Synthesis, structure, and properties of twofold bridged sesquinorbornenes

Article abstract of DOI:10.1002/(SICI)1099-0690(199809)1998:9<1759::AID-EJOC1759>3.0.CO;2-I

The twofold bridged sesquinorbornenes 2 and 6 were prepared using sequential [4 + 2] cycloadditions of benzoquinone with 1,5-dihydropentalenes 1 and 5. These syntheses were improved using dilution conditions or a more reactive substituted benzoquinone. Results from semiempirical and ab initio DFT calculations indicated remarkably high pyramidalization angles (φ = 46-47°) for the central C-C double-bond atoms. The chemical reactivity with triplet and singlet oxygen, dimethyldioxirane and N-methyl-1,2,4-triazoline-3,5-dione supports these structural assignments.

Full text of DOI:10.1002/(SICI)1099-0690(199809)1998:9<1759::AID-EJOC1759>3.0.CO;2-I

FULL PAPER
Synthesis, Structure, and Properties of Twofold Bridged Sesquinorbornenes
Axel G. Griesbeck*a, Thomas Deufelc, Georg Hohlneicherb, Rupert Rebentischb, and Jörg Steinwaschera
Institut für Organische Chemie der Universität zu Kölna,
Greinstraße 4, D-50939 Köln, Germany
Fax: (internat) ϩ 49(0)221/470-3083
E-mail: griesbeck@uni-koeln.de
Institut für Physikalische Chemie der Universität zu Kölnb,
Luxemburgstraße 116, D-50939 Köln, Germany
Institut für Organische Chemie der Universität Würzburgc,
Am Hubland, D-90737 Würzburg, Germany
Received April 23, 1998
Keywords: Alkenes / Cycloadditions / Cage compounds / Ab initio calculations / Double-bond pyramidalization
The twofold bridged sesquinorbornenes
prepared using sequential [4 2] cycloadditions of central C–C double-bond atoms. The chemical reactivity
benzoquinone with 1,5-dihydropentalenes 1 and 5. These with triplet and singlet oxygen, dimethyldioxirane and N-
syntheses were improved using dilution conditions or a more methyl-1,2,4-triazoline-3,5-dione supports these structural
reactive substituted benzoquinone. Results from assignments.
semiempirical and ab initio DFT calculations indicated
2
and
6
were
remarkably high pyramidalization angles (␾ = 46–47°) for the
+
The structural properties and the chemical reactivity of ments and studies on the chemical reactivity as well as
syn-sesquinorbornes have been studied intensively[1] in the theoretical investigations with these molecules.
last decades. Especially the symmetric deformation of the
Figure 1. Pyramidalization angle ␾
central CϪC double bond is a remarkable property which
leads to an increased reactivity in comparison with nor-
bornenes. One out of several parameters which are used to
describe the out-of-plane deformation is the pyramidali-
zation angle ␾ as defined by Borden[2] (cos ␾ ϭ Ϫcos
(RCC)/[cos 0.5(RCR)], see Figure 1). Several syn-sesquinor-
bornes have been described with ␾ values up to 25°.[3]
Much higher pyramidalization angles have been determined
A sequence of inter- and intramolecular Diels-Alder re-
actions of the dihydropentalene 1[13] with 1 equivalent of p-
benzoquinone gave the cage compound 2a in relatively low
yields (15Ϫ20%). The major product was the 1:2 adduct 3a
from 1 and two equivalents of p-benzoquinones. (Scheme
1).
for the fullerene C60 (␾ ϭ 31.6°),[4] a sesquinorbornatri-
ex.
ene (␾ ϭ 32.4°)[5] and a secododecahedradiene (␾
ϭ
ex.
ex.
