Semisynthesis and inhibitory effects of solidagenone derivatives on TLR-mediated inflammatory responses

Article abstract of DOI:10.3390/molecules23123197

A series of nine derivatives (2–10) were prepared from the diterpene solidagenone (1) and their structures were elucidated by means of spectroscopic studies. Their ability to inhibit inflammatory responses elicited in peritoneal macrophages by TLR ligands was investigated. Compounds 5 and 6 showed significant anti-inflammatory effects, as they inhibited the protein expression of nitric oxide synthase (NOS-2), cyclooxygenase-2 (COX-2), and cytokine production (TNF-α, IL-6, and IL-12) induced by the ligand of TLR4, lipopolysaccharide (LPS), acting at the transcriptional level. Some structure–activity relationships were outlined. Compound 5 was selected as a representative compound and molecular mechanisms involved in its biological activity were investigated. Inhibition of NF-B and p38 signaling seems to be involved in the mechanism of action of compound 5. In addition, this compound also inhibited inflammatory responses mediated by ligands of TLR2 and TLR3 receptors. To rationalize the obtained results, molecular docking and molecular dynamic studies were carried out on TLR4. All these data indicate that solidagenone derivative 5 might be used for the design of new anti-inflammatory agents.

Full text of DOI:10.3390/molecules23123197

molecules
Article
Semisynthesis and Inhibitory Effects of
Solidagenone Derivatives on TLR-Mediated
Inflammatory Responses
Irene Cuadrado 1, Ángel Amesty 2, Juan Carlos Cedrón 2, Juan Carlos Oberti 2,3
,
Ana Estévez-Braun 2,
* *
, Sonsoles Hortelano 4,* and Beatriz de las Heras 1,
1
Departamento de Farmacología, Farmacognosia y Botánica. Facultad de Farmacia, Universidad
Complutense de Madrid (UCM), Plaza Ramón y Cajal s/n. 28040 Madrid, Spain; icberrocal@ucm.es
Departamento de Química Orgánica, Instituto Universitario de Bio-Orgánica Antonio González,
Universidad de La Laguna. Avda. Astrofísico Fco. Sánchez 2. La Laguna, 38206 Tenerife, Spain;
angelamesty@yahoo.es (A.A.); jccedron@ull.es (J.C.C.); jco@fcq.unc.edu.ar (J.C.O.)
2
3
4
Facultad de Ciencias Químicas, Universidad de Córdoba and IMBIV (UNC
la Torre y M. Allende, Ciudad Universitaria, X5000HUA Córdoba, Argentina
−
CONICET), Avenida Haya de
Unidad de Terapias Farmacológicas. Área de Genética Humana. Instituto de Investigación de Enfermedades
Raras (IIER), Instituto de Salud Carlos III, Carretera de Majadahonda-Pozuelo Km 2, 28220 Madrid, Spain
Correspondence: aestebra@ull.edu.es (A.E.-B.); shortelano@isciii.es (S.H.); lasheras@ucm.es (B.d.l.H.);
Tel.: +34-913942276 (B.d.l.H.)
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 5 November 2018; Accepted: 3 December 2018; Published: 4 December 2018
Abstract: A series of nine derivatives (2–10) were prepared from the diterpene solidagenone (1)
and their structures were elucidated by means of spectroscopic studies. Their ability to inhibit
inflammatory responses elicited in peritoneal macrophages by TLR ligands was investigated.
Compounds
expression of nitric oxide synthase (NOS-2), cyclooxygenase-2 (COX-2), and cytokine production
(TNF- , IL-6, and IL-12) induced by the ligand of TLR4, lipopolysaccharide (LPS), acting at the
transcriptional level. Some structure–activity relationships were outlined. Compound was selected
as a representative compound and molecular mechanisms involved in its biological activity were
investigated. Inhibition of NF- B and p38 signaling seems to be involved in the mechanism of action
of compound . In addition, this compound also inhibited inflammatory responses mediated by
5 and 6 showed significant anti-inflammatory effects, as they inhibited the protein
α
5
κ
5
ligands of TLR2 and TLR3 receptors. To rationalize the obtained results, molecular docking and
molecular dynamic studies were carried out on TLR4. All these data indicate that solidagenone
derivative 5 might be used for the design of new anti-inflammatory agents.
Keywords: solidagenone derivatives; diterpenes; inflammation; TLR4; molecular docking
1. Introduction
Inflammation is a protective physiological response of body tissues to harmful stimuli such as
microbial infection or tissue injury. Nevertheless, an imbalance in the mechanisms that govern this
process lead to the development of several pathologies [1,2]. The triggers and mechanisms leading
to inflammation may vary between clinical conditions, but they share many common mediators,
including specific patterns of eicosanoid and cytokine production.
The inflammatory response is initiated by the cellular sensing of either pathogen-associated
molecular patterns (PAMPs) or damage-associated molecular patterns (DAMPs) through pattern
recognition receptors (PRRs), such as Toll-like receptors (TLR), which trigger specific signaling
pathways. During the inflammatory process, macrophages, being critical role players, dominate
Molecules 2018, 23, 3197; doi:10.3390/molecules23123197
www.mdpi.com/journal/molecules

Molecules 2018, 23, 3197
2 of 19
in the context of tissue injury and in the subsequent tissue repair [
3,4
]. Upon sensing the presence
of pathogens through TLRs and other receptors, macrophages are stimulated to secrete a battery of
cytokines that recruit effector cells into the infected area [ ]. Most TLRs use the myeloid differentiation
5,6
primary-response protein 88 (MyD88), a TIR (Toll/IL-1 receptor)-containing adaptor, to trigger a
signaling pathway that culminates in the activation of downstream signaling pathways, such as the
nuclear transcription factor-κB (NF-κB) pathway [7,8]. Activation of NF-κB leads to the upregulation
of proinflammatory enzymes such as nitric oxide synthase-2 (NOS-2) and cyclooxygenase-2 (COX-2)
and the production of inflammatory mediators such as nitric oxide (NO), prostaglandins, chemokines,
and inflammatory cytokines that are well-known to be involved in the pathogenesis of inflammatory
response. These signals are essential for the classical outcome of TLR activation: the orchestration of the
host’s innate and adaptive immune responses. However, a persistent activation of the TLR-mediated
intracellular signal transduction pathway in monocytes/macrophages, characterized by the excessive
release of proinflammatory cytokines, maintains a chronic inflammatory state and may lead to the
development of numerous pathologies [2,6]. Thus, control of macrophage activation and suppression
and/or inhibition of the abovementioned signaling molecules may have great potential for preventing
and treating inflammation-associated diseases.
Traditionally, natural products have represented an excellent resource for drug discovery and
development. Natural product chemistry has been an effective strategy for the identification of bioactive
lead candidates. An interesting group of natural products are the diterpenes, as they possess a plethora
of biological activities and display many pharmacological properties with therapeutic potential [9–14].
However, no report has been issued on the anti-inflammatory effects of labdane diterpenes isolated
from the rhizomes of Solidago chilensis, a plant traditionally used to treat symptomatologies related to
inflammation [15].
Therefore, as part of our ongoing screening program to evaluate the potential of diterpenes as
a source of novel bioactive compounds in inflammation-based diseases, a series of diterpenes were
semisynthesized from the natural diterpene solidagenone. Herein, we report the preparation and
anti-inflammatory effects of these solidagenone derivatives (2−10) in peritoneal macrophages.
Among the derivatives evaluated, solidagenone derivative 5 exhibited significant anti-inflammatory
activity in TLR-activated peritoneal macrophages. This derivative suppressed the production of
proinflammatory mediators via inhibition of the NOS-2 and COX-2 enzymes, as well as cytokines.
These effects were accompanied by the downregulation of NF-
protein kinase (MAPK) phosphorylation.
κB activation and mitogen-activated
2. Results and Discussion
Several modifications were carried out on the diterpene solidagenone (1), aiming to obtain new
derivatives and to evaluate the role of the different functional groups and moieties present in the
structure of 1 (Scheme 1) in its anti-inflammatory activity.
Thus, the treatment of solidagenone with NaBH4 yielded the unexpected spirolactone (
Compound has three fewer carbons than , and it is probably formed by rupture of the furan
ring followed by reductive cyclization. The existence of the lactone moiety was supported by the
presence of a carbonyl group at 176.0 ppm, a quaternary oxygenated carbon at 90.0, and two
methylene carbons at 30.9 and 23.9, respectively. The HSQC and HMBC (Figure 1) correlations
observed for (2) in the corresponding spectra ratified its structure.
When was treated with AcCl/Py, the two compounds ( ) and (
mechanism of formation involves the acetylation of the hydroxyl group and elimination of the
corresponding acetyl group via 1,2-methyl shift to afford ( ). An intramolecular Michael addition of
the furan ring on the -unsaturated carbonyl system could explain the formation of the tetracyclic
compound (4) (Scheme 2).
2).
2
1
δ
δ
1
3
4) were formed. A plausible
3
α,β

