Diels–Alder Reaction of 9-Substituted Anthracenes
699
eter using either residual solvent signals as an internal reference or
from internal TMS on the δ scale (for CDCl3: δH = 7.24 ppm, δC =
77.0 ppm; for DMSO-d6: δH = 2.52 ppm, δC = 41.23 ppm). The
chemical shifts (δ) are reported in ppm. The following abbreviations
are used: m (multiplet), s (singlet), br s (broad singlet), d (doublet),
t (triplet) dd (doublet of doublet). FTIR spectra were obtained using
FTIR spectrophotometer as KBr disc and reported in cm–1. All melt-
ing points were measured in open glass capillary and values are un-
corrected using a melting point apparatus. Crystal structures were
recorded on a single-crystal X-ray diffractometer.
Anthracen-9-ylmethylbenzoate (1f)
To a solution of 9-anthracenemethanol (200 mg, 0.96 mmol) in dry
CH2Cl2 (10 mL) were added pyridine (152 μL, 7.2 mmol), DMAP
(12 mg, 0.10 mmol), and benzoyl chloride (223 μL, 1.92 mmol) at
0 °C, and the solution was stirred at same temperature for 1 h. The
solvent was removed under removed pressure to obtain a residue
which was purified by column chromatography over silica gel (10%
EtOAc in PE) to furnish the pure compound 1f as pale yellow solid
(180 mg, 67%); mp 118–119 °C. 1H NMR (CDCl3): δ = 8.47 (s, 1
H), 8.38 (d, J = 8.8 Hz, 2 H), 7.99 (d, J = 8.4 Hz, 2 H), 7.92 (d, J =
8.3 Hz, 2 H), 7.43–7.53 (m, 5 H), 7.19–7.29 (m, 2 H), 6.33 (s, 2 H).
13C NMR (CDCl3): δ = 166.8, 133.0, 131.4, 131.2, 130.0, 129.7,
129.2,129.1, 128.5, 128.3, 127.9, 126.7, 126.2, 125.1, 124.0, 123.7,
121.4, 59.4. IR (KBr): 3067, 3002, 2880, 1789, 1603, 1424, 1296,
936 cm–1; Anal. Calcd for C22H16O2: C, 84.59; H, 5.16; O, 10.24.
Found: C, 84.50, H, 5.09, O, 10.21.
9-Anthracenemethanol (1a)
Pale yellow solid; yield: 990 mg (98%); mp 159–162 °C (lit.24 162–
64 °C). 1H NMR (CDCl3): δ = 8.50 (s, 1 H), 8.45 (d, J = 7.5 Hz, 2
H), 8.06 (d, J = 7.5 Hz, 2 H), 7.63–7.52 (m, 4 H), 5.72 (s, 2 H), 1.59
(br s, 1 H) ppm. 13C NMR (CDCl3): δ = 131.6, 131.0, 130.2, 129.2,
128.4, 126.50, 125.1, 123.9, 57.5 ppm. IR (KBr): 3452, 3045, 2961,
2910, 1622, 1443, 1277, 983, 739 cm–1. Anal. Calcd for C15H12O:
C, 86.51; H, 5.81; O, 7.68. Found: C, 86.31; H, 5.79; O, 7.65.
General Procedure for the Cycloaddition Reactions of Citro-
conic Anhydride and 9-Substituted Anthracenes under Ther-
mal Conditions
To a 25 mL round-bottom flask, citroconic anhydride (2, 3 equiv),
and 9-substituted anthracenes 1a–f (1 equiv) were dissolved in tol-
uene (5 mL, c 0.23 M) and stirred at reflux temperature in an oil
bath. After stirring for 72 h, TLC showed completion of reaction.
The solvent was evaporated under reduced pressure, and the residue
was purified by column chromatography using 10% EtOAc in PE to
afford the corresponding adducts in good yields (71–82%).
9-Methoxymethyl Anthracene (1b)
Yellow crystalline solid; yield: 210 mg (70%); mp 89–91 °C (lit.25
92–93 °C). 1H NMR (DMSO-d6): δ = 8.47 (s, 1 H), 8.02 (d, J = 7.8
Hz, 2 H), 7.91 (d, J = 7.8 Hz, 2 H), 7.54–7.39 (m, 2 H), 7.33 (d, J =
7.2 Hz, 2 H), 5.34 (s, 2 H), 3.47 (s, 3 H). 13C NMR (DMSO-d6): δ =
131.5, 130.3, 128.5, 128.2, 127.8, 125.9, 124.5, 124.1, 66.2, 58.1.
