A practical synthesis of (4-(spiro[chromane-2,4'-piperidin]- 6-yl)phenyl)methanol as a key intermediate of novel GPR119 agonist

Article abstract of DOI:10.3987/COM-14-13012

Starting from commercially available 4'-hydroxy-[1,1'-biphenyl]- 4-carboxylic acid, a practical synthesis has been established in high yield for (4-(spiro[chromane-2,4'-piperidin]-6-yl)phenyl)methanol as a key intermediate for a novel GPR119 agonist.

Full text of DOI:10.3987/COM-14-13012

1632
HETEROCYCLES, Vol. 89, No. 7, 2014
HETEROCYCLES, Vol. 89, No. 7, 2014, pp. 1632 - 1643. © 2014 The Japan Institute of Heterocyclic Chemistry
Received, 23rd April, 2014, Accepted, 23rd May, 2014, Published online, 4th June, 2014
DOI: 10.3987/COM-14-13012
A PRACTICAL SYNTHESIS OF
(4-(SPIRO[CHROMANE-2,4'-PIPERIDIN]- 6-YL)PHENYL)METHANOL
AS A KEY INTERMEDIATE OF NOVEL GPR119 AGONIST
Tomoaki Koshizawa, Hayato Hosoi, Gen Watanabe, Toshiharu Morimoto,
Tadaaki Ohgiya, and Kimiyuki Shibuya*
Tokyo New Drug Research Laboratories, Pharmaceutical Division, Kowa
Company, Ltd., 2-17-43, Noguchicho, Higashimurayama, Tokyo 189-0022,
Japan; E-mail: k-sibuya@kowa.co.jp
Abstract – Starting from commercially available 4'-hydroxy-[1,1'-biphenyl]-
4-carboxylic acid, a practical synthesis has been established in high yield for
(4-(spiro[chromane-2,4'-piperidin]-6-yl)phenyl)methanol as a key intermediate for
a novel GPR119 agonist.
INTRODUCTION
GPR119 is a G protein-coupled receptor predominantly expressed in pancreatic islet -cells and
incretin-releasing cells in the gastrointestinal tract. GPR119 agonists are reported to stimulate
glucose-dependent insulin secretion in vitro and lower elevated blood-glucose levels in vivo.1 Therefore,
these agents have emerged as a promising target for the treatment of type 2 diabetes and obesity by
improving glucose homoeostasis.2
During the course of our drug discovery program, we identified (R)-1,1,1-trifluoropropan-2-yl 6-
(4-(((pyridin-2-ylmethyl)sulfonyl)methyl)phenyl)spiro[chromane-2,4'-piperidine]-1'-carboxylate (1) as a
highly potent GPR119 agonist (EC50 = 54 nM) with a hypoglycemic effect (3 mg/kg po. 30% decrease in
OGTT/C57BL mice).3 We required a large amount of 1 to conduct a safety test.
In the initial production of 1, we performed a palladium-mediated coupling reaction between
(4-(hydroxymethyl)phenyl)boronic acid (4) and tert-butyl 6-bromospiro[chromane-2,4'-piperidine]-
1'-carboxylate (5)4 to produce the key intermediate 3 leading to 2 as a precursor of 1 in moderate yield, as
shown in Figure 1.

HETEROCYCLES, Vol. 89, No. 7, 2014
1633
N
HO
S
O O
O
O
1
N
N
O
CF3
H
2: X=H
3: X=Boc
X
O
Me
Key intermediate
Br
HO
+
B(OH)2
O
N
Boc
5
4
Figure 1. Structure of the GPR119 agonist (1) and a retrosynthetic analysis in the initial synthesis
To date, the Suzuki-Miyaura coupling reaction has been widely demonstrated for industrial applications
as a convenient and useful method for the construction of biaryl compounds.5 However, when applying it
to the production of an active pharmaceutical ingredient (API), we encountered several potential
drawbacks. a) The cost: the Pd catalyst and arylboronic acid are expensive. b) Genotoxicity concerns:
arylboronic acids have been recently indicated as structure alerts for mutagenicity or carcinogenicity
according to a structure-based assessment using the in silico tool DEREK (Deductive Estimation of Risk
from Existing Knowledge).6,7 c) Residual-Pd issue: the content of Pd should be controlled to less than 10
ppm in orally administered drug substances according to API regulations.8,9 d) Process control: attention
should be paid to the suitable selection of the Pd ligands and base, ligand-particle size, and moisture and
oxygen content for the optimization of the reaction procedure when converting to large-scale
production.10 To avoid these problems, we must develop an alternative synthetic method for the
production of 2 without using a metal-catalyzed cross coupling reaction. Here, we report a facile and
powerful synthetic route to the key intermediate 2 from readily available and affordable starting materials.
RESULTS AND DISCUSSION
In the retrosynthetic analysis (Scheme 1), our attention was focused on avoiding C-C bond formation of
the biaryl compound by the unfavorable Suzuki-Miyaura coupling reaction and on constructing the
requisite skeleton starting from a commercially available biphenyl material. The key intermediate 2 that
possesses a 6-phenylspiro[chromane-2,4'-piperidine] skeleton would be dismantled into the