Molecules 2018, 23, 3197
3 of 19
Scheme 1. Solidagenone derivatives. Reagents and conditions: (a) NaBH4, ethanol, rt; (b) AcCl, rt;
(c) Br2, dry DCM, rt; (d) BBr3, dry DCM, 0 ◦C; (e) SOCl2, dry DCM, reflux; (f) NaH; dry THF, reflux;
(g) H2, 10% Pd/C, rt.
Figure 1. Key HMBC correlations for 2.
Scheme 2. Plausible formation of compounds 3 and 4.
The minimum-energy conformers for compound
3 were analyzed in order to corroborate
this plausible mechanism. One of them (Figure 2) showed an appropriate distance (2.83 Å) and
relative spatial position between the carbons C-8 and C-16 to support the intramolecular ring-closing
reaction [16]. The syn orientation of the methyl groups on the new formed ring was ratified by the
NOEs detected between the methyl groups at C-8 and C-9, respectively.

Molecules 2018, 23, 3197
4 of 19
Figure 2. Representative minimum-energy conformer of compound 3.
When
1
was reacted with 2 equiv. of Br2/DCM, the brominated compounds (
5) and (
6
) were
formed. The regiosubstitution of the furan ring was determined by an HMBC experiment. Thus,
the following HMBC correlations: H-14 with C-13, C-15, and C-16; and H-12 with C-13, C-14, and C-16
located the two bromine atoms at the carbons C-15 and C-16. The third bromine was located at C-7
in compound
carbonyl carbon at
was determined as
6
, since a singlet was observed at
δ
4.37, which showed HMBC correlations with the
203.3 (C-6) and with the olefinic carbons C-8 and C-9. The relative orientation
on the basis of the ROEs detected in the ROESY spectrum. The reaction of
), which showed similar NMR data to compound
but corresponding to the furan ring. A similar chlorine derivative ( ) was obtained when was
reacted with thionyl chloride in DCM. The treatment of with NaH in THF led to derivative ( ).
The hydrogenation of yielded the corresponding derivative (10) with the furan ring reduced to
tetrahydrofuran. The orientation of the methyl group at C-8 was established on the basis of the NOE
δ
β
1
6,
with BBr3 led to the monobrominated derivative (
7
8
1
1
9
1
α
effect between the multiplet at δ 2.34 (1H, H-8) and the singlet at δ 1.03 (3H, H-20).
2.1. Effects of Solidagenone Derivatives on Inflammatory Responses
To evaluate whether these diterpenes (1–10) regulate the inflammatory response, we investigated
the anti-inflammatory effects and underlying mechanisms of action of these derivatives in peritoneal
macrophages. We first identified compounds which can inhibit the inflammatory response induced
by bacterial lipopolysaccharide (LPS), a well-characterized ligand of TLR4 in murine peritoneal
macrophages. For this, cells were preincubated with diterpenes for 30 min before their stimulation
with LPS (200 ng/mL), and NO production was assayed. Initial testing of the compounds at a fixed
concentration of 20
µM revealed that all the derivatives exhibited significant inhibitory effects on
NO release. Four compounds (
3
,
5,
6
, and ) were able to inhibit NO release by more than 50%
7
(Figure 3A). Moreover, they also displayed higher inhibitory activity than indomethacin at 10
used as a reference anti-inflammatory drug.
µM,
To discard the possibility that the inhibitory effect on NO release was due to cytotoxicity, we
analyzed the percentage of cell viability by MTT (3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium
bromide) assay. As shown in Figure 3B, compounds
the rest of compounds tested were noncytotoxic, as cell viability was not significantly affected by
compounds in the 10–50 M range where the anti-inflammatory activity was studied (data not shown).
3 and 7 significantly reduced cell viability, whereas
µ
From the obtained results, some structure–activity relationships were outlined. It was thus
found that the presence of bromine groups is important for the activity in the bicyclic derivatives.
If we compare the inhibition of NO release of compound 4 with that of compound 5, the presence of

Molecules 2018, 23, 3197
5 of 19
bromines in the furan ring is associated with a lower percentage of NO release. The replacement of a
bromine group at C-7 (7) by a chlorine group (8) led to a lower inhibition of NO production.
In view of these data, compounds
5
and
6 were selected for further evaluation. Studies of the
dose–response effects of compounds and
5
6
on NO release showed NO inhibitory effects with IC50
values of 9.1 ± 1.51 and 14.52 ± 1.03 µM, respectively (Figure 3C).
LPS has been the most studied TLR4 ligand. The binding of LPS to TLR4 on macrophages activates
the transcription factor NF-
κB, a key step in the onset of the inflammatory response. NF-κB regulates
the expression of proinflammatory mediators and enzymes such as NOS-2 and COX-2. To further
analyze the signaling pathways modulated by the two selected compounds
activation of the proinflammatory genes NOS-2 and COX-2.
5 and 6, we studied the
Figure 3. Effects of solidagenone derivatives on nitric oxide (NO) release and cell viability.
) Peritoneal macrophages were treated with vehicle (Vh), lipopolysaccharide (LPS) (200 ng/mL),
LPS and 10 M of indomethacin (In), or LPS and 20 M of solidagenone derivatives ( 10) for 24 h.
The accumulation of nitrite in the culture medium was measured with the Griess method and expressed
as the percentage of NO release compared to LPS treatment. ( ) Peritoneal macrophages were treated
with vehicle (Vh) or 20 M of solidagenone derivatives ( 10) for 24 h. Cell viability was determined by
MTT assay. ( ) Dose-dependent effects of compounds and (5–20 M) on NO release. Experiments
SD of three independent experiments.
(
A
µ
µ
1–
B
µ
1–
C
5
6
µ
were carried out in triplicate and results are the means
* p < 0.05 and ** p < 0.01 with respect to the LPS treatment.
±

Molecules 2018, 23, 3197
6 of 19
In unstimulated peritoneal macrophages, the levels of NOS-2 and COX-2 proteins were
undetectable. As expected, LPS treatment induced the activation of both proteins. However, when
macrophages were preincubated with compounds 5 and 6 and stimulated with LPS for 24 h, a significant
inhibition of the protein expression of NOS-2 and COX-2 was observed (Figure 4). Although similar
inhibitory effects on NOS-2 and COX-2 expression were observed for both solidagenone derivatives,
compound 5 exhibited the lowest IC50 value, being selected for further studies.
Figure 4. NOS-2 and COX-2 expression is inhibited by solidagenone derivatives. (
were preincubated for 30 min with derivatives and (10 and 20 M) followed by stimulation
with 200 ng/mL LPS for 24 h. NOS-2 and COX-2 proteins were detected by Western blot. -actin
content was used as a loading control. The Western blot in ( ) shows a representative experiment.
) Densitometry analysis of NOS-2 ( ) and COX-2 ( ) expression was performed. Results show
the mean SD of three independent Western blot experiments and are expressed as the percentage of
A) Macrophages
5
6
µ
β
A
(
B–
C
B
C
±
relative signal intensity with respect to the LPS condition. * p < 0.05, ** p < 0.01, with respect to the
LPS condition.
Analysis of NOS-2 and COX-2 mRNA by real-time quantitative PCR revealed that compound
5
inhibited LPS-induced expression of both enzymes, acting at the transcriptional level (Figure 5).
In order to explore whether other inflammatory mediators such as cytokines were affected by treatment
with compound 5, we next analyzed levels of tumor necrosis factor-α (TNF-α), interleukin (IL)-6,

