2746
M. P. Rainka et al.
PAPER
All non-aqueous reactions were performed under an atmosphere of
dry nitrogen unless otherwise specified. Commercial grade reagents
and anhydrous solvents were used as received from vendors and no
attempts were made to purify or dry these components further. Re-
moval of solvents under reduced pressure was accomplished with a
Buchi rotary evaporator using a Teflon-linked KNF vacuum pump.
Data for 1H NMR spectra were obtained on a Bruker AC 300 MHz
NMR spectrometer and are reported in ppm (d) values, using tet-
ramethylsilane as an internal reference. Mass spectroscopic analy-
ses were performed on a PESciex API 150EX mass spectrometer,
using atmospheric pressure chemical ionization (APCI).
1H NMR (300 MHz, CDCl3): d = 1.49–1.78 (m, 4 H), 1.78–1.92 (m,
2 H), 2.47 (s, 1 H), 3.22 (s, 3 H), 3.28–3.36 (m, 2 H), 3.36–3.43 (m,
2 H), 3.61 (s, 3 H), 4.44 (s, 2 H), 7.27–7.38 (m, 5 H).
MS (APCI): m/z = 281 [C16H24O4 + H]+.
5-Benzyloxy-2-(2-methoxyethyl)pentan-1-ol (16)
A solution of methyl 5-benzyloxy-2-(2-methoxyethyl)pentanoate
(15; 112.0 g, 400 mmol) in Et2O (500 mL) was added dropwise over
2 h to a suspension of LiAlH4 (15.2 g, 400 mmol) in Et2O (1.6 L) at
r.t. under nitrogen. The mixture was stirred for 15 h, after which
EtOAc (240 mL) was added dropwise, followed by H2O (160 mL)
and 1 N NaOH solution (240 mL). The organic layer was collected,
dried over Na2SO4, filtered and the solvents were removed under re-
duced pressure to afford 5-benzyloxy-2-(2-methoxyethyl)pentan-1-
ol (16) as a clear colorless oil (100.0 g, 89% yield).
Dimethyl 2-(2-Methoxyethyl)malonate (13)
Dimethyl malonate (12; 100.0 g, 757 mmol) was added dropwise
over 40 min to a solution of NaH (33.3 g, 832 mmol, 60% dispersion
in mineral oil) in THF (500 mL) and DMF (500 mL) at 0 °C under
nitrogen, after which the mixture was warmed to r.t. over 30 min.
The mixture was treated with 1-chloro-2-methoxyethane (76 mL,
832 mmol) followed by KI (138 g, 832 mmol) and the resulting
mixture was heated at 60 °C for 15 h. The cooled mixture was dilut-
ed with H2O (1 L) and extracted with EtOAc (2 × 1 L). The com-
bined organic extracts were washed with brine (500 mL), dried over
Na2SO4 and the solvents were removed under reduced pressure. The
resulting clear yellow oil was distilled under reduced pressure (89–
105 °C/0.10 mm Hg) to afford dimethyl 2-(2-methoxyethyl)mal-
onate (13) as a clear amber oil (101.8 g, 70% yield).
1H NMR (300 MHz, CDCl3): d = 1.27–1.55 (m, 2 H), 1.55–1.79 (m,
5 H), 3.02 (t, J = 7.0 Hz, 2 H), 3.40 (s, 3 H), 3.40–3.67 (m, 4 H),
4.51 (s, 2 H), 7.27–7.38 (m, 5 H).
MS (APCI): m/z = 252 [C15H24O3]+.
5-Benzyloxy-2-(2-methoxyethyl)pentanal (17)
A solution of DMSO (65.9 mL, 928 mmol) in CH2Cl2 (36 mL) was
added dropwise to a solution of oxalyl chloride (40.5 mL, 464
mmol) in CH2Cl2 (1.5 mL) at –70 °C under nitrogen, at a rate which
maintained the internal reaction temperature below –60 °C. The
mixture was then treated with a solution of 5-benzyloxy-2-(2-meth-
oxyethyl)pentan-1-ol (16; 100.0 g, 357 mmol) in CH2Cl2 (300 mL)
at a rate which maintained the internal reaction temperature below
–60 °C. The mixture was stirred at –70 °C for 1 h, after which Et3N
(200 mL, 1.43 mol) was added at a rate which maintained the inter-
nal reaction temperature below –60 °C. The mixture was slowly
warmed to r.t. and washed with H2O (1 L). The aqueous layer was
back-extracted with Et2O (1 × 1 L) and the combined organic ex-
tracts were washed with H2O (800 mL) and brine (800 mL), dried
over Na2SO4, filtered and the solvents were removed under reduced
pressure to produce a yellow oil. The residue was diluted with Et2O
(500 mL), filtered and the filtrate solvents were removed under re-
duced pressure to afford 5-benzyloxy-2-(2-methoxyethyl)pentanal
(17) as a colorless oil (131.0 g, > 99% yield).
1H NMR (300 MHz, CDCl3): d = 2.13–2.27 (m, 2 H), 3.31 (s, 3 H),
3.42 (t, J = 7.0 Hz, 2 H), 3.55 (t, J = 7.0 Hz, 1 H), 3.75 (s, 6 H).