35.3°).[6] The 9,9Ј,10,10Ј-tetradehydrodianthracene (10),
prepared more than twenty years ago, has one of the high-
est ␾ angles for symmetrically out-of-plane bent alkenes
Scheme 1
(␾ ϭ 35.9°).[7] Recent studies have revealed the unusual
ex.
reactivity of this compound.[8] Even higher pyramidaliz-
ation values were determined for bridgehead-substituted
tribenzodihydroacepentalenes (␾ ϭ 45.8 and 47.2°),[9]
ex.
however, these molecules are asymmetrically bent, i.e. the
pyramidalization angles for the second olefinic carbon atom
are much lower (␾ ϭ 27.6 and 30.2°). In the series of
ex.
isolable unsaturated dodecahedrane molecules, for dodeca-
hedradiene a remarkably high pyramidalization angle was
For other monofunctional dienophiles such as maleic an-
calculated (␾
ϭ 42.9°).[10][11] Recently, we discovered a hydride, the equilibrium constant of the double-bond iso-
calc.
simple reaction sequence which results in cage compounds mers I and II could be determined (ca. 5). This was not
with a twofold bridged sesquinorbornene structure.[12] We possible for the benzoquinone adducts Ia and IIa due to the
expected these compounds to exhibit an additional increase rapid consumption of IIa by intramolecular cycloaddition.
in double-bond nonplanarity compared with their un- When the reaction of 1 and benzoquinone was performed
bridged analogues. Herein we describe synthetic improve- with 0.2 equivalents of benzoquinone, the primary Diels-
Eur. J. Org. Chem. 1998, 1759Ϫ1762
WILEY-VCH Verlag GmbH, D-69451 Weinheim, 1998
1434Ϫ193X/98/0909Ϫ1759 $ 17.50ϩ.50/0
1759

A. G. Griesbeck, T. Deufel, G. Hohlneicher, R. Rebentisch, J. Steinwascher
1
FULL PAPER
Alder cycloadduct Ia was detected by low-temperature H lations (vide infra). A characteristic property of syn-sesqui-
NMR and the activation barrier for isomerization was de- norbornenes is that they readily add oxygen to give the cor-
termined to be 23 ± 2 kcal/mol (see Scheme 2).
responding epoxides.[16] Actually, the cage compound 2a
was quantitatively epoxidized by a variety of reagents: Di-
methyldioxirane (DMD) gave the epoxides 7 already after
some minutes at Ϫ20°C, singlet oxygen likewise reacted ef-
ficiently, whereas triplet oxygen needed some days for com-
pletion (Scheme 4). Oxirane 7 was crystallized as its meth-
anol adduct and characterized by X-ray analysis.[17] It is
important to mention, that no trace of 1,2-dioxetane or the
corresponding cleavage products were formed in the singlet-
oxygen reaction. Dioxetane formation can be found for
many strained alkenes which have no properly aligned al-
lylic hydrogen atoms.[18] Thus, the pyramidalization of the
central double bond is depicted in a radical-like behaviour
in its reaction with triplet oxygen as well as the unusual
oxygen-atom transfer from singlet oxygen. That this behav-
iour is not a consequence of extreme shielding by the two
flanking methylene bridges became apparent from the reac-
tion of 2a with N-methyl-1,2,4-triazoline-3,5-dione
(MTAD) in aqueous THF which led to the adduct 8. For
TAD [2 ϩ 2] cycloaddition reactions an intermediate aziri-
dinium imide zwitterion has been proven recently.[19] Thus,
adduct 8 probably resulted from the nucleophilic ring open-
ing of such an intermediate with substrate 2a.
Scheme 2
In order to improve the yield of cage compounds we
examined two modifications: (a) Use of more reactive
benzoquinones which should accelerate the intra- versus the
intermolecular cycloaddition, and (b) application of the di-
lution principle in order to suppress the addition of a se-
cond equivalent of benzoquinone to the intermediate I.
Treatment of the 1,5-dihydropentalene 1 with 2-(4-nitro-
phenyl)benzoquinone as bifunctional nonsymmetric dieno-
phile resulted in two regioisomeric products 2b and 2c in a
ratio of 57:43 (Scheme 1). The constitution of the cage
products could be easily derived from the H-H coupling
patterns. Surprisingly, no 1:2 cycloaddition products were
isolated. As can be seen from the product substituent pat-
tern, the primary cycloaddition exclusively involves the un-
substituted benzoquinone double bond (which can be easily
derived from the H-H coupling pattern in the products).