Molecules 2018, 23, 3197
7 of 19
and IL-12. All cytokines were downregulated at the mRNA level in the presence of compound
5 after
stimulation with LPS (Figure 5). Interestingly, these data demonstrated that this derivative has a broad
effect on the transcription of proinflammatory genes associated with the LPS-induced response.
NOS-2
COX-2
400
350
300
250
200
150
100
50
500
400
300
200
100
*
**
**
**
**
***
0
0
-
-
5
10 20
LPS
comp. 5 (μM)
comp. 5 (μM)
-
-
5
10 20
LPS
TNF-α
IL-6
*
IL-12
**
70
60
50
40
30
20
10
0
1200
1000
800
400
300
200
100
0
*
600
**
400
**
***
***
200
***
***
0
-
-
5
10 20
LPS
-
-
5
10 20
-
-
5
10 20
LPS
comp. 5 (μM)
comp. 5 (μM)
comp. 5(μM)
LPS
Figure 5. Diterpene
Macrophages were preincubated for 30 min with compound 5 (5, 10, and 20
stimulation with 200 ng/mL LPS for 4 h. Relative expression of NOS-2, COX-2, TNF-
mRNA was determined by real-time quantitative PCR. Results are the means SD of three independent
5
inhibits expression of inflammatory genes in a dose-dependent manner.
M) followed by
, IL-6, and IL-12
µ
α
±
experiments carried out in triplicate. * p < 0.05, ** p < 0.01, and *** p < 0.001 vs. the LPS condition.
TLR ligands activate various downstream intracellular signaling cascades, such as the NF-κB and
MAPK pathways. NF-
kappa B (I B) proteins, leading to the translocation of p65/p50 heterodimers to the nucleus.
Interestingly, this transcription factor has been a common target in the mechanism of action of some
diterpenes [ 14 17 19]. The activation of MAPK cascades, including extracellular-signal regulated
kinase 1/2 (ERK1/2), c-Jun-N-terminal kinase (JNK), and p38 MAPK, is another event triggered by TLR
ligands in macrophages [20 22], which also plays important roles in the induction of proinflammatory
genes. Thus, we next evaluated whether the anti-inflammatory effect of compound could be
attributed to inhibitory effects on these pathways. First, we examined its effects on the levels of
cytosolic I and I proteins in LPS-activated macrophages. As shown in Figure 6, degradation of
and I were impaired in activated cells pretreated with compound . Furthermore, a reduced
accumulation of the NF- B p65 subunit in the nucleus was observed after treatment with diterpene
In addition, compound also inhibited p38 phosphorylation (Figure 7), whereas the activation of other
MAPKs (ERK1/2 or JNK) was not affected (Figure 7 and data not shown). These data suggest that the
diterpene affects proinflammatory signaling mainly through regulation of NF- B and p38 activation.
κB activation requires the phosphorylation and degradation of inhibitory
κ
9, , –
–
5
κ
B
α
κBβ
I
κ
B
α
κ
Bβ
5
κ
5.
5
5
κ

Molecules 2018, 23, 3197
8 of 19
Figure 6. Diterpene
were pretreated for 30 min with compound
30, 45, and 60 min) with 200 ng/mL LPS. The levels of proteins I
by Western blot. -actin and PSF were used as loading controls. A representative experiment is shown.
5
inhibits NF-
κ
B activation in LPS-stimulated murine macrophages. Macrophages
(20 M) and then activated for the indicated times (5, 15,
, I , and p65 were determined
5
µ
κBα κBβ
β
Densitometry analysis shows the mean
** p < 0.01 vs. LPS.
±
SD of three independent Western blot experiments. * p < 0.05,
Figure 7. Regulation of MAPK activities by diterpene
with compound (20 M) and then activated for the indicated times (5, 15, 30, 45, and 60 min) with
200 ng/mL LPS. Levels of phospho- and total MAPKs (ERK and p38) were determined by Western
5. Macrophages were pretreated for 30 min
5
µ
blot. A representative experiment is shown. Densitometry analysis shows the mean
independent Western blot experiments. * p < 0.05, ** p < 0.01, and *** p < 0.001 vs, LPS.
±
SD of three
2.2. Effects of Compound 5 in Response to Different TLR Ligands
Pharmacological regulation of TLR signaling is a promising therapeutic strategy for various
inflammatory and autoimmune diseases [23 25]. Other TLR ligands, including TLR2 and TLR3,
also induce inflammatory responses in macrophages. In order to determine if compound exhibits
–
5
inhibitory effects against other TLRs, we examined the response of macrophages to the TLR3 ligand
polyriboinosinic–polyribocytidylic acid (polyI:C) and to the TLR2 ligand lipoteichoic acid (LTA).

Molecules 2018, 23, 3197
9 of 19
The accumulation of the proinflammatory mediator NO in the culture medium was also
dose-dependently (5–20 M) inhibited, regardless of ligand treatment (Figure 8A). The dose–response
µ
curves for all three ligands showed comparable inhibition. As shown in Figure 8B, LPS, polyI:C,
and LTA promoted the expression of NOS-2 in macrophages, an effect that was attenuated in the
presence of compound 5. COX-2 expression induced by LPS and LTA was also inhibited by compound 5.
These results suggest that this diterpene has a broad suppressive effect on TLR-mediated inflammatory
responses. Considering the pathological role of TLRs in inflammatory diseases, inhibitors targeting
TLR signaling may emerge as novel therapeutics to treat these disorders [24].
Figure 8. Compound
receptors (TLRs).
5
inhibits NO release and gene expression mediated by different Toll-like
(
A
) Peritoneal macrophages were incubated with diterpene (5–20 M) or
5
µ
vehicle for 30 min, followed by stimulation with (TLR ligands): LPS 200 ng/mL (TLR4 ligand),
polyriboinosinic–polyribocytidylic acid (poly I:C) 20 µg/mL (TLR3 ligand), or lipoteichoic acid (LTA)
10
with the Griess reagent. Experiments were carried out in triplicate and results show the mean
three independent experiments. ( ) Peritoneal macrophages were incubated with diterpene
or vehicle for 30 min, followed by stimulation with TLR ligands for 20 h. NOS-2 and COX-2 proteins
were detected by Western blot and -actin was used as a loading control. A representative experiment
µ
g/mL (TLR2 ligand) for 24 h. The accumulation of nitrite in the culture medium was measured
SD of
(20 M)
±
B
5
µ
β
of three is shown. Densitometry analysis shows the mean
experiments. ** p < 0.01, *** p < 0.001.
±
SD of three independent Western blot

Molecules 2018, 23, 3197
10 of 19
2.3. Molecular Docking Studies
In order to propose a mode of action of the significant anti-inflammatory effects of the solidagenone
derivatives and , we carried out a molecular docking study using the Glide software [26] on reported
5
6
the crystal structure of human TLR4 in complex with MD-2 and LPS (PDB 4G8A). Like the extracellular
domains of other TLRs, TLR4 contains leucine-rich repeats and adopts a characteristic horseshoe-like
shape. MD-2 is noncovalently bound to the side of the horseshoe ring and also directly interfaces
with the ligand. MD-2 has a β-cup fold structure composed of two antiparallel β-sheets, forming
a large hydrophobic pocket for ligand binding. The molecular docking study is a well-known and
effective method to predict the binding mode of the ligand to its receptors. Hence, in order to explore
the binding mode of solidagenone derivatives 5 and 6, we simulated docking of the compounds into
the large hydrophobic binding pocket of MD-2 to see if these compounds could interact with this
target, and consequently, to understand the possible binding mode and key active site interactions.
An analysis of the docking results showed that the compounds fit very well and could be inserted into
the large hydrophobic binding pocket of MD-2 and easily occupy a large portion of the LPS binding
site. In addition, these docking results strongly suggested that the solidagenone derivatives
share a common binding mode into the hydrophobic binding pocket of MD-2. The best docking
scores were found in the range from 6.83 to
8.51 kcal mol−1. According to the predicted binding
modes, the most active compounds showed a stacking interaction between the furan ring present
5 and
6
−
−
π–π
in these compounds and some amino acid residues. Hydrophobic interactions therefore probably play
a dominant role in the interaction. In the favored docking conformation, many hydrophobic side-chain
residues of the MD-2 pocket are in close proximity to the solidagenone derivatives.
In the predicted pose of the most active compound (5), the furan ring showed a key π–π interaction
with Phe 76 (Figure 9). There are also multiple potential hydrophobic interactions with MD-2, involving
residues such as Leu 61, Phe 104, Ile 94, Phe 151, Phe 147, Tyr 102, Val 135, Ile 46, Ile 63, and Ile 117
(Figure 9). Taken together, such interactions of the compound with MD-2 suggest that the binding of
forms a bulky hindrance that blocks the interaction of LPS with MD-2.
5
Figure 9. Docking model and key interactions of compound 5 into the TLR4 active site (PDB 4G8A).
2.4. Molecular Dynamics (MD) Simulation
The docking protocols can be combined with accurate molecular dynamics (MD) simulation
techniques to predict more reliable protein–ligand complex structures and confirm system stability.
We explored the stability of the best docking pose of
5 with molecular dynamics (MD) simulation,
and the protein–ligand interactions were investigated throughout the course of the MD simulations.
The simulations provide minute detail about the movement of every particle/atom over time. This will
help in answering the questions arising about the deviation and fluctuation patterns of the proteins.

