a Schrock alkylidyne.[7] From the synthetic vantage point,
however, their use is desirable as they are often accessible in
fewer steps. The first successful metathesis reactions of
terminal alkynes have been reported only very recently
using catalysts with barely basic ancillary ligands.[11,12] Yet,
attempted ring closure of di-terminal diyne substrates gave
variable outcomes, which might be explained, at least in part,
by the particular constraints of macrocyclization; in contrast,
reactions of substrates that comprise one terminal and one
internal alkyne seem to be more robust.[12] However, all
available information derives from a small set of simple
model compounds, and this tactic definitely needs further
validation. The mandelalide case, invoking an elaborate
cyclization precursor of type B, provides a compelling test.
The required acid sector C was readily prepared from
propane-1,3-diol (Scheme 2). An iridium-catalyzed two-
directional Krische allylation furnished multigram amounts
of the known C2-symmetric diol 4 with exquisite levels of
diastereo- and enantioselectivity and hence served as a prac-
tical entry point.[13] Desymmetrization by iodoetherification
followed by TBS protection afforded alkyl iodide 5,[14] which
was reacted with the lithium enolate of 6. Although somewhat
forcing conditions were needed for this alkylation to proceed,
the methyl-branched chiral center was set with impeccable
selectivity (d.r. = 97:3).[15] Reductive cleavage of the auxiliary
preceded chain extension by cross metathesis with methyl
acrylate.[16] Subsequent oxidation of the primary alcohol
terminus led to the corresponding aldehyde 8, which was
exposed to the lithium anion of 14 to give the desired enyne
10. The yield, however, was modest and variable and could
not be improved, despite considerable experimentation.
Therefore, aldehyde 8 was first subjected to a Takai olefina-
tion[17–19] to give alkenyl iodide 9, which was amenable to
a modified Suzuki propynylation;[20] this reliable sequence
was much better suited for material throughput. Somewhat
unexpectedly though, the saponification of the methyl ester in
10 gave rather complex mixtures; best results were obtained
with Me3SiOK in Et2O, although partial deconjugation of the
double bond could not be avoided even under these mild
conditions (ca. 8%). This outcome, albeit a slight complica-
tion with respect to product characterization, was inconse-
quential and could be rectified prior to macrocyclization (see
below).
The second major building block D was prepared as
shown in Scheme 3. Silylation of commercially available 15
followed by cobalt-catalyzed carbonylative epoxide opening
in the presence of N-(trimethylsilyl)morpholine opened
a convenient entry into amide 17, which reacted with 1-
propenylmagnesium bromide (18) to give enone 19 in good
overall yield.[21,22] In parallel, the terminal alkene 23 was
prepared by a copper/TEMPO-co-catalyzed air oxidation of
20[23] followed by scandium triflate catalyzed crotylation of
the resulting aldehyde 21 with the chlorosilane donor 31. As
expected, this reaction was distinguished by excellent dia-
stereo- and enantioselectivity in favor of the syn-configured
product 22 (d.r. = 98:2, 94% ee).[24] Cross-metathesis of the
derived TES ether 23 with enone 19 worked best using
complex 32 as the catalyst.[25] A SmI2-catalyzed Evans–
Tishchenko reaction of product 24 with an excess of
iPrCHO set the anti-configured 1,3-diol motif while discrim-
inating the two alcohol groups at the same time.[26,27]
Compound 25 thus formed was swiftly elaborated into the
homoallylic alcohol 26 as an adequate precursor for the
signature tetrahydrofuran motif yet to be closed. A brief
screening of several conceivable [I+] or [PhSe+] sources
suggested that a selenoetherification under acidic conditions
was most promising, provided the system was operated in the
presence of a catalytic Lewis base activator.[28] Specifically,
treatment of 26 with a slight excess of N-(phenylselenyl)ph-
thalimide and trifluoroacetic acid in the presence of catalytic
=
amounts of Ph3P S in CH2Cl2 at low temperature furnished
product 27 in high yield and excellent selectivity (d.r. = 14:1).
Attempted deselenation over Raney Ni with concomitant
cleavage of the terminal benzyl ether gave erratic results.
Therefore, this compound was first subjected to deselenation
under free-radical conditions followed by hydrogenolysis of
the benzyl ether over Pearlmanꢀs catalyst. The resulting
alcohol was oxidized to give the rather sensitive aldehyde 28.
Although treatment with diazophosphonate 33 under stan-
dard conditions (K2CO3, MeOH)[29] provided alkyne 29,
substantial epimerization at the C17 position through
a retro-oxa-Michael/Michael process was noticed. Gratify-
ingly, this stereochemical erosion could be suppressed by
activation of 33 with NaOMe in THF prior to addition of the
aldehyde at low temperature.[30] The terminal alkyne 30 thus
formed was meant to serve in the projected alkyne metathesis
Scheme 2. a) [Ir(cod)Cl]2 (5 mol%), 12 (10 mol%), 3-nitro-4-chloroben-
zoic acid (20 mol%), Cs2CO3, 1,4-dioxane, 908C, 71% (d.r.ꢁ29:1,
99% ee); b) I2, NaHCO3, MeCN, ꢀ408C, 81% (d.r.=5:1); c) TBSOTf,
2,6-lutidine, CH2Cl2, 08C, 96%; d) LDA, LiCl, THF, 08C!458C, 76%
(d.r.=97:3); e) LDA, BH3·NH3, THF, 08C!RT, 96%; f) methyl acrylate,
13 (3 mol%), CH2Cl2, 83% (+ 7% of the Z-isomer); g) Dess–Martin
periodinane, CH2Cl2, 08C!RT, 77%; h) CHI3, CrCl2·THF, THF, ꢀ88C,
aq. serine work-up, 72% (+8% of the Z-isomer); i) propynyl sodium,
B(OMe)3, [Pd(dppf)Cl2]·(CH2Cl2) (10 mol%), THF, 708C, 81%;
j) Me3SiOK, Et2O, 80% (+7% of the b,g-isomer); k) 14, LiHMDS,
THF, ꢀ788C, 41–54% (E/Z=7:1). Aux*=(1S,2S)-2-(methyl-l2-azanyl)-
1-phenylpropan-1-ol, cod=1,5-cyclooctadiene, dppf=1,1’-bis(diphenyl-
phosphino)ferrocene, LDA=lithium diisopropylamide, LiHMDS=
lithium hexamethyldisilazide, Mes=2,4,6-trimethylphenyl, TBS=tert-
butyldimethylsilyl, Tf=trifluoromethanesulfonyl.
