High-Throughput Screening
Reaction Discovery by Using a Sandwich Immunoassay**
Julia Quinton, Sergii Kolodych, Manon Chaumonet, Valentina Bevilacqua, Marie-Claire Nevers,
Hervꢀ Volland, Sandra Gabillet, Pierre Thuꢀry, Christophe Crꢀminon, and Frꢀdꢀric Taran*
Despite the bredth of the synthetic chemistꢀs arsenal, there is
still a need to develop new organic reactions, to allow for
unprecedented connection of reactive functions. A recent and
still underdeveloped approach to reaction discovery involves
the use of efficient screening techniques that allow test
reactions to be systematized in a format that maximizes the
opportunity for discovering new reactions. This “forced
serendipity” approach is based on the assumption that the
probability of serendipitous findings increases when a large
number of chemical reactions are performed. Robust and
general high-throughput screening techniques allowing the
quick identification of new reactions are the critical point of
such an approach.
Improvements in the automation of mass spectroscopy
(MS) coupled to gas (GC) or liquid (LC) chromatography
were the initial driving force of this serendipity-based
strategy. Weber et al. reported in 1999 the discovery of
a new Ugi-type reaction after screening thousands of reaction
mixtures.[1] Since this pioneering work, a few examples of new
reactions discovered by MS-based screening have been
reported. Porco, Jr. and co-workers developed a so-called
multidimensional screening, wherein reactions are run in an
array format and analyzed by LC-MS techniques.[2] Several
new interesting reactions were successfully identified, but
because of moderate throughput of the screening, the
approach was rather focused on one particular type of
designed substrate or reaction process, which may leave
many areas of chemical reactivity unexplored. Recently,
MacMillan and co-workers discovered a useful photoredox-
An alternative strategy for discovery of new reactions,
initially used to facilitate MS analysis,[5] relies on the use of
tagged reactants. Liu and co-workers developed a powerful
method based on DNA-tagged reactants allowing the quick
identification of new chemical transformations.[6] However,
DNA tags require particular chemistry and might interact
with the catalysts.
Herein, we discuss an approach to discover chemical
reactions using an immunoassay screening technique that uses
tags that are easier to synthesize and more compatible with
the chemical reactions studied. As we reported,[7] sandwich
immunoassays can be adapted to monitor cross-coupling
reactions by connecting small-molecule tags to chemically
reactive groups. Products of coupling reactions can then be
specifically detected by two anti-tag monoclonal antibodies:
one antibody capturing the double-tagged coupling product
onto a solid phase and a second acting as a detector. The
required tags are respectively a tert-butoxycarbonyl (Boc)-
protected imidazole and a tert-butyldimethylsilyl (TBDMS)-
protected guaiacol derivative, both are linked to functional
groups A and B by standard peptide coupling (Figure 1). We
recently showed that any kind of cross-coupling products can
be detected by this technique if the tags are separated by at
least eight atoms.[8]
Typically our sandwich immunoassay is run in microtiter
plates and allows the measurement of at least 1000 reaction
yields in a single day (for one person, without robotization).
We anticipated that this throughput should be high enough to
apply the technique to reaction discovery projects.
Our strategy (Figure 1) is therefore based on a three-step
procedure: 1) parallel reactions of combinations of tagged
functional groups A and B and catalysts are run in 96-well
plates, 2) quenching, dilution, and transfer of crude reaction
mixtures to determine cross-coupling yields by sandwich
immunoassay, and 3) validation and evaluation of hits by
reproducing the active combination with nontagged func-
tional groups.
[3]
À
catalyzed C H arylation reaction using robotic GC-MS.
A
copper-catalyzed alkyne hydroamination and two nickel-
catalyzed hydroarylation reactions were also recently discov-
ered by Robbins and Hartwig using a simpler MS instru-
ment.[4]
[*] Dr. J. Quinton, S. Kolodych, Dr. M. Chaumonet, V. Bevilacqua,
S. Gabillet, Dr. F. Taran
CEA, iBiTecS, Service de Chimie Bioorganique et de Marquage
91191 Gif sur Yvette (France)
E-mail: frederic.taran@cea.fr
A particularly critical design element of this strategy relies
on the choice of reactive functional groups that, in theory,
should not be based on preconceived ideas of what will react.
Herein, we conducted the core experiment with 21 tagged A
functional groups and 16 tagged B functional groups (see
Supporting Information for synthesis), most of them contain-
ing common functional groups (such as alcohol, nitro, amine,
alkene, alkyne, azide, aldehyde, and nitrile). Assuming that
the probability of identifying new reactions should be higher
with functionalities whose chemistry has been less explored,
we also selected some less common functional groups (such as
skipped alkyne, N-hydroxy thiourea, alkynyl oxime, and
amidoxime). Alkane groups were also added to the library as
M.-C. Nevers, Dr. H. Volland, Dr. C. Crꢀminon
CEA, iBiTecS, Service de Pharmacologie et d’Immunoanalyse
91191 Gif sur Yvette (France)
Dr. P. Thuꢀry
CEA, IRAMIS, Service Interdisciplinaire sur les Systꢁmes
Molꢀculaires et les Matꢀriaux
91191 Gif sur Yvette (France)
[**] This work was supported by the European Union, BioChemLig
project and by ANR, ClickScreen project.
Supporting information for this article is available on the WWW