Molecules 2018, 23, 3197
11 of 19
The MD simulation of the energy-minimized docked complex with the best docking scores of
compound with MD-2 was performed over 50 ns in an explicitly aqueous solution environment
5
employing the Desmond Software (which was developed at D. E. Shaw Research to perform high-speed
molecular dynamics simulations of biological systems), the OPL-2005 force field, and the TIP3P solvent
model. Molecular dynamic simulations were performed to confirm the orientation of compound
5 in
the binding site. The MD simulation results indicated that the compound does not leave the binding
cavity of the protein and remains in a similar orientation during the entire simulation (Figure 10).
Figure 10. Interaction diagram for compound 5 and MD-2 complex obtained in molecular dynamics
simulation studies.
In the graphical snapshot of the production phase, it was revealed that compound 5 efficiently
interacted through water bridges to form two H-bond interactions between the carbonyl group present
in the solidagenone scaffold and the critical polar amino acid residues Ser 120 and Arg 90. It indicated
that compound
5 is additionally stabilized by hydrogen bonds, which may explain the potency of this
derivative. However, the interaction with Ser 120 is less significant, since it was only observed for
about 11% of the simulation time, while the interaction with Arg 90 occurred for more than 28% of the
simulation time in the selected trajectory (Figure 11).
In addition, it could also be observed that compound
5 interacted with other essential amino acid
residues such as Phe 119, Phe 121, and Phe 151, which are part of the large hydrophobic pocket by
means of hydrophobic interactions. These interactions of the protein with the ligand could be observed
as interaction fractions throughout the molecular dynamics simulation (Figure 12). The stacked bar
charts are normalized over the course of the trajectory: for example, a value of 0.7 suggests that the
specific interaction is maintained for 70% of the simulation time. This allowed us to establish the
role of each of the particular bonds with the amino acid residues responsible for the stabilization of
the complex. This model and subsequent dynamical observation can help in explaining the activity
of compound
5 confirming the potential of solidagenone derivatives as promising candidates for
TLR4 inhibitors.

Molecules 2018, 23, 3197
12 of 19
Figure 11. Interactions of compound
5 with the key amino acid residues at the hydrophobic binding
pocket of MD-2 (docking score:
−
8.51 kcal mol−1). The colors indicate the residue type: green are
lipophilic residues; blue are polar residues; purple are basic residues. Ligand atoms that are exposed to
the solvent are marked with grey spheres. C: means MD2 region of TLR4.
Figure 12. The stacked bar charts of MD-2 interaction with compound 5.

Molecules 2018, 23, 3197
13 of 19
3. Materials and Methods
3.1. Chemistry
3.1.1. General Methods
NMR spectra were recorded in CDCl3 or at 400 MHz for 1H NMR and 100 MHz for 13C NMR.
1
Chemical shifts are given in (
δ
) parts per million and coupling constants (J) in hertz (Hz). H and 13
C
spectra were referenced using the solvent signal as the internal standard. HREIMS were recorded
using a high-resolution magnetic trisector (EBE) mass analyzer. Analytical thin-layer chromatography
plates used were POLYGRAM-SILG/UV. Preparative thin-layer chromatography was carried out with
Analtech GF plates (20
All solvents and reagents were purified by standard techniques as reported previously [27] or used
as supplied from commercial sources. Solidagenone ( ) was isolated from the air-dried rhizomes of
×
20 cm, 1000 microns) using appropriate mixtures of ethyl acetate and hexanes.
1
Solidago chilensis Meyen (Asteraceae) as previously reported [28].
3.1.2. Solidagenone (1)
1HNMR (400 MHz)
δ 1.00 (3H, s, H-20), 1.14 (3H, s, H-18), 1.16 (1H, m, H-3a), 1.19 (3H, s, H-20),
1.34 (1H, m, H-3b), 1.52 (2H, m, H-1), 1.57 (2H, m, H-2), 1.77 (1H, m, H-11a), 1,90 (1H, m, H-11b), 2.01
(3H, s, H-17), 2.65 (2H, m, H-12), 2.70 (1H, s, H-5), 5.70 (1H, s, H-7), 6.30 (1H, s, H-14), 7.25 (1H, s, H-16),
7.37 (1H, s, H-15); 13C-NMR (100 MHz)
δ 200.1 (C-6), 155.6 (C-8), 143.1 (C-15), 138.5 (C-16), 129.2 (C-7),
125.1 (C-13), 110.7 (C-14), 76.5 (C-9), 55.8 (C-5), 46.4 (C-10), 42.6 (C-3), 33.8 (C-19), 33.2 (C-11), 32.2
(C-4), 31.6 (C-1), 21.7 (C-18), 21.2 (C-12), 20.0 (C-20), 18.3 (C-17), 17.8 (C-2); HR-ESMS m/z 316.2047
(calculated for C20H28O3, 316.2038).
3.1.3. Preparation of Solidagenone Derivative (2)
To a solution of 55 mg (0.17 mmol) of 1 in 2 mL ethanol, a solution of 15 mg (2 equiv.) of NaBH4
in 2 mL of EtOH was added dropwise at rt. After 2 h stirring, the mixture was acidified with 10%
HCl and extracted with DCM. The organic phase was dried with MgSO4, filtered, and concentrated.
The residue was purified by preparative TLC using hexane/EtOAc 4:1 as the eluent to yield 8 mg
(17% yield) of 2.
1H-NMR (400 MHz)
2.28 (1H, m, H-11), 2.14 (1H, m, H-11), 1.84 (3H, s, H-14), 1.52 (3H, m, H-1, H-2), 1.45 (1H, m, H-1),
1.31 (2H, m, H-3), 1.16 (6H, s, H-15, H-16), 0.96 (3H, s, H-17); 13C-NMR (100 MHz)
198.9 (C-6), 176.0
δ 5.76 (1H, s, H-7), 2.68 (1H, m, H-12), 2.64 (1H, s, H-5), 2.58 (1H, m, H-12),
δ
(C-13), 149.3 (C-8), 130.9 (C-7), 90.0 (C-9), 56.5 (C-5), 44.5 (C-10), 42.1 (C-3), 33.1 (C-16), 32.2 (C-4), 31.5
(C-1), 30.9 (C-12), 23.9 (C-11), 21.6 (C-15), 18.8 (C-17), 18.1 (C-2), 17.5 (C-14); HR-ESMS m/z 299.1623
(calculated for C17H24O3Na, 299.1623).
3.1.4. Preparation of Solidagenone Derivatives (3) and (4)
A solution of 50 mg (0.16 mmol) of
1 in 2 mL of N,N-dimethylaniline was treated with an excess
of AcCl (2 mL) and stirred at rt for 2 h. Then, ice was added and the reaction mixture was extracted
with DCM. The solvent was evaporated and the residue was purified by preparative TLC, using
hexane/EtOAc 4:1 as the eluent, to obtain 7 mg (15%) of compound
3 and 17 mg (37%) of compound 4.
1
Compound
3: H-NMR (400 MHz)
δ
7.33 (1H, br s, H-15), 7.14 (1H, s, H-16), 6.18 (1H, brs, H-14),
6.14 (1H, s, H-7), 2.34 (1H, m, H-1), 2.20 (1H, m, H-1), 1.95 (3H, s, H-17), 1.92 (2H, m, H-12), 1.85 (2H,
m, H-3), 1.63 (2H, m. H-2), 1.47 (2H, m, H-11), 1.32 (3H, s, H-19), 1.30 (3H, s, H-18), 1.20 (3H, s, H-20);
13C-NMR (100 MHz)
δ 185.8 (C-6), 159.8 (C-8), 158.1 (C-10), 142.8 (C-15), 141.1 (C-5), 138.5 (C-16),
130.6 (C-7), 124.2 (C-13), 110.6 (C-14), 46.4 (C-9), 41.5 (C-11), 37.4 (C-3), 33.7 (C-4), 28.4 (C-19), 28.0
(C-18), 27.4 (C-1), 25.4 (C-20), 19.9 (C-12), 19.0 (C-2), 18.9 (C-17); HR-ESIMS m/z 321.1829 (calculated
for C20H26O2Na, 321.1831).