Thus, the secondary intramolecular cycloaddition must
have been accelerated by the p-nitrophenyl group and the
intermolecular reaction is widely suppressed. The second
alternative was the use of dilution conditions. By slow ad-
dition of p-benzoquinone to a solution of 1 in dichloro-
methane the yield of 2a could be raised to 52%. More im-
portant was the fact that this procedure allowed the prep-
aration of the unsubstituted cage compound 6 from 1,5-
dihydropentalene 5 (Scheme 3). The starting material 5 is
easily available by thermolysis of the pentafulvene 4.[14][15]
After treatment with 1.1 equivalents of p-benzoquinone un-
der dilution conditions, a 65:35 mixture of cage product 6
and a 1:2 cycloaddition product were isolated. After flash
chromatography, 6 could be isolated as a colorless oil in
29% yield.
In order to gain more detailed information on the degree
of double-bond deformation, we performed a series of semi-
empirical and DFT calculations for the unsubstituted cage
compound 6, its deoxygenated (hypothetical) analogue 9 (in
order to exclude through-space carbonyl-carbonyl interac-
tions) and the tetradehydrodianthracene 10 (Figure 2).
Force field calculations (MM2[20]) resulted in too high val-
ues for the pyramidalization angle ␾: e.g. for GreeneЈs com-
pound 10 a ␾ value of 43.3° resulted (␾ ϭ 35.9°). Semi-
ex.
empirical methods resulted in more realistic values: AM1[21]
calculation gave 35.4° for 10 [for C60
␾
is 31.9° (␾
ϭ
calc.
ex.
31.6°)]. For compound 6 the force field predicts a pyrami-
dalization of 52.8°, the AM1 calculation gave 48.6°. To
further optimize these results we performed density func-
tional theory calculations (DFT-B3LYP[22]) with the 6-
31G* basis set.[23] The GAUSSIAN94 program package
was used for these calculations.[24] The results for 6 and 9
were nearly identical: for 6 a ␾ value of 46.5° (9: 47.1°)
resulted (Table 1). Another useful parameter for the de-
scription of large symmetrical out-of-plane bending is the
αav value.[25][26][28] For GreeneЈs compound 10 αav is 114.8°,
Scheme 3
for C60 aav ϭ 116° (from X-ray data). The DFT calculations
for 6 and 9 resulted in αav values of 114.4° and 114.2°,
respectively. These calculations lead to the suggestion that
the (at room temperature stable) cage compounds 2, 6 have
remarkably high double-bond pyramidalizations. This pyr-
amidalization results mainly from the fact that the strong
compression of the α and β angles, which is typical for ses-
Unfortunately, no X-ray analysis could be performed so quinorbornenes, cannot be counterbalanced by expansion
far, neither from the parent compound 6 nor from its de- of the γ angle. In typical syn-sesquinorbornenes the γ angle
rivatives 2 due to low crystal quality. Nevertheless, we tried can reach values up to 144°.[3a]
to gain more information on the double-bond deformation
by studying the chemical behaviour and performing calcu-
This work was supported by the Deutsche Forschungsgemein-
schaft (SFB 347, University of Würzburg) and the Fonds der Chem-
ischen Industrie.
1760
Eur. J. Org. Chem. 1998, 1759Ϫ1762

Synthesis, Structure, and Properties of Twofold Bridged Sesquinorbornenes
Scheme 4
FULL PAPER
nitrogen at room temp. to a solution of 2.20 g (11.3 mmol) of 1 in
600 ml of CH2Cl2 by means of a motor-driven syringe during 24
h. After evaporation of the solvent, column chromatography re-
sulted in 1.90 g (40%) of a mixture of 2b and 2c as a brown solid
which was recrystallized several times from cyclohexane to give
1.20 g (25%) of a 1.3:1 mixture of 2b and 2c as a colorless powder.
