DonorꢀAcceptor Segregated
Paracyclophanes Composed of
Naphthobipyrrole and Stacked
Fluoroarenes
Masayoshi Takase,* Ayumi Inabe, Yuki Sugawara, Wataru Fujita, Tohru Nishinaga,*
and Kotohiro Nomura
Department of Chemistry, Graduate School of Science and Engineering,
Tokyo Metropolitan University, Hachioji, Tokyo 192-0397, Japan
mtakase@tmu.ac.jp; nishinaga-tohru@tmu.ac.jp
Received March 31, 2013
ABSTRACT
The expeditious synthesis of donorꢀacceptor segregated paracyclophanes has been achieved by a selective SNAr reaction of hexafluorobenzene
with o-dipyrrolylbenzenes and subsequent cyclodehydrogenation. An orthogonally arranged DꢀA segregated structure was confirmed by X-ray
crystallography. The combined results of DFT calculations and absorption spectra revealed the charge transfer (CT) nature from the
naphthobipyrrole (donor) to the stacked fluoroarene moiety (acceptor).
Cyclophanes possessing a rigid and stacked structure
such as [2,2]paracyclophane have attracted a great deal of
attention due to the interest in strongly stacked π-systems.1,2
Such stacked/strained π-systems are regarded as excellent
models for studying not only molecular design and synthesis3
but also optical and electrical properties.4 Recently, π-stacked
structures have been used in the fields of molecular electronics
as (super)conductors and field effect transistors (FET)
and molecular photonics as organic light emitting diodes
(OLED).5 Considering electrical conductors and super-
conductors as well as photovoltaic cells, donorꢀacceptor
segregated structures are a key issue. Such structures have
typically been achieved in the solid state as cocrystals
or mixed supramolecular assemblies, which resulted in
difficulties tuning the crystalline6 and supramolecular
morphologies,7 respectively. On the basis of these findings,
