.
3.10. Statistical Analysis
Data are presented as the mean ± SD. Differences were evaluated using Statistical Package for Social
Science 11.0 (SPSS11.0, Chicago, IL, USA). Statistical analysis was performed using One-way ANOVA
followed by least-significant difference (LSD). p < 0.05 was considered to be statistically significant.
4. Conclusions
In conclusion, we have demonstrated that GP can induce DC maturation. Additionally, we have
determined that the mechanism by which GP exerts its effects may be through the regulation of the
TLR4-related signaling pathway. Therefore, GP may be useful as part of the treatment regimen that
regulates DC maturation.

Molecules 2012, 17
6566
Acknowledgments
This research is supported in part by the projects from Ministry of Sciences and Technology of China
(No. 2009ZX09502-019 and 2009ZX09103-150), National Science Foundation of China (No. 30825047,
30902000 and 81001676) and China Academy of Chinese Medical Sciences (No. Z02116).
References and Notes
1. Asada, Y.; Li, W.; Yoshikawa, T. Biosynthesis of the dimethylallyl moiety of glabrol in
Glycyrrhiza glabra hairy root cultures via a non-mevalonate pathway. Phytochemistry 2000, 55,
323–326.
2. Xu, H.; Fabricant, D.S.; Piersen, C.E.; Bolton, J.L.; Pezzuto, J.M.; Fong, H.; Totura, S.;
Farnsworth, N.R.; Constantinou, A.I. A preliminary RAPD-PCR analysis of Cimicifuga species
and other botanicals used for women’s health. Phytomedicine 2002, 9, 757–762.
3. Arase, Y.; Ikeda, K.; Murashima, N.; Chayama, K.; Tsubota, A.; Koida, I.; Suzuki, Y.; Saitoh, S.;
Kobayashi, M.; Kumada, H. The long term efficacy of glycyrrhizin in chronic hepatitis C patients.
Cancer 1997, 79, 1494–1500.
4. Davis, E.A.; Morris, D.J. Medicinal uses of licorice through the millennia: The good and plenty of it.
Mol. Cell. Endocrinol. 1991, 78, 1–6.
5. Takahara, T.; Watanabe, A.; Shiraki, K. Effects of glycyrrhizin on hepatitis B surface antigen:
A biochemical and morphological study. J. Hepatol. 1994, 21, 601–609.
6. Yang, G.; Yu, Y. Immunopotentiating effect of traditional Chinese drugs—Ginsenoside and
glycyrrhiza polysaccharide (in Chinese). Proc. Chin. Acad. Med. Sci. Peking Union Med. Coll.
1990, 5, 188–193.
7. Nose, M.; Terawaki, K.; Oguri, K.; Ogihara, Y.; Yoshimatsu, K.; Shimomura, K. Activation of
macrophages by crude polysaccharide fractions obtained from shoots of Glycyrrhiza glabra and
hairy roots of Glycyrrhiza uralensis in vitro. Biol. Pharm. Bull. 1998, 21, 1110–1112.
8. Takada, K.; Tomoda, M.; Shimizu, N. Core structure of glycyrrhizan GA, the main
polysaccharide from the stolon of Glycyrrhiza glabra var. glandulifera; anti-complementary and
alkaline phosphatase-inducing activities of the polysaccharide and its degradation products.
Chem. Pharm. Bull. (Tokyo) 1992, 40, 2487–2490.
9. Wang, Y.W.; Zhang, H.B.; Lv, J.; Shi, Y.R.; He, M.; Wang, S.S. Inhibitionof Glycyrrhiza
polysaccharides on virus (in Chinese). Acta Sci. Nat. Univ. Nankaiensis 2000, 33, 46–48.
10. Wang, C.; Xie, G.R.; Shi, Y.R.; Zhang, L.H. Study on the anti-tumor effect in vivo of glycyrrhizia
polysaccharide and its mechanism (in Chinese). Chin. Clin. Oncol. 2003, 8, 85–87.
11. Crowley, M.; Inaba, K.; Steinman, R.M. Dendritic cells are the principal cells in mouse spleen
bearing immunogenic fragments of foreign proteins. J. Exp. Med. 1990, 172, 383–386.
12. Steinman, R.M. The dendritic cell system and its role in immunogenicity. Annu. Rev. Immunol.
1991, 9, 271–296.
13. Ardeshna, K.M.; Pizzey, A.R.; Devereux, S.; Khwaja, A. The PI3 kinase, p38 SAP kinase, and
NF-kappaB signal transduction pathways are involved in the survival and maturation of
lipopolysaccharide-stimulated human monocyte-derived dendritic cells. Blood 2000, 96, 1039–1046.