MS (APCI): m/z = 191 [C8H14O5 + H]+.
Dimethyl 2-(3-Benzyloxypropyl)-2-(2-methoxyethyl)malonate
(14)
Dimethyl 2-(2-methoxyethyl)malonate (13; 107.5 g, 640 mmol)
was added dropwise over 30 min to a solution of NaH (23.3 g, 585
mmol, 60% dispersion in mineral oil) in THF (500 mL) and DMF
(500 mL) at 0 °C under nitrogen, after which the mixture was
warmed to r.t. over 30 min. The mixture was treated with 1-(benzyl-
oxy)-2-chloropropane (107.5 g, 640 mmol) followed by KI (96.6 g,
640 mmol) and the resulting mixture was heated at 60 °C for 15 h.
The cooled mixture was washed with brine (1 L) and the aqueous
layer was back-extracted with EtOAc (2 × 500 mL). The combined
organic extracts were washed with brine (500 mL), dried over
Na2SO4, filtered and the solvents were removed under reduced pres-
sure to afford dimethyl 2-(3-benzyloxypropyl)-2-(2-methoxyeth-
yl)malonate (14) as a reddish-orange oil that contained residual
amounts of DMF solvent, but was otherwise suitable for use without
further purification (200.0 g, >99% yield).
1H NMR (300 MHz, CDCl3): d = 1.53–1.70 (m, 4 H), 1.70–1.79 (m,
2 H), 2.37–2.44 (m, 1 H), 3.28 (s, 3 H), 3.39 (t, J = 7.0 Hz, 2 H),
3.48 (t, J = 7.0 Hz, 2 H), 4.48 (s, 2 H), 7.27–7.38 (m, 5 H), 9.58 (s,
1 H).
MS (APCI): m/z = 250 [C15H22O3]+.
2-[4-Benzyloxy-1-(2-methoxyethyl)butyl]-[1,3]dioxolane (18)
A solution of 5-benzyloxy-2-(2-methoxyethyl)pentanal (17; 121.0
g, 484 mmol), ethylene glycol (40.5 mL, 726 mmol) and pyridinium
p-toluenesulfonate (12.0 g, 48 mmol) in benzene (970 mL) was
heated to reflux under nitrogen for 20 h. The cooled mixture was
poured into sat. NaHCO3 solution (1.5 L) and extracted with Et2O
(2 × 1 L). The combined organic extracts were dried over Na2SO4,
filtered and the solvents were removed under reduced pressure to
afford 2-[4-benzyloxy-1-(2-methoxyethyl)butyl]-[1,3]dioxolane
(18) as a yellow oil (109.4 g, 77% yield).
1H NMR (300 MHz, CDCl3): d = 1.43–1.58 (m, 2 H), 1.97–2.06 (m,
2 H), 2.21 (t, J = 7.0 Hz, 2 H), 3.26 (s, 3 H), 3.39 (t, J = 7.0 Hz, 2
H), 3.47 (t, J = 7.0 Hz, 2 H), 3.71 (s, 6 H), 4.48 (s, 2 H), 7.27–7.38
(m, 5 H).
MS (APCI): m/z = 339 [C18H26O6 + H]+.
Methyl 5-Benzyloxy-2-(2-methoxyethyl)pentanoate (15)
A solution of dimethyl 2-(3-benzyloxypropyl)-2-(2-methoxyeth-
yl)malonate (14; 200.0 g, 590 mmol), LiCl (50.0 g, 1.18 mol) and
H2O (100 mL) in DMSO (600 mL) was heated at reflux under nitro-
gen for 22 h. The cooled mixture was diluted with H2O (400 mL)
and extracted with hexanes (3 × 500 mL). The combined organic ex-
tracts were washed with brine (500 mL), dried over Na2SO4, filtered
and the solvents were removed under reduced pressure to afford
dimethyl 5-benzyloxy-2-(2-methoxyethyl)pentanoate (15) as a
clear yellow oil (112.0 g, 67% yield over two steps).
1H NMR (300 MHz, CDCl3): d = 1.53–1.85 (m, 7 H), 3.32 (s, 3 H),
3.38–3.48 (m, 4 H), 3.80–3.91 (m, 2 H), 3.90–3.96 (m, 2 H), 4.45
(s, 2 H), 4.79 (s, 1 H), 7.27–7.38 (m, 5 H).
MS (APCI): m/z = 295 [C17H26O4 + H]+.
4-[1,3]Dioxolan-2-yl-6-methoxyhexan-1-ol (9)2,3
Solid palladium hydroxide on activated carbon (Pearlman’s cata-
lyst, 20% palladium hydroxide on carbon, ~50% wet, 38 g) was
added to a solution of 2-[4-benzyloxy-1-(2-methoxyethyl)butyl]-
[1,3]dioxolane (18; 40.0 g, 136 mmol), cyclohexene (141 mL, 1.36
Synthesis 2006, No. 16, 2743–2747 © Thieme Stuttgart · New York
