Synthesis of Benzopyrans by Pd(II)-
or Ru(II)-Catalyzed CÀH Alkenylation
of 2‑Aryl-3-hydroxy-2-cyclohexenones
Suresh Reddy Chidipudi, Martin D. Wieczysty, Imtiaz Khan, and Hon Wai Lam*
EaStCHEM, School of Chemistry, University of Edinburgh, Joseph Black Building,
The King’s Buildings, West Mains Road, Edinburgh, EH9 3JJ, United Kingdom
h.lam@ed.ac.uk
Received December 11, 2012
ABSTRACT
2-Aryl-3-hydroxy-2-cyclohexenones are shown to be competent substrates for palladium- and ruthenium-catalyzed CÀH alkenylation reactions
with terminal alkenes, providing, in most cases, benzopyrans.
The metal-catalyzed alkenylation of aromatic C(sp2)ÀH
bonds, directed by a coordinating functional group, has
proven to be a versatile strategy in organic synthesis,1À3
successfully complementing alternatives such as the
MizorokiÀHeck reaction4,5 and the FujiwaraÀMoritani
reaction.6,7 Directing groups not only offer enhanced
reactivity but also high site selectivity, which minimizes
the formation of unwieldy mixtures of positional isomers.1À3
Strategically, however, the use of directing groups can be a
limitation, especially if several steps are required to convert
the directing group intothe final desired functional group.8
Nevertheless, this drawback is mitigated by the continued
development of new procedures that employ an expanded
range of directing groups, thus increasing the toolbox of
methods available for catalytic CÀH alkenylation and
allowing access to a greater diversity of products.
(3) For some of the most recent representative examples, see: (a)
Ueyama, T.; Mochida, S.; Fukutani, T.; Hirano, K.; Satoh, T.; Miura,
M. Org. Lett. 2011, 13, 706–708. (b) Ackermann, L.; Pospech, J. Org.
Lett. 2011, 13, 4153–4155. (c) Arockiam, P. B.; Fischmeister, C.;
Bruneau, C.; Dixneuf, P. H. Green Chem. 2011, 13, 3075–3078. (d)
Leow, D.; Li, G.; Mei, T.-S.; Yu, J.-Q. Nature 2012, 486, 518–522. (e)
€
Schroder, N.; Besset, T.; Glorius, F. Adv. Synth. Catal. 2012, 354, 579–
583. (f) Ackermann, L.; Wang, L.; Wolfram, R.; Lygin, A. V. Org. Lett.
2012, 14, 728–731. (g) Zhu, C.; Falck, J. R. Chem. Commun. 2012, 48,
1674–1676. (h) Yu, M.; Xie, Y.; Xie, C.; Zhang, Y. Org. Lett. 2012, 14,
2164–2167. (i) Graczyk, K.; Ma, W.; Ackermann, L. Org. Lett. 2012, 14,
(1) For some leading references, see: (a) Miura, M.; Tsuda, T.; Satoh,
T.; Nomura, M. Chem. Lett. 1997, 1103–1104. (b) Miura, M.; Tsuda, T.;
Satoh, T.; Pivsa-Art, S.; Nomura, M. J. Org. Chem. 1998, 63, 5211–5215.
(c) Boele, M. D. K.; van Strijdonck, G. P. F.; de Vries, A. H. M.; Kamer,
P. C. J.; deVries, J. G.; vanLeeuwen, P. W. N. M. J. Am. Chem. Soc. 2002,
124, 1586–1587. (d) Ueura, K.; Satoh, T.; Miura, M. Org. Lett. 2007, 9,
1407–1409. (e) Ueura, K.; Satoh, T.; Miura, M. J. Org. Chem. 2007, 72,
5362–5367. (f) Kwon, K.-H.; Lee, D. W.; Yi, C. S. Organometallics 2010,
29, 5748–5750.
€
4110–4113. (j) Shi, Z.; Schroder, N.; Glorius, F. Angew. Chem., Int. Ed.
2012, 51, 8092–8096. (k) Liang, Z.; Ju, L.; Xie, Y.; Huang, L.; Zhang, Y.
Chem.;Eur. J. 2012, 18, 15816–15821. (l) Li, J.; Kornhaa; Ackermann,
L. Chem. Commun. 2012, 48, 11343–11345. (m) Zhen, W.; Wang, F.;
Zhao, M.; Du, Z.; Li, X. Angew. Chem., Int. Ed. 2012, 51, 11819–11823.
(4) Seminal references: (a) Mizoroki, T.; Mori, K.; Ozaki, A. Bull.
Chem. Soc. Jpn. 1971, 44, 581. (b) Heck, R. F.; Nolley, J. P. J. Org. Chem.
1972, 37, 2320–2322.