Ϫ IR (CCl4, mixture): ν˜ ϭ 3010 cmϪ1, 2940, 1695, 1590, 1510,
Table 1. Results of calculations for 6 (9)
MM2
AM1
B3LYP/6-31G*
α
107.25
107.25
121.23
335.73
52.8
106.77
106.77
128.18
341.72
48.6
107.62 (107.55)
107.62 (107.55)
127.87 (127.53)
343.11 (342.63)
46.5 (47.1)
β
γ
α ϩ β ϩ γ
␾
1
1340, 1250, 1130. Ϫ 2b: H NMR (CDCl3): δ ϭ 1.55 (s, 3H), 1.73
(d, J ϭ 10.1 Hz, 1 H, 11-Hanti), 1.93 (d, J ϭ 10.3 Hz, 1 H, 14-
Hanti), 2.19 (m, 2 H, 11-Hsyn, 14-Hsyn), 2.96 (dd, J ϭ 2.9, 8.0 Hz, 1
H, 2-H), 3.08 (dd, J ϭ 2.9, 3.5 Hz, 1 H, 4-H), 3.52 (d, J ϭ 8.0 Hz,
1 H, 7-H), 3.65 (m, 1 H, 12-H), 4.03 (s, 1 H, 10-H), 7.20Ϫ7.51 (m,
7 H, Ar.-H), 8.10Ϫ8.20 (m, 2 H, Ar.-H). Ϫ 13C NMR (CDCl3):
δ ϭ 15.1 (q), 41.8 (t), 51.5 (d), 55.0 (d), 56.2 (t), 60.2 (s), 62.4 (d),
65.4 (d), 65.6 (d), 68.8 (s), 70.0 (s), 123.3 (d), 127.3 (d), 127.6 (d),
128.8 (d), 129.7 (d), 136.4 (s), 137.2 (s), 146.7 (s), 157.7 (s), 160.3
αav.
111.91
113.91
114.37 (114.21)
Figure 2. Pyramidalized alkenes 6, 9, 10
1
(s), 208.5 (s), 209.4 (s). Ϫ 2c: H NMR (CDCl3): δ ϭ 1.54 (s, 3H),
1.75 (d, J ϭ 10.6 Hz, 1 H, 11-H), 1.94 (d, J ϭ 10.3 Hz, 1 H, 14-
H), 2.19 (m, 2 H, 11Ј-H, 14Ј-H), 3.01 (d, J ϭ 8.0 Hz, 1 H, 2-H),
3.02 (dd, J ϭ 2.8, 3.6 Hz, 1 H, 5-H), 3.46 (dd, J ϭ 2.8, 8.0 Hz, 1
H, 7-H), 3.65 (m, 1 H, 10-H), 4.03 (s, 1 H, 12-H), 7.20Ϫ7.51 (m,
7 H, Ar.-H), 8.10Ϫ8.20 (m, 2 H, Ar.-H). Ϫ 13C NMR (CDCl3):
δ ϭ 15.1 (q), 41.8 (t), 52.2 (d), 54.0 (d), 55.9 (t), 60.7 (s), 63.2 (d),
65.1 (d), 65.2 (d), 68.3 (s), 69.6 (s), 123.4 (d), 127.3 (d), 127.6 (d),
128.8 (d), 129.7 (d), 136.4 (s), 137.2 (s), 147.0 (s), 154.8 (s), 157.4
(s), 208.5 (s), 209.4 (s).
