4-(4’-alkyloxyphenylazo)benzoyl chlorides not only intermediates
butphotosensitive mesogens for optical switching
Joanna Jaworska1, Izabela Korbecka2, Andrzej Kochel2 and Zbigniew Galewski2*
(1) Wrocław University of Science and Technology, Faculty of Chemistry, Advanced
Materials Engineering and Modelling Group, Wybrzeze Wyspianskiego 27, 50-370
Wroclaw, Poland
(2) Faculty of Chemistry, University of Wroclaw, Joliot- Curie 14 , 50-383 Wroclaw,
Poland
E-mail addresses:
Joanna Jaworska: joanna.jaworska@pwr.edu.pl
Izabela Korbecka: izabela.korbecka@chem.uni.wroc.pl
Andrzej Kochel: andrzej.kochel@chem.uni.wroc.pl
Zbigniew Galewski: zbigniew.galewski@chem.uni.wroc.pl
Corresponding author:
zbigniew.galewski@chem.uni.wroc.pl
Abstract
This paper presents results of our studies of a full homologous series of 4-(4’-
alkyloxyphenylazo)benzoyl chlorides. Until now these compounds have been used only as
intermediates for more complex materials and their properties were not investigated as acid
chlorides are considered unstable and hence useless for applications. We show that they are in
fact quite durable and posses liquid-crystalline properties in a broad temperature range. In
addition fast switching times of cis-trans isomerization with less than an hour relaxation time
are demonstrated for the series, which makes these compounds promising materials for optical
switching.
Keywords: liquid crystals, azobenzene, chloride, photoisomerization, optical switching, new
materials.
1. Introduction
Liquid crystals are unique materials with properties placing them between
conventional liquids and solid crystals1-3. Long-range order combined with flow ability allow
to apply them in many branches of modern technology. They have contributed to considerable

ACCEPTED MANUSCRIPT
development of optoelectronics, photovoltaics, diagnostics, sensorics and obviously LC
display technologies4-10. Special properties of these materials are strictly related to molecules
arrangement which can be modified by different factors such as temperature, light,
concentration etc11-14. Among liquid crystalline materials, azobenzene derivatives15-20 are of
special interest due to theirintriguing ability of cis-trans isomerization21-23 upon irradiation by
light of suitable wavelength. This process causes a change in material properties, like for
example absorption spectra, yet is fully reversible. Cis isomer is unstable and after certain
time it returns to trans form. It had to be the reason why these materials have gained
popularity as components for optical storage24-26, photomechanical actuators27-28
,
photoresponsive surface29-32. Furthermore, isomerisation changes the geometry of molecule -
isomer cis is a bent version of isomer trans which must affect the arrangement of molecules
in the system. This leads to the conclusion that the appearance of the cis-isomer in the system
affects the mesomorphism of the compound33.
Nowadays, great emphasis is placed on finding new liquid-crystalline phases34-37. By
certain modifications of chemical structure completely different properties can be obtained38-
39. Still, our knowledge related to properties-structure dependence is insufficient to enable us
to precisely design and synthesize the compounds with desired properties. The syntheses of
whole homologous series of liquid-crystallinecompounds allow to contribute to this
knowledge and examine the impact of some aspects of chemical structure on material
properties, especially mesomorphism40-42
.
This paper describes our studies of a full homologous series of 4-(4’-
alkyloxyphenylazo)benzoyl chlorides. Although, these compounds are well known in the
literature, they are rather obtained as intermediates, which are used in further steps of
syntheses, for example of very popular bent-core molecules. Based on the published papers,
in which 4-(4’-alkyloxyphenylazo)benzoyl chlorides are mentioned,it can be concluded that
these compounds were considered, together with other acid chlorides, unstable and hence
useless from applications point of view. Their properties were not studied. This paper
demonstrates that 4-(4'-alkyloxyphenylazo)benzoyl chlorides are in fact quite stable for a
considerable period of time. They possess as well liquid-crystalline properties in a relatively
wide temperature range. The kinetics studies of their cis-trans isomerisation are also presented
here. Finally, the influence of the molecule length on selected physical properties such as
mesoporphism and photoisomerization rate is described.