(5) Selected reviews: (a) Heck, R. F. Acc. Chem. Res. 1979, 12, 146–
151. (b) Heck, R. F. Org. React. 1982, 27, 345–390. (c) Brase, S.; de
(2) For representative reviews: (a) Chen, X.; Engle, K. M.; Wang
D.-H.; Yu, J.-Q. Angew. Chem., Int. Ed. 2009, 48, 5094–5115. (b) Lyons,
T. W.; Sanford, M. S. Chem. Rev. 2010, 110, 1147–1169. (c) Satoh, T.;
Miura, M. Chem.;Eur. J. 2010, 16, 11212–11222. (d) Yeung, C. S.;
Dong, V. M. Chem. Rev. 2011, 111, 1215–1292. (e) Engle, K. M.; Mei
T.-S.; Wasa, M.; Yu, J.-Q. Acc. Chem. Res. 2012, 45, 788–802. (f) Song,
G.; Wang, F.; Li, X. Chem. Soc. Rev. 2012, 41, 3651–3678. (g) Patureau,
F. W.; Wencel-Delord, J.; Glorius, F. Aldrichimica Acta 2012, 45, 31–41.
(h) Arockiam, P. B.; Bruneau, C.; Dixneuf, P. H. Chem. Rev. 2012, 112,
5879–5918. (i) Ackermann, L.; Kozhushkov, S. I. Chem. Sci. 2012,
Advance Article, DOI: 10.1039/C2SC21524A.
€
Meijere, A. In Metal-Catalyzed Cross-Coupling Reactions; de Meijere,
A., Diederich, F., Eds.; Wiley-VCH: New York, 2004; Chapter 5.
(6) A seminal reference: Moritani, I.; Fujiwara, Y. Tetrahedron Lett.
1967, 8, 1119–1122.
(7) Selected reviews: (a) Moritani, I.; Fujiwara, Y. Synthesis 1973,
524–533. (b) Jia, C.; Kitamura, T.; Fujiwara, Y. Acc. Chem. Res. 2001,
34, 633–639. (c) Beccalli, E. M.; Broggini, G.; Martinelli, M.; Sottocornola,
S. Chem. Rev. 2007, 107, 5318–5365. (d) Le Bras, J.; Muzart, J. Chem. Rev.
2011, 111, 1170–1214.
r
10.1021/ol3033835
XXXX American Chemical Society

Yu and co-workers also reported the palladium-catalyzed
hydroxyl-directed CÀH alkenylation of homobenzylic
alcohols.13 However, to our knowledge, the use of 2-aryl-
3-hydroxy-2-cyclohexenones as substrates for metal-catalyzed
directed CÀH alkenylation has not been reported pre-
viously. In this paper, we describe the successful use of
these substrates in the strategy presented in Figure 1B.
Furthermore, these reactions proceed using not only well-
established palladium catalysis1aÀc,2a,b,e but also more
recently developed ruthenium catalysis.3aÀc,14,15
Table 1. Evaluation of Reaction Conditionsa
temp time yield
entry
[M]
Pd(OAc)2
mol % solvent (°C)
(h) (%)b
1
5
DMF
DMF
DMF
120
120
120
5
78
30
7
2
[RuCl2(p-cymene)]2
[RuCl2(p-cymene)]2
[RuCl2(p-cymene)]2
[RuCl2(p-cymene)]2
[RhCp*Cl2]2
2.5
2.5
2.5
2.5
2.5
2.5
15
15
15
15
15
15
3c
4
t-AmOH 90
t-AmOH 90
8
5c
6
61
69
51
Figure 1. CÀH functionalization of 2-aryl-3-hydroxy-2-cyclo-
DMF
120
hexenones (A and B) and bioactive benzopyrans (C).
7c
[RhCp*Cl2]2
t-AmOH 90
a Reactions were conducted using 0.50 mmol of 1a. b Isolated yield.
The present study was initiated by our recent finding that
2-aryl-3-hydroxy-2-cyclohexenones are effective substrates
for ruthenium-catalyzed oxidative annulations with al-
kynes (Figure 1A).9 Proceeding via sequential C(sp2)ÀH
and C(sp3)ÀH functionalization, this process affords a
range of spiroindenes in generally good yields.9 In light of
these results, we wondered whether replacement of the
alkyne with a terminal alkene would enable the corre-
sponding C(sp2)ÀH alkenylation of these substrates to
proceed (Figure 1B). If successful, the initially formed
product 2 would likely undergo cyclization of an enolate
oxygen atom onto the electron-deficient alkene. This
process would be attractive as the resulting benzopyrans
3 resemble the core structures of biologically active natural
c Reaction conducted in the presence of K2CO3 (2.0 equiv).
This study began with an investigation of metal pre-
catalysts and reaction conditions for the reaction of
3-hydroxy-2-phenyl-2-cyclohexenone (1a) with phenyl vinyl
sulfone, using Cu(OAc)2 (2.1 equiv) as the oxidant (Table 1).16
Pleasingly, Pd(OAc)2 (5 mol %) provided benzopyran