1634
HETEROCYCLES, Vol. 89, No. 7, 2014
biphenylethanone unit 6 and the 4-oxopiperidine unit 7 via spirocyclization. The required compound 6
could be prepared by a regioselective acylation of 4'-hydroxy-[1,1'-biphenyl]-4-carboxylic acid (8), which
was chosen as an inexpensive starting material.11
O
disconnection
HO
HO
O
O
+
N
Boc
O
OH
NH
disconnection
7
2
6
O
HO
OH
8
Scheme 1. Retrosynthetic analysis of the key intermediate 2
At first, we attempted to transform 4'-acetoxy-[1,1'-biphenyl]-4-carboxylic acid (9a) into 10a via a
Fries-rearrangement reaction with AlCl3 (Scheme 2), but we did not obtain a satisfactory result because of
the difficult separation between the deacetylated compound 8 and the desired compound 10a in a simple
workup.
Scheme 2. Reagents and conditions: (a) Ac2O, pyridine, 25 °C; (b) MeI, K2CO3, DMF, 25 °C; (c) AcCl,
AlCl3, 1,2-dichloroethane, 70 °C; (d) 7, pyrrolidine, MeOH, reflux; (e) NaBH4, MeOH, THF, 0 °C.

HETEROCYCLES, Vol. 89, No. 7, 2014
1635
Then, we followed a reported procedure12 to prepare methyl 4'-methoxy-[1,1'-biphenyl]-4-carboxylate
(9b) and conducted a Friedel-Crafts reaction of 9b with acetyl chloride and AlCl3 in 1,2-dichloroethane.
The regioselective acylation, subsequently followed by demethylation of methyl ether, proceeded
smoothly to produce the desired compound 10b in 89% yield. Thus, the obtained compound 10b was
treated with tert-butyl 4-oxopiperidine-1-carboxylate (7) and pyrrolidine13 in MeOH at reflux temperature
to give the cyclized product 11 in 86% yield. The reduction of the spirochromanone-piperidine compound
11 with NaBH4 produced the spirochromanol-piperidine compound 12 in 93% yield.
To convert 11 or 12 into the desired spirochroman-piperidine 13, we investigated a variety of reaction
conditions to identify a high-yield and efficient procedure (Scheme 3, Table 1).
Scheme 3. Reagents and conditions: (a) see Table 1; (b) NaBH4, pyridine, 100 °C.
Upon exposure of the spirochromanol-piperidine compound 12 to Et3SiH and CF3CO2H in CH2Cl2,4
deoxygenation occurred (entry 1). The desired product 13 was successfully obtained along with the
deprotection of the N-Boc group in 89% yield. Having obtained a satisfactory yield, we next sought to
avoid expensive and erosive solvent such as CF3CO2H. Similarly, the deprotection product 13 was
obtained in 95% yield when conducting the hydrogenolysis of 12 in the presence of Pd-C in AcOH at
80 °C (entry 2). To avoid stepwise reduction, we investigated an alternative reaction, treating 11 with a
combination of Et3SiH and InCl3 or InBr3,14 but these conditions resulted in no reaction (entries 3 and 4).
The conversion of 11 into 13 by a conventional method such as the Clemmensen reduction could be
performed in 68% yield, but it also resulted in a small amount of subproduct 14 (entry 5).