Experimental Section
General: The dihydropentalenes 1 and 5 were synthesized accord-
ing to literature procedures.[13][14] Ϫ IR: Perkin-Elmer 1420. Ϫ H
1
NMR: AC 200 (200 MHz), Bruker AC 250 (250 MHz), Bruker AC
300 (300 MHz) Bruker AC 500 (500 MHz). Ϫ 13C NMR: Bruker
AC 200 (50.3 MHz), Bruker AC 250 (63.4 MHz), carbon multi-
plicities were determined by DEPT. Ϫ For 1H NMR, CDCl3 as
Hexacyclo[6.5.1.02,7.04,12.05,10.09,13]tetradec-9(13)-ene-3,6-dione
(6): A solution of 1.36 g (12.65 mmol) of p-benzoquinone in 100 ml
of CH2Cl2 was added under nitrogen at room temp. to a solution of
1.20 g (11.5 mmol) of 5 in 1000 ml of CH2Cl2 by means of a motor-
driven syringe during 24 h. After evaporation of the solvent, flash
chromatography resulted in 0.71 g (29%) of 6 as a colorless oil. Ϫ
solvent, TMS as internal standard; for 13C NMR, CDCl3 (δC
ϭ
77.0). Ϫ Column chromatography: Silica gel (Merck) 60Ϫ230
mesh; petroleum ether (PE, 40Ϫ60°C), ethyl acetate (EA). Ϫ Com-
bustion analyses: Institut für Anorganische Chemie der Univer-
sität Würzburg.
1-Methyl-8-phenyl-hexacyclo[6.5.1.02,7.04,12.05,10.09,13]tetradec-
9(13)-ene-3,6-dione (2a): A solution of 1.95 g (18.0 mmol) of p-
benzoquinone in 100 ml of CH2Cl2 was added under nitrogen at
room temp. to a solution of 3.50 g (18.0 mmol) of 1 in 1000 ml of
CH2Cl2 by means of a motor-driven syringe during 24 h. After
evaporation of the solvent, column chromatography (CH2Cl2/EA,
5:1, Rf ϭ 0.45) resulted in 2.83 g (52%) of 2a as a colorless powder,
m.p. 108Ϫ109°C (ref.[12] 106Ϫ108°C).
IR (CCl4): ν ϭ 2975 cmϪ1, 1725, 1685, 1265, 1090. Ϫ 1H NMR
˜
(CDCl3): δ ϭ 1.35 (d, J ϭ 10.2 Hz, 2 H, 11-Hanti, 14-Hanti), 1.84
(d, J ϭ 10.2 Hz, 2 H, 11-Hsyn, 14-Hsyn), 2.64 (s, 4H), 3.35 (s, 4H).
Ϫ
13C NMR (CDCl3): δ ϭ 42.3 (t, C-11, C-14), 52.3 (d, 4C), 56.6
(d, 4C), 154.9 (s, C-9, C-13), 211.7 (s, 2 CϭO). Ϫ C14H12O2 (212.2):
calcd. C 79.21, H 5.70; found C 79.40, H 5.64.
1-Methyl-8-phenyl-9,13-epoxyhexacyclo[6.5.1.02,7.04,12
.
05,10.09,13]tetradeca-3,6-dione (7): A solution of 80 mg (0.27 mmol)
of compound 2a in 2 ml of CH2Cl2 and 1 mg of tetraphenylpor-
phine (TPP) was irradiated with a 150-W sodium lamp at Ϫ10°C
under constant purging with dry oxygen (syringe needle). After
1-Methyl-5-(4-nitrophenyl)-8-phenylhexacyclo[6.5.1.02,7.04,12
.