ACCEPTED MANUSCRIPT
2. Experimental
2.1. Synthesis
4-(4’-alkyloxyphenylazo)benzoic acids were prepared according to the procedure
which is described elsewhere43. Oxalyl chloride, triethylamine and all used solvents were
purchased and used without additional purification. For the purpose of this study a full
homologous series of 4-(4’-alkyloxyphenylazo)benzoyl chlorides has been synthesized [Fig.
1], from methyl to octadecyl one. Further in this work acronyms X-Cl for 4-(4’-
alkyloxyphenylazo)benzoyl chlorides will be used, where X represents the length of the
alkoxy chain.
Figure 1. The synthesis route of 4-(4’-alkyloxyphenylazo)benzoyl chlorides.
A mixture of appropriate 4-(4’-alkyloxyphenylazo)benzoic acid (1.25 mmol), oxalyl
chloride (0.16 g, 1.25 mmol) and triethylamine (0.13 g, 1.25 mmol) in dry tetrahydrofuran
was stirred at room temperature for 24 hours. After that time the solvent was removed. The
crude precipitate was purified by column gel chromatography (dichloromethane- silica gel
mobile phase- stationary phase). Subsequently the product was recrystallized from hexane.
1
Yield: 40-75%. H NMR and EA measurements details of all synthesized compounds are
available in supplementary data.
2.2. Measurements Setup
Elemental analysis measurements ere conducted with the Vario EL III elemental
analyzer while the NMR spectra were measured in deuterated chloroform with the Bruker
Avance III 500 MHz high resolution spectrometer. These methods confirmed structure and
purity of all studied molecules.
Liquid-crystalline mesophases were investigated by polarized optical microscopy
(POM), thermo-optical analysis (TOA) and differential scanning calorimetry (DSC).
Characteristic liquid-crystalline textures were observed under Olymp1us polarized light

ACCEPTED MANUSCRIPT
microscope BX61-P (TRF) and captured with Bresser camera 9 Mpix. The thermo-optical
analyser used in experiment is described in details in different paper44. Calorimetric
measurements were carried out by Perkin Elmer 8500 calorimeter under nitrogen atmosphere
with the scan rate of 10 K min-1. Thermograms were recorded by the use of thermogravimeter
TG-DTA Setaram SETSYS 16/18.
X-Ray studies were conducted by the use of Xcalibur diffractometer with a Ruby CCD
detector, MoK radiation,  = 0.71073 Å, T = 100(2) K; 5736 reflections collected
(CrysAlisPro, Agilent Technologies, Version 1.171.35.19, 2011), 3140 unique (Rint = 0.0433);
refinement: 3140 reflections, 182 parameters, R1 [I > 2(I)] = 0.0616, wR2 (all data) =
0.1431, GOF on F2 = 0.942; max./min. residual electron density: 0.549/0.313 e Å3;
min/max absorption coefficients 0.789/0.356. The crystal structure was solved by direct
methods in SHELXS and refined in SHELXL software (G. M. Sheldrick, SHELXTL 5.1,
Bruker AXS Inc., 6300 Enterprise Lane, Madison, WI 53719-1173, USA 1997).
2.3. UV-Vis studies
Optical properties of all 14 synthesized compounds were studied by UV-Vis
spectroscopy. The measurements were conducted for dichloromethane solutions of average
concentration of 1,72·10-5mol/dm3. First the wavelength corresponding to the maximum
absorbance has been determined. In further studies all compounds were irradiated by the
suitable wavelength to cause the isomerization process. The kinetics of both isomerization and
relaxation processeswere evaluated. All measurements were performed on UV-Visible
Spectrophotometer Varian Carry500 in the room temperature. Moreover the mercury lamp
was used as a source of the UV light causing isomerization (λ=365nm). As the influence of
the alkyl chain length on isomerization kinetics is minor the results are presented for one
selected derivative 18-Cl.
3. Results and Discussion
3.1. Thermal properties and crystal structure
Thermal stability of synthesized compounds was examined by thermogravimetry. The
obtained results are shown in Figure 2. All materials are stable in the temperature range from 0
to 150 °C.The least stable is the shortest homologue 1-Cl, which starts to decompose above
200°C. Other compounds decompose on average between 300 and 350°C.