Molecules 2018, 23, 3197
14 of 19
1
Compound
4
: H-NMR (400 MHz)
δ
7.21 (1H, br s, H-15), 6.10 (1H, br s, H-14), 2.73 (1H, d, J = 16.1
Hz, H-7), 2.52 (1H, d, J = 16.1 Hz, H-7), 2.42 (1H, m, H-1), 2.32 (3H, m, H-1, H-12), 1.95 (1H, m, H-11),
1.84 (1H, m, H-11), 1.58 (2H, m, H-2), 1.42 (2H, m, H-3), 1.24 (3H, s, H-19), 1.21 (3H, s, H-18), 1.14 (3H, s,
H-17), 1.06 (3H, s, H-20); 13C-NMR (100 MHz)
δ 196.5 (C-6), 159.2 (C-10), 154.6 (C-5), 154.6 (C-16), 141.1
(C-15), 114.5 (C-13), 109.6 (C-14), 43.5 (C-9), 41.5 (C-3), 41.4 (C-7), 39.7 (C-8), 33.6 (C-4), 30.4 (C-11), 28.8
(C-19), 28.6 (C-18), 28.5 (C-1), 28.5 (C-20), 19.4 (C-12), 19.3 (C-2), 19.2 (C-17); HR-ESIMS m/z 321.1833
(calculated for C20H26O2Na, 321.1831).
3.1.5. Preparation of Solidagenone Derivatives (5) and (6)
A solution of 100 mg (0.32 mmol) of 1 in 3 mL of dry DCM was stirred with 32 µL (2 equiv.) of Br2 at
rt for 15 h. Then, the solvent was evaporated and the residue was purified by preparative TLC, using
hexane/EtOAc 9:1 as the eluent. Two products were obtained: 22 mg (15%) of 5 and 17 mg (11%) of 6.
1
Compound
5
: H-NMR (400 MHz)
δ
6.15 (2H, brs, H-7, H-14), 2.32 (1H, m, H-1), 2.22 (1H, m, H-1),
1.96 (3H, s, H-17), 1.82 (4H, m, H-3, H-12), 1.67 (2H, m, H-2), 1.51 (2H, m, H-11), 1.32 (3H, s, H-19), 1.31
(3H, s, H-18), 1.23 (3H, s, H-20); 13C-NMR (100 MHz)
185.7 (C-6), 159.2 (C-8), 157.7 (C-10), 141.4 (C-5),
δ
130.7 (C-7), 126.2 (C-15), 121.6 (C-13), 119.6 (C-16), 114.5 (C-14), 46.2 (C-9), 41.5 (C-11), 36.8 (C-3), 33.7
(C-4), 28.5 (C-19), 28.0 (C-18), 27.4 (C-1), 25.1 (C-20), 20.6 (C-12), 19.0 (C-2), 18.9 (C-17); HR-ESIMS m/z
477.0034 (calculated for C20H24O2Br2Na, 477.0041).
1
Compound
6
: H-NMR (400 MHz)
δ
6.28 (1H, s, H-14), 4.37 (1H, s, H-7), 3.22 (1H, s, H-5), 2.45
(2H, t, J = 8.7 Hz, H-12), 2.28 (1H, m, H-1), 2.18 (1H, m, H-1), 1.95 (1H, br d, J = 12.2 Hz, H-11), 1.86 (3H,
s, H-17), 1.69 (2H, m, H-2), 1.56 (1H, m, H-11), 1.42 (1H, br d, J = 13.2 Hz, H-3), 1.32 (3H, s, H-18), 1.17
(1H, m, H-3), 1.04 (3H, s, H-19), 0.95 (3H, s, H-20); 13C-NMR (100 MHz)
δ 203.3 (C-6), 147.7 (C-8), 126.4
(C-9), 126.3 (C-13), 121.8 (C-15), 119.6 (C-16), 114.4 (C-14), 57.7 (C-5), 54.9 (C-7), 46.3 (C-10), 41.8 (C-3),
36.1 (C-11), 31.9 (C-4), 31.6 (C-19), 28.8 (C-1), 25.0 (C-12), 22.0 (C-18), 21.5 (C-20), 18.6 (C-2), 17.4 (C-17);
HR-ESIMS m/z 556.9216 (calculated for C20H25O2Br3Na, 556.9302).
3.1.6. Preparation of Solidagenone Derivative (7)
◦
A solution of 100 mg (0.32 mmol) of
1
in 5 mL of dry DCM at 0 C was treated with 0.63 mL
(2 equiv.) of a 1 M solution of BBr3 in DCM. The mixture was stirred for 4 h. Then, the solvent was
evaporated and the residue purified by preparative TLC using hexane/EtOAc 9:1 as the eluent to
1
yield 24 mg (21%) of compound
7
. H-NMR (400 MHz)
δ
7.37 (1H, s, H-15), 7.26 (1H, s, H-16), 6.30
(1H, br s, H-14), 4.38 (1H, s, H-7), 3.23 (1H, s, H-5), 2.55 (2H, t, J = 8.6 Hz, H-12), 2.35 (1H, m, H-1),
2.23 (1H, m, H-1), 1.91 (1H, brd, J = 16.7 Hz, H-11), 1.72 (3H, s, H-17), 1.65 (2H, m, H-2), 1.49 (1H, m,
H-11), 1.41 (1H, brd, J = 12.9 Hz, H-3), 1.32 (3H, s, H-18), 1.17 (1H, m, H-3), 1.01 (3H, s, H-19), 0.96 (3H,
s, H-20); 13C-NMR (100 MHz)
δ 203.5 (C-6), 148.8 (C-8), 142.9 (C-15), 138.5 (C-16), 125.7 (C-9), 124.4
(C-13), 110.6 (C-14), 57.8 (C-5), 55.3 (C-7), 46.3 (C-10), 41.8 (C-3), 36.1 (C-11), 31.9 (C-4), 31.7 (C-19), 29.6
(C-1), 24.6 (C-12), 22.0 (C-18), 21.5 (C-20), 18.6 (C-2), 17.4 (C-17); HR-EIMS m/z 378.1122 (calculated for
C20H27O2Br, 378.1195).
3.1.7. Preparation of Solidagenone Derivative (8)
To a solution of 100 mg (0.316 mmol) of 1 in 5 mL of dry DCM, 92 µL (4 equiv.) of SOCl2 was added
under a dry N2 atmosphere. The mixture was refluxed for 15 h until disappearance of the starting
diterpene. At this point, the mixture was cooled, the solvent was evaporated, and the residue was
purified by preparative TLC using hexane/EtOAc 9:1 as the eluent to obtain 24 mg (25%) of compound
1
8
. H-NMR (400 MHz)
δ
7.37 (1H, brs, H-15), 7.26 (1H, s, H-16), 6.30 (1H, brs, H-14), 4.10 (1H, s, H-7),
3.04 (1H, s, H-5), 2.55 (2H, t, J = 8.5 Hz, H-12), 2.37 (1H, m, H-1), 2.25 (1H, m, H-1), 1.95 (1H, brd,
J = 12.3 Hz, H-11), 1.82 (3H, s, H-17), 1.65 (2H, m, H-2), 1.57 (1H, m, H-11), 1.40 (1H, brd, J = 13.2 Hz,
H-3), 1.32 (3H, s, H-18), 1.17 (1H, m, H-3), 1.02 (3H, s, H-19), 0.97 (3H, s, H-20); 13C-NMR (100 MHz)
δ
203.9 (C-6), 148.5 (C-8), 142.9 (C-15), 138.5 (C-16), 125.5 (C-9), 124.5 (C-13), 110.6 (C-14), 62.6 (C-7), 58.2