1636
HETEROCYCLES, Vol. 89, No. 7, 2014
Table 1. Results of the reduction of chromanol 12 and chromanone 11
Entry
1
Substrate
Reagents (eq.)
Et3SiH (10.7), CF3CO2H
/ CH2Cl2
Temp. (°C)
rt
Time (h)
12
Yield (%)
89a
12
H2, Pd-C
/ AcOH
Et3SiH (2.4), InCl3 (0.05)
/ CH2Cl2
Et3SiH (4), InBr3 (0.05)
/ CHCl3
2
3
4
5
12
11
11
11
80
rt
9
5
5
5
95a
no reaction
no reaction
13 : 64, 14 : 4b
60
100
Zn (25)
/ AcOH
TiCl4 (1.4), Me2NH·BH3 (1.4)
/ CH2Cl2
6
7
11
11
0 to rt
3
13 : 83, 15 :8c
TiCl4 (1.2), Me2NH·BH3 (1.2)
/ CH2Cl2
-20 to rt
3.5
79a,d
a Isolated yield.
b Each yield was calculated on the basis of 1H-NMR analysis for an inseparable mixture of 13 and 14.
c
1
Each yield was calculated on the basis of H-NMR analysis for a mixture of 13 and 15 as
hydrochloride salts.
d A mixture of 13 and 15 (1H-NMR analytical ratio of 50:1) hydrochloride salts was crystallized from
MeOH to give the pure hydrochloride salt of 13.
We additionally attempted this conversion with a combination of a reducing reagent and a Lewis acid
such as Me2NH·BH3/TiCl4.15 Our initial attempt gave a mixture of 13 and the over-reduced compound 15
when performing the reaction at 0 °C (entry 6). Then, we optimized the reaction conditions for the
quantity of reducing agent and the reaction temperature to minimize the over-reduction of 13, leading to
the subproduct 15 by way of 2. Finally, we were able to control well the reduction of the ketone
accompanied by the deprotection of the N-Boc in 11 to produce the intermediate 13 in 79% yield when
treated with a small surplus amount (1.2 eq.) of reducing reagent in the temperature range from -20 °C to
room temperature (entry 7). After workup, the remaining ester could be smoothly reduced by NaBH4 in
pyridine at 100 °C in 75% yield.
In conclusion, we established a practical synthesis of a key intermediate 2 of a novel GPR119 agonist
staring from 4'-hydroxy-[1,1'-biphenyl]-4-carboxylic acid (8) without troublesome intermediates or a
tedious protocol. Furthermore, we developed a feasible, convenient reduction system to convert a ketone
into a methylene and an ester into an alcohol with deprotection. Further process development and
toxicological study are currently in progress.

HETEROCYCLES, Vol. 89, No. 7, 2014
1637
EXPERIMENTAL
General. All reactions were performed under an argon atmosphere unless otherwise noted. The IR
1
13
spectra were recorded on a Thermo Nicolet 370 FTIR spectrometer. The H-NMR spectra and C-NMR
spectra were obtained on a JEOL JNM-AL 400 MHz spectrometer using the solvents CDCl3 or CD3OD
with tetramethylsilane as an internal standard, unless otherwise noted. The mass spectra were obtained on
a JEOL MS-BU20 mass spectrometer. The elemental analyses (C, H, and N) were performed by Yanaco
MT-5. The melting points were determined in open glass capillaries on a Buchi B-545 melting point
apparatus.
tert-Butyl 6-bromospiro[chromane-2,4'-piperidine]-1'-carboxylate (5)
The target compound 5 was prepared according to the patent literature.4
tert-Butyl 6-(4-(hydroxymethyl)phenyl)spiro[chroman-2,4'-piperidine]-1'-carboxylate (3)
Na2CO3 (55.0 g, 520 mmol) and Pd(PPh3)4 (2.40 g, 2.10 mmol) were added at room temperature under an
argon atmosphere to a stirred solution of 4 (21.0 g, 140 mmol) and 5 (40.0 g, 100 mmol) in a mixture of
DME (500 mL) and water (500 mL). The reaction mixture was stirred at 90 °C for 18 h and then allowed
to cool to room temperature. The reaction mixture was extracted with AcOEt (3 x 300 mL). The
combined organic layers were washed with brine (200 mL), dried over Na2SO4, and concentrated in
vacuo. The crude product was crystallized from AcOEt to give 3 (31.0 g, 72%) as a colorless, crystalline
powder.
mp 173 °C; IR (KBr): 3462, 2942, 1679, 1488, 1432, 1366, 1234, 1165, 1149, 819;
1H-NMR (400 MHz, CDCl3) δ: 1.47 (9H, s), 1.54-1.67 (2H, m), 1.79-1.87 (4H, m), 2.84 (2H, t, J = 6.8
Hz), 3.14-3.36 (2H, m), 3.75-4.02 (2H, m), 4.69-4.75 (2H, br), 6.90 (1H, d, J = 8.3 Hz), 7.29 (1H, d, J =
2.2 Hz), 7.34 (1H, dd, J = 8.3, 2.2 Hz), 7.40 (2H, d, J = 8.0 Hz), 7.53 (2H, d, J = 8.0 Hz); 13C-NMR (100
MHz, CDCl3) δ: 23.0, 29.9, 33.4, 35.8, 40.9, 66.3, 74.3, 81.0, 119.1, 122.9, 127.6, 128.2, 128.9, 129.5,
134.3, 140.8, 141.6, 154.3, 156.4; MS (EI) m/z 409 [M+]; Anal. Calcd for C25H31NO4: C, 73.32; H, 7.63;
N, 3.42. Found: C, 73.46; H, 7.69; N, 3.48.
Methyl 4'-methoxy-[1,1'-biphenyl]-4-carboxylate (9b)
The target compound was prepared from 4’-hydroxy-[1,1’-biphenyl]-4-carboxylic acid (8) according to
the patent literature.12
Methyl 3'-acetyl-4'-hydroxy-[1,1'-biphenyl]-4-carboxylate (10b)