ACCEPTED MANUSCRIPT
Figure 2. The thermogravimetric results for the homologues series of 4-(4’-
alkyloxyphenylazo)benzoyl chlorides.
For homologue 2-Cl XRD measurements were carried out and crystal structure was
solved. Resulting crystal structure is shown in Figure 3. 2-Cl crystallizes in triclinic
1
crystallography system and P group. In one cell there are two molecules of 2-Cl. The
dimensions and angles of the cell are as follows: a = 6.9100(4), b = 9.4973(6), c = 10.7025(6)
Å,  = 82.013(5),  = 74.561(5)o,  = 81.894(5). Moreover, two hydrogen bonds were
identified. Their parameters are shown in Table 1. Full XRD results are available in CIF file in
supplementary data.
Figure 3. Molecular structure of 2-Cl. Thermal ellipsoids are drown at 50% probability.

ACCEPTED MANUSCRIPT
Table 1. Hydrogen bonds for 2-Cl [Å and deg.].
D-H...A
d(D-H)
0.95
d(H...A) d(D...A)
<(DHA)
108
C(3)-H(3)···Cl(1)
C(4)-H(4)···O(1)i
2.58
2.49
3.019(3)
3.196(4)
0.95
131
Symmetry code: [ i ] -1+x,y,z
3.2. Mesomorphic Behaviour
Among 14 synthesised compounds 12 exhibit liquid-crystalline properties [Fig. 4.].
Phase transition temperatures and enthalpies are shown in Table 2. In the presented series
only 1-Cl and 2-Cl do not undergo mesomorphic phase transitions. This fact can be explained
by significantly higher (more than 20 Celsius degree) melting temperatures than in case of
the other homologues. All other homologues display one enantiotropic mesophase, which has
been identified as smectic A basing on the well described in literature characteristic focal-
conic texture observed under polarised microscope A sample photograph representative of
observed textures is presented in Figure 5. For the first homologue with liquid-crystalline
behaviour - 3-Cl, smectic A has 30 Celsius degrees width. For compounds with middle-length
alkyloxy chain, from 4-Cl to 12-Cl, smectic A is much wider and ranges from 40 to even 75
degrees.With the increase of alkyloxy chain length to 14 and above, range of smectic phase is
narrowing However, in each material the liquid-crystalline range can be regarded as broad
compared to quite low phase transitions temperatures. Except first three homologues melting
points of presented materials do not exceed 100°C.

ACCEPTED MANUSCRIPT
Figure 4. The diagram of liquid-crystalline properties of presented materials.
Figure 5. Focal-conic texture of smectic A mesophase.
Allphase transitions entropy values are presented in Figure 6. The average value of
crystallization entropy amounts to 87.83 J mol-1K-1 and is shown as a green line in the Figure
6. Melting entropy is on average 109.75 J mol-1K-1 and is shown with the red line. In the
homologous series both parameters increase with the length of the alkyloxy chain. Moreover
for isotropic-smectic transition the entropy was calculated. Results are shown in Figure 7. The
average value of this phase transition is significantly lower. It amounts to 17,26 J mol-1K-1 on
average. Values for all homologues are mostly congruous.

ACCEPTED MANUSCRIPT
Figure 6. Entropies of crystallisation and melting of full homologues series of X-Cl.
Table 2. Temperatures (in °C) and enthalpies (in kJ mol-1) of observed phase transitions in 4-
(4’-alkyloxyphenylazo)benzoyl chlorides.
Acronym
1-Cl
Melting
120.1
[32.3]
118.6
[34.3]
101.1
[18.8]
77.0
Crystallization
107.3
SmA
Iso

[30.7]
112.8
2-Cl
3-Cl
4-Cl
5-Cl




[25.6]
84.0
114.6
[6.65]
119.5
[6.21]
122.9
[6.48]



[18.0]
55.5
[23.1]
72.8
[21.7]
54.6
[6.91]*
[24.7]