Molecules 2018, 23, 3197
15 of 19
(C-5), 46.2 (C-10), 41.8 (C-3), 36.3 (C-11), 31.9 (C-4), 31.8 (C-19), 29.4 (C-1), 24.9 (C-12), 21.9 (C-18), 21.1
(C-18), 18.6 (C-2), 16.6 (C-17); HR-EIMS m/z 334.1694 (calculated for C20H27O2Cl: 334.1700).
3.1.8. Preparation of Solidagenone Derivative (9)
To a solution of 100 mg (0.32 mmol) of
1 in 5 mL of dry THF, 26 mg (2 equiv.) of NaH was added
under a N2 atmosphere. The mixture was refluxed for 15 h, then MeOH was added and the solvent
was evaporated under vacuum. The residue was purified by preparative TLC, using hexane/EtOAc
1
9:1 as the eluent, to yield 19 mg (20%) of compound
9
. H-NMR (400 MHz)
δ
7.39 (1H, brs, H-15), 7.29
(1H, s, H-16), 6.99 (1H, brs, -OH), 6.33 (1H, brs, H-14), 2.65 (1H, m, H-1), 2.57 (3H, m, H-1, H-12), 2.05
(1H, m, H-3), 1.99 (3H, s, H-17), 1.87 (2H, m, H-2, H-11), 1.72 (1H, m, H-2), 1.56 (1H, m, H-3), 1.43 (1H,
m, H-11), 1.39 (9H, brs, H-18, H-19, H-20); 13C-NMR (100 MHz)
δ: 181.6 (C-6), 165.8 (C-7), 143.1 (C-15),
140.4 (C-5), 140.4 (C-10), 138.6 (C-16), 127.3 (C-8), 124.3 (C-13), 110.5 (C-14), 43.8 (C-9), 37.2 (CH2, C-11),
35.6 (C-4), 31.5 (C-1), 29.4 (C-3), 28.0 (C-19), 27.9 (C-18), 27.6 (C-20), 23.7 (C-12), 17.2 (C-2), 11.5 (C-17);
HR-ESMIS m/z 337.1776 (calculated for C20H26O3Na: 337.1780).
3.1.9. Preparation of Solidagenone Derivative (10)
A mixture of 100 mg (0.32 mmol) of
1 in 5 mL of DCM/MeOH 1:1 was hydrogenated in the
presence of a catalytic amount of Pd/C 10% for 15 h. Then, the mixture was filtered and the solvent
was evaporated under vacuum and purified by preparative TLC, using hexane/EtOAc 4:1 as the
eluent, to yield 26 mg (25%) of 10.
1H-NMR (400 MHz),
δ (ppm): 3.92 (1H, m, H-16), 3.87 (1H, m, H-15), 3.76 (1H, dd, J = 15.8, 7.6 Hz,
H-15), 3.36 (1H, dd, J = 15.3, 7.6 Hz, H-16), 2.99 (1H, s, H-5), 2.96 (1H, dd, J = 12.6, 8.0 Hz, H-7), 2.34
(1H, m, H-8), 2.14 (1H, m, H-13), 2.08 (1H, m, H-14), 1.95 (1H, brd, J = 12.6 Hz, H-7), 1.77 (1H, m, H-1),
1.52 (8H, m, H-1, H-2, H-11, H-12, H-14), 1.25 (1H, m, H-3), 1.25 (3H, s, H-18), 1.08 (1H, m, H-3), 1.03
(3H, d, J = 4.3 Hz, H-17), 1.00 (3H, s, H-20), 0.95 (3H, s, H-19); 13C-NMR (100 MHz)
δ: 212.8 (C-6), 77.9
(C-9), 73.3 (C-16), 67.8 (C-15), 57.9 (C-5), 48.7 (C-10), 46.9 (C-7), 42.0 (C-3), 40.9 (C-8), 39.9 (C-13), 32.8
(C-19), 32.6 (C-11), 32.4 (C-14), 32.1 (C-4), 31.1 (C-1), 26.6 (C-12), 21.8 (C-18), 18.8 (C-20), 18.5 (C-17),
17.8 (C-2); HR-EIMS m/z 322.2514 (calculated for C20H34O3, 322.2508).
3.2. Biology
3.2.1. Cell Culture Conditions
Peritoneal macrophages were obtained from Male BALB/c mice free of pathogens (8–10 weeks
old) from Charles River Laboratories. All experimental protocols were reviewed and approved by
the Institutional Committee for Research Ethics and were in accordance with Spanish and European
guidelines legislation.
Four days prior to the assay, mice were injected intraperitoneally (i.p.) with 2.5 mL of thioglycolate
broth. Elicited peritoneal macrophages were obtained as previously described [29]. Cells were seeded
in RPMI 1640 containing 10% fetal bovine serum and 2% penicillin/streptomycin antibiotics.
3.2.2. Determination of NO Production and Cell Viability
Peritoneal macrophages were seeded on a 96-well plate (105 cells/well), stimulated with LPS
(200 ng/mL), and incubated with the compounds for 24 h. Nitrite levels in supernatants were measured
using the Griess reagent (1% sulfanilamide in 5% phosphoric acid and 0.1% naphtylethylenediamine
dihydrochloride). Briefly, 100 µL of supernatant was mixed with an equal volume of Griess reagent
and incubated at room temperature for 10 min. Absorbance was then measured at 540 nm using a
microplate reader (Perkin Elmer Cetus, Foster City, CA, USA) and compared with a sodium nitrite
standard curve.
To identify potential cytotoxicity of the compounds, cell viability was assessed using the MTT
assay. Macrophages were seeded in 96-well plates and incubated with various concentrations of