1638
HETEROCYCLES, Vol. 89, No. 7, 2014
Acetyl chloride (30.0 mL, 420 mmol) was added at 0 °C under an argon atmosphere to a suspension of
AlCl3 (112 g, 839 mmol) in dry 1,2-dichloroethane (210 mL). After stirring for 10 min, 9b (50.8 g, 210
mmol) was added to this mixture dropwise. The resulting mixture was stirred at 70 °C for 1 h. After
completing the reaction, the reaction mixture was poured onto ice (1000 g) and then diluted with AcOEt
(1.7 L). The organic layer was washed with water (600 mL), dried over Na2SO4, and concentrated in
vacuo. The crude product was dissolved in CHCl3 (130 mL) and diluted with hexane (500 mL). The
precipitate was filtered off and washed with hexane (200 mL) to give 10b (50.3 g, 89%) as a yellow solid.
A sample was crystallized from CHCl3 and hexane to give colorless prisms for analysis.
mp 150-152 °C; IR (KBr): 3017, 1709, 1641, 1606, 1520, 1433, 1304, 1288, 1216, 1109;
1H-NMR (400 MHz, CDCl3) δ: 2.74 (3H, s), 3.97 (3H, s), 7.11 (1H, d, J = 8.8 Hz), 7.63 (2H, d, J = 8.0
Hz), 7.77 (1H, dd, J = 8.8, 2.0 Hz), 7.98 (1H, d, J = 2.0 Hz), 8.14 (2H, d, J = 8.0 Hz), 12.36 (1H, s);
13C-NMR (100 MHz, CDCl3) δ: 26.7, 52.2, 119.2, 119.9, 126.9, 128.9, 129.2, 130.3, 131.1, 135.3, 144.3,
162.5, 166.8, 204.5; MS (EI) m/z 270 [M+]; Anal. Calcd for C16H14O4: C, 71.10; H, 5.22. Found: C,
71.12; H, 5.29.
tert-Butyl 6-(4-(methoxycarbonyl)phenyl)-4-oxospiro[chromane-2,4'-piperidine]-1'-carboxylate (11)
At room temperature, 10b (74.8 g, 277 mmol) was added to a solution of tert-butyl
4-oxopiperidine-1-carboxylate (55.2 g, 277 mmol) and pyrrolidine (11.4 mL, 138 mmol) in MeOH (277
mL). The reaction mixture was stirred at reflux temperature for 12 h. After completing the reaction, the
reaction mixture was cooled to 0 °C. The precipitate was filtered off and washed with cold MeOH to give
11 (107.8 g, 86%) as a yellow solid. A sample was crystallized from AcOEt and hexane to give yellow
prisms for analysis.
mp 159-160 °C; IR (KBr): 1722, 1688, 1607, 1433, 1397, 1303, 1249, 1147, 1115, 770;
1H-NMR (400 MHz, CDCl3) δ: 1.49 (9H, s), 1.63-1.71 (2H, m), 2.04-2.12 (2H, br m), 2.79 (2H, s),
3.22-3.34 (2H, br m), 3.80-3.99 (2H, m), 3.96 (3H, s), 7.12 (1H, d, J = 8.8 Hz), 7.67 (2H, d, J = 8.0 Hz),
7.81 (1H, dd, J = 8.8, 2.0 Hz), 8.13 (2H, d, J = 8.0 Hz), 8.17 (1H, d, J = 2.0 Hz); 13C-NMR (100 MHz,
CDCl3) δ: 28.3, 33.9, 39.1, 47.9, 52.0, 78.2, 79.8, 119.0, 120.1, 125.0, 126.4, 128.9, 130.1, 133.9, 134.9,
143.8, 154.6, 158.9, 166.7, 191.2; MS (EI) m/z 451 [M+]; Anal. Calcd for C26H29NO6: C, 69.16; H, 6.47;
N, 3.10. Found: C, 69.24; H, 6.53; N, 3.06.
tert-Butyl 4-hydroxy-6-(4-(methoxycarbonyl)phenyl)spiro[chromane-2,4'-piperidine]-1'-carboxylate
(12)
NaBH4 (4.40 g, 116 mmol) was added portionwise at 0 °C to a solution of 11 (52.6 g, 116 mmol) in a
mixture of MeOH (50 mL) and THF (200 mL). The reaction mixture was stirred at room temperature for

