Angewandte
Chemie
DOI: 10.1002/anie.201109113
Lithiation Chemistry
Exploiting the Lithiation-Directing Ability of Oxetane for the
Regioselective Preparation of Functionalized 2-Aryloxetane Scaffolds
under Mild Conditions**
Donato Ivan Coppi, Antonio Salomone, Filippo Maria Perna, and Vito Capriati*
Dedicated to Professor Saverio Florio on the occasion of his retirement
More than seventy years ago, Gilman[1] and Wittig[2] inde-
pendently observed that the lithiation of an aromatic ring
could be achieved ortho to a substituent, and hence opened up
new horizons for obtaining differently functionalized organo-
lithium derivatives through what is today known as the
directed ortho metalation (DoM) reaction. Since then, and
particularly thanks to seminal contributions from the groups
of Hauser, Meyers, Gschwend, Beak, Snieckus, and others,[3]
DoM methodology, which strikingly complements traditional
electrophilic aromatic substitution, has received an extra-
ordinary level of attention in the field of organometallic
chemistry.[4] The reaction is proposed to proceed by the
involvement of a direct metalation group (DMG) whose
ability to effect the ortho metalation process has generally
been interpreted in terms of an interplay of inductive and
complexation effects. The mechanistic rationalization for the
DoM reaction, however, still remains elusive and controver-
sial.[5]
Despite the broad range of hetero- and carbon-linked
substituents available to synthetic chemists for performing
hydrogen/metal permutation processes, saturated ring hetero-
cycles have surprisingly received much less attention as
potential DMGs.[6] The oxetane ring motif is an important
structural component of several naturally occurring com-
pounds, and oxetane derivatives have received increasing
exposure over the years as attractive and versatile modules
for both drug discovery and organic synthesis.[7] Herein, we
report the first successful use of oxetane as an effective DMG
in the regioselective preparation of functionalized 2-arylox-
etane scaffolds and explore the scope of such a methodology.
On the basis of intra- and intermolecular competition experi-
ments and kinetic evidence, we rank the lithiation-promoting
power of oxetane as being equal to that of an aminomethyl
group, and support a complex-induced proximity effect
(CIPE) as the main mechanism responsible for modulating
À
the ortho C H acidity.
Recently, the search for a new way to access 2-substituted-
2-phenyloxetanes has led to the discovery that sBuLi in THF
at À788C is the base of choice to perform a clean a-lithiation/
functionalization of 2-phenyloxetane.[8] As for saturated
cyclic ethers, it is also known that the electron-donor ability
of the oxygen atom is dependent upon the size of the ring, the
basicity being in the order four- > five- > six- > three-mem-
bered ring.[9] Thus, the intrinsic basicity of an oxetane ring is
not only higher than that of an epoxide, but also higher
compared with that of tetrahydrofuran. Inspired by this
observation, we became intrigued by the possibility that an
oxetane ring, in view of its remarkable basicity, could behave
as an ortho-directing group in the absence of a benzylic
proton. Thus, 2-Methyl-2-phenyloxetane 1 was chosen as
a model substrate. It was straightforwardly prepared in 90%
yield by the reaction of acetophenone with dimethylsulfoxo-
nium methylide (508C, 3 days) through a double methylene
transfer reaction.[10]
We were pleased to find that treatment of an Et2O
solution (0.2m) of 1 (1 equiv) at 08C with sBuLi (1.4 equiv),
followed by quenching of the reaction mixture after 10 min
with MeI, led to the ortho-methylated product 2a in 98%
yield, probably through the putative ortho-lithiated inter-
mediate 1-Li, which proved to be chemically stable for up to
30 min at 08C and for up to 10 min even at room temperature
(Scheme 1).
[*] Dr. D. I. Coppi, Dr. A. Salomone, Dr. F. M. Perna, Prof. V. Capriati
Dipartimento Farmaco-Chimico, Universitꢀ di Bari “A. Moro”
Consorzio Interuniversitario Nazionale Metodologie e Processi
Innovativi di Sintesi C.I.N.M.P.I.S.
Scheme 1. Synthesis of ortho-methylated 2-phenyloxetanes 2a and 5,
and of homoallylic alcohol 3. LIDAKOR=iPr2NLi/tBuOK.
Via E. Orabona, 4, 70125 Bari (Italy)
E-mail: capriati@farmchim.uniba.it
[**] This work was financially supported by MIUR-FIRB (CINECA
RBF12083M5N), the University of Bari, and Interuniversities
Consortium C.I.N.M.P.I.S. We would like to acknowledge Dr.
Francesca Sassone for her contribution to the Experimental Section.
As for the bases, we also ascertained that nBuLi, lithium
diisopropylamide (LDA), and lithium 2,2,6,6-tetramethylpi-
peridide (LTMP) were ineffective (08C, Et2O, 10 min),
whereas employing sBuLi in THF at 08C, followed by
quenching with MeI, afforded only an 80% yield of 2a after
Supporting information for this article is available on the WWW
Angew. Chem. Int. Ed. 2012, 51, 1 – 6
ꢀ 2012 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1
These are not the final page numbers!