Molecules 2018, 23, 3197
16 of 19
compounds for 24 h. The MTT solution (5 mg/mL) was added to the cells and the cells were incubated
at 37 ◦C for 4 h. The reaction product, formazan, was extracted with dimethyl sulfoxide (DMSO) and
the absorbance was read at 540 nm. Results are expressed as the percent reduction in cell viability
compared to untreated control cultures for at least three independent experiments.
3.2.3. Western Blot Analysis
Cytosolic extracts were prepared as previously described [29]. Protein content was estimated by
the Bio-Rad protein assay. Protein extracts were subjected to SDS–PAGE (10–15% gels) and blotted
onto polyvinylidene difluoride membranes, which were incubated with the following antibodies: total
MAPKs and phosphorylated forms of p38 and ERK (Cell Signaling Technology); with anti-NOS-2,
anti-IκBα, anti-IκBβ, anti-β-actin, anti-p65, and anti-PSF (Santa Cruz Biotechnology); or with
anti-COX-2 (Cayman Chemical). The blots were then incubated with secondary goat anti-mouse
or rabbit IgG antibodies (Cell Signaling) and developed with ECL according to the manufacturer’s
instructions (GE Healthcare). β-Actin and PSF were used as loading controls.
3.2.4. RNA Analysis and Quantitative PCR
Total RNA was isolated from cells with Trizol reagent (Invitrogen). Quantitative PCR (SYBRgreen)
analysis was performed with an ABI7700 sequence analyzer as described [30]. Each sample was run in
duplicate, and all samples were analyzed in parallel for the expression of the housekeeping gene 36B4
(acidic ribosomal phosphoprotein P0), which was used as an endogenous control for normalization
of the expression level of target genes. Fold induction was determined from mean replicate values.
Primer sequences are available on request.
3.2.5. Protein Preparation and Docking
The X-ray coordinates of human TLR4 in complex with MD-2 and LPS were extracted from
the Protein Data Bank (PDB code 4G8A). The PDB structures were prepared for docking using the
Protein Preparation Workflow (Schrodinger, LLC, New York, NY, 2018) accessible from the Maestro
program (Maestro, version 11.5; Schrodinger, LLC: New York, NY, 2018). The substrate and water
molecules were removed beyond 5 Å, bond corrections were applied to the cocrystallized ligands,
and an exhaustive sampling of the orientations of groups was performed. Finally, the receptors were
optimized in Maestro 11.5 by using the OPLS3 force field before the docking study. In the final stage,
the optimization and minimization of the ligand–protein complexes were carried out with the OPLS3
force field and the default value for RMSD of 0.30 Å for nonhydrogen atoms were used. The receptor
grids were generated using the prepared proteins, with the docking grids centered on the center of
the bound ligand for each receptor. A receptor grid was generated using a 1.00 van der Waals (vdW)
radius scaling factor and 0.25 partial charge cutoff. The binding sites were enclosed in a grid box of
20 Å3 with default parameters and without constrains. The three-dimensional structures of the ligands
to be docked were generated and prepared using LigPrep as implemented in Maestro 11.5 (LigPrep,
Schrodinger, LLC: New York, NY, 2018) to generate the most probable ionization states at pH 7
±
1
(to retain the original ionization state). These conformations were used as the initial input structures
for the docking study. In this stage, a series of treatments were applied to the structures. Finally,
the geometries were optimized using the OPLS3 force field. These conformations were used as the
initial input structures for the docking study. The ligands were docked using the extra precision mode
(XP) [31] without using any constraints and with a 0.80 van der Waals (vdW) radius scaling factor
and 0.15 partial charge cutoff. The dockings were carried out with flexibility of the residues of the
pocket near the ligand. The generated ligand poses were evaluated with the empirical scoring function
GlideScore, a modified version of ChemScore [32]; GlideScore, implemented in Glide, was used to
estimate the binding affinity and ranking of ligands [33]. The XP Pose Rank was used to select the best
docked pose for each ligand. The best correlation with human TLR4 in complex with MD-2 and LPS
inhibition, as well as the best values of docking score, were achieved when the 4G8A was used.

Molecules 2018, 23, 3197
17 of 19
3.2.6. Molecular Dynamics Simulation
The Optimized Potentials for Liquid Simulations-2005 (OPLS2005) [34] force field in the Desmond
Molecular Dynamic System was used in order to study the behavior of the ligand–target complex.
The resulting docking complexes were solvated with a orthorhombic box of TIP3P (Transferable
Intermolecular Potential 3-Point) water [35] and counter ions were added, creating an overall neutral
system simulating approximately 0.15 M NaCl. The ions were equally distributed in a water box.
The final system was subjected to a MD simulation of up to 50 ns using Desmond [36]. The method
selected was NPT (Noose–Hover chain thermostat at 300 K, Martyna–Tobias–Klein barostat method at
1.01325 bar with a relaxation time of 2 ps and isotropic coupling, and a 9 Å radius cutoff was used for
coulombic short-range interaction), and constraints were not applied. During the simulation process,
a smooth-particle Mesh–Ewald method was used to calculate long-range electrostatic interactions.
For multiple time-step integration, RESPA (REversible reference System Propagator Algorithm) was
applied to integrate the equation of motion with Fourier-space electrostatics computed every 6 fs,
and all remaining interactions were computed every 2 fs [37]. MD simulations were carried out on
these equilibrated systems for a time period of 50 ns, and frames of energy and trajectory were captured
every 1.2 ps and 4.8 ps, respectively. The quality of MD simulations was assessed by the Simulation
Event Analysis tool; ligand–receptor interactions were identified using the Simulation Interaction
Diagram tool.
3.2.7. Statistical Analysis
All numerical data were presented as means
±
SD for at least three independent experiments.
Statistical significance was estimated by the Student’s t-test for comparison between two groups.
For comparison between two or more groups, one-way ANOVA followed by Bonferroni’s post-hoc
comparisons were used. Differences were considered significant at * p < 0.05. All statistical analyses
were conducted using GraphPad Prism 5.0 (GraphPad Software, CA, USA). For Western blots, a linear
correlation was observed between increasing amounts of input protein and signal intensity.
4. Conclusions
A series of solidagenone derivatives were semisynthesized. Initial screening for anti-inflammatory
potential in terms of inhibition of NO production and cytotoxicity showed that two compounds
(namely
in peritoneal macrophages. Compound
NOS-2 and COX-2 and cytokine production induced by LPS in macrophages through inhibition of
NF- B and p38 signaling. In addition, this compound also inhibited inflammatory responses mediated
by ligands of TLR2 and TLR3. Docking studies revealed that derivatives and fit very well into
the large hydrophobic binding pocket of MD-2 of TLR-4. Furthermore, molecular dynamics (MD)
simulations showed that was additionally stabilized by hydrogen bonds between the carbonyl group
present in the solidagenone scaffold and the critical polar amino acid residues Ser 120 and Arg 90,
5
and
6) were promising diterpenes. Accordingly, their mechanism of action was studied
5
suppressed the expression of the inflammatory enzymes
κ
5
6
5
which could explain the potency of this derivative. Taken together, our results suggest that diterpene
might be a promising therapeutic agent in drug development for inflammatory diseases.
5
1
Supplementary Materials: H NMR (CDCl3, 400 MHz) and 13C NMR (CDCl3, 100 MHz) of compounds 1–10.
Author Contributions: I.C. contributed to conducting the biological experimental work and drafting of the
manuscript. A.A. carried out the computational studies; J.C.C. and J.C.O. prepared, purified, and characterized
the solidagenone derivatives. A.E.-B., S.H., and B.d.l.H., all corresponding authors, contributed in the conception,
design, discussion of the results, drafting, and financial support of the manuscript submitted. All authors read
and approved the final manuscript for submission to Molecules.
Funding: This research received no external funding.