HETEROCYCLES, Vol. 89, No. 7, 2014
1639
1 h. After completing the reaction, the solvent was removed under reduced pressure. The residue was
dissolved in AcOEt (300 mL) and quenched with a saturated aqueous solution of NH4Cl (100 mL). The
aqueous layer was extracted with AcOEt (100 mL). The combined organic layers were washed with brine
(40 mL), dried over Na2SO4, and concentrated in vacuo. The crude product was dissolved in AcOEt (50
mL) and diluted with hexane (150 mL). The precipitate was filtered off and washed with hexane to give
12 (48.9 g, 93%) as a white solid. A sample was crystallized from AcOEt and hexane to give colorless
prisms for analysis.
mp 168-170 °C; IR (KBr): 3476, 2957, 1713, 1674, 1607, 1488, 1427, 1284, 1236, 1170;
1H-NMR (400 MHz, CDCl3) δ: 1.47 (9H, s), 1.63-2.00 (5H, m), 2.20 (1H, dd, J = 13.4, 6.1 Hz), 3.12-3.34
(2H, br m), 3.86-3.94 (2H, m), 3.94 (3H, s), 4.99-4.92 (1H, br m), 6.96 (1H, d, J = 8.4 Hz), 7.50 (1H, dd,
J = 8.4, 2.0 Hz), 7.63 (2H, d, J = 8.3 Hz), 7.74 (1H, d, J = 2.0 Hz), 8.08 (2H, d, J = 8.3 Hz); 13C-NMR
(100 MHz, CDCl3) δ: 28.4, 33.7, 35.9, 41.8, 52.1, 62.8, 74.2, 79.6, 117.9, 125.1, 126.4, 126.9, 128.2,
128.3, 130.1, 132.5, 145.1, 152.8, 154.8, 167.1; MS (EI) m/z 453 [M+]; Anal. Calcd for C26H31NO6: C,
68.86; H, 6.89; N, 3.09. Found: C, 68.91; H, 6.94; N, 3.07.
Methyl 4-(spiro[chromane-2,4'-piperidin]-6-yl)benzoate (13) (Entry 1)
CF3CO2H (441 mL) and subsequently Et3SiH (75.0 mL, 470 mmol) were added at 0 °C to a stirred
solution of 12 (20.0 g, 44.1 mmol) in CH2Cl2 (66 mL). The reaction mixture was stirred at room
temperature for 12 h. After completing the reaction, the reaction mixture was concentrated in vacuo. The
residue was dissolved in AcOEt (50 mL) and diluted with hexane (50 mL). The precipitate was filtered
off to give the CF3CO2H salt of 13 (19.3 g) as a white solid. A saturated aqueous solution of NaHCO3
(300 mL) was added to a stirred suspension of the CF3CO2H salt in MeOH (200 mL). The reaction
mixture was stirred at room temperature for 30 min. MeOH was evaporated from the reaction solvent
under reduced pressure. The precipitate was filtered off and washed with THF (60 mL) and hexane (60
mL) to give 13 (14.4 g, 96%) as a white solid.
A sample was recrystallized from CHCl3 and hexane to give a colorless, crystalline powder for analysis.
mp 148-149 °C; IR (KBr): 3340, 2934, 1711, 1605, 1486, 1436, 1284, 1245, 1184, 1110;
1H-NMR (400 MHz, CDCl3) δ: 1.52-1.62 (2H, br m), 1.78-1.87 (4H, br m), 2.93-2.78 (4H, br m), 3.06
(2H, t, J = 10.5 Hz), 3.92 (3H, s), 6.92 (1H, d, J = 8.3 Hz), 7.33 (1H, s), 7.37 (1H, d, J = 8.3 Hz), 7.59
(2H, d, J = 8.3 Hz), 8.05 (2H, d, J = 8.3 Hz); 13C-NMR (100 MHz, CDCl3) δ: 21.1, 31.7, 35.3, 41.6, 51.6,
73.1, 117.5, 121.4, 125.8, 125.9, 127.6, 127.9, 129.6, 131.1, 145.0, 153.5, 166.7; MS (EI) m/z 337 [M+];
Anal. Calcd for C21H23NO3: C, 74.75; H, 6.87; N, 4.15. Found: C, 74.77; H, 6.92; N, 4.19.
Hydrogenolysis of 12 (Entry 2)