ACCEPTED MANUSCRIPT
73.2
[30.2]
75.3
53.3
[6.86]*
50.5
125.2
[6.58]
125.2
[6.77]
124.5
[6.93]
121.5
[6.97]
119.5
[6.99]
113.8
[6.97]
109.5
[6.46]
104.1
[6.99]
101.4
[6.73]
6-Cl
7-Cl


















[30.1]
72.7
[6.96]*
49.1
8-Cl
[37.8]
75.0
[34.26]
46.2
9-Cl
[36.3]
76.1
[24.0]
54.6
10-Cl
12-Cl
14-Cl
16-Cl
18-Cl
[43.0]
79.9
[36.9]
48.0
[50.36]
87.8
[45.51]
64.5
[56.5]
92.1
[48.3]
73.9
[67.4]
96.2
[60.1]
76.1
[68.4]
[52.6]
*- only partial crystallisation was observed.

ACCEPTED MANUSCRIPT
Figure 7. Entropies for Isotropic-SmA phase transitions of 4-(4’-alkyloxyphenylazo)benzoyl
chlorides.
3.3. Photoisomerization Studies
At the beginning of spectroscopic studies all compounds were in pure trans form. The
adequate spectrum is marked with a black line [A, Fig.8.]. Two local maximums can be seen,
characteristic of azobenzen derivatives, low intensity n-π* absorption band in the visible
region around 450 nm and high intensity π-π* absorption band in the UV region at 371nm
Subsequently the wavelength corresponding to maximum absorbance value was denoted. For
most synthesized compounds this wavelength was 371nm. The mercury lamp with filter
(365nm) was used to irradiate the materials. This light corresponds to the π-π* transition
energy gapand is suitable for converting trans isomer into cis one. This geometry change is
reflected in the shape of the UV-Vis spectrum. With irradiation the cis isomer population is
growing in the system. That can be observed as a decrease of absorption band in the UV
region and simultaneous increase of band in the visible region [A, Fig.8.]. This process
continues until the equilibrium between trans and cis isomers is reached. The
photoisomerization phenomenon in azobenzene derivatives is fully reversible. After certain

ACCEPTED MANUSCRIPT
time the thermal relaxation process can be observed [C, Fig.8.]. Normally it is much slower
than isomerization and it defines the usefulness of the material for optical applications.
Kinetic constants of isomerization and relaxation processes were calculated for all members
of the series, an example of 18-Cl is shown in Figure 8. [B, D, Fig.8.]. For most of the
analysed compounds these values were around 1,20·10-1 for isomerization and 2,15·10-3
for relaxation. Especially the second value is quite surprisingbe cause typically similar
compounds are characterized by the values of 10-5 order.
Figure 8. UV-Vis spectra of 18-Cl compound in dichloromethane solution and corresponding
kinetics plots:
A UV-Vis spectra captured after different irradiation times, B – the plot of
ln(An-At / An-A0) vs irradiation time , C – UV-Vis spectra captured in different intervals after
the irradiation was switched off, D - the plot of ln(An-At / An-A0) vs relaxation time
4. Conclusions