Molecules 2012, 17
6567
14. Sallusto, F.; Lanzavecchia, A. Efficient presentation of soluble antigen by cultured human
dendritic cells is maintained by granulocyte/macrophage colony-stimulating factor plus interleukin 4
and downregulated by tumor necrosis factor alpha. J. Exp. Med. 1994, 179, 1109–1118.
15. Sallusto, F.; Cella, M.; Danieli, C.; Lanzavecchia, A. Dendritic cells use macropinocytosis and the
mannose receptor to concentrate macromolecules in the major histocompatibility complex class II
compartment: Downregulation by cytokines and bacterial products. J. Exp. Med. 1995, 182, 389–400.
16. Roake, J.A.; Rao, A.S.; Morris, P.J.; Larsen, C.P.; Hankins, D.F.; Austyn, J.M. Dendritic cell loss
from nonlymphoid tissues after systemic administration of lipopolysaccharide, tumor necrosis
factor, and interleukin 1. J. Exp. Med. 1995, 181, 2237–2247.
17. Cella, M.; Engering, A.; Pinet, V.; Pieters, J.; Lanzavecchia, A. Inflammatory stimuli induce
accumulation of MHC class II complexes on dendritic cells. Nature 1997, 388, 782–787.
18. de Jong, E.C.; Smits, H.H.; Kapsenberg, M.L. Dendritic cell-mediated T cell polarization.
Springer Semin. Immunopathol. 2005, 26, 289–307.
19. Yoshimura, S.; Bondeson, J.; Foxwell, B.M.; Brennan, F.M.; Feldmann, M. Effective antigen
presentation by dendritic cells is NF-kappaB dependent: Coordinate regulation of MHC,
co-stimulatory molecules and cytokines. Int. Immunol. 2001, 13, 675–683.
20. Ardeshna, K.M.; Pizzey, A.R.; Devereux, S.; Khwaja, A. The PI3 kinase, p38 SAP kinase, and
NF-kappaB signal transduction pathways are involved in the survival and maturation of
lipopolysaccharide-stimulated human monocyte-derived dendritic cells. Blood 2000, 96, 1039–1046.
21. Lin, Y.L.; Liang, Y.C.; Lee, S.S.; Chiang, B.L. Polysaccharide purified from Ganoderma lucidum
induced activation and maturation of human monocyte-derived dendritic cells by the NF-kappaB
and p38 mitogen-activated protein kinase pathways. J. Leukoc. Biol. 2005, 78, 1–10.
22. Kim, G.Y.; Han, M.G.; Song, Y.S.; Shin, B.C.; Shin, Y.I.; Lee, H.J.; Moon, D.O.; Lee, C.M.;
Kwak, J.Y.; Bae, Y.S.; et al. Proteoglycan isolated from Phellinus linteus induces toll-like
receptors 2- and 4-mediated maturation of murine dendritic cells via activation of ERK, p38, and
NF-kappaB. Biol. Pharm. Bull. 2004, 27, 1656–1662.
23. Banchereau, J.; Steinman, R.M. Dendritic cells and the control of immunity. Nature 1998, 392,
245–252.
24. Kobayashi, M.; Fitz, L.; Ryan, M.; Hewick, R.M.; Clark, S.C.; Chan, S.; Loudon, R.; Sherman, F.;
Perussia, B.; Trinchieri, G. Identification and purification of natural killer cell stimulatory factor
(NKSF), a cytokine with multiple biologic effects on human lymphocytes. J. Exp. Med. 1989,
170, 827–845.
25. Poltorak, A.; He, X.; Smirnova, I.; Liu, M.Y.; van Huffel, C.; Du, X.; Birdwell, D.; Alejos, E.;
Silva, M.; Galanos, C.; et al. Defective LPS signaling in C3H/HeJ and C57BL/10ScCr mice:
Mutations in Tlr4 gene. Science 1998, 282, 2085–2088.
26. Cheng, A.; Wan, F.; Jin, Z.; Wang, J.; Xu, X. Nitrite oxide and inducible nitric oxide synthase
were regulated by polysaccharides isolated from Glycyrrhiza uralensis Fisch. J. Ethnopharmacol.
2008, 118, 59–64.
27. Cheng, A.; Wan, F.; Wang, J.; Jin, Z.; Xu, X. Macrophage immunomodulatory activity of
polysaccharides isolated from Glycyrrhiza uralensis fish. Int. Immunopharmacol. 2008, 8, 43–50.

Molecules 2012, 17
6568
28. He, X.; Li, X.; Liu, B.; Xu, L.; Zhao, H.; Lu, A. Down-regulation of treg cells and up-regulation
of TH1/TH2 cytokine ratio were induced by polysaccharide from radix glycyrrhizae in h22
hepatocarcinoma bearing mice. Molecules 2011, 16, 8343–8352.
29. Seder, R.A.; Gazzinelli, R.; Sher, A.; Paul, W.E. Interleukin 12 acts directly on CD4+ T cells to
enhance priming for interferon gamma production and diminishes interleukin 4 inhibition of such
priming. Proc. Natl. Acad. Sci. USA 1993, 90, 10188–10192.
30. Rhee, S.H.; Hwang, D. Murine TOLL-like receptor 4 confers lipopolysaccharide responsiveness
as determined by activation of NF kappaB and expression of the inducible cyclooxygenase.
J. Biol. Chem. 2000, 275, 34035–34040.
31. Fitzgerald, K.A.; Palsson-McDermott, E.M.; Bowie, A.G.; Jefferies, C.A.; Mansell, A.S.; Brady, G.;
Brint, E.; Dunne, A.; Gray, P.; Harte, M.T.; et al. Mal (MyD88-adapter-like) is required for
Toll-like receptor-4 signal transduction. Nature 2001, 413, 78–83.
32. Inaba, K.; Inaba, M.; Romani, N.; Aya, H.; Deguchi, M.; Ikehara, S.; Muramatsu, S.; Steinman, R.M.
Generation of large numbers of dendritic cells from mouse bone marrow cultures supplemented
with granulocyte/macrophage colony-stimulating factor. J. Exp. Med. 1992, 176, 1693–702.
Sample Availability: Samples of the Radix Glycyrrhizae polysaccharide are available from the authors.
© 2012 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