1640
HETEROCYCLES, Vol. 89, No. 7, 2014
Under an argon atmosphere, 5% Pd-C (60 mg) was added to a solution of 12 (200 mg, 0.442 mmol) in
AcOH (3 mL). The reaction mixture was stirred at room temperature for 4 h and heated at 60 °C for 15 h
and at 80 °C for 9 h under a hydrogen atmosphere. After completing the reaction, 4N HCl/AcOEt (9 mL)
was added to the reaction mixture. The resulting mixture was stirred overnight at room temperature.
MeOH (10 mL) was added to this mixture to dissolve the precipitate that appeared. The insoluble material
(Pd-C) from the reaction mixture was filtered off. The filtrate was concentrated in vacuo and diluted with
AcOEt (30 mL). The organic solution was washed with a saturated aqueous solution of NaHCO3 (30 mL)
and brine, dried over Na2SO4 and concentrated in vacuo. The residue was purified by column
chromatography on silica gel (20% sat. NH3/MeOH in CHCl3) to give 13 (141 mg, 95%) as a white solid.
Clemmensen reduction (Entry 5)
Zinc powder (3.60 g, 552 mmol) was added at room temperature to a stirred solution of 11 (1.00 g, 22.1
mmol) in AcOH (10 mL). The reaction mixture was stirred at 100 °C for 5 h. After completing the
reaction, the insoluble material was filtered off and washed with a mixed solvent of THF and MeOH (40
mL/10 mL). To cleave the N-Boc group, 4N HCl/AcOEt (20 mL) was added at room temperature to the
filtrate. The resulting mixture was stirred overnight at room temperature and concentrated in vacuo. The
residue was dissolved in CHCl3 (100 mL). The organic layer was washed with a saturated aqueous
solution of NaHCO3 (30 mL) and brine, dried over Na2SO4 and concentrated in vacuo. The residue was
purified by column chromatography on silica gel (20% sat. NH3/MeOH-CHCl3) to give an inseparable
mixture of 13 and 14 (517 mg) as a white solid. The yield of 13 and 14 were calculated on the basis of
1H-NMR analysis to show 64% and 4%, respectively.
Methyl 4-(spiro[chromene-2,4'-piperidin]-6-yl)benzoate (14)
The authentic sample 14 was synthesized after mesylation of 12 and elimination under basic conditions.
mp 144-145 °C; IR (KBr): 3351, 2940, 2809, 1705, 1604, 1488, 1429, 1292, 1180, 1106;
1H-NMR (400 MHz, CDCl3) δ: 1.55-1.68 (2H, m), 1.90-2.03 (2H, m), 2.78-2.87 (2H, m), 3.04-3.14 (2H,
m), 3.90 (3H, s), 5.65 (1H, d, J = 9.6 Hz), 6.39 (1H, d, J = 9.6 Hz), 6.90 (1H, d, J = 8.0 Hz), 7.22 (1H, d,
J = 2.0 Hz), 7.36 (1H, dd, J = 8.0, 2.0 Hz), 7.56 (2H, d, J = 8.0 Hz), 8.04 (2H, d, J = 8.0 Hz); 13C-NMR
(100 MHz, CDCl3) δ: 36.3, 41.5, 51.8, 75.5, 116.7, 122.0, 122.7, 124.9, 126.1, 127.7, 128.0, 129.8, 130.2,
132.4, 144.8, 152.7, 166.7; MS (EI) m/z 309 [M+]; Anal. Calcd for C21H21NO3: C, 75.20; H, 6.31; N, 4.18.
Found: C, 75.16; H, 6.38; N, 4.05.
Reduction of 11 by Me2NH·BH3 and TiCl4 (Entry 6)