ACCEPTED MANUSCRIPT
In this paper properties of 14 new azobenzene derivatives from homologous series of
4-(4’-alkyloxyphenylazo)benzoyl chlorides have been described . Until now these compounds
were considered unsuitable for any applications due to suspected instability common for acid
chlorides and therefore mentioned only as intermediates towards more complex compounds
and never studied in detail. Our studies demonstrate that they are in fact stable in time and
when heated up to 150 degrees Celsius. 12 of 14 members of the series are also liquid-
crystalline with single smectic A mesophase appearing in a range of 30 or more degrees. As is
expected of azo compounds, they display cis-trans isomerization. What is however surprising
is the very short time of relaxation back to trans state, which is 1 hour while similar known
compounds need at least 24 hours. This last parameter makes the analysed materials worth
considering as optical switches.
5. References
(1) Reinitzer, F. R. Beiträge zur Kenntnis des Cholesterins. Monatsh. Chem. 1888, 9, 421–
441.
(2) Vorländer, D. Die Richtung der Kohlenstoff-Valenzen in Benzol-Abkömmlingen. Ber.
Dtsch. Chem. Ges. 1929, 62 (10), 2831-2835.
(3) Gray, G. W. Molecular Structure and the Properties of Liquid Crystals; Academic Press,
Inc., London-New York, 1962.
(4) Cunningham, P. D.; Souza, J. B. Jr.; Fedin, I.; She, C.; Lee, B.; Talapin, D. V. Assessment
of Anisotropic Semiconductor Nanorod and Nanoplatelet Heterostructures with Polarized
Emission for Liquid Crystal Display Technology. ACS Nano 2016, 10 (6), 5769-5781.
(5) Wang, M.; He, L.; Zorba, S.; Yin, Y. Magnetically Actuated Liquid Crystals. Nano Lett.
2014, 14 (7), 3966-3971.
(6) Lee, K. M.; Tondiglia, V. P.; McConney, M. E.; Natarajan, L. V.; Bunning, T. J.; White,
T. J. Color-Tunable Mirrors Based on Electrically Regulated Bandwidth Broadening in
Polymer-Stabilized Cholesteric Liquid Crystals. ACS Photonics 2014, 1 (10), 1033-1041.
(7) Shibaev, P. V.; Wenzlick, M.; Murray, J.; Tantillo, A.; Howard-Jennings, J. Rebirth of
Liquid Crystals for Sensoric Applications: Environmental and Gas Sensors. Adv. Cond
Matter Phys. 2015, 2015, 1-8.

ACCEPTED MANUSCRIPT
(8) Chang, W.-S.; Link, S. Enhancing the Sensitivity of Single-Particle Photothermal Imaging
with Thermotropic Liquid Crystals. J. Phys. Chem. Lett. 2012, 3 (10), 1393-1399.
(9) Yoon, S. H.; Gupta, K. C.; Borah, J. S.; Park, S.-Y.; Kim, Y.-K.; Lee, J.-H.; Kang, I.-K.
Folate Ligand Anchored Liquid Crystal Microdroplets Emulsion for in Vitro Detection of KB
Cancer Cells. Langmuir 2014, 30 (35), 10668-10677.
(10) Kim, H. J.; Rim, J.; Jang, C.-H. Diagnosis of tuberculosis using a liquid crystal-based
optical sensor. Macromol. Res. 2016, 24 (2), 123-30.
(11) Bhowmik, P. K.; Killarney, S. T.; Koh, J. J.; Tanthmanatham, O.; Han, H.; Harris, T.;
Fisch, M. R.; Agra-Kooijman, D.M.; Sharpnack, L.; Kumar, S. Thermotropic liquid–
crystalline properties of 4,4’-dialkoxy-3,3’-diaminobiphenyl compounds and their precursors,
Liq. Cryst. 2016, DOI:10.1080/02678292.2016.1187770.
(12) Ikeda, T. Photomodulation of Liquid Crystal Orientations for Photonic Applications. J.
Matter. Chem. 2003, 13, 2037-2057.
(13) Kosa, T.; Sukhomlinova, L.; Su, L.; Taheri, B.; White, T. J.; Bunning, T. J. Light-
Induced Liquid Crystallinity. Nature 2012, 485, 347-349.
(14) Park, M. S.; Aiyar, A.; Park, J. O.; Reichmanis, E.; Srinivasarao, M. Solvent Evaporation
Induced Liquid Crystalline Phase in Poly(3-hexylthiophene). J. Am. Chem. Soc. 2011, 133
(19), 7244-7247.
(15) Niezgoda, I.; Jaworska, J.; Pociecha, D.; Galewski, Z. The kinetics of the E-Z-E
isomerisation and liquid-crystalline properties of selected azobenzene derivatives investigated
by the prism of the ester group inversion. Liq. Cryst. 2015, 42, 1148-1158.
(16) Yoona, J. H.; Yoon, S. Photoisomerization of azobenzene derivatives confined in gold
nanoparticle aggregates. Phys. Chem. Chem. Phys. 2011, 13, 12900-12905.
(17) Natansohn, A.; Rochon, P. Photoinduced motions in azo-containing polymers. Chem.
Rev. 2002, 102 (11), 4139–4175.
(18) Hana, M.; Ishikawab, D.; Mutoc, E.; Haraa, M. Isomerization and fluorescence
characteristics of sterically hindered azobenzene derivatives. J. Lumin. 2009, 129 (10), 1163–
1168.