05,10.09,13]tetradec-9(13)-ene-3,6-dione (2b) and 1-Methyl-4-(4- evaporation of the solvent, the residue was chromatographed which
nitrophenyl)-8-phenylhexacyclo[6.5.1.02,7.04,12.05,10.09,13]tetradec- resulted in 60 mg (71%) of colorless needles, m. p. 115Ϫ117°C. Ϫ
9(13)-ene-3,6-dione (2c): A solution of 2.60 g (11.3 mmol) of 2-(4-
nitro-phenyl)benzoquinone in 150 ml of CH2Cl2 was added under NMR (CDCl3): δ ϭ 1.33 (dd, J ϭ 1.3, 10.7 Hz, 1 H, 11-Hanti), 1.39
IR (CCl4): ν˜ ϭ 3020 cmϪ1, 2920, 1700, 1680, 1425, 1255. Ϫ 1H
Eur. J. Org. Chem. 1998, 1759Ϫ1762
1761

A. G. Griesbeck, T. Deufel, G. Hohlneicher, R. Rebentisch, J. Steinwascher
FULL PAPER
[8c]
1283Ϫ1289. Ϫ
R. Herges, S. Kammermaier, H. Neumann,
(s, 3H), 1.55 (d, J ϭ 10.7 Hz, 1 H, 14-Hanti), 2.19 (dd, J ϭ 1.6, 10.7
Hz, 1 H, 11-Hsyn), 2.36 (d, J ϭ 10.7 Hz, 1 H, 14-Hsyn), 2.93 (dd, 1
H, J ϭ 2.8, 9.7 Hz, 1 H, 2-H), 3.02 (m, 2 H, 4-H, 5-H), 3.21 (m,
2 H, 10-H, 12-H), 3.43 (dd, J ϭ 2.8, 9.7 Hz, 1 H, 7-H), 7.28Ϫ7.42
(m, 5 H, Ph.-H). Ϫ 13C NMR (CDCl3): δ ϭ 14.6 (q), 37.4 (t), 45.6
(d), 45.9 (d), 51.3 (t), 53.9 (s), 57.2 (d), 57.6 (d), 60.8 (s), 62.1 (s),
62.2 (d), 62.9 (s), 64.7 (d), 126.6 (d), 127.6 (d), 128.8 (d), 137.0 (s),
208.3 (s), 208.4 (s). Ϫ C21H18O3 (318.4): calcd. C 79.20, H 5.70;
found C 78.67, H 5.60. Ϫ Crystallization of the crude material from
methanol resulted in a methanol addition product in 96% yield.[17]
F. Hampel, Liebigs Ann. 1996, 1795Ϫ1800.
[9a] R. Haag, B. Ohlhorst, M. Noltemeyer, A. Schuster, D. Kuck,
[9]
A. de Meijere, J. Chem. Soc., Chem. Commun. 1993,
[9b]
1727Ϫ1729. Ϫ
R. Haag, B. Ohlhorst, M. Noltemeyer, R.
Fleischer, D. Stalke, A. Schuster, D. Kuck, A. de Meijere, J.
Am. Chem. Soc. 1995, 117, 10474Ϫ10485.
[10]
[11]
J.-P. Melder, R. Pinkos, H. Fritz, H. Prinzbach, Angew. Chem.
1990, 102, 105Ϫ109; Angew. Chem. Int. Ed. Engl. 1990, 29,
95Ϫ99.
A variety of non-isolable highly pyramidalized alkenes have
been trapped by Diels-Alder reactions, e.g. cubene with
␾
ഠ 85°:
[11a]P.calEc. aton, M. Maggini, J. Am. Chem. Soc. 1988, 110,
[11b]
13-Hydroxy-1-methyl-9-(4-methyl-3,5-dioxo-1,2,4-triazolin-1-yl)-
8-phenylhexacyclo[6.5.1.02,7.04,12.05,10.09,13]tetradec-9(13)-ene-3,6-
dione (8): A solution of 1.00 g (3.3 mmol) of 2a in 100 ml of aqeous
THF was precooled to Ϫ20°C and a solution of 0.38 g (3.3 mmol)
of MTAD in 20 ml of THF was added within 10 min. After stirring
for 16 h at room temperature, the solvent was evaporated and the
residue dissolved in 5 ml of acetone. After cooling to Ϫ10°C, 0.48
g (35%) of 8 crystallized as colorless needles m.p. 279Ϫ280°C. Ϫ
IR (CCl4): ν˜ ϭ 3280 cmϪ1, 2920, 1735, 1670, 1090, 1070. Ϫ 1H
NMR (CDCl3): δ ϭ 0.72 (s, 3H), 1.39 (d, J ϭ 11.0 Hz, 1 H, 11-
7230Ϫ7232. Ϫ
K. Lukrin, P. Eaton, J. Am. Chem. Soc.
1995, 117, 7652Ϫ7656.