HETEROCYCLES, Vol. 89, No. 7, 2014
1641
A solution of 11 (10.0 g, 22.1 mmol) in dry CH2Cl2 (70 mL) was added dropwise at 0 °C under an argon
atmosphere to a stirred solution of TiCl4 in dry CH2Cl2 (1.0 M solution, 26.5 mL) and Me2NH·BH3 (1.60
g, 26.5 mmol) in dry CH2Cl2 (30 mL). After stirring at this temperature for 30 min, the reaction mixture
was allowed to warm to room temperature and was stirred for 3 h. After completing the reaction, the
reaction mixture was quenched with H2O (100 mL) at 0 °C. The resulting mixture was stirred overnight at
room temperature. The precipitate was filtered off to give a mixture of 13 and 15 as hydrochloride salts
(7.54 g). The yield of 13 and 15 were calculated on the basis of 1H-NMR analysis (CD3OD) to show 83%
and 8%, respectively.
Reduction of 11 by Me2NH·BH3 and TiCl4 (Entry 7)
This procedure was the same as that in Entry 6 except for the reaction temperature at -20 °C.The ratio of
each compound of hydrochloride salts (13:15 = 50:1) was determined by 1H-NMR analysis (CD3OD). A
mixture of products was crystallized from MeOH to give the hydrochloride salt of 13 (6.54 g, 79%).
(4-(Spiro[chromane-2,4'-piperidin]-6-yl)phenyl)methanol (2)
NaBH4 (1.52 g, 40.0 mmol) at 0 °C under an argon atmosphere was added to a stirred solution of 13·HCl
(6.00 g, 16.0 mmol) in dry pyridine (100 mL). The stirring reaction mixture was allowed to warm to room
temperature and heated at 100 °C for 14 h. After completing the reaction, the reaction mixture was
quenched with MeOH (50 mL) at 0 °C and concentrated in vacuo. The residue was dissolved in CHCl3
(200 mL) and H2O (200 mL). The aqueous layer was extracted with CHCl3 (200 mL x 2). The combined
organic layers were dried over Na2SO4, filtered, and concentrated in vacuo. The residue was dissolved in
MeOH (20 mL) and AcOEt (80 mL). At 0 °C, 4N HCl/AcOEt (20 mL) was added to this solution. The
resulting mixture was stirred at 0 °C for 30 min and concentrated in vacuo. The residue was dissolved in
CHCl3 (200 mL). The organic layer was washed with 1N NaOH (30 mL), and the aqueous layer was
extracted with CHCl3 (200 mL x 2). The combined organic layers were dried over Na2SO4, filtered, and
concentrated in vacuo. The solid product was crystallized from THF (100 mL) and hexane (50 mL) to
give 2 (2.88 g, 58%) as a colorless, crystalline powder. The mother liquid was concentrated in vacuo and
crystallized from THF (40 mL) and hexane (15 mL) to give 2 (0.83 g, 17%) as a colorless, crystalline
powder.
A sample was recrystallized from THF to give a colorless needle for analysis.
mp 190-191 °C; IR (KBr): 3260, 3066, 2924, 1490, 1250, 1160, 1142, 1036, 972, 841;
1H-NMR (400 MHz, CDCl3) δ: 1.61-1.72 (2H, m), 1.81-1.90 (4H, m), 2.71-2.96 (4H, m), 3.08 (2H, t, J =
11.7 Hz), 4.62 (2H, s), 6.82-6.88 (1H, m), 7.32-7.39 (4H, m), 7.53 (2H, d, J = 8.3 Hz); 13C-NMR (100
MHz, CDCl3) δ: 20.9, 31.8, 34.4, 40.9, 63.6, 72.8, 117.2, 121.6, 125.4, 126.0, 127.1, 127.5, 132.7, 139.4,