ACCEPTED MANUSCRIPT
(19) Jaffé, H. H.; Yeh, S.-J.; Gardner, R. W. The electronic spectra of azobenzene derivatives
and their conjugate acid. J. Mol. Spectrosc. 1958, 2 (1-6), 120-136.
(20) Kurihara, S.; Yoneyama, D.; Nonaka, T. Photochemical Switching Behavior of Liquid-
Crystalline Networks: Effect of Molecular Structure of Azobenzene Molecules. Chem. Mater.
2001, 13 (9), 2807-2812.
(21) Diau, E. W.-G. A New Trans-to-Cis Photoisomerization Mechanism of Azobenzene on
the S1( n,π*) Surface. J. Phys. Chem. A 2004, 108, 950-956.
(22) Sekkat, Z.; Morichère, D.; Dumont, M.; Loucif-Saibi, R.; Delaire, J. A.
Photoisomerization of Azobenzene Derivatives in Polymeric Thin Films. J. Appl. Phys. 1992,
71, 1543-1545.
(23) Bandarab, H. M. D.; Burdette, S. C. Photoisomerization in different classes of
azobenzene. Chem. Soc. Rev. 2012, 41, 1809-1825.
(24) Ikeda, T.; Tsutsumi, O. Optical Switching and Image Storage by Means of Azobenzene
Liquid-Crystal Films. Science 1995, 268, 1873-1875.
(25) Gindre, D.; Boeglin, A.; Fort, A.; Mager, L.; Dorkenoo, K. D. Rewritable optical data
storage in azobenzene copolymers. Opt. Express 2006, 14, 9896-9901.
(26) Hua,D.; Lina, J.; Jina, S.; Hub, Y.; Wanga, W.; Wanga, R.; Yanga, B. Synthesis,
structure and optical data storage properties of silver nanoparticles modified with azobenzene
thiols. Mater. Chem. Phys. 2016, 170, 108–112.
(27) Wen, H.; Zhang, W.; Wengab, Y.; Hu, Z. Photomechanical bending of linear azobenzene
polymer. RSC Adv. 2014, 4, 11776-11781.
(28) Ye, X.; Kuzyk, M. G. Azobenzene compound-based photomechanical actuator devices,
Proc. SPIE 8519, Nanophotonics and Macrophotonics for Space Environments VI, 85190I
(October 15, 2012); doi:10.1117/12.928879.
(29) Ichimura, K. Photoalignment of Liquid-Crystal Systems. Chem. Rev. 2000, 100, 1847-
1873.
(30) Itoh, M.; Harada, K.; Kamemaru, S.; Yatagai, T. Holographic Recording on Azo-benzene
Functionalized Polymer Film. Jpn. J. Appl. Phys. 2004, 43, 4968-4971.

