Photoreactions of chromium cyclodienyl complexes with alkynes: Double [5 + 2],homo[5 + 2] cycloaddition reactions

Article abstract of DOI:10.1021/om960183r

UV irradiation of the cycloheptadienyl complexes [(η⁵-C₇H₈R)Cr(CO)₃SnPh ₃] (1a, R = H; 1b, R = C(Me)S(CH₂)₃S; 1c, R = CHPh₂) or cyclohexadienyl complexes [(η⁵

Full text of DOI:10.1021/om960183r

Organometallics 1996, 15, 3337-3344
3337
P h otor ea ction s of Ch r om iu m Cyclod ien yl Com p lexes
w ith Alk yn es: Dou ble [5 + 2],h om o[5 + 2]
Cycloa d d ition Rea ction s
Weichun Chen, Hyei-J ha Chung, Chenjie Wang, J ohn B. Sheridan,*
Marie L. Cote´, and Roger A. Lalancette
Department of Chemistry, Rutgers, The State University of New J ersey,
University Heights, Newark, New J ersey 07102
Received March 8, 1996X
UV irradiation of the cycloheptadienyl complexes [(η5-C7H8R)Cr(CO)3SnPh3] (1a , R ) H;
1b, R ) C(Me)S(CH2)3S; 1c, R ) CHPh2) or cyclohexadienyl complexes [(η5-C6H6R)Cr(CO)2-
(NO)] (7, R ) C(Me)S(CH2)3S) and 2 equiv of 2-butyne or 3-hexyne in toluene or n-hexane
gave new tricyclic complexes 2, 5, and 8. These complexes arise from sequential [5 + 2]
and homo[5 + 2] cycloadditions of two alkyne molecules to the η5-dienyl manifold forming
11-alkylidenetricyclo[5.3.1.04,10]undeca-2,5-diene or tricyclo[5.2.1.04,9]deca-2,5-dien-10-yl ligands,
respectively. Heating 2 in acetonitrile gave [Cr(CO)3(CH3CN)3] and the tricyclic organic
compounds 3. UV irradiation of 1a and 1-phenyl-1-propyne or 1c and 2-butyne directly
gave the organic compounds 4a ,b and 5c, 6a ,b, respectively, as mixtures of isomers. The
adduct resulting from 1a and two molecules of 3-hexyne has been characterized by an X-ray
diffraction study.
Sch em e 1. [5 + 2],h om o[5 + 2] Dou ble Alk yn e
Ad d ition to [Mn (CO)3(η5-C6H7)]
In tr od u ction
Transition metal-mediated cycloaddition reactions
continue to attract interest as a means of generating a
variety of ring systems both efficiently and stereoselec-
tively.1 Within this field, significant advances have
been made in the construction of medium-size carbo-
and heterocyclic rings through transition metal-medi-
ated higher-order cycloaddition processes.2-4 For ex-
ample, Rigby and co-workers have extensively investi-
gated photoinduced [6 + 2] and [6 + 4] cycloadditions
using [(η6-triene)Cr(CO)3] complexes and olefins,4
dienes,5,6 heterocumulenes,7 or even transition metal
carbene complexes.8 Likewise, we9,10 and others11 have
demonstrated the related chromium-mediated [6 + 2]
cycloadditions of alkynes to trienes.
Photoassisted higher-order cycloadditions of alkynes
to η5-dienyl ligands have also been reported by us,12
as well as by Kreiter and co-workers,13 using tricar-
bonyl(η5-cyclohexadienyl)manganese(0). In these stud-
ies, sequential [5 + 2],homo[5 + 2] double alkyne
additions to the dienyl ligand gave new tricyclic species,
(Scheme 1).
More recently, Kreiter has reported a [5 + 2] coupling
of alkynes and pentadienylmanganese complexes,14,15 as
well as [5 + 2],homo[5 + 2] double alkyne addition to
tricarbonyl(η5-cycloheptadienyl)manganese(0),16 again
promoted by UV light. The [5 + 4] coupling of dienyl
ligands and dienes at a manganese center is also
known,17-21 and it appears [5 + 2] or [5 + 4] cycload-
ditions of dienyl ligands to appropriate dienylophiles
X Abstract published in Advance ACS Abstracts, J une 1, 1996.
(1) Lautens, M.; Klute, W.; Tam, W. Chem. Rev. 1996, 96, 49.
(2) Rigby, J . H.; Ateeq, H. S.; Charles, N. R.; Henshilwood, J . A.;
Short, K. M.; Sugathapala, P. M. Tetrahedron 1993, 49, 5495.
(3) Rigby, J . H. Acc. Chem. Res. 1993, 26, 579.
(4) Rigby, J . H.; Henshilwood, J . A. J . Am. Chem. Soc. 1991, 113,
5122.
(5) Rigby, J . H.; Ateeq, H. S.; Charles, N. R.; Cuisiat, S. V.; Ferguson,
M. D.; Henshilwood, J . A.; Krueger, A. C.; Ogbu, C. O.; Short, K. M.;
Heeg, M. J . J . Am. Chem. Soc. 1993, 115, 1382.
(6) Rigby, J . H.; Scribner, S.; Heeg, M. J . Tetrahedron Lett. 1995,
36, 8569.
(7) Rigby, J . H.; Ahmed, G.; Ferguson, M. D. Tetrahedron Lett. 1993,
34, 5397.
(8) Rigby, J . H.; Pigge, F. C.; Ferguson, M. D. Tetrahedron Lett.
1994, 35, 8131.
(9) Chaffee, K.; Huo, P.; Sheridan, J . B.; Barbieri, A.; Aistars, A.;
Lalancette, R. A.; Ostrander, R. L.; Rheingold, A. L. J . Am. Chem. Soc.
1995, 117, 1900.
(13) Kreiter, C. G.; Fiedler, C.; Frank, W.; Reiss, G. J . J . Organomet.
Chem. 1995, 490, 133.
(14) Kreiter, C. G.; Koch, E.-C.; Frank, W.; Reiss, G. J . J . Organomet.
Chem. 1995, 490, 125.
(15) Kreiter, C. G.; Koch, E.-C.; Frank, W.; Reiss, G. J . Inorg. Chim.
Acta 1994, 220, 77.
(10) Chaffee, K.; Sheridan, J . B.; Aistars, A. Organometallics 1992,
11, 18.
(11) Fischler, I.; Grevels, F.; Leitich, J .; O¨ zkar, S. Chem. Ber. 1991,
124, 2857.
(16) Kreiter, C. G.; Fiedler, C.; Frank, W.; Reiss, G. J . Chem. Ber.
1995, 128, 515.
(17) Kreiter, C. G.; Lehr, K. J . Organomet. Chem. 1993, 454,
199.
(12) Wang, C.; Sheridan, J . B.; Chung, H.-J .; Cote, M.; Lalancette,
R. A.; Rheingold, A. L. J . Am. Chem. Soc. 1994, 116, 8966.
(18) Kreiter, C. G.; Lehr, K.; Leyendecker, M.; Sheldrick, W. S.;
Exner, R. Chem. Ber. 1991, 124, 3.
S0276-7333(96)00183-5 CCC: $12.00 © 1996 American Chemical Society
+
+

