The synthesis and characterization of 4-isopropylanilino derivatives
of cyclotriphosphazene
⇑
Aylin Uslu , Sßule Sßahin Ün, Adem Kılıç, Sßükriye Yılmaz, Fatma Yuksel, Ferda Hacıveliog˘lu
Department of Chemistry, Gebze Institute of Technology, PB. 141, 41400 Kocaeli, Turkey
a r t i c l e i n f o
a b s t r a c t
Article history:
Hexachlorocyclotriphosphazene N3P3Cl6 and gem-disubstituted cyclotriphosphazene derivatives N3P3-
Cl4X2 (X = Ph, PhS, PhNH) were reacted with 4-isopropylaniline to give geminal tetra and hexa substi-
tuted compounds (1a–4a, 1b–4b). The compounds (1a–4a, 1b–4b) were separated by column
chromatography on silica gel and analyzed by elemental analysis, mass spectrometry, and 31P and 1H
NMR spectroscopies, and also crystal structures of 2a and 3b were determined by X-ray crystallography.
Compounds were prepared to cover the normal ranges of C-, S- and N-substituents in cyclophosphazene
(X = Cl, Ph, SPh, NHPh). Compounds (1a–4a, 1b–4b) were reported for the first time. We additionally
investigated the effect of substituent (Cl, Ph, SPh, NHPh) on 31P NMR chemical shifts of neighboring phos-
phorus atoms.
Received 22 November 2012
Received in revised form 17 May 2013
Accepted 24 May 2013
Available online 3 June 2013
Keywords:
Cyclotriphosphazene
31P NMR
X-ray
4-Isopropylaniline
Ó 2013 Elsevier B.V. All rights reserved.
1. Introduction
2. Experimental
Phosphazenes are cyclic or linear molecules that contain a
framework of alternating phosphorus and nitrogen atoms with
two substituent groups attached to each phosphorus atom [1]. Cyc-
lic phosphazenes are an important family of inorganic ring systems
[2,3] which have attracted the attention of inorganic chemists in
recent years because of their applications as flame retardants, anti-
microbial agents, lithium-ion batteries, liquid crystals, organic
light emitting diodes, membrane hydrogels, drug carriers, surfac-
tants and phase transfer catalysts [4–16]. Also the preparation of
new cyclophosphazene derivatives is very straightforward by a
substitution reaction of chlorine atoms on the phosphorus and
their physical and chemical properties can be tailored via appropri-
ate selection of substituted groups of phosphorus atoms [17–20].
In this work, we report the synthesis of the geminal 4-isopropy-
lanilino substituted derivatives of cyclotriphosphazenes N3P3Cl4X2
(X = Cl, Ph, PhS, PhNH). The structures of obtaining compounds
(1a–4a, 1b–4b) were characterized by elemental analysis, mass
spectrometry, and 31P and 1H NMR spectroscopies and crystal
structures of 2a and 3b were also confirmed by X-ray crystallogra-
phy. In addition, relationships between substituents effect (Cl, Ph,
SPh, NHPh) on phosphazene ring and 31P NMR chemical shifts of
4-isopropylanilino substituted phosphorus were obtained for com-
pounds (1a–4a) and (1b–4b).
2.1. Materials
Hexachlorocyclotriphosphazene (Otsuka Chemical Co., Ltd.)
was purified by fractional crystallization from hexane. The follow-
ing chemicals were obtained from Merck; triethylamine (>99%), n-
hexane (>96%), benzene (P99.5%), thiophenol (>98.0%), aniline
(>99%), tetrahydrofuran (THF) (P99.0%), dichloromethane
(P99.0%), diethyl ether (P99.0%), anhydrous sodium sulfate
(P99.0%) ethyl acetate (P99.0%) and chloroform-d1, from Alfa Ae-
sar; 4-isopropylaniline (>99%) and toluene (>99%). Column chro-
matography was performed on silica gel (Merck, Kieselgel 60,
230–400 mesh and, Kieselgel 60, 70–230 mesh; for 3 g crude mix-
ture, 100 g silica gel was used in a column of 3 cm in diameter and
60 cm in length).
2.2. Equipment
Elemental analyses were carried out using a Thermo Finnigan
Flash 1112 Instrument. Mass spectra were recorded on a Bruker
MicrOTOF LC–MS spectrometer with the electrospray ionization
method. 31P and 1H NMR spectra were recorded in CDCl3 solutions
on a Varian INOVA 500 MHz spectrometer using 85% H3PO4 as an
external reference for 31P and TMS as an internal reference for 1H.
2.2.1. X-ray crystallography
Intensity data were recorded on a Bruker APEX II QUAZAR dif-
fractometer. Absorption correction by multi-scan has been applied
[21] and space groups were determined using XPREP implemented
⇑
Corresponding author. Tel.: +90 262 6053129; fax: +90 262 6053101.
E-mail address: aylin@gyte.edu.tr (A. Uslu).