Molecules 2018, 23, 3197
18 of 19
Acknowledgments: We thank the financial support from the Spanish MINECO (SAF2015-65113-C2-1-R) and
Gobierno Autónomo de Canarias (ProID2017010071). These projects are also cofunded by the European Regional
Development Fund (FEDER). This work was also supported by grants PI11/00036, PI14/00055, and PI17/00012
from Instituto de Salud Carlos III to S.H.
Conflicts of Interest: The authors declare no competing financial interest.
Abbreviations
NO
Nitric oxide
COX-2
NOS-2
LPS
Cyclooxygenase-2
Nitric oxide synthase-2
Lipopolysaccharide
TLRs
Toll-like receptors
NF-κB
MAPKs
Nuclear transcription factor-κB
Mitogen-activated protein kinases
References
1.
2.
Weiss, U. Inflammation. Nature 2008, 454, 427. [CrossRef]
Achek, A.; Yesudhas, D.; Choi, S. Toll-like receptors: Promising therapeutic targets for inflammatory diseases.
Arch. Pharm. Res. 2016, 39, 1032–1049. [CrossRef] [PubMed]
3.
Gordon, S.; Martinez, F.O. Alternative activation of macrophages: Mechanism and functions. Immunity 2010
32, 593–604. [CrossRef]
,
4.
5.
Nathan, C.; Ding, A. Nonresolving inflammation. Cell 2010, 140, 871–882. [CrossRef] [PubMed]
Garantziotis, S.; Hollingsworth, J.W.; Zaas, A.K.; Schwartz, D.A. The effect of toll-like receptors and toll-like
receptor genetics in human disease. Annu. Rev. Med. 2008, 59, 343–359. [CrossRef] [PubMed]
Roy, A.; Srivastava, M.; Saqib, U.; Liu, D.; Faisal, S.M.; Sugathan, S.; Bishnoi, S.; Baig, M.S. Potential therapeutic
targets for inflammation in toll-like receptor 4 (TLR4)-mediated signaling pathways. Int. Immunopharmacol. 2016
40, 79–89. [CrossRef] [PubMed]
Doyle, S.L.; O’Neill, L.A. Toll-like receptors: From the discovery of NFkappaB to new insights into
transcriptional regulations in innate immunity. Biochem. Pharmacol. 2006, 72, 1102–1113. [CrossRef]
[PubMed]
6.
7.
,
8.
9.
O’Neill, L.A.; Golenbock, D.; Bowie, A.G. The history of Toll-like receptors—redefining innate immunity.
Nat. Rev. Immunol. 2013, 13, 453–460. [CrossRef] [PubMed]
de las Heras, B.; Hortelano, S. Molecular basis of the anti-inflammatory effects of terpenoids. Inflamm. Allergy
Drug Targets 2009, 8, 28–39. [CrossRef] [PubMed]
10. Chinou, I. Labdanes of natural origin-biological activities (1981-2004). Curr. Med. Chem. 2005, 12, 1295–1317.
[CrossRef] [PubMed]
11. Gonzalez, Y.; Torres-Mendoza, D.; Jones, G.E.; Fernandez, P.L. Marine diterpenoids as potential
anti-inflammatory agents. Mediators Inflamm. 2015, 2015, 263543. [CrossRef] [PubMed]
12. Lim, J.C.; Chan, T.K.; Ng, D.S.; Sagineedu, S.R.; Stanslas, J.; Wong, W.S. Andrographolide and its analogues:
Versatile bioactive molecules for combating inflammation and cancer. Clin. Exp. Pharmacol. Physiol. 2012, 39,
300–310. [CrossRef] [PubMed]
13. Tran, Q.T.N.; Wong, W.S.F.; Chai, C.L.L. Labdane diterpenoids as potential anti-inflammatory agents.
Pharmacol. Res. 2017, 124, 43–63. [CrossRef] [PubMed]
14. Tan, W.S.D.; Liao, W.; Zhou, S.; Wong, W.S.F. Is there a future for andrographolide to be an anti-inflammatory
drug? Deciphering its major mechanisms of action. Biochem. Pharmacol. 2017, 139, 71–81. [CrossRef]
15. Razmilic, I.; Schmeda-Hirschmann, G. Activity of solidagenone and their semisynthetic derivatives on the
glucocorticoid-mediated signal transduction. Planta Med. 2000, 66, 86–88. [CrossRef] [PubMed]
16. Karaman, R. Proximity vs. strain in intramolecular ring-closing reactions. Mol. Phys. 2010, 108, 1723–1730.
[CrossRef]
17. Lee, K.C.; Chang, H.H.; Chung, Y.H.; Lee, T.Y. Andrographolide acts as an anti-inflammatory agent in
LPS-stimulated RAW264.7 macrophages by inhibiting STAT3-mediated suppression of the NF-kappaB
pathway. J. Ethnopharmacol. 2011, 135, 678–684. [CrossRef]

Molecules 2018, 23, 3197
19 of 19
18. Lee, J.H.; Koo, T.H.; Hwang, B.Y.; Lee, J.J. Kaurane diterpene, kamebakaurin, inhibits NF-kappa B by directly
targeting the DNA-binding activity of p50 and blocks the expression of antiapoptotic NF-kappa B target
genes. J. Biol. Chem. 2002, 277, 18411–18420. [CrossRef]
19. Zhu, T.; Wang, D.X.; Zhang, W.; Liao, X.Q.; Guan, X.; Bo, H.; Sun, J.Y.; Huang, N.W.; He, J.; Zhang, Y.K.; et al.
Andrographolide protects against LPS-induced acute lung injury by inactivation of NF-kappaB. PLoS ONE
2013, 8, e56407.
20. Kawai, T.; Akira, S. The role of pattern-recognition receptors in innate immunity: Update on toll-like
receptors. Nat. Immunol. 2010, 11, 373–384. [CrossRef]
21. Janssen-Heininger, Y.M.; Poynter, M.E.; Baeuerle, P.A. Recent advances towards understanding redox
mechanisms in the activation of nuclear factor kappaB. Free Radic. Biol. Med. 2000, 28, 1317–1327. [CrossRef]
22. Schulze-Osthoff, K.; Ferrari, D.; Riehemann, K.; Wesselborg, S. Regulation of NF-kappa B activation by MAP
kinase cascades. Immunobiology 1997, 198, 35–49. [CrossRef]
23. Barrat, F.J.; Coffman, R.L. Development of TLR inhibitors for the treatment of autoimmune diseases.
Immunol. Rev. 2008, 223, 271–283. [CrossRef]
24. Gao, W.; Xiong, Y.; Li, Q.; Yang, H. Inhibition of toll-like receptor signaling as a promising therapy for
inflammatory diseases: A journey from molecular to nano therapeutics. Front. Physiol. 2017, 8, 508. [CrossRef]
25. Hennessy, E.J.; Parker, A.E.; O’Neill, L.A. Targeting toll-like receptors: Emerging therapeutics? Nat. Rev.
Drug Discov. 2010, 9, 293–307. [CrossRef]
26. Schrodinger: Glide Software, Glide, Version 7; Ed LLC: New York, NY, USA, 2018.
27. Perrin, D.D.; Amarego, W.L.F. Purification of Laboratory Chemicals; Pergamon Press: Oxford, UK, 1988.
28. Hirschmann, G.S. A labdan diterpene from Solidago chilensis roots. Planta Med. 1988, 54, 179–180. [CrossRef]
29. Zeini, M.; Traves, P.G.; Lopez-Fontal, R.; Pantoja, C.; Matheu, A.; Serrano, M.; Bosca, L.; Hortelano, S. Specific
contribution of p19(ARF) to nitric oxide-dependent apoptosis. J. Immunol. 2006, 177, 3327–3336. [CrossRef]
30. Giron, N.; Traves, P.G.; Rodriguez, B.; Lopez-Fontal, R.; Bosca, L.; Hortelano, S.; de las Heras, B. Suppression of
inflammatory responses by labdane-type diterpenoids. Toxicol. Appl. Pharmacol. 2008, 228, 179–189. [CrossRef]
31. Friesner, R.A.; Murphy, R.B.; Repasky, M.P.; Frye, L.L.; Greenwood, J.R.; Halgren, T.A.; Sanschagrin, P.C.;
Mainz, D.T. Extra precision glide: Docking and scoring incorporating a model of hydrophobic enclosure for
protein-ligand complexes. J. Med. Chem. 2006, 49, 6177–6196. [CrossRef]
32. Eldridge, M.D.; Murray, C.W.; Auton, T.R.; Paolini, G.V.; Mee, R.P. Empirical scoring functions: I.
The development of a fast empirical scoring function to estimate the binding affinity of ligands in receptor
complexes. J. Comput. Aided Mol. Des. 1997, 11, 425–445. [CrossRef]
33. Friesner, R.A.; Banks, J.L.; Murphy, R.B.; Halgren, T.A.; Klicic, J.J.; Mainz, D.T.; Repasky, M.P.; Knoll, E.H.;
Shelley, M.; Perry, J.K.; et al. Glide: A new approach for rapid, accurate docking and scoring. Method and
assessment of docking accuracy. J. Med. Chem. 2004, 47, 1739–1749. [CrossRef]
34. Banks, J.L.; Beard, H.S.; Cao, Y.; Cho, A.E.; Damm, W.; Farid, R.; Felts, A.K.; Halgren, T.A.; Mainz, D.T.;
Maple, J.R.; et al. Integrated Modeling Program, Applied Chemical Theory (IMPACT). J. Comput. Chem.
2005, 26, 1752–1780. [CrossRef]
35. Jorgensen, W.L.; Chandrasekhar, J.; Madura, J.D.; Impey, R.W.; Klein, M.L. Comparison of simple potential
functions for simulating liquid water. J. Chem. Phys. 1983, 79, 926–935. [CrossRef]
36. Bowers, K.J.; Dror, R.O.; Shaw, D.E. The midpoint method for parallelization of particle simulations. J. Chem. Phys.
2006, 124, 184109. [CrossRef]
37. Gibson, D.A.; Carter, E.A. Time-reversible multiple time-scale ab-initio molecular-dynamics. J. Phys. Chem.
1993, 97, 13429–13434. [CrossRef]
Sample Availability: Samples of the compounds are not available from the authors.
©