1642
HETEROCYCLES, Vol. 89, No. 7, 2014
139.9, 152.8; MS (EI) m/z 309 [M+]; Anal. Calcd for C20H23NO2: C, 77.64; H, 7.49; N, 4.53. Found: C,
77.46; H, 7.55; N, 4.54.
ACKNOWLEDGEMENTS
We thank Dr. S. Tanabe, Director, for his encouragement and support at Tokyo New Drug Research
Laboratories, Kowa Co., Ltd.
REFERENCES AND NOTES
1. a) E. Darout, R. P. Robinson, K. F. McClure, M. Corbett, B. Li, A. Shavnya, M. P. Andrews, C. S.
Jones, Q. Li, M. L. Minich, V. Mascitti, C. R. W. Guimarães, M. J. Munchhof, K. B. Bahnck, C. Cai,
D. A. Price, S. Liras, P. D. Bonin, P. Cornelius, R. Wang, V. Bagdasarian, C. P. Sobota, S. Hornby,
V. M. Masterson, R. M. Joseph, A. S. Kalgutkar, and Y. Chen, J. Med. Chem., 2013, 56, 301; b) J.
Zhang, A. Li, M. Yu, Y. Wang, J. Zhu, F. Kayser, J. C. Medina, K. Siegler, M. Conn, B. Shan, M. P.
Grillo, J. Eksterowicz, P. Coward, and J. J. Liu, Bioorg. Med. Chem. Lett., 2013, 23, 3609; c) K.
Negoro, Y. Yonetoku, A. Moritomo, M. Hayakawa, K. Iikubo, S. Yoshida, M. Takeuchi, and M.
Ohta, Bioorg. Med. Chem., 2012, 20, 6442; d) Y. Xia, S. Chackalamannil, W. J. Greenlee, C. Jayne,
B. Neustadt, A. Stamford, H. Vaccaro, X. Xu, H. Baker, K. O’Neill, M. Woods, B. Hawes, and T.
Kowalski, Bioorg. Med. Chem. Lett., 2011, 21, 3290.
2. T. Ohishi and S. Yoshida, Expert Opin. Investig. Drugs, 2012, 21, 321.
3. T. Morimoto, T. Koshizawa, G. Watanabe, T. Fukuda, T. Ohgiya, N. Yamasaki, N. Inoue, T. Araki,
H. Tsukagoshi, and S. Hagita, World Patent WO2012161119, 2012.
4. a) T. W. Butler, R. H. Howard, and T. T. Wagner, World Patent WO2007088462, 2007; b) K. D.
McCormick, R. G. Aslanian, P. Mangiaracina, M. Y. Berlin, M. L. Ruiz, C. W. Boyce, J. Chao, P. C.
Ting, J. Zheng, and S. B. Rosenblum, United State Patent US20110166124, 2011.
5. N. Miyaura and A. Suzuki, Chem. Rev., 1995, 95, 2457.
6. a) M. R. O’Donovan, C. D. Mee, S. Fenner, A. Teasdale, and D. H. Phillips, Mutation Research,
2011, 724, 1; b) P. N. Judson, S. A. Stalford, and J. Vessey, Toxicol. Res., 2013, 2, 70.
7. An efficient removal of arylboronic acid from the reaction mixture was required until the acceptable
level of risk management and referred therein. a) W. Yang, X. Gao, G. Springsteen, and B. Wang,
Tetrahedron Lett., 2002, 43, 6339; b) D. G. Hall, J. Tailor, and M. Gravel, Angew. Chem. Int. Ed.,
1999, 38, 3064.
8. European Medicines Agency, Committee for Medicinal Products for Human Use. Guideline on the
specification limits for residues of metal catalysts or metal reagents, CPMP/SWP/4446/2000;
London, U.K., February 2008.

HETEROCYCLES, Vol. 89, No. 7, 2014
1643
9. Some scavenger resins were used as efficient removal of the residual Pd from the reaction mixture
and referred in the following. a) K. Königsberger, G. Chen, R. R. Wu, M. J. Girgis, K. Prasad, O.
Repic, and T. J. Blacklock, Org. Process Res. Dev., 2003, 7, 733; b) C. J. Welch, J.
Albaneze-Walker, W. R. Leonard, M. Biba, J. DaSilva, D. Henderson, B. Laing, D. J. Mathre, S.
Spencer, X. Bu, and T. Wang, Org. Process Res. Dev., 2005, 9, 198.
10. a) L. V. Desai, M. B. Hay, D. K. Leahy, C. Wei, D, Fanfair, T. Rosner, and Y, Hsiao, Tetrahedron,
2013, 69, 5677; b) A. W. Kruger, M. J. Rozema, A. Chu-Kung, J. Gandarilla, A. R. Haight, B. J.
Kotecki, S. M. Richter, A. M. Schwartz, and Z. Wang, Org. Process Res. Dev., 2009, 13, 1419.
11. 4'-Hydroxy-[1,1'-biphenyl]-4-carboxylic acid (8) in bulk for multi-kg scale is commercially available
from Nanjing Chemlin Chemical Co., Ltd. (China).
12. C. T. Joseph, C. S. Christman, T. E. John, E. H. Mahmoud, and C. D. LeRoy, World Patent
WO2005030702, 2005.
13. M. Yamato, K. Hashigaki, A. Tsutsumi, and K. Tasaka, Chem. Pharm. Bull., 1981, 29, 3494.
14. N. Sakai, K. Nagasawa, R. Ikeda, Y. Nakaike, and T. Konakahara, Tetrahedron Lett., 2011, 52,
3133.
15. E. V. Dehmlow, T. Niemann, and A. Kraft, Synth. Commun., 1996, 26, 1467.