IR (KBr): 3023, 2977, 2924, 1623, 1447, 1344, 1188, 1087, 940,
894, 738, 729 cm–1. Anal. Calcd for C16H14O: C, 86.45; H, 6.35; O,
7.20. Found: C, 86.41; H, 6.24; O, 7.15.
9-(Methoxymethyl)-15-methyl-9,10,11,15-tetrahydro-9,10-
[3,4]furanoanthracene-12,14-dione (3a)
Colorless crystalline solid; yield: 342 mg (76%). 1H NMR (CDCl3):
δ = 7.46 (d, J = 7.6 Hz, 1 H), 7.22–7.32 (m, 2 H), 7.06–7.21 (m, 5
H), 4.59–4.65 (q, 2 H), 4.31 (s, 1 H), 3.64 (s, 3 H), 3.14 (s, 1 H), 1.22
(s, 3 H). 13C NMR (CDCl3): δ = 174.8, 169.1, 140.0, 139.5, 138.1,
127.5, 127.4, 127.1, 126.5, 125.9,125.5, 124.0, 122.0, 68.8, 59.4,
53.2, 51.5, 49.1, 22.7. IR (KBr): 3073, 2963, 2930, 2845, 1841,
1745, 1439, 1235, 918, 751 cm–1. Anal. Calcd for C21H18O4: C,
75.43; H, 5.43; O, 19.14. Found: C, 75.25; H, 5.40; O, 19.03.
9-Ethoxymethyl Anthracene (1c)
To a solution of 9-anthracenemethanol (300 mg, 1.44 mmol) in an-
hydrous THF (10 mL) was added NaH (150 mg, 8.6 mmol), and the
solution was stirred at r.t. for 3 min. Then iodoethane (347 μg, 4.32
mmol) was added at r.t. The mixture was stirred for 12 h at r.t. and
then poured in the H2O. The aqueous layer was extracted with EtO-
Ac (3 × 10 mL). The combined organic layers were washed with
brine (20 mL) and dried over Na2SO4. The solvent was removed un-
der reduced pressure to obtain a residue which was purified by col-
umn chromatography over silica gel (eluent: 2% EtOAc in PE) to
furnish the pure compound 1c as yellow solid (300 mg, 88%); mp
101–103 °C. 1H NMR (CDCl3): δ = 7.53 (d, J = 15.4 Hz, 1 H), 7.32
(d, J = 7.1 Hz, 1 H), 7.28 (t, J = 4.3 Hz, 1 H), 7.22 (d, J = 4.6 Hz, 2
H), 7.11–7.20 (m, 4 H), 4.67 (s, 1 H), 3.82–3.89 (q, 2 H), 1.36 (t, J
= 7.3 Hz, 3 H). 13C NMR (CDCl3): δ = 139.3, 137.8, 129.7, 129.5,
128.2, 128.0, 127.4, 127.3, 127.0, 126.5, 126.2, 126.0, 125.2, 124.1,
71.2, 67.2,15.2. IR (KBr): 3023, 3012, 2934, 2922, 2843, 1403,
1223, 915, 723 cm–1. Anal. Calcd for C17H16O: C, 86.40; H, 6.82;
O, 6.77. Found: C, 86.21; H, 6.70; O, 6.65.
Compound 3b
Colorless solid; yield: 362 mg (82%). 1H NMR (CDCl3): δ = 7.52
(d, J = 7.8 Hz, 1 H), 7.27–7.33 (m, 2 H), 7.22 (d, J = 4.6 Hz, 1 H),
7.11–7.20 (m, 4 H), 4.63–4.70 (q, 2 H), 4.32 (s, 1 H), 3.84–3.90 (q,
2 H), 3.17 (s, 1 H), 1.35 (t, J = 6.9 Hz, 3 H), 1.25 (s, 3 H). 13C NMR
(CDCl3): δ = 174.9, 169.1, 140.3, 140.1, 139.6, 138.3, 127.5, 127.4,
127.0, 126.5, 125.8, 125.4, 124.2, 122.1, 67.2, 66.6, 53.2, 53.1,
51.5, 49.1, 22.7, 15.2. IR (KBr): 3083, 3061, 2949, 2932, 2872,
1843, 1759, 1423, 1229, 921, 753 cm–1. Anal. Calcd for C22H20O4:
C, 75.84; H, 5.79; O, 18.37. Found: C, 75.34; H, 5.70; O, 18.27.