ACCEPTED MANUSCRIPT
(31) Han, M.; Honda, T.; Ishikawa, D.; Ito, E.; Hara, M.; Norikaned, Y. Realization of highly
photoresponsive azobenzene-functionalized monolayers. J. Mater. Chem. 2011, 21, 4696-
4702.
(32) Takeshima, T.; Liao, W.-Y.; Nagashima, Y.; Beppu, K.; Hara, M.; Nagano, S.; Seki, T.
Photoresponsive Surface Wrinkle Morphologies in Liquid Crystalline Polymer Films.
Macromolecules 2015, 48 (18), 6378-6384.
(33) Jaworska, J.; Bartkiewicz, S.; Galewski, Z. Phase diagram oftrans–cis isomers for
photoactive and mesogenic 4-hexyl-4'-propoxyazobenzene. J. Phys. Chem. C 2013, 117,
27067-27072.
(34) Bedel, J. P.; Rouillon, J. C.; Marcerou, J. P.; Laguerre, M.; Nguyen, H. T.; Achard, M. F.
New switchable smectic phases in banana-shaped compounds. Liq. Cryst. 2001, 28 (9), 1285-
1292.
(35) Takezoe, H.; Takanishi, Y. Bent-core liquid crystals: their mysterious and attractive
world. Jpn. J. Appl. Phys. 2006, 45, 597- 625.
(36) Dantlgraber, G.; Baumeister, U.; Diele, S.; Kresse, H.; Lühmann, B.; Lang, H.;
Tschierske, C. Evidence for a New Ferroelectric Switching Liquid Crystalline Phase Formed
by a Carbosilane Based Dendrimer with Banana-Shaped Mesogenic Units. J. Am. Chem.
Soc. 2002, 124 (50), 14852-14853.
(37) Prehm, M.; Diele, S.; Das, M. K.; Tschierske, C. Correlated Layer Structures: A Novel
Type of Liquid Crystalline Phase with 2D-Lattice. J. Am. Chem. Soc. 2003, 125 (3), 614-
615.
(38) Kirsch, P.; Bremer, M.; Huber, F.; Lannert, H.; Ruhl, A.; Lieb, M.; Wallmichrath, T.
Nematic Liquid Crystals with a Tetrafluoroethylene Bridge in the Mesogenic Core Structure.
J. Am. Chem. Soc. 2001, 123 (23), 5414-5417.
(39) Rego, J. A.; Kumar, S.; Ringsdorf, H. Synthesis and Characterization of Fluorescent,
Low-Symmetry Triphenylene Discotic Liquid Crystals: Tailoring of Mesomorphic and
Optical Properties. Chem. Mater. 1996, 8 (7), 1402-1409.
(40) Yang, J.; Zhang, Q.; Zhu, L.; Zhang, S.; Li, J.; Zhang, X.; Deng, Y. Novel Ionic Liquid
Crystals Based on N-Alkylcaprolactam as Cations. Chem. Mater. 2007, 19 (10), 2544-2550.

ACCEPTED MANUSCRIPT
(41) Vasconcelos, U. B.; Dalmolin, E.; Merlo, A. A. Synthesis and Thermal Behavior of New
N-Heterotolan Liquid Crystals. Org. Lett. 2005, 7 (6), 1027-1030.
(42) Raja, K. S.; Ramakrishnan, S.; Raghunathan,V. A. Asymmetric Discotic Liquid Crystals
Based on Rufigallol. Chem. Mater. 1997, 9 (7), 1630-1637.
(43) Niezgoda, I.; Pociecha, D.; Galewski, Z. Monotropic or enantiotropic mesophases?
Liquid-crystalline and solid state polymorphism 4-chloro-1,3-phenylene bis-[4-(4-
alkyloxyphenylazo)benzoates. Thermochim. Acta 2014, 587, 59–66.
(44) Galewski, Z.; Coles, H. J. Liquid crystalline properties and phase situations in 4-
chlorobenzylidene-4-alkylanilines. J. Mol. Liq. 1999, 79, 77-87.
(45) Horiuchi, K.; Yamamura, Y.; Pełka, R.; Sumita, M.; Yasuzuka, S.; Massalska-Arodź, M.;
Saito, K., Entropic Contribution of Flexible Terminals to Mesophase Formation Revealed by
Thermodynamic Analysis of 4-Alkyl-4’-isothiocyanatobiphenyl (nTCB). J. Phys. Chem. B
2010, 114 (14), 4870-4875.
Acknowledgment
Authors thank dr. Urszula Jarek-Mikulska for fruitful discussion and valuable comments.
The work was financed by Grant No. 2014/15/B/ST8/00115 from the Polish National Science
Centre.

ACCEPTED MANUSCRIPT
Graphical Abstract

ACCEPTED MANUSCRIPT
Highlights
 Full homologues series of 4-alkoxyazobenzene chlorides was synthesized
 Unexpected liquid-crystalline properties were discovered and investigated
 Kinetic constants of photoisomerization process were calculated
 Influence of the molecule length on mesomorphism and photoisomerization rate
were defined