3338 Organometallics, Vol. 15, No. 15, 1996
Chen et al.
Sch em e 2. [5 + 2],h om o[5 + 2] Dou ble Alk yn e
may be quite general. The potential of metal-mediated
higher-order cycloaddition reactions is further exempli-
fied by a complementary catalytic [5 + 2] cycloaddi-
tion protocol between alkynes and vinylcyclopropanes
that has recently been reported by Wender and asso-
ciates.22
Ad d ition to a Cycloh ep ta d ien yl Rin g
In continuing our studies on the photoreactions of
dienyl complexes with alkynes, we now present de-
tails of a [5 + 2],homo[5 + 2] double cycloaddition to
both cycloheptadienyl(triarylstannyl)- and cyclohexadi-
enyl(nitrosyl)chromium manifolds. A schematic repre-
sentation of the coupling reaction for the seven-
membered ring is shown in Scheme 2. The final
products from the tin precursors contain an 11-alkyli-
dene-tricyclo[5.3.1.04,10]undeca-2,5-diene ring coordi-
nated to a Cr(CO)3 group, with an exocyclic alkylidene
that is generated by elimination of Ph3SnH. Subse-
quent reaction of these species with acetonitrile gives
the functionalized tricyclic compounds in good to excel-
lent yields.
The new ligand is a tricyclic triene that results from
the coupling of two alkynes with the cycloheptadienyl
ring via sequential [5 + 2] and homo[5 + 2] cycloaddi-
tions. Elimination of a hydrogen atom adjacent to C(11)
of the newly formed ring forms an exocyclic double bond
at this site. The ligand consists of three fused rings (C5,
C6, C7) with four of the ring carbon atoms, C(1), C(2),
C(3) and C(11), derived from added alkynes. It is
bonded to a chromium tricarbonyl group through all
three double bonds, i.e. C(2)dC(3), C(5)dC(6), and
C(11)dC(12), each trans to a CO ligand.
The 1H NMR spectrum of 2a shows nine distinct
resonances for the C7 ring as well as two singlets at δ
3.94 and 3.87 assigned to the exocyclic methylene
protons at C(12). Only three methyl group signals
are observed at δ 1.18, 1.55, and 2.06 since one of the
former alkyne methyl groups has been converted to the
methylene moiety. Likewise, the 13C{1H} NMR spec-
trum shows a signals at δ 74.3 {C(12)} and δ 63.6 {C-
(11)} for the coordinated exocyclic methylene and a
further 10 signals associated with the ring as well as
three distinct CO resonances at δ 233.4, 234.8, and
235.6 (Table 1).
Resu lts a n d Discu ssion
Ch r om iu m -Med ia ted Cycloh ep ta d ien yl-Alk yn e
Cou p lin g. Irradiation of toluene or n-hexane solutions
of tricarbonyl(η5-cycloheptadienyl)(triphenylstannyl)-
chromium(II) (1a ) and 2-butyne or 3-hexyne (2 equiv)
with UV light at room temperature for 0.5-4 h re-
sulted in a gradual disappearance of 1a , as monitored
by IR spectroscopy, and the formation of new neutral
tricarbonyl species 2a ,b, respectively (eq 1). Analysis
Complex 2b is analogous to 2a and was similarly
characterized. However, for 2b there exists the pos-
sibility of two isomers (E/ Z) for the exocyclic alkylidene
group, since either of the two disatereoselective meth-
ylene hydrogens adjacent to the ring can be eliminated
with the Ph3Sn moiety. Remarkably, a single isomer
is formed as observed by NMR spectroscopy, which
contrasts with the related manganese complexes gener-
ated by hydride abstraction with [CPh3]+. In those
species both E and Z isomers were formed.12 The
molecular structure of 2b was confirmed by an X-ray
