Fluorescence Control of Boron
Enaminoketonate Using a Rotaxane Shuttle
Yasuhito Koyama,*,† Tohru Matsumura,‡ Tatsuto Yui,§ Osamu Ishitani, and
Toshikazu Takata*,‡
Catalysis Research Center, Hokkaido University, N21 W10, Kita-ku,
Sapporo 001-0021, Japan, Department of Organic and Polymeric Materials, Tokyo Institute
of Technology, 2-12-1 (H-126), Ookayama, Meguro, Tokyo 152-8552, Japan, Department
of Material Science and Technology, Faculty of Engineering, Niigata University,
Igarashi 2-8050, Niigata 950-2181, Japan, and Department of Chemistry,
Tokyo Institute of Technology, 2-12-1 (E1-9), Ookayama, Meguro, Tokyo 152-8551, Japan
yasuhito.koyama@cat.hokudai.ac.jp; ttakata@polymer.titech.ac.jp
Received July 15, 2013
ABSTRACT
The effect of rotaxane shuttling on the fluorescence properties of a fluorophore was investigated by exploiting fluorophore-tethered [2]rotaxanes.
A fluorescent boron enaminoketonate (BEK) moiety was introduced in a rotaxane via transformation of an isoxazole unit generated as a result of
an end-capping reaction using a nitrile N-oxide. The rotaxane exhibited a red shift of the fluorescence maximum along with a remarkable
enhancement of the fluorescence quantum yield through wheel translation to the fluorophore.
Boron enaminoketonates (BEKs) are a new type of
boron-chelating dye.1 Their optical properties feature a
large Stokes shift and high-molarabsorption coefficient (ε)
that are quite similar to those of boron diketonates. Boron
diketonates are useful in molecular probes,2 lasers,3 and in
optical sensing devices,4 which are capable of incorporat-
ing various organic backbones.
attracted much interest as a new concept for improving
the electro-optical properties of fluorophores via static
encapsulation, because the method enables direct modifi-
cation of such properties without any structural change
in the fluorophore itself.5,6 Considering such studies, we
envisaged that the statistical and dynamic coverage of a
fluorophore moiety on the rotaxane axle via wheel shut-
tling may diminish quenching to a certain extent by an
On the other hand, mechanically interlocked molecules,
such as rotaxanes, catenanes, and polyrotaxanes, have