Compound 3c
9-Bromomethylanthracene (1d)
Colorless crystalline solid; yield: 299 mg (71%). 1H NMR (CDCl3):
δ = 7.63 (s, 1 H), 7.34 (d, J = 6.8 Hz, 1 H), 7.18–7.28 (m, 6 H), 4.91
(br s, 1 H), 4.51 (br s, 1 H), 4.33 (s, 1 H), 3.40 (s, 1 H), 1.29 (s, 3 H).
13C NMR (CDCl3): δ = 174.9, 168.1, 140.5, 139.8, 138.5, 127.9,
127.4, 127.2, 126.8, 126.1, 125.5, 124.8, 122.3, 53.1, 51.4, 48.1,
44.0, 22.7. IR (KBr): 3079, 2961, 2934, 2861, 2853, 1840, 1762,
1430, 1215, 925, 750 cm–1. Anal. Calcd for C20H15BrO3: C, 62.68;
H, 3.95; Br, 20.85; O, 12.52. Found: C, 62.61; H, 3.75; Br, 20.35;
O, 12.42.
Yellow solid (1.6 g, 82%); mp 145–147 °C (lit.26 143–146 °C). 1H
NMR (DMSO-d6): δ = 7.89 (s, 1 H), 7.27–7.65 (m, 8 H), 5.11 (s, 2
H). 13C NMR (DMSO-d6): δ = 131.8, 130.2, 128.5, 127.3, 125.9,
125.7,125.2, 31.0. IR (KBr): 3067, 2958, 2832, 1605, 1462, 1380,
1197, 912 cm–1. Anal. Calcd for C15H11Br: C, 66.44; H, 4.09; Br,
29.47. Found: C, 66.23; H, 4.11; Br, 29.35.
Anthracen-9-ylmethylacetate (1e)
Yellow crystalline solid; yield: 240 mg (67%); mp 114–115 °C
(lit.27 115–116 °C). 1H NMR (DMSO-d6): δ = 8.47 (s, 1 H), 8.29 (d,
J = 9.2 Hz, 2 H), 7.99 (d, J = 8.8 Hz, 2 H), 7.43–7.55 (m, 4 H), 6.11
(s, 2 H), 2.04 (s, 3 H). 13C NMR (DMSO-d6): δ = 171.3, 131.4,
131.0, 129.2, 129.1, 126.7, 126.2, 125.1, 123.9, 58.8, 21.0. IR
(KBr): 3206, 2316, 1658, 1605, 1462, 1380, 1197, 912, 735 cm–1;
Anal. Calcd for C17H14O2: C, 81.58; H, 5.64; O, 12.78. Found: C,
81.50; H, 5.56; O, 12.70.
Compound 3d
Colorless crystalline solid; yield: 317 mg (78%). 1H NMR (CDCl3):
δ = 7.89(d, J = 7.6 Hz, 2 H), 7.20–7.40 (m, 11 H), 5.75 (d, J = 16.0
Hz, 1 H), 5.57 (d, J = 12.0 Hz, 1 H), 4.74 (s, 1 H), 2.97 (s, 1 H), 1.27
(s, 3 H). 13C NMR (CDCl3): δ = 173.1, 169.7, 166.4, 140.1, 138.3,
138.2, 138.1, 133.4, 129.8, 129.5, 128.5, 127.9, 127.8, 127.5, 127.1,
125.3, 125.2, 124.3, 124.2, 60.7, 57.5, 54.8, 51.1, 46.2, 20.8. IR
(KBr): 3075, 3020, 2934, 2863, 2839, 1842, 1786, 1673, 1453,
1289, 915, 743 cm–1. Anal. Calcd for C27H20O5: C, 76.40; H, 4.75;
O, 18.85. Found: C, 76.10; H, 4.25; O, 18.80.