[12]
W. Adam, T. Deufel, R. Finzel, A. G. Griesbeck, J. Hirt, J. Org.
Chem. 1992, 57, 3991Ϫ3994.
[13]
[14]
[15]
A. G. Griesbeck, Chem. Ber. 1990, 123, 549Ϫ554.
A. G. Griesbeck, Synthesis 1990, 144Ϫ147.
Recent application of this dihydropentalene-synthesis have been
described: [15a] K. Jonas, B. Gabor, R. Mynott, K. Angermund,
O. Heinemann, C. Krüger, Angew. Chem. 1997, 109,
1790Ϫ1793; Angew. Chem. Int. Ed. Engl. 1997, 36, 1710Ϫ1714.
[15b]
Ϫ
K. Jonas, P. Kolb, G. Kollbach, B. Gabor, R. Mynott,
K. Angermund, O. Heinemann, C. Krüger, Angew. Chem. 1997,
109, 1793Ϫ1796; Angew. Chem. Int. Ed. Engl. 1997, 36,
1714Ϫ1718.
H
anti), 1.49 (d, J ϭ 11.3 Hz, 1 H, 14-Hanti), 2.31 (d, J ϭ 12.2 Hz,
[16]
[17]
[18]
1 H, 2-H), 2.46 (d, J ϭ 12.2 Hz, 1 H, 7-H), 2.50 (mc, 1 H, 11-
Hsyn), 2.56 (s, 2 H, 4-H, 5-H), 2.63 (s, 3 H), 2.70 (s, 1 H, 12-H),
3.18 (d, J ϭ 11.3 Hz, 1 H, 14-Hsyn), 4.69 (s, 1 H, 10-H), 5.72 (s, 1
H, OH), 6.72Ϫ6.96 (m, 5 H, Ph.-H), 8.44 (s, 1 H, NH). Ϫ 13C
NMR (CDCl3): δ ϭ 15.9 (q), 24.7 (q), 43.3 (t), 50.3 (d), 52.3 (d),
52.7 (d), 53.5 (d), 54.2 (t), 57.4 (s), 57.8 (d), 60.0 (d), 63.9 (s), 80.1
(s), 91.3 (s), 126.9 (d), 127.6 (d), 128.0 (d), 138.3 (s), 153.3 (s), 153.4
(s), 208.5 (s), 210.7 (s). Ϫ C24H23N3O4 (417.5): calcd. C 69.05, N
10.07, H 5.55; found C 68.93, N 9.93, H 5.70.
P. D. Bartlett, A. J. Blakeney, M. Kimura, W. H. Watson, J.
Am. Chem. Soc. 1980, 102, 1383Ϫ1390.
K. Peters, E.-M. Peters, H. G. von Schnering, A. G. Griesbeck,
T. Deufel, Z. Kristallogr. 1996, 211, 435Ϫ436.
A. L. Baumstark, A. Rodriguez, in Handbook of Organic Photo-
chemistry and Photobiology (Eds.: W. Horspool, P.-S. Song)
CRC, Boca Raton, 1995, p. 335Ϫ345.
[19] [19a]
T. H. W. Poon, S. H. Park, Y. Elemes, C. S. Foote, J. Am.
[19b]
Chem. Soc. 1995, 117, 10468Ϫ10473. Ϫ
I. Smounou, S.
Khan, C. S. Foote, Y. Elemes, I. M. Mavridis, A. Pantidou, M.
Orfanopoulos, J. Am. Chem. Soc. 1995, 117, 7081Ϫ7087.
N. L. Allinger, X. Zhou, J. Bergsma, J. Mol. Struct. (Theochem)
1994, 312, 69.
[20]
[21]
[22]
[23]
J. J. P. Stewart, J. Comput. Chem. 1989, 10, 209, 221Ϫ264.
A. D. Becke, J. Chem. Phys. 1993, 98, 5648Ϫ5652.
P. C. Hariharan, J. A. Pople, Theoret. Chim. Acta 1973, 28,
213Ϫ222.