0020-1693/$ - see front matter Ó 2013 Elsevier B.V. All rights reserved.
http://dx.doi.org/10.1016/j.ica.2013.05.031

A. Uslu et al. / Inorganica Chimica Acta 405 (2013) 140–146
141
X
X
X
X
X
X
P
N
P
N
P
N
N
N
CH3
CH3
H3C
H3C
N
N
N
N
CH3
CH3
CH3
CH3
H
N
H
N
H
N
Cl
Cl
Cl
Cl
Cl
Cl
H2N
+
+
P
P
P
P
P
NH
P
NH
NH
X = Cl, Ph, SPh, NHPh
CH3
CH3
H3C
CH3
CH3
CH3
(1a-4a)
(1b-4b)
X = Cl
Ph
(1a)
(2a)
(3a)
(4a)
Cl
(1b)
(2b)
(3b)
(4b)
Ph
SPh
NHPh
SPh
NHPh
Scheme 1. The synthesis scheme of compounds (1a–4a, 1b–4b).
in APEX2 [22]. Structures were determined using the direct meth-
ods procedure in SHELXS-97 [23] and refined by full-matrix least
squares on F2 using SHELXL-97 [23]. All non-hydrogen atoms were
refined with anisotropic displacement parameters and C–H hydro-
gen atoms were placed in calculated positions and allowed to ride
on the parent atoms. The final geometrical calculations and the
molecular drawings were carried out with PLATON [24], and MERCURY
[25] programs. Structure determinations have been deposited with
the Cambridge Crystallographic Data Centre with references CCDC-
886526 for structure 2a and CCDC-886527 for structure 3b.
isolated by column chromatography using hexane:ethylacetate
(8:1) to give compounds 2a (0.23 g, 31.6%, mp. 155.0 °C) and 2b
(0.46 g, 48.1%, mp. 212.3 °C). Compound 2a was crystallized from
hexane-dichloromethane (1:4).
2.3.3. Reaction of N3P3Cl4(SPh)2 with 4-isopropylaniline to give
compounds 3a and 3b
Triethylamine (0.70 mL, 5.05 mmol) and 4-isopropylaniline
(0.68 mL, 5.05 mmol) in 10 mL dry THF were added to a stirred
solution of N3P3Cl4(SPh)2 (0.5 g, 1.01 mmol) dissolved in 10 mL
dry THF at room temperature under an argon atmosphere. The
reaction mixture was refluxed for 10 days and was followed by
TLC, which indicated product and no starting material remaining.
Triethylamine hydrochloride was then removed by filtration, and
the solvent removed under reduced pressure. The products were
isolated by column chromatography using hexane:THF (8:1) to
give compounds 3a (0.25 g, 35.8%, oily) and 3b (0.07 g, 7.8%, mp.
206.5 °C). Compound 3b was crystallized from hexane–dichloro-
methane (1:2).
2.3. Syntheses
The cyclotriphosphazene derivatives N3P3Cl4X2, (X = Ph, SPh,
NHPh), which we used as starting compounds were prepared as gi-
ven in the literature [26–28]. The reactions of cyclotriphosphazene
and gem-disubstituted derivatives of cyclotriphosphazene with 4-
isopropylaniline were done and compounds (1a–4a, 1b–4b)
(Scheme 1) were obtained.
2.3.4. Reaction of N3P3Cl4(NHPh)2 with 4-isopropylaniline to give
compounds 4a and 4b
2.3.1. Reaction of N3P3Cl6 with 4-isopropylaniline to give compounds
1a and 1b
Triethylamine (0.76 mL, 5.43 mmol) and 4-isopropylaniline
(0.74 mL, 5.43 mmol) in 10 mL dry toluene were added to a stirred
solution of N3P3Cl4(NHPh)2 (0.5 g, 1.09 mmol) dissolved in 10 mL
dry toluene at room temperature under an argon atmosphere.
The reaction mixture was refluxed for 5 days and was followed
by TLC, which indicated product and no starting material remain-
ing. Triethylamine hydrochloride was then removed by filtration,
and the solvent removed under reduced pressure. The products
were isolated by column chromatography using hexane:ethylace-
tate (3:1) to give compounds 4a (0.24 g, 15.3%, mp. 209.3 °C) and
4b (0.36 g, 16.8%, mp. 129 °C).
Triethylamine (1.60 mL,11.52 mmol) and 4-isopropylaniline
(1.58 mL, 11.52 mmol) in 20 mL dry THF were added to a stirred
solution of N3P3Cl6 (1 g, 2.88 mmol) dissolved in 20 mL dry THF
at room temperature under an argon atmosphere. The reaction
mixture was refluxed for 8 days and was followed by TLC, which
indicated product and no starting material remaining. Triethyl-
amine hydrochloride was then removed by filtration, and the sol-
vent removed under reduced pressure. The products were
isolated by column chromatography using hexane:ethylacetate
(3:1) to give compounds 1a (0.86 g, 54.9%, mp. 161.3 °C) and 1b
(0.08 g, 3.7%, mp. 212.3 °C).
2.3.2. Reaction of N3P3Cl4Ph2 with 4-isopropylaniline to give
compounds 2a and 2b
3. Results and discussion
Triethylamine (0.81 mL, 5.80 mmol) and 4-isopropylaniline
(0.79 mL, 5.80 mmol) in 10 mL dry toluene were added to a stirred
solution of N3P3Cl4(Ph)2 (0.5 g, 1.16 mmol) dissolved in 10 mL dry
toluene at room temperature under an argon atmosphere. The
reaction mixture was refluxed for 5 days and was followed by
TLC, which indicated product and no starting material remaining.
Triethylamine hydrochloride was then removed by filtration, and
the solvent removed under reduced pressure. The products were
3.1. Syntheses and characterizations of compounds 1a–4a, 1b–4b
Compounds 1a–4a and 1b–4b were obtained from the reactions
of hexachlorocyclotriphosphazene, N3P3Cl6 and gem-disubstituted
cyclotriphosphazene derivatives, N3P3Cl4X2 (X = Ph, PhS, PhNH)
with 4-isopropylaniline (Scheme 1). In present work, compounds
were prepared to cover the normal ranges of Cl-, C-, S- and N-sub-
stituents in di- or tetra- substituted 4-isopropylanilino derivatives