M. J. Frisch, G. W. Trucks, H. B. Schlegel, P. M. W. Gill, B. G.
Johnson, M. A. Robb, J. R. Cheeseman, T. Keith, G. A. Peters-
son, J. A. Montgomery, K. Raghavachari, M. A. Alaham, V. G.
Zakrzewski, V. G.; J. V. Ortiz, J. B. Foresman, J. Cioslowski, B.
B. Stefanov, A. Nanayakkara, M. Challacombe, C. Y. Peng, P.
Y. Ayala, W. Chen, M. W. Wong, J. L. Andres, E. S. Replogle,
R. Gomperts, R. L. Martin, D. J. Fox, J. S. Binkley, D. J. Derees,
J. Baker, J. P. Stewart, M. Head-Gordon, C. Gonzalez, J. A.
Pople, Gaussian 94, Revision B.1, Gaussian Inc., Pittsburgh, PA,
USA, 1995.
αav ϭ(Σθij)/3: S. F. Nelson, T. B. Frigo, Y. Kim, J. Am. Chem.
Soc. 1989, 111, 5387Ϫ5397.
The out-of-plane deformation of a double bond can also be
described using the flap or hinge angle:[27] 180° Ϫ χ ϭ 141°
(χ ϭ 39°) for 6, for the tetradehydrodianthracene 10 χ ϭ 45°,
for C60 χ ϭ 41°.
Ermer, C.-D. Bödecker, Helv. Chim. Acta 1983, 943Ϫ959.
POAV analysis[29] gives a θσα value of 103.3° (9: 103.0°) for
compound 6.
R. C. Haddon, J. Am. Chem. Soc. 1990, 112, 3385Ϫ3389.
[98186]
[1] [1a]
W. Luef, R. Keese, Top. Stereochem. 1991, 20, 231Ϫ318. Ϫ
P. D. Bartlett, A. J. Blakeney, G. L. Combs, J. M. Galloy,
A. A. M. Roof, R. Subramanyan, W. J. Winter, C. Wu, in
Stereochemistry and Reactivity of Systems Containing π-Elec-
trons (Ed.: W. H. Watson), VCH, Deerfield Beach, FL, 1983,
p. 75.
[1b]
[24]
[2]
W. T. Borden Chem. Rev. 1989, 89, 1095Ϫ1109.
[3] [3a]
W. H. Watson, J. Galloy, P. D. Bartlett, A. A. M. Roof, J.
[3b]
Am. Chem. Soc. 1981, 103, 2022Ϫ2031. Ϫ
L. A. Paquette,
P. Charumilind, M. C. Böhm, R. Gleiter, L. S. Bass, J. Clardy,
J. Am. Chem. Soc. 1983, 105, 3136Ϫ3147.
[4]
[5]
R. C. Haddon, Science 1993, 261, 1545Ϫ1550.
L. A. Paquette, C.-C. Shen, J. A. Krause, J. Am. Chem. Soc.
1989, 111, 2351Ϫ2352.
[25]
[26]
[6]
R. Pinkos, J.-P. Melder, K. Weber, D. Hunkler, H. Prinzbach, J.
Am. Chem. Soc. 1993, 115, 7173Ϫ7191.
[7] [7a]
R. L. Viavatenne, F. D. Greene, L. D. Cheung, R. Majeste,
[7b]
L. M. Trefonas, J. Am. Chem. Soc. 1974, 96, 4342Ϫ4343. Ϫ
Second X-ray analysis: S. Kammermeier, P. G. Jones, R. Herges,
Angew. Chem. 1996, 108, 2834Ϫ2836; Angew. Chem. Int. Ed.
Engl. 1996, 35, 2669Ϫ2671.
[27]
[28]
[8] [8a]
R. Herges, H. Neumann, F. Hampel, Angew. Chem. 1994,
106, 1024Ϫ1026; Angew. Chem. Int. Ed. Engl. 1994, 33,
[29]
[8b]
993Ϫ995. Ϫ
R. Herges, H. Neumann, Liebigs Ann. 1995,
1762
Eur. J. Org. Chem. 1998, 1759Ϫ1762
